Caldertech Calderprep Plus User manual

Designed and Manufactured in the UK
Calderprep Plus Rotary
Scraping Tool 20-63mm
Model: 01-07-330
Operating Instructions
REVISION: 

© Copyright Caldervale Technology Ltd.
The copyright for this product and instruction manual is held by Caldervale Technology Ltd.
Any technical specifications, or illustrations part of this manual cannot be reproduced, used
illicitly or distributed in any form for competitive purposes.
Helping you
make the right
connections.

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
01
Contents
01. Introduction 02
02. Safety Instructions 03
03. Mandrel Heads 04
04. Operation 05
05. Specifications 07
06. Warranty Information 08
07. Service and Repair 10
08. Decommissioning and Disposal 10
Certificate of Conformity 11
Page
Contents

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
02
01. Introduction
Introduction
General Description
Calderprep tools are designed for scraping small diameter pipes
primarily for electrofusion purposes. The Calderprep tool is lightweight,
strong and durable. It removes ovality from pipe before scraping 100%
of the scraped area every time and produces consistent results over
hand scraping. It is designed to fit pipe sizes from 20mm through to
63mm.
The tool had mandrel inserts to allow for dierent sizes and wall
thicknesses of pipes allowing quick and easy changing of size.
The tool is designed to remove a thin layer of the pipe wall to prepare
the pipe (new, weathered or previously installed) and provide a fusible
surface for electrofusion purposes in accordance with Gas Industry
Standards GIS/PL2-5 Part 5 Electrofusion Ancillary Tools.
This product (Calderprep Plus) has been manufactured, inspected and
tested in accordance with the ISO9001 quality control systems and
procedures in place at Caldervale Technology Ltd, Dewsbury.
Before Using
It is important to ensure all component parts are present and in
serviceable condition.
The condition of the tool should be inspected thoroughly prior to use,
attention should be paid to the cutting tip, if this is damaged or worn the
quality of scrape can be severely limited.
Note: These tools are designed only to work with pipe size
specified, are not interchangeable and will not work on another
size of pipe. For example, a 63mm Calderprep will not scrape a
50mm pipe.
01.

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
03
02. Safety Instructions
Safety Instructions
1. Read and understand the whole booklet before using the tool.
2. Never attempt to operate on pipes that are not within the specified
dimensions.
3. Operatives should wear eye protection, gloves, safety headwear &
footwear when using the equipment.
Important!
This tool should be used in accordance with the pipe manufacturers’
recommendations and in line with local codes of practice.
This manual outlines the operation of the pipe preparation tool for PE
pipe and forms a part of the product to which it relates. It should be
kept for the life of the product. Any amendments issued by Caldervale
Technology Ltd should be incorporated in the text. The manual should
be passed to any subsequent holder or user of this product.
Caldervale Technology Ltd has a policy of continuous improvement
in product quality and design. Caldervale Technology Ltd therefore
reserves the right to change the specification of its models at any time,
without prior notice.
02.

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
04
Mandrel Heads
There are a number of mandrels readily available for the calderprep
line of rotary scraping tools. A dierent mandrel insert will allow the
Calderprep Plus to work on dierent pipe diameter as well as dierent
wall thicknesses of pipe to be scraped.
Mandrel heads are available for pipe sizes 20, 25, 32, 40, 50 and 63mm
and a range of wall thicknesses and SDR ratings are available. Special
sizes are available upon request.
Our mandrel heads can be found at www.caldertech.com
03.
03. Mandrel Heads

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
05
Operation
04.
04. Operation
Instructions for Use
1. Check the pipe size and SDR in order to select the correct Mandrel.
2. Unscrew the shaft thumbscrew by turning anticlockwise. It is not
necessary to fully remove this from the tool.
3. Use the shaft locator to locate the shaft at the correct position for
the pipe being used by lining up the line on the side of the shaft
locator with the size markings on the body of the tool then tighten
the shaft thumbscrew clockwise.
4. Ensure the arm spring clip is keeping the arm of the tool in its
uppermost position. If it is not, press on the rear of the arm with the
thumb and move the clip to keep the arm in its uppermost position.
5. Insert the mandrel shaft into the selected mandrel.
6. Insert the mandrel fully into the pipe to be scraped.
7. Turn the whole tool clockwise until the cutting tip is over the edge
of the pipe. Ensure it is on the edge to ensure there are no areas of
un-scraped pipe.
8. Push down on the rear of the arm and release the spring clip to
allow the cutting tip to rest on the pipe.
Cutting Tip
Shaft Locator
Mandrel Shaft
Shaft Thumbscrew
Arm Spring Clip

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
06
04. Operation
9. Begin to turn the whole tool clockwise using the crank handle. As the
tool is turned it will automatically advance the scrape down the pipe.
10. It may be necessary to pause scraping to remove excess peel.
Removal
1. When the scrape is complete push down once again on the rear of
the arm and put the arm spring clip in place to keep the arm raised
away from the pipe.
2. Remove the mandrel head from the pipe If there is diiculty
removing it, turn (the mandrel only), anticlockwise to remove.
Storage
IMPORTANT! When not in use always:
1. Ensure the tool is clean and dry before storage.
2. Always store in the tool case provided.
Routine Maintenance
1. Check for correct movement and operation and lubricate moving
parts at regular intervals before using.
2. It is important to ensure all component parts are present and in
serviceable condition.

