BSD-Racing BS909T User manual

www.bsdracing.com
Product Size:
Length: 410mm
Width: 320mm
Height: 165mm
Wheelbase: 305mm
Tire size: 100 * 51mm
Ground clearance: 25mm
Gear Ratio: 12.98:1
Brushless Motor
(RC 540 KV: 3570) and
Brushless ESC
SAFETY PRECAUTIONS
This radio controlled racing car is not a toy!
This high-performance R/C model is recommended for ages14 and older.
First-time builders should seek the advice of experienced modellers
before commencing assembly.
Take enough safety precautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
4WD Drive System.
Ready Assemble Ready to Run.
High Performance RC-540 KV 3570 Brushless Electric Motor,More power!
Brushless ESC 35A-SL
7.2V Ni-Mh Rechargeable Battery,Long Running Time!
Assembled Chassis.
Colored Coil Spring Damped Suspension System.
Full Function Radio Control.
Battery in Standing Position to Save Space,Keeping the Car in Perfect Balance!
Waterproof and Dustproof Sealed Gearbox.
Fast Easy Assembly and Disassembly Receiver and Battery Cover.
Quality Differential with Four Bevel Gears.
Precise Sealed Ball Bearing for the Whole Model.
Aluminum Alloy Driveshafts.
1/10 4WD ELECTRIC-POWERED BRUSHLESS MONSTER TRUCK
BSD-RACING
Instruction Manual
Highlights:

Required equipment for operation
1.Tools required for building and maintenance:
Hobby knife
Flat and Philips screwdriver
Needle nose pliers
Lexan scissors
Cross wrench Thread locking compound Hex wrench
WARNING!
Do not use a power screw driver to install screws into nylon or plastic materials.The fast
locking may heat up the screws being installed that may break the molded parts or
strip the threads during installation.
2.Additional items needed for operation:
Check all the screws are tight before playing the vehicle!
Use thread lock on all screws that work loose.
Wire cutters
Cross wrench
CA glue&rubber cement
8pcs AA alkaline batteries
for transmitter
Precision ruler
1
IMPORTANT!
BS803-031
Lipo battery charger

Please read the instruction carefully before starting the assembly.
1.Please assemble and install this R/C vehicle without children’s reach,as it includes
small and sharp parts.
2.Do not run the vehicle on public streets or highways,as it might cause serious
accidents,personal injuries and property damage etc.
3.During racing and after operation,the motor and ESC will become HOT.
Therefore please do not touch them before cooling down.
4.Please make sure everyone is using different frequencies while racing the vehicle
in the same area.
TRANSMITTER PREPARATION
Install eight "AA" batteries into transmitter,making
sure the polarity is correct.
Insert the antenna into the top of the transmitter and
tighten the screw.
Turn the transmitter on and check the battery light.
If all LED's light up,the batteries are acceptable.If
only the red LED lights up,immediately replace the
batteries.
2

GLOSSARY OF TRANSMITTER
The transmitter antenna is for transmitting
the radio waves.
The power switch is for switching the
power on/off.
The steering wheel is for controlling the
direction of right/left.
The throttle trigger is for controlling the
throttle and brake.
The steering trim is for adjusting the
position of neutral.(right/left)
The throttle trim is for adjusting the carb
in idle position.
The LED indicator is for showing the
remaining power of the battery when
turning on the power switch.
Crystal for transmitter is for changing
the radio frequency by replacing the
crystal.
BEFORE THE OPERATING
Install the receiver antenna.
Install the transmitter antenna.
Load the battery on the transmitter.
Install the charged battery on the car.
RC OPERATING PROCEDURES
1.Please pull out the transmitter antenna and then turn on the power switch first,
before turning on the receiver.
2.Please raise the tires off the ground and check if the control is responding.
3.Hold the throttle trigger to let the car run.If it doesn't work,please adjust the
throttle servo and trim.
4.Please replace the battery,when the speed drops down.
5.When you finish the racing,please switch off the receiver first,and then the
transmitter.
6.Please make sure the battery is disconnected and remove the battery after
finishing the racing.
①
②
③
④
⑤
⑥
⑦
⑧
3

