CalDigit TS4 User manual

For more information visit www.caldigit.com
USER GUIDE

2
Table of Contents
1. General Information ..................................................
Introduction
General Use Warnings
Safety Warnings
System Requirements
In the Box
TS4 Diagram
2. Using the TS4 ................................................................
Powering the TS4
Connecting the TS4
LED Indicator
CalDigit Docking Station Utility
Interfaces Summary
Thunderbolt 4
USB-C (10Gb/s)
USB-A (10Gb/s)
UHS-II SD/micro SD Card Slots
DisplayPort
Connecting Dual Monitors
How to connect Dual Displays to the TS4
2.5 Gigabit Ethernet
Audio
3. Specications ...............................................................
4. Optional Accessories(available on CalDigit online store) ......
5. Technical Support & Warranty Information .......
3
3
3
3
4
4
5
7
7
8
8
9
10
10
10
11
11
12
14
15
16
16
17
18
19

3
Introduction
The CalDigit Thunderbolt Station 4 (TS4) maximizes the potential of your
Thunderbolt 4, Thunderbolt 3, USB4, or USB-C host device by adding up to
18 ports of connectivity. In addition to this, the TS4 can provide up to 98W of
power delivery in order to charge your host device and will supply up to 2.5
Gigabit Ethernet for fast network connectivity.
Please read the TS4 manual thoroughly and familiarize yourself with the
product before use.
Avoid using the TS4 in extremely hot and cold environments. A safe
temperature range is between 50°F – 95°F (10°C - 35°C).
Avoid using theTS4 in humid environments. Moisture and condensation can
accumulate in the device and cause damage to the electrical components.
Only use the power adapter that has been supplied with the TS4. An
excessive or inadequate power supply can result in unstable performance
or device failure.
•
•
•
•
Keep the TS4 away from liquids and moisture. Exposure to liquids can result
in damaging the unit, electric shock, and result in a re hazard.
If your TS4 gets wet while it is still o, do not turn it on. In the case of any
issue with the device, do not attempt to repair or open the device yourself.
Doing so can result in personal injury, damage the device, and will void the
warranty. If you have any issues, please contact CalDigit Technical Support.
•
•
General Use Warnings
Safety Warnings
1. General Information

4
A
C
D
B
E
macOS 11.4 or above
Windows 10 (20H2) or above
Thunderbolt 4 Computer
Thunderbolt 3 Computer
Thunderbolt, USB4 or
USB-C Chromebook
System Requirements
USB-C (USB4) Computer
USB-C Computer
Thunderbolt or USB-C iPad
1 x CalDigit TS4
1 x Power Supply (230W)
1 x Power Cord
1 x Thunderbolt 4 Cable
0.8m (Passive)
2 x Rubber Feet Strips
A
B
C
D
E
In the Box

5
TS4 Diagram
SD UHS-II / microSD UHS-II Card Reader Audio Combo Jack USB-A 3.2 Gen2 (10Gb/s)
USB-C 3.2 Gen2 (10Gb/s)USB-C 3.2 Gen2 (10Gb/s)
7.5W20W
USB-A 3.2 Gen2 (10Gb/s) USB-C 3.2 Gen2 (10Gb/s)
7.5W7.5W
DisplayPort 1.4PowerSecurity Slot
Downstream Devices
Thunderbolt 4 / USB4 (40Gb/ s)
15W
Upstream Host

6
Audio
Combo Jack USB 3.2
Host (98W Charging)
Internet Micro-
phone
Pen Drive
Pen Drive
SSD Drive
SSD Drive
External Storage
External Storage
Smart phone
Smart phone
Tablet
Tablet
HeadphonesmicroSD Card
SD Card
Headphones/
Speakers
Thunderbolt 4 / USB4
SD UHS-II Card Reader
microSD UHS-II
Card Reader
Up to 8K MonitorUp to 8K Monitor External storage
DisplayPort 1.4Power
USB 3.2
USB 3.2
Audio In/OutUSB 3.22.5 Gigabit Ethernet

