Bristan Opac TS1503 Mounting instructions

Please keep this booklet for future
reference.
Installer, when you have read these
instructions please ensure you leave
them with the user.
Installation Instructions
and User Guide
Opac TS1503 Thermostatic
Shower Valves

Contents
• Important Safety Information 3
• Specification 4
• Pack Contents 5
• Installation Requirements 6-8
• Prior to Installation 9-10
• Installation 11-12
• General Cleaning 13
• Operation 13
• Maintenance 14-16
• Troubleshooting 17
• Notes 18-19
2Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Contents
Thank you for choosing Bristan, the UK’s leading taps and showers expert. We have
designed this product with your enjoyment in mind. To ensure that it works to its
full potential, it needs to be fitted correctly. These fitting instructions have been
created to give you all of the information you need and, if you need any further help,
please do not hesitate to give us a call on 0330 026 6273.

Please make sure you read these instructions and retain for future use.
All products manufactured by Bristan are safe, providing they are installed and used
correctly and also receive maintenance when needed.
These fittings, including the connecting water and waste system need to be installed
in accordance with and meet the requirements of the Water Supply Regulations 1999
(Water Fittings) and current by-laws. If you are in doubt about your ability to install
this product correctly or safely, you should employ the services of an experienced
qualified plumber.
This product must not be modified in any way otherwise this will invalidate the
guarantee. Remove all packaging and check the contents for damage before starting
installation.
Warning: Before installing the new mixer valve it is essential that you thoroughly
flush through the pipework in order to remove any remaining swarf,
solder, etc. Failure to carry out this procedure could cause problems or
damage to the workings of the mixer tap.
Fitting isolating valves to the inlet feeds is required for ease of maintenance.
Warning: Do not operate the mixer if you suspect it is frozen. Do not site the mixer
valve where it might be subjected to freezing conditions.
Consider the following whilst using power tools:
• Prior to drilling into walls, check there are no hidden electrical cables or
wires and there are also no water pipes. These can potentially be found
using an electrical or metal detector. You may also need to know some
of the schematics of previous installations to determine the suitability
and accommodation of the installation.
• Wear the correct PPE, especially ear, eye and hand protection
when using power tools. Unplug any mains equipment after use.
• Keep electrical equipment away from sources of water.
• If a blow-lamp is used when plumbing, the flame must be kept well away from
the product otherwise damage may occur.
If in doubt, contact a registered plumber, your Local Water Authority or the
Secretary of The Institute of Plumbing, address as follows;-
The Institute of Plumbing,
64 Station Lane,
Hornchurch,
Essex, RM12 6NB
Tel:[phone]
3
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Important Safety Information

Supply Requirements:
Minimum cold water
supply temperature: 5°C.
Maximum cold water
supply temperature: 25°C.
Maximum hot water
supply temperature: 80°C.
(a maximum hot water supply
temperature of 60 – 80°C is
recommended for ablutionary purposes).
Note: The inlet hot water temperature
must be at least 10°C above the
required blend temperature (e.g. shower
temperature 43°C: minimum hot supply
53°C.
These showers are designed to be used
in conjunction with the kit supplied, or
Bristan shower kits where not supplied.
We cannot guarantee compatability or
adequate performance when used with
other kits. This would also invalidate your
guarantee. Please refer to the installation
manual supplied with your Bristan
shower kits for their specification
information.
This shower valve must be installed
in compliance with current water
regulations. If you have any doubts
about the water regulation requirements
contact your local water services
provider or use the services of a
professional plumber.
Inlet Connections: 15mm compression
connections.
OP TS1503 SCL C – 125-132mm adjustable
centres.
TS1503ECP-2000-MK - 138-145mm
adjustable centres.
Outlet Connections: Top or bottom G ½”
BSP male, 15mm compression adaptor.
Operating Pressure Range:
Min: 0.1 bar – Max: 5.0 bar
Maximum recommended imbalance
between hot and cold supply should not
exceed a ratio of 5:1.
Maximum Static Pressure: 10.0 bar
Maximum Outlet Temperature: Factory
pre-set to 43°C (can be re-set to suit site
conditions). If the temperature is re-set
to suit dierent site conditions the valve
will work adequately however the TMV3
scheme will not apply.
TMV Type 3 Designation:
HP-SE; LP-S
4Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Specification

