Caliber RDN 902BTi Assembly instructions

RDN 902BTi
MANUAL

For audio connectivity you can use USB sync cable that came with your Apple device.
For video or photo playback you’ll need to use the included 30 pin Dock connector to USB and 3,5mm Jack connector combi plug.
(Which can be connected to the input on the rear of the unit,as shown in the illustration below)
AUX input Optional wiring diagram:

Note: video playback from Apple devices with a lightning connector is not supported

RDN 902BTi 
29
Appendix
P. CONT
PINK
GREEN/WHITE
CAMERA
AVSYSTEM
WIRELESS HEADPHONES
MIC
TMC
USB IPOD RADIO ANT
MIC LINE
To iPod
TMC
CAN BOX
Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Front right / Gray CAN-L / Brown with black stripe
CAN-H / Orange with white stripe
Front right (-) / Gray with black stripe
Front left (+) / White Tele-mute / Brown
Front left (-) / White with black stripe
ACC+ / Red
Rear left (+) / Green Ground / Black
Battery 12V(+) / Yellow
Rear left (-) / Green with black stripe
Function
Connector A Connector B
PIN NO.
Connector
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8

General
Reference Supply Voltage 12V(DC)
Operating Voltage Range 10.5 - 15.8V(DC)
Max Operating Current 15A
Grounding System Car Battery Negative Pole
Dimensions(WXHXD) 178X100X173mm
Weight(main unit 2.5kg
FM
 
 
Frequency Response(±3dB) 20Hz~12.5KHz
 
 
 
 
AM
 
 
LCD
Screen size 6.2inches(16:9)
Display resolution 800X480dots
Contrast radio 400
Brightness 280cd/m2
DVD Player
Signal / Noise Ratio 80dB
Dynamic Range 80dB
 
Frequency Response(±3dB) 20Hz~20KHz
Maximum Output Power 4×75W
 
AUX IN
 
Frequency Response(±3dB) 20Hz~20KHz
Audio Input Level 1Vrms
Audio
 
Audio Output Level 2Vrms(Max)
Video
Normal Video Input Level(CVBS) 1.0±0.2V
 
 
Video Output Level 1.0±0.2V
Environment
Operating Temperature -10°C ~ +60°C
Storing Temperature -20°C ~ +70°C
 
 
Note: When the unit is operated extremely, such as operated with
maximum power output for a long time, or the temperature is over 70°C,
it will enter heat protection mode, the volume will be lower automatically.
This is normal.
Supported formats:
 
- Mp3 bit rate(date rate): 32-320 Kbps and variable bit rate
- WMA: v9 or earlier
- Directory nesting up to a maximum of 8 levels
- Number of albums/folders: maximum 99
- Number of tracks/titles: maximum 999
- ID3 tag: v2.0 or later
- File name in Unicode UTF8(maximum length:128 bytes)
Unsupported formates:
- Empty albums:an empty album is an album that does not contain
 

 



Supported MP3 disc format:
- ISO9660,Joliet
- Maximum title number: 512 
- Maximum album number: 255
- Supported sampling frequencies: 32kHz,44.1kHz,48kHz
- Supported Bit-rates: 32-320Kbps and variable bit rate
Supported video formats:
- DVD
- MP4
- DivX
This unit supports only the following iPod/iPhone models:






Video playback from an iPhone/iPod touch with lightning-connector is
not supported. Playing music and using the App Direct-mode are sup-
ported. Please consult our website to stay up to date on this topic.
Region code
According to DVD sale region, the whole world is divided into six
regions. A DVD disc can be played back only when its region code is
compatible with that of the player in use.
 
Region 2: Japan, West Europe, North Europe, Egypt, South Africa,
 
Region 3: Taiwan of China, Hong Kong of China, South Korea,
 
 
 
Region 5: Russia, Mongolia, India, Middle Asia, East Europe,
 
Region 6: Chinese Mainland.
Specially shaped

Replacement for a VW RNS510, RNS315 VW, Škoda Columbus, Škoda
Amundsen.
SPECIFICATIONS
RDN 902BTi 


