Brush Bandit 2000XP User manual

STUMP GRINDER
MODELS 2000XP / 2100SP
OPERATING & PARTS MANUAL
MANUFACTURED BY
BANDIT INDUSTRIES, INC.
6750 Millbrook Road
REMUS, MICHIGAN, USA 49340
PHONE: [phone] IN USA
PHONE: [phone] OR 561-2272
FAX: [phone] ~ SALES DEPT.
FAX: [phone] ~ PARTS/SERVICE
E-MAIL: www.banditchippers.com
Model No: _________________
Serial No: _________________
DEALER:
Name: ____________________
Address: __________________
City/State: _________________
Phone No: _________________
Delivery Date: ______________
Engine Make: ______________
Serial No: _________________
Clutch Make: _______________
Model: _________ S/N _______
Copyright 5/09
ATTENTION:
Depending on what replacement
parts you are ordering, we will
need the following information:
GRINDER COMPONENTS
Serial Number
Model Number of Grinder
ENGINE COMPONENTS
Brand
Engine Serial Number
Engine Spec. Number
CLUTCH COMPONENTS
Brand
Serial Number
Assembly of Clutch
BUILT WITH QUALITY
AND DESIGN FIRST

I have inspected this equipment and nd it in correct working condition. To the best of my knowledge, the customer and
his/her personnel are aware of, and agree to the above procedures.
Signed: ________________________________________________________________________ Date: ______________
(Dealer Representative)
The equipment has been thoroughly checked by the above named dealer representative, and I am satised with his/her
instructions. I have also read, understand, and agree to reverse side of page.
Signed: ________________________________________________________________________ Date: ______________
(Customer)
Copyright 12-07 FORM #WV-124
IT IS VERY IMPORTANT THAT THIS FORM IS FILLED OUT COMPLETELY & ACCURATELY. IF WE CANNOT READ THE
PURCHASER’S INFORMATION OR IT IS INCORRECT, OUR CUSTOMER LIST WILL NOT BE ACCURATE.
IMPORTANT - THIS FORM MUST BE RETURNED TO THE
CUSTOMER DATA DEPARTMENT WITHIN TEN (10)
DAYS IN ORDER TO VALIDATE WARRANTY
WARRANTY VALIDATION FORM
(STUMP GRINDER)
PURCHASER INFORMATION:
Company Name _____________________________________ Mailing/Street Address __________________________
City __________________________________________ State _________________ Zip Code _________________
Telephone Number ( ____ ) _______________________ E-mail ___________________________________________
Contact Name ___________________________ Stump Grinder Model No. ___________ Serial No. _____________
Date Put Into Service _____________________ Engine Make & S/N _______________________________________
DEALER INFORMATION:
Dealer Name _______________________________ Mailing/Street Address __________________________________
City __________________________________________ State __________________ Zip Code _________________
Telephone Number ( ____ ) ___________________________ Contact Name _________________________________
1. _______ Customer has been instructed and understands operation and all safety aspects of operating the equipment.
2. _______ Customer has been instructed and understands that everyone within 100 feet (30 m) of machine must wear
personal safety equipment (i.e. hard hat, face shield, safety glasses, gloves, ear protection, etc.)
3. _______ Customer has been instructed and understands equipment maintenance schedules, procedures, and that it
is their responsibility to perform maintenance (i.e. retightening all fasteners as needed, clutch and
belt adjustments, etc.)
4. _______ Customer has been advised and understands not to reach near the cutter head with hands or feet or to be
 locatedneardebriseldwithenginerunning.Themachineoperatorsmustalways be located within easy
reach of all control and shut down devices.
5. _______ Customer understands to not start grinding a stump without checking for power lines, water lines, sewer lines,
phone lines, etc.
6. _______ Customer understands the purpose of and how to operate the shut down/shut-off devices, and will not
attempt to override any safety devices or guards.
7. _______ Customer has been instructed and understands to always remove the ignition key and completely disconnect
battery from cables, wait for the cutter head to come to a complete stop, and to install the cutter head lock
before performing any type of maintenance on the machine. Allow all the time necessary for the cutter head
to come to a complete stop before opening the cutter head guard or starting any maintenance or service
procedures. Customer has been shown and understands the purpose of the beltshield inspection hole and to
 notattemptanymaintenanceuntilbeltsarevisuallyconrmedtohavecometoacompletestop.
8. _______ Customer has been instructed and understands: To Not operate this machine without the factory approved
cutter head guard assembly in place. To Not operate this machine with any type of make shift cutter head
guard. To Not operate this machine under any circumstances with the cutter guard open or unsecured.
9. _______ Customer has reviewed and understands limited warranty, and all written and visual instructions.
10. _______ Customer hasreceived,beenadvised, andunderstands the manuals, and the Safety/Service video supplied
with the grinder. A video is supplied for equipment models as available.
11. _______ All Danger, Warning and Operational decals are properly displayed on equipment and fully understood by customer.
12. _______ Customer has been instructed, understands, and agrees that all potential operators must: See the supplied video,
be instructed on all the Danger, Warning and Operational decals, read the manual and follow the procedures.
Customer Data Department
6750 Millbrook Road
Remus, MI, USA 49340
Phone: [phone] in USA
Phone: [phone]
Fax: [phone]
E-mail: www.banditchippers.com

