BUTURE VC50 User manual
USER MANUAL
Cordless Vacuum Cleaner
Model: VC50
Email:tech-support@ibuture.com
English
Deutsch
Français
Español
Italiano
日本語
03-16
17-30
31-44
45-58
59-72
73-86
LANGUAGE
1. WARRING.................................................
2. PACKAGE LIST........................................
3. KNOW THE PRODUCT.............................
3.1 Product Details...............................................
3.2 Digital Touch Screen.....................................
3.3 Accessories Function....................................
4. PRODUCT ASSEMBLY.............................
4.1 Install Vacuum Cleaner.................................
4.2 Install Wall Mount.........................................
4.3 Charging Wall Mount Installation....................
5. HOW TO USE ..........................................
5.1 Charging.........................................................
5.2 Operating.......................................................
6. MAINTENANCE ......................................
6.1 Main Body Cleaning.......................................
6.2 Wash Dust Cup and Filters..........................
6.3 Brush Roller Cleaning...................................
7. SPECIFICATION .....................................
8. TROUBLESHOOTING .............................
9. WARRANTY............................................
03
04
05
05
06
06
07
07
07
08
09
09
10
12
12
12
14
15
15
16
CONTENT
3EN
Thank you for purchasing the BUTURE VC50 cordless vacuum cleaner. Before
using this machine, please read the following safety warning rst and take
safety protection measures to avoid malfunctions caused by improper
operation.
①This BuTure appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction by a
responsible person concerning use of the appliance to ensure that they can use it
safety.
②Suitable for dry locations only. Do not use or store outdoors with wet surfaces.
Do not handle any part of the plug or appliance with wet hands. Store properly in
a dry place indoors.
③Do not use a damaged cable or plug. If the device or charger does not work
properly, dropped, damaged, missed or dropped into water, please contact tech-
④Do not vacuum flammable or combustible liquids, such as petrol, or use in
areas where liquids may be present.
⑤Turn off the power switch before plug or unplug the adapter.
⑥Do not vacuum anything that is burning or smoking, such as cigarettes,
matches or hot ashes.
⑦Do not use without filters or dust cup to avoid damaging the motor and
contaminating the air. Wash hands after using the vacuum cleaner.
⑧FIRE WARNING: Do not place this product on or near a cooker or any other hot
surface and do not incinerate this appliance even if it is severely damaged. The
battery might catch re or explode.
⑨Unplug the charger from the power outlet before performing routine cleaning
or maintenance.
⑩Battery leaks may occur under extreme conditions. If any liquid gets on your
skin wash quickly with soap and water. f liquid gets into your eyes, rinse with
water for at least 15 minutes immediately. Seek medical attention immediately.
⑪Charge the unit with the charger we provided.
⑫Avoid using this product to vacuum hard, sharp objects, as this may cause
damage.
Note: The vacuum cleaner adopted thermal protection technology to prevent
overheating, will stop working when the item is over-heated.
1. WARNING
4
EN
Main Body*1
Adjustable Extension
Tube*1 Motorized Floor Brush*1
Charging Wall Mount*1 Long Crevice Nozzle *1 2 in 1 Upholstery Brush*1
Extra Hepa Filter*1 Charger*1 Extra sponge Filter*1
Cleaning Brush*1 User Manual*1
2. PACKAGE LIST
Please check and confirm the accessories and parts according to the following
sheet before using.
5EN
3. KNOW THE PRODUCT
3.1 Product Details
Motorized Floor Brush
Release Button
Motorized Floor Brush
Digial Touch
Screen
Switch Button
Dust Cup
Dust Empty
Button
Battery Pack
Dust Cup Release Button
Motor
Telescopic Tube Release
Button
Adjustable Extension
Tube
LED Light
6
EN
3.2 Digital Touch Screen
3.3 Accessories Function
Brush Blocked
Indicator
Suction level
indicator light
Manual
Mode
Battery Power
Indicator
Brand Name
AUTO Mode
2 in 1 Upholstery Brush Long Crevice Nozzle
Charging Wall Mount Mini Cleaning Brush
Easy to snap-on design,can help you
remove dust and hair on the carpet. Remove dust on the hard-to-reach
areas like windows, bed feet, gaps
between sofa, etc.
Fix the vacuum cleaner and
accessories on the wall hanger for
easy storage and charging.
Remove hair, rubbish, and micro dust
on the accessories or lters.
7EN
1. Directly Install Cleaning Accessories
2. Install Extension Tube & Cleaning Accessories
4. PRODUCT ASSEMBLY
4.1 Install Vacuum Cleaner
4.2 Install the Machine
Click
Click
Click Click
ClickClick
8
EN
4.1 Install Vacuum Cleaner
4.3 Charging Wall Mount Installation
1 2
WARNING
• Please make sure there is no gas, water, or electrical cables and wires behind
the mounting area.
