Calcana CAL Series Guide

CAL-SERIES Specifications, Installation, Operation Service and Spare Parts Manual
Printed in USA ©2019 Calcana USA Ltd.. Rev 4 1/19
Vented Radiant Tube Heater/ L’Appareil de chauffage de Tube Rayonnant donné vent
Gravity Vented Wall Furnace/ La gravité A Donné vent Fournaise de Mur
Low Intensity Infrared Heater/Radiateur à infrarouge a faible intensité
Also for Brooder Use/Aussi pour l’eveage des poules
For either indoor or outdoor installation/Installer à l’intérieur ou à l’extérieur
For Industrial, Commercial, Agricultural, Restaurant, Patio and
Residential Garage Applications.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause property
damage, injury or death. Read (refer to) the
installation operating and maintenance instructions
thoroughly before installing or servicing this
equipment. For assistance or additional information
consult a qualified installer, service agency or the gas
supplier.
ADVERTISSEMENT. L’installation déplacée,
l’ajustement, le changement, le service ou
l’entretien peuvent causer les dommages de
propriété, la blessure ou la mort. Lire (se référer à)
l’installation qui fonctionne et les instructions
d’entretien à fond avant d’installer ou entretenir
cet équipement. Pour obtenir de l’aide ou les
informations supplémentaires consultent un
programme d’installation, une agence de service
ou le fournisseur de gaz qualifié.
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may result;
causing property damage, personal injury or loss of
life.
ADVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette notice
pour réduire au minimum le risqué d’incendie ou
d’explosion ou pour éviter tout dommage
matériel, toute blessure ou la mort.
-Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
DANGER: WHAT TO DO IF YOU SMELL GAS:
1) Extinguish any open flame
2) DO NOT try to light any appliance.
3) DO NOT use or touch any electrical switches.
4) DO NOT use any phone in your building
5) Turn off gas.
6) Open Windows
7) Leave the building
8) Immediately call your gas supplier from a
neighbor’s phone or after you have left the
building. Follow the gas supplier's instructions.
9) If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a
qualified installer, service agency or the gas supplier
- Ne pas entreposer ni utiliser d’essence ni d’autres
vapours ou liquidés inflammables à proximité de cet
appareil ou de tout autre appareil.
DANGER: QUE FAIRE SI VOUV SENTEZ UNE
ODEUR DE GAZ:
1) Éteindre la flamme ouverte
2) Ne pas tenter d’allumer d’appareils
3) Ne touchez à aucun interrupteur.
4) Ne pas vous server des téléphonés dans le
bâtiment ou vous vous trouvez.
5) le Virage du gaz.
6) Ouvrir Windows
7) Part le bâtiment
8) Appelez immédiatement votre fournisseur de
gaz depuis un voisin ou âpres que vous êtes
parti le bâtiment. Suivez les instructions du
fournisseur.
9) Si vous ne pouvez rejoindre le service des
incendies.
- L’installation et I' entretien doivent être assures par
un installateur ou un service d’entretien qualifié ou
par fournisseur de gaz.
WARNING: Heat exchanger surface is hot. Do not touch surface or burn may result. Combustible material or
articles should not be placed on or near heater. Observe clearance to combustibles as noted on heater and in this
manual.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
INSATLLATEUR: Laissez cette notice
avec I’ appareil.
CONSOMMATEUR: Conservez cette
notice pour consultation ultérieure.
Calcana USA Ltd.
30201 Country Road 49
Loxley, AL, 36551
Tel: [phone]
Fax: [phone]

CAL-SERIES
ii
WHEN AN EXISTING CATEGORY I HEATER IS REMOVED OR
REPLACED, THE ORGINAL VENTING SYSTEM MAY NO LONGER
BE SIZED TO PROPERLY VENT THE ATTACHED APPLIANCES.
The effects of an improperly sized venting system can
include but not limited to: the formation of
condensate, leakage, spillage etc. The following test
procedure is required:
WARNING
CARBON MONOXIDE POISONING HAZARD
Failure to follow the steps outlined below for each appliance connected
to the venting system being placed into operation could result in carbon
monoxide poisoning or death.
The following steps shall be followed for each appliance connected to
the venting system being placed into operation, while all other
appliances connected to the venting system are not in operation:
1) Seal any unused openings in the venting system.
2) Inspect the venting system for proper size and horizontal pitch, as
required in the National Fuel Gas Code, ANSI Z223.1/NFPA 54 or the
Natural Gas and Propane Installation Code, CSA B149.1 and these
instructions. Determine that there is no blockage or restriction,
leakage, corrosion and other deficiencies which could cause an
unsafe condition.
3) As far as practical, close all building doors and windows and all
doors between the space in which the appliance(s) connected to
the venting system are located and other spaces of the building.
4) Close fireplace dampers.
5) Turn on clothes dryers and any appliance not connected to the
venting system. Turn on any exhaust fans, such as range hoods and
bathroom exhausts, so they are operating at maximum speed. Do
not operate a summer exhaust fan.
6) Follow the lighting instructions. Place the appliance being inspected
into operation. Adjust the thermostat so appliance is operating
continuously.
7) Test for spillage from draft hood equipped appliances at the draft
hood relief opening after 5 minutes of main burner operation. Use
the flame of a match or candle.
8) If improper venting is observed during any of the above tests, the
venting system must be corrected in accordance with the National
Fuel Gas Code, ANSI Z223.1/NFPA 54 and/or Natural Gas and
Propane Installation Code, CSA B149.1.
9) After it has been determined that each appliance connected to the
venting system properly vents when tested as outlined above,
return doors, windows, exhaust fans, fireplace dampers and any
other gas-fired burning appliance to their previous conditions of use.

