Buschmann tools DOUBLE FALZ SEAMER Operator's manual

SKU#0600
WEIGHT 5.3KG

Technical data
• STAINLESS STEEL: 0.5 MM
• ALUMINUM, COPPER, ZINC: 0.8 MM
• STEEL: 0.7 MM
max speed
DOUBLE FALZ SEAMER
The DOUBLE FALZ SEAMER is the perfect hand-held equipment for perfect and effortless seaming of
single and double standing-seam in one operation.
The DOUBLE FALZ SEAMER is used for seaming of single and double standing seam on prole and is
suitable for several materials - Stainless steel, steel, Aluminum, Copper and Zinc.
• Double seaming process is easy to overview because of open type housing
• Starting from 25 mm any seaming height is usable without additional height adjustment
• fastest seaming machine in the world - up to 30 m / min
• 30 m / min
• Seaming rolls are at the size of 60 mm for flatter seaming process to avoid metal
stretching
• can be attached and deatached at any point on the seam
• Usable with cordless drill
• Lightweight
• 100 m² / 7 min
• You can use single and double standing-seam operations separately
Single step
Facade Double step
Roof
• The tools are placed inside the Military grade cases with safety
1 2 3 4 5
• Lightest and fastest tool in the world for seaming single and double standing-seam
in one operation
• WEIGHT: 5.3 KG
max thickness

DOUBLE FALZ SEAMER SETUP
1
2
3/4
Position the cordless drill machine on the
10mm rotating hex cap head axle and tighten
it.
Tighten the cordless drill inside the Holder
with the key that comes with the the tool.
The holder must be tightened until the inside
edges of the holder stops against the cordless
drill machine.
Adjust support bar which connects cordless
drill mounting to Double Falz Seamer machine
When setting up the DOUBLE FALZ SEAMER
we must remove and make sure that
cordless drill accumulator is removed
from the Accumulator drill machine
Only when we are denitely sure that everything is con-
nected properly only then we place the battery inside the
cordless drill machine and start working!
4
31
2
FOR ROOF DOUBLE STEP
The beginning of
the metal prole
is in line with the
middle of third
roll marker
Position the DOUBLE FALZ SEAMER
so that 3rd roll is in line with the
Pull the handle upwards, so rolls lock in
their position and start seaming!
Using without twin square seam folder
• For metal prole thickness of 0.4 - 0.6 mm you must use a
spacer of 4 mm
• For metal prole thickness of 0.6 - 0.8 mm you must use a
spacer of 5 mm
UNSCREW THE THIRD ROLL AND CHANGE THE SPACERS DEPENDING
ON THE METAL PROFILE THICKNESS
3

Make sure the 3rd roll is below the seam and 4th roll is above the seam
Position the Double Falz Seamer on the seam with an open handle and then close the Double Falz
Seamer and start seaming! Double Falz Seamer is attachable on any place in to the seam
34
Third roll must be
under the seaming
prole
Fourth roll must be
above the seam-
ing prole
Use twin square seam folder
once
FOR ROOF DOUBLE STEP
Using with twin square seam folder
1. Use twin square seam folder
twice
2. Use twin square seam folder
for double seaming operation
3.
4.
3 4
5.

FOR FACADE SINGLE STEP
The beginning of
the metal prole
is in line with the
middle of third
roll marker
Pull the handle upwards, so the rolls x in
their position and start seaming!
If its necessary only to do single step, you
need to unscrew 4 and 5 roll off and you can
start seaming!
when you unscrew the rollers you will see
that fourth (4) roll is marked with gold and
fth (5) roll is marked with red engravement
Position the DOUBLE FALZ SEAMER so that
the 3rd roll is in line with the beginning of
the metal prole ( see picture )
1.
2.

