Bush BU-203 User manual

BU-203 Bagless Upright Vacuum Cleaner
Instruction Manual - Please keep for future reference
BU-203
For help, spares or
assistance please call
0845 6042377
or visit
www.bagsandfilters.com
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:32 Page 1

BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:32 Page 2

1
IMP RTANT SAFETY INSTRUCTI NS
Read all instruction before use and keep for future reference.
F R H USEH LD USE NLY.
When using the vacuum cleaner, basic safety
precautions should always be observed, including
the following:
1. Only use the vacuum cleaner indoors on dry surfaces.
Do not handle the plug or vacuum cleaner with wet
hands. Do not use outdoors or on wet surfaces.
2. Turn off the vacuum cleaner controls before
disconnecting or connecting from the mains supply.
3. Always unplug the vacuum cleaner before connecting
or disconnecting the vacuum hose and accessories.
4. Children should be supervised to ensure that they do
not play with the appliance.
5. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
6. Only use as described in this manual. Only use
recommended attachments.
7. Do not use the vacuum cleaner if it has been
dropped, damaged, left outdoors or dropped into water.
8. Do not use the vacuum cleaner with a damaged cord
or plug. If the supply cord is damaged, call the helpline
for assistance.
9. Do not pull or carry by cord/hose. Do not use the
cord/hose as a handle, close a door on the cord/hose or
pull cord/hose around sharp edges or corners. Do not
run the vacuum cleaner over the cord. Keep the cord
away from heated surfaces.
10. Do not put any objects into openings. Do not use
with any openings blocked and do not restrict air-flow.
Keep all openings free of dust, lint, hair or anything that
might reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the
body away from openings and moving parts.
12. Do not pick up hot coals, cigarette butts, matches
or any hot, smoking or burning objects.
13. Do not pick up flammable or combustible materials
(lighter fluid, petrol, kerosene etc.) or use in the
presence of explosive liquids or vapours.
14. Do not vacuum up harmful or toxic material
(chlorine, bleach, ammonia, drain cleaner etc.).
15. Do not vacuum up hard or sharp objects such as
glass, nails, screws, coins, etc.
16 Do not use without A of the filters in place.
17. Take extra care when vacuuming on stairs.
18. Keep vacuuming area well lit.
19. Store the vacuum cleaner in a cool, dry area.
20. Turn off the on/off switch before unplugging the
vacuum cleaner.
21. Only use CE - approved 13 amp extension cords.
Non-approved cords may overheat. Care should be
taken to arrange the cord so that the cord cannot be
tripped over.
WARNING: Always switch off and unplug the
vacuum cleaner from the electrical outlet before
assembling, opening or emptying the dirt container,
connecting/disconnecting the attachments, or carrying
out maintenance or troubleshooting checks.
CAUTI N: The vacuum cleaner is a very
powerful unit. Before plugging the cord into the
electrical outlet, make sure the switch is in the ‘off’
position. Hold the vacuum cleaner firmly when starting
and in use.
IMP RTANT: If the inlet, hose or extension
tube is blocked, switch off the vacuum cleaner
and remove the blockage(s) before re-starting the
vacuum cleaner.
IMP RTANT: We recommend that filters should
be checked and cleaned periodically. For
washable filters, ensure they are completely dry before
inserting back into the vacuum cleaner. Do not wash
with detergents. Use only warm water, max 40°c.
IMP RTANT: The motor is equipped with a
thermal cut-out. If for any reason the unit should
overheat, the thermostat will automatically turn the unit
off. Should this occur, unplug the vacuum cleaner from
the electrical outlet and turn off the switch. Remove
dirt container and empty. Clean filters. Allow the unit to
cool for approximately one (1) hour. To re-start, plug
into an electrical outlet and switch back on.
This vacuum cleaner is intended for household use
only and N T for commercial or industrial use.
PLEASE KEEP INSTRUCTI NS F R FURTHER USE.
!
!
!
!
!
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:32 Page 3

