Bryant Legacy 113ANC Series Operation manual

113ANC
LegacytLine Air Conditioner for Coastal Applications
with PuronrRefrigerant
Product Data
the environmentally sound refrigerant
Bryant’s Air Conditioners with Puronrrefrigerant provide a
collection of features unmatched by any other family of
equipment. The 113A has been designed utilizing Bryant’s Puron
refrigerant. The environmentally sound refrigerant allows you to
make a responsible decision in the protection of the earth’s ozone
layer.
As an Energy StarrPartner, Bryant Heating & Cooling has
determined that this product meets the Energy Starrguidelines
for energy efficiency. Refer to AHRI ratings for system
combinations that meet Energy Starrguidelines.
NOTE:Ratings contained in this document are subject to
change at any time. Always refer to the AHRI directory
(www.ahridirectory.org) for the most up--to--date ratings
information.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S13.0 -- 15.0 SEER/10.5 -- 12.2 EER
SMicrotube Technologytrefrigeration system
SIndoor air quality accessories available
Sound
SSound level as low as 75 dBA
Comfort
SSystem supports Thermidistattor standard thermostat
controls
Reliability
SPuronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime servce cost.
SFront--seating service valves
SScroll compressor
SInternal pressure relief valve
SInternal thermal overload
SFilter drier
SBalanced refrigeration system for maximum reliability
Durability
DuraGuardtprotection package:
SSolid, durable sheet metal construction
SDense wire coil guard
SBaked--on powder paint on all sides
CoastGuard Condenser Coil
SAluminum fin material is pre--coated on both sides with
a corrosion protective epoxy phenolic coating.
Applications
SLong--line -- up to 250 feet (76.20 m) total equivalent
length, up to 200 feet (60.96 m) condenser above
evaporator, or up to 80 ft. (24.38 m) evaporator above
condenser (See Longline Guide for more information.)
SLow ambient (down to --20_F/--28.9_C) with accessory
kit

2
MODEL NUMBER NOMENCLATURE
12 3 4 5 6 78910 11 12 14
N N N A A/N N N N N A/N A/N N A
11 3 A N C 036 0 0 0 A
Product
Family
Tier SEER Major
Series
Voltage Variations Cooling Capacity Open Open Open Minor-
Series
1=AC 1=
Legacy 3=13 SEER A=Puron N= 208---230 ---1 C = Coastal 0=Not Defined
0=Not
Defined
0=Not
Defined
A=
Original
Series
the environmentally sound refrigerant
This product has been designed and manufactured to
meet Energy Star®criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
Feature 18 24 30 36 42 48 60
Puron Refrigerant XXXXXXX
Maximum SEER Rating 14.5 14.5 14.5 15 14.5 14.5 13.5
Scroll Compressor XXXXXXX
DenseWireCoilGuard XXXXXXX
FieldInstalledFilterDrier XXXXXXX
Front Seating Service Valves XXXXXXX
Internal Pressure Relief Valve XXXXXXX
Internal Thermal Overload XXXXXXX
Long Line capability XXXXXXX
Low Ambient capability with Kit XXXXXXX
X = Stanadard
113ANC

3
PHYSICAL DATA
UNIT SIZE SERIES 018---B 024---B 030---B 036 ---B 042---B 048---B 060---C
Operating Weight lb (kg) 128
(58.1)
133
(60.3)
155
(70.3)
167
(75.7)
188
(85.3)
197
(89.4)
227
(103.0)
Shipping Weight lb (kg) 159
(72.1)
167
(75.7)
193
(87.5)
205
(93.0)
225
(102.1)
235
(106.6)
267
(121.1)
Compressor Type Scroll
REFRIGERANT Puron (R---410A)
Control TXV (Puron Hard Shutoff)
Charge lb (kg) 4.1
(1.9)
5.1
(2.3)
5.8
(2.6)
6.8
(3.1)
6.2
(2.8)
7.3
(3.3)
9.9
(4.5)
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 1881 2196 3167 3167 3810 3810 4046
Motor HP 1/12 1/10 1/5 1/5 1/5 1/5 1/4
Motor RPM 1100 1100 1100 1100 800 800 800
COND COIL
Face Area (Sq ft) 13.13 14.77 17.25 21.56 17.60 20.12 17.60
Fins per In. 20 20 20 20 20 20 20
Rows 1 1 1 1 1 1 2
Circuits 3 3 3 5 4 5 8
VALVECONNECT.(In.ID)
Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT TUBES (In. OD)
Rated Vapor* 5/8 3/4 7/8 1 --- 1 / 8
Vapor 3/4 7/8 1 --- 1 / 8 1 --- 1 / 8
Liquid ( 0 --- 5 0 f t / 0 --- 1 5 . 2 m ) Tu b e L e n g t h ) 3/8”
Liquid (For Long---Line applications) 3/8”
* Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset
Note: See unit Installation Instruction for proper installation.
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
LONG LINE APPLICATION: An application is considered
”Long line” when the total equivalent tubing length exceeds 80
ft. (24.38 m) or when there is more than 20 ft. (6.09 m) vertical
separation between indoor and outdoor units. These applications
require additional accessories and system modifications for
reliable system operation. The maximum allowable total
equivalent length is up to 250 ft. (76.2 m). The maximum
vertical separation is 200 ft. (60.96 m) when outdoor unit is
above indoor unit, and up to 80 ft. (24.38 m) when the outdoor
unit is below the indoor unit. Refer to Accessory Usage Guideline
below for required accessories. See Longline Application
Guideline for required piping and system modifications. Also,
refer to the table below for the vapor tube diameters based on the
total length to minimize the cooling capacity loss.
Unit Nomi-
nal Size
(Btuh)
Maximum
Liquid Line
Diameters
(In. OD)
Vapor Line
Diameters
(In. OD)
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
Standard
Application Long Line Application Requires Accessories
26 --- 50
(7.9--- 15.2)
51 --- 80
(15.5--- 24.4)
81 --- 100
(24.7--- 30.5)
101 --- 125
(30.8--- 38.1)
126 --- 150
(38.4--- 45.7)
151 --- 175
(46.0--- 53.3)
176 --- 200
(53.6--- 61.0)
201 --- 225
(61.3--- 68.6)
226 --- 250
(68.9--- 76.2)
18000
1Stage
Puron AC
3/8 1/2 1234678910
5/8 001112233
24000
1Stage
Puron AC
3/8
5/8 011233445
3/4 000011111
7/8 000000000
30000
1Stage
Puron AC
3/8
5/8 123345678
3/4 001112223
7/8 000011111
36000
1Stage
Puron AC
3/8
5/8 124568910 12
3/4 011223344
7/8 000011122
42000
1Stage
Puron AC
3/8
3/4 012234456
7/8 001112223
11/8 000000000
48000
1Stage
Puron AC
3/8
3/4 012345567
7/8 001122233
11/8 000000011
60000
1Stage
Puron AC
3/8
3/4 124567910 11
7/8 012234455
11/8 000111111
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines
Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See Long Line Applica-
tion Guidelines
113ANC

4
ACCESSORY THERMOSTATS
PART NUMBER PROGRAM GAS ELECTRIC HEAT PUMP HEAT COOL
T C --- PA C 0 1 5 --- 2 D a y √ √ 1 1
T C --- N A C 0 1 NP √ √ 1 1
TCSNAC01 NP √ √ 1 1
THERMOSTAT ACCESSORIES
PART NUMBER DESCRIPTION THERMOSTATS USED WITH
TSTATXXCNV10‡ Thermostat Conversion Kit (4 to 5 wire) --- 10 pack All Carrier branded thermostats
T X --- L B P 0 1 LargeDecorativeBackplate T P --- P x x , T P --- N x x , T C --- P x x
T X --- M B P 0 1 Medium Decorative Backplate T C --- N x x , T B --- P x x
ACCESSORIES
ORDER
NUMBER DESCRIPTION Size --- Voltage & Series
018 --- B 024--- B 030 --- B 036 --- B 042 --- B 048 --- B 060 --- C
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X
KAATD0101TDR TIME DELAY RELAY X X X X X X X
KAAWS0101AAA WINTER START X X X X X X X
KSALA0301410 LOW AMBIENT PSW X X X X X X X
KSALA0601AAA{MOTORMASTER 230V X X X X X X X
HC32GE234 MOTOR FAN BALL BEARING X
HC34GE239 MOTOR FAN BALL BEARING X
HC38GE219 MOTOR FAN BALL BEARING X X
HC38GE228 MOTOR FAN BALL BEARING X X
HC40GE228 MOTOR FAN BALL BEARING X
KSAHS1701AAA HARD START (CAP / RELAY) X X X X X X X
KSACY0101AAA CYCLE PROTECTOR X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X
KAACS0201PTC START ASSIST PTC X X X X X X X
KAACH1201AAA CRANKCASE HTR X X X
KAACH1401AAA CRANKCASE HTR X X X X
KSATX0201PUR TXV PURON HSO X X X
KSATX0301PUR TXV PURON HSO X X
KSATX0401PUR TXV PURON HSO X
KSATX0501PUR TXV PURON HSO X
KSASH0601COP SOUND HOOD X X X X X X
KSASH2101COP SOUND HOOD X
KAALP0401PUR LOW PRESSURE SWITCH X X X X X X X
KAAHI0501PUR HIGH PRESSURE SWITCH X X X X X X X
KAALS0201LLS LIQUID LINE SOLENOID X X X X X X X
KHASS0606MPK* SNOW STAND RACK X X X X X X X
{Required accessories include ball bearing fan motor, compressor start assist (CAP / Relay), crankcase heater, evaporator freeze stat, hard shut---off TXV.
X Available accessory
* Available for order through RCD
113ANC

5
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR LOW--- AMBIENT
COOLING APPLICATIONS
(Below 55°F/12.8_C)
REQUIRED FOR LONG LINE
APPLICATIONS*
(Over 80 ft./24.38 m)
REQUIRED FOR
SEA COAST
APPLICATIONS
(Within 2 miles/3.22 km)
Ball Bearing Fan Motor Ye s {No No
Compressor Start Assist Capacitor and Relay Ye s Ye s No
Crankcase Heater Ye s Ye s No
Evaporator Freeze Thermostat Ye s No No
H a r d S h u t --- O f f T X V Ye s Ye s Ye s
Liquid Line Solenoid Valve No No No
Motor Master®or Low--- ambient Pressure Switch Ye s No No
Support Feet Recommended No Recommended
Winter Start Control Ye s No No
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 20 ft. (6.09 m) vertical differential, refer to Residential Split---System Longline
Application Guideline.
{Additional requirement for Low ---Ambient Controller (full modulation feature) MotorMasterrControl.
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when MotorMasterr—
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Required for reciprocating compressors in the
following applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil
Required for single--phase scroll compressors in the
following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
5. Cycle Protector
The cycle protector is designed to prevent compressor short
cycling. This control provides an approximate 5--minute delay
after power to the compressor has been interrupted for any
reason, including power outage, protector control trip, thermostat
jiggling, or normal cycling.
6. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
7. Liquid--Line Solenoid Valve (LLS)
An electrically operated shutoff valve which stops and starts
refrigerant liquid flow in response to compressor operation. It is
to be installed at the outdoor unit to control refrigerant off cycle
migration in the heating mode.
Usage Guideline:
An LLS is required in all long line heat pump
applications to control refrigerant off cycle migration in
the heating mode. See Long Line Guideline.
Required when low ambient kit has been added.
8. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits
(approximately 100 psig to 225 psig). The control will maintain
working head pressure at low--ambient temperatures down to 0_F
when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling operation is
used at outdoor temperatures below 55_F (12.8_C).
9. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F±10_F (37.8_C±
-- 5 . 5 _C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
113ANC

