User's Guide
QL-570VM
Be sure to read this guide before using the machine. We recommend that
you keep this guide nearby for future reference.
www.brother.com

2
Thank you for purchasing the Brother QL-570VM.
This guide briefly describes the steps to start using the Brother QL-570VM.
We strongly recommend that you read this guide carefully before using the Brother
QL-570VM, and then keep it nearby for future reference.
To take full advantage of our service and support we recommend that you take this
opportunity to register with us by visiting us at:
Online User Registration
http://registermybrother.com/
Online Support Page
http://solutions.brother.com/
If a UPC must be entered, refer to the back cover.
NOTE: It is also possible to access the above sites from the online user registration
window on the included CD-ROM. We look forward to your registration.
Federal Communications Commission (FCC) Declaration of Conformity (For USA Only)
Responsible Party: Brother International Corporation
100 Somerset Corporate Boulevard
Bridgewater, NJ 08807-0911 USA
TEL: [phone]
declares that the product
Products Description: Label Printer
Product Name: QL-570VM
Model Number: QL-570
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Important
• The enclosed USB interface cable should be used in order to ensure compliance with the
limits for a Class B digital device.
• Changes or modifications not expressly approved by Brother Industries, Ltd. could void the
user's authority to operate the equipment.

3
Brother®Two-Year Limited Warranty and Replacement Service
(USA Only)
Who is covered:
• This limited warranty ("warranty") is given only to the original end-use/retail
purchaser (referred to in this warranty as "Original Purchaser") of the
accompanying product, consumables and accessories (collectively referred to in
this warranty as "this Product").
• If you purchased a product from someone other than an authorized Brother reseller
in the United States or if the product was used (including but not limited to floor
models or refurbished product), prior to your purchase you are not the Original
Purchaser and the product that you purchased is not covered by this warranty.
What is covered:
• This Product includes a Machine and Consumable and Accessory Items.
Consumable and Accessory Items include but are not limited to label and tape rolls
and print servers.
• Except as otherwise provided herein, Brother warrants that the Machine and the
accompanying Consumable and Accessory Items will be free from defects in
materials and workmanship, when used under normal conditions.
• This warranty applies only to products purchased and used in the United States.
For products purchased in, but used outside, the United States, this warranty
covers only warranty service within the United States (and does not include
shipping outside the United States).
What is the length of the Warranty Periods:
• Machines: two year from the original purchase date.
• Accompanying Consumable and Accessory Items: 90 days from the original
purchase date or the rated life of consumable, whichever comes first.
What is NOT covered:
This warranty does not cover:
(1) Physical damage to this Product;
(2) Damage caused by improper installation, improper or abnormal use, misuse,
neglect or accident (including but not limited to transporting this Product without
the proper preparation and/or packaging);
(3) Damage caused by another device or software used with this Product (including
but not limited to damage resulting from use of non Brother®-brand parts and
Consumable and Accessory Items);
(4) Consumable and Accessory Items that expired in accordance with a rated life;
and,
(5) Problems arising from other than defects in materials or workmanship.
This limited warranty is VOID if this Product has been altered or modified in any way
(including but not limited to attempted warranty repair without authorization from
Brother and/or alteration/removal of the serial number).

