Brighter Magic Matrix User manual

1
Magic Matrix
This product manual contains important information about the
safe installation and use of this projector. Please read and follow
these instructions carefully and keep this manual in a safe place
User manual
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions ............................................................................................. ……………………………..3
2. Technical Specifications ..................................................................................... ……………………………..4
3. How to control the device ................................................................................. ……………………………..5
4. How to control the device with Art-net ............................................................. …………………..13
5. Troubleshooting............................................................................................... ……………………………..13
6. Cleaning the device…..…………………………………………………………………………………………..…………….……….14
Statement
The product has full capability and intact packing when it leaves factory. All the users should
comply with provided warnings and manual. Any damages caused by misuse are not included in
our guarantee. We cannot be responsible for any malfunctions & problems owing to ignoring the
manual.

3
1. Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
Unpack and check carefully there is no transportation damage before using the unit.
Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
The unit is for indoor use only. Use only in a dry location.
The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
Disconnect main power before replacement or servicing.
Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃.
DO NOT touch the housing bare-hands during its operation. Turn off the power and allow about 15
minutes for the unit to cool down before replacing or serving.
In case of serious operating problem, stop using the unit immediately. Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance centre. Always use the same type spare parts.
DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
DO NOT open the unit within five minutes after switching off.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs by
yourself. If your unit requires service, please contact your nearest dealer.
Installation:
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to
avoid vibration and slipping while operating. And make sure that the structure to which you are attaching
the unit is secure and is able to support a weight of 10 times of the unit’s weight. Always use a safety cable
that can hold 12 times of the weight of the unit when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at the safe place where it is not available
for other people.

4
2. Technical Specifications
Light Sources: 25x 4in1 RGBW LED
LENS Beam Angle: 6.5-60°
Power Consumption: 484W
Power Voltage: AC 100-240V, 50/60H
Dimension: 40*31*47CM
Net Weight: 14Kgs
Control
Control Modes: DMX512,Artnet control
DMX mode: 13/ 24/88/113 Channels
Art-net mode : 75/100 channels
Pan/Tilt
Pan/Tilt: infinite rotation
Pan/Tilt Resolution: 8/16 bit
Construction
Display: 180°reversible LCD Display
Data In/Out socket: 3-pin & 5-pin XLR sockets
Powercon in
Protection Rating: IP20
Features
Dimmer:0~100% smooth dimming ; Two dimmers model in optional( delay or without delay)
Outstanding color macro effect
Fast, quiet operation and flicker free
Led temperature protection & Speed of fan run automatic based on the temperature of the head.
Single led control, zoom effect, Art-net control , infinite Pan and tilt rotation.

5
3. How To Control the device
The DMX512 is widely used in intelligent lighting control system. Connect several lights together with a
DMX 512 controller. DMX in and DMX out, 3 pin XLR connectors are: Pin 1: GND, Pin 2: Negative signal (-),
Pin 3: Positive signal (+)
Display:
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions
Set DMX Address Code
1. Press "Menu" to "Set DMX Address", and press "ENTER" key.
2. Show "Set DMX Address DMX Address:001", Press "UP and DOWN" keys to amended.
3. Press "ENTER" key to save and Exit, Press the "MENU" key to exit without saving the changes.

6
Menu:
Address
Address 001~XXX
Set DMX Address
Inf
DMX Value
ALL..
Display DMX
Value
LED Temperature
XXXC/F
Fixture Hours
Current Hours
Total Hours
Last Hours
Ethernet IP
X.X.X.X
IP Address
X.X.X.X
IP Mark
Software Version
VX.X.X…
Software Version
Option Config
Pan Tilt
Pan Reverse
ON/OFF
Tilt Reverse
ON/OFF
Pan-Degree
540/360
Encoder
ON/OFF
Pan Tilt Speed
Speed 1~4
Service
Password
XXXX
Password
Code=123
RDM PID
0-131071
RDM PID
IP Address
Manual Set
Art-Net On IP2
Art-Net On IP10
IP Mask
X.X.X.X
IP Mask
Universe
. OFF, 1-255
Art Universe
LED Address
1-512
LED Address
Source Select
DMX Only
Signal Select DMX
Art-Net
Art
DMX&Art-Net
DMX and Art
Display
Shutoff
2-60 m
Reverse
ON/OFF
Lock On
ON/OFF
Temperature C/F
Celsius
Fahrenheit
Reset Default
ON/OFF
Reset To Factory
Default
Manual Control
Manual
PAN
…….
White All
Password=XXX
……
White All=XXX
Test Channel
PAN
….
White All
Calibration
Password
Password=XXX
PAN
PAN=XXX
Tilt
PAN=XXX

