Brother PJ-822 User manual

User's Guide
PJ-822
PJ-823
PJ-862
PJ-863
PJ-883
© 2022 Brother Industries, Ltd. All rights reserved.

Table of Contents
Before You Use Your Printer ................................................................................................................ 1
Definitions of Notes ........................................................................................................................................ 2
Safety Precautions ......................................................................................................................................... 3
General Precautions ...................................................................................................................................... 4
Trademarks and Licenses.............................................................................................................................. 5
Open Source Licensing Remarks .................................................................................................................. 6
Important Note ............................................................................................................................................... 7
Set Up Your Printer ............................................................................................................................... 8
Parts Description............................................................................................................................................ 9
Control Panel Overview ............................................................................................................................... 11
LED Patterns and Indications....................................................................................................................... 16
Install the Rechargeable Li-ion Battery ........................................................................................................ 20
Remove the Rechargeable Li-ion Battery .................................................................................................... 22
Connect the Printer to External Power......................................................................................................... 23
Turn the Printer On or Off............................................................................................................................. 25
Charge the Rechargeable Li-ion Battery...................................................................................................... 26
Load Paper in the Printer ............................................................................................................................. 28
Install Software.................................................................................................................................... 30
Install Printer Drivers and Software on a Computer..................................................................................... 31
Available Applications......................................................................................................................... 32
Connect the Printer to a Computer or Mobile Device................................................................................... 34
Connect the Printer to a Computer Using a USB Cable..................................................................... 35
Connect the Printer to a Computer Using Wi-Fi ................................................................................. 36
Connect the Printer to a Computer Using Bluetooth Connection ....................................................... 43
Connect the Printer to a Mobile Device Using NFC (Android) ........................................................... 44
Create and Print Documents Using Your Computer ........................................................................ 45
Create Labels Using P-touch Editor (Windows)........................................................................................... 46
Main Window of P-touch Editor Express Mode (Windows) ................................................................ 47
Main Window of P-touch Editor Professional Mode (Windows) ......................................................... 48
Main Window of P-touch Editor Snap Mode (Windows)..................................................................... 49
Print Documents Using P-touch Editor (Windows)....................................................................................... 50
Create and Print Custom Documents Using P-touch Editor (Mac) .............................................................. 51
Print Documents without Installing Software and Drivers ............................................................................ 52
Print Using the USB Interface (Mass Storage Mode)......................................................................... 53
Notes on Printing Image Data without Using the Printer Driver ......................................................... 54
Print a Document Using the Printer Driver (Windows/Mac) ......................................................................... 55
Print Settings (Windows) .................................................................................................................... 57
Print Settings (Mac)............................................................................................................................ 61
Print Documents Using Mobile Devices ........................................................................................... 63
Compatible Printing Apps............................................................................................................................. 64
AirPrint Overview ......................................................................................................................................... 66
Mopria® Print Service................................................................................................................................... 67
Transfer Templates Created on a Computer to the Printer Using a Mobile Device ..................................... 68
Transfer Templates to the Printer (P-touch Transfer Manager) (Windows) ................................... 69
Home > Table of Contents
i

