MULTI-FUNCTION CENTER
SERVICE MANUAL
MODEL: MFC9800/MFC9700/DCP1400
MFC9880/MFC9860/MFC9760

© Copyright Brother 2002
All rights reserved.
No part of this publication may be reproduced in any form or by any means without permission in writing from
the publisher.
Specifications are subject to change without notice.
All products and company names mentioned in this manual are trademarks or registered trademarks of their
respective holders.

PREFACE
This publication is a Service Manual covering the specifications, construction, theory of operation,
and maintenance of the Brother machine. It includes information required for field troubleshooting
and repair--disassembly, reassembly, and lubrication--so that service personnel will be able to
understand machine function, to rapidly repair the machine and order any necessary spare parts.
To perform appropriate maintenance so that the machine is always in best condition for the
customer, the service personnel must adequately understand and apply this manual.
This manual is made up of six chapters and appendices.
CHAPTER I. GENERAL DESCRIPTION
CHAPTER II. INSTALLATION
CHAPTER III. THEORY OF OPERATION
CHAPTER IV. DISASSEMBLY/REASSEMBLY AND LUBRICATION
CHAPTER V. MAINTENANCE MODE
CHAPTER VI. ERROR INDICATION AND TROUBLESHOOTING
Appendix 1. EEPROM Customizing Codes
Appendix 2. Firmware Switches (WSW)
Appendix 3. Circuit Diagrams
This manual describes the models and their versions to be destined for major countries. The specifications
and functions are subject to change depending upon each destination.

SAFETY INFORMATION
Laser Safety (110-120V Model only)
This printer is certified as a Class 1 laser product under the US Department of Health and Human
Services (DHHS) Radiation Performance Standard according to the Radiation Control for Health
and Safety Act of 1968. This means that the printer does not produce hazardous laser radiation.
Since radiation emitted inside the printer is completely confined within the protective housings and
external covers, the laser beam cannot escape from the machine during any phase of user
operation.
CDRH Regulations (110-120V Model only)
The Center for Device and Radiological Health (CDRH) of the US Food and Drug Administration
implemented regulations for laser products on August 2, 1976. These regulations apply to laser
products manufactured from August 1, 1976. Compliance is mandatory for products marketed in
the United States. The label shown below indicates compliance with the CDRH regulations and
must be attached to laser products marketed in the United States.
The label for Chinese products
MANUFACTURED: JULY 2001 C
BROTHER CORP. (ASIA) LTD.
BROTHER BUJI NAN LING FACTORY
Gold Garden Industry, Nan Ling Village, Buji,
Rong Gang, Shenzhen, China.
This product complies with FDA radiation
performance standards, 21 CFR Subchapter J.

CHAPTER I.
GENERAL DESCRIPTION

CHAPTER I. GENERAL DESCRIPTION
CONTENTS
1. MACHINE OUTLINE................................................................................................. I-1
1.1 External Appearance and Weight..................................................................... I-1
1.2 Components ..................................................................................................... I-1
2. SPECIFICATIONS..................................................................................................... I-2

I- 1
1. MACHINE OUTLINE
1.1 External Appearance and Weight
The figure below shows the machine appearance and approximate dimensions.
Weight: Machine proper 15.2 kg
Machine (incl. drum unit & toner cartridge) 17.0 kg
In package 21.2 kg
1.2 Components
The machine consists of the following major components:

