Bushnell Edge Disc Golf Rangefinder User manual

Model #: DG850SBL 421
OWNER’S GUIDE
DISC GOLF RANGEFINDER
EDGE™

2
Thank you for purchasing your new Bushnell® Edge Disc Golf Rangender.
This manual will help you optimize your viewing experience by explaining how to utilize the rangender’s features
and how to care for it. Read the instructions carefully before using your rangender.
WARNING: As with any laser device, it is not recommended to directly view the emissions for long periods of time
with magnied lenses.
INTRODUCTION
Your Bushnell® Edge is an ultra-compact, premium laser rangender with the latest Digital Technology, providing precise
range readings from 15-2,550 feet (4.6-777 meters). Measuring 1.3 x 4.2 x 2.9 inches, the 6-ounce Edge delivers high-
speed target acquisition, with +/- 3 feet accuracy to the maximum range. The Edge Disc Golf Rangender features
Bushnell’s Z-Mode Height Measurement, a new Ranging Engine for faster, more consistent response and readings, a Vivid
LCD display with higher light transmission, and water-resistant (IPX4) construction.
*Note: You will get both longer and shorter maximum distances depending on the reective properties of the particular
target and the environmental conditions at the time the distance of an object is being measured. The color, surface nish,
size, and shape of the target all affect reectivity and range. The brighter the color, the longer the range. White is highly
reective, for example, and allows longer ranges than the color black, which is the least reective color. A shiny nish
provides more range than a dull one. A small target is more difcult to range than a larger target. The angle to the target
also affects. Shooting to a target at a 70-degree angle (where the target surface is perpendicular to the ight path of the
emitted energy pulses) provides a good range. In contrast, a steep angle, on the other hand, provides limited ranging. Also,
lighting conditions (e.g., the amount of sunlight) will affect the ranging capabilities of the unit—the less light (e.g., overcast
skies), the farther the unit’s maximum range. Conversely, very sunny days will decrease the unit’s maximum range.
HOW OUR DIGITAL TECHNOLOGY WORKS
The Edge Disc Golf Rangender emits invisible, eye-safe, infrared energy pulses. The Edge Rangender’s microprocessor
results in instantaneous and accurate readings every time. Sophisticated digital technology instantaneously calculates
distances by measuring the time it takes for each pulse to travel from the rangender to the target and back.
BATTERY ACTIVATION / BATTERY LIFE INDICATOR
Before rst use: Remove the battery compartment cover by lifting the battery cover tab and then
rotating the cover counter-clockwise. Remove and discard the “Remove Battery Disk” sticker
covering the positive battery terminal, then replace the battery cover. NOTE: It is recommended
that the CR2 3-volt lithium battery be replaced at least once every 12 months. Please insert it into
the negative end into the compartment rst.
PARTS GUIDE
LASER TRANSMIT/RECEIVE LENS
POWER/FIRE BUTTON
MONOCULAR EYEPIECE
BATTERY COMPARTMENT
MONOCULAR
OBJECTIVE LENS

3
7b
2
1
3
4
5
7a
6
Battery Level Indicator Icon (1):
Full charge
3/4 battery level remaining
1/2 battery level remaining
1/4 battery level remaining
Battery icon blinks - battery needs to be replaced, and the unit will not be operable.
BASIC OPERATION
While looking through the laser rangender, press and release the Power/Fire button to activate the display.
If the display appears blurry, rotate the rubber eyecup/diopter adjustment in either direction until the display is sharp for
your vision.
Placing the aiming circle (located in the center of the display) on a target at least 5-6 meters away, depress and hold the
Fire button down until the range reading is displayed below the aiming circle.
Once a range has been acquired, you can release the Fire button. The four “crosshairs” just outside the aiming circle
will go out, indicating the laser is no longer being transmitted. The display will remain on and display the last distance
measurement for about 15 seconds until the display automatically switches off to extend battery life.
You can press the Fire button again at any time to check the range to a new target. To re-re, press the button again.
To scan the laser across an area and get continuously updated range readings, continue to hold the Fire button down and
sweep the rangender over multiple targets. The crosshairs outside the aiming circle will ash to indicate scan operation.
DISPLAY INDICATORS/ICONS
The Edge Rangender’s display incorporates the following illuminated indicators:
Battery Level Indicator (1)
Aiming Circle/Dot (2)
Active/Scan Laser Indicator (3)
Standard “Line of Sight” Distance (4)
Distance Units Indicators (5): M=Meters (blank if Feet)
Angle Indicator-incline in degrees (6)
Height Measurement (7a) / FEEt (Feet) Distance Units Indicator
(during setup only) (7b)
SELECTING UNITS OF MEASURE (METERS/FEET)
The Edge Disc Golf rangender measures distance in meters or feet. The unit of measure indicators for Meters (5) is
located to the right of the Standard “Line of Sight” Distance (4). If “M” (5) highlighted when ranging, distances are in Feet
(default).
To select a different unit of measure, start with the unit powered off. Press and continue to hold the Fire button. “M” or
“FEEt” will begin ashing, with the display slowly cycling through these two unit options (5,7b). Release the Fire button
when your desired display units are ashing. To select a different unit of measure, repeat this process.
AUTOMATIC SCAN
To use the Automatic SCAN feature, press and hold the Fire button, then move the rangender from object to object
while keeping the Fire button depressed. Automatic SCAN will cause the standard line of sight distance readout (4) to be
continuously updated as multiple objects are targeted. The Active/Scan indicator lines (3) ash while scanning.
Z-MODE HEIGHT MEASUREMENT
Z-Mode displays the elevation of the target relative to where you are
ranging from. This can help with elevated baskets or large uphill or downhill
shots that can be tough to visually gauge.
RANGING TO BASKET
35 ft
312 ft DISTANCE
VERTICLE
ELEVATION

