Thank you for buying this product.
Please read this manual carefully to get the best performance from this unit
Manual
*49009000* 49009000

|2
© 09195_sp10.monus.indd
The overvoltage protection device SP10 should be used in order to protect the
susceptible temperature sensors in or at the collector against induced overvol-
tages.
In the case of local thunderstorms, voltage peaks which could destroy the sensor
can be induced in the sensor cable. The protector diodes in the SP10 limit these
overvoltages to a value harmless to the sensor.
The best way to protect the sensor is to install this connecting box close to
the sensor. Because of the weather conditions, the SP10 is designed as a ro-
bust connecting box in a dripping water-protected housing which can be used
outdoors. Glands for the sensor cables at the bottom of the housing allow easy
installation.
SP10
Overvoltage protection device
Table of contents
Safety advice.............................................................................................2
Technical data...........................................................................................2
1. Mounting .............................................................................................3
2. Electrical connection..........................................................................4
Imprint ...................................................................................................4
Technical data
Material:
Lower part of housing:
Karilen E42D-H201
Upper part of housing: Luran S757R
Protection type: IP 65
Dimensions: 111 x 68 x 40 mm
(4.37 x 2.68 x 1.57")
Ambient temperature:
-25 ... +70 °C (-13 ... 158 °F)
Safety advice
Please pay attention to the following
safety advice in order to avoid danger
and damage to people and property.
Appropriate usage
This product is an overvoltage pro-
tection device used for protecting
the susceptible temperature sensors
in or at the collector against induced
overvoltages in compliance with the
technical data specified in these in-
structions.
Improper use excludes all liability
claims Subject to change. Errors excepted.
CE-Declaration of conformity
The product complies with the relevant directives and is there-
fore labelled with the CE mark.The Declaration of Conformity
is available upon request, please contact the manufacturer.

3 |
© 09195_sp10.monus.indd
• Stableandweather-proofhousingwith
outstanding design
• Overvoltageprotectionagainstlocallightningstrokes
and other externally induced voltages
• Easytomount
64,07 mm
67,79 mm
111 mm
40 mm
34 mm
1.Wall mounting For optimum protection against moisture,the sensor protection
device must be fitted vertically:
• Unscrewthehousingscrewandremovetheupperpart
of the housing
• Markthefasteningpointsonthewallanddrill
(centers 5 cm; 1.97“)
• Attachthelowerpartofthehousingtothewallsusing
the screws
• Puttheupperpartofthehousingontothelowerpart
and attach with screw.
lower part of
the housing
upper part of the housing
SP10
Overvoltage protection device

2. Electrical connection •Piercethecableglandswithapointedobject(g.1).Insert
the cables into the holes and pull them slightly back, such
that the edge of the gland is slightly turned to the outside.
Thus the device is protected against moisture.
•Connectthesensorcabletotheterminals1and2with
either polarity (fig. 2).
•Connectthecablewhichleadstothecontrolleratthe
terminals 3 und 4 to the corresponding controller terminals.
Sensor cables carry safety extra low voltage (SELV) and
must not be placed in a gland together with cables carrying
230V(US/CA:115V).Iftheconnectingboxisusedout-
doors,it is recommended to pierce the condensation water
hole at the bottom after the device has been installed.
1