I- 2
2. SPECIFICATIONS (1/4)
Model Name MFC9800 MFC9700
GENERAL
Print Engine Laser (ZLe) Laser (ZLe)
Modem Speed(bps) 33,600(Fax) 14,400(Fax)
Transmission Speed(sec.) Approx. 2 Approx. 5
ITU-T Group Super G3 G3
Coding Method MH/MR/MMR/JBIG MH/MR/MMR/JBIG
Input/Output Width 5.8"-8.5"/2.75"-8.5" 5.8"-8.5"/2.75"-8.5"
ADF(pages) up to 50 up to 50
LCD Size 16 Characters x 2 Lines 16 Characters x 1 Lines
On-Screen Programming Yes Yes
Back up Clock Yes (9 hours) Yes (1 hours)
Memory Capacity(Physical:MByte) 8 8
Back up Memory Yes No
Optional Memory 16/32MByte(DIMM) No
Optional Paper Tray Yes(250pages:LT-400) Yes(250pages:LT-400)
Dimensions (WxDxH) 19.4x18.0x16.8 inches 19.4x18.0x16.8 inches
492x456x429 mm 492x456x429 mm
Weight 35.2 lbs/(17 kg) 35.2 lbs/(17 kg)
Color Gray 1495 Gray 1495
Standby Mode Yes Yes
PC-Fax Protocol Compliance Class 2 Class 2
Simultaneous Operation Yes Yes
Data Modem No No
Energy Star Compliance (for U.S.A.) Yes Yes
LCD Back Light No No
Operating Environment Temperature 10 - 32.5 degrees Centigrade 10 - 32.5 degrees Centigrade
Humidity 20 - 80%(without condensation) 20 - 80%(without condensation)
Power Source 120VAC 50/60Hz 120VAC 50/60Hz
Power Consumption Less than 15W / 75W / 940W Less than 15W / 75W / 940W
(Sleep/Standby/Peak)
Demo Model N / A Yes([Start]+[Stop])
TELEPHONE
Automatic Redial Yes Yes
Handset No No
One-Touch Dial 32 (16x2) 8 (4x2)
Speed Dial 100 100
Telephone Index Yes Yes
Speaker Phone No No
Chain Dialing Yes Yes
Caller ID Yes Yes
Call Waiting Caller ID No No
Distinctive Ringing Yes Yes
Hold/Mute Key No No
Power Failure Dialing No No
Speaker Volume - -
Ring Volume - -
Handset Volume - -
PBX Feature No No
Transfer Method Flash Flash
Figures of One-Touch & Speed Dial 20 digits 20 digits
Resisterable Number Of Characters 15 char 15 char

I- 3
(1/4)
Model Nam
e
DCP140
0
GENERAL
Print Engine Laser (ZLe)
Modem Speed(bps) -
Transmission Speed(sec.) -
ITU-T Group -
Coding Method -
Input/Output Width 5.8"-8.5"/2.75"-8.5"
ADF(pages) up to 50
LCD Size 16 Characters x 2 Lines
On-Screen Programming Yes
Backup Clock No
Memory Capacity(Physical:MByte) 8
Backup Memory No
Optional Memory No
Optional Paper Tray Yes(250pages:LT-400)
Dimensions (WxDxH) 19.4x18.0x16.8 inches
492x456x429 mm
Weight 35.2 lbs/(17 kg)
Color Gray 1495
Standby Mode Yes
PC-Fax Protocol Compliance -
Simultaneous Operation Yes
Data Modem No
Energy Star Compliance (for U.S.A.) Yes
LCD Back Light No
Operating Environment Temperature 10 - 32.5 degrees Centigrade
Humidity 20 - 80%(without condensation)
Power Source 120VAC 50/60Hz
Power Consumption Less than 15W / 75W / 940W
(Sleep/Standby/Peak)
Demo Model N / A
TELEPHONE
Automatic Redial -
Handset -
One-Touch Dial -
Speed Dial -
Telephone Index -
Speaker Phone -
Chain Dialing -
Caller ID -
Call Waiting Caller ID -
Distinctive Ringing -
Hold/Mute Key -
Power Failure Dialing -
Speaker Volume -
Ring Volume -
Handset Volume -
PBX Feature -
Transfer Method -
Figures of One-Touch & Speed Dial -
Resisterable Number Of Characters -

