C.T.M. 7 Series User manual

C.T.M. MOBILITY SCOOTER
C.T.M. MOBILITY SCOOTER
C.T.M. MOBILITY SCOOTER
7-Series Instruction Booklet
HS-735
HS-745

Instruction Booklet7-Series
TABLE OF CONTENTS
INTRODUCTION
IMPORTANT PRECAUTIONS
ELECTROMAGNETIC INTERFERENCE AND WARNINGS
SAFETY WARNING AND INSTRUCTION LABELS
IDENTIFICATION OF PARTS
OPERATING YOUR SCOOTER
DISASSEMBLING YOUR SCOOTER
ASSEMBLING YOUR SCOOTER
CHARGING THE BATTERIES
CARE AND MAINTENANCE
TROUBLE SHOOTING
OTHER INFORMATION
TECHNICAL SPECIFICATIONS
-------------------------------------------------------1
---------------------------------------2
---3
--------------5
----------------------------------------6
-------------------------------------8
------------------------------9
---------------------------------10
-------------------------------------11
---------------------------------------12
---------------------------------------------13
--------------------------------------------14
----------------------------------15

Instruction Booklet7-Series
Information of European Representative :
EMERGO EUROPE
Prinsessegracht 20
2514 AP The Hague
The Netherlands
If you have any questions, you can contact:
INTRODUCTION
1
Thank you and congratulations on purchasing your new C.T.M. Mobility Scooter. It
is designed to provide you with transportation indoors and outdoors.
We pride ourselves on providing safe and comfortable products. Our goal is to ensure
your complete satisfaction with our product. We are certain that you will enjoy your
C.T.M. mobility scooter.
Please read and observe all warnings and instructions given in the owner's manual
before operating this scooter. Also, retain this booklet for future reference.
CHIEN TI ENTERPRISE CO., LTD.
No. 13, Lane 227, Fu Ying Rd., Hsin Chuang District,
New Taipei City, Taiwan
Tel : [phone] Fax : [phone]
E-Mail : [email protected] http : //www.chienti.com.tw

Instruction Booklet7-Series
IMPORTANT PRECAUTIONS
2
•Only one person at a time could ride a C.T.M. Mobility Scooter.
•Maximum load is 181 kg / 400 lbs.
•Turn key off before getting on or off.
•Always drive carefully and be aware of others using the same area.
•Always use pedestrian crossings wherever possible. Take extreme care when crossing
roads.
•
Do not drive on slope exceeding a 1 in 4 degree, and take extreme care when turning on slope.
•Do not use full power when turning to sharp corner.
•Take great care and drive in low speed when backing up, riding downhill or on uneven
surface, and climbing curb.
•Please use the lowest speed when driving through the descending road or uneven terrain.
If speed is too fast, leave your hand off the handle bar, let the scooter stop. Make sure
safety and start again.
•A slow speed must always be used when ascending, descending or traversing aslope
or incline and also on uneven terrain, ramps and soft or loose surfaces, such as gravel
or grass.
•To prevent any danger, do not turn around at high speed on ascending, descending ramp.
•Scooter may not operate well in high humidity.
•Do not leave the powered scooter in a rain storm of any kind.
•Do not use the powered scooter in a shower.
•Direct exposure to rain or dampness will cause the scooter to malfunction electrically
and mechanically; may cause the powered scooter to prematurely rust.
•Never put scooter in neutral when staying on slopes.
•Follow traffic laws when riding outside.
•When scooter on moving transport vehicles, do not sit or stay on scooter.
•The weight capacity limit at different ramp degree (please refer to following picture).
•The grade climbing degree will be affected by weight capacity, driving speed, and ramp degree, and scooter parameter.
•To prevent any danger from motor defected; please avoid to drive on long ramp or any uneven terrain.
45 kg /
11 degree 59 kg / 9 degree 91 kg / 7 degree 181 kg / 5degree