6
Accessory Description and Usage (Listed Alphabetically) (Continued)
10. Outdoor Air Temperature Sensor
Designed for use with Bryant Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also
is required to enable special thermostat features such as auxiliary
heat lock out.
Usage Guideline:
Suggested for all Bryant thermostats listed in this
publication.
11. Sound Hood
Wraparound sound reducing cover for the compressor. Reduces
the sound level by about 2 dBA.
Usage Guideline:
Suggested when unit is installed closer than 15 ft (4.6 m) to
quiet areas, bedrooms, etc.
Suggested when unit is installed between two houses less
than 10 ft (3.0 m) apart.
12. Support Feet
Four stick--on plastic feet that raise the unit 4 in. above the
mounting pad. This allows sand, dirt, and other debris to be
flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
13. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Required to achieve AHRI ratings in certain equipment
combinations. Refer to combination ratings.
Hard shut off TXV or LLS required in air conditioner
long line applications.
Required for use on all zoning systems.
14. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
NOTE: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
For improved efficiency ratings for certain
combinations of indoor and outdoor units. Refer to
AHRI Unitary Directory.
15. Winter Start Control
This control is designed to alleviate nuisance opening of the
low--pressure switch by bypassing it for the first 3 minutes of
operation.
113ANC

7
ELECTRICAL DATA
U N I T S I Z E ---
VOLTAGE,
SERIES
V/PH OPER VOLTS* COMPR FAN MCA
MIN
WIRE
SIZE†
MIN WIRE
SIZE†
MAX
LENGTH
ft. (m)‡
MAX
LENGTH
ft. (m)‡
MAX
FUSE**
or CKT
BRK
AMPS
MAX MIN LRA RLA FLA 60° C 75° C 60° C 75° C
018 --- B
208/230/1 253 197
48.0 9.0 0.5 11.7 14 14 67 (20.4) 64 (19.5) 20
024 --- B 58.3 13.5 0.8 17.6 14 14 44 (13.4) 42 (12.8) 30
030 --- B 73.0 14.1 1.1 18.7 14 14 42 (12.8) 40 (12.2) 30
036 --- B 79.0 16.7 1.1 21.9 12 12 57 (17.4) 54 (16.5) 35
042 --- B 109.0 19.9 1.2 26.0 10 10 76 (23.2) 73 (22.3) 40
048 --- B 117.0 21.8 1.2 28.4 10 10 70 (21.3) 66 (20.1) 40
060 --- C 134.0 26.3 1.2 34.1 810 91 (27.7) 55 (16.8) 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30_C(86_F), consult table 310---16 of the NEC ---2008 (ANSI/NFPA 70). The ampacity of non---metallic---sheathed
cable(NM),tradenameROMEX,shallbethatof60_C (140_F) conditions, per the NEC (ANSI/NFPA 70) Article 334.80. If other than uncoated (no---plated),
60 or 75_C (140 or 167_F) insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable
tables of the NEC (ANSI/NFPA 70).
}Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2001 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER LEVEL (dBA)
U N I T S I Z E ---
VOLTAGE, SERIES
STANDARD RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018---B 75 50.0 59.0 65.5 69.5 64.5 61.0 55.0
024---B 75 53.0 60.0 68.0 69.5 68.0 63.0 58.5
030---B 77 57.0 66.5 71.0 73.0 69.5 66.5 59.0
036---B 77 55.0 66.5 71.0 70.5 69.0 67.0 63.5
042---B 77 57.0 60.0 66.5 69.0 68.0 64.5 58.0
048---B 80 57.0 60.0 68.0 75.0 69.0 66.5 65.5
060---C 80 59.5 65.0 71.5 72.0 67.0 65.0 62.0
NOTE: Tested in accordance with AHRI Standard 270---95. (Not listed with AHRI).
A--WEIGHTED SOUND POWER LEVEL (dBA) WITH SOUND SHIELD
U N I T S I Z E ---
VOLTAGE, SERIES
STANDARD RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018---B 73 50.5 60.0 66.0 68.0 64.0 60.5 54.0
024---B 73 53.5 60.0 67.0 68.5 66.5 61.5 56.0
030---B 77 57.5 66.0 71.0 72.5 69.0 65.5 57.5
036---B 76 55.5 66.0 70.0 69.5 68.5 66.0 61.5
042---B 74 57.0 60.5 66.5 67.5 67.0 62.5 56.5
048---B 78 57.0 60.5 67.5 74.0 68.0 64.0 62.5
060---C 77 59.5 65.0 71.0 68.5 66.0 61.5 58.5
NOTE: Tested in accordance with AHRI Standard 270---95. (Not listed with AHRI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- VOLTAGE, SERIES REQUIRED SUBCOOLING ° F (° C)
018---B 8 (4.4)
024---B 11 (6.1)
030---B 9 (5.0)
036---B 10 (5.6)
042---B 11 (6.1)
048---B 12 (6.7)
060---C 11 (6.1)
113ANC

8
DIMENSIONS -- ENGLISH
B
3"
K
5/16"
L
C3 1/2"
1 7/8"
N
P
M
E
F
G
A
UNIT SERIES ELECTRICAL
CHARACTERISTICS ABCDEFGKLMNP
OPERATING
WEIGHT (lbs)
SHIPPING
WEIGHT (lbs)
SHIPPING
DIMENSIONS (L x W x H)
113ANC018 B X O O O 25 3/4" 31 13/16" 3 3/4" 5/8" 4 7/16" 21 1/4" 9 1/8" 2 13/16" 1/2" 15 3/8" 12 1/2" 14 3/4" 128 159 26 7/8" X 30 1/16" X 35 15/16"
113ANC024 B X O O O 25 3/4" 35 1/4" 3 3/4" 5/8" 4 7/16" 21 1/4" 9 1/8" 2 13/16" 1/2" 13" 14 1/4" 15 7/8" 133 167 26 7/8" X 30 1/16" X 39 3/8"
113ANC030 B X O O O 31 3/16" 32 5/16" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 16 1/8" 15" 15 7/8" 155 193 32 3/8" X 35 1/2" X 35 15/16"
113ANC036 B X O O O 31 3/16" 39 1/8" 3 3/4" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 13 5/8" 15 3/4" 18 1/2" 167 205 32 3/8" X 35 1/2" X 42 3/4"
113ANC042 B X O O O 35" 28 15/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 15 3/4" 15" 12 3/8" 188 225 36 1/8" X 39 5/16" X 32 9/16"
113ANC048 B X O O O 35" 32 5/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16 1/4" 16 3/8" 14 1/4" 197 235 36 1/8" X 39 5/16" X 35 15/16"
113ANC060 X O O O 35" 28 15/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16 3/8" 16 5/8" 12 1/4" 227 267 36 1/8" X 39 5/16" X 32 9/16"
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
- 23 1/2" X 23 1/2"
18,24 26" X 26" 30,36 31 1/2" X 31 1/2"
42,48,60 35" X 35"
AIR DISCHARGE
AIR DISCHARGE
X = YES O = NO
SQ.
AIR IN
VAPOR LINE CONN.
D
3/8"
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
3/8" TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
7/8" HOLE
FIELD POWER SUPPLY CONN.
7/8" HOLE WITH 1 1/8" KNOCKOUT
113ANC

9
DIMENSIONS -- SI
B
76.2
K
8.0
L
C
88.9
47.6
N
P
M
E
F
G
A
UNIT SERIES ELECTRICAL
CHARACTERISTICS ABCDEFGKLMNP
OPERATING
WEIGHT (Kgs)
SHIPPING
WEIGHT (Kgs)
SHIPPING
DIMENSIONS (L x W x H)
113ANC018 B X O O O 654.0 808.5 95.6 15.9 113.0 539.9 231.3 70.9 12.8 390.5 317.5 374.6 58.0 72.1 682.8 X 762.8 X 913.2
113ANC024 B X O O O 654.0 894.8 95.6 15.9 113.0 539.9 231.3 70.9 12.8 330.2 362.0 403.2 60.3 75.7 682.8 X 762.8 X 999.5
113ANC030 B X O O O 792.5 821.2 95.6 19.1 166.7 626.3 231.3 70.9 12.8 409.6 381.0 403.2 70.3 87.5 821.2 X 901.2 X 913.2
113ANC036 B X O O O 792.5 993.9 95.6 19.1 166.7 626.3 231.3 70.9 12.8 346.1 400.0 469.9 75.7 93.0 821.2 X 901.2 X 1085.9
113ANC042 B X O O O 889.0 734.8 97.9 22.2 166.7 722.8 231.3 74.5 16.3 400.0 381.0 314.3 85.3 102.0 917.7 X 997.7 X 826.8
113ANC048 B X O O O 889.0 821.2 97.9 22.2 166.7 722.8 231.3 74.5 16.3 412.8 415.9 362.0 89.4 106.6 917.7 X 997.7 X 913.2
113ANC060 X O O O 889.0 734.8 97.9 22.2 166.7 722.8 231.3 74.5 16.3 415.9 422.3 311.2 103.0 121.1 917.7 X 997.7 X 826.8
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
- 596.9 X 596.9
18,24 660.4 X 660.4 30,36 800.1 X 800.1
42,48,60 889.0 X 889.0
AIR DISCHARGE
X = YES O = NO
SQ.
AIR DISCHARGE
AIR IN
VAPOR LINE CONN.
D
9.53
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
9.53 TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
22.23 HOLE
FIELD POWER SUPPLY CONN.
22.23 HOLE WITH
28.58 KNOCKOUT
113ANC

10
CLEARANCES
Clearances (various examples)
Wall
6”
(152.4)
24”
(609.6)
Service
Wall
Wall
Wall
12”
(304.8)
12”
(304.8)
18”
(457.2)
24”
(609.6)
Service
6”
(152.4)
12”
(304.8)
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
Note: Numbers in ( ) = mm
18”
(457.2)
18”
(457.2)
12”
(304.8)
A07832
IMPORTANT:When installing multiple units in an alcove, roof well, or partially enclosed area, ensure there is adequate ventilation to prevent re--circulation of discharge air.
113ANC