I- 4
(2/4)
Model Name MFC9800 MFC9700
FAX
Internet FAX Available with Optional LAN Board Available with Optional LAN Board
Easy Receive/Fax Detect Yes Yes
Fax/Tel Switch Yes No
Super Fine Yes (TX & RX) Yes (TX & RX)
300dpi Transmission No No
Gray Scale 64 64
Contrast Yes (Auto/S.Light/S.Dark) Yes (Auto/S.Light/S.Dark)
Smoothing Yes Yes
Call Reservation Over Auto TX No No
Password Check No No
Enhanced Remote Activate Yes Yes
Multi Resolution Transmission No No
Multi Transmission No No
Next-Fax Reservation Yes (Dual Access) Yes (Dual Access)
Delayed Timer Yes (up to 50) Yes (up to 50)
Polling (RX only) Yes (Std/Seq) Yes (Std/Seq)
Quick Scan (Memory Transmission) Approx. 3 sec./page (A4:standard) Approx. 3 sec./page (A4:standard)
Broadcasting Yes (182 locations) Yes (158 locations)
Batch Transmission Yes Yes
Auto Reduction Yes Yes
Out-of-Paper Reception *2 up to 600 pages up to 600 pages
Dual Access Yes Yes
ECM(Error Correction Mode) Yes Yes
ITU SUB Addressing No No
Group Dial Yes (6) Yes (6)
Resend After Receive Error Signal No No
Confidential No No
Station ID 1 (20digits/20char) 1 (20digits/20char)
Off Hook Alarm No No
Remote Maintenance Yes Yes
Call Reservation Over Manual TX No No
RX Mode Indication LCD LCD
Resolution Indication LED LCD
LIST REPORT
Activity Report/Journal Report Yes (up to 200) Yes (up to 200)
Transmission Verification Report Yes Yes
Coverpage Yes (Super) Yes (Super)
Help List Yes Yes
Call Back Message No No
Caller ID List Yes Yes
INTERFACE
External TAD Interface Yes Yes
Missing Link/PC Interface No No
Host Interface Yes (Auto switching : Parallel/USB *3) Yes (Auto switching : Parallel/USB *3)
LAN Interface Available with Option LAN Board Available with Option LAN Board

I- 5
(2/4)
Model Name DCP1400
FAX
Internet FAX -
Easy Receive/Fax Detect -
Fax/Tel Switch -
Super Fine -
300dpi Transmission -
Gray Scale -
Contrast -
Smoothing -
Call Reservation Over Auto TX -
Password Check -
Enhanced Remote Activate -
Multi Resolution Transmission -
Multi Transmission -
Next-Fax Reservation -
Delayed Timer -
Polling (RX only) -
Quick Scan (Memory Transmission) -
Broadcasting -
Batch Transmission -
Auto Reduction -
Out-of-Paper Reception *2 -
Dual Access -
ECM(Error Correction Mode) -
ITU SUB Addressing -
Group Dial -
Resend After Receive Error Signal -
Confidential -
Station ID -
Off Hook Alarm -
Remote Maintenance -
Call Reservation Over Manual TX -
RX Mode Indication -
Resolution Indication -
LIST REPORT
Activity Report/Journal Report -
Transmission Verification Report -
Coverpage -
Help List -
Call Back Message -
Caller ID List -
INTERFACE
External TAD Interface No
Missing Link/PC Interface No
Host Interface Yes (Auto switching : Parallel/USB *3)
LAN Interface No

