BYECOLD HH0606L User manual

INFRARED HEATER PANEL WITH LED LIGHT
INSTRUCTION MANUAL
(EN + DE)

I
SYMBOLS
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
CONTENT
1┃WARNING & PRECAUTION
2┃FEATURES
3┃TECHNICAL INFORMATION
4┃SCOPE OF SUPPLY
5┃DEVICE STRUCTURE
6┃INSTALLATION
7┃THERMOSTAT
8┃TROUBLESHOOTING
9┃MAINTENANCE & SERVICING
10┃STORAGE
11┃TECHNICAL ANNEX
12┃DISPOSAL
Symbols Meaning
This symbol located on the device indicates that it is
prohibited to place objects (such as towels, clothes etc.)
above or directly in front of the device.
In order to avoid overheating and fire hazards, the device
must not be covered.
This symbol located on the device indicates dangers to the
life and health of persons due to hot surface.
This symbol located on the device indicates that it is
prohibited to spray the device.
This symbol located on the device and i
nformation marked
indicates that operating manual must be observed.

- 1 - EN
1┃WARNING & PRECAUTION
Read this manual carefully before starting or using the device. Always store
the manual in the immediate vicinity of the device or its site of use!
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric
shock, fire and / or serious injury. Save all warnings and instructions for
future reference.
Warning
This series must be mounted above 1.8meters high！
Make sure the series you bought and install it in accordance to the tips in
installation part!
Warning
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Warning
Children of less than 3 years should be kept away unless continuously
supervised.
Children aged from 3 years and less than 8 years shall only switch on/off
the appliance provided that it has been placed or installed in its intended
normal operating position and they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Children aged from 3 years and less than 8 years shall not plug in,
regulate and clean the appliance or perform user maintenance.
Warning
Do not use the device in small rooms if persons are present who cannot
leave the room independently and who are not under constant supervision.
Warning
Sensors with temperature detection,
or temperature controller, should not
be placed within the radiation range
of 130 degrees of the ceiling heating plate, otherwise it will affect the
actual temperature detection .
Warning
Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
Its dangerous of installation close to curtains and other combustible materials.
To avoid the possibility of burns, the following people should be much more
careful when using the heaters: infants and kids, people with sensitive skin, the
old, the sick, people who is drunk, people who takes sleeping pills.
•Remove the protective film(on the front) before using.
•Be sure the usage voltage is between 220-240V, 50Hz, and power supply has
been strictly in accordance with IEC, left is null wire and right is live wire, and also
well grounded.
•The devices will draw more current than small appliances, so a separate 5A
socket is required.
•Do not use the device in potentially explosive rooms.
•Do not use the device in aggressive atmosphere.
•Set the device up in an upright and stable position.
•Let the device dry out after a wet clean. Do not operate it
when wet.
•Do not use the device with wet or damp hands.
•Do not expose the device to directly squirting water.
•Never insert any objects or limbs into the device.

- 2 - EN
•Do not cover or transport the device during operation.
•Do not sit on the device.
•This appliance is not a toy! Keep away from children and animals. Do not leave
the device unattended during operation.
•Check accessories and connection parts for possible damage prior to every use
of the device. Do not use any defective devices or device parts.
•Ensure that all electric cables outside of the device are protected from damage
(e.g. caused by animals). Never use the device if electric cables or the power
connection are damaged!
•The electrical connection must correspond to the specifications in chapter
Technical data.
•Do not use the device when the socket or wire overloaded.
•Observe the device's power input, cable length and intended use when selecting
extensions to the power cable. Completely unroll extension cables. Avoid electrical
overload.
•Before carrying out maintenance, care or repair work on the device, remove the
mains plug from the mains socket or disconnect the circuit.
•Switch the device off and disconnect the power cable from the main socket
when the device is not in use.
•Do not use the device under any circumstances if any damages on the mains
plug or power cable. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard. Defective power cables pose a serious health risk.
•During the installation of the device observe the minimum distances from walls
and other objects as well as the storage and operating conditions specified in the
Technical data chapter.
•Never drill into the heating device.
•Do not use the device in immediate proximity to curtains.
•Do not place the device on combustible ground.
•Do not transport the device during operation.
•Do not touch the surface during the device working to avoid burns.
•Allow the device to cool down before transport and / or maintenance work.
•Do not use this device near bathtubs, shower trays, swimming pools or other
water containers. Risk of electric shock!
•The device must be placed where the switches and controllers cannot be
touched by a person in a bathtub or shower.
•Do not use this device in a child-care centre and bathroom.(Only for Sweden)
2┃FEATURES
•The device is designed to provide an efficient, comfortable and
healthy heating system for any domestic users.
•These devices can reduce air circulation and help to maintain a
clean, silent, dust free environment.
•A wide range of devices available in a huge choice of colors, sizes and styles.
3┃TECHNICAL INFORMATION
LED Light HH series
Heating element Carbon
Heating way Far infrared heating
Input Voltage 220-240V/50Hz
Surface temperature Main 130-150°C
Frame Aluminum
Over heating protection Yes
Power cord length ≤1.9m
Model NO. Size(mm) Heating
Power
LED
Power
Voltage
Frequency
Rated
Current
HH0606L 655*630*35 370W 30W
230V/50Hz
1.7A
HH1006L 1080*630*35 660W 40W 3A
HH1206L 1280*630*35 800W 40W 3.6A