OPERATING INSTRUCTIONS
BRUSH BANDIT STUMP GRINDERS
THIS IS GENERAL INFORMATION REVIEW, UNDERSTAND AND FOLLOW DETAILED
INFORMATION IN MANUALS AND DECALS AT ALL TIMES
Torn or loose clothing is more likely to get
caught in moving machinery parts. Keep such
items as long hair, shirt sleeves, and shirt tails
properly contained. Avoid wearing necklaces,
rings, watches, and especially neckties while
operatingthismachinery. Make sure the machine
is in excellent condition, and all the guards are in
place, tight and secure.
Wear all personal protection equipment and
follow all safety standards per ANSI and OSHA
instructions. Examples of equipment: hard hat,
faceshield,safetyglasses,gloves,earprotection,
etc.Alwayskeepafullychargedreextinguisher
with the machine while operating or servicing the
machine.
DANGER
DANGER
This machine is equipped with safety decals,
guards and designs for your protection.
Don’tevertakethemachineforgranted,always
be cautious and careful when operating your
equipment.
Read and follow all the instructions in your
manual thoroughly. Your safety is dependent on
your knowledge of how to operate and maintain
this machine. You may obtain additional copies
of this manual from your Bandit Dealer.
Before operating machine, you must have
all potential operators; read and understand
manuals and decals, watch video and follow the
recommendations.
Regardless of how hard a manufacturer tries to
produce a safe machine, accidents still happen.
Normally accidents are caused by people making
mistakes. They do not read the manual, they
ignore warning decals or do not use lockouts
provided for their safety. This normally happens
after the person has become accustomed to the
machinery. In the initial start up and operation
of the machinery, they are cautious, they are
very careful because they do not understand the
machine.
Thisequipmentisintendedforuseby personnel
who are experienced with similar equipment.
Always operate safely. It is also recommended
that someone else is present while operating or
servicingin case an accident should occur. Never
operateanymachinewhileundertheinuenceof
drugs or alcohol.
Keep children, bystanders and animals clear of
working area. Never operate equipment that is in
need of repair or adjustment.
DANGER
Signal Word Likelihood of Occurrence Degree of Potential
Injury or Damage
DANGER Will occur if warning is ignored
Can occur if warning is ignored
Will or can occur if warning is ignored
Important, but not hazard related
Severe
Severe
Minor
Minor to Severe
SAFETY ALERT SYMBOLS AND NOTATIONS
WARNING
CAUTION
NOTICE
WARNING
START-UP PROCEDURES
Position the engage handle in the disengaged
position and start the engine. Let the engine
warm up at 1000 RPM’s. (Follow engine manual
information.) The machine may show signs of
vibration until the engine can brought up to full
throttle. Theengine causes most of this vibration
until it is brought up to full throttle. Engage
belt/clutch, if applicable.
Oncetheengineisproperlywarmedup,bringthe
engine to full throttle. (Follow engine break-in
procedures.)
Make sure to wear all personal protection
equipment and follow all safety standards per
ANSI and OSHA instructions. Examples of
equipment: hard hat, face shield, safety glasses,
gloves, ear protection, etc.
Never grind any materials that might contain
wires, stones, nails, or other metal objects which
may damage the teeth and become dangerous
projectiles. Remove all rocks and stones from
stump grinding area.
DANGER
Do Not start to grind a stump unless you are
completely sure there are not any power lines,
water lines, sewer lines, phone lines, etc. in the
area above or below ground level where you are
grinding.
Nevergo near cutterwheel or teethwhile engine
is running or cutter wheel is coasting to a stop.
DANGER
DANGER
Before starting the machine, take a minute to
check a few things. The grinder should be in an
area restricted from people passing by. This area
around the grinder must be free of all objects that
can obstruct movement when working with the
grinder. The machine should be checkedforloose
tools or foreign objects, especially in the grinding
area. All tools not in use should be secured in a
tool box.
Operators must at all times be located within
easy reach of all feed control and shut-off devices
when the unit is running. They must be attentive
and prepared to activate the devices.
Before attempting any type of maintenance
disengageclutch, turnoffengine,wait forthecutter
wheelto come to a completestop,install the cutter
wheellockpin,disconnectbattery, and make sure
the ignition key is in your possession.
ALWAYS install the lock pin into the cutter lock
tube before working on the grinder.
Simply slide the lock pin into the cutter wheel
lock tube. This is to insure that the cutter wheel
cannot be started while you are working on the
grinder. If for some reason thecutter wheel would
start to turn, it would simply hit the lock pin.
DANGER
 Donotgonearorin-linewiththedebriseld
of the stump grinder while in operation. While
grinding stumps, the chips and portions of the
stump y from the cutterhead and can cause
severe injury.
DANGER
It is very important after you have operated a
new machine for approximately an hour to shut
down the machine and recheck all nuts and bolts.
It is normal for nuts and bolts to loosen once on
a new piece of machinery. If you tighten them
now, there is a good possibility they won’t loosen
again. Certain nuts and bolts must be checked
periodically such as cutter teeth bolts, etc. for
torqueandt.
Most of the nutsused on the Bandit Grinderare
self locking.After a nut or bolt has been removed
vetimes,itshouldbereplacedtoinsureproper
tightness. This is especially critical on the cutter
tooth bolts!
After the engine is started, let the cuter wheel
turn at the lowest RPM’s possible. Listen for any
type of noise that is foreign. Any steel on steel
noise is foreign. If you hear a noise, stop the
engine,ndtheproblemandxit.
WARNING
Cutter Wheel
Cutter Wheel
Guard
Belt Engage Handle
Jack Shaft
Guard
Jack Shaft
Beltshield
Fuel Tank
Hydraulic Tank
Chip Curtain
Chock Block
Cutter Wheel
Lock Pin