11
COMBINATION RATINGS
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4765908 113ANC018---B †CAP**1814A** 17,700 11.0 13.0
3040598 113ANC018---B †CAP**1814A**+TDR 17,700 11.0 13.0
3040600 113ANC018---B CAP**1814A** 313*AV024045 17,800 12.2 14.5
3040599 113ANC018---B CAP**1814A** 315(A,J)AV036070 17,500 12.0 14.0
4734042 113ANC018---B CAP**1814A** 925*A30040E14*** 17,300 11.5 14.0
3040603 113ANC018---B CAP**2414A** 313*AV024045 18,000 12.2 14.5
3040602 113ANC018---B CAP**2414A** 315(A,J)AV036070 17,800 12.2 14.5
4734043 113ANC018---B CAP**2414A** 925*A30040E14*** 17,700 11.8 14.2
4765886 113ANC018---B CAP**2414A** 986*A30040V14*** 18,000 12.0 14.5
3040601 113ANC018---B CAP**2414A**+TDR 18,000 11.2 13.2
3040606 113ANC018---B CAP**2417A** 315(A,J)AV048090 17,900 12.2 14.5
3613600 113ANC018---B CAP**2417A** 353(A,B)AV036040 17,800 12.0 14.5
3099100 113ANC018---B CAP**2417A** 353(A,B)AV036060 17,800 12.0 14.5
3099099 113ANC018---B CAP**2417A** 353AAV036040 17,800 12.0 14.5
3040605 113ANC018---B CAP**2417A** 355(A,C)AV042060 17,800 12.2 14.5
3808327 113ANC018---B CAP**2417A** 355BAV042060 17,800 12.2 14.5
4130245 113ANC018---B CAP**2417A** 368RAN036105 18,000 12.0 14.5
4130244 113ANC018---B CAP**2417A** 374RAN036105 17,800 12.0 14.5
4734046 113ANC018---B CAP**2417A** 925*A30040E14*** 17,700 12.0 14.5
4765887 113ANC018---B CAP**2417A** 986*A30040V14*** 18,000 12.0 14.5
4765894 113ANC018---B CAP**2417A** 986*A42060V17*** 18,000 12.5 15.0
4765899 113ANC018---B CAP**2417A** 986*A48080V17*** 18,000 12.5 15.2
4734044 113ANC018---B CAP**2417A** 987*A42060V17*** 17,800 12.0 14.5
4734045 113ANC018---B CAP**2417A** 987*A42080V17*** 17,700 12.0 14.5
4255261 113ANC018---B CAP**2417A** OVLAAB036098 17,900 12.0 14.5
4130246 113ANC018---B CAP**2417A** OVMAAB036098 18,000 12.0 14.5
3040604 113ANC018---B CAP**2417A**+TDR 18,000 11.2 13.2
3040622 113ANC018---B CNPH*2417A** 313*AV024045 18,000 12.2 14.5
3040620 113ANC018---B CNPH*2417A** 315(A,J)AV036070 17,800 12.2 14.5
3040621 113ANC018---B CNPH*2417A** 315(A,J)AV048090 17,900 12.2 14.5
3613601 113ANC018---B CNPH*2417A** 353(A,B)AV036040 17,800 12.0 14.5
3099104 113ANC018---B CNPH*2417A** 353(A,B)AV036060 17,800 12.0 14.5
3099103 113ANC018---B CNPH*2417A** 353AAV036040 17,800 12.0 14.5
3040618 113ANC018---B CNPH*2417A** 355(A,C)AV042060 17,800 12.2 14.5
3040619 113ANC018---B CNPH*2417A** 355(A,C)AV042080 17,800 12.2 14.5
4130261 113ANC018---B CNPH*2417A** 359BAV036040 18,000 12.0 14.0
4130262 113ANC018---B CNPH*2417A** 359BAV036060 18,000 12.0 14.0
4130254 113ANC018---B CNPH*2417A** 368RAN036105 18,000 12.0 14.5
4130253 113ANC018---B CNPH*2417A** 374RAN036105 17,700 12.0 14.5
4734057 113ANC018---B CNPH*2417A** 925*A30040E14*** 17,700 11.8 14.2
4765893 113ANC018---B CNPH*2417A** 986*A30040V14*** 18,000 12.0 14.5
4765898 113ANC018---B CNPH*2417A** 986*A42060V17*** 18,000 12.5 15.0
4765903 113ANC018---B CNPH*2417A** 986*A48080V17*** 18,000 12.5 15.0
4765905 113ANC018---B CNPH*2417A** 986*A48100V21*** 18,000 12.5 15.0
4765907 113ANC018---B CNPH*2417A** 986*A66120V24*** 18,000 12.5 15.0
4734055 113ANC018---B CNPH*2417A** 987*A42060V17*** 17,800 12.0 14.5
4734056 113ANC018---B CNPH*2417A** 987*A42080V17*** 17,700 12.0 14.5
4255264 113ANC018---B CNPH*2417A** OVLAAB036098 17,900 12.0 14.5
4130255 113ANC018---B CNPH*2417A** OVMAAB036098 18,000 12.0 14.5
3040616 113ANC018---B CNPH*2417A**+TDR 18,000 11.2 13.2
3040609 113ANC018---B CNPV*1814A** 313*AV024045 17,900 12.2 14.5
3040608 113ANC018---B CNPV*1814A** 315(A,J)AV036070 17,500 12.0 14.0
4734047 113ANC018---B CNPV*1814A** 925*A30040E14*** 17,400 11.8 14.2
4765889 113ANC018---B CNPV*1814A** 986*A30040V14*** 17,700 11.8 14.2
3040607 113ANC018---B CNPV*1814A**+TDR 17,700 11.0 13.0
3689947 113ANC018---B CNPV*1917A** 315(A,J)AV048090 18,000 12.0 14.5
3689993 113ANC018---B CNPV*1917A** 353(A,B)AV036060 18,000 12.0 14.5
3689992 113ANC018---B CNPV*1917A** 353AAV036040 18,000 12.0 14.5
3689946 113ANC018---B CNPV*1917A** 355(A,C)AV042060 18,000 12.0 14.5
3690003 113ANC018---B CNPV*1917A** 355BAV042060 18,000 12.0 14.5
4130248 113ANC018---B CNPV*1917A** 368RAN036105 18,000 12.0 15.0
4130247 113ANC018---B CNPV*1917A** 374RAN036105 17,800 12.0 14.5
4734050 113ANC018---B CNPV*1917A** 925*A30040E14*** 17,900 12.0 14.5
4765890 113ANC018---B CNPV*1917A** 986*A30040V14*** 18,000 12.0 14.5
4765896 113ANC018---B CNPV*1917A** 986*A42060V17*** 18,000 12.5 15.2
4765901 113ANC018---B CNPV*1917A** 986*A48080V17*** 18,000 12.5 15.2
4734048 113ANC018---B CNPV*1917A** 987*A42060V17*** 17,900 12.0 14.5
4734049 113ANC018---B CNPV*1917A** 987*A42080V17*** 17,800 12.0 14.5
4255262 113ANC018---B CNPV*1917A** OVLAAB036098 18,000 12.0 14.5
4130249 113ANC018---B CNPV*1917A** OVMAAB036098 18,000 12.0 14.5
3689945 113ANC018---B CNPV*1917A**+TDR 18,000 11.0 13.0
3040612 113ANC018---B CNPV*2414A** 313*AV024045 18,000 12.2 14.5
3040611 113ANC018---B CNPV*2414A** 315(A,J)AV036070 17,800 12.2 14.5
See notes on page 38
113ANC

12
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4734051 113ANC018---B CNPV*2414A** 925*A30040E14*** 17,700 11.8 14.2
4765891 113ANC018---B CNPV*2414A** 986*A30040V14*** 18,000 12.0 14.5
3040610 113ANC018---B CNPV*2414A**+TDR 18,000 11.2 13.2
3040615 113ANC018---B CNPV*2417A** 315(A,J)AV048090 17,900 12.2 14.5
3613602 113ANC018---B CNPV*2417A** 353(A,B)AV036040 17,800 12.0 14.5
3099102 113ANC018---B CNPV*2417A** 353(A,B)AV036060 17,800 12.0 14.5
3099101 113ANC018---B CNPV*2417A** 353AAV036040 17,800 12.0 14.5
3040614 113ANC018---B CNPV*2417A** 355(A,C)AV042060 17,800 12.2 14.5
3751078 113ANC018---B CNPV*2417A** 355BAV042060 17,800 12.2 14.5
4130259 113ANC018---B CNPV*2417A** 359BAV036040 18,000 12.0 14.0
4130260 113ANC018---B CNPV*2417A** 359BAV036060 18,000 12.0 14.0
4130251 113ANC018---B CNPV*2417A** 368RAN036105 18,000 12.0 14.5
4130250 113ANC018---B CNPV*2417A** 374RAN036105 17,700 12.0 14.5
4734054 113ANC018---B CNPV*2417A** 925*A30040E14*** 17,700 11.8 14.2
4765892 113ANC018---B CNPV*2417A** 986*A30040V14*** 18,000 12.0 14.5
4765897 113ANC018---B CNPV*2417A** 986*A42060V17*** 18,000 12.5 15.0
4765902 113ANC018---B CNPV*2417A** 986*A48080V17*** 18,000 12.5 15.0
4734052 113ANC018---B CNPV*2417A** 987*A42060V17*** 17,800 12.0 14.5
4734053 113ANC018---B CNPV*2417A** 987*A42080V17*** 17,700 12.0 14.5
4255263 113ANC018---B CNPV*2417A** OVLAAB036098 17,900 12.0 14.5
4130252 113ANC018---B CNPV*2417A** OVMAAB036098 18,000 12.0 14.5
3040613 113ANC018---B CNPV*2417A**+TDR 18,000 11.2 13.2
3040630 113ANC018---B CSPH*2412A** 313*AV024045 18,000 12.2 14.5
3040628 113ANC018---B CSPH*2412A** 315(A,J)AV036070 17,800 12.2 14.5
3040629 113ANC018---B CSPH*2412A** 315(A,J)AV048090 18,000 12.2 14.5
3613603 113ANC018---B CSPH*2412A** 353(A,B)AV036040 17,800 12.0 14.5
3099106 113ANC018---B CSPH*2412A** 353(A,B)AV036060 17,800 12.0 14.5
3099105 113ANC018---B CSPH*2412A** 353AAV036040 17,800 12.0 14.5
3040626 113ANC018---B CSPH*2412A** 355(A,C)AV042060 18,000 12.2 14.5
3040627 113ANC018---B CSPH*2412A** 355(A,C)AV042080 17,900 12.2 14.5
3689948 113ANC018---B CSPH*2412A** 359BAV036040 18,400 12.0 14.5
3689949 113ANC018---B CSPH*2412A** 359BAV036060 18,400 12.0 14.5
4130257 113ANC018---B CSPH*2412A** 368RAN036105 18,000 12.0 14.5
4130256 113ANC018---B CSPH*2412A** 374RAN036105 17,800 12.0 14.5
4734060 113ANC018---B CSPH*2412A** 925*A30040E14*** 17,700 11.8 14.2
4765888 113ANC018---B CSPH*2412A** 986*A30040V14*** 18,000 12.0 14.5
4765895 113ANC018---B CSPH*2412A** 986*A42060V17*** 18,000 12.0 14.5
4765900 113ANC018---B CSPH*2412A** 986*A48080V17*** 18,000 12.5 15.0
4765904 113ANC018---B CSPH*2412A** 986*A48100V21*** 18,000 12.5 15.0
4765906 113ANC018---B CSPH*2412A** 986*A66120V24*** 18,000 12.5 15.0
4734058 113ANC018---B CSPH*2412A** 987*A42060V17*** 17,900 12.0 14.5
4734059 113ANC018---B CSPH*2412A** 987*A42080V17*** 17,800 12.0 14.5
4255265 113ANC018---B CSPH*2412A** OVLAAB036098 18,000 12.0 14.5
4130258 113ANC018---B CSPH*2412A** OVMAAB036098 18,000 12.0 14.5
3040624 113ANC018---B CSPH*2412A**+TDR 18,000 11.2 13.2
4208560 113ANC018---B FB4CNF018 17,500 11.0 13.0
4208561 113ANC018---B FB4CNF018+TXV 17,500 11.0 13.5
4208562 113ANC018---B FB4CNF024 17,500 11.0 13.0
4208563 113ANC018---B FB4CNF024+TXV 17,500 11.0 13.5
3040635 113ANC018---B FE4ANF002+UI 17,300 12.2 14.5
3040636 113ANC018---B FF1ENP018 17,700 11.0 13.0
3468791 113ANC018---B FF1ENP019 18,000 12.0 14.0
3040637 113ANC018---B FF1ENP024 17,900 11.0 13.0
3468792 113ANC018---B FF1ENP025 18,000 12.2 14.5
3404653 113ANC018---B FV4CNF002 17,300 12.2 14.5
3752148 113ANC018---B FX4DN(B,F)031 18,000 12.0 14.5
3752149 113ANC018---B FX4DN(B,F)037 23,200 12.0 14.5
3752146 113ANC018---B FX4DNF019 18,000 12.0 14.5
3752147 113ANC018---B FX4DNF025 18,000 12.0 14.5
4208564 113ANC018---B FY5BNF018 17,500 11.0 13.0
4208565 113ANC018---B FY5BNF018+TXV 17,500 11.0 13.0
4208566 113ANC018---B FY5BNF024 17,500 11.0 13.0
4208567 113ANC018---B FY5BNF024+TXV 17,500 11.0 13.0
3040639 113ANC024---B †CAP**2414A**+TDR 22,600 10.7 13.0
4765953 113ANC024---B †CAP**2417A** 22,600 10.7 13.0
3040641 113ANC024---B CAP**2414A** 313*AV024045 22,600 11.7 14.0
3040640 113ANC024---B CAP**2414A** 315(A,J)AV036070 22,400 11.7 14.0
4734061 113ANC024---B CAP**2414A** 925*A30040E14*** 22,600 11.0 13.3
4765909 113ANC024---B CAP**2414A** 986*A30040V14*** 22,400 11.2 13.5
3040644 113ANC024---B CAP**2417A** 315(A,J)AV048090 22,600 12.0 14.0
3613612 113ANC024---B CAP**2417A** 353(A,B)AV036040 22,600 12.0 14.5
3099108 113ANC024---B CAP**2417A** 353(A,B)AV036060 22,600 12.0 14.5
See notes on page 38
113ANC

