Bush Hog 5045 User manual














SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Page 70
 Specifications Based on 1997 ASAE STANDARDS 
 60 - 90
 2WD/FWA
 - Measured at Pivot Pin 133 inches
 - Under Level Bucket 123 inches
 45°
 7 inches
 to Maximum Height - At Pivot Pin 4000 lbs
 to Maximum Height - 31.5 inches Forward of Pivot Pin 2560 lbs
 to 59 inch Height - At Pivot Pin 5000 lbs
 to 59 inch Height - 31.5 inches Forward of Pivot Pin 3500 lbs
 - At Pivot Pin 6000 lbs
 - 31.5 inches - Forward of Pivot Pin 4280 lbs
 at Maximum Height - 31.5 inches Forward of Pivot Pin 4800 lbs
 at 59 inch Height - 31.5 inches Forward of Pivot Pin 5600 lbs
 at Ground Level - 31.5 inches Forward of Pivot Pin 3750 lbs
(Ground Level to Full Height) 5 seconds
(Full Height to Ground Level) 3 seconds
 (Full Rollback to Full Dump) 5 seconds
 (Full Dump to Full Rollback) 3 seconds
 Two 2.5 inch Bore, 23.69 inch Stroke Double Acting Bucket Cylinders and Two 3.0 inch Bore, 18.94 inch Stroke Double Acting Lift Cylinders
 2850 PSI hyd. pressure & 16 GPM pump capacity
 Available in 72, 80, 84 and 96 inch widths
 Available in 60, 72, 84 and 96 inch widths
 Forklift Attachment (48 inch tines), Round Bale Spear, Dual Probe Bale Spear, Grapple Fork, Bucket Tine Teeth,
Bolt On Digging Teeth, Side Cutting Edges, Spill Guard Attachment, Hydraulic Self Leveling, and Grill Guards
 1 year limited warranty
 “Universal” skid steer quick attach system compatible with skid steer style attachments,
Available in major tractor colors