Copyright 7-04 FORM #Q-112
DATE PURCHASED: _________________
MODEL: ___________________________
SERIAL NUMBER: ___________________
DEALER NAME: ____________________
___________________________________
TO BE RETURNED AFTER THIRTY (30) DAYS OF OPERATION
Please return to: Customer Data Department
6750 Millbrook Road
Remus, MI 49340
PH: [phone] in USA
PH: [phone]
FAX: [phone]
E-MAIL: www.banditchippers.com
STUMP GRINDER QUALITY REPORT
All of the employees that build your equipment strive to manufacturer the very best quality product on the market.
We would appreciate your efforts in letting us know how we are doing.
We would like you to operate your machine for thirty (30) days and then ll out this questionnaire and mail it to us.
This will help us to keep producing a good product and improving our products through your recommendations.
1. Did your machine perform to your expectations? ____________________________________________
2. Was the machine delivered on schedule? __________________________________________________
3. Was the paint color and nish to your satisfaction? __________________________________________
4. Was machine equipment as ordered? _____________________________________________________
5. Did all welds appear to be of high quality? _________________________________________________
6. Was the overall machine to your liking? ___________________________________________________
7. What problems have you experienced? ___________________________________________________
8. Have any components regularly loosened that caused problems? _______________________________
9. Does the hydraulic system seem to have adequate power? ____________________________________
10. Is the machine manufactured to accommodate service in an adequate manner? If not, please explain:
___________________________________________________________________________________
11. General comments and/or suggestions: ___________________________________________________
___________________________________________________________________________________
___________________________________________________________________________________
12. Would you like to be contacted concerning more of our equipment? _____________________________
YOUR COMPANY:__________________________________
NAME: __________________________________________
ADDRESS: ______________________________________
CITY: ___________________________________________
STATE & ZIP: ____________________________________
PHONE: ( ______ ) ________________________________
E-MAIL: _________________________________________

Bandit
Copyright 5/09 PAGE 1
MODELS 2000XP / 2100SP
TABLE OF CONTENTS
PAGES
INTRODUCTION & WARRANTY ..................................................... 2
SERIAL NUMBER LOCATIONS ...................................................... 6
SAFETY PROCEDURES ................................................................. 7
EQUIPMENT SPECIFICATIONS ...................................................... 11
DECALS ........................................................................................... 12
SUPER SWEEP OPTION ................................................................. 17
CONTROLS ...................................................................................... 21
MACHINE OPERATION ................................................................... 29
TRANSPORTATION PROCEDURES ............................................... 33
MAINTENANCE ............................................................................... 35
HYDRAULIC SECTION ............................................................ 50
CUTTER WHEEL SECTION .................................................... 64
LUBRICATION & COOLANT ................................................... 66
ELECTRICAL SECTION .......................................................... 67
REPLACEMENT PARTS SECTION ................................................. 75
CUTTERWHEEL COMPONENTS ............................................ 76
UPPER FRAME COMPONENTS ............................................. 78
ENGINE MOUNT COMPONENTS ........................................... 84
BELT ENGAGE COMPONENTS ............................................. 86
PIVOT BRACKET COMPONENTS .......................................... 90
FRAME COMPONENTS .......................................................... 91
STEERING COMPONENTS ..................................................... 98
CONTROL BOX COMPONENTS ............................................. 112
TANK COMPONENTS ............................................................. 117
REMOTE CONTROL COMPONENTS ..................................... 120
HYDRAULIC COMPONENTS .................................................. 122
SERVICE RECORD .......................................................................... 134
TABLE OF CONTENTS
ANYPART,PORTION,DESIGN,NUMBER,SPECIFICATION,AND/ORDIMENSIONINTHIS
MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE BY THE MANUFACTURER.
NOTICE

Bandit
Copyright 5/09 PAGE 2
INTRODUCTION
The purpose of this manual is to provide the user with specications and procedures for the operation,
maintenance and repair of this BANDIT product. As with any piece of equipment, safety should always
be a constant thought while the machine is being operated, serviced or stored. In order to highlight
this consideration, the material which addresses safety is proceeded by the following signal words:
Theequipmentis designedandmanufacturedinaccordancewiththelatestproductindustrystandards.
This alone does not prevent injury. It is the operator’s responsibility to use good judgement and follow
the warnings and instructions as indicated in this manual, on the machine and follow all safety standards
per ANSI and OSHA instructions.
Improper use of the product can result in severe personal injury. Personnel using the equipment
must be qualied, trained and familiar with the operating procedures as dened in this manual, prior
to operating the product.
It is the responsibility of the owner or employer to insure that the operator is trained and practices
safe operation while using and servicing the machine. It is also the owner’s responsibility to provide
and follow a regularly scheduled preventative maintenance and repair program on the product,
using only factory approved replacement parts. Any unapproved repairs or modications may not
only damage the machine and its performance, but could result in severe personal injury. Unapproved
repairs or modications will void warranty and eliminate manufacturer of any liability claims. Consult
the equipment manufacturer!!!
Each machine is shipped with a manual, a customer’s check sheet on the product, and any
available parts & service manuals on component parts not produced by this manufacturer. Additional
copies of these manuals and check sheets can be purchased from the manufacturer, or through the
dealer. Engine parts, service and maintenance manuals MUST be purchased through the engine
manufacturer or their dealer.
The producer of this Bandit product reserves the right to make any modications or revisions to the
design or specications of its machine without advance notice. The producer also reserves the right
to change machine and part prices as needed without advance notice.
INTRODUCTION & WARRANTY
WARNING
WARNING
NOTICE
Signal Word Likelihood of Occurrence Degree of Potential
Injury or Damage
DANGER
WARNING
CAUTION
NOTICE
Will occur if warning is ignored
Can occur if warning is ignored
Will or can occur if warning is ignored
Important, but not hazard related
Severe
Severe
Minor
Minor to Severe

