Cardio 60 User’s Guide2
EN
Cardio 60
AM
1
3
2
4
5
1Light / Power ( / )
Press and hold to turn the•
device on or o.
Press to turn on or o the•
backlight.
2Back ( )
Pr• ess to return to the
previous page or cancel an
operation.
In Training mode, press to•
pause or stop recording
log. While the recording
is paused, press again to
stop.
3OK (OK)
In Clock view, press to•
enter the menu mode.
In Menu, press to enter or•
conrm a selection.
When recording, press to•
mark the lap.
4Up (p)
In Menu, press to move•
up to scroll through
menu options. Press and
hold to fast scroll up
through menu options.
5Down (q/ )
In Menu, press to move•
down to scroll through
menu options. Press and
hold to fast scroll down
through menu options.
In meter view, press to•
switch meter screen
page.
Note: When the GPS is set to
On, press to locate the GPS page
before you start recording.

Cardio 60 User’s Guide 3
EN
Getting Started
Turn On/O
Press and hold to turn the
device on or o.
Reset
To reset the device, press and
hold all three keys ( /OK/q) at
the same time.
Initial Setup
When turning the device on for
the rst time, the setup wizard
appears on screen. Follow the
instructions to complete setup.
1. Select the display language.
2. Select the daylight saving
time.
3. Select the unit of
measurement.
4. Enter your“user prole”.
It is recommended to input
the data. Data accuracy will
highly aect your training
analysis.
5. Read and accept the Safety
Agreement.
Connect, Sync, and
Charge
1. Connect the device to a
PC using the supplied USB
charging clipper.
2. Download the Bryton Bridge
2application at brytonsport.
com and sync with the
device.
AM
Keep the device connected to
the PC to charge the battery.
Attach the USB charging clipper
onto the device and plug the
other end to a PC.
Note:
For rst time use, charge the battery•
for about 3 hours.
Please send the watch back to local•
distributor for any battery issues.
Improper battery replacement may•
cause an explosion. When replacing
a new battery, use only the original
battery or a similar type of battery
specied by the manufacturer.
Disposal of the used batteries must
be carried out in accordance to the
regulations of your local authority.
For better environmental
protection, waste batteries
should be collected
separately for recycling or
special disposal.

Cardio 60 User’s Guide4
EN
Time 2
(alternate time)
Icons
icon Description
GPS Signal Strength
No signal
Poor *
Fair **
Good **
GPS Positioning Status
No signal (not xed)
Weak signal
Strong signal
Heart Rate Sensor Active
Cadence Sensor Active
GPS Fixed
GPSGood
1
View Status Bar
Long press to display the status bar.
icon Description
Speed Sensor Active
Dual Sensor Active
1
Bike Type
Training mode
Meter mode
Log Record in Progress
Recording is paused
Power Status
Full battery
/ Half battery
Low battery
Note:
Only the active icons are displayed on the screen.•
When the• Dual sensor is activated, the sensor icon will appear at the Speed sensor
icon position.
*Please go to an open area for better reception.
** When blinking, please wait until it stops blinking.
Battery level
Bike Type
Meter mode
Heart rate sensor
indicator Cadence sensor indicator
GPS positioning
status GPS signal strength
Speed sensor indicator

Cardio 60 User’s Guide 5
EN
Clock View
AM
04:30 AM
Set Time
1. Press qto enter the menu mode.
2. Press p/qto select Settings > Watch
> Time > Set Time 1 or Set Time 2 and
press OK to enter its submenu.
3. Press p/qto select the desired setting
and press OK to conrm.
Set Alarm (Time1)
1. In Menu, press p/qto select Settings >
Watch > Alarm and press OK to enter its
submenu.
2. Press p/qto select the desired setting
and press OK to conrm.
Note: To enable the alarm, select Settings > Watch > Alarm > Switch > ON.
Current date
Time 1
(local time)
Time 2
(alternate time)
Time
Set Time 1
Set Time 2
OFF
Current day
Alarm
Set Alarm:
AM 08:00
Switch:
ON
Reminder icon
Alarm icon

Cardio 60 User’s Guide6
EN
Exercise/Training
During exercise or training, Cardio 60 allows you to measure
and record your exercise activities and displays your current
performance.
Note: Displayed information varies on exercise mode and user preference.
Ready for Simple Training
1. Press qto enter the menu mode.
2. Press p/qto select Train & Test >
Running or Cycling and press OK to
enter Training menu.
3. To set a simple workout, select To Plan >
Simple > By Time, By Distance, or
By Calorie.
4. Set the training target and press OK to
conrm.
5. Select Yes to save the workout. To perform the workout, go to
Train & Test > Running or Cycling > My Workout.
6. Enter the workout name using the
on-screen keyboard.
When nishing the name, choose
END to save the workout name.
Simple
By Time
By Distance
By Calorie
Simple
By Time
By Distance
By Calorie
Yes
Save to my workout?
03:48 PM
Exercises
Train & Test
View History
Settings
01/04

