Bushnell GOLF TOUR V6 SHIFT User manual

Model #: 202321, 202301 05-23
Android and Google Play are registered trademarks of Google Inc. in the
United States and other countries. iPhone and Apple Store are trademarks
of Apple Inc., registered in the U.S. and other countries. Other names may
be trademarks of their respective owners.
Scan the code to download
the Bushnell Golf Mobile app
and register your Tour V6 Laser
Rangender.

Click on each topic in the Table of Contents to go directly to it.
TABLE OF CONTENTS
INTRODUCTION 3
PARTS GUIDE 3
DISPLAY INDICATORS 3
ACTIVATING/REPLACING THE BATTERY 4
BATTERY LEVEL INDICATOR 4
BASIC OPERATION 4
ADJUSTING THE EYEPIECE 4
ACTIVE LASER 4
TOUR V6 SHIFT MODEL ONLY:
SLOPE SWITCH TECHNOLOGY 4
HOW TO USE SLOPE +/-™ 5
THE ADVANTAGE OF SLOPE +/-™ 5
DISTANCE UNITS (Y OR M) & JOLT PREVIEW 5
USING PINSEEKER™ WITH VISUAL JOLT® 5
BITE MAGNETIC MOUNT 6
CLEANING AND GENERAL CARE 6
TROUBLESHOOTING 6
TECHNICAL SPECIFICATIONS 7
LANGUAGES
FRANÇAIS 8
ESPAÑOL 13
DEUTSCH 18
ITALIANO 23
中国人 28
日本語 33
한국어 38
BAHASA INDONESIA 43
SVENSKA 48
DANSK 53
PORTUGUÊS 58

3
Click to Return to the Table of Contents
INTRODUCTION
Congratulations on purchasing your new Tour V6 Series Laser Rangefinder from Bushnell Golf. You are joining 98.6% of
Tour players that trust their games to Bushnell Golf. The Tour V6 Series is packed with new and upgraded features. We
have completely upgraded our electronic components, making the Tour V6 the most accurate, consistent, and fastest Tour
Series Laser ever. Along with all the upgraded electronics, your Tour V6 features PinSeeker with Visual JOLT, BITE magnetic
cart mount, and upgraded weatherproofing to IPX6.
WARNING: AS WITH ANY LASER DEVICE, IT IS NOT RECOMMENDED TO DIRECTLY VIEW THE EMISSIONS
FOR LONG PERIODS WITH MAGNIFIED LENSES.
PARTS GUIDE
1. Slope Switch (Shift model only)
2. Mode Button
3. Power/Fire Button
4. Eyepiece Diopter Dial
5. Battery Compartment
6. BITE Magnet (see inset photo)
6. BITE MAGNET
5
3
1
2
4
DISPLAY INDICATORS
The Tour V6 display incorporates the following indicators:
1. Aiming Circle (surrounding crosshairs indicate laser
transmission)
2. Distance Units (Yards/Meters)
3. Battery Level
4. “Play As” Distance, based on Slope (Shift model only)
5. Slope (% grade) (Shift model only)
6. Line of Sight Distance
7. Visual JOLT Indicator Ring
6
45
3
7
1
2