Bandit
Copyright 5/09 PAGE 3
BANDIT INDUSTRIES, INC.
EXPLANATION OF LIMITED WARRANTY
There are several forms that must be
completely lled out and returned to us in
reference to our portion of warranty. Read
and understand the Bandit Limited Warranty
responsibilities. Some components on your
machine are covered by their respective
manufacturersandcannotbehandledthrough
Bandit Industries as stated in Warranty
Section of this manual.
Use this manual to help you resolve what and
where your problem is, in most cases you
can x it easily. If you still have problems,
work through the dealer you purchased the
machine through, or contact Bandit Industries
direct if needed.
Make sure the following forms are used, for
us as well as you, to keep track of service
and pending warranty request. It is our
company policy that all parts shipped out will
be invoiced until the possible warranty parts
are returned with a Warranty Claim Form
completed for consideration.
Make sure the Warranty Validation Form is
completed and sent in to us as soon as you
receive the Bandit. This will activate our
warranty responsibilities.
If Warranty Validation Form is not on le,
all Warranty consideration is null and
void.
The manufacturer will not reimburse the customer or dealer labor costs incurred for installing
“bolt-on” or “slip-on” items, such as hydraulic pumps and motors, control valves, ow dividers,
belts, sheaves, etc. The manufacturer will provide replacement parts to the customer for
defective parts during the warranty period. Defective parts must be returned to Bandit
Industries, Inc. It will be the customer’s responsibility to install the replacement parts unless
arrangements are made with the selling dealer.
The manufacturer will not reimburse travel costs to servicing dealer unless prior approval has
beenobtainedfromthe manufacturer. It isthecustomer’sresponsibilityto deliverthe machine
to dealer’s service facility, unless other arrangements have been agreed to between selling
dealer and customer.
The manufacturer may elect, at its discretion, to reimburse reasonable labor costs to customer
or dealer for major defect repairs. Diagnostic labor and overtime labor will not be covered
under warranty. Prior approval must be obtained from Bandit Industries, Inc.
Prior to delivery to nal owner and during storage, this machine must be serviced and
lubricatedtoavoiddamagethatwillnot be covered under warranty, see “Lubrication & Coolant”
page.
Also, damage or premature failure of equipment components because of incorrect or
incomplete service and maintenance by the equipment owner will not be covered under
warranty.
All controls, safety devices, guards, and shields must be correctly operational and securely
in place at all times during equipment operation.
NOTICE

Bandit
Copyright 5/09 PAGE 4
BANDIT INDUSTRIES, INC. LIMITED WARRANTY
[phone]
INTRODUCTION & WARRANTY
Bandit Industries Inc., also referred to as “Manufacturer” warrants this new product to be free of
defects in workmanship and material for a period of 1 year.
This warranty takes effect upon delivery to the original retail purchaser. The manufacturer at it’s
option will replace or repair at a point designated by the manufacturer, any parts which appear to have
been defective in material or workmanship. The manufacturer is not responsible for labor, consequential
damages, traveling or down time expenses.
This warranty and any possible liability of Bandit Industries Inc., is expressly in lieu of any other
warranties, expressed or implied, including but not limited to, any implied warranty or merchantability
of tness for a particular purpose and of any noncontractual liabilities including product liabilities based
upon negligence or strict liability. Bandit Industries Inc., will not be liable for consequential damages
resulting from breach of warranty.
All parties involved agree that the Owner’s Sole and Exclusive Remedy against the Manufacturer,
whether in contract or arising out of this warranty, instructions, representations, or defects shall only
be for the replacement or repair of defective parts as provided herein. In no event or circumstances
shall the Manufacturer’s liability exceed the purchase price of the machine. The buyer also agrees
that no other remedy (including but not limited to consequential or incidental loss) shall be available
to him or her.
It is absolutely necessary to return the Warranty Validation Form, completely and accurately lled
out, and notify Bandit Industries Inc., in writing within ten (10) days from the date of purchase to
validate this warranty. If Warranty Validation Form is not on le, all Warranty Consideration is NULL
AND VOID.
ThiswarrantywillnotapplyiftheBanditproductisnotoperatedwithreplacementpartsorequipment
not manufactured or recommended by Bandit Industries, Inc.
This warranty will not apply if the Bandit product is not operated in a manner recommended by the
manufacturer. The following examples would void the warranty:
1. The completed Warranty Validation Form is not on le.
2. The Bandit product has been abused, or not serviced properly.
3. Repairs or attempted repairs made without prior written authorization.
4. Repairs made due to normal wear are not warrantable.
5. The Bandit product was involved in, or damaged by an accident.
6. The Bandit product was damaged from any type of foreign material.
The owner is responsible for all scheduled maintenance as explained in the Operators Manuals.
Negligence of proper maintenance or any other negligence, accident or re; nor with failure to
adjust, tighten, or replace wear items included but not limited to items such as teeth, teeth holders,
belts, lubrication uids, bearings, lters, hydraulic components, loose nuts or bolts, etc. may void
warranty.
All components and parts being returned to Bandit Industries for warranty consideration must
be complete and assembled when delivered. Hydraulic components and parts must be returned
assembled with all uid ports capped or plugged and free of foreign contamination, or warranty will
not be considered.

