BW Technologies CONNEX1 User manual

Gas Detector
Operator’s Manual

ConneX1 Operator’s Manual i
Limited Warranty and Limitation Liability
BW Technologies by Honeywell LP (BW) warrants the product to be free from defects in material and workmanship under normal use and service for a period of
two years, beginning on the date of shipment to the buyer. This warranty extends only to the sale of new and unused products to the original buyer. BW’s warranty
obligation is limited, at BW’s option, to refund of the purchase price, repair or replacement of a defective product that is returned to a BW authorized service center
within the warranty period. In no event shall BW’s liability hereunder exceed the purchase price actually paid by the buyer for the Product.
This warranty does not include:
a. fuses, disposable batteries or the routine replacement of parts due to the normal wear and tear of the product arising from use;
b. any product which in BW’s opinion, has been misused, altered, neglected or damaged, by accident or abnormal conditions of operation, handling or use;
c. any damage or defects attributable to repair of the product by any person other than an authorized dealer, or the installation of unapproved parts on the
product; or
The obligations set forth in this warranty are conditional on:
a. proper storage, installation, calibration, use, maintenance and compliance with the product manual instructions and any other applicable recommendations
of BW;
b. the buyer promptly notifying BW of any defect and, if required, promptly making the product available for correction. No goods shall be returned to BW
until receipt by the buyer of shipping instructions from BW; and
c. the right of BW to require that the buyer provide proof of purchase such as the original invoice, bill of sale or packing slip to establish that the product is
within the warranty period.
THE BUYER AGREES THAT THIS WARRANTY IS THE BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. BW SHALL
NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR BASED ON CONTRACT, TORT OR RELIANCE OR ANY OTHER THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or consequential damages, the limitations
and exclusions of this warranty may not apply to every buyer. If any provision of this warranty is held invalid or unenforceable by a court of competent jurisdiction, such
holding will not affect the validity or enforceability of any other provision.

ConneX1 Operator’s Manual
ii
Contacting BW Technologies by Honeywell
Corporate Headquarters
BW Technologies by Honeywell
2840 2nd Ave. SE
Calgary, AB
Canada T2A 7X9
+1.403.248.9226 / 1.800.663.4164
+1.403.573.3708
United States
BW Technologies by Honeywell
405 Barclay Blvd.
Lincolnshire, IL
USA 60069
+1.847.955.8200 / 1.800.538.0363
+1.847.955.8210
Europe
BW Technologies by Honeywell
4 Stinsford Road
Nuffield Industrial Estate
Poole, Dorset BH17 0RZ
+44 (0) 1295.700.300
+44 (0) 1295.700.301
[e-mail]
www.gasmonitors.com

ConneX1 Operator’s Manual iii
5.1 Break Mode................................................................................... 19
6. Panic Alarm........................................................................................ 20
7. Alarms ................................................................................................ 21
7.1 Alarm Setpoints ................................................................................. 24
7.2 Stopping a Gas Alarm................................................................... 24
7.2.1 Low and High Alarms................................................................. 24
7.2.2 TWA and STEL Alarms ........................................................ 24
7.2.3 Acknowledging Latching Alarms .......................................... 24
8. Modes ................................................................................................. 24
8.1 Standard Operation....................................................................... 24
8.2 Stealth Mode................................................................................. 24
8.3 Safe Mode..................................................................................... 24
8.4 Review Mode ................................................................................ 25
8.4.1 Gas Exposure ...................................................................... 25
8.4.2 Sensor Configuration ........................................................... 25
8.4.3 Detector Information ............................................................ 25
8.4.4 Messages............................................................................. 25
9. Calibration.......................................................................................... 25
9.1 Calibration Using the IntelliDoX .................................................... 25
9.2 Calibration Guidelines................................................................... 26
9.3 Installing the Calibration Cap........................................................ 26
Table of Contents
1. Introduction.......................................................................................... 1
1.1 Intended Use................................................................................... 1
1.2 Product Overview............................................................................ 2
1.2.1 Parts of the ConneX1............................................................. 2
1.2.2 Display Elements ................................................................... 3
1.2.3 Buttons................................................................................... 4
1.3 Sensor Poisons and Contaminants................................................. 5
2. Getting Started..................................................................................... 6
2.1 Activating/Deactivating the Detector ............................................... 6
3. Installing Fleet Manager II................................................................. 11
3.1 Using Fleet Manager II to Configure the Detector ........................ 11
4. User Options...................................................................................... 12
4.1 General User Options ................................................................... 12
4.1.1 Message Configuration ........................................................ 14
4.1.2 Mandown Configuration ....................................................... 15
4.1.3 Password Configuration ...................................................... 15
4.2 Sensor and Profile Configuration.................................................. 15
4.2.1 Profile Options ..................................................................... 15
4.2.2 Sensor Options .................................................................... 16
4.3 Network Information Options ........................................................ 19
5. Mandown Alarm................................................................................. 19

