Brinkmann HANGING MISSION User manual

HANGING MISSION™LIGHT
OWNER’S MANUAL
ASSEMBLY AND OPERATING INSTRUCTIONS
ENDURA
™
EXTRA-LONG RUNNING SOLAR POWERED ACCENT LIGHTS
INSTR_Hanging Mission.qxd 12/20/02 10:09 AM Page 1

1
HOW YOUR HANGING MISSION™
SOLAR-POWERED L.E.D. LIGHTS WORK
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
IMPORTANT:
The EPA Certified RBRC®Battery Recycling
Seal on the nickel-cadmium (Ni-Cd) battery
contained in our product indicates The
Brinkmann Corporation is voluntarily
participating in an industry program to
collect and recycle these batteries at the
end of their useful life, when taken out of
service in the United States or Canada. The
RBRC®program provides a convenient
alternative to placing used Ni-Cd batteries
into the trash or the municipal waste
stream, which may be illegal in your area.
Please call 1-800-8-BATTERY™ for
information on Ni-Cd battery recycling and
disposal bans/restrictions in your area. The
Brinkmann Corporation’s involvement in
this program is part of our commitment to
preserving our environment and conserving
our natural resources.
During the day, the solar panel converts sunlight
into electricity and recharges the battery. At night,
the light turns on automatically using the electricity
stored during that day.
The number of hours the light will stay on is
dependent on your geographical location, weather
conditions and seasonal lighting availability.
Solar lights do not receive as much direct sunlight
in winter months. Therefore, the number of hours
the light will stay on will be reduced during winter.
BEFORE FIRST USE – Pull out to remove the clear
plastic strip with orange sticker in the light fixture
to charge batteries.
Your new solar light’s rechargeable Ni-Cd battery is
fully charged and ready for use. Install the solar
light in direct sunlight. For optimum performance,
it is best to charge the solar light for a FULL,
SUNNY DAY. The light will turn on automatically at
night. The Ni-Cd rechargeable battery provides
increased brightness and stays on longer as it
cycles over time (days and nights of charging and
discharging). The more direct sunlight that the light
receives during the day, the brighter and longer the
light will stay on at night.
The rechargeable Ni-Cd battery must be allowed to
fully charge to operate properly. Partially charging
the battery on a consistent basis will drastically
reduce the life of the battery.
INSTR_Hanging Mission.qxd 12/20/02 10:09 AM Page 2

ASSEMBLY INSTRUCTIONS
Inspect contents of the box to ensure all parts are included and undamaged.
1
2
2
Select a location with FULL, DIRECT
SUNLIGHT. Shady locations will not allow
the battery to charge fully and will reduce
the hours of nighttime light.
NOTE: The rechargeable Ni-Cd battery
must be allowed to fully charge
to operate properly. Partially
charging the battery on a
consistent basis will drastically
reduce the life of the battery.
The selected location should not be near a
nighttime light source such as a porch
light or street light, as these might keep
the solar lights from automatically turning
on. The solar lights should not be placed
closer than 5 feet from one another. This
could cause the solar lights to flicker from
the adjacent light source.
3
PARTS LIST:
Mission Light Head Fixture
3-Piece Hanging Hook
Ground Stand
1
2
3
INSTR_Hanging Mission.qxd 12/20/02 10:09 AM Page 3

3
Ground Stand
Hook Section
Hanging Hook
Ground Stand
Stand Sections
Step 1
To form a hanger for the solar
light, connect the hook section
with one or two stand sections,
depending on the height desired.
Step 2
Locate an area of solid ground
where you can place your solar
lights and insert ground stand.
Step or press down on ground
stand to aid in driving stand into
ground. Make sure ground stand
is inserted all the way into
ground.
NOTE: Ground can be softened by
soaking area with water first.
Step 3
Once ground stand is firmly in
place, insert hanging hook into
center hole of ground stand.
Step 4
Hang light fixture from hanging
hook. The photocell light sensor
should point away from other
nighttime light sources.
Step 5
For optimum performance, it is
best to charge the solar light for
a FULL, SUNNY DAY. The light
will turn on automatically at
night. The Ni-Cd rechargeable
battery provides increased
brightness and stays on longer
as it cycles over time (days and
nights of charging and
discharging). The more direct
sunlight that the light receives
during the day, the brighter and
longer the light will stay on at
night.
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
OPERATING INSTRUCTIONS
INSTR_Hanging Mission.qxd 12/20/02 10:09 AM Page 4

Top Housing
Lens
Battery
Changing Battery
Step 1
Remove lens from top housing by turning
lens clockwise.
Step 2
With top housing upside down (solar
panel facing down), push tabs on battery
compartment lid and remove the lid.
Step 3
Remove battery. Replace with new Ni-Cd
rechargeable battery.
Step 4
Replace battery compartment lid.
Step 5
Attach the lens by aligning the tabs with
the slots in top housing. Turn counter-
clockwise to lock in place.
NOTE: This light utilizes L.E.D. (Light
Emitting Diode) technology. There are
no bulbs to replace.
Top Housing
Battery
Compartment Lid It is important that the solar panel is kept free
of dirt and debris. A dirty solar panel will not
allow the battery to fully charge. This will
shorten the life of the battery and cause the
light to malfunction. Clean regularly with a
dampened cloth or paper towel.
Cleaning
IMPORTANT:
The EPA Certified RBRC®Battery
Recycling Seal on the nickel-
cadmium (Ni-Cd) battery
contained in our product indicates
The Brinkmann Corporation is
voluntarily participating in an
industry program to collect and recycle these
batteries at the end of their useful life, when
taken out of service in the United States or
Canada. The RBRC®program provides a
convenient alternative to placing used Ni-Cd
batteries into the trash or the municipal waste
stream, which may be illegal in your area. Please
call 1-800-8-BATTERY™ for information on Ni-Cd
battery recycling and disposal bans/restrictions in
your area. The Brinkmann Corporation’s
involvement in this program is part of our
commitment to preserving our environment and
conserving our natural resources.
4
Tabs
INSTR_Hanging Mission.qxd 12/30/02 10:21 AM Page 5

