LED DRIVING LIGHTS
LED D
RIVING LIGHTS
OWNERS MANUAL
NHX230 VBP - VCT - VLI |NHX180VLI

Congratulations! on your purchase of the Night Hawk® Variable Series LED Driving
Lights by Bushranger 4X4. To take full advantage of this product, please read
this manual carefully before using. Retain this manual for future reference for
installation and warranty.
Register Your Product
Overview
ModelSpecicFeatures
VariableSeriesDrivingLightFeatures
Speci cations
NHX230VBP | 9” Variable Beam Pattern
NHX230VCT | 9” Variable Colour Temperature
NHX230VLI | 9” Variable Light Intensity
NHX180VLI | 7” Variable Light Intensity
Components
NHX230 | Components Diagram
NHX180 | Components Diagram
Installation
Care and Maintenance
CoverFittingandRemoval
Warranty Policy
Contents
03
04
05
09
13
17
21
22
23
25
25
26

Variable Beam Pattern |NXH230VBP
Variable Colour Temperature | NHX230VCT
Variable Light Intensity | NHX230VLI - NHX180VLI
• 36 genuine high performance CREE LED’s.
• Electronically controlled Beam Pattern and Light Intensity settings.
• 8Beamsettings,fromfullspottofullood.
• 8 Light Intensity settings, from 0% to 100%.
• Beam and Intensity settings are controlled with a backlit dual dial controller.
• Supplied with optional protective covers.
• 36 genuine high performance CREE LED’s.
• Electronically controlled Colour Temperature and Light Intensity settings.
• 8 Colour settings, from warm white to day white (3000K - 6000K).
• 8 Light Intensity settings, from 0% to 100%
• Colour and Intensity settings controlled with a backlit dual dial controller.
• Suppliedwithoptionalspotandoodprotectivecovers.
• Available in both 7” and 9” sizes.
• 37 (9”) or 19 (7”) genuine high performance OSRAM LED’s.
• Electronically controlled Light Intensity settings.
• 8 Light Intensity settings from 0% to 100%.
• Intensity settings controlled with a single dial controller.
• Suppliedwithoptionalspotandoodprotectivecovers.
Built Tough
• Pressure die-cast aluminium housing and strong, 4mm thick stainless steel brackets
will handle even the toughest tracks.
• Designed, engineered and extensively tested in Australia.
• Vibration tested to SAE J575 - Shock/Vibration Standards
Durable Exterior
• Hard Coated polycarbonate lens offers long term scratch resistance ensuring
maximumopticalefciencyforyearstocome.
• UV stable AkzoNobel Powder coat, polycarbonate lens and protective covers
ensure long term durability in the harsh Australian environment.
Sealed Tight
• Waterproof and submersible, IP67 & IP69K rated.
• Genuine GORE breather manages the internal air pressure of the light, preventing
water ingress in all conditions.
Versatile Installation
• Uniqueshapeandlowproledesignallowsfordiversetmentswhereregularround
lights may not suit.
Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 0403
The Night Hawk Variable Series LED Driving Lights by Bushranger 4X4 have been
developed from the ground up by our team of engineers to offer a truly unique design
that takes performance, aesthetics and usability to a whole new level. They lead the
way with simple, plug and play installation and an advanced control system that offers
greater control and reliability over traditional on/off relay-based lighting systems.
The three variations offered in the Variable Series line-up unlock more options to suit
the driver’s individual needs when tackling their next adventure. We have put user-
controlled lighting at the forefront of our development, and the ability to choose the
optimum settings to suit an individual’s visual preference or the environment, plus
changeonthey,setstheselightsapartfromtherest.Thisishighperformancelighting
that is adaptable to suit you and your needs.
Control the night.
Overview
Model Specic Features
Superior Cooling Design
• Large air intakes channel cool air over the heatsink for unmatched cooling
High Performance Genuine LED’s
• Genuine high output CREE or OSRAM LED’s for unmatched performance
• Tested by an Australian NATA accredited photometry lab to produce real
light performance data
Active Temperature Control System
• Intelligent onboard monitoring of the LED temperatures, combined with the
superior cooling design allows for maximum output in all conditions.
Modern Electronics Design
• BuiltinTransistorswitchingsimplieswiringinstallationbyremovingtheneedfor
traditional 12V relay switching.
• PWM output provides complete control at the turn of the dial.
• Over voltage and Reverse Polarity Protection.
Variable Series Driving Light Features