OP TS1503 SCL C
TS1503ECP-2000-MK
*a separate flow control
will be required in order
to use this product.
x1
x1
x1
x1
x1
x1
x1
x1
x2
x2
x2
x2
x2
x3
x3
5
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Pack Contents

Gravity Fed Hot and Cold Gravity Fed Hot and Mains Cold
This shower valve is suitable for use with
the following water supply systems:
• Gravity Fed Hot and Cold
(pressure imbalance should not exceed
a ratio of 5:1 - see Specification section)
• Gravity Fed Hot and Mains Cold
(pressure imbalance should not exceed
a ratio of 5:1 - see Specification section)
• Instantaneous water heater
(combination boiler)
• Unvented System
• Pumped System
Important: If you install this
shower valve with a gravity
fed system, there must be a
minimum head (vertical
distance) from the underside
of the cold water storage tank
to the outlet of at least 1 metre
Note: Pumped system (with Essex flange)
If you install this shower valve to a pumped
gravity fed system where the minimum
head (vertical distance) from the underside
of the cold water storage tank to the top
of the hot water cylinder is less than 1
metre we recommend an Essex flange is
used as shown.
Flushing Pipe-work
Important: Before connecting
the shower valve, the supply
pipe-work must be flushed
to clear debris before
connecting the shower.
Debris will reduce the
performance and life
of the mixer.
cold mains supply
1m min.
cold mains supply
1m
min.
Key: Isolating
Valve
Reducing
Valve
Shower
Valve Pump Essex
Flange
6Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Installation Requirements

Unvented System
Instantaneous Water Heater
Pumped System
cold mains supply
cold mains supply
cold mains supply
Pumped System (with Essex flange)
cold mains supply
1m min.1m min.
50mm
If less
than
1m see
note.
Key: Isolating
Valve
Reducing
Valve
Shower
Valve Pump Essex
Flange
7
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Installation Requirements

This fitting needs to be installed in
accordance with the following Installation
Requirements and Notes (IRN) to ensure
they meet the requirements of the Water
Supply (Water Fittings) Regulations 1999
and the Scottish Byelaws 2004.
IRN R001: See text of entry for
Installation Requirements or Notes.
IRN R040 - Schedule 2-15 (1): The
fitting shall be installed so that its outlet
discharges above the spill-over level of
any fixed appliance as indicated below:-
For backflow protection in domestic or
installations up to, and including, Fluid
Category 3.
If the fitting cannot be installed as
indicated in the table opposite it shall be
installed as either a or b below:
a: with an approved double check valve
assembly or some other no less eective
backflow prevention device immediately
upstream of the inlet.
b: so that it draws water by gravity
only from a cistern, or cylinder having
a permanently open vent pipe, and
the distributing pipe supplies no other
fittings (other than a draining tap) at a
lower level.
For backflow protection in premises or
installations up to, and including Fluid
Category 5.
The vertical distance of the outlet above
the spill-over level shall be not less than
20mm or twice the diameter of the inlet
pipe to the fitting, which ever is the
greater. If the fitting cannot be installed
as indicated it shall be installed with
a backflow prevention arrangement
suitable for the Fluid Category.
Size of tap or
combination fitting
Vertical distance
of outlet above
spill-over level
1. Not exceeding ½” 20mm
2. Exceeding ½”
but not
exceeding ¾”
25mm
3. Exceeding ¾” 70mm
8Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Installation Requirements