Bandit
Copyright 5/09 PAGE 5
BANDIT INDUSTRIES, INC. LIMITED WARRANTY
[phone]
INTRODUCTION & WARRANTY
Bandit Industries Inc., reserves the right to alter, improve, revise or modify any parts or products with the
altered, improved, revised or modied parts or products. They also may change design, specications, or part
prices without advance notice.
Bandit Industries Inc., is NOT responsible for updating or upgrading completed machines with design changes
that are made after it’s production.
Bandit Industries Inc., expects the Customer/Owner to bring their machine to the Dealer/Manufacturer for
Warranty Repairs. The Manufacturer DOES NOT pay Dealers or Customers for bringing their machine in for
repair. Nor does the Manufacturer furnish loaner machines while the unit is being repaired.
In order to process any warranty claims, it is the owner’s responsibility to report the claims promptly to the
Manufacturer, or our authorized dealer from whom the equipment was purchased.
It is necessary to include the following information on any and all requests for warranty:
1) Warranty Claim Form, obtained from Bandit Industries or it’s dealers, completely and accurately lled out.
2) Dealer from whom purchased.
3) Date of delivery.
4) Serial number of unit.
5) Model number of unit.
6) Engine make and serial number.
7) Length of time in use (hours on machine).
8) Date of Failure.
9) Nature of Failure.
NOTICE This warranty applies only to new and unused equipment or parts thereof manufactured by Bandit
Industries Inc. and is void if the machine is operated with replacement parts or equipment not manufactured or
recommended by Bandit Industries Inc.
All other components are warranted by their respective manufacturers (i.e. engines, axles, hydraulic pumps
and motors, clutches, tires, batteries, etc.) Any machines used for lease or rental purposes warranty is limited
to 90 days from the rst day of initial service.
NOTICE Clutch maintenance and adjustments and engine maintenance (air lter maintenance, oil
changes, oil lter maintenance, etc.) are important to your machine. Refer to the clutch or engine manual
for the maintenance schedule. Failure to perform the clutch or engine maintenance will void the warranty
with the respective manufacturer, Bandit Industries Inc. does not warranty these components!
Briggs & Stratton (Vanguard) Engines 1-414-259-5333 PGL Auto Clutch 1-800-551-2938
Caterpillar Engines (Thru 275Hp) 1-800-551-2938 PT Tech Clutch 1-330-414-3172
Caterpillar Engines (300Hp & Up) 1-866-228-2111 NACD, Rockford Clutch 1-800-383-9204
Continental Engines 1-800-726-8870 Twin Disc Clutch 1-262-638-4000
Cummins Engines 1-248-573-1592 Electronic Solutions 1-866-736-6839
Deutz, Lombardini Engines 1-800-445-5273 I.E.C. (formerly E.S.I.) 1-815-985-0383
Ford, Hatz Engines 1-800-726-8870 L.O.R. MFG. 1-866-644-8622
GM, Perkins Engines 1-800-551-2938 Miratron Inc. 1-866-285-0132
Honda Engines 1-734-453-6258 Omnex Radios 1-419-294-4985
John Deere Engines 1-888-803-9175 Dexter Axles 1-574-295-7888
Kohler Engines 1-800-854-9273 Tires 1-989-463-4088
Kubota Engines 1-800-457-7056 Caterpillar Tracks 1-309-636-1100
Robin Engines 1-248-399-0002 Chermack Tracks 1-715-458-2655
Wisconsin Engines 1-800-726-8870 Petro-Canada Hydrex XV 1-888-284-4572
Interstate Batteries 1-800-331-2000
(Phone numbers for outside the continental U.S. can be supplied from your phone directory or local Bandit dealer.)
CONTINENTAL U.S. INFORMATION PHONE NUMBERS FOR ACCESSORIES
(NOT COVERED UNDER PRODUCT WARRANTY PROGRAM)

Bandit
Copyright 5/09 PAGE 6
MODELS 2000XP / 2100SP
TYPICAL GRINDER SERIAL NUMBER AND/OR
WORK ORDER NUMBER LOCATIONS
1. Serial Number
2. Work Order Number welded on top
of frame
3. Work Order Number stamped on
top of steering axle
SERIAL NUMBER LOCATIONS
3
1
1
2
2
Theengine informationis locatedonthe
engine block. The clutch information
is located on the clutch plate (if
equipped).
NOTICE

