Caliber PMT 564BT User manual

PMT 564BT
Manual
• GB •

Bluetooth®version: 5.0
 supportsA2DPandAVRCPprole
Bluetooth®range: up to 10 meters (without barrier)
Transmission: Bluetooth®: Freq range: 2402-2480 Mhz / Max e.r.p:
<100mW/20dBm
Bluetooth name: “PMT564BT_CALIBER”
Built-in connections: - Micro SD card slot (max. size 32GB)
- Aux-out / Aux-in 3.5mm jack connection
Music format: MP3/WMA/FLAC
FM Freq. transmitter range: 87.6-107.9MHZ, Max e.r.p: <50nW/-43dBm
Frequency stability: ±10ppm
Transmit Distance max. 3 meter
USB charging outputs: - 5V DC 2.4A
- QC3.0 DC 3.5-6.5V/3A, 6.5V-9A/2A,9-12V/1.5A.
Power supply: 12-24V DC
Dimensions: 86(W) x 42(D) x 180(H) mm
Packing contents:
Bluetooth and FM Transmitter device PMT564BT
User Guide
3.5mm Aux Cable
PMT 564BT Specifications

Thanks for choosing our Bluetooth FM Transmitter. This device streams calls and music directly from your
Bluetooth device to the car FM stereo system. The built-in microphone provides you with an amazing
hands free function, it also features Micro SD card that lets you stream your favorite MP3 tunes to your car’s
stereo system and charge your phone simultaneously. It also delivers a deeper bass with touch of the bass
button when playing the music. What’s more, the PMT564BT is also equiped with Dual USB Charging ports
( Q.C 3.0 & 2.4A ). This will save you charging time. Please read the User Manual carefully before using.
Features:
1. Wirelessly transmits phone calls & audio to the car FM stereo system
2. Hands-free calling for safe driving
3. With bass boost function
4. Flexible goose-neck for better visablility
5. Big LED display
6. Supports AUX-out function for wired connection
7. Micro SD card reader( Max 32 GB )
8. Dual USB charger, output 5V/2.4A + QC3.0
9. Bluetooth 5.0 Technology
Product Overview:
Using FM Transmitter function:
1. Plug the Bluetooth FM transmitter into your vehicle’s cigarette lighter or power port 12/24V.
2. Tune your radio to an unused FM frequency, then match the same frequency on this unit.
3. Insert a Micro SD card containing MP3 files into MicroSD card slot of this unit, It will play and transmit
the audio automatically.
4. AUX-out function: Plug the provided audio cable into car Aux-in port to connect with car audio system,
Another connector to the Aux-out port of this unit, When using this function, High quality music will
come out from car system.
5. AUX-in function: You can connect an external device e.g. MP3 player to the AUX-in of the PMT564BT
using the provided jack-to-jack cable.
6. Music bass boost function: Press the bass button to active the deeper bass when listening to music.
7. Press & hold to turn ON / OFF the display. The device will still function.
Using Bluetooth function:
1. Using Bluetooth for the rst time, you need to pair your mobile phone with this unit. Activate your
mobile phone’s Bluetooth function, then search new device. When the mobile phone detects this unit
(named as “PMT564BT_Caliber”), pair by using the password “0000”if requested.
2. Onmusicplayingmode, when there is an incoming call, this unit will automatically switch to telephone
mode.
3. Onmusicplayingmode, press the“BASS” and hold for 2 seconds to switch the modes between Bluetooth
and Micro SD card reading.
Bluetooth calling:
1. Press
/ 12 to answer the incoming call or hang-up a call.
2. Press and hold / 12 for 2 seconds during a call to reject the incoming call in Bluetooth calling mode.
3. Press twice to dial the last dialed number.
4. When making a call, you can only dial the phone number by your mobile phone, but once the call is
connected, you can use the hands-free function to enjoy it.

Using USB charger function:
This device has dual USB port for charging, One port is 2.4A, Another port is the quick charge QC3.0. When
this unit is powered from car lighter socket, connect the USB Charger port to your mobile phone or others
device with the needed USB cable (not included).
About QC3.0 USB Port:
If your mobile support the Quick charge, it will charge based on Qualcomm QC 3.0 protocol, DC 3.5-
6.5V/3A, 6.5V-9A/2A,9-12V/1.5A.
Listed compatible devices for reference:
Galaxy S7/S6/Edge/Edge Plus, Galaxy Note 5/4/ Edge, LG G4/G5,LG G Flex2,Nexus 6,HTC One M8/ M9,Droid
Turbo, Xperia Z3/Z3 Compact/Z3 Tablet Compact/Z4 Tablet and many more (please check the ocial
Qualcomm QC product list for a more updated list, click here)
If you plug mobile which not listed among above, it will detect the phone voltage automatically and
output accordingly.
About 2.4A USB Port:
This USB port output maximum 2.4A. It will also detect the phone’s voltage and output accordingly.
Quick Guide:
1. Answer / hang up the call:
Press “
/ 12 ” button: answer the call
Press “
/ 12 ” button: hang up the call
2.Ignore call
Press “
/ 12 ” and hold for 3 seconds to reject incoming calls
3.Call last Number
Press “
/ 12 ” twice to dial the last Number automatically.
4.Private calling
When answering a call ,press“
/ 12 ” and hold for 3 seconds to switch to private call mode.
5.Play and Pause the music:
Press “
/ 12 ” Button: Play the music
Press “
/ 12 ” Button again: Pause playing
6. Adjust the Volume:
Press”8”and hold for 2 seconds to increase the Volume
Press” 7” and hold for 2 seconds to decrease Volume
7.Set frequency:
press “CH+”: increase the frequency
Press ”CH-”: decrease the frequency
8.Choose music:
Press “8”Button: Play the next song
Press ” 7”Button: Play the previous song
9.Bass Booster:
Press “BASS”Button to active the deeper bass music
10.Feature Switch:
Press “BASS”Button and hold for 2 seconds to switch the modes between the Bluetooh and Micro SD card
reading.