Instruction Booklet7-Series
2.Medium-range mobile transceivers, such as those used in police cars, fire trucks,
ambulances, and taxis. These usually have the antenna mounted on the outside of the
vehicle; and
3.Long-range transmitters and transceivers such as commercial broadcast transmitters
(radio and TV broadcast antenna towers) and amateur (HAM) radios.
Other types of hand-held devices, such as cordless phones, laptop
computers, AM/FM radios, TV sets, CD players, and cassette players,
and small appliances, such as electric shavers and hair dryers, so far as
we know, are not likely to cause EMI problems to your motorized scooter.
ELECTROMAGNETIC INTERFERENCE AND WARNINGS
3
CAUTION: It is very important that you read this information regarding the possible
effects of Electromagnetic Interference on your motorized scooter.
Powered wheelchairs and motorized scooters may be susceptible to electromagnetic
interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources
such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and
cellular phones. The interference (from radio wave sources) can cause the motorized
scooter to release its brakes, move by itself, or move in unintended directions. It can also
permanently damage the motorized scooter control system. The intensity of the interfering
EM energy can be measured in volts per meter (V/m). Each motorized scooter can resist
EMI up to a certain intensity. This is called its "immunity level." The higher the immunity
level, the greater the protection. At this time, current technology is capable of achieving at
least a 20 V/m immunity level, which would provide useful protection from the more common
sources of radiated EMI. The immunity level of this motorized scooter model is not known.
There are a number of sources of relatively intense electromagnetic fields in the everyday
environment. Some of these sources are obvious and easy to avoid. Others are not apparent
and exposure is unavoidable. However, we believe that by following the warnings listed
below, your risk to EMI will be minimized.
Some cellular telephones and similar devices transmit signals while
they are ON, even when not being used.
The sources of radiated EMI can be broadly classified into three types :
1.on the transmitting unit. Examples include: citizens band (CB) radios, "walkie talkie,"
security, fire, and police transceivers, cellular telephones, and other personal communication
devices;
Because EM energy rapidly becomes more intense as one moves closer to the transmitting
antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of
special concern. It is possible to unintentionally bring high levels of EM energy very close
to the motorized scooter control system while using these devices. This can affect motorized
scooter movement and braking. Therefore, the warnings listed below are recommended
to prevent possible interference with the control system of the motorized scooter.
Motorized Scooter Electromagnetic Interference：
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur
radio (HAM) transmitters, two-way radios, and cellular phones can affect motorized scooters.
Following the warnings listed below should reduce the chance of unintended brake release
or motorized scooter movement which could result in serious injury.
1.Do not operate hand-held transceivers (transmitters-receivers), such as citizens band
(CB) radios, or turn ON personal communication devices, such as cellular phones, while
the motorized scooter is turned ON;
Warnings：

Instruction Booklet7-Series
4
There is no easy way to evaluate their effect on the overall immunity of
the motorized scooter.
2.Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming
close to them;
3.If unintended movement or brake release occurs, turn the motorized scooter OFF as
soon as it is safe;
4.Be aware that adding accessories or components, or modifying the motorized scooter,
may make it more susceptible to EMI; and
1.20 volts per meter (V/m) is a generally achievable and useful immunity level against
EMI (as of May 1994). The higher the level, the greater the protection.
2.The immunity level of this product is not known.
5.Report all incidents of unintended movement or brake release to the distributor listed
on the inside front cover of this manual. Note whether there is a source of EMI nearby.
Important Information：

