Buderus RC35 User guide

For qualified profes-
sionals
Please read carefully
prior to commission-
ing and servicing
Installation and
servicing instructions
Programming unit
RC35
7 747 006 341  12/2006 GB

Contents
RC35 programming unit - Technical specifications are subject to change without prior notice.
2
Contents
Contents 2
1 Safety instructions and symbols 4
1.1 Safety instructions and explanation of symbols . . . . . . . . . . . . . . 4
1.2 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Information about the product 6
2.1 Correct use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 EU Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Included in delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Validity of these instructions for function modules (accessories) . . . . . 8
2.6 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3Installation 9
3.1 Choosing the right installation position . . . . . . . . . . . . . . . . . . 9
3.1.1 Installation in reference room . . . . . . . . . . . . . . . . . . . . 9
3.1.2 Installation on boiler . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Types of installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4 Attaching or removing the programming unit . . . . . . . . . . . . . . 12
4 Operating basics 13
4.1 Overview of operation . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2 Introduction to the Service menu . . . . . . . . . . . . . . . . . . . . . 14
4.3 Overview of the Service menu . . . . . . . . . . . . . . . . . . . . . . 16
5 Commissioning 17
5.1 General commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Checklist: important parameters for commissioning . . . . . . . . . . . 18
5.3 Quick commissioning (Quick operation menu) . . . . . . . . . . . . . 19
5.4 Detailed commissioning . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.5 System handover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.6 Shut-down / switching off . . . . . . . . . . . . . . . . . . . . . . . . 21
5.7 Operating tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Contents
RC35 programming unit - Technical specifications are subject to change without prior notice. 3
6 Entering system settings (Service menu – Settings) 22
6.1 System data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.1.1 Building type ("damping" of outside temperature) . . . . . . . . 23
6.1.2 Minimum ("lowest expected") outside temperature . . . . . . . . 24
6.2 Boiler data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.3 Heating circuit data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.3.1 Assignment of programming unit / remote control
unit in the software . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.3.2 Control mode (outside temp. controlled / room influence) . . . . 30
6.3.3 Heating characteristics . . . . . . . . . . . . . . . . . . . . . . . 31
6.3.4 Reduction modes (night setback) . . . . . . . . . . . . . . . . . 32
6.3.5 Frost protection . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.4 Domestic hot water (DHW) . . . . . . . . . . . . . . . . . . . . . . . . 35
6.5 Solar data (not with UBA1.x) . . . . . . . . . . . . . . . . . . . . . . . 37
6.6 RC35 calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.7 Contact data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7 Diagnosis 40
7.1 Function test (not with UBA1.x) . . . . . . . . . . . . . . . . . . . . . . 40
7.2 Monitor value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.3 Error message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.4 Htg. charact. curve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.5 Versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8 Servicing 43
9 Reset 44
10 Troubleshooting 45
Index 51

Safety instructions and symbols
1
RC35 programming unit - Technical specifications are subject to change without prior notice.
4
1 Safety instructions and symbols
1.1 Safety instructions and explanation of symbols
Installation and commissioning
zObserve all instructions to ensure satisfactory operation.
zInstallation and commissioning must only be carried out by qualified system installers.
Use
zAlways use this device correctly and in conjunction with the stated control systems.
zThis device must not be used with control systems using the UBA-H3 controller.
zObserve all regulations and standards applicable to installation and operation of the
system in your country.
Read and observe the safety information and instructions:
Risk of death from electric shock
zThe electrical supply must be connected by a qualified electrician. The terminal diagram
must be followed.
zBefore installation: isolate all poles of the power supply (230 V AC). Undertake meas-
ures to prevent power from being switched back on unintentionally.
zDo not install this device in rooms with high moisture exposure (e.g. bathrooms, sau-
nas).
zNever connect this device to the 230 V power mains.
Warning: frost
The heating system can freeze up in cold weather, if switched off.
zLeave the heating system permanently switched on.
zSwitch on frost protection.
zIn the event of a fault: remedy the fault immediately.

