Bristan N2 SHCVO C Wiring diagram

Models covered: N2 SHCVO C / G, AR3 SHCVO C, PM2 SHCVO C, RS
SHCVO C, AR3 SHCMT C, DSC SHCVO C
Installer, when you have read these instructions please ensure you leave
them with the user.
Thermostatic Recessed Dual Control Shower Valve
Installation Instructions & User Guide
IMPORTANT: Please keep these instructions for future reference and request of replacement parts

Contents
Thank you for choosing Bristan, the UK’s leading showers and taps
expert. We have designed this product with your enjoyment in
mind. To ensure that it works to its full potential, it needs to be
fitted correctly. These fitting instructions have been created to give
you all of the information you need and, if you need any further help,
please do not hesitate to give us a call on 0330 026 6273.
Important Safety Information Page 3
General Information Page 4
Product Features Page 5
Specifications Page 6
Pack Contents Page 7 –12
Prior to Installation Page 13
Installation Page 14 –18
Shower Valve Page 14 -15
Wall Outlet Page 16
Shower Kit Page 17 -18
Operating the Shower Page 19
Maintenance Page 20
Adjusting the Temperature Page 21
Troubleshooting Page 22 -23
Notes Page 24 -27
Guarantee
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
2

Important Safety Information
•Please read these instructions thoroughly and retain for future use.
•All products manufactured and supplied by Bristan are safe provided they
are installed, used correctly and receive regular maintenance in
accordance with these instructions.
•If you are in any doubt about your ability to install this product safely,
you must employ the services of an experienced qualified plumber.
•These fittings need to be installed in accordance with, and meet the
requirements of the Water Supply (Water Fittings) Regulations 1999 and
Scottish Byelaws 2004.
•Remove all packaging and check there are no missing or damaged parts.
•Before starting any installation please consider the following:
•Before drilling into walls, check that there are no hidden electrical
wires, cables or water supply pipes. This can be checked with the
aid of an electronic detector
•If power tools are used do not forget to:
•Warning: Before installing the new shower valve, it is essential that
you thoroughly flush through the pipework in order to remove any
remaining swarf, solder, etc. Failure to carry out this procedure could
cause problems or damage to the workings of the shower valve.
•Fitting isolation valves to the inlet feeds is required for ease of
maintenance.
•Access must be made available to the shower valve/mixer body for
maintenance/servicing purposes.
•Do not block the flow of water from the showerhead by placing it
(smothering it) on your hand or any other part of the body or foreign
object.
•Do not crush or kink the shower hose, this could damage the hose and
cause leaks.
•Warning: Do not operate this product if you suspect it is frozen. Do
not site the mixing valve where it might be subjected to freezing
conditions.
•These shower valves must not be modified in any way as this will
invalidate the guarantee.
-Wear eye protection
-Unplug equipment after use
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
3

Recommended Usage
Domestic Heavy
Commercial
Light
Commercial Health Care
This product has been tested to the Water Regulations Advisory Scheme (WRAS) and
satisfies the requirements of the Water Supply (Water Fittings) Regulations 1999 and
current bylaws.
For full Installation Requirements & Notes (IRN) please visit www.wras.co.uk/directory.
BS7600 recommends the temperature of stored water should never exceed 65ºC. A
stored water temperature of 60ºC is considered sufficient to meet all normal
requirements and will minimise the build up of lime scale in hard water areas.
If the shower valve is installed at low pressure (tank fed), then the minimum distance
from the highest installed position of the showerhead to the underside of the cold tank
should be at least 1 metre to ensure adequate performance.
Note: Nominally equal (balanced) inlet supply pressures are recommended for optimum
performance.
This shower valve should be installed in compliance with the Water Supply (Water
Fittings) Regulations1999 and the Scottish Bylaws 2004.
If in doubt, contact a registered plumber or your Local Water Authority or the Secretary
of The Institute of Plumbing, address as follows;-
The Institute of Plumbing,
64 Station Lane,
Hornchurch,
Essex, RM12
6NB
Tel:[phone]
General information
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
4