- 3 - EN
4┃SCOPE OF SUPPLY
•(A)1 x heating device
•(B)4 x Screws
•(C)4 x Dowels
•(D)2 x hanging units
•1 x thermostat
•1 x Manual
5┃DEVICE STRUCTURE
6┃INSTALLATION
Warning
•Mounting work must be carried out by professional electrician !
•Do not suspend panels by heating power cord !
•No any sticking ways are allowed to be used for hanging or suspending support !
•Make sure the ceiling is stable enough !
•Do remove the front protective film before using !
•Power cord must be well grounded!
1. Drill four holes on the ceiling with correct distance A and distance B.
Must use CORRECT diameter drilling bit to avoid panel falling!
Panel Size/mm
Hole Distances of Screws/mm
655*630 (or similar)
A495*B100mm
1080*630(or similar)
A495*B300mm
1280*630 (or similar)
A495*B300mm
2. Mount the two hanging units onto ceiling with screws, and turn
the screws to the end tightly, this is very important.

- 4 - EN
3. Push the rear of the left long frame into the hook, and then push back to make the
rear of the right long frame into the other hook.
Note: 1.Hooks are for the two long frames only, not the two short ones!
2.Make
sure the hooks are between the two limit screws !
WARNING
To avoid falling off, you must slide the panel left and right to make sure the
two hooks have been completely put into the rear of the two long frames!
7┃THERMOSTAT
Specification
•Battery-powered: DC 4x 1.5V AAA batteries (not included)
•Set temperature range: 0°C ~ 45°C, resolution: 1°C
•Room temperature range: 0°C ~ 50°C, display resolution: 0.1°C
•Accuracy of the measured temperature: ±0.5°C
•Working environment range 1°C ~ 50°C
•Radio frequency 433.92MHz
Description
1. This thermostat also includes individual operation part for LED light.
2. The thermostat acquires the room temperature with its integrated sensor and
transmit signal to the panel to turn on/off heating as the ambient temperature
changing, in order to maintain a constant room temperature. When the ROOM
temperature is 0.5°C higher than the SET temperature, thermostat will send OFF
commands to panel; When the ROOM temperature is 0.5°C lower than the SET