Safety instructions and symbols 1
RC35 programming unit - Technical specifications are subject to change without prior notice. 5
1.2 Explanation of symbols
The terms indicate the seriousness of the ensuing risk if measures for minimising damage
are not taken.
–Caution means that minor property damage may occur.
–Warning means that minor injury or severe property damage may occur.
–Danger means that severe injury may occur. Very serious cases may result in death.
Notes contain important information for situations in which there is no risk to the user or
the device.
Display text: Words appearing on the display are shown in bold
in the text.
Example: USER MENU
Action sequences: Each step in an action sequence is marked with a bullet point.
Example: Press .
If action sequences have more than two steps and the order of the steps is important, they
are numbered (1., 2., ...).
Safety instructions throughout the text are indicated by a warning triangle in-
side a rectangular frame.
Notes throughout the text are identified with this symbol. They are bounded by
horizontal lines above and below the text.
Note on using this manual: Section 4.2 "Introduction to the Service menu"
explains in detail the steps needed for programming all the settings in the Serv-
ice menu. In the sections which come after it, programming is only explained in
outline.
standard display
operation modes
switching programme
sum./win. threshold
USER MENU

Information about the product
2
RC35 programming unit - Technical specifications are subject to change without prior notice.
6
2 Information about the product
2.1 Correct use
The RC35 programming unit must only be used to operate and control Buderus heating
systems in residential buildings.
The boiler must be equipped with EMS (energy management system) or UBA1.x (univer-
sal burner control).
The programming unit must not be used in conjunction with Logamatic 2000/4000 con-
trol panels.
We recommend that the heating system is always operated with a programming unit (only
emergency operation is possible without a programming unit).
If RC20 remote control units manufactured before 2006 are being used, only two remote
control units can be connected. If you have any questions about this, please contact your
local Buderus office.
2.2 EU Declaration of Conformity
2.3 Included in delivery
– RC35 programming unit
– Operating instructions
– Installation and servicing instructions
– Wall bracket, mounting materials
The design and operation of this product conforms to European Directives
and the supplementary national requirements. Its conformity is confirmed by
the CE marking. You can view the Declaration of Conformity on the internet
at www.buderus.de/konfo or request a copy from your local Buderus office.

Information about the product 2
RC35 programming unit - Technical specifications are subject to change without prior notice. 7
2.4 Specifications
Temperature sensor characteristics
When measuring temperature sensor resistance, observe the following requirements:
– Isolate the system before measuring.
– Measure the resistance at the cable ends.
– The resistances represent mean values and are subject to tolerances.
Unit RC35
Power supply via bus system V16VDC
Power consumption W0.3
Power consumption with backlighting W0.6
Dimensions (width/height/depth) mm 150/90/32
Weight g233
Operating temperature °C 0 to +50
Storage temperature °C 0 to +70
Relative humidity %0to90
CE marking
Table 1 Specifications for the RC35 programming unit
Outside temperature sensor
Boiler/flow temperature sensor
DHW temperature sensor
°C kΩ°C kΩ°C kΩ
-20 96.358 10 19.872 60 2.49
-15 72.51 16 15.699 65 2.084
-10 55.054 20 12.488 70 1.753
-5 42.162 25 10.001 75 1.481
±0 32.556 30 8.060 80 1.256
525.339
35 6.535 85 1.070
10 19.872 40 5.331 90 0.915
15 15.699 45 4.372 95 0.786
20 12.488 50 3.606 100 0.677
25 10.001 55 2.989
30 8.060
Table 2 Resistances of the temperature sensors, for EMS only

Information about the product
2
RC35 programming unit - Technical specifications are subject to change without prior notice.
8
2.5 Validity of these instructions for function modules (accesso-
ries)
These instructions also apply to the programming unit when used in conjunction with the
MM10 mixer module and the WM10 low loss header module.
If the heating system is equipped with other function modules (e.g. SM10 solar module),
you will find additional setting options in some menus. These are described in separate
instructions.
2.6 Accessories
For precise information regarding suitable accessories, refer to the catalogue.
– MM10 mixer module1for controlling a three-way mixing valve. The instructions for the
MM10 form part of the RC35 instructions.
– WM10 low loss header module1for operating a hydraulic separator
– Solar module and other EMS modules (e.g. ASM10 connection module)1
– Remote control unit1(e.g. RC20/RC20RF) for controlling a particular heating circuit
– Outside temperature sensor, external room temperature sensor
1) The use of modules is not possible with boilers with UBA1.x and DBA.