Cardio 60 User’s Guide 7
EN
Choose Other Trainings/Workouts
1. In Menu, press p/qto select Train & Test > Running or
Cycling and press OK to enter Training menu.
2. Press p/qto select My Workout, Bryton WKT, or Bryton Test
and press OK to enter its submenu.
3. Press p/qto select the desired
setting and press OK to conrm.
r
p
m
1
Note:
Only the active icons are displayed on the screen.•
When the• icon appears on the screen, press p
to skip the current Interval.
Interval Workouts
To set an interval workout, select Train & Test > Running or
Cycling > To Plan > Interval. Then set the training target and
press OK to conrm.
Customize Workouts
To set a customize workout, select Train & Test > Running or
Cycling > To Plan > Customize > Add New. Then set the training
target and press OK to conrm.
Note: If user does not enter the workout name, the system will automatically label
the le name according to the current date and time.
Start / Pause / Stop Exercising/Training
Press• OK to start recording the log.
Press• to pause the recording and
press again to stop the recording.
Note:
During exercising/training, press and hold• to
enter Shortcut menu.
When recording, press• twice to stop recording.
r
p
m
Yes
Do you want
to stop?

Cardio 60 User’s Guide8
EN
5min/km
00:06:00 run
12 km
512 kcal
5 laps
2/5
More
12/25 12:23
Delete
Yes
Backup data
to web
first. Erase?
My Lap
To start a Lap workout, select Settings > Exercise > Running,
Cycling, or Others > My Lap > Distance or Location and press
OK. Then set the training target and press OK to conrm.
Mark Lap
Start an activity rst by pressing OK. While recording, press OK to
mark lap. When using Lap, the Lap screen will be displayed while
you are doing exercise or training.
View Exercise/Training Info
To view the activities:
1. In Menu, press p/qto select View
History > View and press OK to
conrm.
2. Use p/qto view your history. Choose
More for more details.
To view the summary:
1. In Menu, press p/qto select View History > Summary >
Running, Cycling, Others, or All >and press OK to conrm.
2. Use p/qto view the activities summary.
Delete All Exercise/Training Info
1. In Menu, press p/qto select View History and press OK to
conrm.
2. Press p/qto select Delete All and
press OK to enter its submenu. A
“Backup data to web rst. Erase?”
message appears on the screen. To
delete the data, press p/qto select
Yes and press OK to conrm.

Cardio 60 User’s Guide 9
EN
Setting Reminder
1. In Menu, press p/qto select Settings > Exercise > Running,
Cycling, or Others >Reminder > select one of the available
options and press OK to enter the submenu.
Note: The available options vary depending on the selected mode:
- Running mode: O/Time/Distance/StrideRate/HR/Pace
- Cycling mode: O/Time/Distance/Speed/HR/Cadence
- Others mode: O/Time/Distance
2. Press p/qto set the desired setting and press OK to conrm.
Enable Triathlon Transition Time
1. In Menu, press p/qto select Settings
> Exercise > Triathlon and press OK to
enter the submenu.
2. Press p/qto select ON and press OK to
enable the setting.
Multisport Setup
1. In Menu, press p/qto select Settings
> Exercise > Multisport > Create New
and press OK to enter the submenu.
2. Press p/qto select the desired
sports and press OK to conrm.
3. To add more sports, press OK and
repeat Step 2.
4. After the setup is complete, select
Save to enter the transition time
submenu. Then press p/qto select
ON and press OK to enable the
setting.
Triathlon
Off
On
Multisport
View
Create New
Multisport
Running
Cycling
Others
Add
Multisport
ON
Transition
Time

Cardio 60 User’s Guide10
EN
Link Sensors
Use the Link setting to pair sensors to Cardio 60.
1. In Menu, press p/qto select Settings >
Sensors > Heart Rate, Speed, Cadence,
or Speed/CAD and press OK to enter its
submenu.
2. Press p/qto select More and press OK
to enter the selected sensor submenu.
3. When the sensor is successfully
connected, the sensor ID will be
displayed on the screen.
Verify that the sensor ID is correct.
Note: The information on the sensors ID are included in the package.
4. Press p/qto select the desired option and press OK to conrm.
Rescan• : rescan to detect the sensor.
TurnO• (*only if the device has
paired with the sensor): disable the
sensor.
Customize the Display Settings
1. In Menu, press p/qto select Settings >
Exercise > Running, or Cycling > Meter
> Meter > Meter 1, Meter 2, Meter 3,
or Meter 4 and press OK to enter its
submenu.
Note: LapandOthers only have two options
(Meter 1 / Meter 2).
2. Press p/qto select the number of data elds and press OK to
conrm.
Heart Rate
Speed
Cadence
Sensors
Heart Rate
Status: active
ID: xxxxxxxx
More
Sensor
Rescan
Turn Off
Run Meter
Meter 1
Meter 3
Off
On
Meter 2
Off