4Click to Return to the Table of Contents
ACTIVATING/REPLACING THE BATTERY
Please remove the battery door by lifting the battery door tab and rotating counterclockwise
until it is loose. Then, activate the installed CR2 3-volt lithium battery by removing the battery
door as described above. Next, remove the plastic protective disc from the top of the battery,
and replace the door.
Replacing a low battery: Insert a new CR2 3-volt lithium battery into the compartment negative
(flat) end first (positive end facing out towards the battery cover), then replace the battery door.
BATTERY LEVEL INDICATOR
The Battery Indicator (3) shows the remaining power level:
• Full charge
• Approx. 2/3 battery life remaining
• Approx. 1/3 battery Life remaining
• Battery Indicator Blinks - Battery needs replacing, and the unit will not be operable.
WARNING: THIS PRODUCT USES A LITHIUM BASED BATTERY. LITHIUM BATTERIES CAN OVERHEAT AND
CAUSE DAMAGE IF PHYSICALLY ABUSED. DO NOT USE BATTERIES THAT ARE DAMAGED OR SHOW SIGNS OF
PHYSICAL WEAR.
BASIC OPERATION
While looking through the Tour V6, depress the Power/Fire button once to activate the display. If the display icons and
numbers are blurry, rotate the eyepiece in either direction until they are in focus (see “Adjusting the Eyepiece” below).
1. Place the aiming circle (center of the display) over a target at least 5 yards away. Press and hold the Power/Fire button
until the “line of sight” distance displays near the bottom of the display (see “Display Indicators” below). Crosshairs
surrounding the aiming circle indicate that the laser is transmitted.
2. After a range is acquired and displayed, you can release the Power/Fire button. The crosshairs surrounding the aiming
circle will disappear once the Power/Fire button is released (i.e., the laser is no longer transmitting).
3. Once activated, the display will remain visible and display the last distance measurement for 10 seconds. Press the
Power/Fire button again to range to a new target. The maximum time the laser is transmitted (active) is 5 seconds. To
re-fire, press the button down again.
ADJUSTING THE EYEPIECE
The Tour V6 is equipped with an adjustable Fast Focus eyepiece (+/- 3.5 diopter adjustment) that allows you to focus
the displayed data and icons relative to the viewed image from the monocular optics. Rotate the eyepiece until the
display is in focus.
ACTIVE LASER
Crosshairs surrounding the aiming circle indicate that the laser is transmitted. Once a range is acquired, you can
release the Power/Fire button. The crosshairs surrounding the circle will disappear once the Power/Fire button is
released (i.e., the laser is not transmitting).
SLOPE SWITCH TECHNOLOGY (TOUR V6 SHIFT ONLY)
Slope-Switch Technology lets the golfer easily turn Bushnell’s patented Slope
function on and off. The switch allows the golfer to conveniently utilize Slope
to get compensated distances around the course when they want it and have
a USGA conforming device that is legal for tournament play when they need
it.
Slope mode is enabled by sliding the Slope Switch on the side of the Tour
V6 Shift (model# 202321) to the left so the orange Slope indicator is visible
(see photo, right) and Bushnell’s patented Slope Technology is displayed. The Slope +/- mode will automatically compute
an angle compensated range based on distance and Slope determined by the laser rangefinder and built-in inclinometer.
This data is combined with internal algorithmic formulas dealing with average club use and ball trajectories. The angle
compensated range provides direction on how to play the shot (i.e., add distance if an incline, subtract distance if a
decline). Slide the Slope Switch right, and the Tour V6 now conforms to USGA Rule 14-3, with the Slope compensated
ranging feature removed.
Positive (+)
end facing out
Slope Off Slope On

5
Click to Return to the Table of Contents
HOW TO USE SLOPE +/-™ (TOUR V6 SHIFT ONLY)
Move the Slope switch to the “Slope On” position. A second row of information appears in the display, confirming that
you are now in slope mode. Next, press the Power/Fire button to obtain the distance to the flag or other objects. Once
the range is displayed, release the Power/Fire button. Once the Power/Fire button is released, the grade percentage and
compensated range will be displayed beneath the standard distance in the second row of numbers.
For example, if the true distance is 160 yards, but with a slope of +6 percent, the Slope compensated
(“play-as”) range is 168 yards. The display would show this (right):
THE ADVANTAGE OF SLOPE +/-™ (TOUR V6 SHIFT ONLY)
The distance to the black flag in the drawing (see below) is 160 yards. It is also 160 yards to the red flag, although it is on a
slope with a 6% grade (uphill incline). However, if a golfer were to play this hole as 160 yards, the ball (X) would fall short
of the hole/flag if slope was not taken into account. Therefore, due to the slope, it should be played as a 168 yard shot.
This distance displays the “play as” distance below the line of sight distance.
160 YARDS
160 YARDS
X
6%
SETTING DISTANCE UNITS (Y OR M) & JOLT PREVIEW
To set the distance between Yards or Meters, press Fire/Power to turn the unit on, then press and hold the Mode button
until the display blinks. Press the Mode to switch from Y (yards) or M (meters). Press Fire/Power button to set the distance
units.
This action initiates JOLT (vibration and visual ring in display), allowing you to preview/demo the effect of JOLT Technology
without requiring you to fire the laser at a target.
USING PINSEEKER™ WITH VISUAL JOLT®
Bushnell’s exclusive Pinseeker™ feature allows reliable flag targeting without inadvertently getting distances to large
background targets (i.e., trees, club houses, etc.) with stronger signal strength.
When ranging your target, if the laser beam recognizes more than one object (i.e., the flag and a group of trees behind
it), only the distance to the closest object (the flag) will be displayed. The JOLT Technology provides two short bursts of
vibration to confirm that the distance displayed is to the flag, and the red ring (Visual JOLT Indicator) around the outer
edge of the display is activated, confirming the laser has ranged the correct target via Pinseeker.
Occasionally, the laser will only see one object in its path. In this instance, JOLT will not signal.
Tip: While pressing the Power/Fire button, you can move the device slowly from object to object and intentionally force the laser to hit
multiple objects to ensure that you are only displaying the closest of the objects recognized by the laser. Once the device has shut off,
the unit will always default to the last mode used.

