1 Applicable model
1.1 Connection diagram overview
1.2 Programming guide
1.2.1 Access to Web Management interface
1. The programming application can be launched from a web browser. To run
the application type in address bar the IP Door phone IP address.
BT IP Access Control Unit
with inbuilt camera
BT IP Access Control Unit with
inbuilt camera and display
Screw rubber gasket and
metal back plate to the wall
using the template supplied

BT SIP Access Control System Quick Install Guide
Issued by: North Supply Ltd
Issue no: BTDE0202BB02
Date: July 2019
Page 4 of 6
In strictest confidence
2. The default IP Door Phone IP address is 10.10.10.6 and it is configured as
‘Static’ IP address.
3. The default web-programming Administrator credentials are:
3.1. User name: ‘admin’ – For Administrator management level and ‘user’ –
for User management level.
3.2. Default Password: 1234 for both management levels.
PCB elements
Description
1 ( SW2)
Factory Default Settings switch:
‘Normal’ – Door Phone normal working position ‘Default’ – Set to
default procedure mode
2
Hardware Reset ( Cold Reset Switch)
3 ( NO/NC Jumper)
Relay 1 and Relay 2 Normally Open and Normally Close status jumper.
Closed Central Pin (2) + ’NO’- (1) pin means the ‘Normally open’ mode.
Closed Central Pin (2) + ’NC’ - (3) pin means the ‘Normally Close’ mode
Note: Relay 2 works in Normally Open (NO) mode only
4
Microphone Connector
5
Speaker Connector
6-Ethernet
POE+/LAN connection
5VD (5V DC)
External power supply 5VDC 2A input (if no POE+ applied).
Draw attention on connection polarity: +5V and GND marked on PCB
(Fiure 6-2)
The External Power Supply is not included in standard IP394X package
SEN 1/2 (Sensor 1/2*)
Door status detector.
Also can be used as external Switch button connection (Chapter 8.3).
Note:
The External Switch button can be used for manual door opening
usually labelled N/O and C or CMN and Make on the terminals
REL 1/2 (Relay 1/2)
Support 30VDC 2A
Internal relays Normally Open and Normally Close status depends on
JP1 jumper position.
Audio Out*
Reserved for future release
1.3 Help and assistance
Prior to calling, please check the following:
1. You know the extension number the door unit is connect to on the PBX.
2. You can dial the door unit and generate DTMF tones from the PBX.
3. The unit is powered by POE+ or the supplied power supply.
4. Check you are using the correct door release type relative to the power
supply i.e. DC release as standard.
5. To view the full install guide please refer to the CD included with the unit.

BT SIP Access Control System Quick Install Guide
Issued by: North Supply Ltd
Issue no: BTDE0202BB02
Date: July 2019
Page 5 of 6
In strictest confidence
6. For help and assistance please dial:0116 257 8147 opt 2
1.4 Attention
"For safety reasons and to avoid electrical damage to the unit any Power source like an
external power supply or POE must be disconnected during the installation process. The
External Power Supply is not included in standard IP394X package"
Use ONLY 5V DC PSU
1. Connect the door lock(s), press to exit button and the sup plied protection
diode or sensor(s), wires to the provided two-wire terminal connectors.
2. Insert wired terminal connectors into the mating sockets on PCB (Figure 6-
2).
3. Connect POE/LAN cable to RJ-45 socket.
4. Connect door lock to ‘REL 1’ (Relay 1) and/or ‘REL 2’ (Relay 2) via the lock
supply.
5. If an external press to exit button is used (See also chapter 7.6 in user
manual: Web GUI Door Functions -> Sensor), connect the external switch
button wires to ‘SEN 1’ (Sensor 1) and/or ‘SEN 2’ (Sensor 2 )
Attention: NO/NC jumper position.
Jumper PIN (2) + PIN (1) when when selected means the relays are set to “open contact“
volt free power to unlock.
Jumper PIN (2) + PIN (3) means the relays are set to “closed contact“ volt free for power
to lock.