4
What to do if you think your Product is eligible for warranty service:
Report your issue to our P-touch Customer Service Hotline at 1-877-BROTHER (1-
877- 276-8437) or to a Brother Authorized Service Center within the applicable
warranty period. Supply Brother or the Brother Authorized Service Center with a
copy of your dated bill of sale showing that this Product was purchased within the
U.S.. For the name of local Brother Authorized Service Center(s), call 1-877-
BROTHER (1-877-276-8437) or visit www.brother-usa.com.
What Brother will ask you to do:
After contacting Brother or a Brother Authorized Service Center, you may be required
to deliver (by hand if you prefer) or send the Product properly packaged, freight
prepaid, to the Authorized Service Center together with a photocopy of your bill of
sale.
You are responsible for the cost of shipping, packing product, and insurance
(if you desire).
You are also responsible for loss or damage to this Product in shipping.
INTRODUCTION
What Brother will do:
If the problem reported concerning your Machine and/or accompanying Consumable
and Accessory Items is covered by this warranty and if you first reported the problem
to Brother or an Authorized Service Center within the applicable warranty period,
Brother or its Authorized Service Center will repair or replace the Machine and/or
accompanying Consumable and Accessory Items at no charge to you for parts or
labor. The decision as to whether to repair or replace the Machine and/or
accompanying Consumable and Accessory Items is made by Brother in its sole
discretion.
Brother reserves the right to supply a refurbished or remanufactured replacement
Machine and/or accompanying Consumable and Accessory Items and use
refurbished parts provided such replacement products conform to the manufacturer's
specifications for new product/parts.
The repaired or replacement Machine and/or accompanying Consumable and
Accessory Items will be returned to you freight prepaid or made available for you to
pick up at a conveniently located Authorized Service Center.
If the Machine and/or accompanying Consumable and Accessory Items are not
covered by this warranty (either stage), you will be charged for shipping the Machine
and/or accompanying Consumable and Accessory Items back to you and charged for
any service and/or replacement parts/products at Brother's then current published
rates.

5
The foregoing are your sole (i.e., only) and exclusive remedies under this
warranty.
What happens when Brother elects to replace your Machine:
When a replacement Machine is authorized by Brother, and you have delivered the
Machine to an Authorized Service Center, the Authorized Service Center will provide
you with a replacement Machine after receiving one from Brother. If you are dealing
directly with Brother, Brother will send to you a replacement Machine with the
understanding that you will, after receipt of the replacement Machine, supply the
required proof of purchase information, together with the Machine that Brother agreed
to replace. You are then expected to pack the Machine that Brother agreed to replace
in the package from the replacement Machine and return it to Brother using the
prepaid freight bill supplied by Brother in accordance with the instructions provided by
Brother. Since you will be in possession of two machines, Brother will require that you
provide a valid major credit card number.
Brother will issue a hold against the credit card account number that you provide until
Brother receives your original Product and determines that your original Product is
entitled to warranty coverage. Your credit card will be charged up to the cost of a new
Product only if: (i) you do not return your original Product to Brother within five (5)
business days; (ii) the problems with your original Product are not covered by the
limited warranty; (iii) the proper packaging instructions are not followed and has
caused damage to the product; or (iv) the warranty period on your original Product has
expired or has not been sufficiently validated with a copy of the proof of purchase (bill
of sale).
The replacement Machine you receive (even if refurbished or remanufactured) will be
covered by the balance of the limited warranty period remaining on the original
Product, plus an additional thirty (30) days. You will keep the replacement Machine
that is sent to you and your original Machine shall become the property of Brother.
Retain your original Accessory Items and a copy of the return freight bill,
signed by the courier.

6
Limitations:
Brother is not responsible for damage to or loss of any equipment, media, programs
or data related to the use of this Product. Except for that repair or replacement as
described above, Brother shall not be liable for any direct, indirect, incidental or
consequential damages or specific relief. Because some states do not allow the
exclusion or limitation of consequential or incidental damages, the above limitation
may not apply to you.
THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER WARRANTIES, WRITTEN
OR ORAL, WHETHER EXPRESSED BY AFFIRMATION, PROMISE,
DESCRIPTION, DRAWING, MODEL OR SAMPLE. ANY AND ALL WARRANTIES
OTHER THAN THIS ONE, WHETHER EXPRESS OR IMPLIED, INCLUDING
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED.
• This Limited Warranty is the only warranty that Brother is giving for this Product. It
is the final expression and the exclusive and only statement of Brother's obligations
to you. It replaces all other agreements and understandings that you may have with
Brother or its representatives.
• This warranty gives you certain rights and you may also have other rights that may
vary from state to state.
• This Limited Warranty (and Brother's obligation to you) may not be changed in any
way unless you and Brother sign the same piece of paper in which we (1) refer to
this Product and your bill of sale date, (2) describe the change to this warranty and
(3) agree to make that change.
Important:
We recommend that you keep all original packing materials, in the event that you ship
this Product.