At places where multiple sheet metal
proles are connected its prohibited to
use DOUBLE FALZ SEAMER
PROHIBITED USE
WARNING!
Important safety InformatIon for operatIng the DOUBLE FALZ SEAMER
• Before setting up the tool always make sure to remove the accumulator from the cordless drill!
• When performing operation that’s not associated with the seaming task the cordless drill must be
removed from the cordless drill!
• Carefully read all safety information before operating the DOUBLE FALZ SEAMER and save it for future
reference.
• As a matter of principle, any person who is put in charge with the start-up, operation, maintenance
and repair of the machine must have read and understood the operating instructions, specically the
chapter on safety.
• When working with DOUBLE FALZ SEAMER on a roof, always use roof lifeline and follow all safety regula-
tions, as the DOUBLE FALZ SEAMER with a cordless drill machine is a very fast tool.
• Before using DOUBLE FALZ SEAMER for the rst time, carefully remove all packing materials.
• Always make sure that DOUBLE FALZ SEAMER is properly assembled before using.
• Always make sure the battery is disconnected from the DOUBLE FALZ SEAMER’s cordless drill machine
and only then clean the tool or replace the rolls.
• During the work hold hands, ngers, hair, clothes and other tools at a safe distance. Never place your
hands, ngers or tools between the rolls.
• Do not overreach. Keep proper footing and balance at all times.
• Stay alert. Watch what you are doing. Use common sense. Do not operate tool when you are tired or
under the inuence of drugs, alcohol or medication. A moment of inattention while operating may
result in serious personal injury.
• Do not wear loose clothing or jewellery. Keep your hair, clothing, and gloves away from moving parts.
Loose clothes, jewellery or long hair can be caught in moving parts.
• After using DOUBLE FALZ SEAMER, make sure that the tool isn’t wet and then put it in the box. If sand and
dust accumulate around the rollers, clean them.
• Keep the tool clean. For more information on maintenance and cleaning, see on page 7.
• Do not expose the DOUBLE FALZ SEAMER extreme temperatures, it is not recommended to operate
the device in cold weather (below zero degrees). Do not expose DOUBLE FALZ SEAMER to rain or use tit
under moist or wet condition.
• This tool is not intended for use by children. Ensure that children do not have access to the Double Falz
Seamer.
! DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to safety rules for the
subject product. MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal
injury. !

possIble operatIon faIlure preventIon
• if DOUBLE FALZ SEAMER does not work - make sure the drill battery is charged :)
• if rolls scratch color off the metal - make sure the work area is clean from sand, dust etc...
• if sound is not good while seaming - make sure the prole is correctly folded.
• if rotary rolls are starting to rust - after use the tool has not been carefully cleaned.
• if the tool stops - you can’t use it on the specic place, if the cordless drill is powerful enough - it will
withstand the force, but the tool will break, if the cordless drill is not powerful enough - it will break, but
the tool will withstand.
Care, maIntenanCe and storage of DOUBLE FALZ SEAMER
• Always make sure the battery is disconnected from the cordless drill and only then clean the tool!
• Clean the device every time after using it.
• Clean DOUBLE FALZ SEAMER from moisture, dust and sand.
• Always keep gears clean.
• Keep the rotary parts free from dust, sand and moisture.
• Check all screws periodically.
• It is strictly forbidden to put and keep a wet or damp Double Falz Seamer in a case.
Warranty
We guarantee that all DOUBLE FALZ SEAMER is made of high quality materials and does not have
any manufacturing defects. In case your device turns up the following defects, we will eliminate
them in accordance with the law free of charge. Therefore, we give 1 (one) year limited warranty on
our tools from the date of invoice. Limited warranty applies only to rst sale. You must contact the
company that has sold the product to le claims. Be sure that You have the purchase document!
The device must be delivered for repair in a complete set.
If DOUBLE FALZ SEAMER is repaired by an unqualied person, we can no longer guarantee the quality
of the device. Also, we can not guarantee the quality of the device if:
• the tool is mechanically damaged, dropped off or otherwise broken;
• have been used on incorrect working methods;
• have been used with unsuitable accessories;
• the tool is used for unforeseen purposes;
• the tool is used after detection of a defect;
• the tool used by a person without the necessary skills;
• the tool was uncared for;
• the construction and parameters of the tool have been changed.
The DOUBLE FALZ SEAMER is a complex combination of mechanical parts and has a lot of moving
and wearing off parts. Wearing off parts is a normal phenomenon, not a production defect. In result
of normal usage,worn parts will not be exchanged for free. Wearing parts are for example: Handle,
Protectors, Chain, Wheels, Gear Drive Shaft, PVC Gears, PVC Case and all other moving Parts.
operatIng InstruCtIon of DOUBLE FALZ SEAMER
• The DOUBLE FALZ SEAMER is to be operated exclusively by qualied and authorised
persons who must know the national accident-prevention rules.
• Carefully remove packaging and all promotional labels before using DOUBLE FALZ
SEAMER for the rst time.
• Wear adequate working clothes. Long hair should be protected by a hairnet. Put on
protective gloves.
• Obligated to check the DOUBLE FALZ SEAMER for externally visible damage and defects
before starting work and to notify and eliminate any changes (including the opera-
tion behavior) that affect the safety.
• Sight-checking all screws- tighten screws if necessary.
• Operates with cordless drill starting from 80 Nm
thanK you for purChasIng double falZ seamer, enJoy!

Buschmann tools
invention | production
Printable pdf instruction
https://buschmanntools.com/DFalzSeamer/eng