5
Solar lights can be left outside year round, even
in cold weather. However, if you wish to store
your light indoors for more than two or three
days, follow these steps to prevent damage to
rechargeable batteries:
• Store at room temperature in a dry location.
• Store solar light where it can receive some
sunlight or room light each day. The battery
needs light to maintain a charge during
storage.
• During prolonged storage, units must be
fully discharged and charged once every
month or remove batteries and replace with
new Ni-Cd rechargeable batteries when
ready for use. Check and replace batteries
periodically throughout the year.
• Do not store solar lights in a box, or a dark
room without a source of light on the solar
panel. This will damage the batteries and
prevent their ability to hold a charge.
• For best performance, do not store for
prolonged periods.
Storage Tips
If your solar light does not turn on at night, it
may be caused by one the following conditions:
• Battery is not fully charged or needs
replacement:
a. Make sure your light is located in an
area where the solar panel gets the
maximum amount of FULL, DIRECT
SUNLIGHT every day.
b. If the weather has been cloudy or
overcast during the day, the battery will
not be recharged for operation at night.
The solar light must have direct
sunlight every day to fully charge the
battery. If the solar light does not
receive enough sunlight one day, it will
recharge the next sunny day and
resume normal operation.
Troubleshooting
Information
INSTR_Hanging Mission.qxd 12/20/02 10:09 AM Page 6

6
• Clean snow and debris off the solar panel
to allow battery to recharge.
• Check and replace battery periodically
throughout the year, especially after winter
months.
Wintertime
Tips
c. Check and replace the battery
periodically throughout the year,
especially after winter months.
Replacement batteries may be
purchased from The Brinkmann
Corporation Customer Service
Department by calling
1-800-468-5252.
• Other light sources: If your solar lights are
located too close to a street light, porch
light or another solar light, it may not turn
on automatically at night. The built-in
photocell light sensor is reacting to the
other light source. Eliminate the other light
source or relocate your solar lights.
• Dirty solar panel: A dirty solar panel will not
allow the battery to fully charge. This will
shorten the life of the battery and cause the
light to malfunction. Clean regularly with a
dampened cloth or paper towel.
After correcting the problem, check the light
operation immediately after dark or in a dark
room. If the light will only operate for a short
time, the battery needs recharging.
Troubleshooting
Information
(continued)
INSTR_Hanging Mission.qxd 12/20/02 10:09 AM Page 7

140-2506-0
12/02
For 1-year from date of purchase, The Brinkmann Corporation warrants the Hanging Mission solar light
against defects due to workmanship or materials to the original purchaser. The Brinkmann Corporation’s
obligations under this warranty are limited to the following guidelines:
• This warranty does not extend to the L.E.D. or batteries.
• This warranty does not cover solar lights that have been altered or damaged due to: normal wear,
abuse, improper maintenance, improper use, disassembly of parts and/or attempted repair by anyone
other than an authorized employee of The Brinkmann Corporation.
• This warranty does not cover surface scratches or weathering as this is considered normal wear.
• Warranty service is limited to repair or replacement of solar lights which prove defective under
normal use and which upon examination shall indicate to Brinkmann’s satisfaction, they are
defective. If Brinkmann confirms the defect and approves the claim, Brinkmann will elect to repair or
replace the solar light as covered by the terms of this warranty.
• This warranty extends to the original purchaser only and is not transferable or assignable to
subsequent purchasers.
The Brinkmann Corporation requires reasonable proof of purchase. Therefore, we strongly recommend
that you retain your sales receipt or invoice. To obtain repair or replacement of your Hanging Mission
solar light under the terms of this warranty, please call Customer Service Department at 1-800-527-0717
for a Return Authorization Number and further instructions. A receipt or proof of purchase will be
required. Solar lights returned to Brinkmann must include your name, address and telephone number.
Please make sure the light is properly packed, postage prepaid, and insured. A Return Authorization
Number must be clearly marked on the outside of the box. Brinkmann cannot be responsible for any
solar lights forwarded to us without a Return Authorization Number.
EXCEPT AS ABOVE STATED, THE BRINKMANN CORPORATION MAKES NO OTHER EXPRESS WARRANTY.
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
LIMITED IN DURATION TO 1-YEAR FROM THE DATE OF PURCHASE. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
ANY LIABILITY FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE FAILURE
OF THE HANGING MISSION SOLAR LIGHT TO COMPLY WITH THIS WARRANTY OR ANY IMPLIED
WARRANTY IS EXCLUDED. CUSTOMER ACKNOWLEDGES THAT THE PURCHASE PRICE CHARGED IS
BASED UPON THE LIMITATIONS CONTAINED IN THE WARRANTY SET OUT ABOVE. SOME STATES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
1-YEAR LIMITED WARRANTY
©2002 The Brinkmann Corporation
Dallas,Texas 75244 U.S.A
www.brinkmanncorp.com
INSTR_Hanging Mission.qxd 12/20/02 10:09 AM Page 8
