CAES SPARC V8 User manual

SPARC V8 Processor
LEON-XCKU-EX
LEON-XCKU-EX-UM
Jan 2022, Version 1.1
Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler

USER MANUAL JAN 2022
Features
•SPARC V8e integer unit(s)
with dual-issue pipeline,
16 KiB instruction and
16 KiB data caches,
hardware multiplier and
divider, power-down mode,
hardware watchpoints, etc.
• Double precision IEEE-754 floating point unit
• Memory management unit
• Advanced on-chip debug support unit
• Level-2 cache
• DDR4 SDRAM
• UART, Timers, GPIO port, Interrupt controller,
Status registers
• Ethernet 10/100/1000 Mbit MAC interface
Description
The LEON-XCKU FPGA bitstreams are a collection of
example designs built from Cobham Gaisler’s GRLIB
IP library using a template design for Xilinx Kintex
Ultrascale devices. The example designs are suit-
able for evaluation of LEON microprocessors in sys-
tem-on-chip designs.
Specification
• Targets Xilinx Kintex Ultrascale KCU105 Evalua-
tion Kit FPGA board
• 100 MHz system frequency
Applications
The LEON/GRLIB template designs can be adapted as multiple configurations,
covering instrument, payload and control applications.

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 2
LEON-XCKU-EX

Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
Table of contents
1 Introduction.............................................................................................................................. 3
1.1 Scope ....................................................................................................................................................... 3
1.2 Document revision history ...................................................................................................................... 3
1.3 Reference documents .............................................................................................................................. 3
2 Example designs ...................................................................................................................... 4
2.1 Overview ................................................................................................................................................. 4
2.2 Configurations ......................................................................................................................................... 6
3 Architecture.............................................................................................................................. 7
3.1 Cores........................................................................................................................................................ 7
3.2 Interrupts ................................................................................................................................................. 7
3.3 IP core documentation ............................................................................................................................. 8
3.4 Signals ..................................................................................................................................................... 9
3.5 Resource utilization................................................................................................................................. 9
4 Working with the board.......................................................................................................... 10
4.1 Prerequisites .......................................................................................................................................... 10
4.2 Programming the FPGA device and connecting with GRMON3 ......................................................... 10
4.3 Support .................................................................................................................................................. 10
5 Ordering information ............................................................................................................. 11

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 3
LEON-XCKU-EX

Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
1 Introduction
1.1 Scope
The LEON line of processors and the GRLIB IP library has support for Xilinx Kintex Ultrascale
devices. This support consists of a techmap layer that wraps specific technology elements such as
memory macros and pads. GRLIB also contains a template designs for developments boards such as
the Xilinx Kintex UltraScale FPGA KCU105 Evaluation Kit and infrastructure that automatically
builds project files for Xilinx Vivado and synthesis tools such as Mentor Precision Hi-Rel and Synop-
sys Synplify Premier.
This document describes a set of ready-made FPGA configurations (bitstreams) that have been built
from the GRLIB template designs.
1.2 Document revision history
1.3 Reference documents
[AMBA] AMBATM Specification, Rev 2.0, ARM IHI 0011A, 13 May 1999, Issue A, first release,
ARM Limited
[GRLIB] GRLIB IP Library User's Manual, Cobham Gaisler, www.Cobham.com/gaisler
[GRIP] GRLIB IP Core User's Manual, Cobham Gaisler, www.Cobham.com/gaisler
[QSG] LEON-XCKU-EX Quick Start Guide, LEON-XCKU-EX-QSG, www.gaisler.com/LEON-
XCKU
Table 1. Change record
Version Date Note
1.0 2019 December First issue
1.1 2020 December

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 4
Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
LEON-XCKU-EX