RDN 902BTi 
4
Front Panel
1. [ ] Key: Eject disc
2. Microphone
3. [MENU] Key: Switch to the main menu
4. [RADIO] Key: Switch to the Radio source/ Band switch
5. [NAVI] Key: Switch to the navigation mode.
6. [DISC] Key: Switch to the disc source
7. [ MUTE / ] Knob:
Adjust volume (rotate)
Mute (short press)
Turn off the unit (long press)
8. [ TUNE / ] Knob: Tune for radio station
Skip to the previous or next title, chapter or track
Conrm an entry or selection
Play/Pause
9. [ ] Key: Adjust screen brightness
10. [SRC] Key: switch to next available source
11. SD/SDHC/MMC card slot
12. AV-in jack
13. USB connector
14. Reset: Load the original settings.
15. Map card slot
16. Disc slot
Before using
Notice:
The graphic in this manual is for reference
only, and may be different from that in real
unit. Reference to real unit is suggested.
ENGLiSH
NAVIGATION

RDN 902BTi 
5
Remote Control
Before using
1. Return to the home menu.
2. Eject the disc
3. Select DVD dialogue language
Show music catalog
4. Display information
5. Zoom
6. Select radio band
7. Call out
8. Goto search
9. A-B Repeat
10. Repeat playback
11. Setup menu
12. Play / Pause / Enter
13. Move the cursor up/down/left/right.
Up/down: Manual tuning
14. Slow playback
15. Numeric keys
16. Random playback
17. Intro playback
18. Stop playback
19. Mute the volume
20. Adjust volume
21. Image setting
22. Previous/Next
Auto tuning
23. Hang up
24. Clear information
25. DVD title
26. DVD menu / PBC
27. Select view angle
Show video catalog
28. Select DVD subtitle language
Show photo catalog
29. Unit power
30. Open EQ setting menu
EQ
MENU
SCN
RDM
A-B
ENGLiSH

RDN 902BTi 
7
Power On/O
Turn on: Press any button except on the front panel.
Or press [POWER] key on the remote control.
Turn o: When on, press and hold [ MUTE / ] knob on the panel.
Or press [POWER] key on the remote control.
Open SOURCE Menu
Press the [MENU] key on the front panel or touch the top
left corner of the screen to open the SOURCE menu.
Playing Source Selection
Open the SOURCE menu, and touch the desired source,
Notes:
Playing source selection means selecting work mode, such as DVD mode, Radio mode, Camera
mode, etc.
Basic operations
Set Date /Time
1. Touch [Settings].
2. Touch [Time].
The date/time setup menu is displayed.
Set date
1. Touch [Date] on the screen .
A submenu is displayed.
2. Touch or to set year, month and day.
3. Touch blank area to close the submenu.
Set clock mode
1. Touch [Clock mode] repeatedly to choose [12Hr] or [24Hr] .
Set time
1. Touch [Time].
2. Touch the time on the screen to show submenu.
3. Touch or to set hour and minute.
4. Touch blank area to close the submenu.
Tip:
When date/time is set, touch the upper left corner of screen to exit
the Settings menu.
ENGLiSH

RDN 902BTi 
8
Select radio as playing source
Press [RADIO] button on the front panel or touch [Radio] on the SOURCE menu.
Select one radio band
Press the [RADIO] button on the front panel or touch the [ ] icon
on the user interface to select one radio band among FM1, FM2,
FM3, AM1 and AM2.
Tune
Auto tuning
Hold [ ] / [ ] icon on the user interface more than 2 seconds to
seek a lower / higher station.
To stop searching, repeat the operation above or press other keys
having radio functions.
Note:
When a station is received, searching stops and the station is played.
Manual tuning
Method 1:
During manual tuning, the frequency will be changed in steps.
Rotate the [TUNE] knob on the front panel or touch the
[ ] / [ ] icon on the user interface to tune in a lower/higher
station.
Method 2:
1. Touch the numeric keypad icon [ ]. Numeric keyboard
is displayed, touch number to input frequency.
2. Touch [ ] to delete a inputted number.
3. Touch [ C ] to clear all of the inputted numbers.
4. Touch [ ] to enter.
5. Touch [ X ] to exit the keyboard menu.
Preset station
The unit has 5 bands, such as FM1, FM2, FM3, AM1, AM2, and Each band can store 6 stations;
hence the unit can store 30 stations in total.
Search stations automatically
dnabMAroMFnisnoitatstsegnortserotsdnahcraesotlenaptnorfehtnobonk]ENUT[sserP
automatically.
Manual store
1. Tune to a station.
2. Touch [ ].
3. Touch one of the channels P1 to P6 to save the selected band.
Tune to a preset station
1. Select a band.
2. Touch one of the preset channels (1 to 6) on the upper side of the screen.
Radio mode
ENGLiSH

