C.T.M. HS-915 User manual

C.T.M. MOBILITY SCOOTER
C.T.M. MOBILITY SCOOTER
C.T.M. MOBILITY SCOOTER
9-Series Instruction Booklet
HS-915
HS-928

Instruction Booklet9-Series
TABLE OF CONTENTS
INTRODUCTION
IMPORTANT PRECAUTIONS
ELECTROMAGNETIC INTERFERENCE AND WARNINGS
IDENTIFICATION OF PARTS
CHARGING THE BATTERIES
DISASSEMBLING YOUR SCOOTER
LCD DISPLAY PANEL
CAUTION
TECHNICAL SPECIFICATIONS
--------------------------------------------------------1
----------------------------------------2
----3
----------------------------------------5
--------------------------------------11
------------------------------13
------------------------------------------------15
---------------------------------------------------------------26
------------------------------------27

Instruction Booklet9-Series
Information of European Representative :
EMERGO EUROPE
Molenstraat 15
2513 BH, The Hague
The Netherlands
Thank you and congratulations on purchasing your new C.T.M. Mobility Scooter.
It is designed to provide you with transportation ability indoors and outdoors.
We pride ourselves on providing safe and comfortable products. Our goal is to ensure
your complete satisfaction. We sincerely hope you enjoy your C.T.M. Mobility Scooter.
Please read and observe all warnings and instructions provided in owner's manual before
you operate the various functions of this scooter. Also, please retain this booklet for future
reference.
If you have any question, you can contact :
INTRODUCTION
1
CHIEN TI ENTERPRISE CO., LTD.
No. 7, Lane 227, Fu Ying Rd., Sin Jhuang Dist., New Taipei City, Taiwan
Tel : [phone] Fax : [phone]
E-Mail : [email protected] http : //www.chienti.com.tw

Instruction Booklet9-Series
IMPORTANT PRECAUTIONS
2
•The weight capacity limit at different ramp degree (please refer to following picture).
•The grade climbing degree will be affected by weight capacity, driving speed, and ramp degree, and scooter parameter.
•To prevent any danger from motor defected; please avoid to drive on long ramp or any uneven terrain.
85 kg / 9 degree 190 kg / 6 degree HS-928 226 kg / 3 degree
HS-915 190 kg / 3 degree
•Only one person at a time could ride a C.T.M. Mobility Scooter.
•Maximum load : HS-915 is 190 kgs / 419 ; HS-928 is 226 kgs / 498 pounds.
•Turn key off before getting on or off.
•Always drive carefully and be aware of others using the same area.
•Always use pedestrian crossings wherever possible. Take extreme care when crossing
roads.
•
Do not drive on slope exceeding 9 degree, and take extreme care when turning on slope.
•Do not use full power when turning to sharp corner.
•Take great care and drive in low speed when backing up, riding downhill or on uneven
surface, and climbing curb.
•Please use the lowest speed when driving through the descending road or uneven terrain.
If speed is too fast, leave your hand off the handle bar, let the scooter stop. Make sure
safety and start again.
•A slow speed must always be used when ascending, descending or traversing aslope
or incline and also on uneven terrain, ramps and soft or loose surfaces, such as gravel
or grass.
•To prevent any danger, do not turn around at high speed on ascending, descending ramp.
•Scooter may not operate well in high humidity.
•Do not leave the powered scooter in a rain storm of any kind.
•Do not use the powered scooter in a shower.
•Direct exposure to rain or dampness will cause the scooter to malfunction electrically
and mechanically; may cause the powered scooter to prematurely rust.
•Never put scooter in neutral when staying on slopes.
•Follow traffic laws when riding outside.
•When scooter on moving transport vehicles, do not sit or stay on scooter.