1. AUX-in / AUX-out
For an optional wired connection use the provided
jack-to-jack cable
2. USB charging slot QC3.0 Quick charge
To fast charge USB device
3. USB charging slot (5V 2.1A)
To charge USB device
4. Micro SD Card slot
Play music from Micro SD
5. Display
6. / 12
• Play / pause
• Answer phone
• Double tab: reject incoming call or redial last
number
7. Channel
+/- set the channel to an empty fm-band. Tune
your car-radio to the same freq.
8. Bass boost button
• Short press for extra bass
• Press & hold 2 sec to change input to Bluetooth
/ Micro SD
9. Previous / Next
Volume - / +

Latest declaration form can be found at:
www.caliber.nl/media/forms/PMT564BT.pdf
GB Caliber hereby declares that the item PMT564BT is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU (RED), and 2011/65/EU (RoHS).
FR Par la présente Caliber déclare que l’appareil PMT564BT est conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 2014/53/EU (RED), et 2011/65/EU (RoHS).
DE Hiermit erklärt Caliber, dass sich das Gerät PMT564BT in Übereinstimmung mit den grundlegenden Anforderung und
übrigeneinschlägigenBestimmungenderRichtlinie2014/53/EU(RED),und2011/65/EU(RoHS)bendet.
IT Con la presente Caliber dichiara che questo PMT564BT è conforme ai requisiti essenziali ed alle alte disposizioni
pertinenti stabilite dalla directtiva 2014/53/EU (RED), e 2011/65/EU (RoHS).
ES Por medio de la presente Caliber declara que el PMT564BT cumple con los requisitos esenciales y otra disposiciones
aplicables o exigibles de la Directiva 2014/53/EU (RED), y 2011/65/EU (RoHS).
PT Caliber declara que este PMT564BT está conforme com os requisitos essenciais e outras disposições da Directiva
2014/53/EU (RED), e 2011/65/EU (RoHS).
SHärmed intygar Caliber att denna PMT564BT Pro står i överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 2014/53/EU (RED), och 2011/65/EU (RoHS).
PLNiniejszymCaliberoświadcza,źePMT564BTjestzgodnezzasadniczymiwymaganiamiorazinnymistosownymi
postanowieniami Dyrektywy 2014/53/EU (RED), i 2011/65/EU (RoHS).
DK Undertegnede Caliber erklærer hermed, at følgende udstyr PMT564BT overholder de væsentlige krav og øvrige
relevante krav i direktiv 2014/53/EU (RED), og 2011/65/EU (RoHS).
EE Käesolevaga kinnitab Caliber seadme PMT564BT vastavust direktiivi 2014/53/EU (RED), ja 2011/65/EU (RoHS).
pöhinõuetele ja nimetatud direktiivist tulenevatelle teistele asjakohastele sätetele.
LT Šiuo Caliber deklaruoja, kad šis PMT564BT atitinka esminius reikalavimus ir kitas 2014/53/EU (RED), ir 2011/65/EU
(RoHS).Direktyvos nuostatas.
FI Caliber vakuuttaa täten että PMT564BT tyyppinen laite on direktiivin 2014/53/EU (RED), ja 2011/65/EU (RoHS). oleellis-
ten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
ISHérmeðlýsiCaliberyrϸviaðPMT564BTerίsamræmiviðgrunnkröfurogaðrarkröfur,semgerðareruítilskipun
2014/53/EU (RED), og 2011/65/EU (RoHS).
NO Caliber erklærer herved at utstyret PMT564BT er i samsvar med de grunn-leggende krav og øvrige relevante krav i
drektiv 2014/53/EU (RED), og 2011/65/EU (RoHS).
NL Hierbij verklaart Caliber dat het toestel PMT564BT in overeenstemming is met de essentiële eisen en de andere
relevante bepalingen van richtlijn 2014/53/EU (RED), en 2011/65/EU (RoHS).

WWW.CALIBER.NL
CALIBER EUROPE BV • Kortakker 10 • 4264 AE Veen • The Netherlands
