BRIO CLNLPOU520SCF2 User manual

Water Dispenser
Installation and Operation
Manual
Model No.: CLNLPOU520SCF2

2
Table of Contents
Safety Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Intended Use������������������������������������������������������������������������4
Package Contents � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �4
Indicator Panel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operational Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation ��������������������������������������������������������������������������5
Determine Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Install the Drip Tray and Grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Install the Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connect a Water Bottle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Flush the Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operation���������������������������������������������������������������������������7
Turn the Dispenser On/O. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Dispense Cold Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Dispense Hot Water and Activate Child Safety Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Refill the Water Bottle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Troubleshooting Guide � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �8
Cleaning and Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �9
Use the Self-Cleaning Ozone Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Filter Replacement Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replace the Filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Filter Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warranty��������������������������������������������������������������������������� 11

3
Safety Information
WARNING: To reduce risk of injury and property damage, you must read this entire guide before assembling,
installing, and operating the dispenser.
WARNING: This product dispenses water at very high temperatures. Failure to use properly can cause
personal injury. When operating this dispenser, always exercise basic safety precautions,
including the following:
•Prior to use, this dispenser must be properly assembled and installed in accordance with this
manual.
•For indoor use only. Keep the water dispenser in a dry place away from direct sunlight. Do NOT
use outdoors.
•Install and use only on a hard and level surface.
•Do NOT place the water dispenser in an enclosed space or cabinet.
•Do NOT operate the dispenser in the presence of explosive fumes.
•Only use properly grounded outlets.
•Do NOT use an extension cord.
•Always grasp the plug and pull straight out from the outlet. Never unplug by pulling on the
power cord.
•Do NOT use the dispenser if the cord becomes frayed or otherwise damaged. If the supply
cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
•To protect against electric shock, do NOT immerse cord, plug, or any other part of the
dispenser in water or other liquids.
•Do NOT use this dispenser with water that is microbiologically unsafe or of unknown quality.
•Water dispenser is compatible with 3- or 5-gallon (12- or 19-liter) water bottles.
•Clean up all water spills after loading or unloading water bottles into or from the dispenser.
•Ensure the water dispenser is unplugged prior to cleaning.
•Never allow children to dispense hot water without proper and direct supervision. Always
enable the child safety lock feature to prevent unsupervised use by children.
•Service should be performed only by a certified technician.
•Do NOT clean the dispenser with a water jet. Do NOT install in an area where a water jet could
be used.
WARNING: Keep ventilation openings in the dispenser enclosure or in the built-in structure clear of
obstruction.
WARNING: Do NOT use mechanical devices or other means to accelerate the defrosting process, other than
those recommended by the manufacturer.
•This dispenser should work under environmental temperatures from 39–104 °F (4–40 °C) and
humidity ≤90%.
•Never turn the dispenser upside down or lean it more than 45°.
•After turning o the red hot-water switch and the green cold-water switch, allow the dispenser
to sit idle for 3 minutes before turning on switches again.

4
Intended Use
This dispenser is intended to be used in household and similar applications such as:
• Sta kitchen areas in shops, oces, and other working environments
• Farm houses
• Hotels, motels, and other types of residential environments
• Bed-and-breakfast type environments
• Catering and similar non-retail applications
This dispenser is not intended for use by persons (including children) with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Package Contents
1
2
3
4
5
6
8
10
9
7
13
12
14
15
16
17
19
22
11
23
26
25
24
21
20
18
Part Description
1 Cold water button
2 Room temperature water button
3 Hot water button
4 Indicator panel
5 Cold water tap
6 Room temperature water tap
7 Hot water tap
8 Drip tray
9 Water bottle cabinet
10 Night light
11 Ball valve switch
12 Filter reset switch
13 Bottle adapter
Part Description
14 Water line
15 Bottle adapter tube
16 Sediment filter
17 Carbon block filter
18 Ozone switch
19 Night light switch
20 Green cold-water switch
21 Red hot-water switch
22 Condenser
23 Drain outlet
24 Funnel
25 Drain hose
26 5-Gallon bottle (not included)