Instruction Booklet7-Series
5
1.Please read the instruction Booklet carefully before using your scooter.
2.Keep the scooter properly maintained.
3.Do not drive the scooter on slippery surfaces or on slopes over 12°
4.Do not drive on highways, crowded roads, or unfamiliar areas.
5.Do not tum at high speed in either forward or reverse.
6.Do not wash with water or leave scooter in a humid Environment since
water can damage the electric parts.
7.Always re-engage the emergency freewheel drive after use.
1
SAFETY WARNING AND INSTRUCTION LABELS
14 32 5
2
3
5
4
N-D Lever adjustment label which instructs freewheel mode operation.
*Never put scooter in neutral gear when staying on slopes.
Warning Sticker
1.Please read the instruction booklet carefully before using your scooter.
2.Do not drive the scooter on slippery surfaces or on slopes over 12 degrees limit.
3.Do not drive on highway, crowded roads, or unfamiliar areas.
4.Do not turn at high speed in either forward or reverse.
5.Do no wash with water or leave scooter in humid environment since water
can damage the electronic parts.
Wiring diagram Label
Do not hang baggage or other objects on the tiller / tiller adjustment lever.
Serial Number
Date of Manufacture
Manufacturer
WEEE Conformity
Medical Device
European Conformity

Instruction Booklet7-Series
Tall Back Rotating
Seat-Sliding
Adjustment
Tilting Armrest
Seat Rotation
13" Rear Wheels
Mirror
Seat
Slide
Tiller Angle
Adjustment
Front Basket
Throttle
Turn Signals
Head Light
Front Bumper
11" Front Wheels
Self-diagnostic
Warning Light Power Reserve Indicator
Amrest Width
Adjustment
Thumbscrews
Rear Light
and Turn
Signals
Rear
Bumper
Free-Wheels LeverAnti-Tip Wheels
Warning
button
Horn button Speed Control Knob
Figure 1 - HS-745 Front View
Figure 2 - HS-745 Joystick
Figure 3 - HS-745 Rear View
IDENTIFICATION OF PARTS
Before attempting to drive this scooter on your own, it is important that you familiarize
yourself with the controls, and how to operate them.
6

Instruction Booklet7-Series
7
FUNCTION OF PARTS：
TOP CONTROL PANEL
•Speed Dial
The Rabbit means fast and Turtle is slow. By turning this you control the total speed
transferred to the thumb controls.
•Self Diagnostic Warning Lights
Flashing indicates problems with the scooter. See page 17 for more information.
•Battery Gauge
There are five yellow LED lights. When all LED are on, the batteries are fully charged.
When only two lights are on, the batteries need to be recharged.
ADJUCT TO TOP CONTROL PANEL
•Throttle
Pushing the right Throttle moves the scooter forward. Pushing the left Throttle moves
the scooter backward. (This can be reversed if required by local dealer.) Releasing
both engages the automatic brake. These are also your accelerator. The further you
depress them, the faster you go. (Subject to the position of the Rabbit/Turtle control).
AT BASE OF STEERING TILLER
•Tiller Angle Adjustment
Pushing downward on the handle to loose. Moving the handle to left to adjust. Pushing
up to lock tiller at comfortable angle.
BELOW SEAT
•Seat Locker Knob
Turn the seat locker knob counterclockwise to loose. Turn it clockwise to lock the seat
position.
•Seat Height Adjuster
There are three holes on the seat tube to adjust the seat height. Be sure the detent pin
is fully inserted at its new height before sitting on the seat.
•Armrest width Adjustment Thumbscrews
Loosen the two thumbscrews to adjust the arm width; tighten again to lock in the desired
position.
•Legroom Adjuster
There are few holes on the front and rear frame tube to adjust the legroom. Pull the
toggle latch to loosen and insert the detent pin to locate the position. Push the toggle
latch again to lock.
REAR BODY
•Rear Compartment Cover
Open the compartment Cover to access the on board charger.
•Anti-tip wheels
Helps keep the scooter from tipping over.
•Free-Wheeling Lever
When lever is in the N (Neutral) position, the scooter can be moved without power.
When lever is in the D (Drive) position, the scooter can be driven. Normal position is D.