I- 6
(3/4)
Model Name MFC9800 MFC9700
PRINTER Yes Yes
Color/Mono Mono Mono
Engine Type Laser(ZL) Laser(ZL)
Resolution(dpi) 600x600 600x600
Speed(ppm) up to 14 up to 14
Paper Capacity(sheets) 250 250
Additional Paper Capacity(sheets) 250 (User Option) 250 (User Option)
Output Paper Capacity(sheets) 150 150
Standard Print Language Windows GDI(600x600) Windows GDI(600x600)
Emulation PCL5e PCL4
Resident Fonts 24 Bitmap (PCL5 Comp.) 24 Bitmap (PCL4 Comp.)
Fonts Disk Based Yes (35 TrueType) Yes (35 TrueType)
Paper Handling Size LTR, LGL, A4, B5, A5, EXE LTR, LGL, A4, B5, A5, EXE
Manual Feed Slot Custom Size (2.75x5 - 8.5x14) Custom Size (2.75x5 - 8.5x14)
Envelop(DL/C5/CM10/Mona) Envelop(DL/C5/CM10/Mona)
Other Paper Type OHP, Envelopes, Labels, Organizer OHP, Envelopes, Labels, Organizer
Sheet Weight (Paper Cassette) 64-105 g/m2 (17 - 28 lb) 64-105 g/m2 (17 - 28 lb)
(Manual Slot) 64-157 g/m2 (17 - 43 lb) 64-157 g/m2 (17 - 43 lb)
Printer Driver Win95/98(SE)/Me and NT4.0/2000 Win95/98(SE)/Me and NT4.0/2000
Driver with Auto Installer Program Driver with Auto Installer Program
Utility Software Yes (Remote Printer Console for PCL6) Yes (Remote Printer Console for PCL4)
Toner Life (Standard Yield : TN-430) 6,000 A4 pages@5% 6,000 A4 pages@5%
(High Yield : TN-460) 3,000 A4 pages@5% 3,000 A4 pages@5%
Drum Life (DR400) up to 20,000 pages up to 20,000 pages
Interface Type Parallel & USB *3 Parallel & USB *3
Bundled Cable Yes (Parallel) Yes (Parallel)
COPY
Speed(cpm) up to 14 up to 14
Multi Copy(Stack) up to 99 up to 99
Multi Copy(Sort) Yes Yes
Multi Copy(2in1) Yes Yes
Multi Copy(4in1) Yes Yes
Poster Yes Yes
Reduction/Enlargement(%) 25 -- 400 in 1% increments 25 -- 400 in 1% increments
Resolution(dpi) 600x600(600x300:Optical Scanning) 600x600(600x300:Optical Scanning)
SCANNER Yes Yes
Color/Mono Color Color
Resolution(Optical : dpi) 600x300(Max. 600x2,400) 600x300(Max. 600x2,400)
Resolution(Int. : dpi) 9,600x9,600 9,600x9,600
Color Depth(bit) 24(8bitx3) 24(8bitx3)
Gray Scale 256 256
TWAIN Compliant Yes Yes
Formats(Import) TIFF/BMP/PCX/DCX/BTF/BTX/MAX TIFF/BMP/PCX/DCX/BTF/BTX/MAX
Formats(Export) TIFF/BMP/MAX TIFF/BMP/MAX
OCR Yes(ScanSoft TextBridge) Yes(ScanSoft TextBridge)
[Scan] Key es(Scan to E-mail, Scan Image, Scan/OCRes(Scan to E-mail, Scan Image, Scan/OCR

I- 7
(3/4)
Model Name DCP1400
PRINTER Yes
Color/Mono Mono
Engine Type Laser(ZL)
Resolution(dpi) 600x600
Speed(ppm) up to 14
Paper Capacity(sheets) 250
Additional Paper Capacity(sheets) 250 (User Option)
Output Paper Capacity(sheets) 150
Standard Print Language Windows GDI(600x600)
Emulation PCL4
Resident Fonts 24 Bitmap (PCL4 Comp.)
Fonts Disk Based Yes (35 TrueType)
Paper Handling Size LTR, LGL, A4, B5, A5, EXE
Manual Feed Slot Custom Size (2.75x5 - 8.5x14)
Envelop(DL/C5/CM10/Mona)
Other Paper Type OHP, Envelopes, Labels, Organizer
Sheet Weight (Paper Cassette) 64-105 g/m2 (17 - 28 lb)
(Manual Slot) 64-157 g/m2 (17 - 43 lb)
Printer Driver Win95/98(SE)/Me and NT4.0/2000
Driver with Auto Installer Program
Utility Software Yes (Remote Printer Console for PCL4)
Toner Life (Standard Yield : TN-430) 6,000 A4 pages@5%
(High Yield : TN-460) 3,000 A4 pages@5%
Drum Life (DR400) up to 20,000 pages
Interface Type Parallel & USB *3
Bundled Cable Yes (Parallel)
COPY
Speed(cpm) up to 14
Multi Copy(Stack) up to 99
Multi Copy(Sort) Yes
Multi Copy(2in1) Yes
Multi Copy(4in1) Yes
Poster Yes
Reduction/Enlargement(%) 25 -- 400 in 1% increments
Resolution(dpi) 600x600(600x300:Optical Scanning)
SCANNER Yes
Color/Mono Color
Resolution(Optical : dpi) 600x300(Max. 600x2,400)
Resolution(Int. : dpi) 9,600x9,600
Color Depth(bit) 24(8bitx3)
Gray Scale 256
TWAIN Compliant Yes
Formats(Import) TIFF/BMP/PCX/DCX/BTF/BTX/MAX
Formats(Export) TIFF/BMP/MAX
OCR Yes(ScanSoft TextBridge)
[Scan] Key es(Scan to E-mail, Scan Image, Scan/OCR