13
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3099109 113ANC024---B CAP**2417A** 353(A,B)AV036080 22,600 12.0 14.5
3099107 113ANC024---B CAP**2417A** 353AAV036040 22,600 12.0 14.5
3040643 113ANC024---B CAP**2417A** 355(A,C)AV042060 22,800 12.0 14.0
3808328 113ANC024---B CAP**2417A** 355BAV042060 22,800 12.0 14.0
4130264 113ANC024---B CAP**2417A** 368RAN036105 22,600 11.7 14.0
4130263 113ANC024---B CAP**2417A** 374RAN036105 22,400 11.7 14.0
4734064 113ANC024---B CAP**2417A** 925*A30040E14*** 22,600 11.0 13.3
4734065 113ANC024---B CAP**2417A** 925*A42060E17*** 22,400 11.8 14.2
4765910 113ANC024---B CAP**2417A** 986*A30040V14*** 22,600 11.2 13.5
4765923 113ANC024---B CAP**2417A** 986*A42060V17*** 22,600 11.8 14.2
4765933 113ANC024---B CAP**2417A** 986*A48080V17*** 22,600 12.0 14.5
4734062 113ANC024---B CAP**2417A** 987*A42060V17*** 22,400 11.8 14.2
4734063 113ANC024---B CAP**2417A** 987*A42080V17*** 22,400 11.8 14.2
4255266 113ANC024---B CAP**2417A** OVLAAB036098 22,600 11.7 14.0
4130265 113ANC024---B CAP**2417A** OVMAAB036098 22,600 11.7 14.0
4130266 113ANC024---B CAP**2417A** OVMAAB042112 22,600 11.7 14.0
3040642 113ANC024---B CAP**2417A**+TDR 22,600 10.7 13.0
3040647 113ANC024---B CAP**3014A** 313*AV024045 23,000 12.0 14.0
3040646 113ANC024---B CAP**3014A** 315(A,J)AV036070 22,600 12.0 14.0
4734066 113ANC024---B CAP**3014A** 925*A30040E14*** 22,800 11.0 13.3
4765911 113ANC024---B CAP**3014A** 986*A30040V14*** 22,600 11.4 13.7
3040645 113ANC024---B CAP**3014A**+TDR 23,000 10.7 13.0
3040650 113ANC024---B CAP**3017A** 315(A,J)AV048090 22,800 12.0 14.5
3613613 113ANC024---B CAP**3017A** 353(A,B)AV036040 22,600 12.0 14.5
3099111 113ANC024---B CAP**3017A** 353(A,B)AV036060 22,600 12.0 14.5
3099112 113ANC024---B CAP**3017A** 353(A,B)AV036080 22,600 12.0 14.5
3099110 113ANC024---B CAP**3017A** 353AAV036040 22,600 12.0 14.5
3040649 113ANC024---B CAP**3017A** 355(A,C)AV042060 23,000 12.2 14.5
3808329 113ANC024---B CAP**3017A** 355BAV042060 23,000 12.2 14.5
4130268 113ANC024---B CAP**3017A** 368RAN036105 22,800 12.0 14.5
4130267 113ANC024---B CAP**3017A** 374RAN036105 22,600 12.0 14.5
4734069 113ANC024---B CAP**3017A** 925*A30040E14*** 22,800 11.2 13.5
4734070 113ANC024---B CAP**3017A** 925*A42060E17*** 22,800 12.0 14.5
4765912 113ANC024---B CAP**3017A** 986*A30040V14*** 22,600 11.4 13.7
4765924 113ANC024---B CAP**3017A** 986*A42060V17*** 22,800 12.0 14.5
4765934 113ANC024---B CAP**3017A** 986*A48080V17*** 23,000 12.0 14.5
4734067 113ANC024---B CAP**3017A** 987*A42060V17*** 22,600 11.8 14.2
4734068 113ANC024---B CAP**3017A** 987*A42080V17*** 22,600 12.0 14.5
4255267 113ANC024---B CAP**3017A** OVLAAB036098 22,800 11.7 14.0
4130269 113ANC024---B CAP**3017A** OVMAAB036098 22,800 11.7 14.0
4130270 113ANC024---B CAP**3017A** OVMAAB042112 22,800 12.0 14.5
3040648 113ANC024---B CAP**3017A**+TDR 23,000 10.7 13.0
3689943 113ANC024---B CAP**3619A** 359BAV036040 23,000 11.5 14.0
3689944 113ANC024---B CAP**3619A** 359BAV036060 23,000 11.5 14.0
3689942 113ANC024---B CAP**3619A**+TDR 23,000 11.0 13.0
3040675 113ANC024---B CNPH*2417A** 313*AV024045 22,600 11.7 14.0
3040670 113ANC024---B CNPH*2417A** 315(A,J)AV036070 22,400 11.7 14.0
3040671 113ANC024---B CNPH*2417A** 315(A,J)AV048090 22,600 12.0 14.0
3040672 113ANC024---B CNPH*2417A** 315(A,J)AV060110 22,600 11.7 14.0
3040673 113ANC024---B CNPH*2417A** 315(A,J)AV066135 22,600 11.7 14.0
3040674 113ANC024---B CNPH*2417A** 315(A,J)AV066155 22,600 11.7 14.0
3613614 113ANC024---B CNPH*2417A** 353(A,B)AV036040 22,600 12.0 14.5
3099120 113ANC024---B CNPH*2417A** 353(A,B)AV036060 22,600 12.0 14.5
3099121 113ANC024---B CNPH*2417A** 353(A,B)AV036080 22,600 12.0 14.5
3099119 113ANC024---B CNPH*2417A** 353AAV036040 22,600 12.0 14.5
3040665 113ANC024---B CNPH*2417A** 355(A,C)AV042060 22,800 11.7 14.0
3040666 113ANC024---B CNPH*2417A** 355(A,C)AV042080 22,400 11.7 14.0
3040667 113ANC024---B CNPH*2417A** 355(A,C)AV060080 22,200 11.7 14.0
3040668 113ANC024---B CNPH*2417A** 355(A,C)AV060100 22,600 11.7 14.0
3040669 113ANC024---B CNPH*2417A** 355(A,C)AV060120 22,600 12.0 14.0
4130309 113ANC024---B CNPH*2417A** 359BAV036060 22,600 11.5 13.5
4130310 113ANC024---B CNPH*2417A** 359BAV060080 23,000 11.7 14.0
4130311 113ANC024---B CNPH*2417A** 359BAV060100 22,800 11.7 14.0
4130284 113ANC024---B CNPH*2417A** 368RAN036105 22,600 11.7 14.0
4130283 113ANC024---B CNPH*2417A** 374RAN036105 22,400 11.7 14.0
4734089 113ANC024---B CNPH*2417A** 925*A30040E14*** 22,600 11.0 13.0
4734090 113ANC024---B CNPH*2417A** 925*A42060E17*** 22,400 11.8 14.2
4765920 113ANC024---B CNPH*2417A** 986*A30040V14*** 22,400 11.2 13.5
4765930 113ANC024---B CNPH*2417A** 986*A42060V17*** 22,400 11.8 14.2
4765940 113ANC024---B CNPH*2417A** 986*A48080V17*** 22,600 11.8 14.2
4765945 113ANC024---B CNPH*2417A** 986*A48100V21*** 22,400 11.8 14.2
4765950 113ANC024---B CNPH*2417A** 986*A66120V24*** 22,600 12.0 14.5
4734085 113ANC024---B CNPH*2417A** 987*A42060V17*** 22,400 11.5 14.0
See notes on page 38
113ANC

14
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4734086 113ANC024---B CNPH*2417A** 987*A42080V17*** 22,200 11.8 14.2
4734087 113ANC024---B CNPH*2417A** 987*A60100V21*** 22,600 11.8 14.2
4734088 113ANC024---B CNPH*2417A** 987*A66120V24*** 22,600 11.8 14.2
4255273 113ANC024---B CNPH*2417A** OVLAAB036098 22,600 11.7 14.0
4130285 113ANC024---B CNPH*2417A** OVMAAB036098 22,600 11.5 13.5
4130286 113ANC024---B CNPH*2417A** OVMAAB042112 22,600 11.7 14.0
3040663 113ANC024---B CNPH*2417A**+TDR 22,600 10.7 13.0
3040688 113ANC024---B CNPH*3017A** 313*AV024045 23,000 12.0 14.0
3040683 113ANC024---B CNPH*3017A** 315(A,J)AV036070 22,800 12.0 14.0
3040684 113ANC024---B CNPH*3017A** 315(A,J)AV048090 22,800 12.0 14.5
3040685 113ANC024---B CNPH*3017A** 315(A,J)AV060110 22,800 12.0 14.5
3040686 113ANC024---B CNPH*3017A** 315(A,J)AV066135 22,800 12.2 14.5
3040687 113ANC024---B CNPH*3017A** 315(A,J)AV066155 22,800 12.0 14.5
3613615 113ANC024---B CNPH*3017A** 353(A,B)AV036040 22,600 12.0 14.5
3099123 113ANC024---B CNPH*3017A** 353(A,B)AV036060 22,600 12.0 14.5
3099124 113ANC024---B CNPH*3017A** 353(A,B)AV036080 22,600 12.0 14.5
3099122 113ANC024---B CNPH*3017A** 353AAV036040 22,600 12.0 14.5
3040678 113ANC024---B CNPH*3017A** 355(A,C)AV042060 23,000 12.2 14.5
3040679 113ANC024---B CNPH*3017A** 355(A,C)AV042080 22,800 12.0 14.5
3040680 113ANC024---B CNPH*3017A** 355(A,C)AV060080 22,600 12.0 14.0
3040681 113ANC024---B CNPH*3017A** 355(A,C)AV060100 22,800 12.0 14.5
3040682 113ANC024---B CNPH*3017A** 355(A,C)AV060120 23,000 12.2 14.5
4130312 113ANC024---B CNPH*3017A** 359BAV036040 23,000 11.7 14.0
4130313 113ANC024---B CNPH*3017A** 359BAV036060 23,200 11.7 14.0
4130314 113ANC024---B CNPH*3017A** 359BAV060100 23,400 12.0 14.5
4130288 113ANC024---B CNPH*3017A** 368RAN036105 23,000 12.0 14.5
4130287 113ANC024---B CNPH*3017A** 374RAN036105 22,600 11.7 14.0
4734095 113ANC024---B CNPH*3017A** 925*A30040E14*** 22,800 11.2 13.5
4734096 113ANC024---B CNPH*3017A** 925*A42060E17*** 22,800 12.0 14.5
4765921 113ANC024---B CNPH*3017A** 986*A30040V14*** 22,600 11.4 13.7
4765931 113ANC024---B CNPH*3017A** 986*A42060V17*** 22,800 12.0 14.5
4765941 113ANC024---B CNPH*3017A** 986*A48080V17*** 23,000 12.0 14.5
4765946 113ANC024---B CNPH*3017A** 986*A48100V21*** 22,800 12.0 14.5
4765951 113ANC024---B CNPH*3017A** 986*A66120V24*** 23,000 12.0 14.5
4734091 113ANC024---B CNPH*3017A** 987*A42060V17*** 22,600 12.0 14.5
4734092 113ANC024---B CNPH*3017A** 987*A42080V17*** 22,600 12.0 14.5
4734093 113ANC024---B CNPH*3017A** 987*A60100V21*** 23,000 12.0 14.5
4734094 113ANC024---B CNPH*3017A** 987*A66120V24*** 22,800 12.0 14.5
4255274 113ANC024---B CNPH*3017A** OVLAAB036098 22,800 11.7 14.0
4130289 113ANC024---B CNPH*3017A** OVMAAB036098 22,800 11.7 14.0
4130290 113ANC024---B CNPH*3017A** OVMAAB042112 22,800 12.0 14.5
3040676 113ANC024---B CNPH*3017A**+TDR 23,000 10.7 13.0
3689931 113ANC024---B CNPH*3117A** 313*AV024045 23,000 12.0 14.5
3689926 113ANC024---B CNPH*3117A** 315(A,J)AV036070 23,000 12.0 14.5
3689927 113ANC024---B CNPH*3117A** 315(A,J)AV048090 23,000 12.0 14.5
3689928 113ANC024---B CNPH*3117A** 315(A,J)AV060110 23,000 12.0 14.5
3689929 113ANC024---B CNPH*3117A** 315(A,J)AV066135 23,000 12.0 14.5
3689930 113ANC024---B CNPH*3117A** 315(A,J)AV066155 23,000 12.0 14.5
3689990 113ANC024---B CNPH*3117A** 353(A,B)AV036060 23,000 12.0 14.5
3689991 113ANC024---B CNPH*3117A** 353(A,B)AV036080 23,000 12.0 14.5
3689989 113ANC024---B CNPH*3117A** 353AAV036040 23,000 12.0 14.5
3689921 113ANC024---B CNPH*3117A** 355(A,C)AV042060 23,000 12.0 14.5
3689922 113ANC024---B CNPH*3117A** 355(A,C)AV042080 23,000 12.0 14.5
3689923 113ANC024---B CNPH*3117A** 355(A,C)AV060080 23,000 12.0 14.5
3689924 113ANC024---B CNPH*3117A** 355(A,C)AV060100 23,000 12.0 14.5
3689925 113ANC024---B CNPH*3117A** 355(A,C)AV060120 23,000 12.0 14.5
3689920 113ANC024---B CNPH*3117A** 355AAV042040 23,000 12.0 14.5
3689932 113ANC024---B CNPH*3117A** 359BAV036040 23,000 12.0 14.5
3689933 113ANC024---B CNPH*3117A** 359BAV036060 23,000 12.0 14.5
3689934 113ANC024---B CNPH*3117A** 359BAV060100 23,000 12.0 14.5
4130292 113ANC024---B CNPH*3117A** 368RAN036105 23,400 12.0 14.5
4130291 113ANC024---B CNPH*3117A** 374RAN036105 23,000 12.0 14.5
4734101 113ANC024---B CNPH*3117A** 925*A30040E14*** 23,400 11.4 13.7
4734102 113ANC024---B CNPH*3117A** 925*A42060E17*** 23,200 12.0 14.5
4765922 113ANC024---B CNPH*3117A** 986*A30040V14*** 23,200 11.5 14.0
4765932 113ANC024---B CNPH*3117A** 986*A42060V17*** 23,200 12.0 14.5
4765942 113ANC024---B CNPH*3117A** 986*A48080V17*** 23,400 12.5 15.0
4765947 113ANC024---B CNPH*3117A** 986*A48100V21*** 23,200 12.4 15.0
4765952 113ANC024---B CNPH*3117A** 986*A66120V24*** 23,600 12.5 15.0
4734097 113ANC024---B CNPH*3117A** 987*A42060V17*** 23,000 12.0 14.5
4734098 113ANC024---B CNPH*3117A** 987*A42080V17*** 23,000 12.0 14.5
4734099 113ANC024---B CNPH*3117A** 987*A60100V21*** 23,400 12.0 14.5
4734100 113ANC024---B CNPH*3117A** 987*A66120V24*** 23,200 12.4 15.0
See notes on page 38
113ANC

