Cadel FRAME3 User guide

INSTALLER MANUAL
Pellet Stove
EN
©2018 CADEL srl | All rights reserved - Tutti i diritti riservati
FRAME3- FRAME3UP - QUASIMODO3UP -MODO AIRTIGHT

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
2
SUMMARY
1 MANUAL SIMBOLOGY....................................3
2 PACKAGING AND HANDLING..........................3
2.1 PACKAGING .............................................................3
2.2 REMOVING THE STOVE FROM THE PALLET ..............3
2.3 STOVE HANDLING....................................................4
3 CHIMNEY FLUE .............................................4
4 COMBUSTION AIR.........................................4
4.1 EXTERNAL AIR INLET...............................................4
4.2 COMBUSTIBLE AIR INLET FOR SEALEDCHAMBER
INSTALLATION ...................................................................5
4.3 COMBUSTIBLE AIR INLET FOR SEALEDCHAMBER
INSTALLATION ...................................................................5
5 INSTALLATION..............................................6
5.1 INTRODUCTION.......................................................6
5.2 OVERALL DIMENSIONS ...........................................6
5.3 GENERAL INSTALLATION.........................................8
5.4 MOUNTING MODO AT AND QUASIMODO3UP STAND9
5.5 MOUNTING MODO AT LEGS.....................................9
5.6 REMOVE SIDE PANELS FRAME3...............................9
5.7 REMOVESIDEPANELSMODOAIRTIGHT/QUASIMODO3
UP ..............................................................................10
5.8 DOOR ADJUSTMENT..............................................10
5.9 CONNECTION TO THE EXTERNAL THERMOSTAT.....11
5.10 ELECTRIC CONNECTION.........................................11
5.11 AIR REGULATOR ....................................................11
5.12 FRAME3AND QUASIMODO3HOT AIR DUCTING
OPTIONAL .....................................................................12
5.13 MODO AIRTIGHT CONCENTRIC PIPE INSTALLATION14
5.14 STOVE CALIBRATION AND DEPRESSION
MEASUREMENT ...............................................................16
6 SPECIAL MAINTENANCE ..............................16
6.1 INTRODUCTION.....................................................16
6.2 FEED SCREW MAINTENANCE.................................17
6.3 FUME FAN CLEANING............................................17
6.4 FUME CONDUIT CLEANING....................................18
6.5 FUME PIPES ANNUAL CLEANING .........................19
6.6 GASKET REPLACEMENT.........................................19
7 IN CASE OF ANOMALY..................................19
7.1 PROBLEM SOLVING ...............................................19
8 TECHNICAL DATAS ......................................22
8.1 FUSE REPLACEMENT .............................................22
9 FEATURES ..................................................23

3
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
1 MANUAL SIMBOLOGY
USER
AUTHORISED TECHNICIAN
(ONLY to interpret or the Stove-manufacturer or the Authorized Techni-
cian of Technical Assistance Service approved by the Stove-manufacturer)
SPECIALIZED STOVE-REPAIRER
CAUTION:
READ CAREFULLY THE NOTE
CAUTION:
DANGER OR IRREVERSIBLE DAMAGE POSSIBILITY
• The icons with the stylized figures indicates whom the subject dealt in the paragraph is addressed to (between the User and/
or the AuthorizedTechnician and/or the Specialized Stove-repairer).
• WARNING symbols indicates an important note.
2 PACKAGING AND HANDLING
2.1 PACKAGING
• The packaging is made up of recyclable cardboard boxes according to RESY standards, recyclable expanded polystyrene inserts
and wooden pallets.
• All packaging materials can be re-used for a similar use or eventually discharged as waste assimilable to the municipal solid
ones, in accordance with current regulations.
• After having removed the packaging please assure you about the integrity of the product.
2.2 REMOVING THE STOVE FROM THE PALLET
Proceed as follows to remove the stove from the pallet:
Fig. 1 - Remove the screws + brackets
• Remove the screws of the 2 brackets securing the stove (see Fig. 1).
• Then remove the stove from the pallet.