Instruction Booklet7-Series
OPERATING YOUR SCOOTER
8
You can make the following adjustments to increase your comfort when driving.
•adjust seat height and location
•adjust steering column to comfortable position.
•adjust legroom.
1.Before operating your scooter, check the following:
•free-wheeling device on D
•speed dial is at the turtle picture.
2.Sit on scooter and turn on key. All Battery Gauge LED Lights should be lit. The Self-
Diagnostic Warning Lights should not be blinking.
3.When your hands rest comfortably on the handlebars, the thumb control levers should
be within easy reach. The right lever moves the scooter forward, the left one moves it
backward. When you release both levers the scooter will stop.
This scooter has automatic braking systems. Release the thumb finger
control and the brakes will stop the scooter.
4.Steer the scooter by turning the whole steering column the way you want to go.
5.Practice driving where there are no obstacles. Start at the slowest speed and drive
forward and backward; make some turns. As you get more comfortable you can
increase the speed by turning the speed dial toward the picture of the rabbit.
6.
If two Battery Gauge LED Lights be lit, you should plan to recharge the batteries very soon.
7.If the scooter stops, locate the circuit breaker on the top of the battery pack. Push it
and try the scooter again.
8.When you are finished riding, turn off the key before getting off.
9.If you are finished riding for the day, immediately recharge the batteries.
See CHARGING THE BATTERIES, page 12.
Keep in mind these rules：
•Release Throttle and allow scooter to stop completely before changing from forward
to reverse, or reverse to forward.
•When turning a corner, swing the front wheels wide, because the back wheels will turn
more tightly.
•Use the scooter only where it would be safe to walk.
•Use low speeds for reverse, downhills, ramps, curbs, or uneven surfaces.
Other Operating Information：
Hill climbing :
You may need to use a higher speed. Turn to lower speed before going downhill.
Down slopes :
To proceed down steep slopes slowly, set speed control in proximity of the turtle. This
enables driver control, as the closer the speed control is set toward the turtle, the slower
it will become. However, this scooter will not self accelerate down hills due to the automatic
braking taking effect should you attempt to drive too fast.
Curb climbing :
Approach slowly at right angles to the curb. A slight angle is permissible with a 4-wheel
scooter, but a direct approach is needed on a 3-wheel scooter. Do not attempt greater
than a 3" curb.
If Self-Diagnostic Warning Lights start to blink, identify the problem from the chart on
page 17 and take action.
If the scooter breaks down and must be moved, get off the scooter, push the Free-Wheeling
Lever to N, move the scooter slowly to a safe location, and move the lever back to D.

Instruction Booklet7-Series
Batteries are heavy please beware when removing. * Please do not touch the positive
plate and the negative plate of the batteries with any metallicity. (See Fig. 10)
Release two Locking Pins (H) to separate front and rear units. (See Fig. 11)
With one hand on rear frame (I) and other on seat piller (J) as hand hold, detach front and
rear sections. (See Fig. 12)
By removing the front basket
(K) and adjusting the tiller
down by using the tiller angle
adjustment (L) you should be
able to place all parts in the
trunk and part of the rear seat
(See Fig. 13).
9
DISASSEMBLING YOUR SCOOTER
No tools are necessary to disassemble scooter. You can disassemble scooter for
transportation.
Seat (A) is removable by releasing the Seat Adjusting Lever (B) and then lift off. (See Fig. 4)
Rear Shroud (C) is removable by lifting the Rear Shroud toward the direction as the shaft
showed in the picture (See Fig. 5). And unplug (D) connections inside (See Fig. 6).
Unplug Wire Connect (E) of the front and rear nits. *Please make sure the main wires are
tied and placed safely on the frame structure to avoid any hazard. (See Fig. 7)
Remove Battery Fixing Velcro (F). (See Fig. 8)
Batteries are removable by detaching the Battery Power Plugs (G). (See Fig. 9)
Figure 4 Figure 5 Figure 6
Figure 7 Figure 9Figure 8
(A)
(B)
(D)
C
(F) (G)
(E)
(H)
(J)
(I)
(K)
(L)
Figure 10 Figure 11
Figure 12 Figure 13