Instruction Booklet9-Series
2.Medium-range mobile transceivers, such as those used in police cars, fire trucks,
ambulances, and taxis. These usually have the antenna mounted on the outside of the
vehicle; and
3.Long-range transmitters and transceivers such as commercial broadcast transmitters
(radio and TV broadcast antenna towers) and amateur (HAM) radios
Other types of hand-held devices, such as cordless phones, laptop
computers, AM/FM radios, TV sets, CD players, and cassette players,
and small appliances, such as electric shavers and hair dryers, so far as.
we know, are not likely to cause EMI problems to your motorized scooter.
ELECTROMAGNETIC INTERFERENCE
AND WARNINGS
3
CAUTION: It is very important that you read this information regarding the possible
effects of Electromagnetic Interference on your motorized scooter.
Powered wheelchairs and motorized scooters may be susceptible to electromagnetic
interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources
such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and
cellular phones. The interference (from radio wave sources) can cause the motorized
scooter to release its brakes, move by itself, or move in unintended directions. It can also
permanently damage the motorized scooter control system. The intensity of the interfering
EM energy can be measured in volts per meter (V/m). Each motorized scooter can resist
EMI up to a certain intensity. This is called its "immunity level." The higher the immunity
level, the greater the protection. At this time, current technology is capable of achieving
at least a 20 V/m immunity level, which would provide useful protection from the more
common sources of radiated EMI. The immunity level of this motorized scooter model is
not known.
There are a number of sources of relatively intense electromagnetic fields in the everyday
environment. Some of these sources are obvious and easy to avoid. Others are not
apparent and exposure is unavoidable. However, we believe that by following the warnings
listed below, your risk to EMI will be minimized.
Some cellular telephones and similar devices transmit signals while
they are ON, even when not being used
The sources of radiated EMI can be broadly classified into three types :
1.Hand-held portable transceivers (transmitters-receivers) with the antenna mounted
directly on the transmitting unit. Examples include: citizens band (CB) radios, "walkie
talkie," security, fire, and police transceivers, cellular telephones, and other personal
communication devices

Instruction Booklet9-Series
4
There is no easy way to evaluate their effect on the overall immunity of
the motorized scooter.
Because EM energy rapidly becomes more intense as one moves closer to the transmitting
antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of
special concern. It is possible to unintentionally bring high levels of EM energy very close
to the motorized scooter control system while using these devices. This can affect
motorized scooter movement and braking. Therefore, the warnings listed below are
recommended to prevent possible interference with the control system of the motorized
scooter.
Motorized Scooter Electromagnetic Interference：
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur
radio (HAM) transmitters, two-way radios, and cellular phones can affect motorized scooters.
Following the warnings listed below should reduce the chance of unintended brake release
or motorized scooter movement which could result in serious injury.
1.Do not operate hand-held transceivers (transmitters-receivers), such as citizens band
(CB) radios, or turn ON personal communication devices, such as cellular phones, while
the motorized scooter is turned ON;
2.Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming
close to them;
3.If unintended movement or brake release occurs, turn the motorized scooter OFF as
soon as it is safe;
4.Be aware that adding accessories or components, or modifying the motorized scooter,
may make it more susceptible to EMI; and
Warnings：
1.20 volts per meter (V/m) is a generally achievable and useful immunity level against
EMI (as of May 1994). The higher the level, the greater the protection.
2.The immunity level of this product is at least 20/Vm.
5.Report all incidents of unintended movement or brake release to the distributor listed
on the inside front cover of this manual. Note whether there is a source of EMI nearby.
Important Information：

Instruction Booklet9-Series
Wigwag
Seat fore-aft
Adj Lever
Hand Brake
Tiller Angle
Adjustment
22" Captain Seat
Seat Back Angle
Adjustment
Rear Bumper
Swivel Lever
Side Reflector
Rear Mirror
Rear Bag
N-D Lever
Turn Signal
Rear
Reflector
Anti-Tipper
Turn Signal
Headlight
Front Bumper
Left Turn
Indicator
Hazard
Light
Left Turn
Signal
Acceleration
Headlight
Indicator
Mode
Headlight
Hi/Lo
Switch
Power
Indicator High Speed Indicator Right Turn Indicator
Horn Right Turn
Signal
Deceleration
Figure 1 - HS-928 Front View
Figure 2 - HS-928 Control Panel
Figure 3 - HS-928 Rear View
IDENTIFICATION OF PARTS
5
Before you take your first trip, you should familiarize yourself well with the operation of
the scooter and with all operating elements. Take your time to test all functions and driving
modes.
Angle Armrest
Adjustment
Tiller Storage
Compartment