Supply System Flow Regulator Comments
Hot Supply Cold Supply Hot Supply Cold Supply
0.1 - 1.0 bar 0.1 - 1.0 bar Not Required Not Required
Maximum pressure
loss ratio 5:1 between
inlets
1.0 - 5.0 bar
or pumped
1.0 - 5.0 bar
or pumped Yellow (5 litre) Green (7 litre)
Optional, can be used
if water economy
is required
Gravity Fed
0.1 - 0.2 bar
Mains 1.0 - 10
bar
Not Required White Insert No washer required.
Gravity Fed
0.3 - 0.5 bar Not Required Green (7 litre)
Gravity Fed
over 0.5 bar Yellow (5 litre) Green (7 litre)
Unvented
Mains/ Mains
Pressurised
Yellow (5 litre) Green (7 litre)
Instantaneous
Water Gas
Heater
Yellow (5 litre) Green (7 litre) Adjust Bottom Cap -
1/2 turn anti-clockwise
Instantaneous
Water Electric
Heater
Not Required Yellow (5 litre)
Adjust Bottom Cap -
1/2 turn anti-clockwise
It is a requirement that
a stable flow of water
passes through the
heater. This can be
achieved by fitting a
flow stabiliser before
the heater. The heater
temperature should
also be adjusted
to 45-50°C
Any vented
(open outlet)
Heater
Gas/Electric
e.g.
Electric
Shower
Do not use mixer valves with this type of water system;
this would be extremely dangerous!
Flow regulators have been pre-fitted to this product for water eciency.
If you have low water pressure, or certain water supply systems these may need to be
removed in order to achieve adequate flow. Please see the table to check whether the
flow regulators need to be removed.
9
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Prior to Installation

1. Unscrew both inlet elbows
anti-clockwise from the
valve body.
2. Remove the flow regulators
using long-nosed pliers.
3. Screw the inlet elbows
clockwise to fit back into
the valve body.
The bottom cap is factory set at
3/4 turn from the fully closed position.
Only adjust if instructed to do so in
the table on page 9 or when fitting a
replacement cartridge assembly.
Remove mixing valve from backplate (see
Installation). Peel o label to reveal bottom
cap, with a marker pen, mark a point in-line
with the slot. Turn an extra 1/2 turn (180°)
turn using a screwdriver.
The elbows of the shower can be rotated
to fit pipework from the top or bottom.
To prepare the shroud, there are guide
lines inside the front half of the shroud
which can be cut. DO NOT cut to the
edge of the shroud or it will not be
able to be fitted. Use the rubber
bungs as a guide.
Use a file to remove all burrs and rough
edges. Push through the rubber bungs
to fit to the shroud.
To Remove/Replace Flow Regulators:
Adjusting the Bottom Cap:
Shrouded Top/Bottom Feed Pipework (OP TS1503 SCL C only):
Flow Regulator
Bottom Guides
Top Guides
Rubber
Bungs
White Insert
10 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Prior to Installation

1. Prepare the 15mm water pipework,
leaving sucient pipe protruding
from the finished wall to fit
into the elbows.
Flush through the pipework
to ensure removal of any debris.
Turn o the mains water supply
and close any isolating valves.
Important: Water supplies to the mixer
must be with hot on the left and cold on
the right when viewed from the front.
2. Measure the centre distance. Measure
the half-way point between the centres
and mark on the wall.
3. Configure the inlet elbows to
meet the centre distance. Check the
Specification page for measurements.
Centre Distance
Hot Cold
Backplate
Fixing
Holes
REMEMBER
Fit isolation
valves to pipe-
work for future
maintenance.
1. Unscrew both inlet elbows
anti-clockwise from the valve body.
2. Screw in the desired elbows clockwise
for two complete turns to fit. This will
set to largest possible centre
measurement.
3. The elbows can be screwed a maximum
of 1.5 turns after fitting for adjustment.
Screw further clockwise to reduce the
centre measurement; anti-clockwise to
increase.
To Adjust Elbows:Configuring the Inlet Elbows:
The shower valve is supplied with two
adjustable elbows. The elbows can be
pointed to feed from the top, bottom
or rear.
Two full turns are required to fit the
elbows into the body properly.
This will fit the elbows at their
maximum centre distance.
OP TS1503 SCL C – 125-132mm adjustable
centres.
TS1503ECP-2000-MK - 138-145mm
adjustable centres.
11
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Installation