Installation 3
RC35 programming unit - Technical specifications are subject to change without prior notice. 9
3 Installation
3.1 Choosing the right installation position
3.1.1 Installation in reference room
If the system is room-temperature controlled, the following requirements must be
observed:
– Installation position on an internal wall (Fig. 1)
– Maintain the specified distance from the door(s) (to avoid draughts).
– Allow clearance below the programming unit (Fig. 1, shaded area) (to ensure correct
temperature measurement).
– The reference room (= installation room) must be as representative as possible of the
entire home. External heat sources in the reference room (like sunlight or other heat
sources such as an open fire) affect the control's function. This means it may be too
cold in rooms without external heat sources.
– The thermostatic valves on the radiators in the reference room must always stay fully
open so that the two temperature controls do not affect one another.
Fig. 1 Minimum clearances for installation in a reference room
If there is no suitable reference room, we recommend setting the system to out-
side temperature control instead (this requires an outside sensor). Alternatively
you could install an external room sensor in the room with the greatest heating
requirements (e.g. living room).

Installation
3
RC35 programming unit - Technical specifications are subject to change without prior notice.
10
3.1.2 Installation on boiler
The unit can be installed directly on boilers equipped with EMS (Energy Management Sys-
tem).
The outside temperature sensor for outside temperature control is not delivered as stand-
ard, but can be ordered as an accessory.
3.2 Types of installation
The programming unit can be installed in three different ways:
– As the only programming unit in the system (factory setting): the programming unit is
mounted in a room in the home (the reference room) or on the boiler.
Example: detached house with one heating circuit.
– As the only programming unit in a heating system with two or more heating circuits1
(Fig. 2, 1).
Examples: underfloor heating on one floor, radiators on the others; or a main flat
together with a separate annex.
– In conjunction with a remote control unit (e.g. RC20/RC20RF, Fig. 2, 2). In this case
there are always two separate heating circuits. Remote control units cannot be used
with boilers with UBA1.x.
Examples: underfloor heating on one floor, radiators on the others; or a main flat
together with a separate annex.
Fig. 2 Options for a heating system with two heating circuits
1 Both heating circuits are controlled by one programming unit.
2 Each heating circuit has its own programming unit / remote control unit.
1) Not possible with boilers with UBA1.x and DBA.

Installation 3
RC35 programming unit - Technical specifications are subject to change without prior notice. 11
3.3 Installation and connection
The wall bracket can be attached directly to the wall or on a flush-mounting box.
When mounting on a flush-mounting box, note the following:
– Draughts from the flush-mounting box must not distort room temperature recording in
the programming unit (you may need to pack the flush-mounting box with insulation
material).
– Use the horizontal or vertical mounting holes (Fig. 3, 4).
zMount the wall bracket (Fig. 3, left).
zConnect the two-wire bus cable from the Energy Management System (EMS) to the
“RC” cable terminals (Fig. 3, 5).
– Cable type: 2 x 0.75 mm2(0.5 – 1.5 mm2), length max. 100 m
– The two wires are not polarity sensitive.
– Do not lay the cables next to power cables.
Fig. 3 Mounting the wall bracket (left) and connecting the wires (right)
1 Hole drilled in the wall
2 Screws (included with the unit) for surface-mounting on the wall
3 Vertical mounting holes for mounting on a flush-mounting box
4 Horizontal mounting holes for mounting on a flush-mounting box
5 “RC” terminals for EMS (boiler)
6 “EXT” terminals for external room temperature sensor or for jumper
Please use only the wall bracket with screw-type terminals.
zI
f there is a wall bracket without screw-type terminals already fitted, replace it.
1
2
3
4
3
4
1
2
5
6