7
2. Using the TS4
The CalDigit TS4 requires power from the
AC adapter to operate. Connect the AC
adapter connector to the DC jack on the
back of the TS4 and the other side to an
AC outlet.
1.
To power o the TS4, disconnect the
power cable from the AC outlet.
2.
Powering the TS4

8
Once the TS4 has been powered on, connect the device using a
Thunderbolt™ 4 cable from the Thunderbolt™ 4 port labeled “Computer”
on the TS4 to a Thunderbolt™ 4, Thunderbolt™ 3 or USB-C port on your
computer. This single connection will now provide up to 98W charging for
your laptop in addition to expanding your connectivity options.
LED Indicator
The TS4 is equipped with an LED indicator, which will display a WHITE light if
the unit is powered on and connected to your computer.
ON OFF
NOTE
Always use the supplied Thunderbolt™ 4 / USB4 cable or a certied 40Gb/s
Thunderbolt™ 4 /USB4 cable.
Connecting the TS4 to
your computer

9
The CalDigit Docking Station Utility for macOS makes it incredibly easy to
disconnect all your USB storage devices from the TS4 without the need to
manually disconnect them one by one.
Disconnecting all USB storage devices
1. Open the CalDigit Docking Station Utility on the top menu bar.
2. Click the eject button on the TS4 image.
Disconnecting individual USB storage devices
1. Open the CalDigit Docking Station Utility on the top menu bar.
2. Click on the specic USB device you would like to eject. Only that device
will be ejected.
NOTE
The CalDigit Docking Station Utility Installer le needs to be downloaded and installed
on your Mac from the CalDigit website. Please go to downloads.caldigit.com to
download the Installer package.
CalDigit Docking Station Utility

10
Interface Summary
Thunderbolt™ 4
The TS4 features three Thunderbolt™
4 Type-C ports that can transfer at
speeds up to 40Gb/s. One port is
reserved for the connection to your
host computer and the second can be
used to connect extra Thunderbolt™
USB-C (10Gb/s)
The TS4 features three USB 3.2 Type-C ports (10Gb/s). These ports are
intended for data use only and two of them can supply up to 7.5W of power
in order to bus- power or charge devices.
The left front-facing USB-C port supports up to 20W of power and is intended
to be used with devices that require more power and is ideal for charging
devices faster.
All of the USB-C ports provide Oine Charging in order to charge your
devices even when the TS4 is not connected to a host computer.
Front (x2)
Rear(x1)
4 devices. Thunderbolt™ 4 Type-C supports video and data. The
Thunderbolt™ host port also provides charging up to 98W for your
computer.

11
USB-A (10Gb/s)
The TS4 features a total of ve USB-A (10Gb/s) ports all of which support
up to 10Gb/s performance and 7.5W of power. Three of the USB-A ports, as
indicated with a battery icon, provide Oine Charging which allows those
USB-A ports to charge devices even when the TS4 is not connected to a host
device. If you do not wish for the TS4 to Oine Charge your devices you can
connect those devices to the USB-A ports that do not have a battery icon.
UHS-II SD/micro SD Card Slots
The front-facing UHS-II SD (4.0), and UHS-II microSD (4.0) card slots are
capable of transng speeds up to 312MB/s. These card slots are compatible
with SDXC, SDHC, and standard SD cards.
Front (x1) Rear(x4)

12
DisplayPort
The TS4 features a full-size DisplayPort that supports a maximum resolution
up to 8K. DisplayPort can be easily converted to HDMI, miniDisplayPort, VGA,
and DVI with the use of adapter cables or adapters.
Note: The DisplayPort on the TS4 is only compatible with active DisplayPort
adapters. If you attempt to use a passive adapter, your display will not
function correctly. If you are not sure which type you have, please check with
your adapter manufacturer to ensure that it is an active adapter.
Any display connected to the DisplayPort will be regarded as a secondary
display by default. This can be changed in the “Display” section under
“System Preferences”.
NOTE
The TS4 supports dual display functionality. However, the actual resolutions are
limited by GPU, OS, Driver and Firmware. Please refer to the tables below for general
information.