RDN 902BTi 
9
Local Seeking
Touch the [LOC] icon on the top bar of the screen to choose the Radio Local on or o.
EQ Selection
Touch the [ ] icon on the top right of the screen to enter the Equalizer menu.
RDS Basics
RDS service availability varies with areas. Please understand if RDS service is not available in
your area, the following service is not available.
AF Mode
AF (Alternative Frequency): When the radio signal strength is poor, enabling the AF function will
the current station but with stronger signal strength.
Touch [AF] on the top bar to turn on/o AF function.
AF turns green: AF function is activated.
TA Mode
Touch [TA] on the top bar to turn on/o TA function.
When TA mode is turned on, the TA indicator will turns green.
When trac announcement is received, the unit will temporarily switch to the tuner mode
(regardless of the current mode) and begin broadcasting the announcement at TA volume level.
EON default is on.
Adjust RDS Settings
1. In Radio menu, touch [ ].
The option menu appears.
2. Touch an option to change the setting.
∙ [RDS]: to turn on or o “RDS” function.
∙ [CT]: to turn on or o “Clock Time” synchronization function.
∙ [TA VOL]: Touch [ ] or [
volume.
∙ [PTY List]: to set paring code.
Radio mode
ENGLiSH

RDN 902BTi 
10
Load Disc
You can play video, audio or images stored on the following discs:
•DVD Video, DVD-R, DVD+R, DVD-RW, DVD+RW
•VCD
•Audio CD, CD-R, CD-RW
Note:
Ensure that the disc contains playable content.
Eject the Disc
Press the [ ] key on the front panel or remote control to eject the disc. When the disc is ejected,
the unit switches to the previous source.
Touch Screen Controls
The touch key areas for DVD playback are outlined below:
B
C
A
A: Return to the main menu
B: Play the video and display playback information
C: Display onscreen control menu
Connect USB/iPod Device
1. Open the USB door.
2. Insert the small end of the supplied USB/iPod cable to the
USB socket, then connect the other end of the cable to your
USB/iPod device.
* You can also connect the USB/iPod to the rear USB port.
Remove the USB/iPod Device
1. Select other source on the main menu.
2. Remove the USB/iPod device.
Insert SD/MMC Card
1. Open SD card cover.
2. Insert the SD/MMC card into the SD/MMC card slot.
Play starts automatically.
Remove the SD/MMC Card
1. Select other source on the main menu.
2. Press the card until you hear a click sound.
3. Remove the card.
PLAY
ENGLiSH

RDN 902BTi 
Touch [ 1/2
11
Play/Pause
1. Once a disc, USB or SD/MMC card is inserted, play starts
automatically.
For DVD, if a menu appears, press [ ] to start play.
2. To pause, touch [ ].
To resume play, touch [ ].
Previous/Next
Touch [ ] / [ ] key on the screen to skip to previous/next track/chapter.
Fast Forward/Backward
Touch [ ] / [ ] key on the screen repeatedly to playback fast backward/forward.
Search for a Folder
1. Touch [ ] to display all available video folders.
2. Touch a folder, then touch [ ] or [
3. Touch [ ] to start play.
4. Touch [ ] to stop and play to resume.
1. Touch [ ] to display all available audio folders.
2. Touch a folder,then touch [ ] or [
3. Touch [ ] to start play.
4. Touch [ ] to stop and play to resume.
1. Touch [ ] to display all available picture folders
2. Touch a folder,then touch [ ] or [ ] to select a picture.
3. Touch [ ] to view the picture.
4. Touch [ ] to exit playing and play to resume.
Repeat
For DVD/VCD movie disc:
1. Touch bottom half of the screen to display menu on the screen, if necessary.
2. ] to display the 2nd menu.
3. Touch [ ] to select:
DVD
Repeat chapter: play the current chapter repeatedly.
Repeat title: play all chapters in the title repeatedly.
Repeat o: cancel repeat play.
VCD
Repeat single: play the current chapter repeatedly.
Repeat all: play all chapters in the disc repeatedly.
Repeat o: cancel repeat play.
PLAY
(DVD)
(DVD)
(CD/MP3)
ENGLiSH