7
Important Information
Should you have questions, or need information about your Brother Product, we have
a variety of support options for you to choose from:
USA-Customer Service:
Customer Service
1-877-BROTHER (1-877-276-8437)
Customer Service
1-901-379-1210 (fax)
Website
www.brother-usa.com
Supplies / Accessories
www.brothermall.com
or 877-552-6255
BROTHER INTERNATIONAL CORPORATION
100 SOMERSET CORPORATE BLVD.
BRIDGEWATER, NEW JERSEY 08807-0911
Record your model and serial number and your date and location of Purchase below
for your records. Keep this information with your proof of purchase (bill of sale) in case
your Product requires service.
Model #
Serial #
Date of purchase:
Store where purchased:
Location of store:
Important: We recommend that you keep all original packing materials, in the event
that you need to ship the machine.
Save Time - Register On-Line!
Don’t stand in line at the post office or worry about lost mail. Visit us on-line at
www.registermybrother.com
Your product will immediately be registered in our database and you can be on your way!
Also, while you're there, look for contests and other exciting information!
If a UPC must be entered, refer to the back cover.

8
Contents
1Introduction ................................................. 12
1-1. General Information ................................................... 12
Compilation and Publication Notice............................................ 12
Trademarks ................................................................................ 12
Symbols Used in this Guide ....................................................... 13
1-2. Safety Precautions..................................................... 14
To use the machine safely .........................................................15
General Precautions................................................................... 17
2Getting started ............................................. 19
2-1. Unpacking the QL-570VM.......................................... 19
2-2. Parts Description (Main Printing Unit)........................ 20
Front ........................................................................................... 20
Rear............................................................................................ 20
2-3. Connecting the Power Supply.................................... 21
2-4. Removing the Protective Sheet ................................. 22
2-5. Installing the DK Roll.................................................. 23
2-6. Status LED Indications............................................... 25
2-7. Maintenance .............................................................. 26
Print head maintenance ............................................................. 26
Roller maintenance .................................................................... 26
Label outlet maintenance ........................................................... 28
3Installing the VM-100 Software.................. 29
3-1. Introduction ................................................................ 29
VM-100 Modes ........................................................................... 29
3-2. Installing the VM-100 Software .................................. 30
3-3. Uninstalling VM-100................................................... 34
3-4. Uninstalling the QL-570 printer driver ........................ 35

9
Contents
4Using the VM-100 Software ....................... 38
4-1. Launching the VM-100 Software................................ 38
Initial startup operation (Specifying the database file path)........ 39
4-2. Logging On ................................................................ 42
4-3. Logging Off ................................................................ 43
Administrator mode .................................................................... 43
Reception mode ......................................................................... 43
Self Check-in mode .................................................................... 43
5Administrator Mode .................................... 44
5-1. Administrator Mode Dialog Box ................................. 44
5-2. Initial Settings............................................................. 45
Editing login settings .................................................................. 45
Registering host information....................................................... 50
Importing host information.......................................................... 52
Options ....................................................................................... 56
5-3. List Management ....................................................... 64
Displaying the visitor log............................................................. 64
Exporting the visitor log ..............................................................66
Displaying host information ........................................................ 67
5-4. Important Administrator Functions ............................. 71
Printing emergency reports ........................................................ 71
Restoring the backup file............................................................ 72
6Reception Mode .......................................... 74
6-1. Receptionist Procedures............................................ 74
Making a reservation and signing in a visitor ............................. 74
Signing out a visitor .................................................................... 74
6-2. Reception Mode Window ........................................... 75
6-3. Entering Visitor Information........................................ 77
Entering new visitor information ................................................. 77
Recalling Visitor Information from Previous Visits
("Signed Out") ............................................................................ 80