6Click to Return to the Table of Contents
BITE MAGNETIC MOUNT
The Tour V6 features a powerful BITE magnet incorporated into the right side of
its housing, which allows the device to be securely attached to a golf cart bar or
frame. Be sure to attach the rangefinder to the cart frame with the eyepiece at the
one o’clock position. This positioning will ensure the magnet is properly aligned and
engaged with the cart bar.
WARNING: THE BITE FEATURE INCLUDED WITH THE DEVICE CONTAINS A
NEODYMIUM MAGNET. MAGNETS COULD AFFECT THE FUNCTIONING
OF PACEMAKERS AND IMPLANTED HEART DEFIBRILLATORS. IF YOU USE
THESE DEVICES, KEEP A SUFFICIENT DISTANCE FROM THE MAGNET.
ALSO, WARN OTHERS WHO WEAR THESE DEVICES FROM GETTING TOO
CLOSE TO MAGNETS.
• A magnet may permanently lose part of its adhesive force if exposed to
temperatures above 175º F (80ºC).
• Magnets produce a far-reaching, strong magnetic field. They could damage
TVs, laptops, computer hard drives, credit and ATM cards, data storage media,
mechanical watches, hearing aids, and speakers. Keep the unit away from
devices and objects that strong magnetic fields could damage.
• Magnets have strong magnetic fields which can pinch skin and fingers. So use
caution when attaching the unit to a metal bar.
CLEANING AND GENERAL CARE
Your Bushnell Tour V6 laser rangefinder lenses are fully multi-coated for the highest light transmission. However, as with
multi-coated optics, take special care to clean the lenses. Follow these tips for proper lens cleaning:
• Blow away any dust or debris on the lens (or use a soft lens brush).
• To remove dirt or fingerprints, clean with the supplied microfiber cloth rubbing in a circular motion. Using a coarse
cloth or unnecessary rubbing may scratch the lens surface and cause permanent damage. The included washable
microfiber cleaning cloth is ideal for cleaning your optics. First, breathe lightly on the lens to provide slight moisture,
then gently rub the lens with the microfiber cloth.
• For a more thorough cleaning, photographic lens tissue and photographic-type lens cleaning fluid or isopropyl alcohol
may be used. Always apply the fluid to the cleaning cloth – never directly on the lens.
• The rangefinder is water resistant but should not be exposed to heavy rain or other direct streams of water and will not
withstand submersion in water or other liquids.
CAUTION: Use caution to avoid direct sunlight into the eyepiece to prevent damage to the display/internal components. When
using the BITE magnet to attach the device to a cart bar or frame, tilt the device so the eyepiece aims towards the ground, not
pointed upwards towards the sun. When you are not using the device, please store it in the case for additional protection.
TROUBLESHOOTING
NEVER DISASSEMBLE YOUR LASER RANGEFINDER. IRREPARABLE DAMAGE CAN RESULT FROM UNAUTHORIZED
SERVICE ATTEMPTS, VOIDING THE WARRANTY.
If the unit does not turn on or the display does not illuminate:
• Depress Power/Fire button.
• Check and, if necessary, replace the battery. If the unit does not respond to button presses, replace the battery with a
good quality CR2 3-volt Lithium battery.
If the unit powers down (the display goes blank when attempting to power the laser):
• The battery is either weak or low quality. Replace the battery with a new 3-volt lithium battery (CR2).
If target range cannot be obtained:
• Ensure the display is illuminated.
• Make sure that the Power/Fire button is being depressed.
• Ensure that nothing, such as your hand or finger, is blocking the objective lenses (lenses closest to the target) that emit
and receive the laser pulses.
• Make sure the unit holds steady while depressing the Power/Fire button.
NOTE: The last range reading does not need to be cleared before ranging another target. Aim at the new target using the display
reticle, depress the Power/Fire button, and hold until the new range reading is displayed.
Cart
Frame
BITE MAGNET