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
4
2.3 STOVE HANDLING
Both whether the stove is packed or not it is necessary to observe the following instructions for handling and transporting the
stove from its sale point to its installation point and for any future movements:
• The stove must be handled with idoneous means paying attention to the existing safety regulations;
• do not turn the stove upside down and/or upset it on one side, but keep it in vertical position or as accorded with the construc-
tor instructions;
• if the stove is made up of ceramic, stone, glass or any particularly fragile material components, all must be moved with the
utmost care.
3 CHIMNEY FLUE
4 COMBUSTION AIR
4.1 EXTERNAL AIR INLET
Fig. 2 - Direct air inow
LEGEND Fig. 2
1Room to ventilate
2External air inlet
• The room must be endowed with an external air recycling for a good climate in your ambient.
• The air inflow from outside to the inner occurs directly, through an opening on the external wall of the room (see Fig. 2).
• Bedrooms, garages, and store of flammable materials are excluded.
• The air inlet should have a total net surface of 80 sqcm2: the aforesaid surface is to widen if inside the room there are other
activated appliances (for example: electric ventilators for foul air suction, cooker hoods, other stoves, etc...) which depress the
environment.
• At switched on appliance it is necessary to check that the pressure fall between the room and the outside does not exceed 4,0
Pa value: if necessary widen the air inlet (EN 13384).
• The air inlet must be realized at a height close to the floor with an external grid against birds. In such a way it cannot be ob-
structed by any object.
• In case of installation with sealed-chamber the air inlet is not necessary.

5
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
4.2 COMBUSTIBLE AIR INLET FOR SEALEDCHAMBER INSTALLATION
Fig. 3 - Air inlet for sealed-chamber installation
LEGEND Fig. 3
1≥ 1,5 mt
2≥ 0,3 mt
3-3 Sectional view
4Shield grid
5Curve inlet to turn downwards
Check if the purchased stove has a sealed-chamber. If the stove is endowed with a sealed-chamber and you want also the whole
installation with sealed chamber, please read the following instructions:
• It is necessary to extract the air for combustion directly from outside.
• Use a tube with minimum Ø60 mm and maximum 2 meters lenght; to connect see the back of the stove.
• French standards require installation in double-walled flues (concentric system). The combustion air is drawn from the cavity.
• During installation step is necessary to verify the minimum distances required for the combustible air inlet as (for example)
an open door or window causes a vortex which could remove the combustible air necessary to the stove (see the underlying
scheme).
• On the external wall it is necessary to install a curve at 90° to protect the combustible air inflow from wind effects: turn the
curve inlet downwards, see Fig. 3.
• Endow the curve with an external shield grid against birds in such a way that it cannot be obstructed by any object.
Check with your local authorities if exists any restrictive regulation regarding the combustible air inlet: if pre-
sent, they must be applied
In some countries and/or regions the installation with sealed-chamber is obligatory: in case of doubt, please
follow the most restrictive regulations.
4.3 COMBUSTIBLE AIR INLET FOR SEALEDCHAMBER INSTALLATION
How to connect to the stove in the sealed chamber with concentric system:

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
6
Fig. 4 - Phase 1
• Insert the female tube ø 6 cm (see Fig. 4).
5 INSTALLATION
5.1 INTRODUCTION
• The assembly position must be chosen depending on environment, outlet, chimney flue.
• Check with local authorities if there are any restrictive regulations which regard the combustible air inlet, room ventilation,
fume exhaust system together with chimney flue and chimney pot.
• Check if there is the combustible air inlet.
• Check the probable presence of other stoves or appliances which could depress the room.
• Check at switched on stove if there is the presence of CO in the room.
• Check if the chimney has the necessary draught.
• Check if during the fume passage all has been executed in safety (probable fume losses and distances from flammable mate-
rials, etc.…).
• The installation of the appliance must enable an easy access for appliance, fume exhaust pipes and chimney flue cleaning.
• The installation must enable en easy access to the electric connection plug (see ELECTRIC CONNECTION a pag. 11).
• To install more appliances, the external air inlet must be correctly dimensioned (see FEATURES a pag. 23).
5.2 OVERALL DIMENSIONS
Fig. 5 - General dimensions: FRAME3
LEGEND Fig. 5
170,3 cm 836,4 cm
278 cm 921,2 cm
353 cm 10 Exhaust fumes d.8 cm
420,3 cm 11 Hole combustion air inlet d.6 cm
515,4 cm 12 Ducting outlet d.8 cm (optional)
616,7 cm 13 Hot air outlet 32x2 cm
736,7 cm