1. On / off control
Turn the handle anti-clockwise
to turn on and increase the flow
of water.
Turn the handle clockwise to
turn off the flow of water.
2. Temperature control
Adjustable temperature control.
Turn the handle clockwise for
acooler temperature.
Turn the handle anti-clockwise for
ahotter temperature.
Note: The N2 SHCVO C/G & RS SHCVO C
can either be installed portrait or landscape.
1
2
PM2 SHCVO Cshown
Product Features
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
5

Specifications
Inlet Connections: 15mm compression with 150mm between centres.
Minimum working pressure: 0.2 bar
Note: This product has been designed to deliver a high flow of water on low pressure
systems, however, depending on the installation, type of system and shower
accessories, a higher pressure maybe required to optimise the showering experience.
Maximum working pressure: 5.0 Bar
Maximum static pressure: 10 Bar
Note: Static pressure is the build up of pressure when the valve is closed.
Supply Requirements:
Minimum cold water supply temperature: 5°C
Maximum cold water supply temperature: 25°C
Maximum hot water supply temperature: 80°C
Note: The inlet hot water temperature must be at least 10°C above the required blend
temperature (e.g. shower temperature 43°C: minimum hot water temperature 53°C).
System Requirements:
Gravity fed hot & cold (equal pressures)
Gravity fed hot & mains cold (differential pressure, maximum ratio 5:1)
Unvented systems
Instantaneous water heater (Combination boiler)
Pumped system
Note: When using a pumped system we recommend that an essex flange is used.
Important: Minimum wall cavity depth: 35mm
Min. –Max. concealing plate thickness: 45 –75mm
For full dimensional drawings please visit: www.bristan.com
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
6

1. Concealing plate x1
2. Handles x2
3. Shrouds x2
4. Screws x2
5. Valve body x1
6. Valve body fixings x2/2
7. Inserts x2
8. Flow regulators x2
9. Filter washers x2
10. Wall outlet x1
11. Shrouds x2
1
2
3
4
5
6
9
8
7
10
11
Pack Contents –N2 SHCVO C / G
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
7

12
35
4
7
6
8
9
Pack Contents –AR3 SHCVO C
1. Concealing plate x 1
2. Valve body x 1
3. Handles x 2
4. Valve body fixings x2/2
5. Inserts x 2
6. Flow Regulators x 2
7. Filter Washers x 2
8. Wall outlet x 1
9. Shrouds x2
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
8

1. Concealing plate x2
2. Valve body x1
3. Handles x2
4. Spline adaptors x2
5. Valve body fixings x2/2
6. Inserts x2
7. Flow regulators x2
8. Filter washers x2
9. Wall outlet x1
10. Shrouds x2
1
2
3
4
5
8
7
6
9
10
Pack Contents –PM2 SHCVO C
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
9

1. Concealing plate x1
2. Valve body x1
3. Handles x2
4. Spline adaptors x2
5. Valve body fixings x2/2
6. Inserts x2
7. Flow regulators x2
8. Filter washers x2
9. Wall outlet x1
10. Shrouds x2
1
2
5
8
7
6
9
3
4
10
Pack Contents –RS SHCVO C
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
10

1. Concealing plate x2
2. Valve body x1
3. Handles x2
4. Spline adaptors x2
5. Valve body fixings x2/2
6. Inserts x2
7. Flow regulators x2
8. Filter washers x2
9. Wall outlet x1
10. Shrouds x2
1
2
3
4
5
8
7
6
9
10
Pack Contents –DSC SHCVO C
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
11

2
1. Valve body x1
2. Shrouds x2
3. Concealing plate x1
4. Handles x2
5. Valve body fixings x2/2
6. Inserts x2
7. Flow regulators x2
8. Filter washers x2
9. Wall outlet x1
10. Wall brackets & fixings x2
11. Slider bracket x1
12. Riser rail x1
13. Soap dish x1
14. Handset x1
15. Shower hose x1
16. Hose retainer x1
1
3
4
5
7
6
8
9
10
11
12
13
16
14
15
Pack Contents –DSC SHCVO C
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
12