Instruction Booklet7-Series
10
ASSEMBLING YOUR SCOOTER
To assemble the scooter, you can repeat the disassembly directions in reverse.
Abbreviated directions are given below. Refer to the Figures on pages 11 - 12 to
locate the parts.
1.Use the tiller angle adjustment lever to move the steering column up out of the way.
2.Place the front basket
3.Tilting the rear end to a horizontal position, insert the scooter frame tube of the front
end into the rear section first, making sure that the locking pins are removed.
4.Slide the two sections of the unit together until the front half reaches its limits.
5.Insert the two locking pins into their corresponding holes. Both locking pins must be
fully inserted whenever the scooter is assembled.
6.Place batteries, one on each side of the seat post, and use Vel-cro to fix the position.
7.Attach the battery power plugs.
8.Attach the wire connect.
9.Place rear hood, battery cover and free-wheeling knob.
10.Loosen Seat Rotation Lever counterclockwise. Place seat on seat post. Tighten Lever
again by turning clockwise. Lock Seat Control Lever on bottom of seat before sitting
down.

Instruction Booklet7-Series
11
CHARGING THE BATTERIES
Keep in mind these rules：
•Fully charge batteries at least once a month, or more if you use scooter regularly.
Charge after each trip exceeding 3 kilometers.
•If storing your scooter for some time (1 month or more), make sure that batteries are
fully charged, and on returning, charge them again before using scooter.
•
Batteries will only give maximum performance after scooter has been used, and batteries
have been recharged up to 10 times. A bit like breaking in a new car.
Please be aware that the travelling range of your mobility scooter is impacted by how fast the batteries
are discharged. This will depend on many circumstances, such as ambient temperature, condition of the
surface of the road, tyre pressure, weight of the driver, driving environment (inclines etc.) and utilisation
of your lighting system if fitted. We recommend that you test your local ride with a family member to
ensure a safe journey.
Batteries must be charged before using the scooter for the first time and should be
recharged after each day use. You will need the scooter and the battery charger.
1.Insert battery charger cord into the charger connector on the charger
output. Refer to above figure for correct position
2.Plug the other end of the battery charger cable into a standard electrical outlet.
3.Turn the power on. Normally, The LED (Power) Light will turn on when electric current
passes.
4.Charging starts. During charging, LED (Charge) will indicate orange light, when it turns
to green light, that means well-charged.
5.LED indication
•LED(POWER) - GREEN LIGHT ON : Power On.
•LED(CHARGE) - ORANGE LIGHT ON : Charging / GREEN LIGHT ON : Fully Charged
6.Charger Trouble Shooting
(A)If LED (POWER) light is off
•Check the input voltage (115V/230V) is the same as you adjust.
•If light is still off, please check and repair the battery charger.
(B)If LED (CHARGE) light is off
•Check to see clips connection is correct.
•If the battery is fully charged, the LED (CHARGE) light will be off.
•If light is still off, the battery may be defective.
(C)If ORANGE light can turn to GREEN
•The battery can not be charged. Please check and recover it.
(D)If ORANGE light turns to GREEN immediately
•Check to see the battery is fully charged, if not, The battery may be defective
Check and recover it.
Each country may supply different charger.
The charging procedure may be different from below.
If you require more details, please contact your
authorized dealer.
Be sure the scooter key is in the OFF position
The time needed to recharge will vary depending on the depletion of the
batteries. Charging for longer than necessary will not harm the batteries.
They can not be overcharged.
Figure 14

