Brinkmann TIER User manual

TIERTM LIGHT OWNER’S MANUAL
ASSEMBLY AND OPERATING INSTRUCTIONS
ENDURA
™
EXTRA-LONG RUNNING SOLAR POWERED ACCENT LIGHTS
822-0439-6_Tier light Resize 2 4/19/02 5:28 PM Page 1

HOW YOUR TIERTM
SOLAR-POWERED LIGHTS WORK
BEFORE FIRST USE – Pull out to remove the clear
plastic strip with orange sticker in the light
fixture to charge battery.
Install your Tier solar light in direct sunlight and
charge for 10-12 FULL, SUNNY DAYS. The light will
turn on automatically at night. Allow at least 10-12
cycles (i.e., 10-12 days and nights of charging and
discharging) for the battery to charge to its full
capacity.
The rechargeable Ni-Cd battery must be allowed
to fully charge to operate properly. Partially
charging the battery on a consistent basis will
drastically reduce the life of the battery.
During the day, the solar panel converts sunlight
into electricity and recharges the battery. At night,
the light turns on automatically using the electricity
stored during that day.
The number of hours the light will stay on is
dependent on your geographical location, weather
conditions and seasonal lighting availability.
Solar lights do not receive as much direct sunlight
in winter months. Therefore, the number of hours
the light will stay on will be reduced during winter.
1
IMPORTANT: The EPA Certified RBRC®Battery Recycling Seal on the nickel-cadmium
(Ni-Cd) battery contained in our product indicates The Brinkmann Corporation is
voluntarily participating in an industry program to collect and recycle these batteries
at the end of their useful life, when taken out of service in the United States or
Canada. The RBRC®program provides a convenient alternative to placing used Ni-Cd batteries into
the trash or the municipal waste stream, which may be illegal in your area. Please call
1-800-8-BATTERY™ for information on Ni-Cd battery recycling and disposal bans/restrictions in your
area. The Brinkmann Corporation’s involvement in this program is part of our commitment to
preserving our environment and conserving our natural resources.
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
822-0439-6_Tier light Resize 2 4/19/02 5:28 PM Page 2

2
ASSEMBLY INSTRUCTIONS
Inspect contents of the box to ensure all parts are included and undamaged.
Select a location with full, direct
sunlight. Shady locations will not
allow the battery to charge fully and
will reduce the hours of nighttime light.
NOTE: The rechargeable Ni-Cd battery
must be allowed to fully charge
to operate properly. Partially
charging the battery on a
consistent basis will drastically
reduce the life of the battery.
The selected location should not be near
a nighttime light source such as a porch
light or street light, as these might keep
the solar lights from automatically
turning on. The solar lights should not
be placed closer than 5 feet from one
another. This could cause the solar lights
to flicker from the adjacent light source.
PARTS LIST:
Top Housing
Lens
Tier Rings
Ground Stake
Ground Stake Tip
1
2
3
5
4
1
4
5
2
3
822-0439-6_Tier light Resize 2 4/19/02 5:28 PM Page 3

3
Step 1
Working from the bottom of the lens,
place tier ring between the two ridges
near the top of the lens.
Step 2
Place second tier ring between the
two ridges near the bottom of the
lens. Attach the lens by aligning the
slots with the grooves in top housing.
Turn clockwise to lock in place and
set aside until Step 4.
Step 3
Attach the ground stake to the
ground stake tip. Push approximately
3" of the ground stake into the
ground. If the ground is too hard,
soak area with water to soften.
Step 4
Insert light head into ground stake.
The solar panel should be positioned
away from other nighttime light
sources.
Step 5
Charge in direct sunlight for 10-12
FULL, SUNNY DAYS. The light will
turn on automatically at night. Allow
at least 10-12 cycles (i.e., 10-12 days
and nights of charging and
discharging) for the battery to
charge to its full capacity.
OPERATING INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
822-0439-6_Tier light Resize 2 4/19/02 5:28 PM Page 4

4
Changing Battery
It is important that the solar panel
is kept free of dirt and debris. A
dirty solar panel will not allow the
battery to fully charge. This will
shorten the life of the battery and
cause the light to malfunction.
Clean regularly with a dampened
cloth or paper towel.
Cleaning
Step 1
Remove lens from top housing by
turning lens counter-clockwise.
Step 2
With top housing upside down
(solar panel facing down), push tab
on battery compartment lid and
remove lid.
Step 3
Remove battery. Replace with new
Ni-Cd rechargeable battery.
Step 4
Replace battery compartment lid.
Step 5
Attach the lens by aligning the slots
with the grooves in top housing.
Turn clockwise to lock in place.
NOTE:These lights utilize L.E.D. (Light
Emitting Diode) technology.
There are no bulbs to replace.
IMPORTANT: The EPA Certified
RBRC®Battery Recycling Seal on the
nickel-cadmium (Ni-Cd) battery
contained in our product indicates
The Brinkmann Corporation is
voluntarily participating in an industry program to
collect and recycle these batteries at the end of their
useful life, when taken out of service in the United
States or Canada. The RBRC®program provides a
convenient alternative to placing used Ni-Cd
batteries into the trash or the municipal waste
stream, which may be illegal in your area. Please
call 1-800-8-BATTERY™ for information on Ni-Cd
battery recycling and disposal bans/restrictions in
your area. The Brinkmann Corporation’s involvement
in this program is part of our commitment to
preserving our environment and conserving our
natural resources.
Battery Compartment Lid
Top Housing
Lens
Battery
822-0439-6_Tier light Resize 2 4/19/02 5:28 PM Page 5

