Start Here MFC-J2510
MFC-J4510DW
Quick Setup Guide
ARL/ASA/NZ Version 0
Please read the Product Safety Guide first before you set up your machine. Then, please read this Quick Setup
Guide for the correct setup and installation.
1
Unpack the machine and check the components
Most of the illustrations in this Quick Setup Guide show the MFC-J4510DW.
The components included in the box may differ depending on your country.
WARNING
• Plastic bags are used in the packing of your machine. To avoid the danger of suffocation, keep these
plastic bags away from babies and children. Plastic bags are not toys.
• To ensure safe operation the supplied plug must be inserted only into a standard power outlet that is
properly grounded through the standard electrical wiring. Non grounded equipment may cause an
electrical shock hazard, and may cause excessive electrical noise radiation.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injuries.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injuries.
IMPORTANT IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in
damage to property or loss of product functionality.
NOTE Notes tell you how you should respond to a situation that may arise or give tips about how the
operation works with other features.
Starter Ink Cartridges
Black
Yellow
Cyan
Magenta
Quick Setup Guide
Basic User’s Guide Product Safety Guide CD-ROM USB Interface Cable
Telephone Line Cord Adapter
(Australia only)
Power Cord
Cables vary depending on countries.
Taiwan model is using the power cord attached
on the machine.
Telephone Line Cord
NOTE
• Save all packing materials and the box in case for any reason you must ship your machine.
• For a network connection you will need to purchase a network interface cable. Please use the supplied USB
cable for a USB connection.
USB cable
It is recommended to use a USB 2.0 cable (Type A/B) that is no more than 2 metres long.
Network cable
Use a straight-through Category5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast
Ethernet Network.

2
aRemove the protective tape and film covering
the machine, and also from the Touchscreen.
bMake sure you have all the components.
2
Load plain A4 paper
CAUTION
DO NOT carry the machine by holding the scanner
cover or the Jam Clear Cover. Doing this may
cause the machine to slip out of your hands. Only
carry the machine by placing your hands under the
entire machine.
For detailed information, see the Product Safety
Guide.
aPull the paper tray acompletely out of the
machine.
bOpen the output paper tray cover a.
cGently press and slide the paper guides ato fit
the paper size. Make sure that the triangular
mark bon the paper guide alines up with the
mark for the paper size you are using.
dFan the stack of paper well to avoid paper jams
and misfeeds.
1
1
NOTE
Always make sure that the paper is not curled or
wrinkled.
1
2

3
eGently put the paper into the paper tray print
side down and top edge first.
fGently adjust the paper guides to fit the paper.
Make sure that the paper guides touch the
edges of the paper.
gCheck that the paper is flat in the tray and
below the maximum paper mark a. Close the
output paper tray cover.
hSlowly push the paper tray completely into the
machine.
iWhile holding the paper tray in place, pull out
the paper support auntil it clicks, and then
unfold the paper support flap b.
IMPORTANT
Be careful that you do not push the paper in too
far; it may lift at the back of the tray and cause
paper feed problems.
1
NOTE
For printing and copying on special media, open
the manual feed slot aon the back of the
machine. Feed only one sheet at a time of A3,
Ledger, Legal, envelopes, or thicker paper when
using the manual feed slot.
For details, see Loading paper in the manual feed
slot in chapter 2 of the Basic User’s Guide.
2
1
1

4
3
Connect the power cord
and telephone line
WARNING
• The machine must be fitted with an earthed
plug.
• Since the machine is grounded through the
power outlet, you can protect yourself from
potentially hazardous electrical conditions on
the telephone network by keeping the power
cord connected to your machine when you
connect it to a telephone line. Similarly, you
can protect yourself when you want to move
your machine by disconnecting the telephone
line first and then the power cord.
aConnect the power cord.
bLift the scanner cover until it locks securely into
the open position.
cConnect the telephone line cord.
Connect one end of the telephone line cord to
the socket of the machine marked LINE.
Carefully guide the telephone line cord into the
cable channel and out the back of the machine.
Connect the other end to a modular wall
socket.
IMPORTANT
DO NOT connect the USB cable yet (if you are
using a USB cable).
NOTE
To prolong print head life, provide the best ink
cartridge economy and maintain print quality, we
do not recommend frequently unplugging the
machine and/or leaving the machine unplugged
for extended periods of time. We recommend
using to power down the machine. Using
allows minimal power to the machine, which
ensures periodic cleaning of the print head.
(Example for Australia)
IMPORTANT
The telephone line cord MUST be connected to
the socket of the machine marked LINE.

