C-Aire HELiOS U36 User manual

HELiOSTM Reservoirs
User Manual (English)

2 - ENG PN 21157307 A | User Manual
HELiOS
Symbols Glossary
ISO 7000; Graphical symbols for use on equip-
ment—Index and synopsis
Operating temperature limitation of
these units is 10°C to 40°C. Storage
temperature limitation range is -40°C
to 70°C. Reg. # 0632
Portable humidity range is 15 to 95%.
Base humidity range is 30 to 75%.
Reg. # 2620
Keep away from rain, keep dry. Reg.
# 0626
Name and address of manufacturer.
Reg. # 3082
Caution, consult accompanying docu-
ments. Reg. # 0434A
Catalog Number. Reg. # 2493
Serial Number. Reg. # 2498
This way up. Reg. # 0623
Fragile, handle with care. Reg. #
0621
ISO 7010: Graphical symbols—Safety colors and
safety signs—Registered safety signs
Frostbite may occur on contact with
cold liquid or gaseous oxygen, or
frosted parts. Warning low tempera-
ture. To warn of low temperature or
freezing conditions. Reg. # W010
The instruction manual must be read.
Reg. # M002
Keep away from open ame, re,
sparks. Open ignition source and
smoking prohibited. Reg. # P003
Do not smoke near unit or while
operating unit. Reg. # P002
Type BF applied part (degree of
protection against electric shock).
Reg. # 5333
Warning. Reg. # W001
Council Directive 93/42/EEC; concerning medical
devices
Authorized representative in the
European Community
This device complies with the
requirements of Directive 93/42/EEC
concerning medical devices. It bears
the CE marking as shown.
This device complies with the re-
quirements of Directive 2010/35/EU
concerning medical devices. It bears
the pi marking as shown.
ADR: European Agreement concerning the Inter-
national Carriage of Dangerous Goods by Road
Non-toxic gas.
Hazard Oxidizing substances: re
intensifying risk.
Refrigerated Liquid, USP; Produced
by Air Liquefaction
Internal Symbols
Keep unit well ventilated at all times
Keep away from ammable materials,
oil and grease.
Wipe connector with clean dry cloth
before lling.
IEC 60417: Graphical Symbols for use on equip-
ment
Do not cover unit. These units nor-
mally vent oxygen. No. 5641
21 CFR 801.15: Code of Federal Regulations
Title 21
Federal law restricts this device to
sale by or on the order of a physician.
Council Directive 2012/19/EU: waste electrical
and electronic equipment (WEEE)
WEEE
IEC 60601-1: Medical electrical equipment Part
1 General requirements for basic safety and
essential performance
Drip Proof
This product may be covered by one or more
patents, US and international. Please visit our
website, Pat.: patents.cairemedical.com for listing
of applicable patents.

PN 21157307 A | User Manual 3 - ENG
HELiOS
Specifications
• Mode of Operation: Continuous Flow
• Type of Protection Against Electrical Shock: Internally Powered Equipment
• Degree of Protection Against Electrical Shock: Type BF Applied Part
• IP21 Classication According to the Degree of Protection Against Ingress of Water: Internal protec-
tion against ingress of solid foreign objects greater than or equal to 12.5 mm in diameter and ingress
of vertically dripping water.