5
If your solar light does not turn on at night, it may be
caused by one the following conditions:
• Battery is not fully charged or needs replacement:
a.Make sure your light is located in an area where
the solar panel gets the maximum amount of
full, direct sunlight every day. Allow sunlight to
recharge the battery for 10 to 12 FULL, SUNNY
DAYS.
b.If the weather has been cloudy or overcast
during the day, the battery will not be recharged
for operation at night. The solar light must have
direct sunlight every day to fully charge the
battery. If the solar light does not receive enough
sunlight one day, it will recharge the next sunny
day and resume normal operation.
Troubleshooting
Information
Solar lights can be left outside year round, even in
cold weather. However, if you wish to store your light
indoors for more than two or three days, follow
these steps to prevent damage to rechargeable
batteries:
• Store at room temperature in a dry location.
• Store solar light where it can receive some
sunlight or room light each day. The batteries
needs light to maintain a charge during storage.
• During prolonged storage, units must be fully
discharged and charged once every month or
remove batteries and replace with new Ni-Cd
rechargeable battery when ready for use. Check
and replace batteries periodically throughout the
year.
• Do not store solar lights in a box, or a dark room
without a source of light on the solar panel. This
will damage the batteries and prevent their ability
to hold a charge.
• For best performance, do not store for prolonged
periods.
Storage Tips
822-0439-6_Tier light Resize 2 4/19/02 5:28 PM Page 6

• Clean snow and debris off the solar panel to allow
battery to recharge.
• Check and replace battery periodically throughout
the year, especially after winter months.
Wintertime
Tips
6
c.Check and replace the battery periodically
throughout the year, especially after winter
months. Replacement batteries may be
purchased from The Brinkmann Corporation
Customer Service Department by calling
1-800-468-5252.
• Other light sources: If your solar lights are located
too close to a street light, porch light or another
solar light, it may not turn on automatically at night.
The solar panel is reacting to the other light source.
Eliminate the other light source or relocate your
solar lights.
• Dirty solar panel: A dirty solar panel will not allow
the battery to fully charge. This will shorten the life
of the battery and cause the light to malfunction.
Clean regularly with a dampened cloth or paper
towel.
After correcting the problem, check the light operation
immediately after dark or in a dark room. If the light
will only operate for a short time, the battery needs
recharging.
Troubleshooting
Information (Cont.)
822-0439-6_Tier light Resize 2 4/19/02 5:28 PM Page 7

For 1-year from date of purchase, The Brinkmann Corporation warrants the Tier solar light against defects due
to workmanship or materials to the original purchaser. The Brinkmann Corporation’s obligations under this
warranty are limited to the following guidelines:
• This warranty does not extend to the L.E.D. or battery.
• This warranty does not cover solar lights that have been altered or damaged due to: normal wear, abuse,
improper maintenance, improper use, disassembly of parts and/or attempted repair by anyone other than
an authorized employee of The Brinkmann Corporation.
• This warranty does not cover surface scratches or weathering as this is considered normal wear.
• Warranty service is limited to repair or replacement of solar lights which prove defective under normal
use and which upon examination shall indicate to Brinkmann’s satisfaction, they are defective. If
Brinkmann confirms the defect and approves the claim, Brinkmann will elect to repair or replace the solar
light as covered by the terms of this warranty.
• This warranty extends to the original purchaser only and is not transferable or assignable to subsequent
purchasers.
The Brinkmann Corporation requires reasonable proof of purchase. Therefore, we strongly recommend that
you retain your sales receipt or invoice. To obtain repair or replacement of your Tier solar light under the
terms of this warranty, please call Customer Service Department at 1-800-527-0717 for a Return
Authorization Number and further instructions. A receipt or proof of purchase will be required. Solar lights
returned to Brinkmann must include your name, address and telephone number. Please make sure the light is
properly packed, postage prepaid, and insured. A Return Authorization Number must be clearly marked on
the outside of the box. Brinkmann cannot be responsible for any solar lights forwarded to us without a
Return Authorization Number.
EXCEPT AS ABOVE STATED, THE BRINKMANN CORPORATION MAKES NO OTHER EXPRESS WARRANTY. THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN
DURATION TO 1-YEAR FROM THE DATE OF PURCHASE. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
ANY LIABILITY FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE FAILURE OF
THE TIER SOLAR LIGHT TO COMPLY WITH THIS WARRANTY OR ANY IMPLIED WARRANTY IS EXCLUDED.
CUSTOMER ACKNOWLEDGES THAT THE PURCHASE PRICE CHARGED IS BASED UPON THE LIMITATIONS
CONTAINED IN THE WARRANTY SET OUT ABOVE. SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION
MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
1-YEAR LIMITED WARRANTY
140-0439-0
4/02 Owner’s Manual for Model:
822-0439-6
©2002 The Brinkmann Corporation
Dallas, Texas 75244 U.S.A
www.brinkmanncorp.com
