SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
TYPICAL SPECIFICATION
Range hood shall be Broan Model 40000.
Unit shall have backdraft damper and be ducted vertically
(horizontally) to the outside.
Motor to be permanently lubricated. RPM not to exceed
2795.
Unit shall have a two-speed fan switch and separate light
switch.
Sides shall be mitered and bottom edge hemmed - with no
sharp edges.
Air delivery shall be no less than 160 CFM and sound
levels no greater than 6.5 sones (vertical) and 6.5 Sones
(horizontal discharge). All air and sound ratings shall be
certified by HVI. Unit shall be U.L. listed.
50H 99041044J
Tested to show compliance with HUD/FHA Minimum
Property Standards for Mechanical Ventilation.
40000 SERIES
TWO-SPEED
DUCTED
RANGE HOOD
Constructed with quality and good looks, the
40000 out-performs the competition whether
ducted vertically or horizontally.
FEATURES
•Rocker-type fan and light switches
•Polymeric blade and light lens (accepts up to 75W bulb)
•Washable aluminum filter
•Mitered sides and hemmed bottom for safety and good
looks
•Contemporary styling in White, Biscuit, Almond,
Black and Stainless Steel
•Available in 30" and 36" widths
•21"and 42" available in White, Biscuit and Almond
•24" available in White, Biscuit, Almond and Stainless Steel
SONES
VER. HOR.
SPECIFICATIONS
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
HVI-2100 CERTIFIED RATINGS comply with new
testing technologies and procedures prescribed
by the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers.
Product performance is rated at 0.1 in. static
pressure, based on tests conducted in AMCA’s
state-of-the-art test laboratory. Sones are a
measure of humanly-perceived loudness, based
on laboratory measurements.
VOLTS AMPS RPM CFM DUCT
120 2.0 2795 6.5 6.5 160 3-1/4"x10"