RDN 902BTi 
Touch [ 1/2
Touch [ 1/2
Touch [ 1/2
12
1. Touch anywhere except the upper left corner to display menu on the screen, if necessary.
2. Touch [ ] to select:
[ Repeat single ]: Play the current chapter repeatedly.
[ Repeat folder ]: Play all the track s in the folder repeatedly.
[ Repeat all ]: Play all the tracks repeatedly.
[ Repeat o ]: Cancel repeat play
Tip
You can also press REPEAT on the remote control to select repeated play mode.
Repeat A-B
1. Touch bottom half of the screen to display control menu, if necessary.
2. ] to display the 2nd menu, if necessary.
3. Touch [ A-B ] repeatedly to mark:
Repeat A-: the start of the section.
Repeat A-B: the end of the section.
The selected section plays repeatedly.
4. To exit A-B repeat mode, touch A -B until [Repeat A-B o] appears.
Random Play
During play, touch [ ] repeatedly to turn random play on or o.
Select Audio Mode
When you play VCDs, you can select an audio mode (R/L/Stereo).
1. During play, touch bottom half of t he screen to display menu on the screen, if necessary.
2. ] to display the 2nd menu.
. Touch [ ] repeatedly until the audio mode is selected.
Select Subtitle Language
For DVD that contain two or more subtitle languages.
1. During play, touch bottom half of t he screen to display menu on the screen, if necessary.
2. ] to display the 2nd menu.
3. Touch [ ] repeatedly to select a language.
The selected language is displayed.
Tip
You may also press SUBTITLE on the remote control repeatedly to
select subtitle language.
Change View Angle
Some DVDs contain alternate scenes,such as scenes recorded from dierent
camera angles. For such DVDs, you can select from the available alternate scenes.
1. During play, touch bottom half of t he screen to display menu on the screen, if necessary.
2. Press [ ANGLE ] on the bottom control bar.
The view angle is changed.
PLAY
(VCD)
(DVD)
ENGLiSH

RDN 902BTi 
Touch [ 1/2
13
Rotate Pictures
1. When you view pictures,touch bottom half of the screen to
display menu on the screen, if necessary.
2. Touch [ ] repeatedly to rotate the picture.
Zoom
You can zoom in pictures for a close view.
1. When you view pictures, touch bottom half of the screen to
display menu on the screen, if necessary.
2. ] to display the 2nd menu, if necessary.
3. Touch [ ] repeatedly to zoom in the picture.
4. Use [ ], [ ], [ ], [ ] keys to pan through the enlarged
picture.
PLAY
ENGLiSH

RDN 902BTi 
14
You can make or receive phone calls with Bluetooth-enabled phones through the unit. You can
also listen to music from a Bluetooth-enabled device.
Pair the Bluetooth-enabled devices
To connect your Bluetooth device to the unit, you need to pair the device to the unit. Pairing needs
1. Turn on the Bluetooth function on the device.
2. Search for Bluetooth device with the device.
3. Select model name from in the pairing list.
4. Enter default password“0000”.
If pairing succeeds, phone call record is displayed.
Tip:
•The operational range between this unit and a Bluetooth device is approximately 10 meters (30
feet).
•htooteulBehthtiwflesruoyezirailimaf,tinusihtotecivedhtooteulBatcennocuoyerofeB
capabilities of the device.
•Compatibility with all Bluetooth device is not guaranteed.
•Any obstacle between this unit and a Bluetooth device can reduce the operational range.
•Keep this unit away from any othe r electronic device that may cause interference.
Disconnect Bluetooth device
To disconnect one device, touch [ ].
Tip
•The device will also be disconnected when the device is moved beyond the operational range.
•If you want to reconnect the device to the unit, place it within the operational range.
•If you do not want to reconnect the device to the unit automatically, touch [ ], then touch
Make a call
1. Select [Bluetooth] in the home menu.
2. Pair the phone with the unit.
3. Touch [ ], [ ] to select the paired phone, touch it to select.
4. Touch [ ], [ ] to search for phone number from the following
list:
∙ [Missed calls]
∙ [Received calls]
∙ [Dialed calls]
∙ [Mobile phone book]
Or touch [ ] to dial number directly, then touch [ ] to dial.
Bluetooth mode
ENGLiSH