ConneX1 Operator’s Manual
iv
9.3.1 Gas Cylinder Connection ..................................................... 26
9.3.2 Calibration Gas Concentration............................................. 27
9.4 Manual Calibration Procedure ...................................................... 27
10. Bump Test........................................................................................ 29
10.1 Bump Test Using the IntelliDoX................................................... 29
10.2 Performing a Manual Bump Test................................................. 29
11. Datalogs ........................................................................................... 30
12. Event Logs ....................................................................................... 31
13. Messaging ........................................................................................ 31
13.1 Receiving Messages................................................................... 31
13.2 Reading Messages ..................................................................... 32
13.2.1 Sending a Messages ......................................................... 32
13.3 Panic Alarm Messages ............................................................... 32
14. LocaXion Manager........................................................................... 32
15. Fleet Manager II ............................................................................... 32
15.1 Downloading Data To Fleet Manager II....................................... 32
15.2 Upgrading the Firmware ............................................................. 33
15.3 Generating Calibration Certificates............................................. 33
16. Maintenance..................................................................................... 33
16.1 Charging the Rechargeable Battery............................................ 33
16.1.1 Optimum Battery Operation ..................................................... 34
16.1.2 Rechargeable Battery Capacity ......................................... 34
16.2 Replacing the Sensor and Sensor Filter ..................................... 35
16.2.1 Replacing the Sensor......................................................... 36
16.2.2 Replacing the Sensor Filter................................................ 37
17. WEEE Directive and Battery Directive........................................... 38
17.1 Removal and Disposal of the Rechargeable Battery. ................. 38
18. Troubleshooting .............................................................................. 40
19. Replacement Parts and Accessories............................................. 53
20. Specifications .................................................................................. 54
Appendix A Regional Setpoints........................................................... 56
A.1 North America .............................................................................. 56
Appendix B Configuration Menu Structure......................................... 57
Appendix C Review Mode Menu Structure ......................................... 58
Appendix D Datalog Information.......................................................... 59
Appendix E Event Log Information...................................................... 60

ConneX1 Operator’s Manual v

ConneX1 Operator’s Manual
vi

ConneX1 Operator’s Manual vii

ConneX1 Operator’s Manual
viii
aCautions
Ŗ Warning: Substitution of components may impair Intrinsic Safety
s Before using the detector, refer to Sensor Poisons and Contaminants.
Ŗ Caution: For safety reasons, this equipment must be operated and serviced
by qualified personnel only. Read and understand the operator’s manual
completely before operating or servicing.
s Charge the detector before first-time use. BW Technologies by Honeywell
recommends the detector be charged after every workday.
s Calibrate the detector before first-time use and then on a regular schedule,
depending on use and sensor exposure to poisons and contaminants. BW
Technologies by Honeywell recommends that the sensor should be calibrated
regularly and at least once every 180 days (6 months).
s Calibrate only in a safe area that is free of hazardous gas in an atmosphere
of 20.9% oxygen.
s BW Technologies by Honeywell recommends to bump test the sensor before
each day’s use to confirm its ability to respond to gas by exposing the
detector to a gas concentration that exceeds the alarm setpoints. Manually
verify that the audible, visual, and vibrator alarms are activated. Calibrate
if the readings are not within the specified limits.
s Any rapid upscaling reading followed by a declining or erratic reading
may indicate a gas concentration beyond upper scale limit, which can be
hazardous.
s For use only in potentially explosive atmospheres where oxygen
concentrations do not exceed 20.9% (v/v).
s Extended exposure of the detector to certain concentrations of combustible
gases and air may stress an detector element that can seriously affect its
performance. If an alarm occurs due to high concentration of combustible
gases, calibrate the detector. If necessary, replace the sensor.
Ŗ Warning: The lithium battery may present a risk of fire or chemical burn
hazard if misused. Do not disassemble, heat above 212°F (100°C), or
incinerate.
Ŗ Warning: Lithium polymer cells exposed to heat at 266°F (130°C) for 10
minutes can cause fire and/or explosion.
s e Warning: This detector contains a lithium polymer battery. Dispose of
used lithium cells immediately. Do not disassemble. Do not dispose of in fire.
Do not mix with the solid waste stream. Spent batteries must be disposed
of by a qualified recycler or hazardous materials handler.
s Keep lithium cells away from children.
s Deactivating the detector by removing the battery pack may cause improper
operation and harm the detector.
s e Warning: At the end of their working lives, sensors must be disposed
of in an environmentally safe manner, in accordance with local waste
management requirements and environmental legislation.Do NOT incinerate
sensors as they may emit toxic fumes.