- 5 - EN
temperature, thermostat will send ON commands to panel to turn on heating
function.
3. The screen display shows the setting temperature as well as the measured
temperature, time, date, modes etc.
4. The thermostat has week programmable、temperature setting、auto-off when
temperature jump、favorite temperature 、time setting functions etc.
5. It is powered by 4pcs of 1.5V AAA batteries. Please change with new ones if the
battery symbol gets flashing, or else it will not be able to control the panel.
6. Keypad locking function is designed to prevent the children from misusing.
7. LCD screen powered off means only the panel heating power off, the remote
control itself is still under working state until batteries dead/out or broken.
8. The LCD screen only can work in temperature range from 1°C ~ 50°C.
Operation Instructions of Heating Function
Pair the thermostat with the heating device
Plug the panel into power socket, press ON/OFF for thermostat, then press
button °C/°F and MODE buttons at same time to pair the thermostat with panel
until a long beep sound heard.
NOTE:
1) Pairing should be finished within 1 minute, or else you need to re-power on the
device.
2) Please re-power on the panel if you want to pair the device with another
thermostat.
3) One thermostat can be paired to and work with several panels at same time.
4) Before pairing please do power off those panels which you don’t want to pair.
Set the Time and Day
It is essential that the clock time and day are set accurately if you require your
programmed events to start on time.
Step 1. Press and hold TIME button for 3 seconds until the Year of date flashing.
Step 2. Use ▲or ▼button to set the Year, then short press TIME to save and
proceed with setting up Month/Day/Hours/Minutes in similar manner.
Step 3. Short press TIME button again to save and exit.
Manually turn the thermostat ON/OFF
Press ON/OFF button to turn the thermostat on/off.
When thermostat is turned Off, the LCD will only display current room
temperature reading.
When thermostat is turned On, users can press ▲or ▼button to increase or
decrease the set temperature. If the set temperature is below room
temperature, heating device is now OFF. If the set temperature is above room
temperature, the thermostat goes ON and heating symbol appears on the
screen of thermostat, it is now supplying power to heating device.
Lock the buttons
Press and hold the LOCK button for 3 seconds until you see a lock icon
appearing. To unlock, repeat the steps above.
°C/°F Display
Short press the C/F button to convert Celsius/Fahrenheit or Fahrenheit/Celsius.
FAV Function
Press and hold FAV for 3 seconds until the set temperature icon flashes, press
UP and DOWN to set a favorite temperature, short press FAV to confirm.
In daily use, set temperature will convert to favorite temperature when short
press FAV button, and it will convert again to week target temperature at the
time when TIMER ON start to work.
5+2 or 1…7 Programming Mode
Press the MODE and TIME buttons simultaneously to select 5+2 or 1...7
programming modes.
Turns programming mode ON/OFF
Press and hold the MODE buttons for 3 seconds until you see ON appearing. To
turn OFF, repeat the steps above.
How to Programme Your Thermostat？
Press and hold the SET button for 3-5 seconds to enter into programming mode.
Note: Programming mode has a time-out limit whereby if no buttons are pressed
within 3-5seconds, it reverts back to the main screen.
1) 5+2 Programming Mode
You can program the thermostat to fit your lifestyle — week and weekend, plus
up to 4 groups of time interval per day.

- 6 - EN
Step 1. Once in 5+2 mode, Press and hold the SET button for 3-5 seconds until
Program icon ①and MON TUE WED THU FRI is displayed with ON and Time Icon
flashing on screen.
Step 2. Press ▲button to adjust hour(+1hour/press) and press ▼to adjust
Minute(+5minutes/press) to set the starting time of Program ①.
Step 3. Press the SET button once and OFF icon flashing on screen, Use ▲Button
to adjust hour (+1hour/press) and press ▼to adjust minute (+5minutes/press)
to set the ending time of Program ①.
Step 4. Press the SET button once again and set temperature icon flashing on
screen, Use ▲or▼button to set the desired temperature to be maintained for
program ①.
Step 5. Press the SET button to bring up Program ②of week days , repeat Step
2-5. And users can set up Program ③and ④in similar manner.
Step 6. After finishing setting Program ④, press the SET button to bring up SAT
and SUN setting, repeat step 2-5 to set Program①②③④of weekends.
2) 1-7 Programming Mode
You can program the thermostat everyday with setting 2 groups of time interval
per day.
Once in 1-7 Mode, Press and hold the SET button for 3-5 seconds until Program
icon ①and MON is displayed with ON and Time icon flashing on screen, users
can follow the above step 2-4 to set On/Off time and desired temperature of
Program ①and ②from Monday to Sunday in sequence.
Tips
：
1). The default starting time is 00:00, the ending time is 00:00, and the default
operating temperature is 15 degrees.
2). If the user does not adjust the default On/Off time of 00:00, the programming
settings is invalid.
3). Running time of Program ①②③④should not be overlapped, and the
ending time value of each program must be later than the starting time, otherwise
setting is invalid.
4). In 5+2 mode, if you do not want to set a mid-day heating period(Program ②
or ③), simply set the programs ②or ③to a lower temperature than default
with very short intervals. An example is shown below.
5). The programmed time / temperature setting will be restored with the next
program entry in the memory.
6). Once finish setting up the programming mode, the thermostat will work under
programming mode ON even if the thermostat is turned off. The heating device
will be switched ON or OFF according to the programming setting.
Open Window Detection
The thermostat will automatically turn off the heating device if a sudden drop in
temperature in the room is detected.
Operation Instructions of LED Lighting Function
1. Once thermostat is paired with device, Press ON/OFF button for LED light to
turn on/off the led light surrounding the panel, and long press ON/OFF
button to switch light color (Cold Light—Warm Light—Nature Light if
available).
2. Press +/- to adjust the brightness, short press can adjust brightness to 100%,
75%, 50% and 25%, long press can adjust from 100% to 5%.
Notes
1All settings need to be re-set after battery replacement.
2Alkaline battery is recommended. If ALL buttons on the thermostat are not
working, try replacing the batteries.
3Please do change the batteries with new ones once the screen battery symbol
gets flashing, or else it may result in halted/stuck/not working.
4Check if set temperature is higher enough than room temperature first if the
heating can not be turned on by thermostat.