Transfer Templates to the Printer Using P-touch Transfer Manager (Windows).......................................... 70
Notes on Using P-touch Transfer Manager (Windows) ...................................................................... 71
About Transferring Templates from the Computer to the Printer (Windows)...................................... 72
Back up Templates or Other Data Saved in the Printer (Windows).................................................... 80
Delete Printer Data (Windows)........................................................................................................... 81
Create Transfer Files and Transfer Package Files (Windows) ........................................................... 82
Distribute Templates to be Transferred to Users Without Using P-touch Transfer Manager (Windows) ..... 84
Store and Manage Templates (P-touch Library)............................................................................... 88
Edit Templates Using P-touch Library (Windows) ........................................................................................ 89
Print Templates Using P-touch Library (Windows)....................................................................................... 90
Search Templates Using P-touch Library (Windows)................................................................................... 91
Network ................................................................................................................................................ 93
Important Information for Security................................................................................................................ 94
Wireless Network Settings ........................................................................................................................... 95
Use the Wireless Network .................................................................................................................. 96
Enable or Disable Wi-Fi...................................................................................................................... 98
Brother Management Tools .......................................................................................................................... 99
Security .............................................................................................................................................. 100
Before Using Network Security Features ................................................................................................... 101
Configure Certificates for Device Security ................................................................................................. 102
Supported Security Certificate Features .......................................................................................... 103
How to Create and Install a Certificate............................................................................................. 104
Create a Self-signed Certificate ....................................................................................................... 105
Create a Certificate Signing Request (CSR) and Install a Certificate from a Certificate Authority
(CA) .................................................................................................................................................. 106
Import and Export the Certificate and Private Key ........................................................................... 110
Import and Export a CA Certificate................................................................................................... 113
Manage Multiple Certificates ............................................................................................................ 116
Use SSL/TLS ............................................................................................................................................. 117
Introduction to SSL/TLS ................................................................................................................... 118
Manage Your Network Printer Securely Using SSL/TLS ..................................................................121
Print Documents Securely Using SSL/TLS ...................................................................................... 126
Use SNMPv3.............................................................................................................................................. 128
Manage Your Network Printer Securely Using SNMPv3 ...................................................................129
Use IEEE 802.1x Authentication for a Wireless Network........................................................................... 130
What Is IEEE 802.1x Authentication? .............................................................................................. 131
Configure IEEE 802.1x Authentication for a Wireless Network Using Web Based Management
(Web Browser).................................................................................................................................. 132
IEEE 802.1x Authentication Methods............................................................................................... 134
Update ................................................................................................................................................ 135
Update P-touch Editor................................................................................................................................ 136
Update the Firmware.................................................................................................................................. 138
Printer Settings ................................................................................................................................. 140
Change Printer Settings Using the Printer Setting Tool (Windows) ........................................................... 141
Communication Settings of the Printer Setting Tool (Windows) ....................................................... 143
Device Settings of the Printer Setting Tool (Windows) ..................................................................... 149
P-touch Template Settings of the Printer Setting Tool (Windows) .................................................... 155
Home > Table of Contents
ii

Apply Setting Changes to Multiple Printers (Windows).............................................................................. 157
Change Printer Settings Using the Printer Setting Tool (Mac) ................................................................... 158
Setting Dialog Box of Printer Setting Tool (Mac) .............................................................................. 159
Apply Setting Changes to Multiple Printers (Mac)...................................................................................... 163
Change Printer Settings Using Web Based Management ......................................................................... 164
Set or Change a Login Password for Web Based Management...................................................... 165
Confirm Printer Settings ............................................................................................................................. 166
Routine Maintenance ........................................................................................................................ 167
Maintenance............................................................................................................................................... 168
Troubleshooting ................................................................................................................................ 170
If You Are Having Difficulty with Your Printer..............................................................................................171
Printing Problems....................................................................................................................................... 172
Network Problems...................................................................................................................................... 178
Version Information .................................................................................................................................... 181
Reset the Printer ........................................................................................................................................ 182
Appendix............................................................................................................................................ 183
Specifications ............................................................................................................................................. 184
Software Development Kit.......................................................................................................................... 187
Product Dimensions ................................................................................................................................... 188
Brother Help and Customer Support.......................................................................................................... 193
Home > Table of Contents
iii

Home > Before You Use Your Printer
Before You Use Your Printer
•Definitions of Notes
•Safety Precautions
•General Precautions
•Trademarks and Licenses
•Open Source Licensing Remarks
•Important Note
1

Home > Before You Use Your Printer > Definitions of Notes
Definitions of Notes
We use the following symbols and conventions throughout this User's Guide:
DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injuries.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injuries.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injuries.
IMPORTANT IMPORTANT indicates a potentially hazardous situation which, if not avoided, may
result in damage to property or loss of product functionality.
NOTE NOTE specifies the operating environment, conditions for installation, or special
conditions of use.
The tips icon indicates helpful hints and supplementary information.
Bold Bold style identifies buttons on the printer's control panel or computer screen.
Italics Italicized style emphasizes an important point or refers you to a related topic.
Related Information
•Before You Use Your Printer
2

Home > Before You Use Your Printer > Safety Precautions
Safety Precautions
IMPORTANT
• DO NOT remove the labels affixed to the printer. These labels provide operational information and
indicate the printer's model number.
• DO NOT push the power button or LED indicator with an object that has a sharp point, such as a pen.
This could damage the button or LED.
• DO NOT transport the printer while cables are connected to the AC/DC Connector or USB port. The
connector and ports could be damaged.
• DO NOT store the printer in an area exposed to high temperatures, high humidity, direct sunlight, or dust.
These could cause discoloration or a malfunction.
Related Information
•Before You Use Your Printer
3

