Briggs & Stratton 20306 Setup guide

Model No. 020306 (2550 PSI (175.8 BARS) Pressure Washer) Manual No. 203787A Revision - (04/11/2007)
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON, WISCONSIN, U.S.A.
Questions? Help is just a moment away!
Call: Pressure Washer Helpline
1-800-743-4115 M-F 8-5 CT
Illustrated Parts List

2BRIGGSandSTRATTON.COM
Exploded View and Parts List — Main Unit
tem Part # Description
1 202481GS ASSY, Base
2 J199110GS HANDLE
3 202762GS KIT, Bllbrd Assy, w/Decals & Clips
195964GS Clip
30809GS Grommet
4 192529GS KIT, Pump Mounting Hardware
5 B2203GS KIT, Handle Connector
6 202605GS ASSY, Pump
23139GS Key
194298GS Valve, Thermal Relief
7 202483GS KIT, Wheel
201313GS Axle
200520GS Hubcap
192050GS E-Ring
8 202763GS KIT, Cap, Chem Container
9 202017GS HOSE
10 198730GS ASSY, Turbo Max
11 202181GS KIT, Nozzle
201580RGS Nozzle, Project Pro, Yellow
201580XGS Nozzle, Project Pro, Orange
201580AEGS Nozzle, Project Pro, Red
198841GS Nozzle, Plastic, Soap
12 193482GS GUN
13 200595GS EXTENSION
Item Part # Description
14 192310GS KIT, Vibration Mount
15 199229GS ASSY, Tank, Chem
192980GS Kit, Valve
16 195856GS KIT, Wireform
900 NSP ENGINE
Items Not Illustrated:
203787GS MANUAL, Operator’s
BB3061BGS OIL BOTTLE
87815GS GOGGLES
A1040NGS HOSE, Chemical
275034 LABLE, Warning
793943 COVER, Static/Label Assy
200672GS DECAL, Caution, Hearing
202215GS DECAL, Eng, Shroud
195015GS KIT, Tag Warning, Eng/Frnch
Optional Accessories
6039 PUMP SAVER
6048 KIT, O-Ring Maintenance
§ - Contact Engine Manufacturer
Copyright © 2007 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be
reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power
Products Group, LLC.

3
Exploded View and Parts List — Pump
IItem Part # Description
19 190571GS CAP, Oil
28 190627GS MANIFOLD
45 190578GS PIN
62 190581GS CAP, 1/8
76 194298GS THERMAL RELIEF
A 203641GS KIT, UNLOADER STEM
B 190632GS KIT, WATER INLET, ALUM
C 190634GS KIT, OUTLET, ALUMINIUM
D 203631GS KIT, HEAD ALUMINIUM
E 193806GS KIT, CHECK VALVES
F 190592GS KIT, INLET CHECK
G 203640GS KIT, CHEMICAL INJECTION
H 193807GS KIT, SEAL SET
J 189971GS KIT, CHEMICAL HOSE
K 193971GS KIT, PIPE FITTING
L 193972GS KIT, UNLOADER SEAT
Parts Not Illustrated
B2384GS FILTER, Inlet
Optional Accessories
186452GS FILTER, Inlet, Bag of 10
NOTE: Item letters A - L are service kits and include all parts
shown within the box.