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 0605
Power
Current Draw
Voltage Range
Luminous Flux
LED Type
LED Colour Temperature
Power Plug
Control Plug
Fitted Weight
Compliance
170W
11.9A @14.4V
10-30V DC
10,800(effective)withoutprotectivecoverstted
36 x Genuine CREE LED’s
5700k (72 CRI)
Deutsch DTP
4 pin round
3.2kg
CE, UNECE R10, IP67 & IP69K, RoHS, SAE J575 - Shock/
Vibration
SPECIFICATIONS|NHX230VBP
Variable Beam Pattern | 9” Driving Light
SINGLE LIGHT SPECIFICATIONS
230 mm
224mm
94mm 58mm
102 mm
NHX230VBP |SPECIFICATIONS
Voltage Range
Controller
Light Intensity Control
Beam Pattern Control
Light Capacity (as supplied)
Light Capacity (max)
10 - 30V DC
Backlit with two rotary control dials & mounting cradle
8 x Brightness settings (0% - 100%)
8xBeampatternsettings(Spot-Flood)
Connect and control 2 x VBP Series lights
simultaneously
Connect and control 4 x VBP Series lights
simultaneously (additional lights and control leads sold seperately)
VBP WIRING SYSTEM SPECIFICATIONS
32.5mm
80.7
mm
48.2
mm

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 0807
SPECIFICATIONS|NHX230VBP
Allresultsshownbelowareobtainedfromrealscientictestingcarriedoutby
a NATA Accredited Photometric Laboratory in Australia. Measurements displayed
with optional clear protective covers tted.
VBP FULL FLOOD SETTING
VBP FULL SPOT SETTING
Isolux Data (Pair of Lights)
VBP COMBO SETTING
NHX230VBP |SPECIFICATIONS
OPTIONAL PROTECTIVE COVERS FITTED
Max distance @ 1 lux 857m
68m 117m 150m
661m 469m
Max width @ 1 lux
Full Spot Combo (Setting 4) Full Flood
Beam Pattern
OPTIONAL PROTECTIVE COVERS REMOVED
Max distance @ 1 lux 939m
75m 128m 164m
724m 512m
Max width @ 1 lux
Full Spot Combo (Setting 4) Full Flood
Beam Pattern
Light Performance (Pair of Lights)

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 1009
SPECIFICATIONS|NHX230VCT
Variable Colour Temperature | 9” Driving Light
170W
11.9A @14.4V
10-30V DC
11,400(effective)withoutprotectivecoverstted
36 x Genuine CREE LED’s
3000K (82 CRI) & 6000K (72 CRI)
Deutsch DTP
4 pin round
3.2kg
CE, UNECE R10, IP67 & IP69K, RoHS, SAE J575 -
Shock/Vibration
SINGLE LIGHT SPECIFICATIONS
Power
Current Draw
Voltage Range
Luminous Flux
LED Type
LED Colour Temperature
Power Plug
Control Plug
Fitted Weight
Compliance
230 mm
224mm
94mm 58mm
102 mm
NHX230VCT |SPECIFICATIONS
Voltage Range
Controller
Light Intensity Control
Colour Temperature Control
Light Capacity (as supplied)
Light Capacity (max)
10 - 30V DC
Backlit with two rotary control dials & mounting cradle
8 x brightness settings (0% - 100%)
8 x colour temperature settings (3000K - 6000K)
Connect and control 2 x VCT Series lights
simultaneously
Connect and control 4 x VCT Series lights
simultaneously (additional lights and control leads sold seperately)
VCT WIRING SYSTEM SPECIFICATIONS
32.5
mm
80.7
mm
48.2 mm