Home > Before You Use Your Printer > General Precautions
General Precautions
Rechargeable Li-ion Battery
•At the time of purchase, the Rechargeable Li-ion Battery is slightly charged so that the operation of the printer
can be verified; however, before you use the printer for the first time, you must fully charge the Rechargeable
Li-ion Battery using the AC Adapter.
•If the printer is not in use for long periods, remove the battery and disconnect the cord before storing.
•If you notice anything unusual about the Rechargeable Li-ion Battery the first time it is used, for example
overheating or rust, immediately stop using the Rechargeable Li-ion Battery. Contact Brother Customer
Service.
Printer
•If the Bluetooth and wireless LAN functions are both turned on, the communication speed may decrease due
to radio wave interference. If this occurs, turn off the function you are not using (the Bluetooth or wireless
LAN function).
•DO NOT cover, or insert foreign objects into the Paper Outlet Slot, AC/DC Connector, or USB port.
•DO NOT use paint thinner, benzene, alcohol, or any other organic solvent to clean the printer. Doing so may
damage the casing finish. Use a soft, dry cloth to clean the printer.
•When using optional accessories, use them as described in their instruction manuals.
•This printer uses thermal paper. If the printed paper is marked with ink, for example written on or stamped,
the ink may cause the printed text to fade or become discolored. In addition, the applied ink may take some
time to dry.
Printed text may fade or become discolored if the label comes into contact with any of the following: vinyl
chloride products, leather goods such as wallets and purses, organic compounds such as alcohol, ketones,
or esters, adhesive tape, erasers, rubber mats, magic marker ink, permanent marker ink, correction fluid,
carbon, glue, diazo sensitized paper, hand lotion, hair care products, cosmetics, water, or sweat.
•DO NOT touch the printer with wet hands.
•DO NOT use folded, wet or damp paper, otherwise a paper misfeed or malfunction may occur.
•DO NOT touch paper or labels with wet hands, otherwise a malfunction may occur.
•DO NOT leave the Release Cover open. Internal parts of the printer may collect dust and result in printing
failure or paper jams.
Related Information
•Before You Use Your Printer
4

Home > Before You Use Your Printer > Trademarks and Licenses
Trademarks and Licenses
• Apple, App Store, Mac, Safari, AirPrint, the AirPrint logo, iPad, iPhone, iPod touch, macOS, and iPadOS are
trademarks of Apple Inc., registered in the United States and other countries.
• Android and Google Chrome are trademarks of Google LLC.
• The Bluetooth® word mark and logos are registered trademark owned by Bluetooth SIG, Inc. and any use of
such marks by Brother Industries, Ltd. is under license. Other trademarks and trade names are those of their
respective owners.
• Mopria®, the Mopria® Logo, the Mopria Alliance™ word mark and logo, and the Print. Scan. Go.™ tagline are
registered and/or unregistered trademarks and service marks of Mopria Alliance, Inc. in the United States and
other countries. Unauthorized use is strictly prohibited.
• QR Code is a registered trademark of DENSO WAVE INCORPORATED.
• Epson ESC/P is a registered trademark of Seiko Epson Corporation.
• Wi-Fi® is a registered trademark of Wi-Fi Alliance®.
• Wi-Fi Protected Setup™ is a trademark of Wi-Fi Alliance®.
• Mozilla and Firefox are registered trademarks of the Mozilla Foundation.
• QR Code Generating Program Copyright © 2008 DENSO WAVE INCORPORATED.
• BarStar Pro Encode Library (PDF417, Micro PDF417, DataMatrix, MaxiCode, AztecCode, GS1 Composite,
GS1 Databar, Code93, MSI/Plessey, POSTNET, Intelligent Mail Barcode)
Copyright © 2007 AINIX Corporation. All rights reserved.
• Blue SDK
Copyright © 1995-2021 OpenSynergy GmbH.
All rights reserved. All unpublished rights reserved.
• Portions of this software are copyright © 2014 The FreeType Project (www.freetype.org). All rights reserved.
• USB Type-C® is a registered trademark of USB Implementers Forum.
Any trade names and product names of companies appearing on Brother products, related documents
and any other materials are all trademarks or registered trademarks of those respective companies.
Related Information
•Before You Use Your Printer
5

Home > Before You Use Your Printer > Open Source Licensing Remarks
Open Source Licensing Remarks
This product includes open source software.
To see the Open Source Licensing Remarks, go to your model's Manuals page on the Brother support website
at support.brother.com.
Related Information
•Before You Use Your Printer
6