CAL-SERIES
iii
TABLE OF CONTENTS
1.0 OWNERS RESPONSIBILITY--------------------------------- 1
2.0 INSTALLER RESPONSIBILITY------------------------------ 3
3.0 CODE COMPLIANCE ------------------------------------------ 5
4.0 SPECIFICATIONS: GENERAL SPECIFICATIONS -------- 6
5.0 DIMENSIONS--------------------------------------------------- 7
6.0 INSTALLATION CLEARANCES AND CLEARANCE TO
COMBUSTIBLES ------------------------------------------------------- 9
6.1 CLEARANCE TO COMBUSTIBLES FOR SPACE HEATING
AND BROODER INSTALLATION ----------------------------------------- 10
7.0 PRE-INSTALLATION INSPECTION: --------------------- 12
8.0 PACKAGING CONTENTS & DESCRIPTION OF PARTS:
13
CAL-40A-10’ (3 M)---------------------------------------------------- 13
CAL-40A/50A-15’ (4.16 M)------------------------------------------ 14
CAL-40A-10’ (3 M) (TWO PIECE MODEL) OR CAL-
40A/50A/75A-20’ (6.1 M) ------------------------------------------------- 15
CAL-40A/50A-15’ (4.16 M) (THREE PIECE MODEL) ----------- 16
CAL-40A/50A/75A-20’ (6.1 M) (FOUR PIECE MODEL) -------- 17
OUTSIDE: COMBUSTION AIR KIT ---------------------------------- 18
SIDE WALL VENT KIT ------------------------------------------------- 18
90° ELBOW PACKAGE ------------------------------------------------ 19
180° U-BEND PACKAGE---------------------------------------------- 19
PROTECTIVE SCREEN KIT -------------------------------------------- 20
PROTECTIVE SCREEN INSTALLATION ----------------------------- 20
9.0 INSTALLATION---------------------------------------------- 21
9.1 PLANNING---------------------------------------------------------- 21
9.2 TYPICAL GARAGE INSTALLATION ---------------------------- 21
10.0 SUSPENSION OF HEATER: -------------------------------- 22
10.1 HORIZONTAL INSTALLATION---------------------------------- 22
SUSPENSION POINTS------------------------------------------------- 22
HORIZONTAL INSTALLATION --------------------------------------- 23
HORIZONTAL INSTALLATION - MULTI ---------------------------- 24
10.2 TILT INSTALLATION ---------------------------------------------- 25
25° TILT (ALL LENGTHS) --------------------------------------------- 25
45° TILT (ALL LENGTHS) --------------------------------------------- 26
11.0 ASSEMBLY OF COMPONENTS---------------------------- 27
11.1 GENERAL INSTRUCTIONS--------------------------------------- 27
CAL-40A-10’ (3M) TWO PIECE ------------------------------------- 27
CAL-50A-15' (4.8M) THREE PIECE --------------------------------- 28
CAL-75A-20' (8.1M) FOUR PIECE ---------------------------------- 28
11.2 COMPONENT ASSEMBLY--------------------------------------- 28
JOINT HANGER TO REFLECTOR ------------------------------------ 28
CLAMP COUPLER------------------------------------------------------ 29
END CAP TO REFLECTOR -------------------------------------------- 29
BAFFLE/TURBULATOR INSTALLATION---------------------------- 30
VENT ADAPTOR INSTALLATION------------------------------------ 30
12.0 ASSEMBLY OVERVIEW ------------------------------------ 31
12.1 ASSEMBLY OF OPTIONS ---------------------------------------- 31
12.2 REFLECTOR ASSEMBLY: ALL LENGTHS ---------------------- 32
10' (3M) REFLECTOR PACKAGE ------------------------------------ 32
15' (4.16M) REFLECTOR PACKAGE -------------------------------- 32
20' (6.1M) REFLECTOR PACKAGE---------------------------------- 32
90° ELBOW KIT -------------------------------------------------------- 33
180° U-BEND KIT------------------------------------------------------ 33
13.0 OUTSIDE COMBUSTION AIR SUPPLY ------------------ 34
COMBUSTION AIR OPTION A DUCTED --------------------------- 35
COMBUSTION AIR OPTION A DUCTED --------------------------- 35
COMBUSTION AIR OPTION B UN-DUCTED ---------------------- 35
14.0 VENTING------------------------------------------------------ 36
ANSI Z83.20-2016/CSA 2.34-2016 ----------------------------- 36
GAS PRODUCTS NO. 405 ------------------------------------------ 36
JANUARY 1, 2019 --------------------------------------------------- 36
VERTICAL VENTING (CONTINUED) ROOF EXHAUST : TWO OR
MORE UNITS - USE 'B' STYLE CHIMNEY.-------------------------------- 41
15.0 OUTDOOR APPLICATIONS--------------------------------43
OUTDOOR INSTALLATIONS----------------------------------------- 43
16.0 UNVENTED APPLICATIONS------------------------------- 44
UNVENTED INSTALLATIONS---------------------------------------- 44
UNVENTED INSTALLATION END CLEARANCES ----------------- 44
17.0 GAS PIPING ---------------------------------------------------45
18.0 GAS CONNECTION------------------------------------------- 46
FLEX CONNECTOR ---------------------------------------------------- 46
19.0 GAS INPUT RATE --------------------------------------------48
20.0 ELECTRICAL CONNECTION -------------------------------49
21.0 WIRING DIAGRAM ------------------------------------------ 50
21.1 CAL WIRING DIAGRAM ----------------------------------------- 50
21.2 CAL HIGH/LOW WIRING DIAGRAM--------------------------51
21.3 CAL MODULATING WIRING DIAGRAM ---------------------52
21.4 CAL SINGLE INPUT 24 VOLT WIRING DIAGRAM---------- 53
21.5 CAL HIGH/LOW 24 VOLT WIRING DIAGRAM--------------54
21.6 CAL SS 24 VOLT MODULATING WIRING DIAGRAM------55
22.0 THERMOSTATS----------------------------------------------56
22.1 LOW VOLTAGE (SINGLE HEATER)----------------------------- 56
LOW VOLTAGE: ONE THERMOSTAT - ONE HEATER ---------- 56
22.2 LINE VOLTAGE (TWO OR MORE HEATERS) ----------------57
LINE VOLTAGE: ONE THERMOSTAT –TWO OR MORE
HEATERS ---------------------------------------------------------------------- 57
23.0 INITIAL START-UP------------------------------------------ 58
24.0 GAS VALVES --------------------------------------------------59
24.2 GAS VALVE DETAILS HI/LO-------------------------------------60
25.0 MANIFOLD PRESSURE REGULATOR ADJUSTMENT
AND PRESSURE VERIFICATION PROCEDURE:----------------62
26.0 SEQUENCE OPERATION -----------------------------------65
26.1 DESCRIPTION OF 3-TRY DIRECT SPARK IGNITION
SYSTEM: ----------------------------------------------------------------------65
26.2 OPERATIONS:------------------------------------------------------65
POWER UP/STANDBY------------------------------------------------ 65
HEAT MODE ----------------------------------------------------------- 65
FLAME FAILURE - RE-IGNITION------------------------------------ 65
27.0 TROUBLESHOOTING ---------------------------------------66
NO POWER TO HEATER --------------------------------------------- 66
INITIAL ELECTRICAL CHECKS --------------------------------------- 67
INITIAL GAS CHECKS ------------------------------------------------- 68
ELECTRICITY AND GAS TO HEATER, BUT STILL INOPERATIVE68
CHECK CONTROL BOARD ------------------------------------------- 69
FAULT CONDITIONS-------------------------------------------------- 69
INTERNAL CONTROL FAULT ---------------------------------------- 69
AIRFLOW FAULT - LOCK OUT (COMBUSTION AIR FLOW
PROBLEMS)------------------------------------------------------------------- 69
FLAME WITH NO CALL FOR HEAT (FLAME FAULT) ------------ 70
IGNITION LOCK OUT (FAILURE TO LIGHT)----------------------- 70
FLAME SENSOR CURRENT CHECK--------------------------------- 70
PROPER ELECTRODE LOCATION----------------------------------- 71
28.0 MAINTENANCE ----------------------------------------------72
29.0 PARTS:---------------------------------------------------------73
29.1 BURNER HEAD AND RELATED PARTS------------------------73
29.2 REFLECTOR AND TUBE PARTS---------------------------------74
29.3 PARTS LIST:---------------------------------------------------------75
30.0 WARRANTY --------------------------------------------------77
31.0 FUEL CONVERSION -----------------------------------------78
31.1 CONVERSION KIT FOR WHITE RODGERS OR HONEYWELL
SINGLE INPUT GAS VALVE------------------------------------------------ 78
31.2 CONVERSION KIT FOR VARIABLE INPUT GAS VALVES --80
32.0 EXAMPLE OF CONVERSION KIT LABEL ----------------81
33.0 SAFETY AND OPERATING INSTRUCTIONS------------82

