Byron Home Easy HE-107 User manual

Home Easy Romote
Control Dimmer
Light Switches
V1.0
The HomeEasy series of remote control light
switchs allows you to control your lights
manually or using a HomeEasy remote
controls (Except HE-200).The dimmer
module is suitable for 1-way circuits. For 2-
way switching (or Multi-way switching)use
this master unit with any number of
dimming slave units (Contact Byrons directly
- see contact details).
RE-INVENTING THE HOME
HOME
easy
TRANSFORMERS:
- Use only with electronic transformers.
- To Calculate the Load, add the VA ratings of the transformer
(not the bulb wattage)
- Choose transformers with a maximum rating close to the lamp load
e.g. 50VA,, 60VA or 70VA to control a 50 W low voltage bulb
- Wire Wound and Toroidal transformers are not compatible with the HomeEasy
Light switch's (see compatibility), if connect the dimmer will immediately turn
off. If this occurs more than times the dimmer will block any further use, to
unblock the dimmer it will need to be disconnect from the mains supply then
reconnect (see installation guide).
Compatibility:
Compatible -
lighting products
non-compatible -
products
Over Load Protection:
The HomeEasy dimmer switch is design to self protect against over loading
and over heating, this can occur when bulbs age. The dimmer module will
automatically dim the light or turn the lights off completely until the excess
load is removed, to reset the dimmer from the protection mode switch the
lights off then on.
Installation Guide
HomeEasy Remote Control Master t:
1Gang 1-Way Circuits
N
L
Live
S
Lighting Load
2. Isolate the electrical supply to the lighting circuit.
3. Remove the existing switch and disconnect the wiring from the switch
terminals, take note of the wiring of the switch and the terminal markings.
Where there are two or more wires together in the old switch they must be
kept together in the new Home Easy dimmer.
4. Ensure that the wall (back) box has a minimum depth of 25mm and is free
from plaster or projecting screw heads. If using wall box with 4 fixing lugs,
the top and bottom lug must be removed to allow the dimmer switch to fit.
5. Connect the wiring as per the diagrams below, Additional slave units will
allow for 2-way operation, these additional units can only be operated
manually. Contact Byrons for your local distributor.
1. Remove the decorative front plate from the HomEasy Dimmer, place a small
screw driver into one of the side slots so that the screw driver is between the
inside edge of the front plate and the outer edge of the clear plastic and,
gently twist.
1Gang 400W Dimmer
2Gang 250W Dimmer
INSTALLATION WARNINGS:
BEFORE COMMENCING INSTALLATION
ISOLATE YOUR MAINS ELECTRIC SUPPLY
Read the instructions care fully before starting the installation process and keep
them for future reference. If you are in any doubt on the installation process,
consult a qualified electrician.
This product should be installed in accordance with the relevant sections of
the building
regulations code,and the current edition of the IEE Wiring Regulations
(BS 7671:Requirements for electrical installations) and appropriate statutory
regulations.
As of1 April 2004, new installations in the UK should be wired using the EU
harmonised colours for the supply conductors:
New colours:
 BROWN = Live  BLUE = Neutral Earth = Yellow/Green
Old colours:
 RED = Live BLACK = Neutral
Electrical installations in bathrooms, kitchens, gardens, floor and heating systems,
swimming
pools, saunas and extra-low voltage lighting are classed as special installations and
must be certified by an approved competent electrical contractor conforming to
Part P, requirements of BS 7671:2001 and appropriate statutory regulations.
Fluorescent and compact fluorescent bulbs
Wire wound and Toroidal transformers
Electric Motors
Mains Voltage GLS or cable bulbs.
Dimmable Electronic Low voltage transformers
(see Transformer section)
GU10 and equivalent HI spot mains halogen bulbs
Installation Notes:
NOTE:Certain transformer types may not operate according to their stated
power rating when used with the dimmer switch,to avoid overloading of the
dimmer it will turn down the brightness of the lights. A digital transformer or
higher rated dimmer module may be required to resolve this problem.
N
L
Live
S
HomeEasy Remote Control Master unit
2-Way/Mulit-Way Circuits (Slave units will not operate with a HomeEasy
Reomte Control)
Live
S
Live
S
Lighting Load
Manual Operation Only Manual Operation Only
Slave 1 Slave 2
Live
S
Live
S
HomeEasy Remote Control:
2Gang Dimmer Switch with 2way and 1way
Live
S
N
L
Lighting Load =
NOTE: When using 2 gang dimmer switch, module A must be connected to
the lighting circuit.Module A will operate independently, Module B will only
operation when module A is connected.