• Equipment not suitable for use in the presence of ammable mixtures
Product Specifications
HELiOS U36 HELiOS U46 HELiOS 36 HELiOS 46
LOX capacity 85 lb
(38,6 kg)
110 lb
(49,9 kg)
85 lb
(38,6 kg)
110 lb (49,9 kg)
Gaseous equivalent
capacity
29,069 L 37,916 L 29,069 L 37,916 L
Weight, filled 138 lb (62,6 kg) 170 lb (77,1 kg) 138 lb (62,6 kg) 170 lb (77,1 kg)
Weight, empty 53 lb (24 kg) 60 lb (27,2 kg) 53 lb (24 kg) 60 lb (27,2 kg)
Height 33.5 in. (851 mm) 37.5 in. (952 mm) 33.5 in. (851 mm) 37.5 in. (952 mm)
Diameter 15.4 in. (391 mm) 15.4 in. (391 mm) 15.4 in. (391 mm) 15.4 in. (391 mm)
Typical use time at 2
LPM demand mode
10 days
21 hrs
13 days
21 hrs
10 days
21 hrs
13 days
21 hrs
Operating pressure 22 psi (152 kPa) 22 psi (152 kPa) 22 psi (152 kPa) 22 psi (152 kPa)
Normal evaporation
rate
1.2 lb/ day (0,54
kg/day)
1.2 lb/ day (0,54
kg/day)
1.2 lb/ day (0,54
kg/day)
1.2 lb/ day (0,54
kg/day)
Standard flow control
range
Maximum flow 10
LPM
Maximum flow 10
LPM
Maximum flow 10
LPM
Maximum flow 10
LPM
Flow Rate Accuracy*
* This accuracy is only at 70F and 14.7 psig and with a calibrated accurate mass ow meter.

4 - ENG PN 21157307 A | User Manual
HELiOS
Warning Information
Important: Read this manual thoroughly before
operating the HELiOS.
RX Only.
WARNING: THIS DEVICE IS NOT IN-
TENDED FOR LIFE SUSTAINING USE.
WARNING: IF YOU FEEL THE EQUIPMENT
IS NOT OPERATING PROPERLY, CALL
YOUR HEALTH CARE PROVIDER. DO NOT
ATTEMPT TO REPAIR OR ADJUST THE
UNIT YOURSELF.
WARNING: DO NOT MODIFY THIS EQUIP-
MENT WITHOUT AUTHORIZATION FROM
THE MANUFACTURER.
WARNING: IF CONTINUITY OF OXYGEN
SUPPLY IS REQUIRED, ENSURE THAT AN
ADEQUATE SUPPLY OF OXYGEN AND/
OR A SECONDARY OXYGEN SUPPLY
IS AVAILABLE AT ALL TIMES DURING
THERAPY.
WARNING: PATIENT OR OTHERS MAY
BE ENTANGLED IN CANNULA OR OTHER
TUBING CAUSING ASPHYXIATION.
WARNING: DO NOT ALLOW SMOKING,
CANDLES, OR OPEN FLAMES WITHIN 10
FEET (3 METERS) OF THE DEVICE, OR
CLOSER THAN 8 INCHES (20 CM) FROM
ANY SOURCE OF IGNITION.
WARNING: KEEP YOUR UNIT IN A WELL-
VENTILATED AREA.
WARNING: DO NOT STORE LIQUID
OXYGEN EQUIPMENT IN A CLOSET, CAR
TRUNK, OR OTHER CONFINED AREA. DO
NOT PLACE BLANKETS, DRAPERIES, OR
OTHER FABRICS OVER EQUIPMENT.
WARNING: THIS PRODUCT CAN EXPOSE YOU
TO CHEMICALS INCLUDING NICKEL, WHICH IS
KNOWN TO THE STATE OF CALIFORNIA TO CAUSE
CANCER. FOR MORE INFORMATION, GO TO
WWW.P65WARNINGS.CA.GOV.
Caution: Use the HELiOS Reservoir only
as directed by your doctor.
The unit contains liquid oxygen which is
extremely cold, almost 300°F (-184°C).
Exposure to such a low temperature can
cause severe frostbite.
Liquid and gaseous oxygen, though
nonammable, cause other materials to
burn faster than normal. This hazard,
along with the low temperature of liquid
oxygen, warrants certain safety precau-
tions.
Keep ammable materials away from
this equipment. Aerosol sprays, oils and
grease, including facial creams and pe-
troleum jelly, ignite easily and may burn
rapidly in the presence of oxygen.
Smoking while wearing an oxygen can-
nula can cause facial burns and possibly
result in death.