2 Example designs
2.1 Overview
The LEON-XCKU-EX example designs are based on a common architecture. The architecture is cen-
tered around the AMBA [AMBA] Advanced High-speed Bus (AHB), to which the processor(s) and
other high-bandwidth units are connected. Low-bandwidth units are connected to the AMBA
Advanced Peripheral Bus (APB) which is accessed through an AHB to APB bridge. The architecture
for the basic design is shown in figure 1. Please also note that while not shown in the block diagram
above, the Ethernet controller (GRETH_GBIT) is also connected to the main AHB bus and not only
the Debug AHB bus.
The full LEON-XCKU-EX architecture includes the following modules:
• LEON5 SPARC V8e Integer Unit with 16 KiB instruction cache and 16 KiB data cache. IEEE-
754 Floating Point Unit and Memory Management Unit.
• Debug Support Unit with UART, Ethernet, and JTAG Debug Links
• Level-2 cache controller
• Xilinx MIG DDR4 SDRAM controller
• Timer unit with two 32-bit timers
• Interrupt controller for 15 interrupts in two priority levels
• UART with FIFO and separate baud rate generator
• General purpose I/O port (GPIO).
• AMBA AHB status register (not included in all EX variants)
The GRLIB IP library contains a template design that has been used as the base for LEON-XCKU-EX
designs. The template design can easily be extended to add additional GRLIB IP library IP cores such
as:
• Memory controllers with EDAC
• SpaceWire links with CRC support and hardware RMAP target
• SpaceFibre links
• CAN-2.0 controllers
• Mil-Std-1553 BC/BM/RT
Figure 1. Architectural block diagram of LEON-XCKU-EX1

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 5
LEON-XCKU-EX

Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
A full list of GRLIB IP library components can be found in [GRIP]. The GRLIB user’s manual is
available on-line [GRLIB].

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 6
Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
LEON-XCKU-EX

2.2 Configurations
The bitstream is available for download from https://www.gaisler.com/LEON-XCKU
Note: The configurations above are examples on how to use the GRLIB IP cores on Xilinx Kintex
Ultrascale. All IP cores have several configuration parameters and are individually configurable.
Note: While software may report that fault-tolerance is enabled for the example designs, the bit-
streams are not suitable for use in environments with radiation effects.
Table 2. Example configurations
Configuration name EX1 EX2 EX3 EX4
XCKU device 040 (KC105) 040 (KC105) 040 (KC105) 040 (KC105)
Processor LEON5 LEON5 LEON5 LEON5
Number of processor cores 1 1 2 4
Level-1 cache 16+16 KiB 16+16 KiB 16+16 KiB 16+16 KiB
Hardware multiply&divide Yes Yes Yes Yes
Multiply & accumulate No No No No
Single-vector trapping Yes Yes Yes Yes
Power down mode Yes Yes Yes Yes
Memory Management Unit Yes Yes Yes Yes
Floating Point Unit GRFPU5 NanoFPU GRFPU5 NanoFPU
Debug Support Unit Yes Yes Yes Yes
Level-2 cache Yes Yes Yes Yes
UART Debug Link Yes Yes Yes Yes
JTAG Debug Link Yes Yes Yes Yes
Ethernet MAC 10/100/1000
Mbit
Yes Yes Yes Yes
Memory Controller Xilinx DDR4 MIG Xilinx DDR4 MIG Xilinx DDR4 MIG Xilinx DDR4 MIG
Standard peripherals Yes Yes Yes Yes

