Buchi Syncore User manual

Operation Manual
Platform
Sy ncore®
093008 en

Syncore Platform
3
Table of contents
Table of contents
en, Version E (43 pages) Order code
Syncore Instructions 093008
1 Scope of delivery 2
2 Safety 6
3 Function 10
3.1 The single platform 10
3.2 Syncore Analyst R-4, R-6 and R-12 11
3.3 Individual components 11
3.4 Syncore Polyvap R-4 to R-96 12
4 Putting into operation 14
5 Operation 17
5.1 The single platform 17
5.2 Safety instructions 17
5.3 Temperature and RPM 19
5.4 Programm mode: Temperature / Time steps 20
5.5 Further control parameters 22
5.6 Pre-set safety settings 23
5.7 Overview of switches 24
5.8 Signal outlets 25
5.9 After running of the programmable valve 26
5.10 RS-232 interface 26
5.11 Signal inlets 27
5.12 Adjusting the eccentricity 28
5.13 Unbalance compensation 30
5.14 Troubleshooting: the single platform 33
6 Maintenance 34
6.1 Cleaning 34
6.2 Routine inspection of the equipment (monthly) 34
6.3 Routine inspection of the equipment (annually) 35
6.4 Calibration 35
6.5 Error messages: Calibration 37
6.6 Replacement of the fuses 37
6.7 Error Messages: Hardware 38
6.8 Customer service 38
7 Taking out of Operation 39
8 Replacement Parts 40
8.1 Single platform 40
9 Appendix 41
9.1 Technical data 41
9.2 Materials used 41
9.3 FCC requirements (for USA and Canada) 42
9.4 Declaration of conformity 43
Read this Operation Manual through care-
fully before starting to use the Syncore
Product Line.
Always keep these instructions ready at
hand close to the equipment so that they
may be consulted quickly at all times. Chap-
ter 2 provides important safety instructions
that must be followed to ensure safe ope-
ration of the unit.
We reserve the right to make technical changes without
prior notice. No portions of this Operation Manual may be
reproduced in any form (including with the use of electronic
or optical systems), duplicated, or distributed without written
permission from BÜCHI Labortechnik AG. All rights reserved.
Copyright © BÜCHI Labortechnik AG 2013

Syncore Platform
4
1 Scope of delivery
Figure 1: BUCHI Syncore Analyst R-6
Voltage
1 100V 50/60Hz
2 120V 50/60Hz
3 230V 50/60Hz
Condenser
0 None
S Type S, Standard
C Type C, Cold trap
Round receiving flask,
KS 24/20,PLG
0 None
2 2000ml total volume
Rack type (incl. vacuum
cover)
4 Crystal Rack R-4 Analyst
5 Crystal Rack R-6 Analyst
6 Rack R-12 Analy
Residual volume of glass
tubes
4 1ml
5 0.3ml
6 3ml
Glass tube graduation
Y Yes
N No
1 Power system cable PNE, 1.5 m
Type CH 10010
Type Schuko 10016
Type GB 17835
Type USA 10020
Type AUS 17836
1 Scope of delivery
1.1 Configuration Syncore Analyst
1A 0
in addition:
2 Cooling hoses, 1m 04133
1 Power system cable PNE, 1.5m
Type CH 10010
Type Schuko 10016
Type GB 17835
Type USA 10020
Type AUS 17836
1 Operation Manual:
German 93007
English 93008
French 93009
Italian 93010
Spanish 93011

Syncore Platform
5
1 Scope of delivery
Figure 2: BUCHI Syncore Polyvap R-24
1.2 Configuration Syncore Polyvap
1 Power system cable PNE, 1.5 m
Type CH 10010
Type Schuko 10016
Type GB 17835
Type USA 10020
Type AUS 17836
1 Operation Manual:
German 93007
English 93008
French 93009
Italian 93010
Spanish 93011
1P 000
Voltage
1 100V 50/60Hz
2 120V 50/60Hz
3 230V 50/60Hz
Condenser
0 None
S Type S, Standard
C Type C, Cold trap
Round receiving flask,
KS 24/20,PLG
0 None
1 1000ml total volume
2 2000ml total volum
Rack type (incl. vacuum cover)
0 None
1 Crystal Rack R-4
2 Crystal Rack R-6
3 Rack R-12
4 Standard Rack R-24
5 Falcon Rack R-24
6 Rack R-96
in addition:

Syncore Platform
6
1 Scope of delivery
Figure 3: Syncore single platform
1.3 Individual components
Single Platform
Components Order code
Syncore Single Platform 230 V 50/60 Hz 38429
Syncore Single Platform 120 V 50/60 Hz 38430
Syncore Single Platform 100 V 50/60 Hz 38431
Scope of delivery
1 Syncore Single Platform, complete Including:
1 Adjustment wrench for adjusting eccen- 38477
tricity and unbalance compensation
1 Power system cable PNE, 1.5 m
Type CH 10010
Type Schuko 10016
Type GB 17835
Type USA 10020
Type AUS 17836
1 Operation Manual:
German 93007
English 93008
French 93009
Italian 93010
Spanish 93011
Table 4: Individual components single platform

Syncore Platform
7
2 Safety
2 Safety
This unit and all its components have been built in accor-
dance with the state of the art and recognized safety rules.
Nevertheless, certain risks and dangers may be involved
when working with the unit or its individual components:
• Whenevertheunitisnotbeingusedinaccordancewith
its intended purpose, or
• Wheneverthestaffoperatingtheunithavenotlacksuf-
ficient training and know-how.
2.1 Symbols
Stop
Information on hazards that can result in severe material da-
mage or serious to fatal injuries.
Warning
Information on hazards that can result in injury to one’s health
or material damage.
Caution
Information pointing out technical requirements. A failure to
follow these instructions can cause malfunctions, unecono-
mical operation, and production losses.
2.2 Requirements for the user
This unit and all accessories for the Syncore line of equipment
may be used only by laboratory staff and other individuals
who, based on their education, training, or professional
experience, are fully aware of the risks involved in their use.
Staff lacking this training or staff currently being trained need
careful instruction. These operating instructions are valid as
a basic requirement.

Syncore Platform
8
2 Safety
2.3 Authorized use
This unit has been designed and built as a laboratory
instrument. The authorized application for the Syncore single
platform inconjunction with accessories from the Syncore
product line is as follows:
Syncore Polyvap/Syncore single platform
with accessories:
• Parallelevaporation of solvents invarious formats and
containers across a range of temperatures from room
temperature up to + 150 °C and within a range of pres-
sures from 1 mbar up to ambient pressure.
Syncore Analyst:
• Parallelconcentrationofsolventsfrom6differentsamples
across a range of temperatures from room temperatures
up to + 100 ° (or bypassing pre-set safety settings, up to
150 °C), within a range of pressures from 1 mbar up to
ambient pressure.
Applications for the Syncore line of equipment
include:
• Parallelorganic-inorganicchemicalsynthesisintheliqui-
dor in the solid phase.
• Parallelmaterialinvestigations,digestions,preparationof
samples of from 4 to 96 samples, with sample volumes
ranging from 500 down to 1 ml.
• Parallelevaporationoffrom4to96sampleswithsample
volumes from 1 ml up to 500 ml after chemical synthesis,
after chromatography, after extraction, etc.
• Parallelconcentrationinchemicalanalysis,guaranteeing
a residual volume after the evaporation.
2.4 Unauthorized use
Any use other than those indicated above and any application
that does not correspond to the Technical Data is considered
to be improper use.
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment
may be impaired.
The operator himself bears sole responsibility for any risks
arising from such use.
The following in particular are explicitly forbidden:
• The processing of samples that can explode or ignite
explosively as the result of impact, friction, heat, or spar-
king (e.g., explosives, etc.).
• Thecarryingoutofchemicalreactionsthatcanproduce
substances that can explode or ignite explosively as the
resultof impact, friction, heat, or sparking (e.g., explosives,
etc.);
• Use of the unit in rooms that require explosion-proof
equipment;

Syncore Platform
9
2 Safety
Symbol Meaning Location
Elemento caliente,
superficie caliente
General warning
• Useofthesingleplatformwithsampleholdersorsample
containers that have not been developed for use on the
Syncore single platform.
• Workingataboveatmosphericpressure
2.5 Basic hazards
The basic hazards arise from:
• Chemicals that are toxic or cause allergic reactions, or
can, in a chemical reaction, produce compounds that are
toxic or cause allergic reactions;
• Solventmaterialswhichcanformperoxides
• Veryhotorverycoldpartsmadeofplasticsandmetals
(Burn injuries)
• Kinkedhosesorthedissolvingofhosematerialsusedto
introduce liquids, compressed gases under pressure
• Movingpartswhichrotateathighspeedaboutanaxisand
which if used in an improper way can lead to injury or the
destruction of laboratory equipment
• Glassvesselsundervacuumwhichcanimplode
• Electriccableswhichcanbedamagedorincorrectlycon-
nected
• Combustiblegasesorsolventvaporsintheareaimmedi-
ately adjacent to the Syncore.
2.6 Warning labels on housing
The following warning sticker(s) can be found on the housing
or assemblies of the Syncore:

Syncore Platform
10
2 Safety
2.7 Safety procedures
The regional and local laws and regulations must be obser-
ved. It is necessary to wear personal protective equipment
such as protective goggles, gloves and a laboratory
coat.
It is only permissible to assemble and dismantle certain parts
of the Syncore when such action is necessary to carry out
the functional requirements.
This activity can be performed manually or by use of the tool
which is supplied. Except for authorized maintenance per-
sonnel, the removal of protective devices and cover plates/
shrouding with the aid of a conventional tool is forbidden.
The owner of the company is responsible for the instruction
of his personnel. To assist in this context, it is possible to
order these Operating Instructions in other languages. At all
times, these Operating Instructions must be available - as a
component part of Syncore - to the operating personnel at
the point where the equipment is employed.
The owner of the company will inform the Manufacturer
immediately regarding all events having a bearing on safety
which take place while the equipment is in use.
2.8 Modifications
No modifications may be made on this unit or on spare and
accessory parts, nor is use of spare or accessory parts other
than those indicated in this Operation Manual permissible,

Syncore Platform
11
3 Function
3 Function
Syncore comprises a series of compact, highly versatile
instruments suitable for all aspects of parallel synthesis and
evaporation.
There are three pre-defined assemblies:
• SyncoreReactor
• SyncorePolyvap
• SyncoreAnalyst
The instruments are tailored to the customer’s needs in
various applications. The standard configurations can be
modified to meet individual requirements by using additional
accessories.
3.1 The single platform
The Syncore single platform is equipped with a heater and
a shaking mechanism.
• Heatingisaccomplishedacrossaheatingfoilonabase
plate .
• Temperaturesrangefrom-20°Cto150°C.
The quiet an vibration free staking movement is orbital and
horizontal, with a maximum speed of 600 rpm and an ea-
sily adjustable exxenter of 0 to 5 mm. This ensures that all
samples may be thoroughly agitated vy vortex action within
the tubes, eliminating potential contamination souerces such
as stirrer paddles or magnetic followers.
A shield protects the operator from contact with hot, cold,
or moving parts.
The unit is controlled either manually or via a program. Up
to 9 individual temperature/time steps may be programmed,
each lasting for a maximum of 9 hours and 59 minutes. Pre-
set safety limits may also be selected, 100 or 150°C for the
temperature and 300 or 600 rpm for rotational speed.
Thanks to the two valve outlets, valves may be operated eit-
her under temperature control or controlled by the program.
With programmed control, for example, it is possible to
ensure that the cooling water will not be switched off before
one hour after completion of the program.
The single platform has an analog TTL signal socket that
can process an external start or stop signal. This means that
the unit can be operated via an external control unit, e.g. for
integration into a robot station.
The Syncore single platform has a pre-defined stopping
position. After a vortex movement of the base plate, the
unit automatically re-finds its pre-defined stopping position,
thereby enabling integration of the single platform into fully
Figure 4: Syncore single platform (front view)
Figure 5: Syncore single platform (back view)


 

Syncore Platform
12


3.2 Syncore Analyst R-4, R-6 and R-12
The Syncore Analyst is a prallel work-up station designed
go give high productivity. It comprises a basic unit , a rack
with residual volume cooling for samples with appropriate
glass vessels having residual volume appendices, a vacu-
um connection and a condenser unit with appropriate
receiving flasks .
This parallel evaporator can concentrate up to 12 different
120 ml samples simultaneously down to a pre-defined residu-
al volume from 0.3 to 2.5 ml per sample. The residual volume
is collected in an appendix at the bottom of the sample flask
and is kept cool by circulation water or a suitable coolant
around it until it is removed by the operator. The temperature
of the cooling medium may range between 0°C and room
temperature.
Range of temperatures: Room temperature to 100°C
Maximum sample volume: 120, 250 resp. 500 ml.
Due to its innovative variable throw orbital mechanism, a
strong vortex in the sample is produced (max. speed 600
rpm), thereby preventing evaporation retardation. The ope-
rator can adjust the eccentricity of this vortex movement to
suit the working volume at hand.
The vacuum cover is designed so that each sample has its
own vacuum connection and this combined with baffle, eli-
minates the possibility of cross-contamination. The vacuum
cover is also heated, making it possible to evaporate even
high boiling point solvents to dryness quickly and safely. The
cover is constructed from inert materials such as glass, PFA-
coated aluminium and PTFE-coated sealing discs to ensure
that contaminants cannot leach into the sample.
This makes the Syncore Analyst ideal for applications with
aggressive chemicals, analysis of residues from soils, food-
stuffs, or similar materials, and for thermosensitive products.
3.3 Individual components
The Syncore product line is thoroughly modular. Every acces-
sory is usable at any time with a Syncore single platform and
with all standard configurations.
The different accessories are described in the operating
instruction „Accessories“.
Figure 6: Syncore Analyst R-4