Installation
3
RC35 programming unit - Technical specifications are subject to change without prior notice.
12
zIf the RC35 is operated without an external room sensor, a jumper is required on the
“EXT”terminals (Fig. 3, 6) (the jumper is factory fitted).
zIf the RC35 is operated with an external room sensor, the factory-fitted jumper on “EXT”
must be removed and the external room sensor must be connected there instead.
3.4 Attaching or removing the programming unit
Attaching the programming unit
zHook the top of the programming unit onto the mounting plate in the direction shown
by the arrows (Fig. 4, A1).
zPush the bottom of the programming unit against the mounting plate in the direction
shown by the arrow until it clicks into place (Fig. 4, A2).
Removing the programming unit
zPress the button on the underside of the mounting plate in the direction shown by the
arrow (Fig. 4, B1) and pull the programming unit forward at the same time (Fig. 4, B2).
zRemove the programming unit by lifting upward (Fig. 4, B3).
Fig. 4 Attaching the programming unit (left) or removing it (right)
1
2
1
2
1
AB
3

Operating basics 4
RC35 programming unit - Technical specifications are subject to change without prior notice. 13
4 Operating basics
4.1 Overview of operation
Legend for illustration:
1Flap: pull the recessed grip on the
left to open
2Display
3Rotary selector for changing values
and temperatures or for navigating
through the menus
4 Buttons for basic functions: When the LED lights up ...
“AUT” (automatic) ... the switching program is active (automatic switchover between
daytime and nighttime room temperatures).
“Day mode” (manual) ... the heating system operates at the set daytime room temperature.
DHW heating is switched on (factory setting).
“Night mode” (manual) ... the heating system operates at the set nighttime room tempera-
ture. Frost protection is active. DHW heating is switched off (factory
setting).
“DHW” (domestic hot water) ... the DHW temperature has fallen below its set value. The DHW
can be heated up again by pressing the button (the LED will then
flash). 1)
1) The LED can also be switched off. In the case of boilers with UBA1.x, the LED does not light up at all.
5 Buttons for
additional functions:
Function:
“Menu/OK” Open User menu and confirm selection.
When the rotary selector is turned at the same time: change setting.
“Time” Set the time.
“Date” Set the date.
“Temperature” Set the room temperature.
“Info” Open the Info menu (to view values).
“Back” Go back one step or one menu item.

Operating basics
4
RC35 programming unit - Technical specifications are subject to change without prior notice.
14
4.2 Introduction to the Service menu
The SERVICE MENU to set the parameters for the system. The Service menu also con-
tains fault functions diagnosis, for maintenance purposes, and performing a reset. The
procedure for operation is always the same:
1. Open the flap (by pulling the recessed grip on the left).
2. Press the buttons + + at the same time to open the SERVICE MENU.
3. Turn the rotary selector to change the selected item (marked with B).
4. Press to select the marked item.
5. To change the value, hold down the button (the value starts flashing) and turn the
rotary selector at the same time.
Release the button: the modified value is saved.
6. Press to go back one step.
-or-
zPress several times or shut the flap to return to the default display.
Example: Setting the building type ("delay" time)
Operation Result
1. Open the flap (by pulling the recessed grip on the left).
2. Press the buttons + + at the same time to open
the SERVICE MENU.
3. Turn the rotary selector anti-clockwise until settings is
selected (marked with B).
Table 3 How to use the Service menu (example)
Fr 02.12.2005 10:20h
outside temp. -1°C
21.5°C
SERVICE MENU
B quick operation
settings
diagnosis
servicing
SERVICE MENU
quick operation
settings
diagnosis
servicing
B