15
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4255275 113ANC024---B CNPH*3117A** OVLAAB036098 23,400 12.0 14.5
4130293 113ANC024---B CNPH*3117A** OVMAAB036098 23,400 12.0 14.5
4130294 113ANC024---B CNPH*3117A** OVMAAB042112 23,200 12.0 14.5
3689919 113ANC024---B CNPH*3117A**+TDR 23,000 11.0 13.0
3040653 113ANC024---B CNPV*2414A** 313*AV024045 22,600 11.7 14.0
3040652 113ANC024---B CNPV*2414A** 315(A,J)AV036070 22,400 11.7 14.0
4734071 113ANC024---B CNPV*2414A** 925*A30040E14*** 22,600 11.0 13.0
4765915 113ANC024---B CNPV*2414A** 986*A30040V14*** 22,400 11.2 13.5
3040651 113ANC024---B CNPV*2414A**+TDR 22,600 10.7 13.0
3040656 113ANC024---B CNPV*2417A** 315(A,J)AV048090 22,600 12.0 14.0
3613616 113ANC024---B CNPV*2417A** 353(A,B)AV036040 22,600 12.0 14.5
3099114 113ANC024---B CNPV*2417A** 353(A,B)AV036060 22,600 12.0 14.5
3099115 113ANC024---B CNPV*2417A** 353(A,B)AV036080 22,600 12.0 14.5
3099113 113ANC024---B CNPV*2417A** 353AAV036040 22,600 12.0 14.5
3040655 113ANC024---B CNPV*2417A** 355(A,C)AV042060 22,800 11.7 14.0
3751081 113ANC024---B CNPV*2417A** 355BAV042060 22,800 11.7 14.0
4130303 113ANC024---B CNPV*2417A** 359BAV036040 22,600 11.5 13.5
4130304 113ANC024---B CNPV*2417A** 359BAV036060 22,600 11.5 13.5
4130272 113ANC024---B CNPV*2417A** 368RAN036105 22,600 11.7 14.0
4130271 113ANC024---B CNPV*2417A** 374RAN036105 22,400 11.7 14.0
4734074 113ANC024---B CNPV*2417A** 925*A30040E14*** 22,600 11.0 13.0
4734075 113ANC024---B CNPV*2417A** 925*A42060E17*** 22,400 11.8 14.2
4765916 113ANC024---B CNPV*2417A** 986*A30040V14*** 22,400 11.2 13.5
4765927 113ANC024---B CNPV*2417A** 986*A42060V17*** 22,400 11.8 14.2
4765937 113ANC024---B CNPV*2417A** 986*A48080V17*** 22,600 11.8 14.2
4734072 113ANC024---B CNPV*2417A** 987*A42060V17*** 22,400 11.5 14.0
4734073 113ANC024---B CNPV*2417A** 987*A42080V17*** 22,200 11.8 14.2
4255270 113ANC024---B CNPV*2417A** OVLAAB036098 22,600 11.7 14.0
4130273 113ANC024---B CNPV*2417A** OVMAAB036098 22,600 11.5 13.5
4130274 113ANC024---B CNPV*2417A** OVMAAB042112 22,600 11.7 14.0
3040654 113ANC024---B CNPV*2417A**+TDR 22,600 10.7 13.0
3040659 113ANC024---B CNPV*3014A** 313*AV024045 23,000 12.0 14.0
3040658 113ANC024---B CNPV*3014A** 315(A,J)AV036070 22,800 12.0 14.0
4734076 113ANC024---B CNPV*3014A** 925*A30040E14*** 22,800 11.0 13.3
4765917 113ANC024---B CNPV*3014A** 986*A30040V14*** 22,600 11.4 13.7
3040657 113ANC024---B CNPV*3014A**+TDR 23,000 10.7 13.0
3040662 113ANC024---B CNPV*3017A** 315(A,J)AV048090 22,800 12.0 14.5
3613617 113ANC024---B CNPV*3017A** 353(A,B)AV036040 22,600 12.0 14.5
3099117 113ANC024---B CNPV*3017A** 353(A,B)AV036060 22,600 12.0 14.5
3099118 113ANC024---B CNPV*3017A** 353(A,B)AV036080 22,600 12.0 14.5
3099116 113ANC024---B CNPV*3017A** 353AAV036040 22,600 12.0 14.5
3040661 113ANC024---B CNPV*3017A** 355(A,C)AV042060 23,000 12.2 14.5
3751082 113ANC024---B CNPV*3017A** 355BAV042060 23,000 12.2 14.5
4130305 113ANC024---B CNPV*3017A** 359BAV036040 23,000 11.7 14.0
4130306 113ANC024---B CNPV*3017A** 359BAV036060 23,200 11.7 14.0
4130276 113ANC024---B CNPV*3017A** 368RAN036105 23,000 12.0 14.5
4130275 113ANC024---B CNPV*3017A** 374RAN036105 22,600 12.0 14.5
4734079 113ANC024---B CNPV*3017A** 925*A30040E14*** 22,800 11.2 13.5
4734080 113ANC024---B CNPV*3017A** 925*A42060E17*** 22,800 12.0 14.5
4765918 113ANC024---B CNPV*3017A** 986*A30040V14*** 22,600 11.4 13.7
4765928 113ANC024---B CNPV*3017A** 986*A42060V17*** 22,800 12.0 14.5
4765938 113ANC024---B CNPV*3017A** 986*A48080V17*** 23,000 12.0 14.5
4734077 113ANC024---B CNPV*3017A** 987*A42060V17*** 22,600 12.0 14.5
4734078 113ANC024---B CNPV*3017A** 987*A42080V17*** 22,600 12.0 14.5
4255271 113ANC024---B CNPV*3017A** OVLAAB036098 22,800 11.7 14.0
4130277 113ANC024---B CNPV*3017A** OVMAAB036098 22,800 11.7 14.0
4130278 113ANC024---B CNPV*3017A** OVMAAB042112 22,800 12.0 14.5
3040660 113ANC024---B CNPV*3017A**+TDR 23,000 10.7 13.0
3689918 113ANC024---B CNPV*3117A** 315(A,J)AV048090 23,000 12.0 14.5
3689987 113ANC024---B CNPV*3117A** 353(A,B)AV036060 23,000 12.0 14.5
3689988 113ANC024---B CNPV*3117A** 353(A,B)AV036080 23,000 12.0 14.5
3689986 113ANC024---B CNPV*3117A** 353AAV036040 23,000 12.0 14.5
3689917 113ANC024---B CNPV*3117A** 355(A,C)AV042060 23,000 12.0 14.5
3690002 113ANC024---B CNPV*3117A** 355BAV042060 23,000 12.0 14.5
4130307 113ANC024---B CNPV*3117A** 359BAV036040 23,400 11.7 14.0
4130308 113ANC024---B CNPV*3117A** 359BAV036060 23,600 12.0 14.5
4130280 113ANC024---B CNPV*3117A** 368RAN036105 23,400 12.0 14.5
4130279 113ANC024---B CNPV*3117A** 374RAN036105 23,000 12.0 14.5
4734083 113ANC024---B CNPV*3117A** 925*A30040E14*** 23,400 11.4 13.7
4734084 113ANC024---B CNPV*3117A** 925*A42060E17*** 23,200 12.0 14.5
4765919 113ANC024---B CNPV*3117A** 986*A30040V14*** 23,200 11.5 14.0
4765929 113ANC024---B CNPV*3117A** 986*A42060V17*** 23,200 12.0 14.5
4765939 113ANC024---B CNPV*3117A** 986*A48080V17*** 23,400 12.4 15.0
See notes on page 38
113ANC