5
dLift the scanner cover to release the lock a.
Gently push the scanner cover support
down band close the scanner cover cusing
both hands.
NOTE
If you are sharing one telephone line with an
external telephone, connect it as shown below.
aExtension telephone
bExternal telephone
1
2
3
(Example for Australia)
1
2
NOTE
If you are sharing one telephone line with an
external telephone answering machine, connect it
as shown below.
Set the receive mode to External TAD if you
have an external answering machine. See
Choose a Receive Mode on page 9. Detailed
information uuBasic User’s Guide: Connecting
an external TAD (telephone answering device)
(Example for Australia)

6
4
Set your country
(Australia and New
Zealand only)
You must set your country so that the machine works
correctly on local telecommunication lines in each
country.
aCheck that the power is turned on by
connecting in the power cord.
bPress your country (Australia or
New Zealand).
Press OK.
cIf the LCD shows the correct country, press
Yes, and then go to step d. Or press No, and
then go back to step band choose the country
again.
d After the LCD shows Accepted for a few
seconds, the machine will restart automatically.
5
Install the ink cartridges
CAUTION
If ink gets in your eyes, wash it out with water at
once and call a doctor if you are concerned.
aMake sure that the power is turned on.
The Touchscreen will show
No Ink Cartridge.
bOpen the ink cartridge cover a.
NOTE
Make sure you install the Starter Ink Cartridges
included with your machine first.
NOTE
You can adjust the angle of the control panel by
lifting it. When lowering the control panel, make
sure you push the release button athat is
located behind the mark.
1
1

7
cRemove the orange protective part a.
dUnpack the ink cartridge.
Turn the green release lever on the orange
protective packing acounterclockwise until it
clicks to release the vacuum seal. Then
remove the orange protective packing aas
shown.
eTake care to match the sticker colour awith
the cartridge colour bas shown in the diagram
below.
Install each ink cartridge in the direction of the
arrow on the label.
fGently push the back of the ink cartridge
marked “PUSH” until the cartridge lever lifts.
After all the ink cartridges are installed close
the ink cartridge cover.
NOTE
Do not throw away the orange protective part.
You will need it if you transport the machine.
IMPORTANT
• DO NOT shake the ink cartridges. If ink stains
your skin or clothing, wash with soap or
detergent at once.
• DO NOT touch the cartridge in the area
indicated b, as this can cause the machine not
to function with the cartridge.
1
1
2
1
2
IMPORTANT
After initial installation of the ink cartridges, the
machine will start cleaning the ink tube system.
This cleaning process will last approximately four
minutes.
DO NOT unplug the machine from the power
outlet or attempt to stop the cleaning process.
Interruption of cleaning process may cause
undesired print quality problems.
1
2

8
6
Check the print quality
aWhen the preparation process has finished, the
Touchscreen shows Set paper and press
[OK].
Press OK.
bCheck the quality of the four colour blocks on
the sheet. (black/yellow/cyan/magenta)
cIf all lines are clear and visible, press Yes to
finish the quality check and go to the next step.
If you can see missing short lines, press No and
follow the steps on the Touchscreen.
IMPORTANT
• DO NOT take out ink cartridges if you do not
need to replace them. If you do so, it may
reduce the ink quantity and the machine will not
know the quantity of ink left in the cartridge.
• DO NOT repeatedly insert and remove the
cartridges. If you do so, ink may seep out of the
cartridge.
• If you mix the colours by installing an ink
cartridge in the wrong position, clean the print
head several times after correcting the
cartridge installation. (uuBasic User’s Guide:
Cleaning the print head)
• Once you open an ink cartridge, install it in the
machine and use it up within six months of
installation. Use unopened ink cartridges by
the expiration date written on the cartridge
package.
• DO NOT dismantle or tamper with the ink
cartridge, this can cause the ink to leak out of
the cartridge.
• Brother multifunction machines are designed to
work with ink of a particular specification and
will work to a level of optimum performance
when used with genuine Brother branded ink
cartridges. Brother cannot guarantee this
optimum performance if ink or ink cartridges of
other specifications are used. Brother does not
therefore recommend the use of cartridges
other than genuine Brother branded cartridges
with this machine or the refilling of empty
cartridges with ink from other sources. If
damage is caused to the print head or other
parts of this machine as a result of using
incompatible products with this machine, any
repairs required as a result may not be covered
by the warranty.
OK
Poor