PARTS LIST
4
Item No. DescriptionItem No. Description
BS701-001 Chassis
BS701-004 Shock Absorber Unit (plastic) 2pcs
BS701-007R Brushless motor KV:3570
BS701-010 Upper deck
BS701-011 Front drive shaft
BS701-012 Rear drive shaft
BS701-015 Gear mount/Fr, screws/motor mount
BS701-016 Gear mount/Rear
BS701-020 Washer 4pcs
BS701-021 Upper deck /Front upper deck
BS701-022 Steering servo mount
BS701-025 Side guard plate L/R
BS701-026 Upper deck
BS701-027 L/R mount block/screws
BS701-028 Wire clip mount/Spring /Screws 2pcs
BS701-035 Charger for 7.2V Ni-Mh battery
BS701-036H 7.2V/3800mAh Ni-Mh battery
BS701-037 Battery base & cover/Fr
BS701-038 Battery base & cover/Rr
BS701-041 6# Pin 6pcs
BS702-047 Antenna mount
BS703-013 Flat Cross Screw(TPF3*18) 12pcs
BS903-005 Brace
BS903-007 Body Pin 6pcs
BS903-008 Upper Susp. Arm Set 2pcs
BS903-010 Suspension Arm Mount Block 2pcs
BS903-011 Upper susp. Arm Mount-Fr/Rr
BS903-012 Rim Hub W/Pin(φ2*10) 4pcs
BS903-013 Axle W/Pin 2pcs
BS903-014 Ball Bearing(φ6*φ12*4) 2pcs
BS903-015 Lf/Rt Steering Arm
BS903-016 Ball Bearing(φ10*φ15*4) 2pcs
BS903-017 Fr/Rr C-Carrier
BS903-018 Fr.Lower Susp.Arm-Lf/Rt
BS903-019 Drive shaft set 2PCS
BS903-020 Diff. Gearbox Unit
BS903-022 M4 Self-lock Nut W/Washer 4pcs
BS903-023 O-Washer 4pcs
BS903-024 Front Suspension Arm Pin-Short 4pcs
BS903-025 Suspension Arm Pin-Long 4pcs
BS903-026 Fr. Chassis
BS903-028 Lower Susp. Mount Block-Fr/Rr
BS903-030 Steering Linkage Set 2pcs
BS903-031 Servo Saver Unit
BS903-037 Steering Servo Horn and Linkage
BS903-058 Hub Rear Carrier
BS903-059 Rr.Lower Susp.Arm-Lf/Rt
BS903-061 Rear Suspension Arm Pin-Short 4pcs
BS903-065 Flat Cross Screw(TPF2.6*10) 12pcs
BS903-067 Flat Cross Screw(TPF3*10) 12pcs
BS903-068 Flat Cross Screw(TPF3*14) 12pcs
BS903-069 Flat Cross Screw(TPF3*16) 12pcs
BS903-072 B-Head Cross Screw(BT3*8) 12pcs
BS903-073 B-Head Cross Screw(BT3*12) 12pcs
BS903-074 B-Head Cross Screw(BT3*14) 12pcs
BS903-075 B-Head Cross Screw(BT3*16) 12pcs
BS903-076 B-Head Cross Screw(BT3*20) 12pcs
BS903-079 B-Head Cross Screw(BM3*10 12pcs
BS903-083 Diff. Outdrive D/Set Screw(M4*4)
BS903-086 Ball Bearing(φ5*φ10*4) 2pcs
BS903-087 Ball Bearing(φ12*φ18*4) 2pcs
BS903-088 E-Clip(φ4*0.6) 12pcs
BS903-089 Pin(φ2*9.5) 12pcs
BS903-091 Washer A(φ5.2*φ10*0.2) 12pcs
BS903-092 Washer B(φ4.2*φ8*0.2) 12pcs
BS903-093 Nylon Self-lock Nut(M4*4) 6pcs
BS903-094 Double Way Ball end(7*8) 6pcs
BS903-095 Set Screw(M4*4) 6pcs
BS903-097 Diff. Gearbox
BS903-098 Diff. Gearbox Bulkhead-Upper/Lower
BS903-104 Diff. Unit
BS903-105 Driving/Driven Gear, Diff.Gear/Bevel
Gears (alun)
BS903-106 Screw Pin (M3*9.5)