CAL-SERIES
iv
TABLE OF FIGURES
Figure 1. EQUIPMENT DIMENSION .......................................... 7
Figure 2. OUTDOOR END CLEARANCES.................................... 9
Figure 3. VENTED CLEARANCES.............................................. 10
Figure 4. STANDARD REFLECTOR ........................................... 11
Figure 5. 25' TO 45' TILT......................................................... 11
Figure 6. CAL-40A-10’ (3 M) ................................................... 13
Figure 7. CAL-40A/50A-15’ (4.16 M) ...................................... 14
Figure 8. CAL-40A-10’ (3 M) (TWO PIECE MODEL) OR CAL-
40A/50A/75A-20’ (6.1 M) ....................................................... 15
Figure 9. CAL-40A/50A-15’ (4.16 M) (THREE PIECE MODEL). 16
Figure 10. CAL-40A/50A/75A-20’ (6.1 M) (FOUR PIECE MODEL)
................................................................................................ 17
Figure 11. OUTSIDE: COMBUSTION AIR KIT ........................... 18
Figure 12. SIDE WALL VENT KIT.............................................. 18
Figure 13. 90° ELBOW PACKAGE ............................................ 19
Figure 14. 180° U-BEND PACKAGE ......................................... 19
Figure 15. PROTECTIVE SCREEN KIT ....................................... 20
Figure 16. PROTECTIVE SCREEN INSTALLATION..................... 20
Figure 17. TYPICAL GARAGE INSTALLATION........................... 22
Figure 18. EXAMPLE SUSPENSION DETAILS ........................... 22
Figure 19. HORIZONTAL INSTALLATION - 10' (3m) PKG ......... 23
Figure 20. HORIZONTAL INSTALLATIONS ............................... 24
Figure 21. 25° TILT.................................................................. 25
Figure 22. 45° TILT.................................................................. 26
Figure 23. JOINT HANGER INSTALLATION .............................. 28
Figure 24. CLAMP COUPLER INSTALLATION........................... 29
Figure 25. END CAP INSTALLATION........................................ 29
Figure 26. BAFFLE / TURBULATOR INSTALLATION ................. 30
Figure 27. BAFFLE / TURBULATOR + FLUE ADAPTOR
INSTALLATION......................................................................... 30
Figure 28. 10' (3m), 15' (4.16m), 20' (6.1m) REFLECTOR PKG
ASSEMBLY & INSTALLATION DETAILS ..................................... 32
Figure 29. 90° ELBOW KIT INSTALLATION .............................. 33
Figure 30. 180° U-Bend Kit..................................................... 33
Figure 31. OUTSIDE COMBUSTION AIR SUPPLY ..................... 35
Figure 32. SIDE WALL VENTING, SINGLE UNIT...................... 39
Figure 33. VERTICAL VENTING, SINGLE UNIT........................ 40
Figure 34. COMMON VERTICAL VENTING, TWO OR MORE
UNITS INTO ONE COMMON VENT ......................................... 41
Figure 35. OUTDOOR INSTALLATIONS ................................... 43
Figure 36. UNVENTED INSTALLATIONS .................................. 44
Figure 37. END CLEARANCES UNVENTED INSTALLATIONS..... 44
Figure 38. GAS LINE CONNECTION WITH CERTIFIED FLEXIBLE
GAS CONNECTION................................................................... 47
Figure 39. SINGLE INPUT 120 VOLT WIRING DIAGRAM .......... 50
Figure 40. HIGH/LOW 120 VOLT WIRING DIAGRAM............... 51
Figure 41. MODULATING 120 VOLT WIRING DIAGRAM ......... 52
Figure 42. SINGLE INPUT 24 VOLT WIRING DIAGRAM ............ 53
Figure 43. HIGH/LOW 24 VOLT WIRING DIAGRAM .................54
Figure 44. MODULATING 24 VOLT WIRING DIAGRAM............55
Figure 45. LOW VOLTAGE THERMOSTAT WIRING..................56
Figure 46. LINE VOLTAGE THERMOSTAT WIRING...................57
Figure 47. GAS VALVE .............................................................59
Figure 48. HI/LO GAS VALVE...................................................61
Figure 49. FLAME SENSOR CURRENT CHECK ..........................70
Figure 50. PROPER ELECTRODE LOCATION.............................71
Figure 51. BURNER HEAD PARTS ............................................73
Figure 52. REFLECTOR AND TUBE PARTS................................74