3 Function







Syncore Platform
13
3 Function
3.4 Syncore Polyvap R-4 to R-96
The Syncore Polyvap comprises a single platform , a rack
for samples and fitting glasses , a vacuum cover ,
and a condenser unit with a suitable receiving flask .
This configuration can be used to condense different samp-
les simultaneously down to dryness.
Range of temperatures: Room temperature to 150°C
Maximum sample volume: From 10 to 500 ml.
The samples are shaken in a horizontal vortex movement at
up to 300 rpm. The operator can adjust the eccentricity of
this vortex movement to suit the working volume at hand.
A simple mechanism permits manual adjustment of a com-
pensating counterweight, thereby ensuring smooth operation
even ath high rotational speeds.
The vacuum cover is designed so that each sample has its
own vacuum connection and this combined with baffle, eli-
minates the possibility of cross-contamination. The vacuum
cover is also independantly heated (up to 70°C), making it
possible to evaporate even high boiling point solvents to
dryness quickly and safely.
The Syncore Polyvap configuration can be used in the most
varied kinds of applications, e.g., for simultaneous evapo-
ration
of samples after synthesis, after chromatography, extraction
(liquid-liquid, solid-liquid), analysis, etc.
For the sake of compatibility, all Syncore racks are already
programmed into the BUCHI Fraction Collector C-660 of
the Sepacore Line.
Other formats and volumes can be processed by using other
optional sample holders (racks) and vacuum covers.
Figure 7: Syncore Polyvap R-24







Syncore Platform
14
4 Putting into Operation
4.1 Complete and intact delivery
After unpacking the delivery, inspect for any signs of damage.
It is important that any damage that may have occurred in
transit is recognized at the time of unpacking. If any damage is
detected, it is necessary to determine the facts of the situation
immediately (to be reported to the postal authorities, railway
company or transport agent). Please retain the original packing
material for any possible transport operation. at a later date.
4.2 Working location
The Syncore Basic Unit weighs 30 kg and should never be
moved or lifted by a single person. It should be placed in a
horizontal position upon a clean, level and stable base struc-
ture (Check with a spirit level). For safety’s sake, a distance
of at least 30 cm must be maintained from the wall or from
other objects at the back and at the sides of the unit, and a
distance of at least 50 cm above the unit.
No containers, chemicals, or other equipment are permitted to
stand behind, next to, or above the unit, or on shelves connec-
ted to the laboratory table. The single platform may be operated
only at ambient temperatures between 5°C and 40° C.
The single platform must be operated from the front. There
must be open space available for placement of racks or other
accessory equipment. Take care to install the unit ergonomi-
cally and so that it will be comfortable for your back.
To cut the power in case of an emergency by unplugging, the
instrument or any other item must not block the mains plug!
In this case, the plug must be able to be pulled out instantly.
4.3 Electrical connections
Compare the voltage indicated on the unit nameplate with
the voltage indicated on the delivery notice and the local
power system voltage. Do not connect the unit to the power
system unless these voltages all agree.
The power system cables and plug sockets must be groun-
ded. If they are not, do not connect the unit to the power
system. Connect the unit to the power system and switch
the main breaker switch ON. All displays are activated and
the unit runs through a self-test that takes about 5 seconds.
Displays after switching on:
• Allilluminatedelementsremainlitfor1second.
• Thecurrentsoftwareversionisdisplayedfor1second.
• Thelasttemperaturesettingand60RPMaredisplayed
for 3 seconds.
After the self-test, a dot appears in the program display and
4 Putting into operation
Figure 8: Displays on the control panel after starting the unit.