Home > Before You Use Your Printer > Important Note
Important Note
• The contents of this document and the specifications of this product are subject to change without notice.
• Brother reserves the right to make changes without notice in the specifications and materials contained
herein and shall not be responsible for any damages (including consequential) caused by the reliance on the
materials presented, including, but not limited to, typographical and other errors relating to the publications.
• For Windows 11 Users:
This printer supports Microsoft Windows 11.
All features in Windows 8.1 and Windows 10 are available in the Windows 11 environment and work in a
similar way.
• Screen images in this document may differ depending on your computer's operating system, your product
model, and software version.
• Before using the printer, make sure you read all the documents included with the printer for information about
safety and operation.
• The printer shown in the illustrations may be different from your printer.
• The available supplies may vary depending on your country or region.
• We recommend using the latest version of P-touch Editor.
• To keep your printer's performance up to date, visit support.brother.com to check for the latest firmware
updates. Otherwise, some of your printer's functions may not be available.
• When replacing or disposing of your printer, Brother strongly recommends resetting it to its factory settings
to remove all personal information.
Related Information
•Before You Use Your Printer
7

Home > Set Up Your Printer
Set Up Your Printer
•Parts Description
•Control Panel Overview
•LED Patterns and Indications
•Install the Rechargeable Li-ion Battery
•Remove the Rechargeable Li-ion Battery
•Connect the Printer to External Power
•Turn the Printer On or Off
•Charge the Rechargeable Li-ion Battery
•Load Paper in the Printer
8

Home > Set Up Your Printer > Parts Description
Parts Description
PJ-822/PJ-823
1
10
98
6
2
3
5
12
4
16
15
13
14
PJ-862/PJ-863/PJ-883
1
12
10
98
76
25
11
3
4
16
15
13
14
1. Power Button
2. Paper Input Slot
3. Tear Bar
4. Platen Roller
5. Paper Outlet Slot
6. Release Cover
7. Bluetooth Indicator (PJ-862/PJ-863)
Bluetooth and Wi-Fi Indicator (PJ-883)
8. Status Indicator
9. Data Indicator
10. Power Indicator
11. Bluetooth Button (PJ-862/PJ-863)
Bluetooth and Wi-Fi Button (PJ-883)
12. Feed Button
13. Battery Latches
14. USB Port
9

15. DC Connector
16. Battery Cavity Mounting Block
Related Information
•Set Up Your Printer
Related Topics:
•Control Panel Overview
10

Home > Set Up Your Printer > Control Panel Overview
Control Panel Overview
>> PJ-822/PJ-823
>> PJ-862/PJ-863
>> PJ-883
PJ-822/PJ-823
4 3 2
5
1
1. Power Button
Function Operation
Turn on the printer Press and hold the Power button for about one second until the
Power LED lights up.
Turn off the printer Press and hold the Power button for about one second. (If the Auto
Power Off feature is enabled in the Printer Setting Tool, the printer will
turn off automatically after the selected period of inactivity.)
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Windows).
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Mac).
Start the printer in Mass Storage
Mode
Press and hold the Power button and press the Feed button
simultaneously.
For more information about Mass Storage Mode, see Related Topics:
Print Using the USB Interface (Mass Storage Mode).
2. Status Indicator
3. Data Indicator
4. Power Indicator
5. Feed Button
Function Operation
Feed the paper Load the paper and press the Feed button to feed the paper.
If you continue to press and hold the Feed button after about 2.17 in.
(55 mm) of paper has been fed, approximately one page length of paper is
fed at high speed.
The amount of paper fed is determined by the Form Feed Mode setting in
the Printer Setting Tool.
11

Function Operation
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Windows).
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Mac).
To ensure that printing is complete, wait five seconds after the printer has
received the data before using a form feed command.
Print the configuration report You can print a configuration report without connecting the printer to a
computer or mobile device.
For more information, see Related Topics: Confirm Printer Settings.
PJ-862/PJ-863
6 5 4 3
21
8
7
1. Power Button
Function Operation
Turn on the printer Press and hold the Power button for about one second until the
Power LED lights up.
Turn off the printer Press and hold the Power button for about one second. (If the Auto
Power Off feature is enabled in the Printer Setting Tool, the printer will
turn off automatically after the selected period of inactivity.)
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Windows).
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Mac).
Start the printer in Mass Storage
Mode
Press and hold the Power button and press the Feed button
simultaneously.
For more information about Mass Storage Mode, see Related Topics:
Print Using the USB Interface (Mass Storage Mode).
2. Near-Field Communication (NFC) Sensor
3. Bluetooth Indicator
4. Status Indicator
5. Data Indicator
6. Power Indicator
7. Bluetooth Button
12