2
C NTENTS
SAFETY INF RMATI N 1
KN W Y UR MACHINE 3
ASSEMBLY 4
PERATI N 5
Accessories 5
MAINTENANCE 6
Emptying the dirt container 6
Cleaning the HEPA central filter 6
Cleaning the pre motor filter 7
Replacing the belt 7
CLEARING BL CKAGES 8
Removing debris from the hose 8
Removing debris from the brushbar 8
TR UBLESH TING 9
TECHNICAL SPECIFICATI NS 10
PR DUCT GUARANTEE 11
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:32 Page 4

3
KN W Y UR MACHINE
1
15
14
13
16
12
Vacuum Cleaner
18 Pre motor filter
19 HEPA central filter
Filters (pre-assembled in product)
18 19
3
4
7
8
9
2
5
6
1
0
11
17
1 Crevice tool
2 Dirt bin carry handle
3 Extension tube
4 Carpet height adjuster
5 Hose
6 Dirt bin release button
7 HEPA central filter
8 Power cord
9 Dirt container
10 Cable clip
11 On/off pedal
12 Handle release pedal
13 2-in-1 tool (dusting brush & upholstery tool)
14 Upper hose storage/carry handle
15 ower hose storage
16 ower hose/tool connector
17 Upper cord wrap
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:32 Page 5

4
ASSEMBLY
Assembling your vacuum cleaner
12 3
45 6
78 9
10 11 12
13 14
NOTE: Do not over tighten screw.
!
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 6

5
PERATI N
Accessories
PERATI N
perating the appliance
SHORT PILE
CARPET
LONG PILE
CARPET
NOTE: Do not use this vacuum cleaner on hard floors. Intended for all carpet types only. Brushbar continually rotates when in upright position. Do not leave in
one place for extended period of time.
!
NOTE: The carpet height adjust must be set before reclining the machine.
!
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 7

6
MAINTENANCE
Cleaning the HEPA central filter
MAINTENANCE
Emptying the dirt container
NOTE: To obtain the best results, empty the dirt container regularly. When collected dust reaches “MAX” level and performance reduces it is necessary to
empty/clean the dirt container.
TAP
24hr
NOTE: Failure to keep filters clean will result in loss of performance.
!
!
WARNING: To reduce the risk of electric shock, turn the vacuum cleaner off and unplug from the electrical outlet before performing
maintenance/troubleshooting checks.
!
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 8

MAINTENANCE
Cleaning the pre motor filter
7
MAINTENANCE
Replacing the belt
TAP
24hr
NOTE: To re-attach the lid to the dirt container, align arrows as shown:
!
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 9

8
CLEARING BL CKAGES
Removing debris from the brushbar
Removing debris from the hose
NOTE: Disconnect the hose from the vacuum cleaner and remove any blockages found and then reconnect the hose securely.
!
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 10