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
07
05. Specifications
Specifications
Materials: Mild Steel / Stainless Steel /Aluminum /
Plastic / Brass
Finish: Natural / Zinc passivate (Steel) /
Blue (Plastic)
Dimensions: L. 300mm x W. 80mm x H. 280mm
Weight: 0.5kg
Min Pipe Diameter: 20mm
Max Pipe Diameter: 63mm
SDR: All (With correct Mandrel Head)
Product Code: 01-07-330
This unit is design and manufactured to meet the requirements of
National Grid Gas Industry Standards GIS/PL2-5 Part 5 Electrofusion
and Ancillary Tooling.
Caldervale Technology Ltd has a policy of continuous improvement
in product quality and design. Caldervale Technology Ltd therefore
reserves the right to change the specification of its models at any time,
without prior notice.
It is the responsibility of the operator to ensure that the PE pipe is
suitable for this clamping system if in doubt contact the PE pipe
manufacturer for confirmation.
05.

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
08
Warranty Information
1. Extent of Warranty
a) Subject to clauses 2 and 3, Caldervale Technology Ltd warrants to
the end-user customer that its products will be free from defects in
materials and workmanship, for six months after the date of purchase
by the end-user customer, subject to providing proof of purchase.
b) If Caldervale Technology Ltd receives, during the warranty period,
notice of a defect in product which is covered by this warranty;
Caldervale Technology Ltd shall either repair or replace the product,
at its option. Any replacement product may be either new or like-
new, provided that it has functionality at least equal to that of the
product being replaced.
c) All warranty work will be carried out by Caldervale Technology
Ltd unless otherwise agreed. On-site warranty and repair or
replacement services are available from authorised Caldervale
Technology Ltd service facilities world-wide.
d) Customers shall prepay shipping charges for products returned
to Caldervale Technology Ltd for warranty service, and Caldervale
Technology Ltd will charge for return of the products back to the
customer.
e) This warranty statement gives the customer specific legal rights.
The customer may also have other rights which vary from country to
country in the world.
2. Pre-conditions for Warranty Application
Caldervale Technology Ltd’s warranty covers only those defects which
arise as a result of normal use of the product, and this warranty shall
only apply in the following circumstances:
a) All the instructions contained in the operating manual have been
complied with; and
b) None of the following apply:
i) Improper or inadequate maintenance;
ii) Physical abuse;
iii) Unauthorised modification, misuse or any use not in accordance
with the operating manual and good industry practice;
06.
06. Warranty

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
09
06. Warranty
iv) Operation outside the products specifications;
v) Improper site preparation or maintenance;
vi) Faulty pipes.
3. Limitations of Warranty
a) Caldervale Technology Ltd does not warrant the operation of any
product to be uninterrupted or error free.
b) Caldervale Technology Ltd makes no other warranty of any kind,
whether express or implied, with respect to its products. Caldervale
Technology Ltd specifically disclaims the implied warranties of
satisfactory quality and fitness for a particular purpose.
c) To the extent that this warranty statement is inconsistent with
the law of the locality where the customer uses the product, this
warranty statement shall be deemed modified by the minimum
necessary to be consistent with such local law.
d) To the extent allowed by local law, the remedies provided in this
warranty statement are the customer’s sole and exclusive remedies.
e) This tool has been designed for the range of pipes available at the
time of its design and development. Caldervale Technology Ltd can
accept NO liability for the unit’s ability or otherwise to work with
new or dierent pipes that subsequently appear in the market place.
Please complete this information and keep it safely with your proof
of purchase receipt. You will require it for any warranty claim.
Where purchased:
Date of purchase:
Name of purchaser:
Address of purchaser:
Type of tool:
Serial number:

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
10
07. Service and Repair
Service and Repair
This product has no specific calibration period, however periodic safety
inspections should be carried out by the operator as specified in this
manual, if in any doubt please contact the manufacturer for further
information.
INTERNATIONAL AUSTRALIA / NZ
Caldervale Technology Ltd Caldertech Australia Pty Ltd
Bretfield Court, Dewsbury, Unit 3/30 Juna Drive,
West Yorkshire WF12 9BG, UK Malaga WA 6090, Australia
T. [phone] T. [phone]
E. [e-mail] E. [e-mail]
W. caldertech.com W. caldertech.com.au
Decommissioning and Disposal
These give the instructions for decommissioning and disposal of the
equipment and confirm how it is to be taken out of service safely, in
respect of the Essential Environmental, Health and Safety Requirements.
• If a Caldertech Calderprep Plus has reached the end of its useful
working life and cannot be refurbished it must be sent to a licensed
recycling facility for treatment. That will ensure the waste hierarchy
requirements are met.
• End of life treatment is the responsibility of the Customer. This can
also be achieved by returning the product back to the manufacturer
if required.
07.
08.

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
11
Certificate of Conformity
This document certifies that the product
detailed below fully conforms to the following
standard without derogation.
Certificate of Conformity
I. Smith
Managing Director
Caldervale Technology Ltd
Bretfield Court, Dewsbury, West Yorkshire WF12 9BG, UK
CRN 2769288 |ISO 9001:2015 Certified FM 30989
GIS/PL2-5:2018 Electrofusion Ancillary Tools
Product: Calderprep Plus
Rotary Scraping Tool
MARCH 

Operating Instructions Calderprep Plus Rotary Scraping Tool 20-63mm
12
Notes

INTERNATIONAL
Caldervale Technology Ltd
Bretfield Court, Dewsbury,
West Yorkshire WF12 9BG, UK
T. [phone]
E. [e-mail]
W. caldertech.com
AUSTRALIA / NZ
Caldertech Australia Pty Ltd
Unit 3/30 Juna Drive,
Malaga WA 6090, Australia
T. [phone]
E. [e-mail]
W. caldertech.com.au
