Bush hog Bse-1 User manual

Models

BSE-1, BSSS-1

BSSS-2, BSSS-3

BALE SPEAR

Published 08/23 Part No.50084019

BUSH HOG®

2501 Griffin Ave.

Selma, AL 36703

334-874-2700

www.bushhog.com

OPERATOR’S MANUAL

This Operator's Manual is an integral part of the safe operation of this machine and

must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW

the Safety and Operation Instructions contained in this manual before operating the

equipment. C01-Cover str

To the Owner/Operator/Dealer

All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded

operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has

designed this implement to be used with all its safety equipment properly attached to minimize the chance of

accidents.

BEFORE YOU START! Read the safety messages on the implement and shown in your manual. Observe the rules

of safety and common sense!

WARRANTY INFORMATION:

Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty Registration

Form in full and return it to within 30 Days. Make certain the Serial Number of the Machine is recorded on the

Warranty Card and on the Warranty Form that you retain.