ABSlave A
Manual Operation Only
Master Dimmer
Master Dimmer
Master Dimmer A Master Dimmer B

Dimming:
To dim the HomeEasy Dimmer switch manually, switch on the lights and
then press and hold the touch sensor, the dimmer will now enter the
dimming cycle, to select the required level release the touch sensor.
To change direction of the dimming cycle release the button and then
press and hold again.
Manual Operation:
Switching ON/OFF:
To switch the HomeEasy light switch "ON" press the touch sensor once
and, press the touch sensor again to switch the unit "OFF".
Touch Sensor
LED
Up to Six remote control units can be paired with each HomeEasy Dimmer
Switch.To program the dimmer switch, switch the lights On and Off six times.
Deleting Remote Control:
To delete a remote control that has been paired with a dimmer switch, simply
switch the lights On and Off six times.The LED will start to blink and lights will
dim up and down in steps; press the "Off" button on the remote control, the
lights will flash on and off to confirm that the remote control has been
removed from the dimmers memory.A second remote control can now be
deleted from the dimmer switch or press the touch sensor to exit the mode.
Channel reset:
To delete all the remote control units from the memory of the dimmer switch,
switch the lights On and Off six times, the LED will start to blink and lights will
dim up and down in steps,switch the lights On and Off a further six times.The
lights will flash on and off, to confirm that the memory has been reset, press
the touch sensor to exit the reset mode.
Pairing with Remote Control:
The LED will now start to flash and lights will dim up and down in steps,now
press the "ON" button on the remote control, the lights will flash on and off, a
second remote control can now be paired to the dimmer switch or press the
touch sensor to exit the pairing mode. The units are now paired together, you
can test this by pressing the selected "ON/OFF" button on your remote
control.
Always refer to the original instruction when using with additional products
Remote Control Operation:
6X
6. Ensure that all wires are fully sleeved and that only enough bare is
available to connect to the terminal. All wire must be fully inserted into
the terminals and fully tightened, so that the wires are secure and no
bare wires are protruding.
Dimmers with a metal cover plate must have an earth by means of the
earth connect point on the dimmer module
7. When the wires are connected, gently screw the dimmer unit into the wall
box, making sure that the plastic spacer is correctly aligned and that no wires
are trapped between the switch and the back of the wall box.
8. Replace the cover plate and restore the mains electrical supply.
The dimmer now needs to be activated. Press and hold the each of the
touch button(s) for 2 seconds to initialise the dimmer.
9. The dimmer now needs to be paired with a HomeEasy Remote control
- See Pairing/Deleting With Remote Control.
The HomeEasy Dimmer Switch is compatible with all HomeEasy Remote
Controls except the HE200 Programmable Timer Remote Control.
C H Byron
34, Sherwood Rd
Aston Fields
Bromsgrove
B60 3DR
Contact Details:
433MHz
R&TTE
APPROVED
CH Byron Electrical United Kingdom. www.chbyron.com
A
B
DK
FIN
F
D
GR
LT
IRL
I
L
NL
P
E
S
UK
BG
CZ
EST
H
IS
LV
M
N
SK
SLO
CH
PL
RO
0560
Tel: [phone]
Fax: [phone]
Web: www.chbyron.com
E-mail:
[email protected]
Contact:   Helpline: 0845 2301 231
PLASTICS
10 - 15%
BRICK
10 - 40%
TIMBER CONCRETE
METAL GLASS
40- 80%
10 - 40%
90% 5 - 15%
Range Reduction Guide:
The operating distance is 25 Metres
1Gang Dimmer Switch: HE-107
Input: 230V ~50Hz
Load: 400W Max  Min:40W
Range: 25 Metres (Open Distance)
Frequency: 433.92MHz
Indoor Use Only
Warning: Never Exceed the Product Specification
Product Specification:
2Gang Dimmer Switch: HE-108
Input: 230V ~50Hz
Load: 250W Max  Min:40W
Range: 25 Metres (Open Distance)
Frequency: 433.92MHz
Indoor Use Only
The radio operating distance is reduced when the signal has to pass through
solid objects and the material type
i.e. internal walls.
Tip: Using a plastic wall (back)box will increase the operating range of the
dimmer switch.
Live S
Wire Free Antenna
Earth Point
Plastic Spacer
Live S Live S
1 Gang Dimmer:
2 Gang Dimmer:
Dimmer Module A