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 1211
SPECIFICATIONS|NHX230VCT
Allresultsshownbelowareobtainedfromrealscientictestingcarriedoutby
a NATA Accredited Photometric Laboratory in Australia. Measurements displayed
with optional clear protective covers tted.
VCT WITH FLOOD COVERS
VCT WITH SPOT COVERS
Isolux Data (Pair of Lights)
VCT WITH 1X SPOT & 1X FLOOD COVER
NHX230VCT |SPECIFICATIONS
6000K TEMPERATURE SETTING
Max distance @ 1 lux
74m 150m
900m 506m
Max width @ 1 lux
Optional Protective
Covers
113m
719m
+
3000K TEMPERATURE SETTING
Max distance @ 1 lux
72m 149m
888m 501m
Max width @ 1 lux
Spot
Covers
Flood
Covers
112m
709m
+
Light Performance (Pair of Lights)
974m
80m
Covers
Removed
960m
78m
Covers
Removed
Spot
Covers
Flood
Covers
1 Flood Cover
1 Spot Cover
Optional Protective
Covers
1 Flood Cover
1 Spot Cover

80.7
mm
32.5
mm
48.2 mm
Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 1413
SPECIFICATIONS|NHX230VLI
Variable Light Intensity | 9” Driving Light
175W
12.2A @14.4V
10-30V DC
13,700(effective)withoutprotectivecoverstted
37 x Genuine OSRAM LED’s
5700K (72 CRI)
Deutsch DTP
4 pin round
3.2kg
CE, UNECE R10, IP67 & IP69K, RoHS, SAE J575 -
Shock/Vibration
SINGLE LIGHT SPECIFICATIONS
Power
Current Draw
Voltage Range
Luminous Flux
LED Type
LED Colour Temperature
Power Plug
Control Plug
Fitted Weight
Compliance
230 mm
224mm
94mm 58mm
102 mm
NHX230VLI |SPECIFICATIONS
Voltage Range
Controller
Light Intensity Control
Light Capacity (as supplied)
Light Capacity (max)
10 - 30V DC
Single rotary control dial & mounting cradle
8 x Brightness settings (0% - 100%)
Connect and control 2 x VLI Series lights simultaneously
Connect and control 4 x VLI Series lights simultaneously
(additional lights and control leads sold seperately)
VLI WIRING SYSTEM SPECIFICATIONS

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 1615
SPECIFICATIONS|NHX230VLI
VLI 9” WITH FLOOD COVERS
VLI 9” WITH SPOT COVERS
Isolux Data (Pair of Lights)
VLI 9” WITH 1X SPOT & 1X FLOOD COVER
NHX230VLI |SPECIFICATIONS
HIGHEST INTENSITY SETTING
Max distance @ 1 lux 1486m
86m 79m 200m
1362m 636m
Max width @ 1 lux
Spot
Covers
Flood
Covers
Optional Protective
Covers
147m
1035m
Light Performance (Pair of Lights)
Covers
Removed
Allresultsshownbelowareobtainedfromrealscientictestingcarriedoutby
a NATA Accredited Photometric Laboratory in Australia. Measurements displayed
with optional clear protective covers tted. +
1 Flood Cover
1 Spot Cover