Instruction Booklet9-Series
Always ensure that the scooter is switched
off before getting on or off the scooter and
before removing any items of the scooter
Turning the scooter OFF whilst driving will
bring the scooter to an abrupt stop and
danger.
6
FUNCTION OF PARTS：
Main Key Switch (A)
1.Turn the key to the right - Turn the scooter on
2.Turn the key to the left - Turn the scooter off
TOP CONTROL PANEL
Hazard Light (B) : Switch on by pressing once, switch
off by pressing again. Press hazard light button once,
the right/left lights and parking indicator start to flash,
warning tone acts as well; If the Hazard lights are activated,
with the key switched to the on position, the lights will
continue to flash even when the key is switched off. The
Hazard light button should be depressed to cancel the flashing.
Mode (C) : Change mode by pressing once
a. Clock
b. Temperature
c. Speedometer
d. ODO
e. Trip Meter
Horn (D) : Press horn button once to sound warning tone when necessary.
Left Turn Signal (E) : Press Left Turn Signal button once, the front and rear left turn
indicators start to flash, and warning tone sounds simultaneously;
press button again to switch off the turn indicators/signal and tone.
Right Turn Signal (G) : Press Right Turn Signal button once, the front and rear right
turn indicators start to flash, and warning tone sounds simultaneously;
press button again to switch off the turn indicators/signal and tone
Headlight (F) : Press headlight button once to switch on, switch off by pressing again.
Acceleration (H) : Press acceleration button once to increase speed, fine tune in 1'5
speeds.
Deceleration (J) : Press acceleration button once to decrease speed, fine tune in 1'5
speeds.
Hi/Lo Switch (I) : Press H/L Speed button once, the High/Low Speed Indicator will
light on, means driving in high speed mode; Press again, the indicator
will extinguish means driving in low speed mode.
(Hi/Lo speed will vary depend on your current speed settings)
Figure 4
Figure 4
(A)
Figure 5
Figure 5
(B)
(C)
(D)
(E) (F) (G)
(H)
(I)
(J)

Instruction Booklet9-Series
Adjust angle adjustment while driving is prohibited.
Adjust steering to the foremost position before and after getting on the scooter.
By pressing angle adjustment (N) down to adjust to any comfortable angles.
Steering Adjustment
7
If you have to brake in an emergency, simply release the thumb lever and
hold hand brake, which will bring you to a halt!
Keep LCD display panel and Wigwag Lever dry, if panel and Wigwag Lever
get wet, allow to dry out before using.
Tiller Storage Compartment (K) Provide you a spacious room to put things.
Hand Brake (L). Hold brake (L), when immediate stop is required.
Pull the left-hand drive lever (M) carefully to travel forwards.
Pull the right-hand drive lever (N) carefully to travel in reverse.
(This can be reversed if required by local dealer.) Releasing both, engages automatic
brake. These are also your accelerator. The further you depress them, the faster you
go. (Subject to the position of the Rabbit / Turtle control).
Figure 6
Figure 6
(L)
(K)
Figure 7
Figure 7
(M)
(N)
Figure 8
Figure 8
(O)
Wigwag Lever Operation

Instruction Booklet9-Series
Pull the lever (T) upwards to disengage and rotate seat (P) to required angle, Let go of
the lever (T) to lock the seat into its required position.
Seat Swivel Adjustment
Pull the lever (U) upwards to adjust backrest's angle, then release the lever when adjusted
to required position.
Seat Back Angle Adjustment
8
When driving the scooter, set the seat (P) at foremost position to prevent
tip over.
Pull the armrest up when get on or off the scooter.
Do not hang heavy parts on the armrests to cause tip over.
For safety reasons the backrest's position must remain vertical before driving.
Sit firmly on seat after getting on the scooter, do not stand on the foot rest
to prevent tipping over or damaging to the scooter.
Seat Fore-Aft Adjustment (P)
Pull the Seat fore-aft Adj Lever (Q) to disengage the seat (P). Slide the seat forwards or
backwards into the required position. Let go of the lever (Q) again to lock the seat into its
required position.
Angle Armrest Adjustment (R)
Pull the lever (S) and adjust the armrest to the required angle.
Figure 10
Figure 10
(R)
(S)
Figure 9
Figure 9
(P)
(Q)
Figure 12
Figure 12
(U)
Figure 11
Figure 11
(P)
(T)