Syncore Platform
15
4.4 Function test for drive and speed indica-
tor
There should be no objects of any kind resting upon the
base plate or between the base-plate and the housing of
the equipment.
• Setaspeedof60RPMbyturningthespeedcontroller
to the right.
• Thedisplayunitshould indicate “60” and the base
plate of the basic unit should move slowly without any
pronounced vibration.
• Followingcompletionofthefunctiontest,resetthespeed
to 0 RPM
4.5 Function test heating and time
There should be no objects of any kind resting upon the
base plate or between the base-plate and the housing of
the equipment.
• Press once on the „UP“ button on the temperature
control unit. The display shifts from the current tempe-
rature to the set-point temperature.
• Pressthe„UP“buttonrepeatedlytosetanewset-point
for temperature of +40°C.
• After3seconds,theunittakesoverthisnewset-point.
• Pressthe„START“buttonrepeatedly.Thebaseplateis
heated to the set-point temperature. A dot in the tempe-
rature display  shows that the heater has been turned
ON.
• Thetimedisplay shows how much time has passed
since starting.
If not, contact a local BUCHI service agent.
• TurntheheaterOFFafterthefunctionaltestbypressing
once on the “STOP” button.
• Tocheckthetemperatureoftheheatingplate,insertan
external thermometer (Ø 4 mm) into the reference socket.
4 Putting into Operation
Figure 9: Controlling the basic functions from the control panel





Syncore Platform
16
4 Putting into Operation
Figure 10: Attachment of the condenser unit
4.6 Attachment of the condenser unit S and C
• Screwtheright-orleft-handsupportrod (depending
on the work-place or the working procedure) into the hole
provided in the rear feet.
• Securethecoolerbracket(shackle)to the support rod
using the cross sleeve .
• Securethecoolertotheshackle.
• Attachthetransitionpieceto the cooler with the clamp
.
• Alsosecurethereceivingvessel to the transition piece
with the clamp .
• Fastenthecoldwatersupplytotheconnectionunits
and  using GL14 screwed fittings.
• Jointheconnectionelement to the valve unit with a
GL 14 sealing cap .
It is strongly recommend to secure all hose connections by
hose clips.
Figure 11: Cooler connections
 










Syncore Platform
17
5 Operation
5.1 The single Platform
Ensure that the equipment is properly put into operation
according to the recommendations outlined in Chapter 4.
The use of racks, vacuum connections, and further accesso-
ries enable the device to be used for:
• Cooling
• Heating
• Shaking
• Evaporationand
•Concentration
The handling of the device is kept simple. Nevertheless, note
all pertinent safety instructions, particularly the general safety
rules in Chapter 2 of this operation manual, and the indivi-
dual safety instructions provided for the various individual
components (see operating instructions - replacement parts).
5.2 Safety instructions
Chemicals and solvents
The device must be clean before being operated. Residues
of chemicals are to be removed following the general rules
for working with chemicals.
The device must not be put into operation if solvents could
penetrate into it. If that could happen, place the unit in a
well-ventilated fume cupboard and wait until the fumes have
been drawn off completely before operating it.
Whenever the device is being operated with chemicals that
are aggressive, toxic, or likely to cause allergic reactions, it
should always be placed in an fume cupboard.
Indicators, hoses and cables
The Syncore single platform must not be operated if indi-
vidual indicators are not functioning properly and data on
parameters such as time, temperature, or speed are missing.
Live electrical cables and the hoses for the heating and
cooling media must not come into contact with the heated
base plate: They could melt.
Hot and cold parts
Various parts of the unit can be heated or cooled to from
0°C to +150°C. Never touch hot or cold parts with your
hand. No containers used may become either brittle or soft
within the range of temperatures selected.
Maximum temperature
The maximum temperature for the Crystal Rack is limited to
100°C. In that way it is possible to limit the heating of the
Syncore if needed (see chapter 5.6)
Figure 12: The single platform
5 Operation