9
7
Review Touchscreen
display
The Touchscreen displays information on screen
operation and manual feed slot use. Review this
information and go to the next step. For details, see
the Basic User’s Guide.
8
Choose a Receive Mode
There are four possible receive modes: Fax Only,
Fax/Tel, Manual and External TAD.
uuBasic User’s Guide: Using Receive Modes
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dPress Receive Mode.
ePress Fax Only, Fax/Tel, External TAD
or Manual.
fPress .
Do you want to use the telephone features of your
machine (if available) or an external telephone or
external telephone answering device connected on the
same line as the machine?
Your machine
automatically answers
every call as a fax.
Your machine controls
the line and
automatically answers
every call. If the call is
not a fax, the telephone
will ring for you to pick
up the call.
Your external telephone
answering device (TAD)
automatically answers
every call. Voice
messages are stored
on the external TAD.
Fax messages are
printed.
You control the
telephone line and must
answer every call
yourself.
Do you want the machine to
answer fax and telephone calls
automatically?
Manual
Fax Only
Fax/Tel
External TAD
No
Yes
Yes
No
No
Yes
Are you using the voice message
function of an external telephone
answering device?

10
9
Set the date and time
The machine displays the date and time, and if you
set up the station ID, the date and time displayed on
your machine will be printed on every fax you send.
aPress .
bPress (Date and
Time).
cPress Date.
dEnter the last two digits of the year on the
Touchscreen, and then press OK.
eRepeat for month and day.
fPress Time.
gEnter the time on the Touchscreen in 24-hour
format.
hPress OK, and then press .
10
Enter personal
information (Station ID)
You should store your name and fax number to be
printed on all fax pages that you send.
Information on how to enter text uuBasic User’s
Guide: Entering Text
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dPress Station ID.
ePress Fax.
fEnter your fax number (up to 20 digits) on the
Touchscreen, and then press OK.
gPress Name.
hEnter your name (up to 20 characters) using
the Touchscreen, and then press OK.
iPress .
(e.g. Enter 12for 2012.)
00:00 01.01.2012
NOTE
• Press to cycle between letters, numbers
and special characters. (The characters
available may differ depending on your
country.)
• If you entered a number or a character
incorrectly and want to change it, press dor c
to move the cursor to the incorrect one. Press
and then re-enter the correct one.

11
11
Fax Transmission Report
Your Brother machine is equipped with a
Transmission Verification Report that can be used as
confirmation that you sent a fax. This report lists the
name or fax number of the receiving party, the date,
time, and duration of the transmission, the number of
pages transmitted, and whether or not the
transmission was successful.
Instructions on using this feature uuBasic User’s
Guide: Transmission Verification Report
12
Set Tone or Pulse dialling
mode (Not available in
New Zealand)
Your machine comes set for Tone dialling service. If
you have a Pulse dialling service (rotary), you need to
change the dialling mode.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dPress Tone/Pulse.
ePress Pulse (or Tone).
fPress .
13
Set the telephone line
compatibility (VoIP)
If you are connecting the machine to a VoIP service
(over the Internet) we recommend that you change
the modem speed to minimize errors in fax
operations.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto display
Initial Setup.
Press Initial Setup.
dSwipe up or down, or press aor bto display
Compatibility.
Press Compatibility.
ePress Basic(for VoIP).
fPress .
NOTE
If you are using an analogue telephone line you
can skip this step.