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 1817
SPECIFICATIONS|NHX180VLI
Variable Light Intensity | 7” Driving Light
85W
5.9A @14.4V
10-30V DC
6,450 (effective) withprotectivecoverstted
19 x Genuine OSRAM LED’s
5700K (72 CRI)
Deutsch DT
4 pin round
1.7kg
CE, UNECE R10, IP67 & IP69K, RoHS, SAE J575 -
Shock/Vibration
SINGLE LIGHT SPECIFICATIONS
Power
Current Draw
Voltage Range
Luminous Flux
LED Type
LED Colour Temperature
Power Plugs
Control Plugs
Fitted Weight
Compliance
180 mm
178 mm
69 mm
44 mm
77
mm
85 mm
NHX180VLI |SPECIFICATIONS
Voltage Range
Controller
Light Intensity Control
Light Capacity (as supplied)
Light Capacity (max)
10 - 30V DC
Single rotary control dial & mounting cradle
8 x Brightness settings (0% - 100%)
Connect and control 2 x VLI Series lights simultaneously
Connect and control 4 x VLI Series lights simultaneously
(additional lights and control leads sold seperately)
VLI WIRING SYSTEM SPECIFICATIONS
80.7
mm
32.5
mm
48.2 mm

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 2019
SPECIFICATIONS|NHX180VLI
VLI 7” WITH FLOOD COVERS
VLI 7” WITH SPOT COVERS
Isolux Data (Pair of Lights)
VLI 7” WITH 1X SPOT & 1X FLOOD COVER
NHX180VLI |SPECIFICATIONS
HIGHEST INTENSITY SETTING
Max distance @ 1 lux
60m 110m
967m 748m
Max width @ 1 lux
Spot
Covers
Flood
Covers
Optional Protective
Covers
153m
498m
Light Performance (Pair of Lights)
Allresultsshownbelowareobtainedfromrealscientictestingcarriedoutby
a NATA Accredited Photometric Laboratory in Australia. Measurements displayed
with optional clear protective covers tted.
+
1 Flood Cover
1 Spot Cover

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 2221
COMPONENTS
Components Diagram - NHX230 9” Single Light
Item# Component Name Qty
1 NHX230 Driving Light 1
2Cover(1xSpot,1xFlood)* 2
3 Mounting Bracket 1
4 Side Plate (1 x Left, 1 x Right) 2
5 Side Rubber Isolator 2
6 Bottom Rubber Isolator 1
7 M8 x 30mm Cup Head Bolt 2
8M8FlatWasher 2
9 M8 Spring Washer 2
10 M8 Nut 2
Item# Component Name Qty
11 M8 x 30mm Button Head Bolt 4
12 M8 Nyloc Nut 4
13 M12 x 35mm Cup Head Bolt 1
14 M12FlatWasher 1
15 M12 Spring Washer 1
16 M12 Nut 1
17 Power Lead 2.5m with 20A
fuse (not shown)
1
18 Anti-Seize Lubricant Sachet
(not shown)
1
19 Dielectric Grease Sachet
(not shown)
1
*VBPdrivinglightsuppliedwith1xSpotCoverperlight.
2
2x
1
1x
3
1x
4
2x
5
2x
6
1x
7
2x
13
1x
11
4x
12
4x
8
2x
9
2x
10
2x
14
1x
15
1x
16
1x
SPOT COVER
FLOOD COVER
COMPONENTS
Components Diagram - NHX180 7” Single Light
Item# Component Name Qty
1 NHX180 Driving Light 1
2Cover(1xSpot,1xFlood) 2
3 Mounting Bracket 1
4 Bottom Rubber Isolator 1
5 Side Plate (1 x Left, 1 x Right) 2
6 Side Rubber Isolator 2
7 M6 x 25mm Button Head Bolt 4
8 M6 Nyloc Nut 4
9 M10 x 30mm Cup Head Bolt 1
Item# Component Name Qty
10 M10FlatWasher 1
11 M10 Spring Washer 1
12 M10 Nut 1
13 Power Lead 2.5m with fuse
(Not Shown)
1
14 Anti-Seize Lubricant Sachet
(not shown)
1
15 Dielectric Grease Sachet
(not shown)
1
1
1x
2
2x
3
1x
5
2x
6
2x
4
1x
9
1x
10
1x
11
1x
12
1x
7
4x
8
4x
SPOT COVER
FLOOD COVER