I- 8
(4/4)
Model Name MFC9800 MFC9700
MESSAGE CENTER/MESSAGE MANAGER No No
ICM Recording Time No No
Page Memory No No
OGM (MC/MC Pro/Paging) No No
TAD Type No No
Memo/Recording Conversation No No
Toll Saver No No
Fax Forwarding Yes Yes
Fax Retrieval Yes Yes
Paging Yes Yes
Remote Access Yes Yes
MESSAGE CENTER Pro/MESSAGE MANAGER Pro No No
Fax/Voice Mail Box No No
Fax/Voice on Demand No No
MESSAGE CENTER (PC MC) No No
Fax Forwarding No No
Paging No No
ICM Recording Time No No
OGM MC/MC Pro/Paging No No
Fax/Voice Mail Box No No
Fax/Voice on Demand No No
VIDEO CAPTURE No No
Video Capture No No
Video Print No No
Video Format No No
BUNDLED SOFTWARE
For Windows
OS Support Win95/98(SE)/Me, WinNT4.0/2000 Win95/98(SE)/Me, WinNT4.0/2000
Printer Driver (Brother) Yes Yes
Viewer (ScanSoft PaperPort Ver.6.5) Yes Yes
- include Text Bridge OCR
TWAIN (Brother) Yes Yes
PC Fax (Brother) Yes Yes
- TX: FAX Share / RX: Class2
For iMAC/G3/G4
OS Support Printer Driver 8.5 - 9.1 8.5 - 9.1
TWAIN 8.6 - 9.1 8.6 - 9.1
Printer Driver (Brother) Yes Yes
Viewer (ScanSoft PaperPort for MAC) Yes Yes
TWAIN (TII/Brother) Yes Yes
PC Fax (TX[FAX Share] only:Brother) Yes Yes
*2: Brother #1 Chart, JBIG coding, Standard Resolution
*3: USB - Windows98/98SE/Me, Windows2000 only.

I- 9
(4/4)
Model Name DCP1400
MESSAGE CENTER/MESSAGE MANAGER No
ICM Recording Time -
Page Memory -
OGM (MC/MC Pro/Paging) -
TAD Type -
Memo/Recording Conversation -
Toll Saver -
Fax Forwarding -
Fax Retrieval -
Paging -
Remote Access -
MESSAGE CENTER Pro/MESSAGE MANAGER Pro No
Fax/Voice Mail Box -
Fax/Voice on Demand -
MESSAGE CENTER (PC MC) No
Fax Forwarding -
Paging -
ICM Recording Time -
OGM MC/MC Pro/Paging -
Fax/Voice Mail Box -
Fax/Voice on Demand -
VIDEO CAPTURE No
Video Capture No
Video Print No
Video Format No
BUNDLED SOFTWARE
For Windows
OS Support Win95/98(SE)/Me, WinNT4.0/2000
Printer Driver (Brother) Yes
Viewer (ScanSoft PaperPort Ver.6.5) Yes
- include Text Bridge OCR
TWAIN (Brother) Yes
PC Fax (Brother) No
- TX: FAX Share / RX: Class2
For iMAC/G3/G4
OS Support Printer Driver 8.5 - 9.1
TWAIN 8.6 - 9.1
Printer Driver (Brother) Yes
Viewer (ScanSoft PaperPort for MAC) Yes
TWAIN (TII/Brother) Yes
PC Fax (TX[FAX Share] only:Brother) No
*2: Brother #1 Chart, JBIG coding, Standard Resolution
*3: USB - Windows98/98SE/Me, Windows2000 only.