Removing the cannula and placing it
on clothing, bedding, sofas, or other
cushion material will cause a ash re
when exposed to a cigarette, heat source,
spark or ame.
If you smoke please: (1) turn off the
portable, (2) take off the cannula, and
(3) leave the room where the device is
located.
In the event of an accidental tip-over,
immediately but cautiously return the
unit into an upright position if possible.
If any liquid oxygen is escaping, leave
the area immediately and call your
healthcare provider. Do not attempt
to move the unit or stop the liquid
oxygen from escaping.
Do not touch frosted parts of any unit.
Do not store or operate the portable
coupled to the
HELiOS Reservoir
Do not allow untrained personnel to
handle or operate this device.
Use of this device is prohibited on com-
mercial passenger and cargo air ights
by the Federal Aviation Administration.

PN 21157307 A | User Manual 5 - ENG
HELiOS
Introduction
A liquid oxygen system is designed to provide sup-
plementary oxygen as prescribed by a physician.
Your liquid oxygen system includes a HELiOS
reservoir. This user manual contains the instruc-
tions for using the HELiOS reservoir.
The Helios reservoir is intended for the administra-
tion of supplemental oxygen to the patient in the
end user’s home and can also be used in institutions
such as nursing homes or sub-acute care facilities.
The device is not intended for life support nor does
it provide any patient monitoring capabilities. It
is recommended to have an alternate source of
supplemental oxygen in the event of mechanical
failure.
The device is used by COPD patients or those
with diminished breathing capacity. The device is
prescribed to the patient. The device is sold to a
provider that is trained to operate and service the
Helios reservoir. The provider trains the user.”
Your liquid oxygen system may also contain a
portable unit to provide an ambulatory source of
oxygen for an extended period of time. Refer to the
user manual supplied with your portable unit for
information on its operation.
The HELiOS reservoir is lled with liquid oxygen
by your health care provider. It is designed to store
the liquid oxygen for the purposes of lling a por-
table unit, and breathing directly from the reservoir
for stationary use.
The HELiOS reservoir stores liquid oxygen that
can be used to ll a portable liquid oxygen tank.
HELiOS Universal reservoirs can ll any CAIRE
top ll (TF) portable with a compatible ll connec-
HELiOS Universal Reservoir shown.
Universal & Standard reservoirs are available
in 36 and 46 liter models.
tor. HELiOS Standard reservoirs can only ll the
HELiOS H300 Plus and H850 Marathon portable
units (see Standard and Universal Reservoirs sec-
tion for model identication).
The HELiOS reservoir is also designed for station-
ary use. Continuous oxygen ow from 0-10 LPM
can be taken directly from the reservoir with the
attachment of an external ow control valve.
Another method of stationary use is to connect
a HELiOS H300 or H850 portable unit to the
HELiOS reservoir using an oxygen supply line.
When the portable is connected to the reservoir in
this manner, the reservoir supplies gas oxygen to
the portable and allows you to breathe from the
portable as a conserving (demand) device without
lling it.
Controls
1. Portable Fill Con-
nector
2. Vent Valve
3. Battery Housing
4. Contents Indicator
5. Portable Release
Button
6. Pressure Gauge
7. DISS Connection
(Breathing Oxygen
Supply)
8. Moisture Container
7
8
1
2
4
5
6
3

6 - ENG PN 21157307 A | User Manual
HELiOS
Standard & Universal
Reservoirs
HELiOS Reservoirs are available in both Standard
(H36, H46) and Universal (U36, U46) models. The
easiest way to identify which reservoir you have is
by looking at the ll connector. Universal reservoirs
have a higher ll connector whose pop-off assem-
bly is curved upward. Reference the below gure to
identify the model of your reservoir.
HELiOS Standard reservoirs will only ll the
HELiOS H300 and H850 portable units.
HELiOS Universal reservoirs will ll any CAIRE
top-ll (TF) portable unit that has a compatible
female ll connector. A compatible female ll con-
nector is shown on this page.