Instruction Booklet9-Series
9
1.Refer to page 13 for disassembly, then remove seat (P) and rear shroud (Z). (Figs 18 & 19)
2.Remove screw, nut and washer from seat post (V). (Fig 13)
3.Adjust seat post (V) to desired height, and attached tightly with screw, nut and washers. (Fig 13)
4.Then assemble the rear shroud (Z), seat (P) back to its original position. (Fig 18 & 19)
Seat (P) Height Adjustment
•Do not operate this function on a slope, or in motion or under unstable
condition.
•The main purpose of this function is to assist you to reach certain height.
•Seat's position must remain at the lowest before driving.
•Do not set N-D lever at N, before setting the seat at lowest position.
•Please keep the center of gravity of the scooter in the middle, to prevent
the scooter tipping over.
Freewheel operation is only recommended on flat surfaces, never on
gradients. Never leave your scooter on a gradient with its motors disengaged.
Always re-engage the motors immediately after pushing the scooter.
1.Press seat lifter button (W) lightly, seat will raise.
press lightly, seat will lower.
Seat (P) Electrical Lifter (Optional)
1.When scooter stopped or malfunction, press the unlocking knob on the N-D lever (X).
Push the N-D lever forwards this will allow you to push the scooter by hand.
N-D Lever Adjustment :
Figure 14
Figure 14
(V)
(P)
(W)
Figure 13
Figure 13
Figure 15
Figure 15
(X)
N
D
The scooter won't operate, if the
scooter is setting at N position,
to restore to it's normal status,
you must switch the power off
and adjust to D position, then
switch the power on.
(V)
Figure 13
Figure 13

Instruction Booklet9-Series
Avoid shifting your center of gravity as well as abrupt changes of direction
when the scooter is in motion.
When fixed on a transportation system, N-D lever ( X ) must located at D position.
This scooter must not be occupied or used as a seat in a motor vehicle
whilst being transported.
Reduce speed before negotiating corners! Only accelerate when you have
come out of the corner!
10
1.The scooter is equipped with proportional speed reduction. It will automatically reduce
speed when encountering a corner, reducing speed corresponding to the angle of turn.
2.For safety reasons, when pushing the scooter by hand, if a pre-determined speed is
exceeded, the controller automatically switches on and brakes the scooter.
Proportional Speed Reduction :
To enable you to transport your scooter safely and securely there are 2 additional tie down
hooks located on the underside of the scooter. (Fig 16)
Tie - Down Hook :
Figure 16
Figure 16
(Y)

Instruction Booklet9-Series
◎Connect Power supply:
LED (POWER) - RED LIGHT ON
LED (CHARGE) - RED LIGHT ON
◎CC mode:
LED (CHARGE) - ORANGE LIGHT ON
◎Full charged:
LED (CHARGE)-GREEN LIGHT ON
Operating Instruction
1.Make sure the power cord, battery cable, battery terminals are in good condition.
2.Make sure the charge output voltage is the same as the connecting battery.
3.Connect the connector of battery charger to the connector of battery firstly, and then
connect the AC power.
4.Make sure the AC voltage is correct and plug in the power cord normally.
The LED (Power) light will turn on when electric current passes.
5.During charging, LED (Charge) will indicate orange light. When it turns to green light,
that means fully charged.
LED Indication
Batteries must be charged before using the scooter for the first time and should be
recharged after each day use. You will need the scooter and the battery charger.
Maintenance & Repair must only be carried out by a Competent Engineer
or Authorised Dealer or Agent.
11
CHARGING THE BATTERIES
Figure 17
Figure 17
Each country may supply different charger. The charging procedure
may be different from below. If you require more details, please contact
your authorized dealer.
Be sure the scooter key is in the OFF position