CAL-SERIES
1
1.0 OWNERS RESPONSIBILITY
Thank you for purchasing our product. We have designed this unit to provide you with years of trouble-free
heating enjoyment.
READ THIS MANUAL IN ITS ENTIRERTY! If you do not understand any of the safety or hazardous warnings
contained in this manual, or have questions or concerns about the installation, operation, maintenance or
service of this heater, or any other questions or concerns relating to this heater, you MUST CALL THE
FACTORY at the telephone number noted on the front cover of this manual or as detailed on the rating
plate on the heater before operating this heater. Store this manual in a location near the heater, for future
reference. Make sure installation is performed by well qualified, licensed contractors in the required field of
work. If in doubt, DO NOT allow unit to be installed.
DO NOT park vehicles or place combustible objects close to the heater other than specified on the Clearance
to Combustible chart located in this manual and on the heater. Failure to observe the clearance to
combustibles can result in property damage, injury or death.
IMPORTANT NOTICE: The installation portion of these instructions are for the use of qualified individuals
specially trained, licensed and experienced in the installation of this type of equipment and related system
components.
NOTE: - The words "shall" or "must" indicate a requirement which is essential to satisfactory and safe
performance.
GENERAL HAZARD WARNING: The heater and related gas piping, fitting & wiring must be installed
by individuals or firms qualified, licensed and specially trained and experienced in installation of this
type of equipment and related system components.
Only persons who can understand and follow the instructions shall install or service this heater.
Persons not qualified shall not install this equipment nor interpret these instructions.
Failure to comply with the precautions and instructions provided with this heater can result in death,
serious bodily injury and property loss or damage from hazards of fire, explosion, burn, asphyxiation,
carbon monoxide poisoning or electrical shock.
WARNING: Installation and repair should be done by a qualified service person. The heater should be
inspected before use and at least annually by a qualified service person and prior to heating season.
Heaters used in dusty locations such as brooder barns, sawmills, woodworking shops, etc. will require
maintenance on a more regular basis and more frequent cleaning may be required as necessary. It is
imperative that the control compartments, burner(s) and circulating air passageways of the appliance
be kept clean. Periodic examination of the venting system is to be performed.
No one should work on a heater unless they are a licensed/qualified gas fitter or contractor. For all
repairs, parts MUST originate from the manufacturer of this heater in order not to void CGA/AGA
certification. Safety devices are not allowed to be rendered inoperative and left unattended as this
action can cause property damage, injury or death. Failure to do so will void your warranty.