12
14
Set the Time Zone
You can set the time zone (not summer time but
standard time) on the machine for your location.
aPress .
bPress (Date and
Time).
cPress Time Zone.
dEnter your time zone.
Press OK.
ePress .
00:00 01.01.2012

13
Windows®Macintosh Windows®Macintosh
USB Wired Network Wireless Network
15
Choose your connection type
These installation instructions are for Windows®XP Home, XP Professional, XP Professional x64 Edition,
Windows Vista®, Windows®7, and Mac OS X v10.5.8, 10.6.x, 10.7.x.
NOTE
• For Windows Server®2003/2008/2008 R2, the drivers can be found from your model’s download page at
http://solutions.brother.com/.
• If your computer does not have a CD-ROM drive you can download the latest drivers, manuals and utilities
for your model from the Brother Solutions Center at http://solutions.brother.com/. Some software
applications included on the CD-ROM may not be available as a download.
For USB interface cable
Windows
®
, go to page 14
Macintosh, go to page 17
For Wired Network
Windows
®
, go to page 20
Macintosh, go to page 24
For Wireless Network
Windows
®
and Macintosh,
go to page 28

14
Windows®
USB
For USB interface users
(Windows®XP Home/XP Professional/Windows Vista®/Windows®7)
16
Before you install
Make sure that your computer is ON and you are
logged on with Administrator rights.
17
Install MFL-Pro Suite
aPut the supplied installation CD-ROM into your
CD-ROM drive. If the model name screen
appears, choose your machine. If the language
screen appears, choose your language.
bThe CD-ROM Top menu will appear.
Click Install MFL-Pro Suite and click Yes if
you accept the license agreements. Follow the
on-screen instructions.
cChoose Local Connection (USB), and then
click Next. The installation continues.
dWhen this screen appears, go to the next step.
IMPORTANT
• DO NOT connect the USB cable yet.
• If there are any programs running, close them.
NOTE
• The screens may differ depending on your
operating system.
• The CD-ROM includes Nuance™ PaperPort™
12SE*. This software supports Windows®XP
Home (SP3 or greater), XP Professional (SP3
or greater), XP Professional x64 Edition (SP2
or greater), Windows Vista®(SP2 or greater)
and Windows®7. Update to the latest
Windows®Service Pack before installing
MFL-Pro Suite.
* For Taiwan users, the CD-ROM includes Presto!
PageManager instead of Nuance™ PaperPort™12SE.
NOTE
• For Windows Vista®and Windows®7, when
the User Account Control screen appears click
Continue or Yes.
• If the Brother screen does not appear
automatically, go to My Computer or
Computer then double-click the CD-ROM icon
and double-click start.exe.

15
Windows®
USB
Windows®Macintosh
USB
18
Connect the USB cable
aLift the scanner cover until it locks securely into
the open position.
bConnect the USB cable to the USB port
marked with a symbol. You will find the
USB port inside the machine on the right as
shown below.
cCarefully guide the USB cable into the cable
channel and out the back of the machine.
Connect the cable to your computer.
dLift the scanner cover to release the lock a.
Gently push the scanner cover support
down band close the scanner cover cusing
both hands.
eThe installation will continue automatically.
The installation screens appear one after
another.
fIf Environmental Advice for Imaging
Equipment screen appears, click Next.
gWhen the On-Line Registration screen is
displayed, follow the on-screen instructions.
Click Next.
hIf you do not want to set your machine as the
default printer, uncheck Set as Default Printer
and click Next.
IMPORTANT
Make sure that the cable does not restrict the
cover from closing, or an error may occur.
IMPORTANT
DO NOT cancel any of the screens during the
installation. It may take a few seconds for all
screens to appear.
NOTE
For Windows Vista®and Windows®7, when the
Windows®Security screen appears, click the
check box and click Install to complete the
installation correctly.
1
2
3

16
Windows®
USB
19
Finish and restart
aClick Finish to restart your computer.
After restarting the computer, you must log on
with Administrator rights.
bThe following screens will appear.
• When the Software Update Setting screen
appears, choose the software update setting
you want and click OK.
• When the Brother Product Research and
Support Program screen appears, select
your preference and follow the on-screen
instructions.
To install optional applications:
Now go to
Page 44
NOTE
• If an error message appears during the
software installation, run the Installation
Diagnostics located in Start/
All Programs/Brother/MFC-JXXX (where
MFC-JXXX is your model name).
• Depending on your security settings, a
Windows®Security or antivirus software
window may appear when using the machine
or its software. Please allow the window to
continue.
NOTE
Internet access is required for the software
update and the Brother Product Research &
Support Program.
Finish
The installation is now
complete.
NOTE
XML Paper Specification Printer Driver
The XML Paper Specification Printer Driver is the
most suitable driver for Windows Vista®and
Windows®7 when printing from applications that
use the XML Paper Specification documents.
Please download the latest driver by accessing
the Brother Solutions Center at
http://solutions.brother.com/.