Universal Standard PB-Style portable
 reservoir reservoir llconnector
Operating Instructions –
Level Verification
1. Press the blue button on the contents indicator.
2. Read the LED lights to indicate the liquid con-
tents level.
• If you get a green contents level light, there is
sufcient oxygen in the reservoir to ll your
portable unit.
• If the yellow low contents light appears, the
reservoir is empty or nearing empty. Contact
your heath care provider immediately.
• If the yellow low battery light appears, inform
your healthcare provider the next time your
HELiOS reservoir is lled.
NOTE: The HELiOS reservoir will continue to fill and
deliver oxygen when the low battery light is on as
long as there is oxygen in the tank.
Green Contents Level LEDs
Yellow Low Contents LED
Push Button
Yellow Low Battery LED
HELiOS contents indicator
WARNING: REMOVE THE BATTERY FROM
THE HELIOS RESERVOIR IF THE RESER-
VOIR IS NOT LIKELY TO BE USED FOR
SOME TIME.

PN 21157307 A | User Manual 7 - ENG
HELiOS
Operating Instructions –
Filling a Portable
1. Verify the level of liquid oxygen in the unit (see
Operating Instructions — Level Verication).
2. Clean and dry the ll connectors on both the
HELiOS reservoir and the portable unit. Wipe
gently using a clean, dry, lint-free cloth.
WARNING: THE FILL CONNECTORS MUST
BE CLEAN AND DRY WITH A LINT-FREE
CLOTH ON BOTH THE STATIONARY AND
PORTABLE UNITS TO PREVENT FREEZING
AND POSSIBLE EQUIPMENT FAILURE.
WARNING: SHOULD LEAKAGE BE EXCES-
SIVE TO THE POINT THAT A STREAM OF
LIQUID IS PRESENT, LEAVE THE AREA
AND CALL YOUR HEALTH CARE PRO-
VIDER IMMEDIATELY.
WARNING: DO NOT DEPRESS OR DIS-
TURB THE METAL POPPET ON THE FILL
CONNECTOR WHEN DRYING IT. THIS CAN
CAUSE LEAKAGE OF LIQUID OXYGEN.
Caution: Should there be any liquid
leakage from the HELiOS reservoir after
separating the units, set the portable
aside, ensuring it remains vertical, leave
the room and call your health care pro-
vider immediately.
3. Turn the ow control knob on the portable unit to
the off (0) position.
4. Follow the lling instructions provided for your
portable unit.
Operating Instructions –
Breathing Directly from the
Reservoir
Note: Use the duration charts available at www.
cairemedical.com as a guideline to determine the
length of time your HELiOS reservoir will operate
continuously at a given flow rate.
1. Verify the level of liquid oxygen in the unit (see
Operating Instructions — Level Verication).
2. Use the following chart as a guideline to the
recommended tubing length.
FLOW
SETTING
MAXIMUM (RECOMMENDED)
TUBING LENGTH*
(LPM) 22-psig
1-6 100 Ft. (30.5 m)
8 100 Ft. (30.5 m)
10 50 Ft. (15.2 m)
*Length is oxygen tubing only. Does not include a 7 Ft. cannula.
3. Attach an external ow control valve (FCV) to
the DISS connection of the reservoir. Make sure
to tighten the nut until no hissing sound is heard.
External
Flow Control
Tubing Adaptor
Nasal Cannula
Attachment of external ow control valve
4. Ifahumidierbottlewillnotbeused:
• Attach a tubing adaptor to the bottom of the
external ow control valve.
• Attach your nasal cannula or oxygen tubing
to the tubing adaptor.
Ifahumidierbottlewillbeused:
• Attach a humidier bottle to the bottom on
the external ow control valve.
• Fill the humidier bottle with distilled
water to the proper level as indicated by the
humidier’s instructions.
• Attach your nasal cannula or oxygen tubing
to the connector on the humidier bottle.