5
Indicator Panel Description
1� Power indicator – When illuminated, indicates that the dispenser is on. When
blinking, indicates that the self-cleaning feature is operating.
2� Hot water indicator light – When illuminated, indicates that the dispenser is
heating water.
3� Cold water indicator light – When illuminated, indicates that the dispenser is
cooling water.
4� Bottle indicator light – When blinking slowly, indicates water bottle is empty
and needs to be refilled; when blinking quickly, indicates the filter is about to
expire; and when steadily illuminated, indicates the filter has expired.
Product Dimensions
Height Width Depth
41.4 in. (105.1 cm) 12.2 in. (31.1 cm) 15.6 in. (39.6 cm)
Operational Specifications
CAUTION: This unit dispenses water at temperatures that can cause severe burns. Avoid direct contact
with hot water. Keep children and pets away from unit while dispensing. Never allow children to
dispense hot water without proper and direct supervision. Unplug unit to prevent unsupervised
use by children.
Temperature Tank Capacity Flow Rate
Dispensing Cold Water 37–50 °F (3–10 °C) 1 g (3.6 L) 0.32 gpm (1.2 ipm)
Dispensing Hot Water 176–198 °F (80–92 °C) 0.24 g (1 L) 0.32 gpm (1.2 ipm)
Installation
1� Determine Installation Location
A� Place the dispenser upright, on a hard and level surface.
B� Ensure the dispenser is placed in a cool, shaded setting near a
grounded wall outlet.
NOTICE: Do NOT plug in the power cord until the entire installation
section is completed.
C� Position the back of the dispenser no closer than 20cm (8in) from a wall
and permit free airflow between the wall and water dispenser.
2� Install the Drip Tray and Grid
A� Unwrap the removable drip tray and grid (8) from the packaging
material. Attach the grid to the drip tray, then slide them into the dispenser until securely in place.
1 2 3 4
8

6
3� Install the filters
Twist each filter (parts 16 and 17) clockwise into the filter
housings located inside the dispenser cabinet. The
sediment filter (part 16) goes on the left, the carbon filter
(17) goes on the right.
16
17
4� Connect a Water Bottle
IMPORTANT: To prevent dry heating, do NOT turn the red hot-water and green cold-water switches on the
back of the unit to the On position until you complete the steps in this procedure.
A� Clean the top of your own 5-gallon water bottle (purchased
separately) with a clean cloth and fill with tap water. Use the
funnel (24), if necessary.
B� Open the water bottle cabinet door and feed the bottle adapter
tube (15) into the water bottle. Ensure the bottle adapter tube
hits the bottom of the bottle.
C� Fasten the bottle adapter (13) over the neck of the water bottle
and press securely into place.
13
15
24
13

7
D� Slide the water bottle into the dispenser cabinet and close the
door.
E� Plug the unit into a wall outlet, turn the green cold-water switch
and the red hot-water switch to the On position. Wait 5 minutes
for the water tanks to fill with water before attempting to use the
dispenser.
NOTE: Water will not pump from the bottle until the door is
completely closed.
5� Flush the Filters
Before first use and after replacing the filters each time, open the drain outlet and attach the drain hose, running
the end into a bucket or receptacle. Flush the filters for 5-10 minutes or until the water runs clear. Discard the
water. Remove the drain hose and close the drain outlet.
Operation
IMPORTANT: This unit has been tested and sanitized prior to packing and shipping. During transit, dust and
odors can accumulate in the tank and lines. Dispense and dispose of at least 1 quart of water
prior to drinking any water.
Turn the Dispenser On/O
IMPORTANT: Before you plug the dispenser in and turn on the red hot-water and green cold-water
switches, ensure a bottle is installed.
1� Plug in the dispenser.
2� Press the hot, room temperature, and cold water buttons until water begins to dispense from the taps.
3� To power on the cooling system, flip the green cold-water switch on the back of the unit to the On position.
4� To power on the heating system, flip the red hot-water switch on the back of the unit to the On position.
Dispense Cold Water
NOTE: Please allow approximately 1 hour after turning the green cold-water switch to the On position for
the water to become fully chilled. The cooling light will turn o once the water is completely chilled.
1� Place a drinking glass or container under the tap and press the cold water button on top of the dispenser
to dispense cold water.
2� Release when your container is full.