Instruction Booklet9-Series
Troubles Shooting
1.LED(POWER) light is off
Make sure the battery charger output connector is connected properly, and make sure
the battery voltage is higher than the lowest charge voltage range
2.LED(CHARGE)light is off
Check if the connectors are correctly connected.
3.During Charging, LED(CHARGE) light is flashing red, then into the charging abnormal
protected.Need to unplug the AC power, to wait for the power indicator light turns off
completely, then plug in the AC power supply, return to normal work
Warnings
•Fully charge batteries at least once a month, or more if you use scooter regularly.
Charge after each trip exceeding 3 kilometers.
•If storing your scooter for some time (1 month or more), make sure that batteries are
fully charged, and on returning, charge them again before using scooter.
•Batteries will only give maximum performance after scooter has been used, and
batteries have been recharged up to 10 times. A bit like breaking in a new car.
The time needed to recharge will vary depending on the depletion of the
batteries. (Approx. 8 hours). Do no continuous charging for over 15 hours.
12

Instruction Booklet9-Series
If found the seat (P) uneasy to remove, hold seat swivel lever (R), and then
rotate the seat to reduce resistance then pull up.
Proceed with caution, if you need assistance, please have some one to help you
Take into account the heavy weight of the batteries (C1) please consider
your physical condition before disassembling.
DO NOT short-circuit battery terminals (C1).
Battery's red wire plug connects to red positive location, black wire plug
connects to black negative location.
For safety reason, please wash your hands after disassembly.
Pull the lever (T) upwards to disengage the seat (P), hold the seat (P) firmly by the
backrest and front edge and remove it upwards.
Seat (P) disassembling :
1.Remove rear shroud (Z) upwards. (Figure 18)
2.Unplug one battery connector (A1) (Figure 19)
3.Release Velcro (B1) (Figure 20)
4.Remove two batteries (C1) (Figure 21)
Rear Shroud (Z) and Batteries (C1) Disassembling :
13
DISASSEMBLING YOUR SCOOTER
Figure 18
Figure 18
Figure 19
Figure 19
(P)
(T)
Figure 20
Figure 20
(B1)
Figure 21
Figure 21
(C1)
(C1)
(A1)
(Z)

Instruction Booklet9-Series
NEVER defeat or bypass the circuit breaker.
ONLY replace with a circuit breaker of the same rating.
Resetting the circuit breaker may be needed if scooter does not turn on and when a scooter's
circuit over loaded, the circuit breaker will trip.
1.To reset, press the circuit breaker button (D1) upwards.
2.Reassemble the rear shroud (Z).
3.Reassemble the seat.
If the circuit breaker trips repeatedly, IMMEDIATELY unplug charger and contact dealer
or a qualified technician.
Resetting the Circuit Breaker :
14
Figure 22
Figure 22
Figure 23
Figure 23
(D1)

Instruction Booklet9-Series
Function Buttons & Indicators
15
LCD DISPLAY PANEL
Figure 25
Figure 25
ITEM SPECIFICATION
Control Buttons
LED Indicators
Connector
LCD Back Light
Hazard Light, Horn, Right Turn Light, Headlight, Left Turn
Light, Turtle(decelerate), H/L Speed, Rabbit(accelerate)
Status Indicator (Green)
Headlight Indicator (Green)
Left / Right Indicators (Green)
High/Low Speed Indicator (Green)
20PIN
Blue LEDs illuminate while key on.
Function Descriptions
FUNCTION SPECIFICATION
1.Full Lighting
Control
2.Speedometer
3.Digital High / Low
Speed Control
4.Power Indicator
5.Malfunction
Messages
6.Key On Display
7.Warning Tone
Setup
Headlight , Taillight, Left/Right Turn Signal, Hazard
Light, Brake Light
7 Segment display (2 1/2 digits +1 decimal)
"km/h" and "mph" symbol
Low (L) Speed: 1 - 5 Rate
High (H) Speed: 1 - 5 Rate
Battery discharge and charging indicator (6 segments)
Error code: 1~7 (1 digit) + LED Indicator
LCD full segments display
Volume adjustment for tones of Left/Right turn light,
Parking light, Low voltage warning and horn

