Burkert 1062 User manual

1062 -1-
©BÜRKERT 1995 893070 - Ind**/Fév01
We reserve the right to make technical changes without notice
INSTRUCTION MANUAL 1062............................................................. 2
Advice and service .............................................................................. 8
1062

-2-1062
Order Nr
Mechanical limit switch (gold or silver platted)
Piston Switch Reference Voltage VAC/VDC
∅ mm Ag 12/48 V 48/110 V 110/250 V
40 NO 444181 - 444184
40 NF 444182 - 444185
40 NO/NF 444183 - 444186
50-80 NO 007462 420770 005415
50-80 NF 007461 420771 005409
50-80 NO/NF 007463 420772 005416
>100 NO 007465 420773 007459
>100 NF 007464 420774 007458
>100 NO/NF 007466 420775 007460
Piston Switch Reference Voltage VAC/VDC
∅ mm Au 12/30 V 48/110V 110/250 V
50-80 NO 420776 - -
50-80 NF 420777 - -
50-80 NO/NF 420778 - -
>100 NO 420779 - -
>100 NF 420780 - -
>100 NO/NF 420781 - -
Operating Instructions
Follow this manual and proceed in accordance with
the application conditions and specification data of
the device, as referred to in the data sheets. The
position indicator shall be integrated into the process
according to the general technical guidelines. Take
appropriate actions in order to avoid unintended
operation or mutual interference in the process.
Strict observance of these conditions by the user
ensures a reliable operation and a long service life.
Specific Use
The position indicator 1062 is designed for use to
electrical position feedback and optical position
indication. It can be fitted with the Bürkert valves
2000, 2001, 2002, 2030 and 2031.
Safety Rules
Safety rules must be observed. The position
indicator should be connected by trained staff only.
Caution: Disconnect voltage before opening any
position indicator! Do not switch the valve as long as
open - danger of injury !
Operating Data
LED green: Valve open
red: Valve closed
Yellow: Voltage indicator
Ambient temp.:-20 to +60 °C
Protection class: IP 65 (DIN 40 050)
Certification: Mechanic and inductive switching
elements according to VDE, IEC, UL, CSA. Inductive
NAMUR-switch element in Ex i.
Limit switches types
 Mechanical limit switch
(Inverter as standard)
Switch operating characteristics:
Voltage Inductive load Resistance load
En I max. I max.
125 V 8 A 8 A
250 V 8 A 8 A
24 V = 5 A 5 A
30 V = 2 A 5 A
50 V = 0,7 A 1 A
74 V = 0,25 A 0,6 A
125 V = 0,03 A 0,4 A
250 V = 0,02 A 0,25 A
Inductive limit switch
Nominal voltage 10 to 30 VDC
Inductive contact 3 wires 2 wires
Max load 200 mA 100 mA
Output resistance 4,7 k -------
Consumption 25 mA 2 mA
Inductive limit switch 2 wires.
DIN 19 234 (NAMUR) Ex i
Nominal voltage 8 VDC
Consumption cushioned 1 mA
uncushioned > 3 mA
POSITION FEEDBACK 1062
Inductive limit switch; Voltage 10-30 VDC
Piston Switch Reference Switch
∅ mm 3 wires PNP 3 wires NPN 2 wires
50-80 NO 005434 420782 420788
50-80 NF 005422 420783 420789
50-80 NO/NF 005461 420784 420790
>100 NO 007468 420785 420791
>100 NF 007467 420786 420792
>100 NO/NF 007469 420787 420793
Limit switch Exi NAMUR ; Voltage 8 VDC
Piston Switch Reference Switch
∅ mm Type 2 wires NAMUR
50-80 NO 007471
50-80 NF 007470
50-80 NO/NF 007472
>100 NO 007474
>100 NF 007473
>100 NO/NF 007475

1062 -3-
Assembling Instructions
1062 Version
Plug PG
• • Unfasten grub screw 
then carefully remove spindle 
from the body.
O-Ring
POSITION FEEDBACK 1062
••The spindle of valves in control function
B is already in the upper position.
Valves in control function A or I shall thus
be pressurized, that the valve spindle
remains on top.
(The valve shall be pressurized during the
entire installation time).
Unscrew transparent cover .
Unscrew signal cover 
with Allen key.
••Only valve 2031 with C (40 mm) actuator:
Remove cover then indicator .
Install cover  supplied with the 1062.




-4-1062
1062 Version
Plug PG
•• Connect guiding piece of spindle 
into valve cover .
Fasten spindle with
the valve spindle .
•• Carefully place body upon
guiding piece , rotate into
required direction and fix with
grub screw .
POSITION FEEDBACK 1062

1062 -5-
1062 Version
Plug PG
• Unscrew cover  .
• Pull cable through PG
cable gland , peel-off 100 mm
from the cable and connect
according to wiring diagram
(see next page).
• Install cable into guide on bottom
of body .
Fasten PG cable gland .
• Screw back cover .
•• Only valve 2031 with C actuator:
Label specification tag .
If the position feedback indicator in operation
should be changed to another valve, set both
trip cams to the distances shown in the figure.
•• NOT valve 2031 with C actuator:
Label specification tag .
Stroke must not be adjusted (self-adjusting).
In case the position feedback indicator in operation
should be changed to another valve, set the lower
trip cam to the height of 35.5 mm.
POSITION FEEDBACK 1062
Red
Yellow
Green
4,6 mm
26 mm

-6-1062
+
+
PNP
S-
123
1062
Inductive 2 wires
Position
Open/Closed
Connection inductive limit switch
I load ≤100 mA
I load ≤100 mA
Inductive 2 wires
Position
Open/Closed
+ -
12
1062
+
+ -
12
1062
+
OR
POSITION FEEDBACK 1062
+
+
PNP
S-
123
1062
Yellow
Red
Green
I load ≤200 mA I load ≤200 mA
PNP 3 wires
Open Position
24 VDC
PNP 3 wires
Closed Position
24 VDC
+
+
NPN
S-
123
1062
+
+
NPN
S-
123
1062
Yellow
Green
I load ≤200 mA
I load ≤200 mA
Red
Yellow
NPN 3 wires
Open Position
24 VDC
NPN 3 wires
Closed Position
24 VDC
Closed Position
Open Position
Yellow

1062 -7-
Closed Position
Open Position
Connector according
to
DIN 19234 NAMUR
Cushioned ≤1 mA
Uncushioned > 3 mA
Open Position
NAMUR
Ex i
+ -
12
1062
Connection inductive limit switch NAMUR
Closed Position
NAMUR
Ex i
+ -
12
1062
POSITION FEEDBACK 1062
Connection mechanical limit switch
Connector according
to
DIN 19234 NAMUR
Cushioned ≤1 mA
Uncushioned > 3 mA
123
1062
4
+-
The unused contact (NO or NC) is not potential free.
NO
Red
Yellow
1
2
3
1062
4
+
-
Yellow
Green
NC
Contact
NO
Contact
NC

-8-1062