4
CLEANING AND GENERAL CARE
The lenses of your Bushnell Edge Disc Golf Rangender are multi-coated for the highest light transmission. As with any
multi-coated optics, special care must be taken in cleaning the lenses. Follow these tips for proper lens cleaning:
Blow away any dust or debris on the lens (or use a soft lens brush).
To remove dirt or ngerprints, clean with the supplied microber cloth rubbing in a circular motion. Use of coarse cloth
or unnecessary rubbing may scratch the lens surface and eventually cause permanent damage. The included washable
microber cleaning cloth is ideal for the routine cleaning of your optics. Breathe lightly on the lens to provide a slight
amount of moisture, then gently rub the lens with the microber cloth.
For a more thorough cleaning, photographic lens tissue and photographic-type lens cleaning uid or isopropyl alcohol
may be used. Always apply the liquid to the cleaning cloth – never directly on the lens.
The rangender is manufactured and tested to withstand water exposure up to IPX4 standards. It is water-resistant but
should not be submerged.
TROUBLESHOOTING
Never disassemble your laser rangender. Irreparable damage can result from unauthorized service attempts, which also
void the warranty.
If the unit does not turn on, the display does not illuminate:
• Depress Power/Fire button.
• Check and, if necessary, replace the battery. If the unit does not respond to button presses, replace the battery with a
good quality CR2 3-volt Lithium battery.
If unit powers down (display goes blank when attempting to power the laser):
• The battery is either weak or low quality. Replace the battery with a new 3 -volt lithium battery (CR2).
If target range cannot be obtained:
• Make sure the display is illuminated.
• Make sure that the Power/Fire button is being depressed.
• Ensure that nothing, such as your hand or nger, is blocking the lenses at the front of the rangender that emits and
receive the laser pulses.
• Make sure the unit is being held steady while depressing the Power/Fire button.
NOTE: The last range reading does not need to be cleared before ranging another target. Aim at the new target using the
display reticle, depress the power button, and hold until new range reading is displayed.
SKU
Mag x Obj Lens Diam.
Max Range (F/M)
(Disc Golf Basket)
Ranging Accuracy
Optical Coatings
Length (in/mm)
Weight (oz /g)
DG850SBL 6x 24mm 900/275 +/- 3 ft Multicoated 4.3/110 6.3/180
Technical Specications

5
WARNING: This product uses a Lithium based battery. Lithium batteries can overheat and cause
damage if physically abused. Do not use batteries that are damaged or show signs of physical wear.
COVERAGE YOU CAN COUNT ON
All Bushnell products are engineered to deliver to your expectation and manufactured to withstand the rigors of the outdoors
for the lifetime of the product. In the event that our product fails you, we will stand behind it and repair it at no cost to you.
If we can’t repair it then we will replace it with a product of equal or better value. No receipt required and fully transferable.
All Bushnell® products carry a product lifetime warranty against defects in workmanship or materials. Product lifetime is
dened as 30 years for riescopes, 20 years for binoculars and spotters, 5 years for electro-optics and electronic components
(laser rangenders, red dot sights, reex sights, speed gun radars, night vision) and 2 years for trail cams. This warranty does
not cover Bushnell Golf, please click here to view Bushnell Golf product warranty information. Coverage period start date
is determined by proof of purchase or manufacturing date of the product. This warranty does not cover cosmetic damage;
damage caused by failing to properly maintain the product; loss; theft; damage as a result of unauthorized repair, modication,
or disassembly; intentional damage, misuses, or abuse. This Warranty will be void if the date stamp or other serialization codes
have been removed from the Product. We may replace your product with a product of equal or better physical condition.
To view the full warranty and download the details of the warranty, click this link: https://www.bushnell.com/bu-warranty.html
To submit a repair request or check the status of a repair ticket: https://service.bushnell.com/s/
For more information or questions regarding warranty, call toll free in the US: 1-800-423-3537 or Canada: [phone]
For products purchased outside the United States or Canada, please contact your local dealer for applicable warranty
information.
©2020 Bushnell Outdoor Products