• To avoid the dock dropping down, please make sure it must be installed rmly.
• Store appropriately indoors in a dry place. Do not expose the machine to
sunlight or freezing temperature. Recommended temperature range: 39.2°F
(4°C)-104°F(40°C).
9EN
5. HOW TO USE
5.1 Charging
• Charging Methods
• Battery power indicator
• When using a new battery or using it for the rst time after long-term storage,
please fully charge the battery rst.
• When storing and not using the vacuum cleaner for a long time, please ensure that
it is charged and discharged at least once every three months.
①Charge the battery directly
②Charging with Wall Mount
25%
50%
75%
100%
Recharging: Light will ash blue cyclically and indicate the remaining power.
Charged Full: Light will always on.
10
EN
5.2 Operating
• The battery is fully charged, and xed in place.
• The dust cup and lters are cleaned, and xed in place.
Before each use, make sure that
• Start To Work
• Select Cleaning Mode
Press the switch button to turn it on and it will start MANUAL Mode.
①MANUAL Mode
Touch the “M”on the display screen to switch between three suction gears of MIN-MID-
MAX. The corresponding indicator of suction level is :MIN= blue,MID= purple,MAX= red.
MIN Mode MID Mode MAX Mode
11 EN
②AUTO Mode
Press the "A" button to switch to AUTO mode.
In AUTO mode, the Automatic Load Sensor system automatically changes the motor
speed and suction level between carpets and hard floors for energy-efficient powerful
cleaning.
③Abnormal Indicator
When the red light ashing(about 5s) and the motorized oor brush does not work, the
motorized oor brush/telescopic tube/dust cup is blocked, please clean it promptly.
Blue Light : AUTO mode on
White Light : AUTO mode o
12
EN
6. MAINTENANCE
6.1 Main Body Cleaning
6.2 Wash Dust Cup and Filters
• Turn off the power before cleaning the body.
• Please use a neutral detergent, wipe the body with half-wet cloth.
• Please avoid sun exposure and store in a cool and dry place.
• When using, if the garbage in the dust cup exceeds MAX Line, please empty it
in time.
• Press the dust empty button to empty the dust.
Tip: Please clean the vacuum cleaner regularly to extend its lifespan.
①Empty Dust Cup
13 EN
• Remove dust cup from main body.
• Rotate clockwise to remove the stainless steel lter.
• Remove HEPA lter from main body.
②Remove Dust Cup and Filters
③Clean and install dust cups/Filters
• Clean dust cup and lters with water. Make sure that the dust cup and lters
have dried before use.
24h
14
EN
• Installation steps:
1. Twist the stainless steel lter counterclockwise and put it into the dust cup.
2. Put in a sponge strainer.
3. Plug the HEPA lter into the motor.
4. Twist the dust cup clockwise to connect it to the motor.
1. Press the release button upwards to remove the brush roller.
2. To take out the brush roller, and to remove any hair or bers that have been wrapped
around the brush roller. Using the brush cleaning tool to sweep away the trash on the roller.
3. The brush roller is washable. Before replacing, check that the brush roller is completely
dry.
4. Press the brush roller to the brush head and hearing the sounds of locking.
6.3 Brush Roller Cleaning
Tip: After long periods of use, the bristle may be jammed by hair or similar build-up. It’s
recommended to clean the brush roller periodically to ensure efficient operation and
maintain suction.
1 2 3 4
click
1 2 3 4
15 EN
NOTE: If vacuum still does not operate properly, contact Customer Service.
7. SPECIFICATION
8. TROUBLESHOOTING
Product Cordless Vacuum Cleaner
Model VC50
Rated Voltage DC 25.9V
Battery Type Li-ion
Cleaning Mode AUTO & MANUAL
ISSUEL CAUSE SOLUTION
Vacuum cleaner not work
①The product is out of power. ①Please fully charge the
product before using it.
②Automatic protection
triggered by high temperature
caused by blockage.
②Clean the dust suction port
or the HEPA lter, and restart it
after cooling down.
No suction or light suction Dust cup is full, suction port of
the machine is blocked or lter
is clogged.
Empty dust cup and clean
lters (See Emptying the Dust
Cup and Cleaning the Filters
sections).
Battery Indicator does not light
when charging
①Main body and adapter are
not connected properly.
①Check whether the adapter
is plugged in.
②Battery is fully charged and
no more charging. ②Can be used normally.
Can not charge
①The battery temperature is
too high or too low.
①Leave the vacuum and
battery to cool for at least 45
minutes, until they return to
room temperature.
②Charging indicator does not
light up. ②Charger is not plugged in.
The red brush roller Indicator
ashes The brush roller is blocked.
