Cablexpert NCT-4 User manual

USER MANUAL
HANDBUCH
HANDLEIDING
MANUEL DESCRIPTIF
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
КЕРІВНИЦТВО КОРИСТУВАЧА
DSP-2PH4-001 HDMI INTERFACE
SPLITTER, 2 PORTS
NCT-4
HDMI CABLE TESTER

2
NCT-4
HDMI CABLE TESTER
All brands and logos are registered trademarks of their respective owners
HDMI Cable tester
HDMI-Kabeltester
HDMI-kabeltester
Câble HDMI testeur
Тестер кабелей HDMI
Тестер HDMI кабелів
Features
Cable tester for all (type A) HDMI cables
Indicates several different wiring problems: open circuit, short circuit,
jumper wire, etc
Supports HDMI cables with type A connector: v. 1.0 , 1.1 , 1.2 , 1.2a,
1.3a/b/c, 1.4 /a
Up to 50 working hours on a single 9V battery
Practical LED signal indicators
Specifications
Power supply: 9 V DC battery (not included)
Power consumption: up to 20 mA
Display: LEDs for each wire
Working ambient temperature: -10 ... + 60°C

3
NCT-4
HDMI CABLE TESTER
All brands and logos are registered trademarks of their respective owners
Tester ports: tester HDMI A master socket, tester remote HDMI A
socket; remote unit HDMI A socket
Max cable length: up to 30 m
Cable problems detected: open circuit, short circuit, reverse connection,
crossover or cross-talk interference
Sleep mode: after 1 idle minute
Dimensions: 104 x 62 x 29 mm (main unit), 100 x 30 x 25 mm (remote
unit)
Net weight: 0.107 kg