9
TR UBLESH TING
PR BLEM P SSIBLE CAUSES S LUTI NS
There is an accessory
missing
1. A part(s) is missing from box 1. Check the ‘KNOW YOUR MACHINE’ page
of your instructions
The vacuum cleaner
does not switch on
1. The unit is not plugged into a mains socket
2. The power button on the unit has not
been depressed
3. The thermal motor cut out has been activated
4. There is no electricity to the power
socket
1. Ensure the plug is firmly in socket and
switched on
2. Depress the power switch on the unit
3 If the unit has cut out during use, disconnect
the unit from the wall socket, allow to cool for
one hour, clean the filters, empty bin/dust bag
and check the hose/accessories for blockages
4. Seek expert help from a qualified electrician
The vacuum cleaner won’t
pick up
1. The accessories are not correctly fitted
2. There are blockages in the hose/accessory
3. The dirt container/dust bag is full
4. The filters are blocked/clogged
5. The carpet height adjust slider setting is not
correct
6. The belt is broken/brushbar not rotating
1. Check hose/tools are correctly attached to the
machine/hose/tube; refer to ‘OPERATION’ section
2. Check the air paths of the hose/accessory are
not obstructed by blockages
3. Check dirt container/dust bag and if necessary
empty/replace
4. Frequently cleaning filters will maintain
performance; see ‘MAINTENANCE’ section
5. See ‘OPERATION’ section for correct carpet
height setting for your carpet
6. Disconnect the unit from the power supply,
remove the floor head cover and check the belt
has not detached from the motor spindle or that
the belt is not worn/damaged; see
‘MAINTENANCE’ section
Dust is escaping from the
vacuum cleaner
1. The filters/dust bag/dirt container are not
fitted correctly
2. The filters/dust bag are damaged.
1. See ‘ASSEMB Y’ and ‘MAINTENANCE’ sections.
2. If the filters/dust bag are damaged these will
need to be replaced
Accessories wont pick up
dust/debris
1. The wrong tool is fitted for the task
2. The tools are blocked
3. The filters are blocked
4. The dirt container/dust bag is full
5. The hose/tubes are blocked
1. See ‘KNOW YOUR MACHINE’ section
2. Check the air paths of the tools are not
obstructed by blockages
3. Frequently cleaning filters will maintain
performance; check ‘MAINTENANCE’ section
4. Check and empty the dirt container/replace
dust bag
5. Check the air paths of the hose/tubes are not
obstructed by blockages
The blockage indicator (if
applicable to model)
activates
1. The filters/dust bag/dirt container are blocked
2. The dust bag/dirt container is full
3. The accessories/hose/tube are blocked
1. Frequently cleaning filters will maintain
performance; check ‘MAINTENANCE’ section
2. Check and empty dirt container/replace dust
bag
3. Check the air paths of the accessories/hose/
tubes are not obstructed by blockages
For help, spares or assistance please call 0845 6042377
or visit www.bagsandfilters.com
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 11

10
TECHNICAL SPECIFICATI NS
Model number : BU-203
Voltage: 220-240V ~ 50Hz
Wattage: 1700W max.
EEC Statement of Compliance
Manufacturer/EEC importer: Hereby on our own responsibility, declare that the
BU-203 is manufactured in compliance with the following Directives:
Safety: 2006/95/EC Low Voltage Directive
EMC: 2004/108/EC Electromagnetic Compatibility Directive
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or
retailer for recycling advice.
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 12

PPRROODDUUCCTT GGUUAARRAANNTTEEEE
This products is guaranteed against manufacturing defects for a period of
Year
This product is guaranteed for twelve months from the date of original purchase.
Any defect that arises due to faulty materials or workmanship will either be
replaced, refunded or repaired free of charge where possible during this period by
the dealer from whom you purchased the unit.
The guarantee is subject to the following provisions:
- The guarantee does not cover accidental damage, misuse, cabinet parts,
knobs or consumable items.
- The product must be correctly installed and operated in accordance with
the instructions contained in this manual.
- It must be used solely for domestic purpose.
- The guarantee will be rendered invalid if the product is re-sold or has
been damaged by inexpert repair.
- Specifications are subject to change without notice.
- The manufacturer disclaims any liability for the incidental or consequential
damages.
- The guarantee is in addition to, and does not diminish your statutory or
legal rights.
Guarantor: Argos td
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
TECHNICAL SPECIFICATI NS
EEC Statement of Compliance
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 13

This page has been left intentionally blank. This page has been left intentionally blank.
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 14

This page has been left intentionally blank. This page has been left intentionally blank.
BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 15

BU-203 Guide (ame d Ja 2010).qxd:Value 13/1/10 14:33 Page 16
Table of contents
Other Bush Vacuum Cleaner manuals

Bush
Bush BC-501 User manual

Bush
Bush VCB35B15C-1J7W-70 User manual

Bush
Bush BU-204 User manual

Bush
Bush VCS35B15K0D-70 User manual

Bush
Bush VCS35B15K0D-70 User manual

Bush
Bush VCM40A16L0B-70 User manual

Bush
Bush V8211_03 User manual

Bush
Bush VHS01A17Z User manual

Bush
Bush BVC1401 User manual

Bush
Bush VCM40A16L0B-70 User manual