Instruction Booklet7-Series
12
CARE AND MAINTENANCE
DAILY CHECK
Check point Inspection What to do if the inspection is failed
N-D leaver
Horn
Throttles
Electro-
mechanical
brake and
Emergency
hand brake
Battery
Gauge
Rear
mirror (s)
Lighting
Contact your dealer.
Contact your dealer.
Contact your dealer.
Contact your dealer.
‧Contact your dealer if battery gauge is
not working.
‧Recharge the battery immediately if low
‧Clean up the dirt by damp cloth.
‧Tighten the screw or clamping stem that
holds the mirror(s)
Contact your dealer.
Check for correct function
Check for correct function
Pull the wigwag to test the scooter
movement
Pull the wigwag a little bit and
release it to test if brake works.
If your scooter comes with
emergency handbrake, please
check it as well.
Check if the battery gauge is
displayed and whether it is at
low power.
Check if the parts are clean and
firmly tighten to the scooter and
do not wobble.
Check if all lights, such as head
lights, rear lights, and turn signal
are functioning correctly.
WEEKLY CHECK
Check point Inspection What to do if the inspection is failed
Speed Dial
Knob
Armrests
Wheels/Tires
Motor
Battery
Charger
Contact your dealer.
Contact your dealer.
Contact your dealer.
Contact your dealer.
Contact your dealer.
Check for correct function
Check if the parts are clean and
firmly tighten to the scooter and
do not wobble. Tighten the screw
knob that holds the armrest.
Inflate the tire to the correct
pressure and check that
1.Drive wheels rotate without
wobbling.
2.Tire tread depth is not less than
0.5mm.
3.No foreign objects in tires.
Check for correct function
Check if the charger is functioning
correctly and the batteries are
charged.
MONTHLY CHECK
Check point Inspection What to do if the inspection is failed
Seat /
Upholstery
Electronics
Contact your dealer.
Contact your dealer.
Check for movement and if it’s
worn
Check if all the battery cables and
connectors are firmly tighten to the
scooter
Please always check your scooter before you start your every journey.

Instruction Booklet7-Series
13
•The equipment wrapping is potentially recyclable.
•The metal parts are used for scrap metal recycling. The plastic parts are used for plastic
recycling.
•Electric components and printed circuit boards are disposed of as electronic scrap.
•Exhausted or damaged batteries can be returned to your medical equipment supplier.
•Disposal must be carried out in accordance with the respective national legal provisions.
•Ask your city or district council for details of the local waste management companies.
We estimate a service life of five years for this product, provided it is used in strict
accordance with the intended use as set out in this document and all maintenance and
service requirements are met. The estimated service can be exceeded if the product is
carefully used and properly maintained, and provided technical and scientific advances
do not result in technical limitations. The service life can also be considerably reduced
by extreme or incorrect usage. The fact that we estimate a service life for this product
does not constitute an additional warranty.
RECYCLING & DISPOSAL
SERVICE LIFE
OTHER INFORMATION
Only use damp cloth and a little soap to wipe the seat. Do not use abrasive cleaners as
this will damage the seat.
Seat Upholstery :
•Do not use any abrasive or scouring liquids for cleaning. Only use a damp cloth and
gentle detergent.
•Do not use hose pipe or splash water directly onto the scooter as this may cause damage
to electronics.
CLEANING YOUR SCOOTER
•User should inspect the scooter regularly to keep scooter in good running order.
•Check if the electrical cable connectors are fully connected.
•All maintenance and repair of scooter should be done by an authorized dealer.
MAINTENANCE
•Please store the scooter in a dry location. If store the scooter in long time, please
disconnect the battery terminals.
•Do not store your scooter where it will be exposed to source of direct heat, damp, oil,
acid, alkaline, or where Ozone could be possibly generated. All of the above will minimize
scooter / tire cycle and shorten its lifetime.
Storage :