Flow Regulators
This shower valve is supplied with a
5 and 7 litre per minute flow
regulator loose in the box which
must be fitted if the shower valve is
installed in conjunction with an
instantaneous water heater /
combination boiler.
With both flow regulators fitted and
by turning the water heater /
combination boiler to its hottest
setting, will ensure a sufficiently hot
water supply to the shower valve
during winter months (in the UK),
when the mains cold water supply is
at its coldest.
To fit the flow regulators
Remove the inlet elbows ensuring
the filter washer is also removed.
carefully remove the plastic inserts
from the valve inlets and push in the
flow regulators. The green 7 litre per
minute flow regulator must be fitted
to the cold inlet and the yellow 5
litre per minute flow regulator must
be fitted to the hot inlet.
Place the filter washers back into
the elbow nuts and tighten the nuts
fully onto the outlets.
In the event that this shower valve
is not installed with an
instantaneous water heater /
combination boiler, the flow
regulators do not need to be fitted.
Flow
Regulator
Insert
Elbow
Filter
Washer
Prior to Installation
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
13

Nut
Elbow
Important: Water supplies to the
mixer must be with hot on the left
and cold on the right when
viewed from the front.
Wall plugs
Fixing
screws
This shower valve is designed for
installations where a recessed valve is
already installed in the wall cavity
and is to be replaced, or for new
installations.
Before Installation
Flush through the pipework to
ensure removal of any debris. Turn
off the mains water supply and
close any isolating valves.
1. Attach shower valve to wall
Place the shower valve in the required
position and mark the centres of the
fixing holes onto the wall.
Warning: Please check for any
hidden pipes and cables before drilling
holes in the wall.
Drill suitable holes and insert the wall
plugs. Securely attach the shower valve
to the wall using the screws supplied.
2.Connect water supply pipes
Insert 15mm hot and cold water supply
pipes into the inlet connections and
tighten nuts, ensuring the olives are
fitted.
3. Plumb in outlets
Insert 15mm pipework into the top
outlet and plumb into the users
chosen product. Ensure the olives are
fitted when tightening the nuts.
Installation –Shower Valve
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
14

4. Fit concealing plate
Note: The concealing plate can be
used as a template by drawing
around the plate and measuring in
by 10mm to give sufficient
clearance.
Run abead of waterproof silicon
sealant around the inner edge of the
concealing plate.
Slide the concealing plate onto the
shower valve control handles and
apply firm pressure to ensure to
silicon sealant spreads.
5.Fit Shrouds
Screw the shrouds onto the valve
body.
6.Fit Handles
Push the spline adaptors (if required)
onto the valve spindles.
Push the handles onto the spline
adaptors and secure by tightening
the grub screw and push-fit the cap
into position.
Important: All future servicing and
maintenance of the shower valve,
thermostatic cartridge and filters
can be done from the front, so rear
access is not required.
Concealing plate
Installation –Shower Valve
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
15

Fitting the Wall Outlet
There are two methods of fixing
the wall outlet depending on the
type of wall:
a: With rear access once wall
finished Fit the rubber washer to
the back of the wall outlet, place
the assembly through a
25-30mm hole in the wall and secure
with the backnut ensuring the
washer is fitted between the
backnut and the wall.
Connect the wall outlet assembly
to the shower valve outlet.
b: Without rear access once wall
finished
Fit a ‘1/2” female connection’ (not
supplied) within the wall cavity and
plumb in from the shower valve.
Screw the wall outlet into the ‘1/2”
female connection’ using a suitable
thread sealant ensuring the rubber
seal is fitted to the back of the wall
outlet.
Note: The backnut and washer
are not required.
Backnut
Washer
Wall
Rubber
seal
Wall
outlet
Wall
Rubber
seal
Wall
outlet
Female
fitting
Installation –Wall Outlet
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
16