16
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4734081 113ANC024---B CNPV*3117A** 987*A42060V17*** 23,000 12.0 14.5
4734082 113ANC024---B CNPV*3117A** 987*A42080V17*** 23,000 12.0 14.5
4255272 113ANC024---B CNPV*3117A** OVLAAB036098 23,400 12.0 14.5
4130281 113ANC024---B CNPV*3117A** OVMAAB036098 23,400 12.0 14.5
4130282 113ANC024---B CNPV*3117A** OVMAAB042112 23,200 12.0 14.5
3689916 113ANC024---B CNPV*3117A**+TDR 23,000 11.0 13.0
3040702 113ANC024---B CSPH*2412A** 313*AV024045 22,800 11.7 14.0
3040697 113ANC024---B CSPH*2412A** 315(A,J)AV036070 22,400 11.7 14.0
3040698 113ANC024---B CSPH*2412A** 315(A,J)AV048090 22,800 12.0 14.0
3040699 113ANC024---B CSPH*2412A** 315(A,J)AV060110 22,800 11.7 14.0
3040700 113ANC024---B CSPH*2412A** 315(A,J)AV066135 22,800 12.0 14.0
3040701 113ANC024---B CSPH*2412A** 315(A,J)AV066155 22,800 12.0 14.0
3613618 113ANC024---B CSPH*2412A** 353(A,B)AV036040 22,600 12.0 14.5
3099126 113ANC024---B CSPH*2412A** 353(A,B)AV036060 22,600 12.0 14.5
3099127 113ANC024---B CSPH*2412A** 353(A,B)AV036080 22,600 12.0 14.5
3099125 113ANC024---B CSPH*2412A** 353AAV036040 22,600 12.0 14.5
3040692 113ANC024---B CSPH*2412A** 355(A,C)AV042060 23,000 12.0 14.0
3040693 113ANC024---B CSPH*2412A** 355(A,C)AV042080 22,800 12.0 14.0
3040694 113ANC024---B CSPH*2412A** 355(A,C)AV060080 22,600 11.7 14.0
3040695 113ANC024---B CSPH*2412A** 355(A,C)AV060100 22,800 12.0 14.0
3040696 113ANC024---B CSPH*2412A** 355(A,C)AV060120 22,800 12.0 14.0
3689935 113ANC024---B CSPH*2412A** 359BAV036040 22,800 11.5 14.0
3689936 113ANC024---B CSPH*2412A** 359BAV036060 22,800 11.5 14.0
3689937 113ANC024---B CSPH*2412A** 359BAV060080 22,800 11.5 14.0
3689938 113ANC024---B CSPH*2412A** 359BAV060100 22,800 11.5 14.0
4130296 113ANC024---B CSPH*2412A** 368RAN036105 23,000 11.7 14.0
4130295 113ANC024---B CSPH*2412A** 374RAN036105 22,600 11.7 14.0
4734107 113ANC024---B CSPH*2412A** 925*A30040E14*** 22,800 11.0 13.3
4734108 113ANC024---B CSPH*2412A** 925*A42060E17*** 22,400 11.8 14.2
4765913 113ANC024---B CSPH*2412A** 986*A30040V14*** 22,600 11.2 13.5
4765925 113ANC024---B CSPH*2412A** 986*A42060V17*** 22,600 11.8 14.2
4765935 113ANC024---B CSPH*2412A** 986*A48080V17*** 22,800 12.0 14.5
4765943 113ANC024---B CSPH*2412A** 986*A48100V21*** 22,400 11.8 14.2
4765948 113ANC024---B CSPH*2412A** 986*A66120V24*** 22,600 12.0 14.5
4734103 113ANC024---B CSPH*2412A** 987*A42060V17*** 22,600 11.8 14.2
4734104 113ANC024---B CSPH*2412A** 987*A42080V17*** 22,600 11.8 14.2
4734105 113ANC024---B CSPH*2412A** 987*A60100V21*** 23,000 11.8 14.2
4734106 113ANC024---B CSPH*2412A** 987*A66120V24*** 22,800 12.0 14.5
4255268 113ANC024---B CSPH*2412A** OVLAAB036098 22,800 11.7 14.0
4130297 113ANC024---B CSPH*2412A** OVMAAB036098 22,800 11.7 14.0
4130298 113ANC024---B CSPH*2412A** OVMAAB042112 22,800 11.7 14.0
3040690 113ANC024---B CSPH*2412A**+TDR 22,600 10.7 13.0
3040715 113ANC024---B CSPH*3012A** 313*AV024045 23,000 12.0 14.0
3040710 113ANC024---B CSPH*3012A** 315(A,J)AV036070 22,800 12.0 14.0
3040711 113ANC024---B CSPH*3012A** 315(A,J)AV048090 22,800 12.0 14.5
3040712 113ANC024---B CSPH*3012A** 315(A,J)AV060110 22,800 12.0 14.0
3040713 113ANC024---B CSPH*3012A** 315(A,J)AV066135 23,000 12.0 14.5
3040714 113ANC024---B CSPH*3012A** 315(A,J)AV066155 23,000 12.0 14.5
3613619 113ANC024---B CSPH*3012A** 353(A,B)AV036040 22,600 12.0 14.5
3099129 113ANC024---B CSPH*3012A** 353(A,B)AV036060 22,600 12.0 14.5
3099130 113ANC024---B CSPH*3012A** 353(A,B)AV036080 22,600 12.0 14.5
3099128 113ANC024---B CSPH*3012A** 353AAV036040 22,600 12.0 14.5
3040705 113ANC024---B CSPH*3012A** 355(A,C)AV042060 23,200 12.0 14.5
3040706 113ANC024---B CSPH*3012A** 355(A,C)AV042080 22,800 12.0 14.0
3040707 113ANC024---B CSPH*3012A** 355(A,C)AV060080 22,600 12.0 14.0
3040708 113ANC024---B CSPH*3012A** 355(A,C)AV060100 22,800 12.0 14.5
3040709 113ANC024---B CSPH*3012A** 355(A,C)AV060120 23,000 12.0 14.5
3689939 113ANC024---B CSPH*3012A** 359BAV036040 23,000 11.5 14.0
3689940 113ANC024---B CSPH*3012A** 359BAV036060 23,000 11.5 14.0
3689941 113ANC024---B CSPH*3012A** 359BAV060100 23,000 11.5 14.0
4130300 113ANC024---B CSPH*3012A** 368RAN036105 23,000 12.0 14.5
4130299 113ANC024---B CSPH*3012A** 374RAN036105 22,600 11.7 14.0
4734113 113ANC024---B CSPH*3012A** 925*A30040E14*** 23,000 11.2 13.5
4734114 113ANC024---B CSPH*3012A** 925*A42060E17*** 22,800 12.0 14.5
4765914 113ANC024---B CSPH*3012A** 986*A30040V14*** 22,800 11.4 13.7
4765926 113ANC024---B CSPH*3012A** 986*A42060V17*** 22,800 12.0 14.5
4765936 113ANC024---B CSPH*3012A** 986*A48080V17*** 23,000 12.0 14.5
4765944 113ANC024---B CSPH*3012A** 986*A48100V21*** 22,800 12.0 14.5
4765949 113ANC024---B CSPH*3012A** 986*A66120V24*** 23,000 12.0 14.5
4734109 113ANC024---B CSPH*3012A** 987*A42060V17*** 22,800 11.8 14.2
4734110 113ANC024---B CSPH*3012A** 987*A42080V17*** 22,600 12.0 14.5
4734111 113ANC024---B CSPH*3012A** 987*A60100V21*** 23,000 12.0 14.5
4734112 113ANC024---B CSPH*3012A** 987*A66120V24*** 23,000 12.0 14.5
See notes on page 38
113ANC

17
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4255269 113ANC024---B CSPH*3012A** OVLAAB036098 23,000 11.7 14.0
4130301 113ANC024---B CSPH*3012A** OVMAAB036098 23,000 11.7 14.0
4130302 113ANC024---B CSPH*3012A** OVMAAB042112 22,800 12.0 14.5
3040703 113ANC024---B CSPH*3012A**+TDR 23,000 10.7 13.0
3867308 113ANC024---B FB4CNF024 22,400 11.0 13.0
4208568 113ANC024---B FB4CNF024+TXV 22,400 11.0 13.5
3867309 113ANC024---B FB4CNF030 23,000 11.0 13.0
4208569 113ANC024---B FB4CNF030+TXV 23,000 11.0 13.5
3040720 113ANC024---B FE4AN(B,F)003+UI 23,000 12.2 14.5
3040719 113ANC024---B FE4ANF002+UI 22,000 12.0 14.0
3040721 113ANC024---B FE5ANB004+UI 23,600 12.5 15.0
3040722 113ANC024---B FF1ENP024 22,400 10.7 13.0
3468789 113ANC024---B FF1ENP025 23,000 11.7 13.5
3468790 113ANC024---B FF1ENP031 23,000 11.7 13.5
3404656 113ANC024---B FV4CN(B,F)003 23,000 12.2 14.5
3404657 113ANC024---B FV4CNF002 22,000 12.0 14.0
3867310 113ANC024---B FY5BNF024 22,400 11.0 13.0
4208570 113ANC024---B FY5BNF024+TXV 22,400 11.0 13.5
3867311 113ANC024---B FY5BNF030 23,000 11.0 13.0
4208571 113ANC024---B FY5BNF030+TXV 23,000 11.0 13.5
3040725 113ANC030---B †CAP**3014A**+TDR 29,000 11.0 13.0
4765995 113ANC030---B †CAP**3017A** 29,000 11.0 13.0
3040726 113ANC030---B CAP**3014A** 315(A,J)AV036070 28,800 12.0 14.0
3040730 113ANC030---B CAP**3017A** 313*AV048070 29,000 12.0 14.0
3040729 113ANC030---B CAP**3017A** 315(A,J)AV048090 28,800 12.2 14.5
3613636 113ANC030---B CAP**3017A** 353(A,B)AV036040 29,000 12.0 14.5
3099132 113ANC030---B CAP**3017A** 353(A,B)AV036060 29,000 12.0 14.5
3099133 113ANC030---B CAP**3017A** 353(A,B)AV036080 29,000 12.0 14.5
3099134 113ANC030---B CAP**3017A** 353(A,B)AV048080 29,000 12.0 14.0
3099131 113ANC030---B CAP**3017A** 353AAV036040 29,000 12.0 14.5
3040728 113ANC030---B CAP**3017A** 355(A,C)AV042060 29,000 12.0 14.0
3808330 113ANC030---B CAP**3017A** 355BAV042060 29,000 12.0 14.0
4734117 113ANC030---B CAP**3017A** 925*A42060E17*** 28,800 11.8 14.2
4734118 113ANC030---B CAP**3017A** 925*A48080E17*** 29,000 11.8 14.2
4765954 113ANC030---B CAP**3017A** 986*A42060V17*** 28,800 11.8 14.2
4765968 113ANC030---B CAP**3017A** 986*A48080V17*** 29,000 12.0 14.5
4734115 113ANC030---B CAP**3017A** 987*A42060V17*** 28,600 11.8 14.2
4734116 113ANC030---B CAP**3017A** 987*A42080V17*** 28,800 11.8 14.2
4255276 113ANC030---B CAP**3017A** OVLAAB036098 28,600 11.7 14.0
4130315 113ANC030---B CAP**3017A** OVMAAB036098 28,800 11.5 13.5
4130316 113ANC030---B CAP**3017A** OVMAAB042112 28,800 12.0 14.0
3040727 113ANC030---B CAP**3017A**+TDR 29,000 11.0 13.0
3040732 113ANC030---B CAP**3614A** 315(A,J)AV036070 28,800 12.0 14.0
3040731 113ANC030---B CAP**3614A**+TDR 29,200 11.2 13.2
3040736 113ANC030---B CAP**3617A** 313*AV048070 29,200 12.0 14.0
3040735 113ANC030---B CAP**3617A** 315(A,J)AV048090 29,000 12.2 14.5
3613637 113ANC030---B CAP**3617A** 353(A,B)AV036040 29,000 12.0 14.5
3099136 113ANC030---B CAP**3617A** 353(A,B)AV036060 29,000 12.0 14.5
3099137 113ANC030---B CAP**3617A** 353(A,B)AV036080 29,000 12.0 14.5
3099138 113ANC030---B CAP**3617A** 353(A,B)AV048080 29,000 12.0 14.5
3099135 113ANC030---B CAP**3617A** 353AAV036040 29,000 12.0 14.5
3040734 113ANC030---B CAP**3617A** 355(A,C)AV042060 29,000 12.2 14.5
3808331 113ANC030---B CAP**3617A** 355BAV042060 29,000 12.2 14.5
4130318 113ANC030---B CAP**3617A** 368RAN036105 29,000 12.0 14.0
4130317 113ANC030---B CAP**3617A** 374RAN036105 28,600 12.0 14.0
4734121 113ANC030---B CAP**3617A** 925*A42060E17*** 29,000 11.8 14.2
4734122 113ANC030---B CAP**3617A** 925*A48080E17*** 29,200 11.8 14.2
4765955 113ANC030---B CAP**3617A** 986*A42060V17*** 29,000 12.0 14.5
4765969 113ANC030---B CAP**3617A** 986*A48080V17*** 29,000 12.0 14.5
4734119 113ANC030---B CAP**3617A** 987*A42060V17*** 28,600 11.8 14.2
4734120 113ANC030---B CAP**3617A** 987*A42080V17*** 28,800 11.8 14.2
4255277 113ANC030---B CAP**3617A** OVLAAB036098 28,800 11.7 14.0
4130319 113ANC030---B CAP**3617A** OVMAAB036098 28,800 11.7 14.0
4130320 113ANC030---B CAP**3617A** OVMAAB042112 29,000 12.0 14.5
3040733 113ANC030---B CAP**3617A**+TDR 29,200 11.2 13.2
3689878 113ANC030---B CAP**3619A** 359BAV036040 29,200 11.5 14.0
3689879 113ANC030---B CAP**3619A** 359BAV036060 29,200 11.5 14.0
4734131 113ANC030---B CAP**3619A** 925*A42060E17*** 29,000 11.8 14.2
4734132 113ANC030---B CAP**3619A** 925*A48080E17*** 29,200 11.8 14.2
4765957 113ANC030---B CAP**3619A** 986*A42060V17*** 29,000 12.0 14.5
4765971 113ANC030---B CAP**3619A** 986*A48080V17*** 29,000 12.0 14.5
4765983 113ANC030---B CAP**3619A** 986*A48100V21*** 29,000 12.0 14.5
See notes on page 38
113ANC