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 7
LEON-XCKU-EX

Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
3 Architecture
3.1 Cores
The common architecture is based on cores from the GRLIB IP library. The vendor and device identi-
fiers for each core can be extracted from the plug & play information. The used IP cores are listed in
table 3.
Note that the table above lists IP cores used in the full set of planned LEON-XCKU-EX designs. Sev-
eral designs contain a subset of the IP cores in the table.
3.2 Interrupts
The LEON-XCKU-EX example designs use the same interrupt assignment for all configurations. See
the description of the individual cores for how and when the interrupts are raised. All interrupts are
handled by the interrupt controller and forwarded to the processor.
Table 3. Used IP cores
Core Function Vendor Device
AHBCTRL AHB Arbiter & Decoder 0x01 -
APB3CTRL AHB/APB3 Bridge 0x01 0x0A2
APBCTRL AHB/APB Bridge 0x01 0x006
LEON3FT LEON3 SPARC V8 32-bit processor 0x01 0x053
DSU3 LEON3 Debug support unit 0x01 0x004
L3STAT LEON3 Performance counters 0x01 0x098
LEON4 LEON4 SPARC V8 32-bit processor 0x01 0x048
DSU4 LEON4 Debug support unit 0x01 0x049
L4STAT LEON4 Performance counters 0x01 0x047
LEON5 LEON5 SPARC V8 32-bit processor 0x01 0x0BA
DSU5 LEON5 Debug support unit 0x01 0x0BB
L5STAT LEON5 Performance counters 0x01 0x0B9
AHBUART Serial/AHB debug interface 0x01 0x007
AHBJTAG JTAG/AHB debug interface 0x01 0x01C
AHBSTAT AHB failing address register 0x01 0x052
APBUART 8-bit UART with FIFO 0x01 0x00C
GPTIMER Modular timer unit with watchdog 0x01 0x011
IRQMP LEON3 Interrupt controller 0x01 0x00D
GRGPIO General purpose I/O port 0x01 0x01A
L2CACHE Level-2 Cache Controller 0x01 0x04B
Xilinx MIG Xilinx DDR4 MIG - with GRLIB wrapper 0x01 0x090
Table 4. Interrupt assignment
Core Interrupt Comment
AHBSTAT 4 Not included in all EX variants
APBUART 2
GPTIMER 8, 9
GRETH_GBIT 5

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 8
Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
LEON-XCKU-EX

3.3 IP core documentation
This user manual does not contain IP core documentation. Please refer to the GRLIB IP Core User’s
Manual [GRIP] available at http://gaisler.com/products/grlib/grip.pdf.
The GRMON debug monitor also provides information about the system-on-chip’s configuration via
the command info sys.

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 9
LEON-XCKU-EX

Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
3.4 Signals
Please see the LEON-XCKU-EX Quick Start Guide [QSG] for information on FPGA pinout.
3.5 Resource utilization
Resource utilization is described in the GRLIB area spreadsheet, available at:
https://www.gaisler.com/products/grlib/grlib_area.xls

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 10
LEON-XCKU-EX

Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
4 Working with the board
4.1 Prerequisites
The following items are required to use LEON-XCKU-EX designs:
• Workstation with Windows or Linux
• Xilinx KCU105 Evaluation Kit
• LEON-XCKU bitstream
• GRMON3 debug monitor
The two last items can be downloaded via http://gaisler.com/LEON-XCKU.
Cobham Gaislers standard offer of toolchains can be used to build and run software on the LEON-
XCKU-EX designs. Toolchains and run-time environments are available for download via http://gais-
ler.com.
4.2 Programming the FPGA device and connecting with GRMON3
Please see the LEON-XCKU-EX Quick Start Guide [QSG] for information on FPGA programming
and using the SoC design.
4.3 Support
In case of technical issues please contact [e-mail]. The support line is normally available
only to companies and institutions with active support contracts. Limited support for the LEON-
XCKU-EX example designs is provided. When contacting support please provide a clear description
of which design that is used and your affiliation.
Sales and licensing questions should be directed to [e-mail].
There is also an open forum available at https://grlib.community .

LEON-XCKU-EX-UM
Jan 2022, Version 1.1 11
Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
LEON-XCKU-EX

5 Ordering information
Please contact [e-mail] for information on the GRLIB IP library.

Cobham Gaisler AB
Kungsgatan 12
411 19 Göteborg
Sweden
www.caes.com/gaisler
[email protected]
T: [phone]
Cobham Gaisler AB, reserves the right to make changes to any products and services described herein at any
time without notice. Consult Cobham or an authorized sales representative to verify that the information in
this document is current before using this product. Cobham does not assume any responsibility or liability
arising out of the application or use of any product or service described herein, except as expressly agreed to
in writing by Cobham; nor does the purchase, lease, or use of a product or service from Cobham convey a
license under any patent rights, copyrights, trademark rights, or any other of the intellectual rights of Cobham
or of third parties. All information is provided as is. There is no warranty that it is correct or suitable for any
purpose, neither implicit nor explicit.
Copyright © 2022 Cobham Gaisler AB
LEON-XCKU-EX-UM
Jan 2022, Version 1.0 12 of 12
LEON-XCKU-EX

Cobham Gaisler AB
Kungsgatan | SE-411 19 | Goteborg | Sweden
[phone] | www.caes.com/gaisler