13
Resolution Video Display Frequency Single Monitor
Full HD (1920 x 1080p) 60 Hz Yes
2K (2560 x 1600) 60 Hz Yes
4K 60 Hz Yes
6K 60 Hz Yes
8K* 60 Hz Yes
Single Monitor: Using DisplayPort
Resolution Video Display Frequency Single Monitor
Full HD (1920 x 1080p) 60 Hz Yes
2K (2560 x 1600) 60 Hz Yes
4K 60 Hz Yes
5K 60 Hz Yes
6K 60 Hz Yes
8K* 60 Hz Yes
Single Monitor: Connected to Thunderbolt™ 4 Port (With use of a USB-C Video Adapter connected to the Thunderbolt™ 4 port)

14
Connecting Dual Monitors or a single Higher Refresh Rate Monitor
You can add up to two external monitors to the TS4 as long as your computer’s
Thunderbolt ports support dual displays. M1 Pro, M1 Max, Intel based Macs, Thunderbolt
4, and Thunderbolt 3 PCs support up to dual displays. Some early Thunderbolt 3 PCs do
not support dual displays. Check if your Thunderbolt 3 PC supports dual displays. Users
on original Apple M1 computers, or on USB-C PCs can only connect a single display to the
TS4. In addation to the dual monitor support, TS4 can support an external monitor with
higher refresh rate showing below.
TBT4, TBT3 &
USB4 PC
Inrel TBT3
Mac
Apple M1
Mac
Apple M1
Pro & M1
Max Mac
USB-C
10Gb/s PC
(DP1.4)
TBT iPad Pro TBT4/USB4
Chromebook
4K 60Hz √ √ √ √ √ √ √
5K 60Hz √ √ √ √ √ √
6K 60Hz √√√√ √
8K 60Hz* √
Dual 4K
60Hz √ √ √ √
Dual 6K
60Hz √
Higher Refresh Rates* (Single Monitor)
4K
Up to
144Hz √ √ √ √ √ √
3440x1440
Up to
180Hz √√√√100Hz 100Hz
2560x1440
Up to
240Hz √ √ √ √ √ √
*Some refresh rates require DP 1.4, HBR3 and DSC 1.2 support from host, GPU and monitor. Some Thunderbolt 3 hosts
that only support DP 1.2 will be capped at a lower resolution & refresh rate. The bit/color depth may vary in order to
support higher refresh rates. The support of higher refresh rates may vary due to OS updates.

15
How to connect Dual Displays to the TS4
Option 1
- Connect one monitor to the DisplayPort connector.
- Connect the second monitor to one of the spare Thunderbolt 4 ports via a
USB-C Video Adapter*.
Option 2
- Connect one monitor to one of the spare Thunderbolt 4 ports via a USB-C
Video Adapter*.
- Connect the second monitor to one of the spare Thunderbolt 4 ports via
a USB-C Video Adapter*.
Option 3
- Connect two USB-C or Thunderbolt monitors directly to two of the
Thunderbolt 4 ports.
*Adapters sold separately. Also available on the CalDigit Online Store.
Resolution Video Display Frequency Dual Monitor
Full HD (1920 x 1080p) 60 Hz Yes
2K (2560 x 1600) 60 Hz Yes
4K 60 Hz Yes
6K 60 Hz** Yes
Dual Monitors : Connected to DisplayPort & Thunderbolt™ 4 Ports
(With use of a USB-C Video Adapter connected to theThunderbolt™ 4 port)
**6K 60Hz is only possible on M1 Pro or M1 Max based computers.