PARTS LIST
5
Optional parts/Upgrade parts
Item No. DescriptionItem No. Description
BS908-002 Tire unit(plastic) 2pcs
BS701-004A Shock Absorber Unit (alun) 2pcs
BS701-008 Motor heat sink
BS701-039 Connector wire ( NI-MH connector to LIPO battery connector)
BS903-029 Anti-roll bar fixation set 2pcs
BS903-096 (M4*8) Set Screw 6pcs
BS905-009 Rear Anti-roll bar set
BS803-028 7.4V/20C LiPo battery
BS803-031 LiPo battery charger
MP0-01 Wheel hex set
MP0-02 C hub C hub pin
MP0-03 Kunckle Arm set-Lf/Rt
MP0-04 Rear hub set
MP0-05 Shock stay mount
MP0-06 Front suspension mount
MP0-07 Rear suspension mount
MP0-11 Steering link
BS903-109 Diff.outdrive A/Pin(2*10)
BS903-110 Diff.outdrive B/Pin(2*10)
BS801-008 Fr/Rr body post
BS904-003 Bumper 2pcs
BS908-001 Tire Unit(Chromed) 2pcs
BS908-004 Bumper brace-Fr
BS908-005 Bumper brace-Rr
BS908-006 Bumper chassis-Fr
BS908-007 Bumper chassis-Rr
BS908-008 Body
BS901-048 E-Clip(φ3*0.6) 12pcs
BS901-066 M3 locknut 5pcs
BS901-067 Antenna Pipe W/Cap 3pcs
BS902-051 B-Head Cross Screw(BT3*10) 12pcs
BS909-001 Spur gear unit
BS909-002 Central drive shaft/main gear
BS909-003 Main gear-51T
BS909-004 Motor gear 13T/M3 screw
B7001 Radio Unit
B7011 Receiver
B7014 3kgs Servo
B7003-R BRUSHLESS ESC 35A-SL

B7014
BS903-097
BS903-075
BS903-106
BS903-076
BS903-098
BS903-098
BS903-094
BS903-094
BS903-092
BS903-091
BS903-089
BS903-087
BS903-087
BS903-086
BS903-079
BS903-074
BS903-074
BS903-028
BS903-072
BS903-076
BS903-072
BS903-010
BS903-071
BS903-068
BS903-068
BS903-068
BS903-068
BS903-069
BS903-069
BS903-065
BS903-061
BS903-061
BS903-059
BS903-059
BS903-058
BS903-058
BS903-037
BS903-031
BS903-011
BS903-011
BS903-026
BS903-025
BS903-025
BS903-025
BS903-025
BS903-024
BS903-024
BS903-023
BS903-023
BS903-023
BS903-023
BS903-018
BS903-018
BS903-017
BS903-017
BS903-015
BS903-015
BS903-016
BS903-016
BS903-015
BS903-014
BS903-014
BS903-014
BS903-073
BS903-028
BS903-010
I3
I3 G
G
I2
I1
I2
I1
BS903-089
BS903-089
BS903-089
BS903-104
BS701-012
BS903-019
BS903-019
BS903-093
BS903-022
BS903-022
BS903-093
BS903-093
BS903-022
BS903-022
BS903-093
BS903-008
BS903-008
BS903-008
BS903-012
BS903-012
BS903-012
BS903-012
BS701-004
BS701-004
BS701-004
BS701-004
BS903-020
BS903-030
BS903-030
BS903-020
BS903-013
BS903-013
BS903-013
BS903-013
BS701-021
BS701-027
BS701-028
BS901-067
BS903-020
BS903-073
BS903-008
BS701-014
BS903-083
BS903-083
BS701-015
BS701-016
BS909-002
BS903-089
BS903-088
BS903-066
BS903-086
BS903-086
BS903-095
BS903-095
BS903-095
BS903-095
BS902-051
BS701-021
BS702-047
BS903-079
BS903-072
BS902-051
BS902-051
BS903-075
BS903-075
BS903-072
BS903-072
BS701-001
BS903-067
BS903-067
BS903-067
BS903-067
BS903-067
BS903-067
BS903-067
BS701-025
BS903-067
BS903-097
BS903-105
BS903-105
BS701-004A
BS701-004A
BS701-004
BS701-004A
BS701-004A
BS701-004A
BS903-073
BS903-005
BS903-005
BS903-076
BS701-035
BS701-037
BS701-038
BS701-041
BS701-036
BS909-003
BS703-013
BS703-013
BS703-013
BS703-013
BS903-015
BS903-014
BS701-011
EXPLODED V IEW
BS701-022
BS701-020
BS909-001
BS701-026
BS701-010
BS701-007R
BS909-004
BS701-008
B7003-R
BS908-008
BS904-003
BS908-005
BS908-007
BS903-075
BS902-051
BS903-073
BS904-003
BS908-004
BS908-006
BS903-073
BS903-073
BS902-051
BS908-001
BS908-002
BS908-001
BS908-001
BS908-001
BS908-001
BS801-008
BS801-008
67