- 7 - EN
5Make sure the Programming function has been switched to ON by long press
MODE setting if you want to use any programming mode.
6Do not cover or touch the temperature sensor which is at the top of the
thermostat.
7Do put the thermostat in a open normal room environment rather not inside a
drawer/pocket or under pillow/quilt etc.
Please do take out the batteries from the thermostat if long time no use.
8┃TROUBLESHOOTING
Problem Reason Measure
It has noise when original
charged with electricity
Due to the structure
stress of the heat
insulator.
It is a normal
phenomenon.
Don't worry about it.
The surface of the device
was slightly raised.
Due to the thermal
expansion of the surface
material.
It is a normal
phenomenon.
Don't worry about it.
The surface of the
heating device is slightly
warm.
1. The voltage is low.
2. In a low-temperature
environment.
1. Install a voltage
regulator.
2. It is normal.
9┃MAINTENANCE & SERVICING
Activities required before starting maintenance
Warning of electrical voltage
•If the power cord comes without plug, disconnect the circuit before
connecting it.
•Do not touch the mains plug or power cord connection with wet
or damp hands.
•Hold onto the mains plug while pulling the power cable out
of the mains socket.
•Allow the device to cool down completely.
Warning of electrical voltage
Tasks which require the housing to be opened must only be carried
out by authorized specialist companies.
Cleaning the device
Warning of electrical voltage
Never immerse the device in water!
Clean the device with a soft, damp and lint-free cloth.
Ensure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning
10┃STORAGE
When the device is not being used, observe the following storage conditions:
• dry and protected from frost and heat
• in an upright position where it is protected from dust and direct sunlight
• with acover to protect it from invasive dust, if necessary
• Place no further devices or objects on top of the device to
prevent it from being damaged.

- 8 - EN
11┃TECHNICAL ANNEX
Information requirements for electrical local space heaters
Item Unit
Type of heat input, for electric storage local space heaters only (select one)
manual heat charge control, with integrated thermostat
N/A
manual heat charge control with room and/or outdoor
N/A
electronic heat charge control with room and/or outdoor
N/A
fan assisted heat output
N/A
Type of heat output/room temperature control (select one)
single stage heat output and no room temperature control
[no]
Two or more manual stages, no room temperature control
[no]
with mechanic thermostat room temperature control
[no]
with electronic room temperature control
[no]
electronic room temperature control plus day timer
[no]
electronic room temperature contr
ol plus week timer
[yes]
Other control options (multiple selections possible)
room temperature control, with presence detection
[no]
room temperature control, with open window detection
[no]
with distance control option
[no]
with adaptive start control
[yes]
with working time limitation
[no]
with black bulb sensor
[no]
12┃DISPOSAL
The icon with the crossed-out waste bin on waste electrical or electronic equipment
stipulates that this equipment must not be disposed of with the household waste at
the end of its life. You will find collection points for free return of waste electrical
and electronic equipment in your vicinity. The addresses can be obtained from your
municipality or local administration.
The separate collection of waste electrical and electronic equipment aims to enable
the re-use, recycling and other forms of recovery of waste equipment as well as to
prevent negative effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the equipment.