18
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
4734128 113ANC030---B CAP**3619A** 987*A42060V17*** 28,600 11.8 14.2
4734129 113ANC030---B CAP**3619A** 987*A42080V17*** 28,800 11.8 14.2
4734130 113ANC030---B CAP**3619A** 987*A60100V21*** 29,000 12.0 14.5
3689877 113ANC030---B CAP**3619A**+TDR 29,200 11.0 13.0
3040742 113ANC030---B CAP**3621A** 313*AV048090 29,400 12.2 14.5
3040741 113ANC030---B CAP**3621A** 315(A,J)AV060110 29,000 12.2 14.5
3040738 113ANC030---B CAP**3621A** 355(A,C)AV042080 28,800 12.0 14.0
3040739 113ANC030---B CAP**3621A** 355(A,C)AV060080 29,000 12.2 14.5
3040740 113ANC030---B CAP**3621A** 355(A,C)AV060100 28,800 12.0 14.0
3808334 113ANC030---B CAP**3621A** 355BAV042080 28,800 12.0 14.0
3808332 113ANC030---B CAP**3621A** 355BAV060080 29,000 12.2 14.5
3808333 113ANC030---B CAP**3621A** 355BAV060100 28,800 12.0 14.0
4734126 113ANC030---B CAP**3621A** 925*A42060E17*** 29,000 11.8 14.2
4734127 113ANC030---B CAP**3621A** 925*A48080E17*** 29,200 11.8 14.2
4765956 113ANC030---B CAP**3621A** 986*A42060V17*** 29,000 12.0 14.5
4765970 113ANC030---B CAP**3621A** 986*A48080V17*** 29,200 12.0 14.5
4765982 113ANC030---B CAP**3621A** 986*A48100V21*** 29,200 12.0 14.5
4734123 113ANC030---B CAP**3621A** 987*A42060V17*** 28,800 11.8 14.2
4734124 113ANC030---B CAP**3621A** 987*A42080V17*** 28,800 12.0 14.5
4734125 113ANC030---B CAP**3621A** 987*A60100V21*** 29,000 12.0 14.5
4130321 113ANC030---B CAP**3621A** OVLAAB048112 29,000 12.0 14.0
3040737 113ANC030---B CAP**3621A**+TDR 29,200 11.2 13.2
4773912 113ANC030---B CAP**4221A** 986*A48100V21*** 29,400 12.0 14.5
4773627 113ANC030---B CAP**4221A** 987*A60100V21*** 29,200 12.0 14.5
4773927 113ANC030---B CAP**4224A** 986*A48100V21*** 29,400 12.0 14.5
4773628 113ANC030---B CAP**4224A** 987*A60100V21*** 29,200 12.0 14.5
3689911 113ANC030---B CAP**4823A** 359BAV060080 29,800 12.0 14.5
3689910 113ANC030---B CAP**4823A**+TDR 29,600 11.0 13.0
3040771 113ANC030---B CNPH*3017A** 313*AV048070 29,000 12.0 14.0
3040772 113ANC030---B CNPH*3017A** 313*AV048090 29,000 12.0 14.0
3040766 113ANC030---B CNPH*3017A** 315(A,J)AV036070 28,800 12.0 14.0
3040767 113ANC030---B CNPH*3017A** 315(A,J)AV048090 28,800 12.0 14.0
3040768 113ANC030---B CNPH*3017A** 315(A,J)AV060110 29,000 12.0 14.0
3040769 113ANC030---B CNPH*3017A** 315(A,J)AV066135 29,000 12.2 14.5
3040770 113ANC030---B CNPH*3017A** 315(A,J)AV066155 29,000 12.2 14.5
3613638 113ANC030---B CNPH*3017A** 353(A,B)AV036040 29,000 12.0 14.5
3099148 113ANC030---B CNPH*3017A** 353(A,B)AV036060 29,000 12.0 14.5
3099149 113ANC030---B CNPH*3017A** 353(A,B)AV036080 29,000 12.0 14.5
3099150 113ANC030---B CNPH*3017A** 353(A,B)AV048080 29,000 12.0 14.0
3099147 113ANC030---B CNPH*3017A** 353AAV036040 29,000 12.0 14.5
3040761 113ANC030---B CNPH*3017A** 355(A,C)AV042060 29,000 12.0 14.0
3040762 113ANC030---B CNPH*3017A** 355(A,C)AV042080 28,800 12.0 14.0
3040763 113ANC030---B CNPH*3017A** 355(A,C)AV060080 28,800 12.0 14.0
3040764 113ANC030---B CNPH*3017A** 355(A,C)AV060100 28,600 12.0 14.0
3040765 113ANC030---B CNPH*3017A** 355(A,C)AV060120 29,000 12.2 14.5
4130375 113ANC030---B CNPH*3017A** 359BAV036040 28,600 11.5 13.5
4130376 113ANC030---B CNPH*3017A** 359BAV036060 28,800 11.5 13.5
4130377 113ANC030---B CNPH*3017A** 359BAV060080 29,000 12.0 14.0
4130378 113ANC030---B CNPH*3017A** 359BAV060100 29,000 12.0 14.0
4130340 113ANC030---B CNPH*3017A** 368RAN036105 28,800 12.0 14.0
4130339 113ANC030---B CNPH*3017A** 374RAN036105 28,400 12.0 14.0
4734158 113ANC030---B CNPH*3017A** 925*A42060E17*** 28,800 11.8 14.2
4734159 113ANC030---B CNPH*3017A** 925*A48080E17*** 29,000 11.8 14.2
4765965 113ANC030---B CNPH*3017A** 986*A42060V17*** 28,800 11.8 14.2
4765979 113ANC030---B CNPH*3017A** 986*A48080V17*** 29,000 12.0 14.5
4765987 113ANC030---B CNPH*3017A** 986*A48100V21*** 29,000 12.0 14.5
4765992 113ANC030---B CNPH*3017A** 986*A66120V24*** 29,000 12.0 14.5
4734154 113ANC030---B CNPH*3017A** 987*A42060V17*** 28,600 11.8 14.2
4734155 113ANC030---B CNPH*3017A** 987*A42080V17*** 28,800 11.8 14.2
4734156 113ANC030---B CNPH*3017A** 987*A60100V21*** 28,800 11.8 14.2
4734157 113ANC030---B CNPH*3017A** 987*A66120V24*** 28,800 12.0 14.5
4255282 113ANC030---B CNPH*3017A** OVLAAB036098 28,600 11.7 14.0
4130343 113ANC030---B CNPH*3017A** OVLAAB048112 29,000 11.7 14.0
4130341 113ANC030---B CNPH*3017A** OVMAAB036098 28,800 11.5 13.5
4130342 113ANC030---B CNPH*3017A** OVMAAB042112 28,800 12.0 14.0
3040759 113ANC030---B CNPH*3017A**+TDR 29,000 11.0 13.0
3689896 113ANC030---B CNPH*3117A** 313*AV048070 29,400 11.5 14.0
3689897 113ANC030---B CNPH*3117A** 313*AV048090 29,400 12.0 14.5
3689891 113ANC030---B CNPH*3117A** 315(A,J)AV036070 29,400 12.0 14.5
3689892 113ANC030---B CNPH*3117A** 315(A,J)AV048090 29,400 12.0 14.5
3689893 113ANC030---B CNPH*3117A** 315(A,J)AV060110 29,400 12.0 14.5
3689894 113ANC030---B CNPH*3117A** 315(A,J)AV066135 29,400 12.0 14.5
3689895 113ANC030---B CNPH*3117A** 315(A,J)AV066155 29,400 12.0 14.5
See notes on page 38
113ANC