16
Audio
The TS4 has one front-facing audio combo port, one rear-facing audio out
port, and a second audio in port on the back of the device. Only the front-
facing combo port or the rear-facing audio ports can be connected at a time.
If you have all of these three audio ports connected to the devices at the
same time, the TS4 will default to the audio in/out on the front audio port.
Once you disconnect your audio device from the front audio port, the audio
will default to the device connected to the back of the TS4.
On macOS, the audio devices must be selected in the “Sound” section under
“System Preferences”. The TS4’s audio devices will be listed as ‘CalDigit TS4
Audio - Front’ or ‘CalDigit TS4 Audio - Rear’ in your settings depends on the
audio port you use.
2.5 Gigabit Ethernet
The TS4 has a 2.5 Gigabit Ethernet port with up to 2.5X performance* of
Gigabit Ethernet. The 2.5GbE ports is backwards compatible with standard
Gigabit Ethernet, and can be used with a 5GbE, or 10GbE network.
* 2.5 Gigabit Ethernet is only supported on Thunderbolt based hosts.

17
Interface:
3x Thunderbolt 4 (40Gb/s)
3x USB-C (10Gb/s)
5x USB-A (10Gb/s)
1x SD UHI-II
1x microSD UHI-II
1x DisplayPort 1.4
1x 2.5 Gigabit Ethernet
1x Front Combo Audio Jack
1x Rear Audio Jack In
1x Rear Audio Jack Out
Power:
DC IN (19.5V 11.80A)
Power Delivery:
98W to Host Device
Dimensions & Weight:
Height : 5.55” (141.0mm)
Width : 1.65” (42.0mm)
Length : 4.46” (113.4mm)
Weight : 1.41Ibs (0.64kg)
3. CalDigit TS4 Specifications
System Requirements
macOS 11.4 or above
Windows 10 (20H2) or above
Thunderbolt 4 Computer
Thunderbolt 3 Computer
USB-C (USB4) Computer
USB-C Computer
Thunderbolt or USB-C iPad
Windows Tablet
(Thunderbolt or USB-C)
Chromebook
(Thunderbolt 4, USB4, USB-C)
In The Box:
1 x CalDigit TS4
1 x Thunderbolt 4 Cable
2 x Rubber Feet Strips
1 x Power Cord
1 x Power Supply (230w)
100-240Vca; 50/60Hz
Warranty:
2 Year Limited Warranty

18
Thunderbolt™ 4 Cables
• Thunderbolt™ 4 / USB4 Cable Passive 0.8m (40Gb/s)
• Thunderbolt™ 4 / USB4 Cable Passive 1m (40Gb/s)
• Thunderbolt™ 4 / USB4 Cable Active 2m (40Gb/s)
Power Supply
• CalDigit TS4-230W AC Adapter PSU
DisplayPort Adapter
• CalDigit Active DisplayPort 1.2 to HDMI 2.0 Adapter
USB-C Video Adapters
• CalDigit USB-C to DisplayPort adapter
• CalDigit USB-C to HDMI adapter
Please contact CalDigit or an authorized CalDigit reseller for availability and pricing.
4. CalDigit TS4 Accessories

19
5. Technical Support and
Warranty Information
If you run into any issues while using your TS4, please contact CalDigit Technical
Support.
• Email (US): suppor[email protected]
• Email (UK/EU): eusuppor[email protected]
• Phone (US): [phone]
• Phone (UK/EU): [phone]
• Website: https://www.caldigit.com/support
When contacting CalDigit Technical Support, make sure to be at your computer
and have the following information available:
1. Your TS4 serial number
2. Operating system and version
3. Computer make and model
Warranty Information
• The TS4 is covered by a 2-year limited warranty.
Please visit www.caldigit.com for more information on all CalDigit products.
Specications and package contents are subject to change without notice.
USB Type-C®, USB-C® and USB4™ are trademarks of the Universal Serial Bus Implementers Forum (USB-IF).
Thunderbolt™ is a trademark of Intel Corporation. All product names are trademarks, registered trademarks, or
service marks of their respective owners.
Technical Support