Contents
10
Searching for host information ................................................... 82
6-4. Including Visitor Photos on Badges ........................... 84
6-5. Previewing Visitor Badges ......................................... 85
6-6. Signing In (Issuing Visitor Badges)/
Signing Out Visitors ................................................... 86
Signing in.................................................................................... 86
Signing out ................................................................................. 89
6-7. Issuing Visitor Badges without Signing In .................. 90
6-8. Issuing Parking Permits ............................................. 92
6-9. Making Visitor Reservations ...................................... 93
6-10. Editing Visitor Reservations ....................................... 95
6-11. Deleting Visitor Information........................................ 97
6-12. Printing Emergency Reports ...................................... 98
6-13. Backing Up Visitor Information................................... 98
7Self Check-in Mode .................................... 99
7-1. Initial Screen of Self Check-in Mode.......................... 99
7-2. Visitor Operations .................................................... 100
7-3. Exiting Self Check-in Mode or Printing
the Emergency Report ............................................. 101
Unlocking.................................................................................. 101
8Customizing Layouts................................. 103
9Troubleshooting ........................................ 107
9-1. QL-570 Label Printer................................................ 107
9-2. Visitor Badge & Management Software (VM-100) ... 108
10 Error Messages.......................................... 110

11
Contents
11 Reference................................................... 112
11-1. Main Specifications .................................................. 112
Product specifications .............................................................. 112
Operating environment............................................................. 112
11-2. Accessories (For USA Only) .................................... 113
DK Rolls .................................................................................. 113
Cleaning Sheet......................................................................... 114

12
1Introduction
1-1. General Information
Compilation and Publication Notice
• Under the supervision of Brother Industries Ltd., this guide has
been compiled and published, covering the latest product’s
descriptions and specifications.
• The contents of this guide and the specifications of this product
are subject to change without notice.
• The actual windows and dialog boxes of the software and its
operation may differ from those described in this manual. The
names of people and companies used in this manual and software
are fictional.
• Brother reserves the right to make changes without notice in the
specifications and materials contained herein and shall not be
responsible for any damages (including consequential) caused by
reliance on the materials presented, including but not limited to
typographical and other errors relating to the publication.
• The screen images in this guide can differ depending on your
Operating System (OS) or printer.
© 2008 Brother Industries Ltd.
Trademarks
• The Brother logo is a registered trademark of Brother Industries,
Ltd.
• Brother is a registered trademark of Brother Industries, Ltd.
© 2008 Brother Industries, Ltd. All rights reserved.
• Microsoft, Windows Vista, Windows Server and Windows are
either registered trademarks or trademarks of Microsoft Corp. in
the United States and/or other countries.
• The names of other software or products used in this document
are trademarks or registered trademarks of the respective
companies that developed them.
• Each company whose software title is mentioned in this guide has
a Software License Agreement specific to its proprietary
programs.
• All other brand and product names mentioned in this User's Guide
are registered trademarks of their respective companies.

13
Introduction 1
Symbols Used in this Guide
The symbols used throughout this guide are as follows:
NOTE
• This symbol shows information or directions that should be followed. If
ignored, the result may be damage, or failed operations.