7
ZOOM
ZOOM=XXX
Rotation
Rotation=XXX
Reset
Reset ALL
Reset All Motors
DMX Mode
Standard
Standard Mode
Shape RGB
Shape Mode With RGB
Shape RGBW
Shape Mode With RGBW
DMX&Net RGB
Shape Mode With RGB While DMX&Art-Net select
DMX&Net RGBW
Shape Mode With RGBW While DMX&Art-Net select
1. When DMX mode is DMX&NetRGB or DMX&NetRGBW, DMX&Art-Net under Option
Config /Source select should be selected. LED1-LED25 (RGBW) control by Art-Net,
and the rest controlled by DMX.
2. When DMX Mode set is DMX&NET RGB or DMX&NET RGBW. DMX&Art-Net under
source select was chosen. LED R/G/B/W will be controlled by the Art-Net. LED
address means from which channel begin to control. LED address=10, means
control Red of first LED from channel 10 , channel 11 control Green of first LED,
channel 12 control Blue of first LED, channel 12 control White of first LED, channel
14 control RED of second LED.

8
Mode/Channel
Value
Standard
Shape
RGB
Shape
RGBW
DMX&Net
RGB
DMX&Net
RGBW
1
1
1
controlled by DMX
1
1
PAN Movement 8bit :
0-255
Pan Movement
2
2
2
2
2
Pan Fine 16bit
0-255
Fine control of Pan movement
3
3
3
3
3
TILT Movement 8bit :
0-255
Tilt Movement
4
4
4
4
4
Tilt Fine 16bit
0-255
Fine control of Tilt movement
5
5
5
5
5
Speed Pan/Tilt movement:
0-255
max to min speed
226-255
no function
6
6
6
6
6
PAN Rotation :
0-127
No function
128-189
PAN Rotation Forward min to max speed
190-193
PAN Rotation Stop
194-255
PAN Rotation Reverse min to max speed
7
7
7
7
7
TILT Rotation :
0-127
No function
128-189
TILT Rotation Forward min to max speed
190-193
TILT Rotation Stop
194-255
TILT Rotation Reverse min to max speed
8
8
8
10
10
Zoom :
0-255
Zoom adjustment
9
9
STORBE
0-31
Led trun off
32-63
Led turn on
64-95
Strobe effect slow to fast
96-127
Led turn on
128-159
Pulse-effect in sequences
160-191
Led turn on
192-223
Random strobe effect slow to fast
224-255
Led turn on
10
10
10
10
10
Dimmer intensity:
0-255
Intensity 0 to 100%
11
11
11
11
11
Dimmer Mode:
0-20
Mode1
21-40
Mode2
41-60
Mode3
61-80
Mode4
81-100
Mode5
100-255
Mode1
12
12
12
12
12
LED Gamma:
0-59
Gamma 2.0
60-119
Gamma 2.2
120-179
Gamma 2.4