Bandit
Copyright 5/09 PAGE 7
MODELS 2000XP / 2100SP
WARNING
SAFETY PROCEDURES
Before starting the machine, take a minute to check a
fewthings. The grindershouldbe in anarea restricted
from people passing by. This area around the grinder
mustbe freeof allobjects thatcan obstructmovement
when working with the grinder. The machine should be
checked for loose tools or foreign objects, especially
in the grinding area. All tools not in use should be
secured in a tool box.
Operators must at all times be located within easy
reach of all feed control and shut-off devices when the
unit is running. They must be attentive and prepared
to activate the devices.
Torn or loose clothing is more likely to get caught in
moving machinery parts. Keep such items as long hair,
shirt sleeves, and shirt tails properly contained. Avoid
wearing necklaces, rings, watches, and especially
neckties while operating this machinery. Make sure
the machine is in excellent condition, and all the guards
are in place, tight and secure.
Wear all personal protection equipment and follow
all safety standards perANSI and OSHA instructions.
Examples of equipment: hard hat, face shield, safety
glasses, gloves, ear protection, etc. Always keep a
fully charged re extinguisher with the machine while
operating and servicing the machine.
SAFETY PROCEDURES
DANGER
DANGER
DANGER
The words Danger, Warning, Caution, and
Notice are used on the safety decals and throughout
this manual, to make you aware of the safety
procedures. These procedures are very important,
read and obey them.
YOUR SAFETY IS VERY IMPORTANT TO US!
This machine is equipped with safety decals, guards
and designs for your protection.
Don’t ever take the machine for granted, always
be cautious and careful when operating your
equipment.
Read and follow all the instructions in your manual
thoroughly. Your safety is dependent on your knowledge
ofhowtooperateandmaintainthis machine. Youmay
obtainadditionalcopiesofthismanualfromyourBandit
Dealer.
Before operating machine, you must have all potential
operators; read and understand manuals and decals,
watch the video and follow the recommendations.
Regardless of how hard a manufacturer tries to
produce a safe machine, accidents still happen.
Normally accidents are caused by people making
mistakes. They do not read the manual, they ignore
warning decals or do not use lockouts provided for
their safety. This normally happens after the person
has become accustomed to the machinery. In the
initial start up and operation of the machinery, they
are cautious, they are very careful because they do
not understand the machine.
This equipment is intended for use by personnel
who are experienced with similar equipment. Always
operate safely. There should be at least two qualied
and trained operators at the work site. They should
be positioned in safe working locations, following
safety procedures and instructions, and aware of each
others whereabouts. There should, also, be at least
two people on site during maintenance and service
procedures in case an accident should occur. Never
operate any machine while under the inuence of drugs
or alcohol.
Keep children, bystanders and animals clear of
working area. Never operate equipment that is in need
of repair or adjustment.

Bandit
Copyright 5/09 PAGE 8
MODELS 2000XP / 2100SP
SAFETY PROCEDURES
Before attempting any type of maintenance
disengage clutch, turn off engine, wait for the cutter
wheel to come to a complete stop, install the cutter
wheel lock pin, disconnect battery, and make sure the
ignition key is in your possession.
ALWAYS install the lock pin into the cutter lock tube
before working on the grinder.
Simply slide the lock pin into the cutter wheel lock
tube. This is to insure that the cutter wheel cannot
be started while you are working on the grinder. If for
some reason the cutter wheel would start to turn, it
would simply hit the lock pin.
DO NOT operate this machine indoors! Exhaust
fumes can be fatal. Never refuel while the machine is
running. Never refuel in the shop or building. Always
refuel in a well ventilated area, away from sparks or
open ames, DO NOT SMOKE. Extinguish all smoking
materials. Wipeup allspilledfuel before restartingthe
engine. Do not ll above 1/2” (12.7 mm) from top of
tank.
To obtain the most from your machine, for the least
amount of cost, it is a good practice to set up and follow
ascheduledpreventativemaintenanceprogram. Itwill
eliminate many possible problems and down time.
It is very important after you have operated a new
machine for approximately an hour to shut down the
machine and recheck all nuts and bolts. It is normal
for nuts and bolts to loosen once on a new piece of
machinery. If you tighten them now, there is a good
possibility they won’t loosen again. Certain nuts and
bolts must be checked periodically such as cutter teeth
bolts, etc. for torque and t.
Most of the nuts used on the Bandit Grinder are self
locking. After a nut or bolt has been removed ve times,
it should be replaced to insure proper tightness. This
is especially critical on the cutter tooth bolts!
After the engine is started, let the grinder disc turn
at the lowest RPM’s possible. Listen for any type of
noisethatisforeign. Anysteelonsteelnoiseisforeign.
If you hear a noise, stop the engine, nd the problem
and x it.
Never use jumper cables during freezing
temperatures. Haul the machine inside and allow
the battery time to warm up. If the machine must
be started outside, inspect the battery acid for ice
formation. Explosion will occur with a frozen battery.
If the machine is going to be operated in excessively
cold conditions, a larger cold cranking amp battery
may be needed to insure proper and prompt starting.
Never use jumper cables in a conned or unventilated
area. Battery acid fumes are explosive. Battery acid
can cause severe burns. Never expose an open ame
or spark near the battery. Keep all burning materials
away from the battery. When servicing the battery,
shield eyes and face, and do not smoke. Service in a
well ventilated area.
NEVER sit, stand, lay, climb or ride anywhere
on this machine while it is running, operating, or in
transit. You will be injured.
It is very important after you have operated a new
machine for approximately an hour to shut down the
machine and recheck all hydraulic ttings. Retighten
as needed.
DO NOT GO NEAR HYDRAULIC LEAKS! High
pressure oil easily punctures skin causing serious
injury, gangrene, or death. DO NOT use ngers or
skin to check for leaks. Lower load or relieve hydraulic
pressure before loosening ttings. Use a piece of
cardboard to nd leaks. Never use your bare hands.
In cold weather situations let your hydraulic system
idle for approximately 15 minutes to allow the system
towarmuptooperatingtemperature. Avoidburnsfrom
uid. Hot uid under pressure can cause severe burns.
Relieveallpressureinthesystembeforedisconnecting
the lines, hoses or performing other work. Allow system
to cool down to ambient temperature before opening
any coolant or hydraulic oil system.
Do not go near or in-line with the debris eld of
the stump grinder while in operation. While grinding
stumps, the chips and portions of the stump y from
the cutterhead and can cause severe injury.
DO NOT operate this machine unless all hydraulic
control devices operate properly. They must function,
shift and position smoothly and accurately at all times.
Faulty controls can cause personal injury!
SAFETY PROCEDURES
WARNING
WARNING
DANGER
DANGER
DANGER
DANGER
WARNING
WARNING