8
Dispense Hot Water and Activate Child Safety Lock
CAUTION: This unit dispenses water at temperatures that can cause severe burns. Avoid direct contact
with hot water. Keep children and pets away from the unit while dispensing. Never allow children
to dispense hot water without proper and direct supervision. Disable the heating feature by
switching the red hot-water switch to the O position.
NOTE: Water will take approximately 15-20 minutes after switching on to reach its hottest temperature. The
heating light will turn o once the water has been fully heated.
1� This water dispenser is equipped with a child safety feature in order to prevent inadvertent dispensing. To
enable dispensing of hot water, press and hold the red lock button and then place your mug or container
underneath the tap directly beneath the red lock button. Press and hold the hot water button.
2� Release the hot water button once your container is full.
Refill the Water Bottle
CAUTION: Do NOT dispense hot, room temperature, or cold water if the red light is flashing. You could
empty the tanks and cause the dispenser to overheat.
When the bottle indicator light on the front-right of the dispenser flashes red, it is time to refill your water bottle:
1� Open the dispenser cabinet door and slide the empty bottle out of the cabinet.
2� Remove the bottle adapter from the empty bottle and let the bottle adapter tube drip into the bottle. Once
dripping has stopped, place the bottle adapter on the hanger.
3� Follow the steps in Connect a Water Bottle, on page 6.
Troubleshooting Guide
Refer to the table below for possible problems and their solutions.
Problem Solution
The cold water is not cold.
• It takes approximately one hour after setup to dispense cold water.
• Make sure the power cord is properly connected to a working outlet.
• Language is confusing. Change to: Make sure the dispenser is at least 8 in.
(20 cm) from all walls, especially the back wall, and that there is free airflow
on all sides.
• Make sure green cold-water switch on back of dispenser is in the On position.
• If water still isn’t cold, call customer service at [phone] for assistance.
The hot water is not hot.
• It takes 15-20 minutes after setup to dispense hot water.
• Make sure the power cord is properly connected to a working outlet.
• Make sure red hot-water switch on back of dispenser is in the On position.

9
Problem Solution
The nightlight is not working.
• Make sure the power cord is properly connected to a working outlet.
• Make sure the night light power switch on back of dispenser is in the On
position.
The dispenser is noisy.
• Ensure the dispenser is located on a hard, level surface.
• The heating tube may be generating a slight sound. This is normal.
The bottle is leaking.
• Ensure the bottle is installed correctly.
• Check to see if the bottle is cracked or broken. If so, replace the bottle with a
new one.
The dispenser is not
dispensing water.
• Check to see if the bottle is empty and refill if necessary.
• There may still be air in the tank. Press and hold the water buttons to remove
air until water begins to flow.
Cleaning and Maintenance
Task Frequency Instruction
Sanitizing Every 3
months
Use a disinfectant, purchased separately, and follow directions from
manufacturer for proper amount to use.
Removing
mineral
deposits
Every 6
months
Mix 1 gallon (4 liters) of water with 7 oz (200 g) of citric acid crystals. Remove
top of dispenser and pour solution directly into water tank. Allow some
solution to flow out of tap. Turn on red hot-water switch on the back of the
unit and allow water to heat for about 10 minutes. After 30 minutes, drain the
liquid by unplugging the drain outlet on the back of the dispenser, attaching
the drain hose and threading the end into a receptacle. Then flush the tank
with fresh water, allowing it to dispense in the same manner. Repeat flushing
process 1 or 2 times more.
Cleaning the
water pump
Every 6
months
Mix 1/3 a bucket of water and 1.8 oz (50 g) of citric acid crystals. Remove top
of dispenser and pour solution directly into water tank. Turn o ball valve
switch and remove drain plug on back of dispenser. Press cold water paddle
until the water bottle pump begins to work. Extract the citric-acid mixture for 5
minutes through the back drain outlet. Then allow clean water to drain for 5-10
minutes. Replug drain and turn on the ball valve switch.
Use the Self-Cleaning Ozone Feature
It is highly recommended that you use the self-cleaning feature on a weekly basis to sanitize tanks and water
lines. To activate the self-cleaning cycle, press the ozone switch, hold for 5 seconds, then release.
During the cleaning cycle, ozone is produced and injected into the water system. This ozone kills bacteria and
biofilms typically found in water dispensers. By the time the cleaning cycle ends, the ozone is converted to
harmless oxygen and emitted into the air.
IMPORTANT: The cycle takes 90 minutes to complete. During this time do not dispense and drink the
water. Doing so may result in an odd taste. For your convenience, we recommend that you do
this during a period when the dispenser is not in use, such as overnight hours or when sta is
away from the oce. During the cleaning cycle you may smell a faint trace of ozone.