7
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
Fig. 6 - General dimensions: FRAME3UP
LEGEND Fig. 6
170,3 cm
283 cm
361 cm
435,1 cm
512,5 cm
636,4 cm
721,2 cm
8Exhaust fumes d.8 cm
9Hole combustion air inlet d.13 cm
10 Ducting outlet d.8 cm (optional)
11 Hot air outlet 32x2 cm
Fig. 7 - General dimensions: QUASIMODO3UP
LEGEND Fig. 7
170 cm 835 cm
298,5 cm 910,6 cm
356,4 cm 10 17,3 cm
442,5 cm 11 71,2 cm
560 cm 12 Exhaust fumes d.8 cm
656,4 cm 13 Hole combustion air inlet d.13 cm
747,5 cm 14 Ducting outlet d.8 cm (optional)

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
8
Fig. 8 - General dimensions: MODO AT
LEGEND Fig. 8
170 cm
256 cm
358 cm
442,5 cm
535 cm
610,6 cm
7Exhaust fumes d.8 cm
8Hole combustion air inlet d.13 cm
970 cm
10 30 cm
11 60 cm
12 42,5 cm
13 65 cm
14 30 cm
5.3 GENERAL INSTALLATION
Fig. 9 - General installation
LEGEND Fig. 9
1Stove
2Minimum lateral distance = 200 mm
3Minimum rear distance = 200 mm
4Minimum front distance = 1000 mm

9
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
It is obligatory to install the stove away from walls and/or pieces of furniture, with a minimum air flow of 200 mm on the sides and
200 mm on the back, to enable an efficient appliance cooling and a good distribution of heat in the room (see Fig. 9).
If the walls are made up of flammable materials, check the safety distances (see Fig. 9).
At maximum power check that the wall temperature does not ever exceed 80°C. If it would be necessary please install a fire re-
sistant plate on the concerned walls.
In some countries also masonring load-bearing walls are considered flammable.
5.4 MOUNTING MODO AT AND QUASIMODO3UP STAND
Assembly operations must always be carried out by 2 people!
Proceed as follows to assemble the stand:
Fig. 10 - Stand fastening
• Set the machine body above the stand and fix it all with the supplied screws (see Fig. 10).
5.5 MOUNTING MODO AT LEGS
Assembly operations must always be carried out by 2 people!
To assemble the legs, proceed as follows:
Fig. 11 - Position base and legs Fig. 12 - Fasten legs to the base Fig. 13 - Stove fastening
• Set the base on a flat surface (with the bend facing upwards) and position it above the legs (see Fig. 11).
• Secure the legs to the base (see Fig. 12).
• Set the machine body above the legs and fix it all with the supplied screws (see Fig. 13).
5.6 REMOVE SIDE PANELS FRAME3
Proceed as follows to remove the stove side panels:

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
10
Fig. 14 - Remove the screws Fig. 15 - Unhook the side
• Loosen the 2 screws (see Fig. 14).
• Release the 2 teeth on the bottom of the side panel and remove it (see Fig. 15).
5.7 REMOVE SIDE PANELS MODO AIRTIGHT / QUASIMODO3UP
Proceed as follows to remove the stove side panels:
Fig. 16 - Remove the screws Fig. 17 - Unhook the side
• Loosen the 2 screws (see Fig. 16).
• Release the 2 teeth on the bottom of the side panel and remove it (see Fig. 17).
5.8 DOOR ADJUSTMENT
To centre the door, proceed as follows:
Fig. 18 - Door adjustment
• Open the door.
• Loosen the two front screws in the upper hinge and, using the side screw (the one circled in the picture) adjust the door