Syncore Platform
18
5 Operation
Exceeding the maximum temperature
Do not under any circumstances continue using the unit
when the temperature displayed is above 155°C. Contact a
BUCHI service agent immediately in such a case.
Moving parts
Various parts of the accessories are accelerated in the ho-
rizontal plane to speeds of up to 600 rpm. This means that
the machine may cast off parts that have not been fastened
correctly and present a risk for the operator and the labo-
ratory equipment. Whenever you have any doubts about
how well an accessory part has been fastened, switch the
unit OFF immediately and, if necessary, contact a BUCHI
service agent.
Never touch moving parts with your hand or with other
laboratory equipment.
An incorrect speed of rotation, eccentricity, or unbalance
compensation can cause the unit itself or the area around it
to vibrate strongly. In that case, stop the shaking movement
and correct the settings.
The unit must never vibrate so strongly that it can move about
on the base on its own or cause laboratory equipment to
change position.
Never under any circumstance put the unit into operation if
you have any doubts about the condition of these vibration
elements. Inform a BUCHI service agent immediately.
It is not permissible for any objects to penetrate into the
inside of the unit while it is in operation, nor is it permissible
to make any adjustments of the eccentricity or unbalance
compensation under such circumstances.
Noises
If ever any strong noises should occur during operation, take
the unit out of operation immediately and contact a BUCHI
service agent.
Error messages
The unit must not continue in operation after an error message
has been received unless it has been possible to determine the
cause of the error and eliminate the error. Otherwise, contact
a BUCHI service agent.
Refer here also to the chapter, „Error messages.“

Syncore Platform
19
5.3 Temperature and speed of rotation
1. Press once on the „UP“ or the „DOWN“ button on the
temperature control unit. The display shifts from the
current temperature to the prescribed set-point tempe-
rature.
2. Set a new control temperature by repeated pressing of
the„UP“-Key.
3. After 3 seconds the new control temperature will be ac-
cepted by the equipment and the ACTUAL temperature
will be displayed. Heating of the plate, however,
only commences after the „START“-Key has
been pressed!
4. Turn the speed control clockwise to set the desired
number of revolutions per minute.
For higher speeds, please note that the eccentricity and the
unbalance compensation must be checked as described
below before starting, and must be adjusted if necessary.
The reading in the display must change when the control
is turned and the base plate of the single platform must
move at the speed that has been set.
5. Starting the heating process: Press once on the „Start“
button  to heat the base plate to the prescribed tem-
perature. A dot in the temperature display indicates that
the heater is ON. The running time display shows how
much time has elapsed since starting.
6. Changing the temperature during operation in the manual
mode: The display for set-point temperature must be
activated in a way analogous to points 3 to 5, and the
desired temperature must then be set. After a delay of
3 seconds, the unit then takes over the new set-point
temperature. This does not affect the display for time.
7. Ending the heating process: Pressing once on the „Stop“
button switches the temperature control OFF and the
unit stops heating. This does not affect the shaking
movement.
8. Ending the shaking movement: Turning the speed con-
trol counterclockwise reduces the rotational speed and
brings the shaking movement to an end.
Important:
The shaking movement prevents evaporation retardation.
Therefore, pressure should always be equalized with the
atmosphere before switching off the shaking movement.
Figure 13: Display of the basic unit after starting up the equipment





5 Operation

Syncore Platform
20
5 Operation
5.4 Program mode, temperature/time steps
Typical application:
• Denitionofthetemperatureandtimeinseveralstagesat
a constant RPM, e.g. in a parallel evaporation at different
temperatures.
• Repetitionofheatingcyclesfor,e.g.materialtestingcycles
Schematic:
Programming mode, controlled parameters
1. Activating the programming function:
Press once on the „PROGRAM“ button.
The display indicates the first step (Step 1).
2. Entering the temperature for step 1:
Adjust the temperature set-point by pressing repeatedly
on the „UP“ or „DOWN“ button of the temperature control
.
3. Entering the time for step 1:
Press repeatedly on the „UP“ or „DOWN“ buttons of the
time control to define the time for step 1. The unit
will heat the base plate to this temperature and remains
constant for the time given.
4. Activating the next step:
Press once on the „PROGRAM“ button to activate
the next step in the program. The display indicates
the second step (step 2).
5. Entering the temperature and time for step 2:
Analogous to points 2 and 3.
6. Defining the last step in the program:
Press the „PROGRAM“ button once. The display 
indicates the next step. Set the time to 00:00. This ter-
minates the prgram after the preceding step, i.e. heating
is switched off and the equipment continues to rotate
at a constant RPM or it stops (depending on the safety
settings).
 Ifthe„UP“-Keyofthetimecontrollerisholduntil„OFF“
appears in the display (following the display of 9:59),
the equipment continues to operate at the temperature
denedinthisstepuntilthe„STOP“-Keyispressed.
Figure 14: Display of the basic unit after starting up the equipment