Bandit
Copyright 5/09 PAGE 9
MODELS 2000XP / 2100SP


Diesel engine exhaust and some of its
constituents are known to the State of
California to cause cancer, birth defects,
and other reproductive harm.
SAFETY PROCEDURES
Never grind any materials that might contain wires,
stones, nails, or other metal objects which may damage
the teeth and become dangerous projectiles. Remove
all rocks and stones from stump grinding area.
Do Not start to grind a stump unless you are
completely sure there are not any power lines, water
lines, sewer lines, phone lines, etc. in the area above
or below ground level where you are grinding.
Never go near cutter wheel or teeth while engine is
running or cutter wheel is coasting to a stop.
Your machine may or may not be equipped with
a clutch. Depending on the options ordered, some
machines are direct drive.
Do not work on the machine if the engine is running
with the clutch disengaged. A clutch can self engage
if either the pilot or throw-out bearing happens to seize
to the main output shaft.
There are various types of clutches (PTO’s)
available for this type of equipment. Make sure to
study the original clutch manufacturer’s manual that
isprovidedwith the machineandfollow its instructions
for operation, service, and adjustments. Some styles
require clutch engagement to be maintained so that it
takes a lot of force, others will require very little force,
and some are push button, electric, manual lever, or
hydraulic activation. Each different style clutch (PTO)
is a very expensive item that will fail if not correctly
maintained and adjusted. It will be quite costly if a
few minutes are not taken daily, weekly, and monthly
to keep the clutch serviced as required.
The operator must take care in the engagement
and disengagement of the clutch, engine RPM should
always be below 1000 RPM. When the engine has
sufciently warmed up, bump the clutch handle against
engagement to start the cutter wheel turning. This will
have to be repeated until the cutter wheel is turning at
proper ratio with engine RPM. Then push the handle
all the way in gear until it locks into position securely.
After engagement raise engine RPM to full throttle.
Engaging and disengaging the clutch at high engine
RPM will quickly and excessively wear out clutch plates
as well as bearings. Refer to clutch manufacturer’s
manual for proper service and operation.
Do not attempt to start the engine or engage the
engine PTO (power-take-off) system on this machine
if the cutter wheel is jammed or frozen in place. If you
do, you will damage or ruin the drive belts and/or the
PTO which will not be covered under warranty and will
cost you down time and money.
SAFETY PROCEDURES
DANGER
DANGER
DANGER DANGER
NOTICE
Avoid moving parts. Keep hands, feet, and clothing
away from power driven parts. Keep all guards and
shields in place and properly secured.
DANGER
Keep the machine in good condition. Be sure the
machine is in good operating condition and that all
safety devices, including guards and shields are
installed and functioning properly. Visually inspect the
machinedailybeforestartingthemachine. Refertothe
“Daily Start Up & Maintenance”. Make no modications
to your equipment unless specically recommended
or requested by Bandit Industries Inc.
DANGER
Check laws and regulations. Know and obey all
federal, state, and local laws and regulations that
apply to your work situation and the transportation of
a machine this size.
WARNING

Bandit
Copyright 5/09 PAGE 10
MODELS 2000XP / 2100SP SAFETY PROCEDURES
SAFETY PROCEDURES
Do not attempt to operate the machine on an ascending or descending slope of more than 25° or 46% or a
side slope of more than 17° or 30%, it is Dangerous and could be Fatal. This is the maximum slope grade the
machine can be operated on if the hydraulics, self propelled undercarriage, and engine are running at maximum
performance and good traction is sustained.
The machine should never be parked on a slope at any time. The machine can coast or creep causing
equipment and/or personal injury.
DANGER
Make sure everyone is clear of machine before moving the machine. Stay clear of undercarriage travel system
when the machine is moving.
DANGER
DO NOT entangle feet or hands in undercarriage travel system.
DANGER
NEVER sit, stand, lay, climb or ride anywhere on this machine while it is running, operating, or in transit. You
will be injured.
DANGER
Use EXTREME CAUTION when traveling over non-level surface! This machine can tip over or tip backwards
on non-level surface. You will cause engine damage, machine damage and possible personal injury!
DANGER
WARNING
Any increase from the specied maximum operating angles may cause loss of lubrication function and damage
the engine.
WARNING
Maximum Slope Grade
Diagram shows percentage to degree of slope.
Percentage is in vertical feet for every 100 horizontal feet.
Ascending or Descending Slope Side Slope
IF MACHINE IS EQUIPPED WITH A SELF PROPELLED UNDERCARRIAGE
Machines equipped with undercarriage tracks are shipped with a manual from the track manufacturer. Refer
to it for service, operation, and safety information.