11
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
forward or backward (see Fig. 18).
• Once the door is centred, lock the 2 front screws.
5.9 CONNECTION TO THE EXTERNAL THERMOSTAT
The stove works through a thermostat probe placed in its inner. If you desire, the stove can be connected to an external room
thermostat. This operation must be executed by an authorized technician.
Connect the wires from the external thermostat to the "Term opt" terminal on the stove board. Activate the external thermostat
(default setting OFF) as indicated below:
• Press the "menu" button.
• Scroll with the arrows to "Settings".
• Select by pressing "menu".
• Scroll with the arrows again to "Ext.Thermostat".
• Select by pressing "menu".
• Press the - + buttons.
• To activate the external thermostat select "on".
• Press the "menu" button to confirm.
5.10 ELECTRIC CONNECTION
Warning: the appliance must be installed by an authorized technician!
• The electric connection occurs through a cable with plug put in an electric socket which is able to support charge and tension
specific of every model, as described in the technical datas table (see FEATURES a pag. 23).
• The plug must be easily accessible when the appliance is installed.
• Please further assure you that your network is endowed with an efficient earth connection: if it does not exist or if it is not
efficient, please endow you with one in compliance with the law.
• Connect the supply cable first on the back of the stove (see Fig. 19) and then at a wall electric socket.
Fig. 19 - Electric socket with master switch
• The master switch O/I (see Fig. 19) is to open only to switch the stove on, otherwise it is advisable to keep it off.
• Do not use extension cables.
• If the feeder cable is damaged, it must be replaced by an authorized technician.
• When the stove is not going to be used for a long period of time, it advisable to remove the plug from the socket on the wall.
5.11 AIR REGULATOR
The stove is fitted with a removable rear air regulator.
The stove is regulated according to the flue data and pellet used, as per the technical features (see FEATURES a pag. 23).
If the data does not match, the authorised technician can increase the stove draft by removing/loosening the ring located inside
the air inlet pipe (see Fig. 20).

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
12
Fig. 20 - Ring removal
Air regulator opening 35 mm for nominal power with flue 11 Pa.
5.12 FRAME3AND QUASIMODO3HOT AIR DUCTING OPTIONAL
WITH THE INSTALLATION OF THE DUCTING, IT IS NECESSARY TO LOAD THE NEW DATABASE IN THE BOARD (DA-
TABASE NO. 07).
SEE “SERVICE MANUAL”.
By default, the insert inserts the hot air into the environment from both the front vents.
It is possible to channel the left air on the back of the stove, through a ducting kit.
To assemble the kit, proceed as follows
• Remove the 4 fixing screws of the left fan (see Fig. 21 and Fig. 22).
• Remove the fan.
Fig. 21 - Remove the screws Fig. 22 - Remove the screw
Proceed as follows to assemble the casing to the fan:
• Tighten the flange to the fitting (see Fig. 23).
• Fix the flange + fitting to the fan (see Fig. 24 and Fig. 25).

13
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
Fig. 23 - Fix the ange to the tting Fig. 24 - Fix the ange + tting to the fan Fig. 25 - Fix with screws
• Fix the casing cover to the fan as in Fig. 26.
• Assemble everything to the casing and fix it with the screws (see Fig. 27 and Fig. 28).
Fig. 26 - Fix the cover Fig. 27 - Fix the fan to the casing Fig. 28 - Fix with screws
• Fix the casing + fan to the stove with the screws (see Fig. 29).
• Position the fitting at 45° to the fan fitting (see Fig. 30).
• Remove the precut cap from the back of the stove.
• Fix the back to the stove and engage the pipe for the ducting (see Fig. 31).
Fig. 29 - Fix the casing + fan to the stove Fig. 30 - Position tting at 45° Fig. 31 - Back xing