Instruction Booklet9-Series
1.Full Lighting Control
16
Headlight, Taillight
ITEM SPECIFICATION
Operation
Feature
Usage Condition
Remarks
Control Mode
Take exterior headlight switch as determinant signal.
Press button to turn on headlight & turn signal and
headlight indicator.
Press button again to turn off headlight & turn signal and
headlight indicator.
While (1) controller shut down (2) on power-saving mode,
all functions closed.
(1) Loop Load of Headlight : 12V/50W Max
(2) Loop Load of Taillight : 24V/50W Max
(3) With "short circuit" and "overload" protection
Brake Light
ITEM SPECIFICATION
Operation
Feature
Usage Condition
Remarks
Control Mode
Take accelerator & manual brake as determinant signal.
While
(1)accelerator is moved from Forward to Center position,
(2)
accelerator is moved from Backward to Center position or
(3) manual brake is operated, the vehicle is considered to brake.
The brake light will be lit After 5 seconds, the light will
switch off automatically.
While (1) controller shut down (2) on power-saving mode, all
functions closed.
(1) Loop Load of Brake light: 24V/50W Max
(2) With "short circuit" and "overload" protection
ITEM DESCRIPTIONS
(Control Mode)
Left Turn Light
Press left-indicator button once, the left light and left
indicator starts to flash, and warning tone sounds
simultaneously; press button again to switch off the
indicator/light and tone.
Right Turn Light
Press right-indicator button once, the right light and right
indicator starts to flash, and warning tone sounds
simultaneously; press button again to switch off the
indicator/light and tone.
Turn Light and Parking Lights

Instruction Booklet9-Series
L
F
E
AM
SPD TRIP ODO
2-1 Clock
2.Mode
ITEM DESCRIPTIONS
Timekeeping
error per day
Time Format
(12 hours- AM/PM)
Initial Display 「HH」「MM」Mode :「AM 12:00」
Press「Mode」button and switch to Clock mode.
Display range : AM12:00 ~ PM11:59
HH display : The "0 of ten's digit is invisible from
1O' clock to 9O' clock.
Hazard Lights
Press hazard indicator button once, the right/left lights
and hazard indicator start to flash, warning tone acts as
well; press button again will turn off above indicators and
tone. To activate the parking lights while KEY ON, the
lights would keep flashing even KEY OFF.
Determinant
Condition There is no priority between left / right lights or parking lights.
Usage Condition While (1) controller shut down (2) in charging-mode,
the function will be disabled.
Flicker Frequency 1 second, Duty 50%
Warning Tone
Frequency 1 second, Duty 30%
Remarks
(1)Load circuit for left turn light: 24V/50W max
(2)Load circuit for right turn light: 24V/50W max
(3)With "short circuit" and "overload" protection
(4)The volume of warning tones for left/right turn lights,
parking lights could be adjusted.
Automatic Turn Off The direction lights and indicators will be turned off
automatically while flashing for 30 seconds.
17
2 seconds
+
-

Instruction Booklet9-Series
The user could quit the setup mode with the following
conditions.
(1) Leave or buttons alone for 15secs.
(2) Press any button of Parking light, Horn, Turn signal or
Headlight, the definitive settings will be stored and return
to normal thermometer mode.
Press + together for 3 secs to enter setup mode.
While「
o
C」/ (「
o
F」) is flashing, press or
to switch to「
o
F」/ (「
o
C」)
Setup Mode
(Time adjustment)
Press + together for 3 secs to enter setup mode.
While「HH」zis flashing,
Press to increase digits and to decrease digits.
Press「Mode」to enter¡yMM¡zsetup mode when finished.
While「MM」is flashing,
Press to increase digits and to decrease digits.
Press「Mode」to return「HH」setup mode when finished.
Press ( ) once to increase (decrease) one digit. The
digits can increase (decrease) accumulating when press the
buttons more than 2 secs. The display is cycling. It takes 2
secs to increase from 0 to 9 for each position.
Quit Setup Mode The user could quit the setup mode with the following
conditions.
(1) Leave or buttons alone for 15secs.
(2) Press any button of Parking light, Horn, Turn light or
Headlight, the definitive settings will be stored and return
to normal clock mode.
18
2-2 Thermometer
ITEM DESCRIPTIONS
Display Errors
Operational
Mode of
Thermometer
Operation
Feature Use thermistor (NTC) to detect the signal and transfers to related temperature.
Press「Mode」button and switch to thermometer mode
Setup Mode
(Unit change)
Quit Setup Mode
Display range : Centigrade -20~50
o
C or Fahrenheit
-4~122
o
F
2
o
C
+
-
H
F
E
O
C
SPD TRIP ODO