BS903-020 Diff.gearbox unit
BS903-022 M4 Self-lock
Nut W/Washer 4PCS
BS903-023 O-Washer 4PCS
BS903-024 Front Suspension
Arm Pin-Short 4PCS
BS903-025 Suspension Arm
Pin-Long 4PCS
φ3*56mm
φ3*37.5mm
BS903-026 Fr. Chassis
BS903-028 Lower Susp.
Mount Block-Fr/Rr
BS903-030 Steering
Linkage Set 2PCS
BS903-037 Steering Servo
Horn and Linkage
BS903-031 Servo Saver Unit
BS903-058
Hub rear carrier
BS903-059 Rr.Lower Susp.
Arm-Lf/Rt
BS903-061 Rear Suspension
Arm Pin-Short 4PCS
BS903-065 Flat Cross Screw
(TPF2.6*10) 12PCS
BS903-068 Flat Cross Screw
(TPF3*14) 12PCS
BS903-069 Flat Cross Screw
(TPF3*16) 12PCS
BS903-072 B-Head Cross Screw
(BT3*8) 12PCS
BS903-075 B-Head Cross Screw
(BT3*16) 12PCS
BS903-076 B-Head Cross Screw
(BT3*20) 12PCS
BS903-079 B-Head Cross Screw
(BM3*10) 12PCS
BS903-073 B-Head Cross Screw
(BT3*12) 12PCS
BS903-074 B-Head Cross Screw
(BT3*14) 12PCS
BS903-067 Flat Cross Screw
(TPF3*10) 12PCS
φ3*34.5mm
BS903-083 Diff. Outdrive
D/Set Screw(M4*4)
BS903-086 Ball Bearing
(φ5*φ10*4) 2PCS
BS903-087 Ball Bearing
(φ12*φ18*4) 2PCS
BS903-093 Nylon Self-lock
Nut(M4*4) 6PCS
BS903-094 Double Way Ball
end(7*8) 6PCS
BS903-088 E-Clip(φ4*0.6)
2PCS
BS903-089 Pin(φ2*9.5)
12PCS
BS903-095 Set Screw
(M4*4) 6PCS
BS903-097 Diff. Gearbox
BS903-098 Diff. Gearbox
Bulkhead-Upper/Lower
BS903-091 Washer A
(φ5.2*φ10*0.2) 12PCS
BS903-092 Washer B
(φ4.2*φ8*0.2) 12PCS
9
