CalDigit TS3 Lite User manual

For more information visit www.caldigit.com
USER GUIDE
3 Lite
Lite

2
Table of Contents
Section 1 : General Information
Introduction 3
General Use Warnings 3
Safety Warnings 3
System Requirements 4
In the Box 4
TS3 Lite Diagram 5
Section 2 : Using the TS3 Lite
Powering the TS3 Lite 6
Connecting the TS3 Lite 7
LED Indicator 7
Using the TS3 Lite Utility 8
Interfaces Summary 9
Thunderbolt™ 3 9
USB 3.1 Type-C 9
USB 3.1 Type-A 9
DisplayPort 1.2 10
Ethernet 11
Audio 11
Technical Specications 12
TS3 Lite Accessories 13
Section 3 : Technical Support and
Warranty Information
Technical Support 14
Warranty 14

3
1. General Information
Introduction
The CalDigit Thunderbolt™ Station 3 Lite maximizes the potential of Thunderbolt™ 3’s 40G/s
throughout to add a plethora of devices to any Mac or PC Thunderbolt™ 3 enabled computer.
Featuring dual Thunderbolt™ 3 Type-C ports for daisy-chaining extra Thunderbolt™ 3 devices, the
TS3 Lite can t into any workow without sacricing a Thunderbolt™ 3 port.
Please read the TS3 Lite manual thoroughly and familiarize yourself with the product
before use.
Avoid using the TS3 Lite in extremely hot and cold environments. A safe temperature range
is between 40°F – 95°F (4.4°C - 35°C).
Avoid using the TS3 Lite in humid environments. Moisture and condensation can
accumulate in the device and cause damage to the electrical components.
Only use the power adapter that has been supplied with the TS3 Lite. An excessive or
inadequate power supply can result in unstable performance or device failure.
•
•
•
•
Keep the TS3 Lite away from liquids and moisture. Exposure to liquids can result in
damaging the unit, electric shock, and result in a re hazard.
If your TS3 Lite gets wet while it is still o, do not turn it on. In the case of any issue with the
device, do not attempt to repair or open the device yourself. Doing so can result in personal
injury, damage the device, and will void the warranty. If you have any issues, please contact
CalDigit Technical Support.
•
•
General Use Warnings
Safety Warnings

4
System Requirements
Thunderbolt™ 3 computers
Mac OSX 10.12 or later
Windows 7, 8, 10 or later
In the Box
A • 1 x CalDigit TS3 Lite
B • 1 x Power Supply
C • 1 x Power Cord (plug style may vary based on regional regulations and requirements.)
D • 1 x Thunderbolt™ 3 Cable
A
C
D
B

5
TS3 Lite Diagram
AC Adapter
USB 3.1 Type-C
(Data & Charge)
USB 3. 1
Type-A
USB 3. 1
Type-A
DisplayPortThunderbol t™3Gigabit
Ethernet
Audio
Out
Audio
In
Computer with
Thunderbolt™ 3
Pen Drive External Drive
4K
Monitor
Wall Outlet4K/5K
Monitor
External Storage
9:41 9:41

6
2. Using the TS3 Lite
The CalDigit TS3 Lite requires power from the AC adapter to operate. Connect the AC adapter
connector to the DC jack on the back of the TS3 Lite and the other side to an AC outlet.
1.
To power o the TS3 Lite, disconnect the power cable from the AC outlet.2.
Powering the TS3 Lite

7
Connecting the TS3 Lite to your computer
Once the TS3 Lite has been powered on, connect the device using a Thunderbolt™ 3 cable from
one of the Thunderbolt™ 3 ports on the TS3 Lite to a Thunderbolt™ 3 port on your computer.
LED Indicator
The TS3 Lite is equipped with an LED indicator, which will display a BLUE light if the unit is powered
on and connected to your computer.
ON OFF

8
CalDigit Docking Station Utility
The CalDigit Docking Station Utility makes it incredibly easy to disconnect all your USB storage
devices from the TS3 Lite without the need to manually disconnect them one by one.
Disconnecting all USB storage devices
1. Open the CalDigit Docking Station Utility on the top menu bar.
2. Click the eject button on the TS3 Lite image.
Disconnecting individual USB storage devices
1. Open the CalDigit Docking Station Utility on the top menu bar.
2. Click on the specic USB device you would like to eject. Only that device will be ejected.
NOTE
The CalDigit Docking Station Utility Installer le needs to be downloaded and
installed on your Mac from the CalDigit website. Please go to www.caldigit.
com/support.asp to download the Installer package.