CAL-SERIES
2
WARNING: Do not store or use halogen-emitting substances in the vicinity of this heater. Such
substances include chlorine based cleaners and swimming pool chemicals, water softening chemicals,
de-icing salts and chemicals, cleaning solvents such as carbon tetrachloride or perchloroethylene,
halogen type refrigerants, printing inks, paint and paint removers, varnishes, hydrochloric acid,
cements and glues, and masonry acid washing materials, The air used by the burner for combustion
must be free of halogens to avoid possible corrosion to the heating surfaces, which could result in
asphyxiation, fire and/or death.
WARNING: Children and adults should be alerted to the hazards of high surface temperatures and
should stay away to avoid burns or clothing ignition.
Young children should be carefully supervised when they are in the same place as the heater.
Clothing or other flammable materials should not be hung from the heater, or placed on or near the
heater.
Any safety screen, guard or other protective device removed for servicing a heater must be replaced
prior to operating the heater.
WARNING: Do not operate heater in a residential garage application without an approved (exhaust)
venting system installed and connected to the heater. When this heater is installed in a residential
garage, the operation of the heater, when not connected to a properly installed and maintained
venting system, can result in carbon monoxide (CO) poisoning and possible death.
Do not use this appliance if any part has been under water. Immediately call a qualified service
technician to inspect the appliance and to replace any part of the control system and any gas control
which has been under water.
Ne pas se server de cet appareil sil a été plongé dans I ‘eau, complètement ou en partie, Faire inspecter
I’ appareil par un technicien qualifié et remplacer toute partie du système de control et toute
commande qui ont été plongée dans I’ eau.

CAL-SERIES
3
2.0 INSTALLER RESPONSIBILITY
WARNING:
FIRE OR EXPLOSION HAZARD
The heater and related gas piping and wiring must be installed only by individuals or firms well qualified and
licensed in the required field of work.
Read and understand this manual in its entirety BEFORE you install this heater. If you have any questions call
your local representative. Verify that the fuel on the installation site is the same as what is required for this
heater. Check heater for damage or missing parts. If damage has occurred, notify carrier or point of purchase
at once for reconciliation of damaged goods. We are not responsible for transit damage. Do not install if
heater is damaged.
If you do not understand any of the safety or hazardous warnings contained in this manual, or have
questions or concerns about the installation, operation, maintenance or service of this heater, or any other
questions or concerns relating to this heater, you MUST CALL THE FACTORY at the telephone number noted
on the front cover of this manual or as detailed on the rating plate on the heater before operating this
heater.
Verify that model, input & length is what was ordered and is appropriate for installation. If heater is too small
for the heating load of the building, property damage can occur due to freezing. If unit is too large, severe
heat damage call occur to the building and/or its contents, fire, explosion, injury or death. If in doubt compare
heat loss of building with unit on site. If you are unable to calculate heat loss, call your local representative
for assistance.
Installation shall be in accordance with local codes. (See ‘CODE COMPLIANCE’).
If installation requires tilting, DO NOT over tilt the unit. Units are certified for installations up to 45°; however,
the maximum recommended tilt is 25°.
Install unit according to the “Clearance to Combustibles” for that particular heater and type of installation.
Make sure that clearances are maintained from vehicles parked below or in front of heater. Take into
consideration hoists. Failure to do so could result in property damage, injury or death.
Make sure unit is adequately suspended from ceiling or roof. Select hanging location that has adequate
strength to support heater.
This heater needs fresh air for safe operation and must be installed so there are provisions for adequate
combustion and ventilation air. In the USA, do not operate this heater without installing air intake hood or
duct (pin #800209) and exhaust/chimney vent in a residential garage application. In Canada, the outside air
intake is optional for residential garages. This heater must not be connected to a chimney flue serving a
separate solid-fuel burning appliance. This heater must only be installed with the venting that it is certified
for. Refer to the installation instructions for installation details. See pages 34 & 35)
If unit is to be sidewall vented, use part #800208 (Sidewall Vent Kit). Make sure vent cap is past eave. (See
pages 36 titled “VENTING”).
Do not render safety devices inoperable. Make sure gas line and/or service have adequate capacity for the
increased load of heater.

CAL-SERIES
4
Check line and manifold pressure with a manometer to confirm unit is set according to the specification on
the rating plate. Perform check with all gas-fired appliances operating. (See pages 48, 58 & 59 for further
details).
Provide adequate accessibility clearances for servicing.
Leave copy of this manual with owner (or a copy) for future reference.
HEATER OPERATION NOTE: Heater will have a higher heat output at the burner end as compared to the
exhaust end.
SPACE HEATING: As a general rule, it is suggested to locate the burner end toward the highest heat-loss area
(doors) of the space being heated. If you have any concerns or questions concerning orientation or layout of
the heater in your application, contact factory for assistance.
SPOT HEATING: On heaters with a straight-line configuration as well as units that have the maximum length
of radiant tube selected for the input capacity of a given burner, there will be a noticeable and more
pronounced perception of greater heat output from the burner end of the heater as compared to the exhaust
end. As a general rule, it is suggested for spot heating applications, to use a u-tube configuration to provide
a more even source of heat. If you have any concerns or questions concerning orientation or layout of the
heater in your application. Contact factory for assistance.
NOTE: Condensation from the exhaust may occur from this heater when it starts the heating cycle. The
condensation will stop once the heater warms up. Make sure venting is sealed according to section titled
"VENTING".