4. Undo the grub screws at the back of the
shower valve to remove the backplate.
Place the backplate on the marked
half-way point between the centres
and mark the fixing holes
5. Drill the fixing holes using a suitable drill
bit. A pilot drill will be required if drilling
into tiles. Insert the wall plugs and screw
the backplate to the wall.
Warning: Please check for any hidden
pipes and cables before
drilling holes into the wall.
6. Place the plinths over the water
supply pipes (TS1503ECP-2000-MK
only). Feed the shower valve on to the
water supply pipes and tighten with the
nuts and olives. Secure the valve to the
back plate using the grub screw.
7. OP TS1503 SCL C only: Use a hex key
to remove the handle from the valve.
Slide on the shroud cover until in clips
into the backplate. Secure in place with
the grub screws. Re-fit the handle in the
same position and secure with the
grub screw.
Please refer to your specific shower kit instructions, or shower contents
sheet if a kit is supplied to install the shower kit. If your shower needs to follow the
TMV scheme, please refer to the TMV Manual to commission your shower.
TS1503ECP-2000-MK
OP TS1503 SCL C
12 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Installation

Bristan products are made from
premium materials, with hand polished,
PVD, EPD or electroplated finishes.
Your product should be regularly cleaned
with warm water, a mild pH-neutral liquid
soap, and polished with a soft cloth.
Any residues from soap, toothpaste,
shampoos and shower gels can cause
blemishes if not rinsed o straight
after use.
Household bleaches and cleaners
contain harsh chemicals and may damage
the surface finish. Avoid using abrasive
cloths, scouring pads, scrub sponges,
steel wool or anything similar.
Some surfaces such as nickel and pewter
may be aected by the dye found in some
cloths, so it is also important to avoid
hanging cloths on surfaces.
Spare Parts
Visit www.bristan.com or scan the
QR Code and search for your product
code to find all the spares available
for your shower.
Cold
Hot
Increase
Temperature
and Flow
A separate flow control is
required for this product
TS1503ECP-2000-MK OP TS1503 SCL C
13
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
General Cleaning
Operation

Use a 30mm socket spanner to unscrew
the cartridge from the valve body.
Carefully remove the cartridge and spring.
Reverse the steps to re-fit
the cartridge and handle.
Reset the maximum temperature.
Remove all seals and check for any
damage. Place the cartridge in a
suitable solution and soak until fully
de-scaled. Rinse thoroughly.
Replace all seals and grease
with a WRAS approved sealant.
Undo the grub screw to
remove the handle. This can
be located at the top or underneath
the handle. Unscrew the cartridge
shroud if necessary.
Replace/Clean Cartridge:
Sequential Shower Valves:
1
3 4
2
123
IMPORTANT
Isolate the
water supply
before starting!
14 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Maintenance

2
3
Using the 2.5mm hex key supplied,
adjust the temperature:
Turn the temperature handle to the
maximum temperature. Undo the grub
screw to remove the handle.
Re-fit the temperature handle back in
the maximum temperature position.
Sequential Shower Valves:
Maximum Temperature Setting:
Wait for a couple of minutes for the
temperature to stabilise after adjusting.
Measure the water outlet temperature
using a thermometer. Adjust until the
desired temperature is reached.
Decrease
Temperature
Increase
Temperature
1
The shower has been pre-set to 43°C as
per TMV standards. This is based on being
fitted with nominally balanced pressures
with the hot water inlet supply at 65°C.
If your operating conditions are dierent
to the above your maximum outlet
temperature may dier.
Please note if the maximum temperature is
increased the shower will no longer comply
with the TMV scheme. If this isn’t an issue,
we recommend setting the maximum
outlet temperature no higher than 43°C.
15
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Maintenance