9
Interfaces Summary
USB 3.1 Type-A
The TS3 Lite features two USB 3.1 5Gb/s ports. Both ports feature Battery Charging v.1.2.
USB 3.1 Type-C
The TS3 Lite features a USB 3.1 5Gb/s Type-C
port that can transfer at speeds up to 5Gb/s.
Thunderbolt™ 3
The TS3 Lite features two Thunderbolt™ 3
Type-C ports that can transfer at speeds up to
40Gb/s. One port is reserved for the connection
to your host computer and the second can be
used to connect extra Thunderbolt™ 3 devices.
Thunderbolt™ 3 Type-C supports video and
data.
Front (x1)
Rear (x1)

10
DisplayPort
The TS3 Lite features a full-size DisplayPort that supports a maximum resolution up to
4K. DisplayPort can be easily converted to HDMI, miniDisplayPort, VGA, and DVI with the use of
adapter cables or adapters.
Any display connected to the DisplayPort will be regarded as a secondary display by default. This
can be changed in the “Display” section under “System Preferences”.
NOTE
The TS3 Lite supports dual display functionality. However, the actual
resolutions are limited by GPU, OS, Driver and Firmware. Please refer to the
tables below for general information.
Resolution Video Display Frequency Single Monitor
2K (2560 x 1600) 60 Hz Yes
Full HD (1920 x 1080p) 60 Hz Yes
4K Yes
2K (2560 x 1600) 30 Hz Yes
Full HD (1920 x 1080p) 30 Hz Yes
Single Monitor: Using DisplayPort

11
Audio
The TS3 Lite has one 3.5mm audio input and one 3.5mm amplied audio output. The audio devices
must be selected in the “Sound” section under “System Preferences”. The TS3’s audio device will be
listed as ‘USB audio CODEC’ in your settings.
Ethernet
The TS3 Lite has a single Gigabit Ethernet port to connect to a Gigabit Ethernet network. Your
computer will connect to whichever network is connected to the TS3 Lite by default. These
settings can be changed in the “Network” section under “System Preferences”. The Ethernet port
also supports wake-on-LAN which allows your computer to wake from standby remotely via the
network.
Resolution Video Display Frequency Single Monitor
5K 60 Hz Yes
4K 60 Hz Yes
2K (2560 x 1600) 60 Hz Yes
Full HD (1920 x 1080p) 60 Hz Yes
2K (2560 x 1600) 30 Hz Yes
Full HD (1920 x 1080p) 30 Hz Yes
Resolution Video Display Frequency Dual Monitor
2K (2560 x 1600) 60 Hz Yes
Full HD (1920 x 1080p) 60 Hz Yes
4K Yes
2K (2560 x 1600) 30 Hz Yes
Full HD (1920 x 1080p) 30 Hz Yes
Single Monitor: Connected to Thunderbolt™ 3 Port (With use of a USB-C Video Adapter connected to the Thunderbolt™ 3 port)
Dual Monitors : Connected to DisplayPort & Thunderbolt™ 3 Port (With use of a USB-C Video Adapter connected to the Thunderbolt™ 3 port)

12
CalDigit TS3 Lite Specications
Dimensions and Weight
• Width : 8.78 inches ( 22.3 cm)
• Depth : 3.15 inches ( 8.0 cm)
• Height : 1.06 inches ( 2.7 cm)
• Weight: 0.97 lb ( 0.44 kg )
Interface
• 2 x Thunderbolt™ 3 Type-C
• 1 x USB 3.1 Gen 1 Type-C
• 2 x USB 3.1 Gen 1 Type-A
• 1 x DisplayPort
• 1 x Gigabit Ethernet
• 1 x Audio In & Out
Power
AC Input : 100V-240V ~50Hz/60Hz
DC Output: 12V/6A, 72W
System Requirements
Thunderbolt™ 3 computers
Mac OSX 10.12 or later
Windows 7, 8, 10 or later
Environment
Ambient Operating Temperature: 32°F ~ 158°F (0°C ~ 70°C)

13
CalDigit TS3 Lite Accessories
Thunderbolt™ 3 Cables
• Thunderbolt™ 3 Cable 1m (40Gb/s)
• Thunderbolt™ 3 Cable 2m (40Gb/s)
Power Supply
• TS3 Lite PSU 72W
USB-C Video Adapters
• CalDigit USB-C to VGA adapter
• CalDigit USB-C to HDMI adapter
Please contact CalDigit or an authorized CalDigit reseller for availability and pricing.

14
Specications and package contents are subject to change without notice.
Thunderbolt™ and the Thunderbolt™ logo are trademarks of Intel Corporation in the U.S. and/or other countries.
HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC. All other trademarks mentioned are the property of their respective owners.
Technical Support
If you run into any issues while using your TS3 Lite, please contact CalDigit Technical Support.
• Email: suppor[email protected]
• Phone: [phone]
• Website: www.caldigit.com/support.asp
To be eligible for customer support and warranty services, please register your CalDigit product
on our website.
• http://www.caldigit.com/Register/Register.asp
When contacting CalDigit Technical Support, make sure to be at your computer and have the
following information available:
1. Your TS3 Lite serial number
2. Operating system and version
3. Computer make and model
4. Devices being used on the TS3 Lite
Warranty Information
• The TS3 Lite is covered by a 1-year limited warranty.
• For detailed CalDigit warranty information please visit our website :
http://www.caldigit.com/rma/Limited-Warranty.pdf
Please visit www.caldigit.com for more information on all CalDigit products.
3. Technical Support and Warranty Information