CAL-SERIES
5
3.0 CODE COMPLIANCE
Installation shall be in accordance with local building codes, or in the absence of local codes, in accordance
with:
FUEL SUPPLY:
CANADA: Natural Gas and Propane Installation Code, CSA B149.1 or latest edition.
USA: National Fuel Gas Code, ANSI Z223.1/NFPA 54, or latest edition.
ELECTRICAL GROUNDING:
CANADA: Canadian Electrical Code, CSA C22.1 or latest edition.
USA: National Electrical Code, ANSI/NFPA 70 or latest edition
In Canada: Electrical equipment and wiring shall comply with the applicable provisions of the current
Canadian Electrical Code, CAN/CSA C22.1, Part I and Part II, and CAN/CSA C22.2 No.3, Electrical
features of Fuel Burning Equipment.
PUBLIC GARAGE INSTALLATION:
Adequate clearances must be maintained according to the following standards:
CANADA: Natural Gas and Propane Installation Code, CSA B149.1 or latest edition.
USA: Parking Structures, ANSI/NFPA 88A or the standard for Repair Garages, ANSI/NFPA 88B or latest
edition.
Heaters must be installed a minimum of eight feet above the floor. Minimum required safe distances
to combustibles must be maintained from vehicles parked below the heater.
•When installed over hoists, the minimum required safe distances to combustibles must be
maintained from the uppermost point of the combustible materials placed on the hoist.
AIRCRAFT HANGERS:
Adequate clearances must be maintained according to the following standards:
CANADA: Enforcing Authority.
USA: Aircraft Hangers, ANSI/NFPA 409
•Heaters in aircraft storageor service areas must be installed a minimum of ten feet above the upper
surface of wings or engine enclosures of the highest aircraft which may be housed in the hangar.
(This should be measured from the bottom of the heater to the top of the wingor engine enclosure,
whichever is highest from the floor.)
•In other sections of aircraft hangars, such as shops or offices, heaters must be installed a minimum
of eight feet above the floor.
•Heaters installed in aircraft hangars shall be located so as not to be subject to damage by aircraft,
cranes, movable scaffolding or other objects.
•When installed over hoists, the minimum safe distances to combustibles must be maintained from
the uppermost point of the combustible materials placed on the hoist.
OTHER TYPES OF INSTALLATIONS:
If the installation is such that it doesn't meet the above-mentioned criteria or there is a possibility of
airborne combustible vapor or material in the building (HAZARDOUS LOCATION), consult the local Fire
Marshall, the Fire Insurance Carrier or other authorities for approval of the proposed installation prior
to installing the heater.

CAL-SERIES
6
4.0 SPECIFICATIONS: GENERAL SPECIFICATIONS
Rating: (Input: Natural and Propane Gas)
In Canada: 0-4500' (1372 m) In USA: 0-2000' (610 m) - De-rate Above 2000' (610 m) (see pg 48)
MODEL
BURNER INPUT BTU/hr
TUBE LENGTH
MIN
MAX
MIN
MAX
CAL-35A
n/a
35,000
10' (3 m)
20’ (6.1 m)
CAL-35AHL
17,500
35,000
10' (3 m)
20’ (6.1 m)
CAL-35AM
17,500
35,000
10' (3 m)
20’ (6.1 m)
CAL-40A
N/A
40,000
10' (3 m)
20’ (6.1 m)
CAL-40AHL
20,000
40,000
10' (3 m)
20’ (6.1 m)
CAL-40AM
20,000
40,000
10' (3 m)
20’ (6.1 m)
CAL-50A
N/A
50,000
15' (4.2 m)
20’ (6.1 m)
CAL-50AHL
25,000
50,000
15' (4.2 m)
20’ (6.1 m)
CAL-50AM
25,000
50,000
15' (4.2 m)
20’ (6.1 m)
CAL-75A
N/A
75,000
20' (6.1 m)
30’ (9.14 m)
CAL-75AHL
37,500
75,000
20' (6.1 m)
30’ (9.14 m)
CAL-75AM
37,500
75,000
20' (6.1 m)
30’ (9.14 m)
CAL-80A
n/a
40,000
80,000
20' (6.1 m)
40’ (12.2m)
CAL-80AHL
40,000
80,000
20' (6.1 m)
40’ (12.2m)
CAL-80AM
40,000
80,000
20' (6.1 m)
40’ (12.2m)
CAL-100A
n/a
100,000
30’ (9.14 m)
50’ (15.2m)
CAL-100AHL
50,000
100,000
30’ (9.14 m)
50’ (15.2m)
CAL-100AM
50,000
100,000
30’ (9.14 m)
50’ (15.2m)
CAL-125A
n/a
125,000
40’ (12.2m)
50’ (15.2m)
CAL-125AHL
62,500
125,000
40’ (12.2m)
50’ (15.2m)
CAL-125AM
62,500
125,000
40’ (12.2m)
50’ (15.2m)
GAS PRESSURE at MANIFOLD:
SINGLE INPUT:
VARIABLE INPUT:
Natural Gas:
3.5" (8.89 cm) W.C.
Lo: 1.5" (3.8 cm) W.C.
Hi 3.5" (8.89 cm) W.C.
Propane Gas:
10.5" (26.67 cm) W.C.
Lo: 5.5" (13.97 cm) W.C.
Hi: 10.5" (26.67 cm) W.C.
Gas Connection
Size:
0.5" (1.27 cm) N.P.T.
GAS INLET PRESSURE:
GAS:
MINIMUM:
MAXIMUM:
Natural
4.5" (11.43 cm) W.C.
14.0" (35.56 cm) W.C.
Propane
11.5" (29.21 cm) W.C.
14.0" (35.56 cm) W.C.
ELECTRICAL RATING:
DSI Ignition, 120v. 60hz, 1 Amps, Appliance, 3 prong plug connection, 24-volt low voltage thermostat.

