BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
User Guide
BT STUDI 500
BT STUDI 500 TWIN
5464 BT Studio 500/Twin UG [3] 14/8/03 4:05 PM Page 1

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
Section
12 minutes digital recording time with a capacity for up
to 59 messages.
Access your messages from any other modern telephone.
Use Caller Display and the calls list to see who is
calling before you pick up the phone and keep track
of incoming calls.
Use the Quickdial directory to store and dial up to 10 of
most frequently used phone numbers.
As a Digitally Enhanced Cordless Telecommunications
(DECT) product, BT Studio 500 provides digital quality
call clarity.
Welcome…
to your BT Studio 500
Digital Cordless Telephone
Answering Machine
5464 BT Studio 500/Twin UG [2] 14/8/03 3:32 PM Page 2

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
Section
This User Guide provides you with all
the information you need to get the
most from your phone.
Additional instructions are included
for the BT Studio 500 Twin.
Before you make your first call you will
need to set up your phone. Follow the
simple instructions in ‘Getting Started’,
on the next few pages.
Need help?
If you have any problems setting up or using your
BT Studio 500 please contact the Helpline on
0870 605 8047.
Alternatively, you may find the answer in ‘Help’
at the back of this guide.
Got everything?
BT Studio 500 handset
BT Studio 500 base
2 x AAA NiMH
rechargeable batteries
Mains power adaptor
Telephone line cord
If you have purchased
the BT Studio 500
Twin you will also
have:
BT Studio 500
additional handset
BT Studio 500 charger
2 x AAA NiMH
rechargeable batteries
Mains power adaptor
5464 BT Studio 500/Twin UG [2] 14/8/03 3:32 PM Page 3

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
Getting started
Location . . . . . . . . . . . . . . . . . . . . . .6
Setting up the base . . . . . . . . . . . . . .6
Setting up the charger . . . . . . . . . . . .8
Getting to know your phone
Handset buttons . . . . . . . . . . . . . . . .10
Handset display icons . . . . . . . . . . . . .11
Base buttons . . . . . . . . . . . . . . . . . . .12
Base LEDs . . . . . . . . . . . . . . . . . . . . .13
Using the phone
Make an external call . . . . . . . . . . . . .14
Preparatory dialling . . . . . . . . . . . . . .14
End a call . . . . . . . . . . . . . . . . . . . . . .14
Receiving calls . . . . . . . . . . . . . . . . . .14
Earpiece volume . . . . . . . . . . . . . . . .15
Handset ringer volume . . . . . . . . . . . .15
Secrecy . . . . . . . . . . . . . . . . . . . . . . .15
Last number redial . . . . . . . . . . . . . . .16
Paging . . . . . . . . . . . . . . . . . . . . . . .16
Quickdial
Store a number in the Quickdial
memory . . . . . . . . . . . . . . . . . . . . . .17
Dial a Quickdial number . . . . . . . . . . .17
Delete a Quickdial number . . . . . . . . .17
Caller Display and the calls list
View, dial and delete entries in
the calls list . . . . . . . . . . . . . . . . . . . .18
Exit the calls list . . . . . . . . . . . . . . . . .18
B Studio 500 win additional handset
Making internal calls . . . . . . . . . . . . . .19
Receiving internal calls . . . . . . . . . . . .19
Transferring calls . . . . . . . . . . . . . . . .20
Using the answering machine
Switching the answering machine
on/off . . . . . . . . . . . . . . . . . . . . . . . .21
Set date and time . . . . . . . . . . . . . . .21
Play all messages . . . . . . . . . . . . . . . .22
Play new messages only . . . . . . . . . . .22
Select and play outgoing message . . .24
Record your own outgoing message(s) 25
Delete your outgoing message(s) . . . .25
Adjust answer delay . . . . . . . . . . . . . .26
Record a memo . . . . . . . . . . . . . . . . .26
Memory full during a call . . . . . . . . . .27
Call screening . . . . . . . . . . . . . . . . . .28
Remote access
Switch on your answering machine from
another phone . . . . . . . . . . . . . . . . . .29
4In this guide
5464 BT Studio 500/Twin UG [2] 14/8/03 3:32 PM Page 4

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
5In this guide
Change the securit PIN . . . . . . . . . . .29
Operating our answering machine
from another phone . . . . . . . . . . . . . .30
Outgoing message menu . . . . . . . . . .32
Switchboard use
Switchboard compatibilit . . . . . . . . . .33
Switchboard external line access code . .33
Recall . . . . . . . . . . . . . . . . . . . . . . . .34
Help . . . . . . . . . . . . . . . . . . . . . . . . .35
General information
Safet . . . . . . . . . . . . . . . . . . . . . . . .38
Cleaning . . . . . . . . . . . . . . . . . . . . . .39
How man telephones can ou have? . .40
Guarantee . . . . . . . . . . . . . . . . . . . . .41
Returning our phone . . . . . . . . . . . . .42
R&TTE . . . . . . . . . . . . . . . . . . . . . . .43
Declaration of Conformance . . . . . . . .43
5464 BT Studio 500/Twin UG [3] 15/8/03 9:48 AM Page 5