Operating basics 4
RC35 programming unit - Technical specifications are subject to change without prior notice. 15
4. Press to confirm the selection.
The SERVICE\SETTINGS menu is opened.
5. Turn the rotary selector anti-clockwise until boiler data
is selected (marked with B).
Press to select boiler data.
6. To change the value, hold down the button (the value
starts flashing) and turn the rotary selector at the same
time.
7. Release the button .
The value stops flashing. The modified value is saved.
8. If you have carried out this example as practice only, make
sure that the original setting is retained.
To do so, repeat steps 6 and 7 if necessary.
9. Press to go back one step.
-or-
To finish entering settings, press several times or shut
the flap.
The default display re-appears.
You can enter all settings in the SERVICE MENU using this procedure.
Operation Result
Table 3 How to use the Service menu (example)
SERVICE\SETTINGS
B plant data
boiler data
domestic hot water
heating circuit 1
SETTINGS\BOILER
What type of building
do you have?
medium
SETTINGS\BOILER
What type of building
do you have?
medium
SETTINGS\BOILER
What type of building
do you have?
light
SETTINGS\BOILER
What type of building
do you have?
medium

Operating basics
4
RC35 programming unit - Technical specifications are subject to change without prior notice.
16
4.3 Overview of the Service menu
The Service menu is divided into the following menus and submenus:
Menu Submenu Contents/function Page
Quick opera-
tion
The most important parameters from the Set-
tings menu for configuration of the heating sys-
tem (e.g. number of heating circuits, installed
modules)
19
Settings
(all parameters)
Plant data1)
1) Boilers with DBA: restricted functionality only.
Parameters: language, number of heating cir-
cuits, installed modules, building type, minimum
outside temperature
22
Boiler data
Parameters: pump after-run time and modulation 25
Heating circuit data1) Parameters of the installed heating circuits 26
Domestic hot water
(DHW)
Parameters for domestic hot water 35
Solar data1) If solar is installed: see documentation for the
solar module
37
RC35 calibration Parameters: calibration of the displayed room
temperature
38
Contact data Entering the heating contractor's name and tele-
phone number
39
Diagnosis Function test2)1)
2) Not possible or not available with boilers with UBA1.x.
Activating individual components for test pur-
poses
40
Monitor value Viewing target values and actual values 41
Error message Viewing fault messages 42
Htg. charact. curve Viewing the set heating characteristics in the
form of a graph
42
Versions Viewing software versions 42
Servicing2)1) Service interval Setting times for maintenance, by number of
operating hours or by date
43
Current messages Viewing service messages 43
RESET servicing Resetting service messages 43
RESET2)1) Factory setting 44
Error list 44
Service message 44
Operating hours 44
Table 4 Service menu navigator

Commissioning 5
RC35 programming unit - Technical specifications are subject to change without prior notice. 17
5 Commissioning
5.1 General commissioning
Operation Result
1. Switch on the heating system.
While setting up the connection between the RC35 and EMS
or UBA1.X, the display shows the message on the right.
If the display shows a different message, look it up in
section 10, page 45.
2. Set the language:
Open the flap. Hold down the button and use the rotary
selector to set the language.
3. Set the date and time:
Hold down the button and use the rotary selector to set
the values which are flashing. Release the button.
Hold down the button and use the rotary selector to set
the values which are flashing. Release the button.
In the event of a power failure, the date and time are retained
for up to 8 hours. All other settings are retained permanently.
4. Press the buttons + + at the same time to open
the SERVICE MENU.
Table 5 General commissioning
If necessary, you can change the contrast on the display:
zHold down the buttons and and turn the rotary selector at the
same time.
RC35 version:
connect to: EMS
connection setup ...
please wait
Open cover in order
to set language with
OK key.
language set:
English
SET DATE
set year
01.01.2000
SERVICE MENU
B quick operation
settings
diagnosis
servicing