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
14
Fig. 32 - Ducting system example
• A stove with no ducting has a variable air flow rate from a minimum of 61 m3/h to a maximum of 130 m3/h, and an air tempe-
rature which varies from a minimum of 90°C to a maximum of 136°C.
• In the case of ducting, it is recommended not to exceed 6 metres of pipe and 3 x 90° bends, otherwise the hot air loses its
effectiveness.
• Use pipes with an 80 mm diameter with smooth internal walls.
• If the pipes pass through cold walls, insulate the pipe with insulating material.
• Place a protective grille with large mesh and a total minimum net surface area of 40 cm2over the outlet.
• After the 6 metres of pipe there can be a variable air flow rate from a minimum of 58 m3/h to a maximum of 83 m3/h, and an air
temperature which varies from a minimum of 65°C to a maximum of 99°C. (These values have been recorded in the laboratory,
there may be differences in both flow rate and temperature in the installation room).
• If you wish to increase the air flow, install a small wall-mounted fan on the outlet with a flow rate of more than 130 m3/h, this
should be performed by an authorised technician.
• With factory parameters 1/2 of the heat produced by the stove is conveyed into the room where it is installed, the remaining
1/2 comes out from the ducting on the left.
• To get the best performance you need to balance the power with the air flow. This operation must be performed with the
assistance of an authorised technician.
• The ductable fans cannot be deactivated, but they can be operated at a power value between 1 and 5 or in automatic mode.
5.13 MODO AIRTIGHT CONCENTRIC PIPE INSTALLATION
The stove is designed for the connection of the concentric pipe.
Proceed as follows to connect:
• Remove the back of the stove (see Fig. 33).
• Unscrew the smoke exhaust (see Fig. 34).
• Remove the ring (see Fig. 35).

15
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
Fig. 33 - Removing the back Fig. 34 - Unscrewing the exhaust Fig. 35 - Removing the ring
• Position the pipe for the upper exhaust with the concentric pipe on the top part (see Fig. 36).
• Fasten the concentric pipe (see Fig. 37).
• Remove the ring inside the silicone fitting (see Fig. 38).
Fig. 36 - Upper exhaust Fig. 37 - Secure the concentric pipe Fig. 38 - Remove the silicone tting
• Connect the 2 combustion air inlets with the flexible hose (see Fig. 39 and Fig. 40) and secure with the metal clamps.
Fig. 39 - 2-inlet connection Fig. 40 - 2-inlet connection

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
16
5.14 STOVE CALIBRATION AND DEPRESSION MEASUREMENT
This stove has a pickup point positioned on the tank in order to measure the depression of the combustion chamber and verify its
proper operation.
To do this, proceed as follows:
• Connect a digital pressure switch with a tube to detect the negative pressure (see Fig. 41 and Fig. 42 or Fig. 43).
• Load the feed screw via appropriate function.
• Start the stove and set "Set flame" to power 1 (the start-up time of this stove lasts between 8 and 10 minutes to ensure mini-
mum draught).
• Compare the read values with those on the table.
• Change power every 10 minutes and wait for it to stabilise.
• Access the user menu and, if necessary, change the parameters.
Fig. 41 - Frame3cap removal Fig. 42 - Frame3digital pressure switch connec-
tion
Fig. 43 - Modo At and Quasimodo3Up digital
pressure switch connection
DATA P1 P2 P3 P4 P5
Stove depression -
temperature 9 kW 18/19 Pa - 110°C 28/29 Pa - 135°C 38/39 Pa - 152°C 42/43 Pa - 176°C 47/48 Pa - 192°
NB: for good combustion, the depression values must be between + -5 Pa and the temperature values between + - 10°C.
6 SPECIAL MAINTENANCE
6.1 INTRODUCTION
For a long working life of the stove, have a periodic cleaning of the stove as described in the following paragrafs.
• Fume outlet pipes (fume conduit + chimney flue + chimney pot) must always be cleaned, scrubbed and checked by an autho-
rized technician in compliance with local regulations, with the instructions of the manufacturer and those of your insurance
company.
• It is also necessary to have the combustion chamber, motors and fans cleaned and to have the gaskets and the electronical
elements checked at least once a year.
All these operations must be planned in time with your Autorized Technical Assistance Service.
• After a long ineffective time, before turning on the stove check if there are obstructions in the fume exhaust.
• If the stove had been using continuously and intensely, the whole system (chimney included), must be cleaned and checked
more frequently.
• In case of replacement of damaged pieces please ask for the original spare part at the Autorized Retailer.