Function Operation
Enable/Disable the Bluetooth function Press the Bluetooth button .
8. Feed Button
Function Operation
Feed the paper Load the paper and press the Feed button to feed the paper.
If you continue to press and hold the Feed button after about 2.17 in.
(55 mm) of paper has been fed, approximately one page length of paper is
fed at high speed.
The amount of paper fed is determined by the Form Feed Mode setting in
the Printer Setting Tool.
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Windows).
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Mac).
To ensure that printing is complete, wait five seconds after the printer has
received the data before using a form feed command.
Print the configuration report You can print a configuration report without connecting the printer to a
computer or mobile device.
For more information, see Related Topics: Confirm Printer Settings.
PJ-883
6 5 4 3
21
8
7
1. Power Button
Function Operation
Turn on the printer Press and hold the Power button for about one second until the
Power LED lights up.
Turn off the printer Press and hold the Power button for about one second. (If the Auto
Power Off feature is enabled in the Printer Setting Tool, the printer will
turn off automatically after the selected period of inactivity.)
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Windows).
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Mac).
Start the printer in Mass Storage
Mode
Press and hold the Power button and press the Feed button
simultaneously.
13

Function Operation
For more information about Mass Storage Mode, see Related Topics:
Print Using the USB Interface (Mass Storage Mode).
2. Near-Field Communication (NFC) Sensor
3. Bluetooth and Wi-Fi Indicator
4. Status Indicator
5. Data Indicator
6. Power Indicator
7. Bluetooth and Wi-Fi Button
Function Operation
Enable/Disable the
Bluetooth and Wi-Fi
function
Press the Bluetooth and Wi-Fi button to enable or disable the Bluetooth and Wi-Fi
functions of the printer.
To toggle between connection modes, press and hold the Bluetooth and Wi-Fi button
for about three seconds. The connection mode changes each time you press and
hold the Bluetooth and Wi-Fi button .
The Bluetooth and Wi-Fi indicator color shows the wireless connection:
• Blue : Bluetooth
• Green : Wi-Fi
• Cyan : Both Bluetooth and Wi-Fi
Use WPS to
configure Wi-Fi
settings easily
Press and hold the Bluetooth and Wi-Fi button for about five seconds to configure
the Wi-Fi settings using WPS.
Use WLAN Assistant
Wizard to configure
Wi-Fi settings
Press and hold the Bluetooth and Wi-Fi button for about 10 seconds to configure the
Wi-Fi settings using WLAN Assistant Wizard.
8. Feed Button
Function Operation
Feed the paper Load the paper and press the Feed button to feed the paper.
If you continue to press and hold the Feed button after about 2.17 in.
(55 mm) of paper has been fed, approximately one page length of paper is
fed at high speed.
The amount of paper fed is determined by the Form Feed Mode setting in
the Printer Setting Tool.
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Windows).
For more information, see Related Topics: Change Printer Settings Using
the Printer Setting Tool (Mac).
To ensure that printing is complete, wait five seconds after the printer has
received the data before using a form feed command.
Print the configuration report You can print a configuration report without connecting the printer to a
computer or mobile device.
For more information, see Related Topics: Confirm Printer Settings.
14

Related Information
•Set Up Your Printer
Related Topics:
•Change Printer Settings Using the Printer Setting Tool (Windows)
•Change Printer Settings Using the Printer Setting Tool (Mac)
•Confirm Printer Settings
•Print Using the USB Interface (Mass Storage Mode)
15

Home > Set Up Your Printer > LED Patterns and Indications
LED Patterns and Indications
Your printer features three LED indicators labeled POWER, DATA, and STATUS that light and flash to indicate
the printer’s status. Each LED indicator may light or flash in a color shown below. The symbols used in this
section explain the meaning of the different indicator colors and patterns.
LED Indicator Color Description
/ / / / / Indicator is lit in the color shown.
/ / / / / Indicator is flashing in the color shown.
Indicator is off, lit, or flashing in any color.
Indicator is off.
Power Data Status Bluetooth
(PJ-862/PJ-863)
Bluetooth and
Wi-Fi (PJ-883)
Description
Battery charge
completed with the
AC Adapter, Car
Adapter, or USB
Type-C® AC Adapter
connected
Battery charging in
progress
Rechargeable Li-ion
Battery in use, battery
charge is full
(Once every four
seconds)
Rechargeable Li-ion
Battery in use, battery
charge is half-full
(Twice every four
seconds)
Rechargeable Li-ion
Battery in use, battery
charge is low
(Once every second)
Rechargeable Li-ion
Battery in use, charge
the battery
Battery charging while
printer is turned off
/ Printer in idle mode
(Once every 3.5
seconds)
Printer in Sleep mode
(Battery charging)
(Once every 3.5
seconds)
Printer in Sleep mode
(Battery not charging)
16