Commissioning
5
RC35 programming unit - Technical specifications are subject to change without prior notice.
18
5.2 Checklist: Important parameters for commissioning
When putting the device into service, ensure the satisfaction of both parties, making sure
that the heating system meets the customer's needs and prevents complaints. In our expe-
rience, the following parameters are very important for the satisfaction of the system
owner.
zFind out the system owner's requirements and preferences regarding ...
zEnter the chosen settings in the Setup log (at the end of the operating instructions
manual).
Setting options
Factory setting in bold
Service menu \
Settings \
... the desired reduction
type (night setback)
Outdoor setback mode, reduced
operation, room setback mode, shut-
down mode
Heating circuit x,
page 27
... the desired control mode Outside temp. controlled, room
temp. controlled
Heating circuit x,
page 30
... the correct heating char-
acteristics
By means of the following parameters:
standard temperature, minimum out-
side temperature, offset, und target
room temperature
Heating circuit x,
page 26
... the correct building type
("delayed" response to out-
side temp.)
Light, medium, heavy Plant data (system
data), page 23
... the switch-on frequency
of the DHW circulation
pump1)
1) This function is not available with boilers with UBA1.x and DBA.
Permanent, 1 x, 2 x, 3 x, 4 x, 5 x, 6 x
per hour for 3 min each time
Domestic hot
water, page 36
... priority DHW Yes, No Heating circuit x,
page 28
... switching program
(times)
Standard program Family,
user defined program
Heating circuit x,
page 29
Table 6 Checklist: important parameters for commissioning

Commissioning 5
RC35 programming unit - Technical specifications are subject to change without prior notice. 19
5.3 Quick commissioning (Quick operation menu)
zPress to open the quick operation menu.
SHORTCUT\ Menu item
Input range
Factory setting in
bold Other information
BASIC SETUP Which language
should be used?
German ...
HYDR. SEP. Have you installed a
module for the
hydraulic separator?
Yes, No 1)
PLANT Is heating circuit 1
installed (unmixed
heating circuit)?
Yes, No
NO. OF MIXERS How many mixed
heating circuits are
installed?
0
0 to 3
Set the address on the rotary
encoder on the mixer module
(factory setting: HC2).1)
HTG. CIRC. 1
(and other heating
circuits)
Which operating unit
is assigned to heat-
ing circuit 1?
RC20/RC20RF,
RC35
None
To assign programming units
to heating circuits, see
page 30.
For general heating circuit
data, see page 26.
Set any other heating circuits
in the same way as for heat-
ing circuit 1.
How should heating
circuit 1 be control-
led?
Outside temp. con-
trolled,
room temp. controlled
Which heating sys-
tem does heating
circuit 1 have?
Radiator, convector,
floor
For heating characteristics,
see page 31
Table 7 Quick operation menu navigator
SERVICE MENU
B quick operation
settings
diagnosis
servicing

Commissioning
5
RC35 programming unit - Technical specifications are subject to change without prior notice.
20
5.4 Detailed commissioning
zCheck whether the factory settings in Service menu \ Settings are suitable for the
customer's heating system.
zNote down modified settings if needed.
5.5 System handover
zMake sure that both dials on the BC10 boiler controller1are set to “Aut”, so that DHW
temperature and flow temperature are controlled by the RC35 programming unit.
zExplain to the customer how the device works and how to operate it.
zInform the customer of the settings chosen (using the Setup log at the end of the oper-
ating instructions manual).
DHW Have you installed
domestic hot water?
Yes, No
Which heating circuit
should be used for
domestic hot water?
3-way switching
valve
Cylinder charge pump
Always set to 3-way switch-
ing valve in the case of boilers
with DBA.
To which tempera-
ture should your
domestic hot water
be heated?
60°C
30 to 80°C
To allow the hot water tem-
perature to be changed, set
the hot water dial on the
boiler controller to Aut.
SOLAR MODULE Have you installed a
solar module?
Yes, No 1)
1) Not possible or not available for boilers with UBA1.x and DBA.
Use the checklist on page 18 to check whether more settings are needed.
1) On boilers with UBA1.x and DBA there is no BC10. See the technical documentation for the boiler
for information on its mode of operation.
We recommend giving these installation and servicing instructions to the cus-
tomer so they can be kept close to the heating system.
SHORTCUT\ Menu item
Input range
Factory setting in
bold Other information
Table 7 Quick operation menu navigator
