Broan MP100 User manual

1 99150591 Screw, #10 x 7/8" (4 required)*
2 97011410 Housing Assembly (includes Key No. 7)
3 98005512 Wiring Adapter Plate
4 99150471 Ground Screw, #10-32 x 1/2"
5 97008575 Wiring Harness
6 99260477 Whiz Nut, 1/4-20 (2 required)*
7 99420470 Grille Nut (2 required)
8 98005513 Outlet Box Cover
9 99400035 Strain Relief Bushing
10 97011394 Blower Wheel (MP100)
97011395 Blower Wheel (MP140)
97011396 Blower Wheel (MP200)
11 97011361 Blower Housing (MP100)
97011362 Blower Housing (MP140)
97011363 Blower Housing (MP200)
12 99100412 Motor Mounting Rubber (2 required)
13 97011400 Motor (MP100) (includes Key No. 16)
97011411 Motor (MP140) (includes Key No. 16)
97011402 Motor (MP200) (includes Key No. 16)
14 95000963 Motor Cup
15 99170245 Screw, #8 x 3/8" (10 required)*
16 97011403 Capacitor (MP100)
97011412 Capacitor (MP140)
97011405 Capacitor (MP200)
17 97011406 Cover
18 99110942 Inlet Cover (covers unused inlet ports)
** 97011407 Blower Assembly Complete (MP100)
(includes Key No.s 10 thru 16)
** 97011413 Blower Assembly Complete (MP140)
(includes Key No.s 10 thru 16)
** 97011409 Blower Assembly Complete (MP200)
(includes Key No.s 10 thru 16)
DIFFUSER
CEILING
DRYWALL
DUCT
TAPE
OR
CLAMP
TO
VENTILATOR
4" ROUND
INSULATED
FLEXIBLE DUCT
DESCRIPTION
KEY PART
NO.
NO.
6
10
11
12
13 12
14
16
17
9
8
15 7
5
2
3
4
18
15
1
15
15
INSTALL EXHAUST DIFFUSERS
Follow instructions packed with diffuser(s). General instructions:
1. Cut hole(s) in ceiling drywall and install diffuser(s).
2. Connect insulated ductwork to diffuser(s) and use duct tape or
clamp (available separately) to seal connection(s).
3. Rotate center of diffuser(s) counterclockwise to fully open for
maximum air flow. Reduce air flow by rotating center of
diffuser(s) clockwise to desired opening. A balancing damper
(available separately) can be used to adjust airflow.
USE AND CARE
WARNING: DISCONNECT ELECTRICAL POWER AND LOCK
OUT SERVICE PANEL BEFORE CLEANING OR SERVICING
THIS UNIT.
CLEANING
A continuously operating in-line ventilator needs to be cleaned
once a year to assure proper performance.
Remove cover and carefully vacuum blower and inside of hous-
ing. Be careful not to bend or otherwise damage blower wheel.
Diffusers and intake vents can be vacuumed and/or wiped clean
with a damp cloth.
MOTOR LUBRICATION
The motor is permanently lubricated. Do not oil or disassemble
motor.
SERVICE PARTS
Models MP100, MP140 & MP200
* Standard Hardware - May be purchased locally.
** Not shown assembled. Always order replacement parts by “Part No, - not by “Key No.”
BROAN ONE YEAR LIMITED WARRANTY
Broan warrants to the original consumer purchaser of its products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE
ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
During this one-year period, Broan will, at its option, repair or replace, without charge, any product or part which is found to be defective under normal use and service.
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS AND TUBES. This warranty does not cover (a) normal maintenance and service or (b) any products or parts which have
been subject to misuse, negligence, accident, improper maintenance or repair (other than by Broan), faulty installation or installation contrary to recommended installation instructions.
The duration of any implied warranty is limited to the one-year period as specified for the express warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above limitation
may not apply to you.
BROAN’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN’S OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY. BROAN SHALL NOT BE
LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH PRODUCT USE OR PERFORMANCE. Some states do not allow the exclusion
or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This warranty supersedes all prior warranties.
To qualify for warranty service, you must (a) notify Broan, (b) give the model number and part identification and (c) describe the nature of any defect in the product or part. At the time of requesting warranty
service,youmustpresentevidenceoftheoriginalpurchasedate. IntheU.S., contact:Broan-NuToneLLC,926 West State Street, Hartford, WI 53027 (1-800-637-1453)
InCanada,contact: Broan-NuTone Canada, Inc., 1140 Tristar Drive, Mississauga, Ontario L5T 1H9 (1-888-882-7626)
99041951J

CAUTION
1. For general ventilating use only. Do not use to exhaust
hazardous or explosive materials and vapors.
2. To avoid motor bearing damage and noisy and/or unbal-
anced impellers, keep drywall spray, construction dust,
etc. off power unit.
3. If ventilator is installed in an unconditioned space
(such as an attic): Surround the ventilator with thermal
insulation - to minimize possible condensation.
4. Please read specification label on product for further
information and requirements.
WARNING
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE FOLLOW-
ING:
1. Use this unit only in the manner intended by the manu-
facturer. If you have questions, contact the manufac-
turer at the address or telephone number listed below
the warranty.
2. Before servicing or cleaning unit, switch power off at
service panel and lock the service disconnecting means
to prevent power from being switched on accidentally.
Whenthe servicedisconnectingmeans cannotbelocked,
securely fasten a prominent warning device, such as a
tag, to the service panel.
3. Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction
codes and standards.
4. Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fueling
equipment to prevent backdrafting. Follow the heating
equipment manufacturer’s guideline and safety stan-
dards such as those published by the National Fire
Protection Association (NFPA), and the American Soci-
ety for Heating, Refrigeration and Air Conditioning Engi-
neers (ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not
damage electrical wiring and other hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. This unit must be grounded.
PLAN THE INSTALLATION
Adequate ventilation requires that both intermittent and
continuous contamination be controlled.
Intermittent ventilation must be provided in the bathroom
and kitchen. The bathroom requires 8 air changes per hour.
(Multiply bathroom sq. footage by 1.1 for proper fan sizing).
The kitchen requires a minimum of 150 CFM capacity (71
l/s) when a ducted range hood is used. If a kitchen fan is
used, determine fan capacity by multiplying the room's sq.
footage by 2. All are run intermittently to control pollution at
the source.
Continuous ventilation, while the house is occupied, pro-
vides the flow of fresh air for good indoor air quality.
This ventilator is intended for continuous operation, supply-
ing fresh air to the entire house.
RECOMMENDED VENTILATOR SIZING
READ AND SAVE THESE INSTRUCTIONS
*AC/HR = Air Changes per Hour. Based on 8' ceilings.
Square Feet x .093 = Square Meters
.50 AC/HR* .35 AC/HR* .30 AC/HR*
1500 2140 2500
2100 3000 3500
3000 4285 5000
MODEL
MP100
MP140
MP200
(include finished basement area)
DWELLING SIZE RANGE (Sq. Ftg.)
MODELS MP100, MP140 & MP200
MULTI-PORT IN-LINE FANS