I- 10
(1/4)
ZLe-FB(w/ Modem ) ZLe-FB(w/ Modem )
Model Name MFC- 9880 MFC-9860
GENERAL
Print Engine Laser (ZL) Laser (ZL)
Modem Speed(bps) 33,600(Fax) 33,600(Fax)
Transmission Speed(sec.) Approx. 2 (brother#1 chart, JBIG) Approx. 2 (brother#1 chart, JBIG)
ITU-T Group Supper G3 Supper G3
Coding Method MH/MR/MMR/JBIG MH/MR/MMR/JBIG
Input/Output Width FB;8.5"X11"ADF;5.8"-8.5/2.75"-8.5" FB;8.5"X11"ADF;5.8"-8.5/2.75"-8.5"
ADF(pages) up to 50 up to 50
LCD size 16 Characters x 2 lines 16 Characters x 2 lines
On-Screen Programming Yes Yes
Back up Clock Yes (9 hours) Yes (9 hours)
Memory Capacity(physical) 8MB(RAM) 8MB(RAM)
Memory Backup Yes( Max. 4 days ) Yes( Max. 4 days )
Optional Memory Yes (16/32MB:DIMM) Yes (16/32MB:DIMM)
Dimensions w/ Carton
(
WxDxH
)
598 x 567 x 580 mm 598 x 567 x 580 mm
Dimensions w/o Carton (WxDxH) 492 x 456 x 429 mm 492 x 456 x 429 mm
Weight w/o Carton (WxDxH) 17.0Kg 17.0Kg
Weight w/ Carton (WxDxH) 21.2Kg 21.2Kg
Color Gray 1495 Gray 1495
Standby Mode Yes Yes
PC-Fax Protocol Compliance Class 2 No
Simultaneous Operation Yes (Print/Fax,Print/Copy,Print/Scan) No
Data Modem No No
Energy Star Compliant N/A N/A
LCD Back Light No No
Operating Environment Temperatur
e
Humidit
y
10 - 32.5 degrees Centigrade
20% - 80
%
10 - 32.5 degrees Centigrad
e
20%- 80
%
Power Source 220-240VAC 50/60Hz 220-240VAC 50/60Hz
Power Consumption (Sleep/Standby/Peak) 15W/75W/940W 15W/75W/940W
Demo Print No No
TELEPHONE
Automatic Redial Yes Yes
Handset No No
One-Touch Dial 32 (16x2) 32 (16x2)
Speed Dial 100 100
Telephone Index Yes(Normal) Yes(Normal)
Speaker Phone No No
Chain Dialing Yes Yes
Caller ID No No
Call Waiting Caller ID No No
Distinctive Ringing Yes(UK, DEN only) Yes(UK, DEN only)
Hold/Mute Key No No
Power Failure Dialing No No
Speaker Volume Yes (3 steps + OFF) Yes (3 steps + OFF)
Ring Volume Yes (3 steps + OFF) Yes (3 steps + OFF)
Handset Volume No No
PBX Feature Yes Yes
Transfer Method Flash Flash
Figures of One-Touch & Speed Dial 20 digits 20 digits
Resisterable Number Of Characters 15 characters 15 characters