9
180-239
Gamma 2.6
240-255
Gamma 2.8
13
Rainbow:
0-7
No function
8-39.
RED to YELLOW
40-71
YELLOW to GREEN
72-103
GREEN to CYAN
104-135
CYAN to BLUE
136-167
BLUE to MAGENTA
168-199
MAGENTA to RED
200-231
RED to WHITE
232-255
Crossfading colours from slow to fast
14
Color Presets:
0-4
No function
5--9
White1
10--14
White2
15-19
White3
20-24
White4
25-29
White 5
30-34
White6
35-39
Color1
40-44
Color2
45-49
Color3
50-54
Color4
55-59
Color5
60-64
Color6
65-69
Color7
70-74
Color8
75-79
Color9
80-84
Color10
85-89
Color11
90-94
Color12
95-99
Color13
100-104
Color14
105-109
Color15
110-114
Color16
115-119
Color17
120-124
Color18
125-129
Color19
130-134
Color20
135-139
Color21
140-144
Color22
145-149
Color23
150-154
Color24
155-159
Color25
160-164
Color26
165-169
Color27
170-255
Reserved
15
Color Presets Dimmer:

10
0-255
Dimmer 100 to 0%
16
Chase Patterns:
0-5
No function
6-10
Number'0'
11-15
Number'1'
16-20
Number'2'
21-25
Number'3'
26-30
Number'4'
31-35
Number'5'
36-40
Number'6'
41-45
Number'7'
46-50
Number'8'
51-55
Number'9'
56-60
A
61-65
B
66-70
C
71-75
D
76-80
E
81-85
F
85-90
G
91-95
H
96-100
I
101-105
J
106-110
K
111-115
L
116-120
M
121-125
N
126-130
O
131-135
P
136-140
Q
141-145
R
146-150
S
151-155
T
155-160
U
161-165
V
166-170
W
171-175
X
176-180
Y
181-185
Z
186-190
0'-'9'
191-195
A'-'Z'
196-200
0'-'Z'
201-205
Pattern function1
206-210
Pattern function2
211-215
Pattern function3
216-220
Pattern function4
221-225
Pattern function5
226-230
Pattern function6
231-235
Pattern function7

11
236-240
Pattern function8
241-245
Pattern function9
246-250
Pattern function10
251-255
Pattern function11
17
Chase Patterns Direction:
0-49
↑Chase Up
50-99
←Chase Left
100-149
↓Chase Down
150-255
→Chase Right
18
Chase Speed:
0-125
Fast to Slow Backward
126-130
Stop(Speed=0)
131-255
Slow to Fast Forward
Chase Fade:
0-255
Fade Chase
Red LED -all arrays
0-255
Red ( 0-Black , 255-100% Red )
21
Green LED-all arrays
0-255
Green ( 0-Black , 255-100% Green )
22
Blue LED-all arrays :
0-255
Blue ( 0-Black , 255-100% Blue )
23
White LED-all arrays :
0-255
White ( 0-Black , 255-100% White )
24
13
13
13
13
Lamp on/off, reset, internal programs:
0-79
Normal
80-99
All motor reset
100-255
Normal
controlled by Art.-Net
14
14
1
1
Red LED -array 1
0-255
Red ( 0-Black , 255-100% Red )
15
15
2
2
Green LED-array 1
0-255
Green ( 0-Black , 255-100% Green )
16
16
3
3
Blue LED-array 1
0-255
Blue ( 0-Black , 255-100% Blue )
17
4
White LED-array 1
0-255
White ( 0-Black , 255-100% White )
17
18
4
5
Red LED -array 2
0-255
Red ( 0-Black , 255-100% Red )
18
19
5
6
Green LED-array 2
0-255
Green ( 0-Black , 255-100% Green )
19
20
6
7
Blue LED-array 2
0-255
Blue ( 0-Black , 255-100% Blue )
21
8
White LED-array 2
0-255
White ( 0-Black , 255-100% White )
20
22
7
9
Red LED -array 3

