HOW YOUR LEGACY™ & HAMPTON™
SOLAR-POWERED L.E.D. LIGHTS WORK
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
OR
Legacy
Hampton
BEFORE FIRST USE – Pull out to remove the clear plastic strip
with orange sticker in the light fixture to charge battery.
Install your Legacy or Hampton solar lights in direct sunlight and charge for 10-
12 FULL, SUNNY DAYS. The lights will turn on automatically at night. Allow at
least 10-12 cycles (i.e., 10-12 days and nights of charging and discharging) for
the battery to charge to its full capacity.
The rechargeable Ni-Cd battery must be allowed to fully charge to operate
properly. Partially charging the batteries on a consistent basis will drastically
reduce the life of the batteries.
IMPORTANT: The EPA Certified RBRC®
Battery Recycling Seal on the nickel-cadmium
(Ni-Cd) battery contained in our product
indicates The Brinkmann Corporation is
voluntarily participating in an industry program
to collect and recycle these batteries at the end
of their useful life, when taken out of service in
the United States or Canada. The RBRC®
program provides a convenient alternative to
placing used Ni-Cd batteries into the trash or
the municipal waste stream, which may be
illegal in your area. Please call
1-800-8-BATTERY™ for information on Ni-Cd
battery recycling and disposal bans/restrictions
in your area. The Brinkmann Corporation’s
involvement in this program is part of our
commitment to preserving our environment
and conserving our natural resources.
During the day, the solar panel converts sunlight
into electricity and recharges the battery. At
night, the light turns on automatically using the
electricity stored during that day.
The number of hours the light will stay on is
dependent on your geographical location,
weather conditions and seasonal lighting
availability.
Solar lights do not receive as much direct
sunlight in winter months. Therefore, the
number of hours the light will stay on will be
reduced during winter.
INSTR-SLRMAX/Legacy&Hampton-3 2/4/02 11:09 AM Page 4

ASSEMBLY INSTRUCTIONS
Inspect contents of the box to ensure all parts are included and undamaged.
Select a location with full, direct sunlight.
Shady locations will not allow the battery
to charge fully and will reduce the hours of
nighttime light.
NOTE: The rechargeable Ni-Cd battery
must be allowed to fully charge
to operate properly. Partially
charging the battery on a
consistent basis will drastically
reduce the life of the battery.
The selected location should not be near a
nighttime light source such as a porch
light or street light, as these might keep
the solar lights from automatically turning
on. The solar lights should not be placed
closer than 5 feet from one another. This
could cause the solar lights to flicker from
the adjacent light source.
1
2
3
PARTS LIST:
Legacy Light Fixture
OR
Hampton Light Fixture
3-Piece Hanging Hook
Ground Stake
1
2
3
2
1
Legacy
Light
Fixture
Hampton
Light
Fixture
INSTR-SLRMAX/Legacy&Hampton-3 2/4/02 11:09 AM Page 7

3
Step 1
To form a hanger for the solar light,
connect the hook section with one or two
stand sections, depending on the height
desired.
Step 2
Locate an area of solid ground where you
can place your solar lights and insert
ground stake.
Step or press down on ground stake to
aid in driving stake into ground. Make
sure ground stake is inserted all the way
into ground.
NOTE: Ground can be softened by soaking
area with water first.
Step 3
Once ground stake is firmly in place,
insert hanging hook into center hole of
ground stake.
Step 4
Hang light fixture from hanging hook.
The photocell light sensor should point
away from other nighttime light sources.
Step 5
Charge in direct sunlight for 10-12 FULL,
SUNNY DAYS. The light will turn on
automatically at night. Allow at least
10-12 cycles (i.e., 10-12 days and nights
of charging and discharging) for the
battery to charge to its full capacity.
OPERATING INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Ground Stake
Hook Section
Hanging Hook
Ground Stake
Stand Sections
INSTR-SLRMAX/Legacy&Hampton-3 2/4/02 11:09 AM Page 8

4
Top Housing
Lens Battery
Changing Battery
LEGACY SOLAR LIGHT
Step 1
Remove lens from top housing by turning
lens clockwise.
Step 2
With top housing upside down (solar
panel facing down), push tab on battery
compartment lid and remove the lid.
Step 3
Remove battery. Replace with new
Ni-Cd rechargeable battery.
Step 4
Replace battery compartment lid.
Step 5
Attach the lens by aligning the slots
with the grooves in top housing. Turn
counter-clockwise to lock in place.
HAMPTON SOLAR LIGHT
Step 1
Remove hanger from top housing by gently
pulling hanger prongs out of top housing.
Step 2
Remove lens from top housing by turning
lens clockwise.
Step 3
With top housing upside down (solar
panel facing down), push tab on battery
compartment lid and remove the lid.
Step 4
Remove battery. Replace with new
Ni-Cd rechargeable battery.
Step 5
Replace battery compartment lid.
Step 6
Attach the lens by aligning the slots
with the grooves in top housing. Turn
counter-clockwise to lock in place.
Step 7
Replace hanger in top housing by gently
pushing hanger prongs in sides of top
housing.
NOTE: These lights utilize L.E.D. (Light
Emitting Diode) technology. There are
no bulbs to replace.
Top Housing
Battery Compartment Lid
Top Housing
Top Housing
Lens Battery
Hanger Prongs
Hanger
Battery Compartment Lid
IMPORTANT: The EPA Certified RBRC®Battery
Recycling Seal on the nickel-cadmium (Ni-Cd)
battery contained in our product indicates The
Brinkmann Corporation is voluntarily participating
in an industry program to collect and recycle
these batteries at the end of their useful life,
when taken out of service in the United States
or Canada. The RBRC®program provides a convenient alternative
to placing used Ni-Cd batteries into the trash or the municipal
waste stream, which may be illegal in your area. Please call
1-800-8-BATTERY™ for information on Ni-Cd battery recycling and
disposal bans/restrictions in your area. The Brinkmann Corporation’s
involvement in this program is part of our commitment to preserving
our environment and conserving our natural resources.
INSTR-SLRMAX/Legacy&Hampton-3 2/4/02 11:09 AM Page 9