I- 11
(1/4)
ZLe-FB(w/out Modem )
Model Name MFC-9760
GENERAL
Print Engine Laser (ZL)
Modem Speed(bps) -
Transmission Speed(sec.) -
ITU-TGroup -
Coding Method -
Input/Output Width FB;8.5"X11"ADF;5.8"-8.5/2.75"-8.5"
ADF(pages) up to 50
LCD size 16 Characters x 2 lines
On-Screen Programming Yes
Back up Clock Yes (1 hour)
Memory Capacity(physical) 8MB(RAM)
Memory Backup No
Optional Memory Yes (16/32MB:DIMM)
Dimensions w/ Carton
(
WxDxH
)
598 x 567 x 580 mm
Dimensions w/o Carton (WxDxH) 492 x 456 x 429 mm
Weight w/o Carton (WxDxH) 17.0Kg
Weight w/ Carton (WxDxH) 21.2Kg
Color Gray 1495
Standby Mode Yes
PC-Fax Protocol Compliance -
Simultaneous Operation Yes (Print/Copy,Print/Scan)
Data Modem -
Energy Star Compliant N/A
LCD Back Light No
Operating Environment Temperatur
e
Humidit
y
10 - 32.5 degrees Centigrad
e
20% - 80
%
Power Source 220-240VAC 50/60Hz
Power Consumption (Sleep/Standby/Peak) 15W/75W/940W
Demo Print No
TELEPHONE N/A
Automatic Redial -
Handset -
One-Touch Dial -
Speed Dial -
Telephone Index -
Speaker Phone -
Chain Dialing -
Caller ID -
Call Waiting Caller ID -
Distinctive Ringing -
Hold/Mute Key -
Power Failure Dialing -
Speaker Volume -
Ring Volume -
Handset Volume -
PBX Feature -
Transfer Method -
Figures of One-Touch & Speed Dial -
Resisterable Number Of Characters -

I- 12
(2/4)
Model Name MFC- 9880 MFC-9860
FAX Yes Yes
Internet FA
X
A
vailable with Option(NC-8100h) N
o
Easy Receive/Fax Detect Yes Yes
Fax/Tel Switch Yes with TEL/R key Yes with TEL/R key
Super Fine Yes (TX & RX) Yes (TX & RX)
300dpi Transmission No No
Gray Scale 64 64
Contrast Yes (Auto/Light/Dark) Yes (Auto/Light/Dark)
Smoothing Yes Yes
Call Reservation Over Auto TX No No
Password Check No No
Enhanced Remote Activate Yes Yes
Multi Resolution Transmission No No
Multi Transmission(>Dual Access) No No
Next-Fax Reservation(>Dual Access) No No
Delayed Timer Yes (50 timers/ 50 jobs ) Yes (50 timers/ 50 jobs )
Polling Yes (Std/Seq/Sec/Del) Yes (Std/Seq/Sec/Del)
Quick-Scan(Memory Transmission) *1 by ADF Yes as default, approx. 2.8sec/page(A4 standard) Yes as default, approx. 2.8sec/page(A4 standard)
by Flatbed Yes as default, approx. 3.8sec/page(A4 standard) Yes as default, approx. 3.8sec/page(A4 standard)
Broadcasting Yes (182 locations) Yes (182 locations)
Batch Transmission Yes Yes
Auto Reduction Yes Yes
Out-of-Pa
p
er Rece
p
tion
(
ITU-T Chart
)
*
2
500
p
a
g
es
(
JBIG/Standard Resolution
)
500
p
a
g
es
(
JBIG/Standard Resolution
)
Dual Access Yes Yes
ECM(Error Correction Mode) Yes Yes
ITU SUB Addressing No No
Group Dial Yes (6) Yes (6)
Station ID Yes (20digits/20characters ) Yes (20digits/20characters )
Off Hook Alarm No No
Remote Maintenance Yes Yes
Call Reservation Over Manual TX No No
RX Mode Indication LCD LCD
Resolution Indication LED LED
LIST/REPORT
Activity Report/Journal Report Yes (up to 200) Yes (up to 200)
Transmission Verification Report Yes Yes
Coverpage Yes (Super) Yes (Super)
Help List Yes(Reports key) Yes(Reports key)
Call Back Message No No
Caller ID List No No
INTERFACE
External TAD Interfac
e
Yes Ye
s
Missing Link/PC Interface(=Serial I/F ) No No
Host Interface (Serial) No No
Host Interface
(
IEEE1284
)
Yes No
Host Interface
(
USB
)
Yes No
LAN Interfac
e
A
vailable with Optional NC-8100h N
o