Introduction
1
14
1-2. Safety Precautions
We recommend that you read all of these instructions prior to using this product,
and save them for later reference. Follow all warnings and instructions marked on
the product.
The symbols used in this guide are as follows:
WARNING Tells you what to do to avoid the risk of injury.
CAUTION Tells you about procedures you must follow to prevent damage to the
machine.
Action NOT allowed to do
DO NOT splash the product with or immerse the product in water.
Mandatory action
Alerts to the possibility of electrical shock
DO NOT disassemble the product.
DO NOT touch a given portion of the product.
Unplugging

15
Introduction 1
To use the machine safely
WARNING
Follow these guidelines to avoid fire, electric shock, or other damage.
The Machine
Unplug the power cord immediately and stop using the machine during an electrical storm.
There may be a remote risk of electric shock from lightning.
Do not touch any metal parts near the print head. The print head becomes very hot during
use and remains very hot immediately after use. Do not touch it directly with your hands.
Dispose of plastic bags correctly and keep away from babies and children. Do not wear or
play with plastic bags.
Unplug the power cord immediately and stop using the machine if you notice any abnormal
odor, heat, discoloration, deformation or anything unusual whilst the machine is in use or
storage.
Do not disassemble the machine. For inspection, adjustment and repair of the machine
contact the retail outlet where the machine was purchased or your local authorized service
center.
Do not drop, hit or otherwise bang the machine.
Do not hold and lift the machine by the DK Roll cover. The cover could come off and the
machine could fall and become damaged.
Do not allow the machine to get wet in any way.
Do not use the machine with foreign objects in it. If water or any foreign objects should
enter the machine, unplug the power cord from the electric outlet and remove the foreign
object. If necessary, contact the retail outlet where the machine was purchased or your
local authorized service center.
Do not hold the machine with only one hand. The machine may slip out of your hand.
Never disassemble the machine or allow it to get wet to avoid possible fire or electrical
shock. Doing so could cause an electrical shock or fire.
Do not use paint thinner, benzene, alcohol or any other organic solvents to clean the
machine. Doing so may cause damage to the surface finish. Use a soft, dry cloth to clean
the machine.
Do not put any heavy objects or objects containing water on top of the machine.
If water or any foreign object enters the machine, contact the retail outlet where the
machine was purchased or your local authorized service center. If you continue to use the
machine with water or a foreign object in the machine, the machine may be damaged or
personal injury could result.
The electrical outlet should be close to the machine and be easily accessible.
Do not touch the cutter. Personal injury could result.
Do not expose the machine to direct sunlight or near heaters or other hot appliances, in
any area exposed to extremely high or low temperatures, high humidity or dusty areas.
Doing so could cause the machine to malfunction.

Introduction
1
16
Follow these guidelines to avoid fire, electric shock, or other damage.
Power Cord
Use only the authorized power source (120V AC) for the machine.
Use only the power cord included with the machine.
Do not handle the power cord or plug if your hands are wet.
Do not overload the electrical outlet sockets with too many appliances or plug the power
cord into a damaged electrical outlet.
Do not cut, damage, alter or place heavy objects on the power cord.
Do not use the power cord if it is damaged.
Ensure the power cord is correctly inserted into the electrical outlet.
Always hold the power cord when unplugging the power cord from or plugging it into
electrical outlet. Do not pull on the power cord. The wire in the electrical cord may become
damaged.
If the machine will not be used for an extended period, remove the power cord from the
electrical outlet.
Cutter
Do not touch the blade of the cutter.
Do not open the top cover when the cutter is operating.
CAUTION
Follow these guidelines to avoid fire, electric shock, or other damage.
Installation/Storage
Put the machine on a flat, stable surface such as a desk.
Do not put any heavy objects on top of the machine.
DK Roll (DK Label, DK Tape)
Be careful not to drop the DK Roll.
DK Rolls use thermal paper and thermal film. Both the label and print will fade with sunlight
and heat. Do not use DK Rolls for outdoor use that requires durability.
Depending on the area, material, and environmental conditions, the label may unpeel or
become irremovable, the color of the label may change or be transferred to other objects.
Before applying the label, check the environmental condition and the material. Test the
label by affixing a small piece of it to an inconspicuous area of the intended surface.
WARNING