Remove any string, carpet
bers, or hair that may be
wrapped around the brush
roller.
Power indicator ashes red
Motor may have protection
functions such as over-
temperature/under-voltage.
Clean the whole machine until
it return to room temperature.
If the Power Indicator still
ashes blue, please contact
us.
16
EN
9. WARRANTY
9.1 The 2-Year Warranty
9.2 What is covered?
9.3 How to claim?
• Our BuTure machine has a 2-year warranty against original defects in material and
workmanship, when used for private household purposes in accordance with the Bu-
Ture Instruction Manual.
• This warranty provides, at no extra cost to you, all labor and parts necessary to ensure
your machine is in proper operating condition during the warranty period.
Only applies to purchases made from authorized retailers of BuTure.
This warranty will only be valid if the machine is used in the country in which it was sold.
Please keep your proof of purchase. To make a claim under our warranty, you need to
provide your original purchase receipt with the purchase date and order number on it.
If your machine is not functioning properly, or you still have any questions
after reading this manual carefully, please feel free to contact us, we will
reply to you in 24 hours and try our best to provide you with a satisfactory
solution.
Email our Customer Service：[email protected]
31 FR
Nous vous remercions d'avoir acheté l'aspirateur sans fil BuTure VC50. Avant d'utiliser
cet appareil, veuillez d'abord lire l'avertissement de sécurité suivant et prendre
des mesures de protection pour éviter les dysfonctionnements causés par une
mauvaise utilisation.
①Cet appareil BuTure n'est pas destiné à être utilisé par des personnes (y compris les
enfants) dont les capacités physiques, sensorielles ou mentales sont réduites, ou qui
manquent d'expérience et de connaissances, à moins qu'elles n'aient été supervisées ou
instruites par une personne responsable concernant l'utilisation de l'appareil an de s'assurer
qu'elles peuvent l'utiliser en toute sécurité.
②Convient uniquement pour les endroits secs. Ne pas utiliser ou stocker à l'extérieur avec
des surfaces humides. Ne manipulez aucune partie de la fiche ou de l'appareil avec des
mains mouillées. Stocker correctement dans un endroit sec à l'intérieur.
③N'utilisez pas un câble ou une prise endommagés. Si l'appareil ou le chargeur ne
fonctionnent pas correctement, s'ils sont tombés, endommagés, manqués ou tombés dans
pour obtenir de l'aide.
④N'aspirez pas de liquides inflammables ou combustibles, tels que l'essence, et ne les
utilisez pas dans des zones où des liquides peuvent être présents.
⑤Mettez l'interrupteur d'alimentation hors tension avant de brancher ou de débrancher
l'adaptateur.
⑥N'aspirez rien qui brûle ou qui fume, comme des cigarettes, des allumettes ou des
cendres chaudes.
⑦N'utilisez pas l'appareil sans filtre ni coupe-poussière pour éviter d'endommager le
moteur et de contaminer l'air. Se laver les mains après avoir utilisé l'aspirateur.
⑧AVERTISSEMENT CONCERNANT LES INCENDIES : ne placez pas ce produit sur ou près
d'une cuisinière ou de toute autre surface chaude et n'incinérez pas cet appareil même s'il
est gravement endommagé. La batterie pourrait prendre feu ou exploser.
⑨Débranchez le chargeur de la prise de courant avant d'effectuer un nettoyage ou un
entretien de routine.
⑩Des fuites de la batterie peuvent se produire dans des conditions extrêmes. Si du liquide
entre en contact avec votre peau, lavez-la rapidement à l'eau et au savon. Si du liquide
entre en contact avec vos yeux, rincez-les immédiatement à l'eau pendant au moins 15
minutes. Consultez immédiatement un médecin.
⑪Chargez l'appareil avec le chargeur que nous avons fourni.
⑫Évitez d'utiliser ce produit pour aspirer des objets durs et pointus, car cela pourrait
l'endommager.
Remarque: l'aspirateur a adopté une technologie de protection thermique pour éviter la
surchauffe, il s'arrête de fonctionner lorsque l'article est surchauffé.
1. AVERTISSEMENT
32
FR
2. LISTE DES PAQUETS
Veuillez vérier et conrmer les accessoires et les pièces selon la che suivante
avant de les utiliser.
Corps principal*1
Tube télescopique
réglable*1
Tête de brosse
motorisée*1
Support mural
rechargeable*1 Buse longue crevasse*1
Brosse à rembourrage
2 en 1 *1
Filtre Hepa
supplémentaire*1 Chargeur*1
Filtre éponge
supplémentaire*1
Mini-brosse de
nettoyage*1 Manuel d’utilisation*1
Other manuals for VC50
2
Table of contents
Languages:
Other BUTURE Vacuum Cleaner manuals