CAL-SERIES
7
STANDARD EQUIPMENT:
Burner control housing is pre-assembled and pre-wired; unit comes complete with the following: industry
standard gas, electrical and venting connections, balanced air rotor, thermal overload protected motor, visual
burner inspection sight glass, combustion and air proving safety switches, 3-try spark ignition control, low
voltage thermostat connection, 4" aluminized steel combustion tube, polished aluminum standard reflector,
4" aluminized steel radiant heat exchanger, tube couplers, joint/hanger pieces, heat economizer baffle,
low/line voltage thermostat, and hanging chain kit.
Optional Equipment:
- 90° Elbow Kit
- Hi/Lo Control
- Sidewall Vent Kit
- Variable Input Control (Modulator)
- Two Piece Construction
- Protective Screen
- Stainless Steel Construction
- 180° U-Bend Kit
- Three Piece Construction
- 24 Volt input
- Fresh Air Kit
- Four Piece Construction
5.0 DIMENSIONS
SIDE VIEW
Figure 1. EQUIPMENT DIMENSION
BURNER END
EXHAUST END
15"
(38.1 cm)
“A” (SEE TABLE BELOW FOR DIMENSIONS)

CAL-SERIES
8
Table of Dimensions:
UNITS
DIMENSION "A" LENGTH
BURNER INPUT:
MIN
MAX
40,000 Btu/hr
10'-4" (3.15 m)
20’-4” (6.4 m)
50,000 Btu/hr
15'-4" (4.7 m)
20’-4” (6.4 m)
75,000 Btu/hr
20'-4" (6.4 m)
30’-4” (9.25 m)
80,000 Btu/hr
20'-4" (6.4 m)
40’-4” (12.13m)
100,000 Btu/hr
30’-4” (9.25 m)
50’-4” (15.13m)
125,000 Btu/hr
40’-4” (12.13m)
50’-4” (15.13m)
Table of Weights:
WEIGHTS
LENGTH
WEIGHTS INCLUDE BURNER HEAD
10’
85 LBS (39 KG)
15’
105 LBS (48.6 KG)
20’
125 LBS (57 KG)
25’
145 LBS (66 KG)
30’
165 LBS (75 KG)

CAL-SERIES
9
6.0 INSTALLATION CLEARANCES AND CLEARANCE TO COMBUSTIBLES
Installation of overhead heaters in garages or hangars MUST meet the requirements for bottom (below)
clearances detailed in CANADA: Natural Gas and Propane Installation Code, CSA B149.1 or latest edition or
USA: National Fuel Gas Code, ANSI Z223.1/NFPA 54, or latest edition.
WARNING: In all situations, clearances to combustibles must be maintained. Minimum clearance
from heater must be maintained from vehicles parked below heater. The posting of signs may be
required in storage areas referring to clearances to combustibles to the heater and/or limiting the
stacking height of stored Items near the heater specifying a maximum height. Clearances are not for
use in four (4) sided enclosures. Certain materials or items, when stored under the heater, will be
subjected to radiant heat and could be seriously damaged.
WARNING:The stated clearance to combustibles represents a surface temperature of 90°F (32°C)
above room temperature. Building material with low heat tolerance (such as plastics, vinyl siding,
canvas, tri-ply, etc) may be subject to degradation at lower temperatures. It is the installer's
responsibility to assure that adjacent materials are protected from degradation. When in doubt, check
heat tolerance of building material(s) with their manufacturer.
END CLEARANCES
(BURNER HEAD END)
Minimum clearances from air intake end of burner head to object is 12" (30.5 cm).
Provide adequate accessibility clearances for servicing and proper operation. Do not install unit in such a
manner that the combustion air entering the heater is reduced in any manner
OUTDOOR APPLICATIONS ONLY
(EXHAUST END)
OUTDOOR
APPLICATIONS
ONLY
WARNING: DO NOT INSTALL
IN RESIDENTIAL GARAGE
WITHOUT AN APPROVED
VENTING SYSTEM. For
Brooder use and some
industrial applications,
unvented installations are
permitted.
In these applications refer
to page 44 for details on
clearances and ventilation
requirements.
Figure 2. OUTDOOR END CLEARANCES