12
0-255
Red ( 0-Black , 255-100% Red )
21
23
8
10
Green LED-array 3
0-255
Green ( 0-Black , 255-100% Green )
22
24
9
11
Blue LED-array 3 :
0-255
Blue ( 0-Black , 255-100% Blue )
25
12
White LED
0-255
White ( 0-Black , 255-100% White )
23
26
10
13
Red LED -array 4
0-255
Red ( 0-Black , 255-100% Red )
24
27
11
14
Green LED-array 4
0-255
Green ( 0-Black , 255-100% Green )
25
28
12
15
Blue LED-array 4
0-255
Blue ( 0-Black , 255-100% Blue )
29
16
White LED-array 4
0-255
White ( 0-Black , 255-100% White )
26
30
13
17
Red LED -array 5
0-255
Red ( 0-Black , 255-100% Red )
27
31
14
18
Green LED-array 5
0-255
Green ( 0-Black , 255-100% Green )
28
32
15
19
Blue LED-array 5
0-255
Blue ( 0-Black , 255-100% Blue )
33
20
White LED-array 5
0-255
White ( 0-Black , 255-100% White )
29
34
16
21
Red LED -array 6
0-255
Red ( 0-Black , 255-100% Red )
30
35
17
22
Green LED-array 6
0-255
Green ( 0-Black , 255-100% Green )
31
36
18
23
Blue LED-array 6 :
0-255
Blue ( 0-Black , 255-100% Blue )
37
24
White LED-array 6:
0-255
White ( 0-Black , 255-100% White )
32
38
19
25
Red LED -array 7
0-255
Red ( 0-Black , 255-100% Red )
33
39
20
26
Green LED-array 7
0-255
Green ( 0-Black , 255-100% Green )
34
40
21
27
Blue LED-array 7 :
0-255
Blue ( 0-Black , 255-100% Blue )
41
28
White LED-array 7:
0-255
White ( 0-Black , 255-100% White )
86
110
73
97
Red LED -array 25:
0-255
Red ( 0-Black , 255-100% Red )
87
111
73
97
Green LED-array 25 :
0-255
Green ( 0-Black , 255-100% Green )
88
112
75
99
Blue LED-array 25 :
0-255
Blue ( 0-Black , 255-100% Blue )
113
100
White LED-array 25:
0-255
White ( 0-Black , 255-100% White )

13
4. How to control the device with Art-Net
1. Setting IP Address, choose Manual set to input IP address manually. You can also choose ON IP2 or ON IP10
auto set.
2. IP Mask, input 255.0.0.0
3. Universe choose OFF or 1
4. Source select, input signal selection, there are three options:
DMX only →input signal is DMX
Art-Net→ input Art-Net signal
DMX &Art-Net→Simultaneous input DMX & Art-Net signal
Notice:
If DMXonly or Art-Net are selected, only Standard or Shape RGB or ShapeRGBW channels modes can be
chosen. Then only DMX or Art-Net signal separately control Pan/Tilt, Dimmer and RGBW, etc.
If DMX&ArtNet is selected, it means simultaneous control by DMX and Art-Net, and Art-Net only control RGBW
Channels, DMX control others channels. Meantime channel modes DMX&ArtnetRGB or DMX&NetRGBW can
be chosen.
For example, if DMX&ArtnetRGB CH Mode is chosen, CH 1 - CH13 are controlled by DMX, RGB matrix is
controlled by Art-Net.
5. When Art-Net or DMX & Art-Net are selected as an input signal, it means that Art-Net
controller will control the unit. But, Art-Net controller also need the same IP address,
IP MARK to be set.
Setting via menu
Information →Ethernet IP →select search fixture’s IP Address, IP MARK information.
5. Troubleshooting
There are a few common problems presented below, that may occur during operation. Here are
some suggestions for easy troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
3. Check the power on LED.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if they are linked properly.
2. If the DMX LED is on and no response to the channel, check the address settings and
DMX polarity.

14
3. If you have intermittent DMX signal problems, check the pins on connectors or on
PCB of the unit or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or alongside to high voltage cables that may
cause damage or interference to DMX interface circuit.
C. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor ’ s drive IC on the PCB might be out of condition.
6. Cleaning the device
Cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output.
Cleaning frequency depends on the environment in which the unit operates: damp, smoky or particularly dirty
surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