RDN 902BTi 
15
Receive call
By default, all incoming calls are received automaticaly.
1. If there is incoming call, [Incoming call...] ashes on the screen.
Speak into the Bluetooth microphone.
2. When conversation ends, touch [ ](red) to terminate the call.
Tip
∙ You can select to receive calls manually by set [Auto answer] to [Off] status.
Switch Phone Call to the Mobile
If you do not want your passenger to hear your incoming call, you can switch the
call to the mobile.
1. During talking, touch [ ].
The voice is transferred from the unit’s loudspeaker to the mobile phone.
Adjust Bluetooth Settings
1. In Bluetooth menu,touch [ ].
The option menu is displayed.
2. Touch on the selected option to change the setting.
∙ [Bluetooth]: to turn on or off “Bluetooth” function.
∙ [Auto Connect]: to turn on or off “Auto connect” function.
∙ [Auto Answer]: to turn on or off “Auto answer” function.
∙ [Pairing Code]: to set paring code.
∙ [Phone Book Sync]: to synchronize phone book, touch [ ] on the sub-menu popped out.
Tip
∙ You can also adjust Bluetooth settings in the “Settings”menu.
Bluetooth mode
ENGLiSH

RDN 902BTi 
16
Select iPod as playing source
Turn on the unit’s power, and connect an iPod to the unit via a iPod cable, the unit will load the
iPod automatically.
Play
On the iPod main menu, operate the iPod via touch panel.
1. When the music root menu appears on the screen,
touch an option (such as PlayLists, Artists...),
then touch [ ] or [
2. Touch the selected option to play back.
3. To pause, touch [ ].
To resume play, touch [ ].
4. Skip to previous/next track, press [ ] / [ ] key.
NowPlaying: If you return to the root menu when playing a song, you can touch [ ] to continue
the previous playback.
1. Touch [ ] to display video folders root.
2. Touch an option, then touch [ ] or [
3. Touch [ ] to start play.
4. Touch [ ] to stop and return to the root menu.
1. Touch [ ] to return to playlist menu.
2. Touch [ ], then operate on your iPod.
iPod
ENGLiSH

RDN 902BTi 
17
Adjust volume
To adjust volume, rotate the volume knob on the bottom left of the front panel.
Mute
When playback, press the volume knob on the panel, the sound is cut o.
To resume sound, press the knob again.
Select preset equalizer
You can select preset equalizer:
∙ [User] ∙ [Jazz]
∙ [Techno] ∙ [Optimal]
∙ [Rock] ∙ [Flat]
∙ [Classic] ∙ [Pop]
1. Touch [ ] on the screen.
The current Equalizer setting is displayed.
2. Touch [ + ] or [ - ] to select an EQ.
3. Touch [ + ] or [ - ] to adjust belowsettings:
∙ [Bass] bass range: -14 to +14
∙ [Mid] middle range: -14 to +14
∙ [Treb]treble range: -14 to +14
4. Touch [ ] to restore the above settings into default settings.
5. Touch the upper left corner of the screen to exit.
Adjust fader/balance
You can also adjust the front and rear speaker balance, the left and right speaker balance,and
subwoofer settings.
1. Touch [ ] on the screen.
2. Touch [ ].
3. Touch [ + ] or [ - ] to adjust subwoofer volume.
∙ Subwoofer volume range: 0 to 24.
4. Touch [ ], [ ] to adjust fader value.
Touch [ ], [ ] to adjust balance value.
∙ Fader range: - 24 to +24
∙ Balance range: -24 to +24
5. Touch the upper left corner of the screen to exit.
Adjust sound
ENGLiSH

RDN 902BTi 
18
Display System
1. Touch the upper left corner to display main menu.
2. Then select [Settings]. The settings menu is displayed.
If [Settings] is not on the current menu, touch on the
right bottom of the screen.
Adjust video settings
1. Touch [Video].
2. Touch [ ] or [ ] to highlight a setting.
3. Touch an option repeatedly to select:
Video settings Options Description
Aspect ratio Full For widescreen display
Normal For normal display
Video input You can select the video input format : Auto/NTSC/PAL/SECAM
Rear view camera Normal When you drive in reverse, the rear view is displayed normally.
Mirror When you drive in reverse, the rear view is displayed inmirror image.
Parking On/O When “Parking” is on, if the video disc is played, the screen appears
WARNING information and blank screen.
Backcar mode Camera/Radar You can switch the backcar mode to camera/radar.
DivX registration code View code for DivX registration.
4. Touch blank area of the screen to close sub-menu or touch
upper left corner of the screen to exit settings menu.
SETUP
Adjust general Settings
1. Touch [General], if necessary.
2. Touch [ ] or [ ] to highlight a setting.
3. Touch on the option to display/select an option.
General settings Options Description
Radio region
USA
Select one that matches your location.
Asia
Japan
Europe
Europe (LW)
OIRT
Dimmer mode Night/Dark/Normal/Bright You can select the dimmer mode.
Key colour You can select the key colour.
Beep On Turn on the beep sound. Each time you press a button,
the unit beeps.
O Turn o the beep sound.
Wallpaper
Black Metallic/Blue Metallic/Red
Metallic/Green Metallic/Black You can select the preferred wallpaper.
Calibration Calibrate the touch screen.
Load factory Reset the unit.
4. Touch blank area of the screen to close sub-menu or touch upper left corner of the screen to
exit settings menu.
ENGLiSH