Bandit
Copyright 5/09 PAGE 11
MODELS 2000XP / 2100SP
EQUIPMENT SPECIFICATIONS
Approximate Dimensions & Weights
(Dimensions & weights will vary depending on optional equipment)
EQUIPMENT SPECIFICATIONS
WIDTH
CUTTER HEAD
SWING
LENGTH
TOP OF CUTTER
WHEEL
CUTTING DEPTH
BELOW GROUND
CENTER OF
CUTTER WHEEL
Approx. Model 2000XP: 1300 to 1450 lbs. (590 to 658 kg)
Weight: Model 2100SP: 1500 to 1800 lbs. (680 to 816 kg)
(Approximate weights depending on engine and equipment options.)
Overall Model 2000XP: Height: 48” (1.2 m), Length: 112” (2.8 m), Width: 35” (.9 m) or opt. 29” (.7 m)
Dimension: Model 2100SP: Height: 48” (1.2 m), Length: 112” (2.8 m), Width: 35” (.9 m) or opt. 29” (.7 m)
Cutting Wheel: Mod. 2000XP: Top of: 43” (1.1 m) Center of: 29” (.7 m) Cutting Depth Below Ground: 14.5” (.4 m)
Mod. 2100SP: Top of: 44” (1.1 m) Center of: 33” (.8 m) Cutting Depth Below Ground: 12.5” (.3 m)
Cutterhead Model 2000XP: Arc: 37” (.9 m)
Swing: Model 2100SP: Arc: 37” (.9 m)
Model 2000XP Model 2100SP
Number of Teeth 18 18 (Start 6/08)
on Cutter Wheel: 20 (Pre 6/08)
Cutter Wheel
Diameter with Teeth: 21” (533 mm) 21” (533 mm)
Fuel Tank Capacity: 7 Gallons (27 Liters) 8.5 Gallons (32 Liters) - Start 6/08
19 Gallons (72 Liters) - Pre 6/08
16Gallons(60Liters)With29”WideOption-Pre6/08
Hydraulic Tank Capacity: 5 Gallons (19 Liters) 8.5 Gallons (32 Liters) - Start 6/08
10 Gallons (38 Liters) - Pre 6/08
(Approximate dimension depending on equipment options.)

Bandit
Copyright 5/09 PAGE 12
MODELS 2000XP / 2100SP DECALS
3,4
1,10
11,17
14,21,31
6,7
1,15
7,10,18
26
13,19
2,5,8,16,32
20,22,30
12,27,28,29
9
1,3,10
10
10
1
25
1,15
15,21,23
9,24
MODEL 2000XP DECAL LOCATIONS
Decal locations may vary, these are general locations.

Bandit
Copyright 5/09 PAGE 13
MODELS 2000XP / 2100SP
MODEL 2000XP DECAL LOCATIONS
Modications and/or additions of decals to this list will happen.
Consult machine dealer or manufacturer for most current decal package.
LOCATION NUMBER DESCRIPTION
1. SPD-02 Moving Parts Keep Hands...
2. SPD-19 ...Minimum 10 Feet Away From Tracks...
3. SPD-20 Flying Objects Stand Clear...
4. SPD-28 Do Not Insert Fingers...
5. SPD-30 Do Not Sit, Stand, Lay, Climb or...
6. SPD-35 Extreme Caution...Non-Level Surface...
7. SPD-36 ...Debris Field...
8. SPD-39 Do Not Operate...
9. ID-42 Bandit Industries, Inc...USA
10. INST-12 Grease Daily
11. INST-44 Proposition 65
12. INST-53 Hydraulic Oil...Hydrex XV...
13. INST-79 Swing Speed - Counter-Clockwise To Slow
14. INST-80 Travel Speed - Counter-Clockwise To Slow
15. INST-86 Grease Daily - Double Arrow
16. INST-88 Controls - 4 Function
17. INST-101 Canada Engine Decal
18. INST-115 Belt Tightening Instructions...
19. INST-119 Clutch Engage On / Off
20. INST-151 Brake Release Procedure
21. INST-152 Turn Ball Valve...To Release Brakes
22. INST-153 Brake Release Hand Pump
23. N-02 Maintain Lubrication...
24. SPN-06 Decal Maintenance..
25. N-24 Service Under Beltshield...
26. N-33 Engine Oil Lubrication...Break-In...
27. SPW-01 Do Not Go Near Oil Leaks...
28. SPW-02 Combustible Liquid...Diesel Fuel Only...
29. SPW-03 Flammable Liquid...Gasoline Fuel Only...
30. SPW-04 Frozen Battery Will Explode...
31. SPW-08 Wear Eye & Personal Protection...
32. SPW-09 ...Go Slow Around Corners...
33. 900-5900-34 Basic Safety Decal Kit (Options may require additional decals)
34. --- Bandit Model 2000XP Logo Decal Kit
DECALS
Some decals are for optional equipment. Decal locations may vary, these are general locations.
If any decals become damaged, replace immediately.
NOTICE

Bandit
Copyright 5/09 PAGE 14
MODELS 2000XP / 2100SP
MODEL 2100SP DECAL LOCATIONS
Decal locations may vary, these are general locations.
DECALS
11
34,35,36
31
5,6 11
121
9,30
11
1
1
15,32
11
14
1
11
1,2
311,27
21
11
5,6
4,10,37,39 121
7,8,12,16,22,23,24,
26,28,29,34,38 25
17 13,18
18,20
17,19