10
Filter Replacement Schedule
Filter Type Replacement Schedule Function
Sediment 6 months or 950 gallons Performs a coarse filtration of original water. Removes mud,
sand, iron, rust, suspensions, and impurities.
Carbon 6 months or 950 gallons Reduces chlorine, taste and odor, lead, and cysts.
Replace the Filters
IMPORTANT: Only replace the filters with new filters designed for this dispenser. Any other type of filter will
damage the machine and void any warranty.
When a filter is approaching the end of its life (around 5 1/2 months), the red bottle-indicator light starts to blink
quickly. When the filter has reached the end of its life (around 6 months), the red bottle-indicator light remains
steadily illuminated.
To change the filters:
1� Remove the old filters by twisting counterclockwise. Attach new
filters by twisting clockwise. Ensure the sediment filter is on the
left and the carbon block filter is on the right.
2� To flush your new filters, follow the instructions in Step 5 - Flush
the Filters, page 7.
3� Press the filter reset switch (12) 3 times until the red indicator
light turns o.
Filter Specifications
Sediment Filter Carbon Filter
(Sediment, Dirt, and Rust Removal) (Taste and Odor Removal)
Filter Capacity 950 Gallons Filter Capacity 950 Gallons
Flow Rate 0.8 GPM Flow Rate 0.8 GPM
Suggested PSI 14.5—58 psi Suggested PSI 14.5—58 psi
Temperature 33—100 °F Temperature 33—100 °F
Care and Maintenance
• Keep this dispenser in a dry and cool place. Avoid placing in direct sunlight.
• Never set the dispenser on paper or foam, which may store water and cause creepage. Never put anything
flammable beside a foam or paper surface.
• Do not use the dispenser outdoors or in a place that can be splashed by water.
• If the dispenser is not in use for longer than a 24-hour period, turn o the red hot-water and green cold-
12

11
water switches to save power, and drain any remaining water.
• Clean your cabinet, controls, bottle adapter tube, and water taps each time you change or refill your water
bottle. Use a soft, clean cloth and a food-grade sanitizer or bleach.
• Empty and clean the drip tray and grid as needed.
Warranty
Brio (“Vendor”) warrants to the original purchaser of the Brio Water Coolers (the “Product”), and to no other
person, that if the Product is assembled and operated in accordance with the printed instructions accompanying
it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free from defects in
material and workmanship. This Limited Warranty shall be limited to repair or replacement of parts, which prove
defective under normal use and service and which Vendor shall determine in its reasonable discretion upon
examination to be defective. To take advantage of this Limited Warranty, please follow these steps:
1. Please retain your sales slip or invoice, as Vendor may require reasonable proof of your date of purchase.
2. Contact Vendor’s Customer Service Department using the contact information listed below.
3. Return parts to Vendor, per Vendor’s instructions, at your cost and expense.
4. Upon receipt by Vendor, Vendor shall advise you in writing whether a defect covered by this Limited Warranty
exists in any returned part and whether your claim has been approved or denied.
5. Upon Vendor’s approval of your claim, Vendor will replace such defective part without charge to you.
WHAT THIS LIMITED WARRANTY DOES NOT COVER: This Limited Warranty does not cover any failures
or operating diculties of the Product due to accident, abuse, misuse, alteration, misapplication, improper
installation or improper maintenance or service by you or any third party, or failure to perform normal and routine
maintenance on the Product, as set out in the User’s Manual. In addition, this Limited Warranty does not cover
damages to the finish, such as scratches, dents, discoloration, or rust after purchase.
This Limited Warranty is the only express warranty given on the Product and is in lieu of all other express
warranties. Vendor disclaims all warranties for products that are purchased from seller other than authorized
retailers or distributors. THIS LIMITED WARRANTY RESTRICTS THE DURATION OF ANY AND ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION, THE IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE TO THE ONE (1) YEAR TERM OF THIS LIMITED WARRANTY. UPON THE
EXPIRATION OF THE ONE (1) YEAR TERM OF THIS LIMITED WARRANTY, VENDOR DISCLAIMS ANY AND ALL
IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, THE PRODUCT BEING THUS SOLD AS-IS, WITH ALL FAULTS.
FURTHER, VENDOR SHALL HAVE NO LIABILITY WHATSOEVER TO PURCHASER OR ANY THIRD PARTY
FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. OTHER THAN THIS
LIMITED WARRANTY, THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE
FACE HEREOF. Vendor assumes no responsibility for any defects caused by third parties. This Limited Warranty
gives you specific legal rights, and you may have other rights which vary from state to state. State law may also
override statements in this Limited Warranty regarding the restriction on the duration of implied warranties.
Some jurisdictions do not allow exclusion or limitation of special, incidental or consequential damages, or
limitations on how long awarranty lasts, so the above exclusion and limitations may not apply to you.

©2020 DTWUSA
Contact Us
Call: [phone]