CAL-SERIES
10
VENTED
Figure 3. VENTED CLEARANCES
6.1 CLEARANCE TO COMBUSTIBLES FOR SPACE HEATING AND BROODER INSTALLATION
IN THE USA: Residential Garage heater installations with less than an 8' (2.44 m) clearance from the bottom
of the tube to the floor require the installation of the Protective Screen Kit PIN#3900212 (see page 20 for
details) The minimum floor clearance is 6' (1.83 m) from the floor to the bottom of the reflector.
IN CANADA: Residential Garage heater installations with less than an 7' (2.14 m) clearance from the bottom
of the tube to the floor require the installation of the Protective Screen Kit PIN#3900212 (see page 20 for
details) The minimum floor clearance is 6' (1.83 m) from the floor to the bottom of the reflector.
WARNING: In all situations, clearances to combustibles must be maintained. Minimum clearance
from heater must be maintained from vehicles parked below heater. The posting of signs may be
required in storage areas referring to clearances to combustibles to the heater and/or limiting the
stacking height of stored Items near the heater specifying a maximum height. Clearances are not for use
in four (4) sided enclosures. Certain materials or items, when stored under the heater, will be subjected
to radiant heat and could be seriously damaged.
WARNING:The stated clearance to combustibles represents a surface temperature of 90°F (32°C)
above room temperature.Building material with low heat tolerance (such as plastics, vinyl siding, canvas,
tri-ply, etc…) may be subject to degradation at lower temperatures. It is the installer's responsibility to
assure that adjacent materials are protected from degradation. When in doubt, check heat tolerance of
building material(s) with their manufacturer.

CAL-SERIES
11
INSTALLATION TYPE 1
INSTALLATION TYPE 2
Input*
A
B
C
D
Input*
A
B
C
D
40
4" (10.2 cm)
12" (31 cm)
36" (92 cm)
12" (31 cm)
40
4" (10.2 cm)
4" (10.2 cm)
36" (92 cm)
28" (72 cm)
50
4" (10.2 cm)
12" (31 cm)
43" (110 cm)
12" (31 cm)
50
4" (10.2 cm)
4" (10.2 cm)
40" (102 cm)
28" (72 cm)
75
4" (10.2 cm)
15" (32 cm)
48" (122 cm)
15" (32 cm)
75
4" (10.2 cm)
4" (10.2 cm)
45" (115 cm)
31" (79 cm)
Figure 4. STANDARD REFLECTOR
Figure 5. 25' TO 45' TILT
D
C
A
B
D
C
A
B

CAL-SERIES
12
7.0 PRE-INSTALLATION INSPECTION:
Refer to pages 13 to 20 for packaging contents.
Inspect the shipping container and heater for any evidence of shipping damage. If heater damage is found,
notify freight carrier and file a claim.
WARNING:
IF HEATER IS DAMAGED, DO NOT INSTALL
Check that all parts and pieces are present and accounted for. Report any missing items to carrier or point of
purchase at once.
Check that overall general appearance, source of fuel required and model numbers match unit requested.
Report any discrepancy to carrier or point of purchase at once.
THOROUGHLY INSPECT THE EQUIPMENT
IMMEDIATELY UPON ARRIVAL
OUR RESPONSIBILITY FOR THIS SHIPMENT CEASED WHEN THE CARRIER SIGNED THE WAYBILL.
If goods are received short or in damaged condition, it is important that you notify the carrier and insist on a
notation of the loss or damage across the face of the freight bill; otherwise no claim can be enforced against
the transportation company.
If concealed loss or damage is discovered, notify your carrier at once and request an inspection. This is
absolutely necessary. A concealed damage report must be made within 15-days of delivery of shipment. Unless
you do this, the carrier will not entertain any claim for loss or damage. The Agent will make an Inspection and
grant a concealed damage notation. If you give the Transportation Company a clear receipt for goods that have
been damaged or lost in transit, you do so at your own risk and expense.
WE ARE WILLING TO ASSIST YOU IN EVERY POSSIBLE MANNER TO COLLECT CLAIMS FOR LOSS OR DAMAGE,
BUT THIS WILLINGNESS ON OUR PART DOES NOT MAKE US RESPONSIBLE FOR COLLECTION OF CLAIMS OR
REPLACEMENT OF MATERIAL. THE ACTUAL FILING AND PROCESSING OF THE CLAIM IS YOUR RESPONSIBILITY.
WE ARE NOT RESPONSIBLE FOR FREIGHT DAMAGED IN TRANSIT!
IF CONTENTS ARE DAMAGED:
EVEN THOUGH CARTON DOES NOT LOOK DAMAGED:
A. MAKE CLAIM TO DELIVERY CARRIER AT ONCE
B. SAVE CARTONS FOR INSPECTION BY CARRIER

CAL-SERIES
13
8.0 PACKAGING CONTENTS & DESCRIPTION OF PARTS:
CAL-40A-10’(3 M)
Preassembled Model
(For two piece model see page 13 for details)
Figure 6. CAL-40A-10’ (3 M)

CAL-SERIES
14
CAL-40A/50A-15’ (4.16 M)
Figure 7. CAL-40A/50A-15’ (4.16 M)

CAL-SERIES
15
CAL-40A-10’ (3 M) (TWO PIECE MODEL) OR CAL-40A/50A/75A-20’ (6.1 M)
Figure 8. CAL-40A-10’ (3 M) (TWO PIECE MODEL) OR CAL-40A/50A/75A-20’ (6.1 M)

CAL-SERIES
16
CAL-40A/50A-15’ (4.16 M) (THREE PIECE MODEL)
Figure 9. CAL-40A/50A-15’ (4.16 M) (THREE PIECE MODEL)