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 2423
• Werecommendthelights/wiringtobettedbyaqualiedautomotiveelectrician.
• A forward facing light system may be used only as an auxiliary to high beam. Check
compliance and regulations with local authorities.
• Vehicle accessories mounted on the outside of the vehicle may need to comply with
regulations governed by your local state authority. Please check before installation.
• When mounting lights, position them appropriately so they do not obstruct existing
automotivefunction.Ifttingtofrontofvehicle,checkforbonnetclearances.
• Considerationshouldbegivenforairowrequirementsofthevehicleandits
mechanical components when mounting lights.
• All stainless steel hardware must have anti-seize lubricant applied to the threads
before tightening to avoid binding or galling of components.
• Ensure all recyclable parts/packaging are discarded in accordance to local
regulations.
Themountingbracketissuppliedlooselyttedtothelight.ThestainlesssteelM6x25mm
or M8 x 30mm button head bolts that secure the mounting bracket to the light must be
removedandhaveanti-seizelubricantappliedtothethreadsbeforenalinstallation.
The use of anti-seize greatly reduces the risk of thread galling or binding commonly seen
between stainless steel nuts and bolts during tightening. Anti-seize must also be applied
to all the mounting fasteners used to secure the light to the vehicle.
Ensurethemountinglocationfortmentofthelight/stothevehicleisat,stable,
sufcientlystrongandhasenoughclearancearoundthelighttoavoiddamagetothe
vehicle from any movement during installation and use. If drilling is required for mounting,
ensure raw edges are coated with corrosion resistant paint or inhibitor.
The light can be adjusted horizontally and vertically. All adjustments are to be made
beforenaltighteningoffasteners.Horizontaladjustmentisgainedbyrotatingthe
light body to the desired position and tightening the centre M10 or M12 bolt. Vertical
adjustment is gained by tilting the light body up or down and tightening the 4 x side bolts.
INSTALLATION
Installation Guide
IMPORTANT!
Light Mounting Bracket
Vehicle Mounting & Adjustment
Power Plug
Control Plug
ISOMETRIC VIEW
N.T.S.
INSTALLATION
The 9” light should always be secured to the vehicle using 1 x M12 centre bolt and 2 x
M8sideboltsassupplied.Applyanti-seizelubricanttothesefastenerswhenttingto
thevehicle.Forinitialsetupandadjustment,thefastenersshouldbengertightened.
Once all adjustments have been made, all fasteners should be tightened and torqued
tothefollowingspecication:
M8 Fasteners
M10 Fasteners
M12 Fasteners
17Nm
33Nm
57Nm
RECOMMENDED TORQUE SETTINGS
Please refer to the wiring
system owners manual, for
the full guide on driving light
installation.
Wiring Installation