5
It is important that the solar panel is kept free of dirt and debris. A dirty solar panel
will not allow the battery to fully charge. This will shorten the life of the battery and
cause the light to malfunction. Clean regularly with a dampened cloth or paper
towel.
Cleaning
Solar lights can be left outside year round, even in cold weather. However, if you
wish to store your light indoors for more than two or three days, follow these steps
to prevent damage to rechargeable batteries:
• Store at room temperature in a dry location.
• Store solar light where it can receive some sunlight or room light each day.
The battery needs light to maintain a charge during storage.
• During prolonged storage, units must be fully discharged and charged once
every month or remove batteries and replace with new Ni-Cd rechargeable
batteries when ready for use. Check and replace batteries periodically
throughout the year.
• Do not store solar lights in a box, or a dark room without a source of light on
the solar panel. This will damage the batteries and prevent their ability to hold
a charge.
• For best performance, do not store for prolonged periods.
Storage Tips
• Clean snow and debris off the solar panel to allow battery to recharge.
• Check and replace battery periodically throughout the year, especially after
winter months.
Wintertime
Tips
If your solar light does not turn on at night, it may be caused by one the following
conditions:
• Battery is not fully charged or needs replacement:
a. Make sure your light is located in an area where the solar panel gets the
maximum amount of full, direct sunlight every day. Allow sunlight to
recharge the battery for 10-12 FULL, SUNNY DAYS.
b. If the weather has been cloudy or overcast during the day, the battery will
not be recharged for operation at night. The solar light must have direct
sunlight every day to fully charge the battery. If the solar light does not
receive enough sunlight one day, it will recharge the next sunny day and
resume normal operation.
c. Check and replace the battery periodically throughout the year, especially
after winter months. Replacement batteries may be purchased from The
Brinkmann Corporation Customer Service Department by calling
1-800-468-5252.
• Other light sources: If your solar lights are located too close to a street light,
porch light or another solar light, it may not turn on automatically at night. The
built-in photocell light sensor is reacting to the other light source. Eliminate the
other light source or relocate your solar lights.
• Dirty solar panel: A dirty solar panel will not allow the battery to fully charge.
This will shorten the life of the battery and cause the light to malfunction.
Clean regularly with a dampened cloth or paper towel.
After correcting the problem, check the light operation immediately after dark or in
a dark room. If the light will only operate for a short time, the battery needs
recharging.
Troubleshooting
Information
INSTR-SLRMAX/Legacy&Hampton-3 2/4/02 11:09 AM Page 6

For 1-year from date of purchase, The Brinkmann Corporation warrants the Legacy or Hampton solar light against defects due to
workmanship or materials to the original purchaser. The Brinkmann Corporation’s obligations under this warranty are limited to the
following guidelines:
• This warranty does not extend to the L.E.D. or battery.
• This warranty does not cover solar lights that have been altered or damaged due to: normal wear, abuse, improper maintenance,
improper use, disassembly of parts and/or attempted repair by anyone other than an authorized employee of The Brinkmann
Corporation.
• This warranty does not cover surface scratches or weathering as this is considered normal wear.
• Warranty service is limited to repair or replacement of solar lights which prove defective under normal use and which upon
examination shall indicate to Brinkmann’s satisfaction, they are defective. If Brinkmann confirms the defect and approves the
claim, Brinkmann will elect to repair or replace the solar light as covered by the terms of this warranty.
• This warranty extends to the original purchaser only and is not transferable or assignable to subsequent purchasers.
The Brinkmann Corporation requires reasonable proof of purchase. Therefore, we strongly recommend that you retain your sales
receipt or invoice. To obtain repair or replacement of your Legacy or Hampton solar light under the terms of this warranty, please call
Customer Service Department at 1-800-527-0717 for a Return Authorization Number and further instructions. A receipt or proof of
purchase will be required. Solar lights returned to Brinkmann must include your name, address and telephone number. Please
make sure the light is properly packed, postage prepaid, and insured. A Return Authorization Number must be clearly marked on
the outside of the box. Brinkmann cannot be responsible for any solar lights forwarded to us without a Return Authorization
Number.
EXCEPT AS ABOVE STATED, THE BRINKMANN CORPORATION MAKES NO OTHER EXPRESS WARRANTY.
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION TO
1-YEAR FROM THE DATE OF PURCHASE. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
ANY LIABILITY FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE FAILURE OF THE LEGACY OR
HAMPTON SOLAR LIGHT TO COMPLY WITH THIS WARRANTY OR ANY IMPLIED WARRANTY IS EXCLUDED. CUSTOMER
ACKNOWLEDGES THAT THE PURCHASE PRICE CHARGED IS BASED UPON THE LIMITATIONS CONTAINED IN THE WARRANTY SET
OUT ABOVE. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
1-YEAR LIMITED WARRANTY
INSTR-SLRMAX/Legacy&Hampton-3 2/4/02 11:09 AM Page 5

140-2416-0
11/00, 2/02 Owner’s Manual for Models 822-0415-0 & 822-0416-0
822-0415-2 & 822-0416-2
822-0415-4 & 822-0416-4
INSTR-SLRMAX/Legacy&Hampton-3 2/4/02 11:09 AM Page 2