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
Getting started6
WARNING
Do not place your BT Studio 500 in
the bathroom or other humid areas.
Handset range
The handset reception range from
the base is up to 300m outdoors
and up to 50m indoors, in ideal
conditions.
Signal strength
The icon on your handset
indicates when you are in range.
When it flashes, you are out of
range.
IMPOR AN
The base station must be plugged
into the mains power socket at all
times.
Do not connect the telephone line
until the handset is fully charged.
Which socket?
Power socket
Telephone line socket
A
If you have purchased the B Studio 500 win please
follow instructions Aand B.
Location
You need to place your BT Studio 500 close enough to
a mains power and telephone socket so that the cables
will reach.
The strength of the handset signal depends on where you
site the base. Putting it as high as possible can help to
provide the best signal. Make sure it is at least 1 metre
away from other electrical appliances to avoid interference.
Setting up the ase
1. Plug the power adaptor and telephone cables into the
back of the base.
Power adaptor cableelephone line cable
5464 BT Studio 500/Twin UG [2] 14/8/03 3:32 PM Page 6

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
2. Plug the power adaptor into the mains wall socket and
switch the power on. The green Power light on the base
comes on.
3. Install the 2 x AAA rechargeable batteries supplied.
Then slide the battery compartment cover into place.
4. Charge the handset for at least 16 hours by placing the
handset on the base. The red Charging light at the base
comes on.
nce the batteries are partly charged the icon will
flash briefly in the handset display and the icon will
appear.
nce the handset links with the base, the icon stops
flashing.
7Getting started
alk/Standby time
Under ideal conditions, the
handset batteries should give
about 14 hours talk time or 350
hours standby on a single charge.
(The base must still remain
plugged in to the mains and
switched on at all times.)
Note that new batteries do not
reach full capacity until they have
been in normal use for several days.
Battery symbols
– Battery charged
– Battery low
Battery low warning
If the battery charge becomes low
during a call you will hear a
warning beep once every minute.
If the battery runs out you will be
cut off.
You will need to recharge the
handset before using it.
During charging, the icon
will be displayed.
See ‘Battery performance’ on the
following page.
5464 BT Studio 500/Twin UG [2] 14/8/03 3:32 PM Page 7

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
5. After the handset is fully charged, the icon will
disappear from the display.
You can now plug the telephone line cord into the
telephone wall socket.
Your BT Studio 500 is ready for use.
B Studio 500 win owners only
Location
You need to place your BT Studio 500 charger close
enough to a mains power socket so that the cable will
reach.
Setting up the charger
1. Plug the power adaptor cable into the underside of
the charger.
2. Plug the power adaptor into the mains wall socket and
switch the power on.
3. Install the 2 x AAA rechargeable batteries supplied into
the second handset.
8 Getting started
Battery performance
To keep your batteries in the best
condition, leave the handset off
the base for a few hours at a time
Running the batteries right down
at least once a week will help them
last as long as possible.
The charge capacity of
rechargeable batteries will reduce
with time as they wear out, giving
the handset less talk/standby time.
Eventually they will need to be
replaced. New batteries are
available from the BT Studio 500
Helpline on 0870 605 8047.
After charging your handset for the
first time, subsequent charging time
is about 6– 8 hours a day. Batteries
and handset may become warm
during charging.This is normal.
B
5464 BT Studio 500/Twin UG [2] 14/8/03 3:32 PM Page 8

4. Place the handset in the charger and charge the handset
for at least 16 hours. The red Charging light on the
charger comes on.
nce the batteries are partly charged, the icon will
flash in the handset display and the icon will appear.
nce the handset registers with the base, the icon
stops flashing.
Your BT Studio 500 Twin is ready for use.
9Getting started
B Studio 500 additional handset
Your BT Studio 500 handsets
are the same, so instructions
throughout this guide apply
to both.
Handset numbers
nce registered with the base,
each handset will display its
handset number, and
respectively.
BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
5464 BT Studio 500/Twin UG [2] 14/8/03 3:32 PM Page 9

BT Studio 500/Studio 500 Twin – 3rd Edition – 14th August ’03 – 5464
10 Getting to know your phone
Quickdial
Use to store and dial up to 10 phone
numbers, page 17.
Calls list/Scroll
pens the Calls list and lets you scroll
through the entries, page 18.
Del/Secrecy
Delete characters, page 17.
Delete entries in the calls list, page 18.
During a call, press to stop your
caller hearing you, page 15.
R (Recall)/Calls list exit
Exits the Calls list, page 18.
Used when connected to a
switchboard/PBX and some
BT Calling Features, page 34.
Handset uttons
In-use light
Comes on when you make/receive
a call.
Redial/P
Redials the last number, page 16.
Enters a Pause when storing numbers,
page 17.
Vol
Adjusts the earpiece volume during
a call, page 15.
Adjusts the handset ringer volume,
page 15.
alk
Press to make, receive and end calls,
page 14.
Int
Use to make an internal call, page 19.
r to transfer a call to an additional
BT Studio 500 handset, page 20.