Undo the compression nuts and grub
screw at the bottom of the shower
valve to remove from the wall.
Disconnect
your shower
kit. If the valve
is shrouded,
remove the
handle and
valve shroud.
Check all
components
for damage
and replace
if necessary.
Rinse
thoroughly
in clean
water to
remove any
debris.
Reverse the steps
to re-fit the
elbows and
secure the
shower to the
wall. Test all joints
and connections
for any leaks.
Unscrew the elbows to
remove the filters and check
valves from the back of each
elbow. Remove the flow
regulators or insert from the
other side if necessary.
1
45
3
2
Servicing the Elbows:
123
IMPORTANT
Isolate the
water supply
before starting!
16 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Maintenance

Symptom Cause Remedy
No flow or
low flow
rate
Partially closed isolation valve. Open isolation valve.
Instantaneous water heater cycles on and
o as flow rate or pressure is too low.
Increase water flow rate or
pressure through system.
Head of water is below the
minimum distance required.
Refer to the specification for the
minimum distance required.
Are the water supply pressures balanced?
If pressures are unbalanced, a pressure
reducing valve should be used for
optimum performance.
Hot or cold water being drawn o else-
where causing pressure changes or instan-
taneous boiler temperature changes.
Do not use other water outlets when
using the shower.
Airlock or partial blockage in the
supply pipework.
Flush through pipework and filters to ensure
removal of debris and any airlocks.
Hot/Cold water supply has failed Check the hot and cold feeds. The shower
will not work if either fails.
Outlet
Water
Tempera-
ture too
Hot/Cold
Maximum Water Temperature
needs adjusting.
Refer to the Temperature Setting section to
set your desired maximum temperature.
Filter/pipe blockage Flush through pipework and filters to ensure
removal of debris and any airlocks.
Installation conditions outside
operating parameters.
Refer to the specification for the
minimum distance required.
Hot water temperature is less than 10°C
above the required blend temperature
Adjust hot water temperature or wait
for water to reheat if a stored water
system is used.
Instantaneous water not igniting because
the water flow rate is too low.
Increase water flow rate through the system.
Refer to the Maintenance section to clean/
check the cartridge and filters for any
damage. Contact your boiler manufacturer.
Instantaneous water not igniting because
the water pressure is too low.
Refer to the specification for system
requirements. Increase water pressure
through the system.
Contact your boiler manufacturer.
Only
hot/cold
water from
Shower
Valve
Inlet water supplies are reversed.
Check the water inlet connections are the
correct way around: Hot on the left, Cold on
the right when viewed from the front.
Rework pipework as necessary.
Filter/pipe blockage Flush through pipework and filters to ensure
removal of debris and any airlocks.
Water
dripping
from
shower
This is normal for a short time after
using the shower.
This is caused by residual water tension,
the build up of water in the shower.
If water continues to drip,
possibly due to the cartridge
Remove cartridge and clean, refer to
'Maintenance' section before starting
any maintenance.
Shower
does not
turn on
Closed isolation valve. Open isolation valve.
Mains water supply turned o. Turn on mains water supply.
17
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Troubleshooting

18 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Notes

19
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Notes

At Bristan, we want to make things as easy as possible for our customers. That’s why we oer solid
guarantees on all our products, eective from the date of purchase, to give you peace of mind.
To start your free guarantee simply scan the QR code and register your product.
Alternatively visit www.bristan.com/register.
For any other queries, please call our Customer Service on 0330 026 6273 where our expert team
of advisors will be able to oer you any help and advice.
For full guarantee terms and conditions visit www.bristan.com/service-centre/guarantees.
Bristan Group Ltd.
UK: Bristan Group, B78 1SG.
EU: Masco Europe S.à.r.l.
14 Rue Strachen
6933 Mensdorf
Luxembourg
Customer Service: [phone]
Web: www.bristan.com
Email: [e-mail]
A Masco Company
Issue: D5
Part Number: FI TS1503