Humidier
Bottle
Nasal Cannula
External
Flow Control
Valve
Caution: To ensure proper flow rates, verify that all
fittings are tight and leak free.
Attachment of a humidier bottle to the external ow control valve.

8 - ENG PN 21157307 A | User Manual
HELiOS
Operating Instructions –
Using the HELiOS Supply Line
1. Thread the oxygen supply line nut onto the DISS
connection of your HELiOS reservoir. Make
sure to tighten the nut until no hissing sound is
heard.
Oxygen Outlet
Connection
Oxygen Supply
Line
Attaching the oxygen supply line to the reservoir
2. Connect the opposite end of the oxygen supply
line to an H300 Plus or H850 Marathon by
pushing the supply line into the connector on the
left-hand side of the unit.
Oxygen Supply
Line
Oxygen Supply
Connector
Release Button
Attaching the oxygen supply line to the H300 or H850 portable
3. Breathe from your portable as normal, following
the operating instructions provided with the
H300 or H850 unit. Use only in the demand
mode only for the H850.
NOTE: For H300’s and H850’s that have the CPC
connector installed or Retrofit Kit P/N 20748595 is
available.
5. Turn the knob on the external ow control valve
until your prescribed continuous ow rate (nu-
meric in LPM) is displayed in the window and a
positive detent is felt.
NOTE: The knob should not be set higher than the
maximum flow rate prescribed by a physician.
NOTE: Out-of-specification oxygen flow will result if
the flow control knob is set between flow rates.
6. Properly position your nasal cannula and adjust
it for comfort.
NOTE: Ensure the cannula is fully inserted and secure.
During inhalation, you should hear or feel oxygen
flow to the prongs of the nasal cannula. The proper
placement and positioning of the prongs of the
nasal cannula in your nose is critical to the amount
of oxygen delivered to the respiratory system of the
end user.
7. You should be receiving oxygen now. Check
to make sure you feel oxygen ow into your
nose and that there are bubbles in the humidier
bottle (if used).
8. Turn the ow control knob to the off (0) position
when the reservoir is not in use.
9. Under certain environmental conditions with
continuous use, the HELiOS reservoir may
develop an excessive amount of ice on the coils
visible under the shroud. You should defrost the
unit between uses to minimize this ice buildup.
To de-frost the unit:
• Fill a portable unit so that you can continue to
receive oxygen while the HELiOS reservoir
defrosts
• Set the knob on the external ow control
valve to the off (0) position and allow the
unit to warm to room temperature, as indi-
cated by the melting of all ice from under the
shroud.
• Check the moisture container frequently dur-
ing defrosting and empty as required.
• The container should be emptied whenever
the water reaches the (1/1) line visible on the
outside of the container. If the water is not
emptied, moisture may spill onto your oor.
• To empty the moisture container, pull out on
the container and pour the water into a sink
for disposal.
Moisture
Container
Emptying the Moisture Container

PN 21157307 A | User Manual 9 - ENG
HELiOS
User Troubleshooting
The following information is intended to help you troubleshoot and solve simple operational problems that
you may experience when using your HELIOS Reservoir.
Issue Solution
The Reservoir makes a
hissing sound.
• Hissing can occur to maintain the correct operating pressure within the Reser-
voir. It is most likely to hiss after filling or when the position of the Reservoir
is changed. Hissing can last for 30-60 minutes after filling. Furthermore,
improper filling or lower than normal operating pressure in the Reservoir will
contribute to the unit not being able to fill portables and improper flows
The Reservoir flow stops
during use.
• Ensure that the cannula is firmly attached to the Oxygen Outlet.
• Ensure that the cannula is not kinked.
• Ensure that there is oxygen in the Reservoir.
The Portable does not fill. • Verify that there is oxygen in the Reservoir.
• Ensure that the Portable and Reservoir fill connectors are fully engaged
throughout the filling process.
The Portable vent valve
does not close properly
at the end of the filling
process.