Night Hawk Variable Series Driving Lights Night Hawk Variable Series Driving Lights 2625
Eachsingledrivinglightcomeswith2*protectivecovers,1xclearspotbeamcoverand
1xutedoodbeamcover.(*exceptfortheVBPmodelwhichcomeswith1xclearspot
cover).
To t a protective cover, align the 5 x clips on the cover with the openings in the front of
the light, thenpushcoverrmlyuntilalloftheclips‘click’intotheopenings.To remove the
cover, pull out on the 2 x lower tabs until the clips release from the light.
• The light is not serviceable – DO NOT disassemble.
• Clean lights using pH neutral soapy water and a soft nonabrasive brush or sponge. Rinse
thoroughly after cleaning.
• DO NOT use solvents, Alkaline based cleaners or abrasive materials to clean the light.
• If lights are exposed to a high salt environment or any other corrosive substance,
remove the light and mounting bracket from the vehicle and thoroughly clean and
rinse the components as outlined above.
• Remove the clear cover and plastic cover on the rear of the light periodically to clean
any dirt and grime build up.
• Regularly check all fasteners to ensure they are secured and properly torqued.
Care & Maintenance
Cover Installation & Removal
Light Care and Maintenance
CARE & MAINTANENCE
Openings
Clips
Tabs
1. Our Warranty
We warrant to you that the Kingsley product is free from defects in workmanship and
materials for the warranty period.
2. Fitting and use
Pleaseensureyou:
a.ttheKingsleyproductinaccordancewiththeproductinformationandall
relevant vehicle safety and compliance laws
b. use the Kingsley product for the purpose for which it was originally designed and
in accordance with the product information and all relevant vehicle safety and
compliance laws
3. Exclusions
Ourwarrantydoesn’tcover:
a. normal wear and tear
b.ttingtheKingsleyproductotherthaninaccordancewiththeproduct
information and any relevant vehicle safety and compliance laws, including
incorrecttting
c. using the Kingsley product other than for the purpose for which it was originally
designed or other than in accordance with the product information and any
relevant vehicle safety and compliance laws, including unusual, improper or
negligent use or misuse or overloading
d. misuse or neglect of the Kingsley product, including improper repair or
maintenance or failing to repair or maintain
e. alteration, abuse, acts of nature, terrorism, vandalism, collision, road hazards or
adverse conditions
4. Making a claim
Please immediately contact us as soon as you become aware of a possible defect
in the Kingsley product. We’ll arrange for you to either attend a Kingsley outlet (at
yourcost)foraKingsleyrepresentativetoinspecttheKingsleyproduct(asttedto
your vehicle) or for you to return the Kingsley product to us. We’ll also request you
to provide the purchase receipt and complete a warranty claim form. In order to
ensure our warranty is not voided, please keep the purchase receipt as proof of
purchaseanddon’tremovethettedKingsleyproductfromyourvehiclebefore
contactingus.Note:Non-transferablewarranty.Theoriginalpurchasercanonly
claim warranty. If your claim’s in order, we’ll notify you and (at our sole discretion)
either repair or replace the defective workmanship or materials (at our cost) or
refund to you the purchase price you paid for the defective Kingsley product. If
further information or investigation is required or if the claim does not meet the
requirements under our warranty, we’ll let you know.
5. Australian Consumer Law
The Kingsley product comes with guarantees that can’t be excluded under the
Australian Customer Law. You’re entitled to a replacement or refund if there’s
a major failure and compensation for any other reasonably foreseeable loss or
damage. You’re also entitled to have the Kingsley product repaired or replaced if it
fails to be of acceptable quality and the failure doesn’t amount to a major failure.
Warranty Policy
WARRANTY POLICY

Night Hawk Variable Series Driving Lights
27
Term Meaning
Product
information
information about the Kingsley product which may be contained
in any of the documentation provided with the Kingsley product,
including safety instructions, installation instructions, operating
instructions, owner’s manual, service manual, labels and packaging
Purchase date the date you purchased the Kingsley product from a Kingsley
outlet,asspeciedinthepurchasereceipt
Kingsley outlet an outlet authorised by Kingsley to sell Kingsley products
Kingsley
products
products or components which Kingsley manufacturers or sells
through Kingsley outlets
Warranty period commencesonandfromthepurchasedateandendsasfollows:
Night Hawk LED Driving Lights - 5 year warranty
We/Us
Kingsley Enterprises Pty Ltd (ABN 23 001 592 749)
E:[email protected]
A:6ABrooksRoad,IngleburnNSW2565
P:1800654767
W:www.bushranger.com.au
You the purchaser of the Kingsley product from a Kingsley outlet
6. Other consumer rights
Thebenetstoyouunderourwarrantyareinadditiontoanyotherrightsand
remedies you are entitled to under relevant consumer laws. Our warranty replaces
any other warranty given by Kingsley or it’s supplier in respect of the Kingsley product.
7. Terms
Thefollowingtermshavethefollowingmeanings:
WARRANTY POLICY
0236-21O

Kingsley Enterprises PTY. LTD.
FreeCall|1800654767(AustraliaOnly)
International | [phone]
Email | [email protected]
Address | 6A Brooks Road, Ingleburn NSW 2565
www.bushranger.com.au/nighthawk