The shower kit is only supplied with
AR3 SHCMT C
1. Mark the position
Position the assembled riser rail on the
wall, bearing in mind the different heights
of people likely to use the shower and the
length of the hose when connected to the
shower.
With the riser rail vertical, mark the wall
bracket positions onto the wall.
Release the slider handle and remove the
slider and wall brackets from the rail.
2. Attach wall brackets
Position the bottom wall bracket onto the
marked position on the wall surface,
ensure it is vertical and mark the centres
of the fixing holes onto the wall. Existing
fixing holes maybe used as the bottom
wall bracket is fully adjustable.
Warning: Please check for any
hidden pipes and cables before drilling
holes in the wall.
Drill suitable holes and insert the wall
plugs. Securely attach the bottom wall
bracket to the wall using the screws
provided.
Slider
handle
Note: If replacing an existing riser
rail, check to see if the existing holes
can be reused or covered by the new
wall
brackets. Try to avoid drilling close to
the edge of tiles, drill in the middle of
the tiles or in the tile joints.
Wall bracket
Wall bracket
Tips:Apiece of insulation or masking
tape positioned where holes are to
be drilled and before marking out the
exact position for the fixing holes will
help stop the drill bit from wandering,
particularly on atiled surface.
When working near a basin, bath or
shower insert plug or cover waste
to prevent losing small parts.
Take care not to drop
tools/equipment into basin, bath or
shower during shower installation.
Installation –Shower Kit
Wall bracket
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
17

3.Insert riser rail
Insert the plastic bracket insert as shown
into the wall bracket and slide the riser rail
down through the bottom wall bracket
ensuring the two holes in the riser are on the
top
4. Fit hose retainer &slider
Push the hose retainer (first) and slider
down onto the riser rial, ensuring they are
the correct way up -asshown.
5. Attach top wall bracket
Push the top wall bracket onto the riser rail,
ensuring the rail is vertical mark the centres
of the fixing holes in the top wall bracket
onto the wall surface.
Remove the top wall bracket and drill
suitable holes and insert the wall plugs
supplied.
Insert the plastic bracket insert into the top
wall bracket and refit the wall bracket onto
the riser rail. Align the fixing centres up with
the holes and secure in place using the
screws provided.
6. Fit end caps
Push-fit the wall bracket end caps onto
position to cover the fixings.
7. Connect shower hose to shower valve
Screw the shower hose onto the mixer
valve ensuring that the rubber washer is
fitted.
8. Connect shower hose to showerhead
Screw the shower hose onto the
showerhead ensuring that the rubber
washer is fitted.
Place the showerhead into the slider.
Bracket
Insert
Bottom wall
bracket
End cap
Slider
Hose
Retainer
Top wall
bracket
Bracket
Insert
Fixings
Installation –Shower Kit
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
18

Cold
1
1. On / off control
Turn the handle anti-clockwise to
turn on and increase the flow of
water.
Turn the handle clockwise to turn
off the flow of water.
2. Temperature control
Adjustable temperature control.
Turn the handle clockwise for a
cooler temperature.
Turn the handle anti-clockwise for a
hotter temperature. 2
Hot
Operating the Shower
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
19

General Cleaning
Your fitting has a high quality finish and
should be treated with care to preserve
the visible surfaces. All surfaces will
wear if not cleaned correctly, the only
safe way to clean your product is to
wipe with a soft damp cloth. Stains can
be removed using washing up liquid.
All bath cleaning powders and liquids
will damage the surface of your fitting,
even the non-scratch cleaners.
Note: Never use abrasive detergents
or disinfectants or those containing
alcohol, hydrochloric acid or
phosphoric acid.
Cartridge Maintenance
We advise that the shower valve is
regularly serviced in hard water areas
to maintain the flow of water.
Isolate both hot and cold water supplies
to the shower valve by either:
•Turning the water supply off at
the mains stopcock or
•Turning off the isolation valves to
the shower valve.
1. Remove the temperature handle
and plastic stop.
Important: Take note of the
position of the plastic stop and handle
-They must be refitted in the same
position.
2. Unscrew the cartridge anti-
clockwise and remove from the
valve body.
3. Remove the piston and thermostat
assembly and place into a bowl.
Carefully add hot water (just off the
boil) and vinegar to de-scale. Leave
in the solution until the water has
cooled and rinse with clean water.
4.Grease the seals with a silicon grease
supplied by Bristan (part number: SP-
495-0002) and carefully refit.
5.Refit the temperature stop and
handle. Reset the maximum
temperature.
Piston
Thermostat
Unscrew
anti-clockwise
to remove
Tighten
clockwise
to replace
Maintenance
Important: Take note of the
position of the plastic stop and
handle –They must be refitted in the
same position
Need Help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
20