• If the vent valve fails to close and the hissing sound and oxygen vapor cloud
continue, carefully remove the Portable by depressing the release button on
the Reservoir. Venting from the bottom of the Portable will stop in a few min-
utes. Allow the unit to warm until you can close the vent valve. The Portable
may require as long as 60 minutes to restore adequate pressure for accurate
oxygen flow. If needed, use an alternate source of oxygen such as a flow
control valve attached to the Reservoir.
The Portable does not
disengage easily from the
Reservoir after filling.
• The Portable and Reservoir fill connectors may have become frozen.
• DO NOT USE FORCE OR USE WATER. Allow a few minutes for the frozen parts
to warm, then disengage the Portable when the ice has melted. To prevent
the units from freezing together, always wipe the male fill connector on the
Reservoir and the female fill connector on the Portable with a clean, dry cloth
before filling.
Liquid is spraying from the
top of the reservoir.
• Contact Oxygen Provider
• Open doors and windows.
• Leave the area immediately.
Frost and ice buildup and
or condensation.
• Some frost and condensation is normal on the warming coils
• Condensate collector is full; empty the tray.
• Ensure the Flow Control Knob is closed if not in use.
Maintenance
Clean the ll connectors on both the stationary
and portable units with a clean, dry, lint-free cloth
between each ll to prevent freezing and possible
equipment failure.
There are no user-serviceable parts in the Helios.
Your service provider is responsible for any mainte-
nance that my be required per the technical manual
of this device. Call your service provider for any
maintenance requirements.
The expected service life is a minimum of ve
years.

10 - ENG PN 21157307 A | User Manual
HELiOS
Accessories
15 in (38.1 cm) Roller Base for
HELiOS Reservoirs, available for
all models.
NOTE: Only use roller base on flat
surfaces.
0-10 LPM External Flow Control
Valve
Allows you to breath continuously
from it between 0-10 LPM. If pre-
scribed, your health care provider
will provide it.
50 ft (15.24 m) HELiOS Oxygen
Supply Line
Used to connect an H300 or H850
portable unit to your reservoir to
allow the portable to be used as a
conserving device.
NOTE: When using the HELIOS
oxygen supply line with the H850,
the portable must be in demand
mode.
Cleaning Standard
WARNING: CLEAN ONLY AFTER THE UNIT
IS EMPTY.
• Clean using a solution of mild dish washing
detergent and water.
• Apply cleaning solution directly to a lint-free
cloth. Approved cleaners include HydroPure
and HydroKlean. Do not spray cleaners
directly on the HELiOS Reservoir.
• Wipe the outside surface with the lint-free
cloth until the outside surface is clean.
Caution: Do not use high temperature
and high pressure washing equipment
to clean these units.
• Do not get cleaner on any internal compo-
nents or valves.
• Allow the unit to dry thoroughly before using.
Note: Note to health care provider – for reprocessing
procedures, see applicable service manual.
Disposal
Always return HELiOS Reservoir, including all
components, to your homecare provider for proper
disposal. You can also contact your local city or
town ofces for instructions on proper disposal of
the battery.
WEEE and RoHS
This symbol is to remind the equipment
owners to return it to a recycling facility at
the end of its life, per Waste Electrical and
Electronic Equipment (WEEE) Directive.
Our products will comply with the restriction of
Hazardous Substances (RoHS) directive. They will
not contain more than trace amounts of lead or
other hazardous material content.
Transport and Storage
The device should be stored in the upright position,
and be well ventilated. Do not allow the device to
lie on its side. Humidity up to 95% noncondensing.
Temperatures range from -40°F to 158°F (-40°C to
70°C).
Operating temperature ranges from 14°F to 104°F
(10°C to 40°C). Relative humidity range from 30%
to 75% noncondensing.
Note: The atmospheric pressure range is 700 hPa to
1060 hPa (elevation of 10,000 Ft. to -1,000 Ft.).