17
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
6.2 FEED SCREW MAINTENANCE
Proceed as follows for the feed screw maintenance:
Fig. 44 - Screw removal Fig. 45 - Coque removal Fig. 46 - Gear motor removal
• Enter the tank and loosen the 4 screws of the feed screw coque (see Fig. 44).
• Remove the coque (see Fig. 45).
• Remove the gear motor by loosening the locking screw (see Fig. 46).
Fig. 47 - Spiral removal Fig. 48 - Bearing removal
• Remove the spiral (see Fig. 47).
• If worn, remove the bearing (see Fig. 48) and replace it.
• To reassemble, proceed in reverse order.
6.3 FUME FAN CLEANING
Clean every the year the fume fan from ash or dust which can cause a blade unbalance and a greater noise.
• Remove the right side panel (see REMOVE SIDE PANELS FRAME3 a pag. 9) and loosen the screw behind the right fan
(see Fig. 49).
• Remove the front screws of the fan (see Fig. 50 and Fig. 51).

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
18
Fig. 49 - Loosen the screw Fig. 50 - Remove screw 1 Fig. 51 - Remove screw 2
• Disconnect the wiring and remove the fan (see Fig. 52).
• Remove the flue gas extractor screws (see Fig. 53) and proceed with cleaning.
Fig. 52 - Remove the fan Fig. 53 - Remove the screws
• Clean with a brush and vacuum the soot inside (see Fig. 54 and Fig. 55).
• Once thoroughly cleaned, put everything back together.
Fig. 54 - Cleaning 1 Fig. 55 - Cleaning 2
6.4 FUME CONDUIT CLEANING
The exhaust system must be cleaned every season (or every 1500 operation hours).

19
FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
Fig. 56 - Fume conduit cleaning Fig. 57 - Fume conduit cleaning
• Remove the inspection lid of the T-union (see Fig. 56, Fig. 57).
• Extract the ash which has accumulated in the inner.
• After cleaning repeat the operation in reverse order, checking the condition and efficiency of the gasket, and if necessary
replace it.
It is important to sealed the cap othrwise noxiuous fumes will propagate among the room.
6.5 FUME PIPES ANNUAL CLEANING
Clean annually from soot with brushes.
The cleaning operation must be executed by a specialized stove-repairer who will provide for the cleaning of fume pipe, chimney
flue and chimney pot. He will also check their eficiency and will release a written declaration of the safety of the appliance. This
operation must be executed at least once a year.
6.6 GASKET REPLACEMENT
In case of deterioration of fire door, hopper or fume chamber gaskets, it is necessary to replace them by an autorized technician in
order to guarantee the good running of the stove.
Use exclusively original spare parts.
7 IN CASE OF ANOMALY
7.1 PROBLEM SOLVING
Before of every Authorized Technician intervention, the same Technician has the duty to check if the parame-
ters of the mother board correspond to those of the table you own.
In case of doubts regarding the use of the stove, please contact ALWAYS the Authorized Technician on order to
avoi irreparable damages!

FRAME3 - FRAME3 UP - QUASIMODO3 UP - MODO AIRTIGHT
20
PROBLEM CAUSE SOLUTION INTERVENTION
The control display
does not switch on
The stove is
without power
supply
Check if the plug is connected.
Burned protection
fuse in the electric
socket
Replace the protection fuses in the electric socket (3.15A-
250V).
Faulty control
display Replace the control display.
Faulty flat cable Replace the flat cable.
Faulty electronic
board Replace the mother board.
Pellets do not
reach the combu-
stion chamber
Empty hopper Full the hopper.
Open fire door or
open pellet door
Close fire door and pellet door and check that there are no
pellet grains at the gasket level.
Clogged stove Fume chamber cleaning
Auger blocked by a
foreign object (for
example nails)
Clean the auger.
The auger geared
motor is out of
order
Replace the geared motor.
Check if on the
display there is an
"ACTIVE ALARM"
Have the stove checked.