RDN 902BTi 
19
SETUP
Adjust time settings
Please refer to <Basic Operations>.
Adjust sound settings
1. Touch [Sound].
2. Touch an option repeatedly to select:
Sound settings Options Description
Subwoofer On Turn on the subwoofer.
Off Turn off the subwoofer
Subwoofer lter
80Hz
Select subwoofer lter criteria.120Hz
160Hz
Dynamic Bass
Boost
On The dynamic Bass Boost functions is on.
Off The loudness function is off.
3. Touch the upper left corner of the screen to exit.
Adjust language settings
1. Touch [Language].
2. Touch an option repeatedly to select.
Language settings Description
On screen display Select on-screen display language.
DVD audio Select DVD audio language. Options available depend on DVD disc.
DVD subtitle Select DVD subtitle language. Options available depend on DVD disc.
Disc menu Select DVD menu language. Options available depend on DVD disc.
3. Touch the upper left corner of the screen to exit.
Adjust Bluetooth settings
1. Touch [Bluetooth].
2. Touch an option repeatedly to select:
Bluetooth settings Options Description
Bluetooth On Turn on the Bluetooth function.
Off Turn off the Bluetooth function.
Auto connect On If the pre-paired device is within the effective range, the unit re-connects
to pre-paired device automatically.
Off Need to re-connect manually.
Auto answer On Answer paired phone call automatically.
Off Answer phone call manually.
Microphone Internal Use internal microphone
External Use external microphone (need to be connected)
Pairing code Set the password for pairing the unit with other Bluetooth device.
3. Touch the upper left corner of the screen to exit.
ENGLiSH

RDN 902BTi 
20
SETUP
Adjust DVD rating
1. Touch [DVD].
2. Touch an option to select:
DVD rating Options Description
Set password Set password to restrict the play of discs. The factory password is 4321.
Rating level
Kid safe Acceptable for children.
GAcceptable for general viewers.
PG Parental guidance suggested.
PG-13 Unsuitable for children under age 13.
PG-R Recommend parents to restrict children under 17 to view.
R Restricted recommend parents to guide children under 17 to view.
NC-17 Unsuitable for children under age 17.
Adult Acceptable for adults only.
3. Touch the upper left corner of the screen to exit.
Adjust volume settings
You can set different volume for different modes.
1. Touch [Volume].
The volume setting sub-menu is displayed.
2. Select a source.
3. Touch [ ] or [ ] to assign value: 0 to 12.
When switching to the source,the volume increases automatically.
4. Touch the upper left corner of the screen to exit.
ENGLiSH

RDN 902BTi 
21
Listen to other devices
You can connect an external audio/video device to the unit.
1. Connect the car audio to the device with the supplied AV cable.
2. Touch the upper left corner to display the main menu.
3. Touch [AV-IN1] / [AV-IN2].
4. Operate the connected device(see the instructions manual of the device).
Reset
When the unit hangs up, you can reset it.
Press RESET button with a ball-point pen or similar tool.
Tip
When the unit is reset, all the settings remain unchanged.
Remove the unit
To remove the unit from the dashboard.
1. Take off the trim plate.
2. Screw off the four screws on the left/right side of the unit.
3. Pull the unit out from the dashboard.
Replace fuse
If there is no power, the fuse may be damaged and need to be replaced.
1. Take out the unit from dashboard.
2. Check the electric connection.
3. Buy a fuse that matches the amp rating of the damaged fuse.
4. Replace the fuse.
GPS
1. Press [NAVI] button on the front panel or select [Navigation] on the main source menu, the
navigation menu will display in a few seconds.
2. Refering to the map manual to operate the navigation system.
Other modes
Reset
ENGLiSH
