Cadco HOT PLATES CDR-1T Installation instructions

l Robertshaw thermostat; infinite heat controls
to attain desired temperatures
l High speed tubular elements
l Easily cleaned stainless surface
l On/Off switch with indicator light
l Power light(s) indicate burner is turned on
l Industrial rated uality ranges
l Full one year warranty covering parts and labor
(All hot plates should be returned to Cadco for
warranty service. Call Cadco for Return
Authorization for repair)
l UL Safety & Sanitary, C-UL
u u
Model CSR-1T - 120 volt single burner hot plate:
6diameter high speed tubular element; 1100 Watts
Model CSR-3T - 120 volt single burner hot plate:
8diameter high speed tubular element; 1500 Watts
Model CDR-1T - 120 volt double burner hot plate:
two 6diameter high speed tubular elements; 1650 Watts (825 per burner)
Hot Plate Common Features
Product Specification Sheet
Hot Plates
Model Color Electrical
Volts Watts Amps
nit Dimensions Ship
Wt./lbs.
Carton
Dimensions
PC#
CSR-1T Stainless 120 1100 9.0 w:14, h:4-1/8, l:12-1/4 6.75 lbs. w:17-1/4, h:5-1/4, l:14-5/8 654796-61102-7
CSR-3T Stainless 120 1500 12.5 w:14, h:4-1/8, l:12-1/4 7.85 lbs. w:17-1/4, h:5-1/4, l:14-5/8 654796-61103-4
CDR-1T Stainless 120 1650 13.8 w:21-1/4, h:4-1/4, l:12-3/16 10.5 lbs. w:24-1/2, h:5-1/4, l:14-5/8 654796-62102-6
Model CDR-1T - Double Burner Hot Plate
825 Watts per burner; 1,650 Watts total
Model CSR-1T - Single Burner Hot Plate
1,100 Watts
Model CSR-3T - Hi-power Single Burner Hot Plate
1,500 Watts
For more information, please contact Cadco, Ltd, 145 Colebrook River Road, Winsted, CT 06098
Tel. [phone] u Fax [phone] u E-mail: [email protected] u Web site: www.cadco-ltd.com
CSR-1T
CSR-3T
CDR-1T
4/21/2010 RV02