7
Click to Return to the Table of Contents
TECHNICAL SPECIFICATIONS
Dimensions 4.5 x 3.07 x 1.61 in (114 x 78 x 41 mm)
Weight Tour V6 - 8.5 oz (241 g) Tour V6 Shift - 8.7 oz (246 g)
Ranging Accuracy Accurate to +/- 1 yd to 500 yds
Range 5–1300 Yards / 5–1189 Meters
Magnification 6x
Objective Diameter 24 mm
Display LCD w/illuminated Jolt indicator ring
Power Source 3-volt lithium (CR-2)
Field Of View 330 ft. @ 1000 yards / 110 meters @ 1000 meters
Extra Long Eye Relief 16 mm
Exit Pupil 4 mm
Included Items Premium Carrying Case and CR2 Battery
Disposal of Electric and Electronic Equipment
(Applicable in the EU and other European countries with separate collection systems)
This equipment contains electric and/or electronic parts and must therefore not be disposed
of as normal household waste. Instead, it should be disposed at the respective collection
points for recycling provided by the communities. For you, this is free of charge.
If the equipment contains exchangeable (rechargeable) batteries, these too must be removed
before and, if necessary, in turn be disposed of according to the relevant regulations (see also
the respective comments in this unit’s instructions).
Further information about the subject is available at your community administration, your local waste collection
company, or in the store where you purchased this equipment.
FDA SAFETY
Complies with 21CFR1040.10 and 1040.11 except for conformance with IEC60825-1 Ed.3., as described in Laser
Notice 56, dated May 8, 2019.
Caution: There are no user controls, adjustments or procedures. Performance of procedures other than those
specied herein may result in access to invisible laser light.
This product contains no user serviceable controls.
This product must not be opened or modied by the consumer.
This product must be returned to the manufacturer for service.
Device specications and design are subject to change without notice
or obligation on the part of the manufacturer.
Industry Canada Statement/Déclaration d'Industrie Canada :
This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d’ ISED applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage
préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de
provoquer un fonctionnement indésirable.
Radiation Exposure Statement / Déclaration d’exposition aux radiations :
This device complies with the Industry Canada portable RF exposure limit set forth for an uncontrolled
environment and is safe for the intended operation as described in this manual. Further RF exposure reduction
can be achieved if the product can be kept as far as possible from the user’s body or if the device is set to a lower
output power if such function is available.
Le produit est conforme aux limites d’exposition pour les appareils portables RF pour les Etats-Unis et le Canada
établies pour un environnement non contrôlé.
Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La réduction aux expositions RF
peut être augmentée si l’appareil peut être conservé aussi loin que possible du corps de l’utilisateur ou que le
dispositif est réglé sur la puissance de sortie la plus faible si une telle fonction est disponible.
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installedand used in accordancewiththe instructions, may cause harmfulinterferencetoradiocommunications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The device does not contain any user-serviceable parts. Repairs should only be made by an Authorized Bushnell
Repair center. Unauthorized repairs or modifications could result in permanent damage to the equipment, and
will void warranty and your authority to operate the device under Part 15 regulations.
Specificationsand design are subject to change without anynoticeorobligationon the part of the manufacturer.
©2023 Bushnell Outdoor Products
Bushnell,™, ®, denote trademarks of Bushnell Outdoor Products
www.bushnell.com
9200 Cody, Overland Park, KS 66214
Made in China
http://bushnellgolf.com/patents
WARNING: AS WITH ANY LASER DEVICE, IT IS NOT RECCOMENDED TO DIRECTLY VIEW THE
EMISSIONS FOR LONG PERIODS OFTIME WITH A MAGNIFIED LENS.
CLASS 1 LASER PRODUCT
EN/IEC 60825-1 2014
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions:
(1)This device may not cause interference.
(2)This device must accept any interference, including interference that may cause undesired operation of
the device.
Warning: Changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
CAN ICES-3B/NMB-3B
