Cable-Tronix CT-HDVD-HDSTR-KIT User manual

www.cabletronix.com www. nacebrands.com
HD VIDEO IP STREAMER
CT-HDVD-HDSTR-KIT
MADE IN CHINA

www.cabletronix.com www.nacebrands.com
1
Read this user manual carefully before using this product. Pictures shown in this
manual are for reference only.
Safety Precaution
Please read all instructions carefully before using the device. Save this manual
for further reference.
Follow basic safety precautions to reduce the risk of fire, electrical shock and
injury to persons.
Do not dismantle the housing or modify the module to avoid electrical shock
or burn.
Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
Do not expose the unit to rain, moisture or install this product near water.
Install the device in a place with adequate ventilation
Do not twist or pull by force the ends any cables.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the
power to the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Refer all servicing to qualified service personnel.

www.cabletronix.com www.nacebrands.com
2
Introduction
The CABLETRONIX CT-HDVD-HDSTR-KIT is a HD Video over IP streamer including a
transmitter and a receiver (CT-HDVD-HDSTR-RX). Featuring HDMI and IP ports, the
CT-HDVD-HDSTR-KIT features real-time AV encoding (transmitter) and decoding
(receiver) to broadcast up to1080p (max) HDMI signal from 1 transmitter to 1 or
several receivers point to point or through an Ethernet Switch. It can be
powered by PoE for up to 200m/656ft via single CAT6.
The CT-HDVD-HDSTR-KIT is ideal in various applications, digital signage and video
surveillance and monitoring.
Features
HD interface for digital audio and 1080p@60Hz (max) video up to 175/200m
or 574/656ft with CAT5e/CAT6 utilizing a PoE Ethernet switch; 60m or 196ft
point to point
RJ45 port for Ethernet Interchange connection
HDMI 1.3& HDCP 1.3 compliant
Auto adjusting indicator for power connection& signal transmission status
Broadcast HDMI signal from 1 transmitter to 1 or several receiver(s)
Powered by power adapter or Ethernet Switch with PoE solution
Compact design for easy operation
Package List
No.
Accessories
1
CT-HDVD-HDSTR-KIT: 1 x Transmitter, 1 x Receiver, 2 x Mounting ears 4 x
Screws, 8 x Plastic cushions, 1 x User manual
2
Power Adapter: 2 x Power Adapter (DC 5V 1A)

www.cabletronix.com www.nacebrands.com
3
Connection
The figure below illustrates a typical connection that can be utilized in a
point-to-point configuration using a CT-HDVD-HDSTR-KIT with one
CT-HDVD-HDSTR-RX unit allowing up to 196’ using CAT6 cable.
Connection
The figure below illustrates a typical connection that can be utilized with the
CT-HDVD-HDSTR-KIT1 and more than 1 CT-HDVD-HDSTR-RX with an Ethernet
switch.
One or more CT-HDVD-HDSTR-RX may be utilized in this case to broadcast signal
from 1 CT-HDVD-HDSTR-KIT to 1 or more CT-HDVD-HDSTR-KIT2.

www.cabletronix.com www.nacebrands.com
4
Specification
Input
Input
1 HDMI, 1 IP
Input Connector
1 female type A HDMI 1.4, 1 RJ45
Min/ Max Signal
Level
T.M.D.S. 2.9V~3.3V
Output
Output
1 HDMI, 1 IP
Output Connector
1 female type A HDMI 1.4, 1 RJ45
Min/ Max Signal
Level
T.M.D.S. 2.9V~3.3V
Output Impedance
Differential 100Ω
Standards
Compliant with HDMI 1.3& HDCP 1.3
General
Transmission
Distance
60m/196ft
(CAT5e/6)
If used with
Ethernet switch:
200m/656ft (CAT6)
175m/574ft
(CAT5e)
Power
Consumption
CT-HDVD-HDSTR-KIT1:
4.2W
CT-HDVD-HDSTR-KIT2:
3.5W
Power Supply
DC 5V 1A
Resolution
1080P@60Hz(Max)
Temperature
0 ~ 50℃/32 122F
Humidity
10% ~ 90%
Weight
80g/2.82oz
Dimension
121x21x60mm
4.7x.9x 2.3in
(W*H*D)
CABLETRONIX 1-Year Limited Warranty

www.cabletronix.com www.nacebrands.com
5
CABLETRONIX. (the "Company") warrants to the Original Purchaser that the item purchased is free from defects in workmanship or
material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser.
During the warranty period, the Company agrees to repair or replace, at its sole option, without charge to Original Purchaser, any
defective component. To obtain service, the Original Purchaser must return the item to the Company properly packaged for shipping.
All defective products must be returned to the Company within thirty (30) days of failure. Products must be returned with a description
of the failure and Return Merchandise Authorization (RMA) number supplied by the Company.To receive a RMAnumber and a return
shipping address on where to deliver the hardware, call 610-429-1821. The shipping, and insurance charges incurred in shipping to
the Company will be paid by Original Purchaser, and all risk for the hardware shall remain with the Original Purchaser until such time
as Company takes receipt of the hardware. Upon receipt, the Company will promptly repair or replace the defective unit, and then
return said unit to Original Purchaser, shipping prepaid. The Company may use reconditioned or like-new parts or units, at its sole
option, when repairing any hardware. Repaired products shall carry the same amount of outstanding warranty as from original
purchase. Any claim under the warranty must include dated proof of purchase or invoice. In any event, the Company's liability for
defective hardware is limited to repairing or replacing the hardware.
This warranty is contingent upon proper use of the hardware by Original Purchaser and does not cover: if damage is due toActs of
God (including fire, flood, earthquake, storm, hurricane or other natural disaster), accident, unusual physical, electrical, or
electromechanical stress, modifications, neglect, misuse, operation with media not approved by the Company, tampering with or
altering of the hardware, riot, war, invasion, act of foreign enemies, hostilities (regardless of whether war is declared), civil war,
rebellion, revolution, insurrection, military or usurped power or confiscation, terrorist activities, nationalization, government sanction,
blockage, embargo, labor dispute, strike, lockout or interruption or failure of electricity, air conditioning, or humidity control, internet,
network, or telephone service
The warranties given herein, together with any implied warranties covering the hardware, including any warranties of merchantability
or fitness for a particular purpose, are limited in duration to one yearfrom the date of shipment to the Original Purchaser. Jurisdictions
vary with regard to the enforceability of warranty limitations, and you should check the laws of your local jurisdiction to find out whether
the above limitation applies to you.
The Company shall not be liable to you for loss of data, loss of profits, lost savings, special, incidental, consequential, indirect, or other
similar damages arising frombreach of warranty, breach of contract, negligence, or other legal action even if the Company or its agent
has been advised of the possibility of such damages, or for any claim brought against your by another party. Jurisdictions vary with
regard to the enforceability of provisions excluding or limiting liability for incidental or consequential damages. You should check the
laws of your local jurisdiction to find out whether the above exclusion applies to you.
This warranty allocates risks of product failure between Original Purchaser and the Company. The Company's hardware pricing
reflects this allocation of risk and the limitations of liability contained in this warranty. The warranty set forth above is in lieu of all other
express warranties, whether oral or written. The agents, employees, distributors, and dealers of the Company are not authorized to
make modification to this warranty, or additional warranties binding on the Company. Accordingly, additional statements such as
dealer advertising or presentations, whether oral or written, do not constitute warranties by the Company and should not be relied
upon.
This warranty gives you specific legal rights. You may also have other rights which vary from one jurisdiction to another.