17
Macintosh
USB
Windows®Macintosh
USB
For USB interface users (Mac OS X v10.5.8, 10.6.x, 10.7.x)
16
Before you install
Make sure your machine is connected to the power
and your Macintosh is ON. You must be logged on
with Administrator rights.
17
Connect the USB cable
aLift the scanner cover until it locks securely into
the open position.
bConnect the USB cable to the USB port
marked with a symbol. You will find the
USB port inside the machine on the right as
shown below.
cCarefully guide the USB cable into the cable
channel and out the back of the machine.
Connect the cable to your Macintosh.
NOTE
For Mac OS X v10.5.0 to 10.5.7 users, upgrade to
Mac OS X v10.5.8 - 10.7.x.
IMPORTANT
• DO NOT connect the machine to a USB port on
a keyboard or a non-powered USB hub.
• Connect the machine directly to your
Macintosh.
IMPORTANT
Make sure that the cable does not restrict the
cover from closing, or an error may occur.

18
Macintosh
USB
dLift the scanner cover to release the lock a.
Gently push the scanner cover support
down band close the scanner cover cusing
both hands.
18
Install MFL-Pro Suite
aPut the supplied installation CD-ROM into your
CD-ROM drive.
bDouble-click the Start Here OSX icon to install.
If the model name screen appears, choose
your machine.
cChoose Local Connection (USB), and then
click Next. Follow the on-screen instructions.
dPlease wait for the software to install. After the
installation, the Brother software will search for
the Brother device. This will take a few
moments to complete.
eChoose your machine from the list, and then
click OK.
fWhen this screen appears, click Add Printer.
Choose your machine from the list. Click Add
and then click Next.
gWhen this screen appears, click Next.
The installation of MFL-Pro Suite is now
complete.
Go to step 19.
1
2
3

19
Macintosh
USB
Windows®Macintosh
USB
19
Download and install
Presto! PageManager
When Presto! PageManager is installed, OCR
capability is added to Brother ControlCenter2. You
can easily scan, share and organize photos and
documents using Presto! PageManager.
aOn the Brother Support screen, click the
Presto! PageManager to go to the
Presto! PageManager download site, and
follow the on-screen instructions.
Finish
The installation is now
complete.

20
Windows®
Wired Network
For wired network interface users
(Windows®XP Home/XP Professional/Windows Vista®/Windows®7)
16
Before you install
Make sure that your computer is ON and you are
logged on with Administrator rights.
17
Connect the network
cable
aLift the scanner cover until it locks securely into
the open position.
bYou will find the Ethernet port marked with a
symbol inside the machine on the left as
shown below. Remove the orange protective
cap and connect the network cable to the
Ethernet port.
IMPORTANT
If there are any programs running, close them.
NOTE
• The screens may differ depending on your
operating system.
• The CD-ROM includes Nuance™ PaperPort™
12SE*. This software supports Windows®XP
Home (SP3 or greater), XP Professional (SP3
or greater), XP Professional x64 Edition (SP2
or greater), Windows Vista®(SP2 or greater)
and Windows®7. Update to the latest
Windows®Service Pack before installing
MFL-Pro Suite.
* For Taiwan users, the CD-ROM includes Presto!
PageManager instead of Nuance™ PaperPort™12SE.
• If you have previously set up your machine for
a wireless network and then want to set it up on
a wired network, you should check that the
machine’s Network I/F is set to
Wired LAN. The wireless network interface
will become inactive with this setting.
On your machine, press .
Press All Settings.
Press Network.
Swipe up or down, or press aor bto display
Network I/F, and then press
Network I/F.
Press Wired LAN.
Press .