Instruction Booklet7-Series
14
Here are some suggestions about solving problems you may have with your scooter. There
is a self-diagnostic warning light on the control panel. To check the self-diagnostic warning
light, turn on the key and count the number of blinks on the warning light.
TROUBLE SHOOTING
SCOOTER WON’T MOVE WHEN KEY IN TURNED ON
ERROR CODE
Flash Description Initial check points
1 Battery Low The batteries are running low.
•Recharge the batteries.
3 High Battery Fault Battery voltage is too high. This may occur if overcharged and/or
traveling down a long slope.
•If traveling down a slope, reduce your speed to minimize the
amount of regenerative charging.
7 Speed Pot
The throttle, speed limit pot. SRW or their associated wiring may be faulty.
•Check the throttle and speed pot and associated connections and wiring.
8 Motor Voltage The motor or its associated wiring is faulty.
•Check the motor and associated connections and wiring.
9 Other Error The controller may have an internal fault.
•Check all connections and wiring.
6 Drive Inhibit
Either a stop function is active or charger inhibits or OONAPU
condition has occurred.
•Release the stop condition (seat raised etc.)
•Disconnect the battery charger.
•Ensure the throttle is in Neutral when turning the controller on.
•The throttle may require re-calibration.
5 Park Brake Either a park brake release switch is active or the park brake is faulty.
•Check the park brake and associated connections and wiring.
•Ensure any associated switches are in their correct positions.
4
Current limit time-out
or controller overheat
The motor has been exceeding its maximum current rating for too long.
•The scooter may have stalled. Turn the controller off, leave for a few
minutes and turn back on again.
•The motor may be faulty. Check the motor and associated
connections and wiring.
2 Low Battery Fault The batteries have run out of charge.
•Recharge the batteries.
•Check the battery and associated connections and wiring.
Check point
Check if the power is off
Check if the N-D lever is in Neutral position
Check if the battery power is enough.
(Battery gauge is under 25%)
Check if the charger power cord is still
plugged in scooter
Solution
Turn the power on.
Switch to D (drive) position. Turn off the power
and turn on again.
Recharge the battery and then retest.
Unplug the charger power cord.
•TIRE : Low tire pressure: pump up tires to 30~40 psi.
•Charger : During charging, light on charger doesn’t change to green. Please refer to
section 5-2.
OTHER PROBLEMS

Instruction Booklet7-Series
SPECIFICATION
15
Overall Length
Overall Width
Overall Height
Front Wheels
Rear Wheels
Weight W/ Batteries
Max. Speed
Weight Capacity
Ground Clearance
Grade Climbable
Curb Climbable
Turning Radius
Suspension
Brake
Seat Type
Seat Width
Motor Size
Battery Size
Weight of Battery
Travel Range
Battery Charger
Electronics
1397 mm / 55"
685 mm / 27"
1060 mm / 41.7"
290 mm / 11"
320 mm / 13"
27 kg / 59.5 lbs
12 kmph / 7.5 mph
160 kg / 355 lbs
85 mm / 3.3"
12 degree
70 mm / 2.8"
1100 mm / 43"
Front & Rear
Electro-Mechanical
480 mm / 19"
700W, 4100 r.p.m
(2) 12V. 50Ah
30.5 kg / 67.2 lbs
36.5 km / 22.7 Miles
5AOff Board
1450 mm / 57"
685 mm / 27"
1060 mm / 41.7"
290 mm / 11"
320 mm / 13"
106 kg / 234 lbs
12 kmph / 7.5 mph
160 kg / 355 lbs
85 mm / 3.3"
12 degree
80 mm / 3.2"
1460 mm / 58"
Rear
Electro-Mechanical
480 mm / 19"
700W, 4100 r.p.m
(2) 12V. 50Ah
30.5 kg / 67.2 lbs
36.5 km / 22.7 Miles
5AOff Board
SPECIFICATIONS HS-735 HS-745
On/Off Key Switch, Battery Level Indicator,
Speed Control Knob
Swivel Tall Back W/ Seat Sliding Mechanism
*Subject to change without notice. ( Rev. 3, 2020/04/01 )