I- 13
(2/4)
Model Name MFC-9760
FAX N/A
Internet FA
X
-
Easy Receive/Fax Detect -
Fax/Tel Switch -
Super Fine -
300dpi Transmission -
Gray Scale -
Contrast -
Smoothing -
Call Reservation Over Auto TX -
Password Check
Enhanced Remote Activate -
Multi Resolution Transmission -
Multi Transmission(>Dual Access) -
Next-Fax Reservation(>Dual Access) -
Delayed Timer
Polling -
Quick-Scan(Memory Transmission) *1 by ADF -
by Flatbed -
Broadcasting -
Batch Transmission
Auto Reduction -
Out-of-Pa
p
er Rece
p
tion
(
ITU-T Chart
)
*2 -
Dual Access -
ECM(Error Correction Mode) -
ITU SUB Addressing -
Group Dial -
Station ID -
Off Hook Alarm -
Remote Maintenance -
Call Reservation Over Manual TX -
RX Mode Indication -
Resolution Indication -
LIST/REPORT No
Activity Report/Journal Report -
Transmission Verification Report -
Coverpage -
Help List N/A
Call Back Message -
Caller IDList -
INTERFACE
External TADInterfac
e
N
o
Missing Link/PC Interface(=Serial I/F ) No
Host Interface (Serial) No
Host Interface
(
IEEE1284
)
Ye
s
Host Interface
(
USB
)
Ye
s
LAN Interfac
e
N
o

I- 14
(3/4)
Model Name MFC- 9880 MFC-9860
PRINTER Yes N/A
Color/Mono Mono No
Engine Type Laser(ZLe) No
Resolution(dpi) 600x600 No
S
p
eed
(pp
m
)
u
p
to 14 No
Paper Capacity(sheets) 250 250
Additional Paper Capacity(sheets) 250 (User Option) 250 (User Option)
Output Paper Capacity(sheets) 150 150
Standard Print Language Windows GDI(600x600) No
Emulation PCL5e No
Resident Fonts Yes ( Bitmap font: LetterGothic 16.66, OCR-A,
OCR-B, Scalable font: 49 fonts ) No
Fonts Disk Based Yes (35 fonts ) No
Paper Handling Size LTR, EXE, A4, A5,A6, ISO B5, ISO B6 No
Manual Feed Slot Custom Size (2.75x5 - 8.5x14)
Envelo
p
(
DL/C5/CM10/Mona
)
No
Other Paper Type OHP, Envelopes, Labels, Organizer No
Sheet Weight (Paper Cassette) 60 -105 g/m2 No
(
ADF
)
64 - 90
g
/m2 No
(
Manual Slot
)
60 -161
g
/m2 No
Printer Driver Win95/98(SE)/Me/NT4.0WS/2000Professinal
MacOS 8.5-9.1 No
Utility Software Yes (Remote Printer Console for PCL5e) No
Toner Life
(
Standard Yield : TN-6300
)
3,000
p
a
g
es/A4
@
5% 3,000
p
a
g
es/A4
@
5%
(
Hi
g
h Yield : TN-6600
)
6,000
p
a
g
es/A4
@
5% 6,000
p
a
g
es/A4
@
5%
Drum Life (DR-6000) up to 20,000 pages up to 20,000 pages
Bundled Cable No No
COPY Yes Yes
Color/Mono Mono Mono
Multi Copy(Stack) Yes ( up to 99 ) Yes ( up to 99 )
Multi Copy(Sort) Yes Yes
N in 1 2in1, 4in1 2in1, 4in1
Poster ( X by Y ) Yes ( 1in3x3 ) Yes ( 1in3x3 )
Reduction/Enlargement(%) 25 -- 400 in 1% increments 25 -- 400 in 1% increments
Resolution(dpi) 600x300 600x300
SCANNER Yes N/A
Color/Mono Color/Mono No
Resolution(Optical: dpi) 600x2,400 No
Resolution(Interpolated: dpi) 9,600x9,600 No
Colour Depth(bit) 24(8bit x 3) No
Gray Scale 256 No
TWAIN Compliant & Operating System Win95/98(SE)/ME/NT4.0WS/2000Professional
MacOS8.6-9.1 No
OCR Yes (TextBridge by ScanSoft ) No
Scan Key No No
Scan to Image key Yes No
Scan to OCR ke
y
Yes No
Scan to E-MAIL key Yes No