19
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3689979 113ANC030---B CNPH*3117A** 353(A,B)AV036060 29,400 12.0 14.5
3689980 113ANC030---B CNPH*3117A** 353(A,B)AV036080 29,400 12.0 14.5
3689981 113ANC030---B CNPH*3117A** 353(A,B)AV048080 29,400 12.0 14.5
3689978 113ANC030---B CNPH*3117A** 353AAV036040 29,400 12.0 14.5
3689886 113ANC030---B CNPH*3117A** 355(A,C)AV042060 29,400 12.0 14.5
3689887 113ANC030---B CNPH*3117A** 355(A,C)AV042080 29,400 12.0 14.5
3689888 113ANC030---B CNPH*3117A** 355(A,C)AV060080 29,400 12.0 14.5
3689889 113ANC030---B CNPH*3117A** 355(A,C)AV060100 29,400 12.0 14.5
3689890 113ANC030---B CNPH*3117A** 355(A,C)AV060120 29,400 12.0 14.5
3689885 113ANC030---B CNPH*3117A** 355AAV042040 29,400 12.0 14.5
3689898 113ANC030---B CNPH*3117A** 359BAV036040 29,400 11.5 14.0
3689899 113ANC030---B CNPH*3117A** 359BAV036060 29,400 12.0 14.5
3689900 113ANC030---B CNPH*3117A** 359BAV060080 29,400 12.0 14.5
3689901 113ANC030---B CNPH*3117A** 359BAV060100 29,400 12.0 14.5
4130345 113ANC030---B CNPH*3117A** 368RAN036105 29,000 12.0 14.5
4130344 113ANC030---B CNPH*3117A** 374RAN036105 29,000 12.0 14.5
4734164 113ANC030---B CNPH*3117A** 925*A42060E17*** 29,600 12.0 14.5
4734165 113ANC030---B CNPH*3117A** 925*A48080E17*** 29,800 12.0 14.5
4765966 113ANC030---B CNPH*3117A** 986*A42060V17*** 29,600 12.0 14.5
4765980 113ANC030---B CNPH*3117A** 986*A48080V17*** 29,600 12.0 14.5
4765988 113ANC030---B CNPH*3117A** 986*A48100V21*** 29,600 12.0 14.5
4765993 113ANC030---B CNPH*3117A** 986*A66120V24*** 29,800 12.5 15.0
4734160 113ANC030---B CNPH*3117A** 987*A42060V17*** 29,200 12.0 14.5
4734161 113ANC030---B CNPH*3117A** 987*A42080V17*** 29,400 12.0 14.5
4734162 113ANC030---B CNPH*3117A** 987*A60100V21*** 29,600 12.0 14.5
4734163 113ANC030---B CNPH*3117A** 987*A66120V24*** 29,600 12.0 14.5
4255283 113ANC030---B CNPH*3117A** OVLAAB036098 29,000 12.0 14.0
4130348 113ANC030---B CNPH*3117A** OVLAAB048112 29,000 12.0 14.5
4130346 113ANC030---B CNPH*3117A** OVMAAB036098 29,000 12.0 14.0
4130347 113ANC030---B CNPH*3117A** OVMAAB042112 29,000 12.0 14.5
3689884 113ANC030---B CNPH*3117A**+TDR 29,400 11.0 13.5
3040785 113ANC030---B CNPH*3617A** 313*AV048070 29,000 12.0 14.0
3040786 113ANC030---B CNPH*3617A** 313*AV048090 29,000 12.0 14.0
3040780 113ANC030---B CNPH*3617A** 315(A,J)AV036070 28,800 12.0 14.0
3040781 113ANC030---B CNPH*3617A** 315(A,J)AV048090 28,800 12.0 14.0
3040782 113ANC030---B CNPH*3617A** 315(A,J)AV060110 29,000 12.0 14.0
3040783 113ANC030---B CNPH*3617A** 315(A,J)AV066135 29,000 12.2 14.5
3040784 113ANC030---B CNPH*3617A** 315(A,J)AV066155 29,000 12.2 14.5
3613639 113ANC030---B CNPH*3617A** 353(A,B)AV036040 29,000 12.0 14.5
3099152 113ANC030---B CNPH*3617A** 353(A,B)AV036060 29,000 12.0 14.5
3099153 113ANC030---B CNPH*3617A** 353(A,B)AV036080 29,000 12.0 14.5
3099154 113ANC030---B CNPH*3617A** 353(A,B)AV048080 29,000 12.0 14.0
3099151 113ANC030---B CNPH*3617A** 353AAV036040 29,000 12.0 14.5
3040775 113ANC030---B CNPH*3617A** 355(A,C)AV042060 29,000 12.0 14.0
3040776 113ANC030---B CNPH*3617A** 355(A,C)AV042080 28,800 12.0 14.0
3040777 113ANC030---B CNPH*3617A** 355(A,C)AV060080 28,800 12.0 14.0
3040778 113ANC030---B CNPH*3617A** 355(A,C)AV060100 28,600 12.0 14.0
3040779 113ANC030---B CNPH*3617A** 355(A,C)AV060120 29,000 12.2 14.5
4130379 113ANC030---B CNPH*3617A** 359BAV036040 28,600 11.5 13.5
4130380 113ANC030---B CNPH*3617A** 359BAV036060 28,800 11.5 13.5
4130381 113ANC030---B CNPH*3617A** 359BAV060080 29,000 12.0 14.0
4130382 113ANC030---B CNPH*3617A** 359BAV060100 29,000 12.0 14.0
4130350 113ANC030---B CNPH*3617A** 368RAN036105 28,800 12.0 14.0
4130349 113ANC030---B CNPH*3617A** 374RAN036105 28,400 12.0 14.0
4734170 113ANC030---B CNPH*3617A** 925*A42060E17*** 28,800 11.8 14.2
4734171 113ANC030---B CNPH*3617A** 925*A48080E17*** 29,000 11.8 14.2
4765967 113ANC030---B CNPH*3617A** 986*A42060V17*** 28,800 11.8 14.2
4765981 113ANC030---B CNPH*3617A** 986*A48080V17*** 29,000 12.0 14.5
4765989 113ANC030---B CNPH*3617A** 986*A48100V21*** 29,000 12.0 14.5
4765994 113ANC030---B CNPH*3617A** 986*A66120V24*** 29,000 12.0 14.5
4734166 113ANC030---B CNPH*3617A** 987*A42060V17*** 28,600 11.8 14.2
4734167 113ANC030---B CNPH*3617A** 987*A42080V17*** 28,800 11.8 14.2
4734168 113ANC030---B CNPH*3617A** 987*A60100V21*** 28,800 11.8 14.2
4734169 113ANC030---B CNPH*3617A** 987*A66120V24*** 28,800 12.0 14.5
4255284 113ANC030---B CNPH*3617A** OVLAAB036098 28,600 11.7 14.0
4130353 113ANC030---B CNPH*3617A** OVLAAB048112 29,000 11.7 14.0
4130351 113ANC030---B CNPH*3617A** OVMAAB036098 28,800 11.5 13.5
4130352 113ANC030---B CNPH*3617A** OVMAAB042112 28,800 12.0 14.0
3040773 113ANC030---B CNPH*3617A**+TDR 29,000 11.0 13.0
3040744 113ANC030---B CNPV*3014A** 315(A,J)AV036070 28,800 12.0 14.0
3040743 113ANC030---B CNPV*3014A**+TDR 29,000 11.0 13.0
3040748 113ANC030---B CNPV*3017A** 313*AV048070 29,000 12.0 14.0
3040747 113ANC030---B CNPV*3017A** 315(A,J)AV048090 28,800 12.0 14.0
See notes on page 38
113ANC

20
COMBINATION RATINGS (CONT.)
AHRI Ref. No. Model Number Indoor Model Furnace Model Capacity EER SEER
3613640 113ANC030---B CNPV*3017A** 353(A,B)AV036040 29,000 12.0 14.5
3099140 113ANC030---B CNPV*3017A** 353(A,B)AV036060 29,000 12.0 14.5
3099141 113ANC030---B CNPV*3017A** 353(A,B)AV036080 29,000 12.0 14.5
3099142 113ANC030---B CNPV*3017A** 353(A,B)AV048080 29,000 12.0 14.0
3099139 113ANC030---B CNPV*3017A** 353AAV036040 29,000 12.0 14.5
3040746 113ANC030---B CNPV*3017A** 355(A,C)AV042060 29,000 12.0 14.0
3751093 113ANC030---B CNPV*3017A** 355BAV042060 29,000 12.0 14.0
4130364 113ANC030---B CNPV*3017A** 359BAV036040 28,600 11.5 13.5
4130365 113ANC030---B CNPV*3017A** 359BAV036060 28,800 11.5 13.5
4130323 113ANC030---B CNPV*3017A** 368RAN036105 28,800 12.0 14.0
4130322 113ANC030---B CNPV*3017A** 374RAN036105 28,400 12.0 14.0
4734135 113ANC030---B CNPV*3017A** 925*A42060E17*** 28,800 11.8 14.2
4734136 113ANC030---B CNPV*3017A** 925*A48080E17*** 29,000 11.8 14.2
4765960 113ANC030---B CNPV*3017A** 986*A42060V17*** 28,800 11.8 14.2
4765974 113ANC030---B CNPV*3017A** 986*A48080V17*** 29,000 12.0 14.5
4734133 113ANC030---B CNPV*3017A** 987*A42060V17*** 28,600 11.8 14.2
4734134 113ANC030---B CNPV*3017A** 987*A42080V17*** 28,800 11.8 14.2
4255278 113ANC030---B CNPV*3017A** OVLAAB036098 28,600 11.7 14.0
4130324 113ANC030---B CNPV*3017A** OVMAAB036098 28,800 11.5 13.5
4130325 113ANC030---B CNPV*3017A** OVMAAB042112 28,800 12.0 14.0
3040745 113ANC030---B CNPV*3017A**+TDR 29,000 11.0 13.0
3689883 113ANC030---B CNPV*3117A** 313*AV048070 29,400 12.0 14.5
3689882 113ANC030---B CNPV*3117A** 315(A,J)AV048090 29,400 12.0 14.5
3689975 113ANC030---B CNPV*3117A** 353(A,B)AV036060 29,400 12.0 14.5
3689976 113ANC030---B CNPV*3117A** 353(A,B)AV036080 29,400 12.0 14.5
3689977 113ANC030---B CNPV*3117A** 353(A,B)AV048080 29,400 12.0 14.5
3689974 113ANC030---B CNPV*3117A** 353AAV036040 29,400 12.0 14.5
3689881 113ANC030---B CNPV*3117A** 355(A,C)AV042060 29,400 12.0 14.5
3690000 113ANC030---B CNPV*3117A** 355BAV042060 29,400 12.0 14.5
4130366 113ANC030---B CNPV*3117A** 359BAV036040 29,000 11.7 14.0
4130367 113ANC030---B CNPV*3117A** 359BAV036060 29,000 12.0 14.0
4130327 113ANC030---B CNPV*3117A** 368RAN036105 29,000 12.0 14.5
4130326 113ANC030---B CNPV*3117A** 374RAN036105 29,000 12.0 14.5
4734139 113ANC030---B CNPV*3117A** 925*A42060E17*** 29,600 12.0 14.5
4734140 113ANC030---B CNPV*3117A** 925*A48080E17*** 29,800 12.0 14.5
4765961 113ANC030---B CNPV*3117A** 986*A42060V17*** 29,600 12.0 14.5
4765975 113ANC030---B CNPV*3117A** 986*A48080V17*** 29,600 12.0 14.5
4734137 113ANC030---B CNPV*3117A** 987*A42060V17*** 29,200 12.0 14.5
4734138 113ANC030---B CNPV*3117A** 987*A42080V17*** 29,400 12.0 14.5
4255279 113ANC030---B CNPV*3117A** OVLAAB036098 29,000 12.0 14.0
4130328 113ANC030---B CNPV*3117A** OVMAAB036098 29,000 12.0 14.0
4130329 113ANC030---B CNPV*3117A** OVMAAB042112 29,000 12.0 14.5
3689880 113ANC030---B CNPV*3117A**+TDR 29,400 11.0 13.5
3040752 113ANC030---B CNPV*3617A** 313*AV048070 29,000 12.0 14.0
3040751 113ANC030---B CNPV*3617A** 315(A,J)AV048090 28,800 12.0 14.0
3613641 113ANC030---B CNPV*3617A** 353(A,B)AV036040 29,000 12.0 14.5
3099144 113ANC030---B CNPV*3617A** 353(A,B)AV036060 29,000 12.0 14.5
3099145 113ANC030---B CNPV*3617A** 353(A,B)AV036080 29,000 12.0 14.5
3099146 113ANC030---B CNPV*3617A** 353(A,B)AV048080 29,000 12.0 14.0
3099143 113ANC030---B CNPV*3617A** 353AAV036040 29,000 12.0 14.5
3040750 113ANC030---B CNPV*3617A** 355(A,C)AV042060 29,000 12.0 14.0
3751094 113ANC030---B CNPV*3617A** 355BAV042060 29,000 12.0 14.0
4130368 113ANC030---B CNPV*3617A** 359BAV036040 28,600 11.5 13.5
4130369 113ANC030---B CNPV*3617A** 359BAV036060 28,800 11.5 13.5
4130331 113ANC030---B CNPV*3617A** 368RAN036105 28,800 12.0 14.0
4130330 113ANC030---B CNPV*3617A** 374RAN036105 28,400 12.0 14.0
4734143 113ANC030---B CNPV*3617A** 925*A42060E17*** 28,800 11.8 14.2
4734144 113ANC030---B CNPV*3617A** 925*A48080E17*** 29,000 11.8 14.2
4765964 113ANC030---B CNPV*3617A** 986*A42060V17*** 28,800 11.8 14.2
4765978 113ANC030---B CNPV*3617A** 986*A48080V17*** 29,000 12.0 14.5
4734141 113ANC030---B CNPV*3617A** 987*A42060V17*** 28,600 11.8 14.2
4734142 113ANC030---B CNPV*3617A** 987*A42080V17*** 28,800 11.8 14.2
4255280 113ANC030---B CNPV*3617A** OVLAAB036098 28,600 11.7 14.0
4130332 113ANC030---B CNPV*3617A** OVMAAB036098 28,800 11.5 13.5
4130333 113ANC030---B CNPV*3617A** OVMAAB042112 28,800 12.0 14.0
3040749 113ANC030---B CNPV*3617A**+TDR 29,000 11.0 13.0
3040758 113ANC030---B CNPV*3621A** 313*AV048090 29,000 12.0 14.0
3040757 113ANC030---B CNPV*3621A** 315(A,J)AV060110 29,000 12.0 14.0
3040754 113ANC030---B CNPV*3621A** 355(A,C)AV042080 28,800 12.0 14.0
3040755 113ANC030---B CNPV*3621A** 355(A,C)AV060080 28,800 12.0 14.0
3040756 113ANC030---B CNPV*3621A** 355(A,C)AV060100 28,600 12.0 14.0
3751096 113ANC030---B CNPV*3621A** 355BAV042080 28,800 12.0 14.0
3751095 113ANC030---B CNPV*3621A** 355BAV060080 28,800 12.0 14.0
See notes on page 38
113ANC