17
Introduction 1
General Precautions
The Machine
• The machine is a precision machine. Do not drop, hit or otherwise bang the
machine.
• Do not lift the machine by the DK Roll compartment cover. The cover could
come off and the machine could fall and become damaged.
• The machine may malfunction if left near a television, radio, etc. Do not use
the machine near any machine that can cause electromagnetic interference.
• Do not insert any objects into or block the label output slot or USB port.
• Use only the interface cable (USB cable) included with the machine.
• When not in use for an extended period, remove the DK Roll from the
machine.
• Do not attempt to print labels while the DK Roll cover is open.
Power Cord
• You should put the machine near an easily accessible, standard electrical
socket.
DK Roll (DK Label and DK Tape)
• Use only genuine Brother accessories and supplies (with , marks).
Do not use any unauthorized accessories or supplies.
• If the label is attached to a wet, dirty, or oily surface, it may peel off easily.
Before applying the label, clean the surface to which the label will be applied.
• DK Roll uses thermal paper and thermal film so that ultraviolet rays, wind,
and rain may cause the color of the label to fade and the ends of the label
to peel off.
• Do not expose the DK Rolls to direct sunlight, high temperatures, high
humidity, or dust. Store in a cool, dark place. Use the DK Rolls soon after
opening the package.
• Scratching the printed surface of the label with your finger nails or metal
objects, or touching the printed surface with hands dampened by water,
sweat, or medicated cream, etc., can cause the color to change or fade.
• Do not apply labels to any persons, animals, or plants.
• As the end of the DK Roll is designed to not adhere to the label spool, the
last label may not be cut properly. If this happens, remove the remaining
labels, insert a new DK Roll, and reprint the last label.
Note: To account for this, the number of DK Labels included on each DK Roll
may be more than indicated on the package.

Introduction
1
18
• If a label is removed after begin applied to a surface, some portion of the
label may remain. Remove the remaining portion before attaching a new
label.
• Some DK Rolls use permanent adhesive for their labels. These labels
cannot be easily peeled off once attached.
• Prior to using CD/DVD labels, be sure to follow the instructions in your CD/
DVD player's instruction guide regarding applying CD/DVD labels.
• Do not use CD/DVD labels in a slot loading CD/DVD player, for example a
CD player in a car where the CD is slid into a slot in the CD player.
• Do not peel off the CD/DVD label once it is applied to the CD/DVD, a thin
surface layer may come off, resulting in damage to the disk.
• Do not apply CD/DVD labels to CD/DVD disks designed for use with ink jet
printers. Labels peel off these disks easily and using disks with peeled labels
can result in loss or damage of data.
• When applying CD/DVD labels, use the applicator included with the CD/
DVD label rolls. Failure to do so could cause damage to the CD/DVD player.
• User's shall take full responsibility for applying CD/DVD labels. Brother
accepts no responsibility for any loss or damage of data caused by the
inappropriate use of CD/DVD labels.
CD-ROM and Software
• Do not scratch or subject the CD-ROM to high or low temperatures.
• Do not put heavy objects on the CD-ROM or apply force to the CD-ROM.
• The software contained on the CD-ROM is meant for use with the machine
only. See the License on the CD for details. This software may be installed
on multiple computers for use in an office, etc.
When you handle personal information, comply with relevant
laws or guidelines in your country.

19
2Getting started
2-1. Unpacking the QL-570VM
Check that the package contains the following before using the printer. If any item
is missing or damaged, contact your Brother dealer.
QL-570
USB cable
CD-ROM
AC Power cord
The plug may differ by country.
DK Roll
The Brother QL-570VM includes two
rolls of DK-N5224, containing 2-1/8" (54
mm) × 100 feet non-adhesive tape.
User's Guide
Quick Reference Sheet
Registration Card
Cleaning Sheet
Badge holders and lanyards (12)

Getting started
2
20
2-2. Parts Description (Main Printing
Unit)
Front
Rear
FEED button
CUT button
LED lamp
ON/OFF button
DK Roll compartment cover
Power port
Power cord
USB port
