Calibre HQView-2xx Series User manual

HQView-2xx Series
Operating Instructions
Version 2.41

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: techsuppo[email protected]
This manual explains how to operate your HQView-2xx Series (HQView-2xx) image scaler. The
HQView-2xx Series comes in two versions HQView-200S and HQView-210. HQView-2xx is
designed to provide users with a powerful and flexible method of driving large display devices
from SD-SDI, HD-SDI and 3G-SDI source.
If you have any queries relating to this or any other product supplied by Calibre please visit
our web site www.calibreuk.com.
For technical support please e-mail [email protected] or send your queries by fax to
(44) 1274 730960, for the attention of our Technical Support Department.
COPYRIGHT
This document and the software described within it are copyrighted with all rights reserved. Under
copyright laws, neither the documentation nor the software may be copied, photocopied, reproduced,
translated, or reduced to electronic medium or machine readable form, in whole or in part, without
prior written consent of Calibre UK Ltd ("Calibre"). Failure to comply with this condition may result in
prosecution.
Calibre does not warrant that this product package will function properly in every hardware/software
environment.
Although Calibre has tested the hardware, firmware, software and reviewed the documentation,
CALIBRE MAKES NO WARRANTY OR REPRESENTATION, EITHER EXPRESS OR IMPLIED,
WITH RESPECT TO THIS HARDWARE, FIRMWARE, SOFTWARE OR DOCUMENTATION, THEIR
QUALITY, PERFORMANCE, MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE.
THIS SOFTWARE AND DOCUMENTATION ARE LICENSED 'AS IS', AND YOU, THE LICENSEE,
BY MAKING USE THEREOF, ARE ASSUMING THE ENTIRE RISK AS TO THEIR QUALITY AND
PERFORMANCE.
IN NO EVENT WILL CALIBRE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE
SOFTWARE OR DOCUMENTATION, even if advised of the possibility of such damages. In
particular, and without prejudice to the generality of the foregoing, Calibre has no liability for any
programs or data stored or used with Calibre software, including costs of recovering such programs or
data.
Calibre UK Ltd
Cornwall House, Cornwall Terrace
Bradford, West Yorkshire
BD8 7JS, England
Telephone [phone]
Fax + 44 (0)1274 730960
Email [e-mail]
Web-site www.calibreuk.com
Copyright (c) 2013 All World-wide Rights Reserved
All trade marks acknowledged
Calibre operates a policy of continued product improvement, therefore specifications are subject to
change without notice as products are updated or revised.
E&OE.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected]
Contents
SAFETY WARNING: 1
INTRODUCTION 2
1.1. General Introduction 2
1.2. Packing List 2
HQVIEW-2XX SYSTEM DESCRIPTION 3
2.1. Product Overview 3
2.2. Product Specification 3
2.2.1. Power Supply Requirement 3
2.2.2. 3GSDI Input 3
2.2.3. Display Output 3
HQVIEW-2XX CONTROL 4
3.1. Menu Tree 4
3.2. Introduction 7
3.3. Main Menu 8
3.4. Input 8
3.5. Output 9
3.5.1. Output Mode 9
3.5.2. Location 9
3.5.3. Optimize for Display 9
3.5.4. DVI Range 9
3.5.5. Frame Rate 10
3.5.6. (Available) Frame Rates 10
3.5.7. I/O Lock 10
3.5.8. Native Color Temp 10
3.5.9. Output Gamma 11
3.6. Colour 11
3.6.1. Black-Level Offset 11
3.6.2. Black-Level 11
3.6.3. Contrast 11
3.6.4. Saturation 11
3.6.5. Hue 11
3.6.6. RGB values 11
3.6.7. Colour Temp 11
3.6.8. RGB values 12
3.6.9. Input Gamma 12
3.7. Geometry 12
3.7.1. Horizontal/Vertical Position 12
3.7.2. Aspect Ratio 12
3.7.3. Warp 12
3.7.4. Picture Format 13
3.7.5. Overscan 13
3.7.6. Pan Tilt Zoom 13
3.8. Enhancement 14
3.8.1. Sharpness 14
3.8.2. Detail 14
3.8.3. Video Filters 14
3.9. System 15
3.9.1. User 15
3.9.2. Names/Profiles 15
3.9.3. Test Pattern 15
3.9.4. Display Mode 15
3.9.5. Switching Transition 15
3.9.6. Menu Settings 16
3.9.6. Network Settings 17
3.9.7. Factory Defaults 17
REMOTE CONTROL WEB SERVER 18
4.1. Introduction 18
4.2. Installing the Software 18

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected]
4.3. Discovery Tool 18
4.4. Software Operation 18
FIRMWARE UPDATE 19
5.1. Introduction 19
5.2. Updating Firmware 19
ENVIRONMENTAL AND EMC 20
6.1. Recommended Operating Conditions 20
6.2. Storage 20
6.3. CE and FCC Compliance 20
6.4. PAT Testing 20

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 1
SAFETY WARNING:
1. THERE ARE NO USER SERVICEABLE PARTS WITHIN THE UNIT. REMOVAL OF THE TOP COVER
WILL EXPOSE DANGEROUS VOLTAGES. DO NOT OPERATE THE UNIT WITHOUT THE TOP COVER
INSTALLED.
2. ENSURE THAT ALL ELECTRICAL CONNECTIONS (INCLUDING THE MAINS PLUG AND ANY
EXTENSION LEADS) ARE PROPERLY MADE AND COMPLY WITH ELECTRICAL SAFETY
REGULATIONS.
3. ENSURE THAT THE INTEGRITY OF THE EQUIPMENT ISOLATION BARRIER IS MAINTAINED WHEN
CONNECTING TO OTHER EQUIPMENT. THIS MEANS THAT ONLY LOW VOLTAGE ISOLATED
CIRCUITS MAY BE CONNECTED TO THE SIGNAL INPUTS AND OUTPUTS. IF ANY DOUBT EXISTS
CONSULT QUALIFIED SERVICE PERSONNEL.
4. TO PREVENT SHOCK OR FIRE HAZARD DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE. IF SUCH EXPOSURE OCCURS, REMOVE THE PLUG FROM THE MAINS OUTLET AND
HAVE THE EXPOSED UNIT CHECKED BY QUALIFIED SERVICE PERSONNEL.
5. DO NOT CONTINUE TO OPERATE THE EQUIPMENT IF YOU HAVE ANY DOUBT ABOUT IT
WORKING NORMALLY, OR IF IT IS DAMAGED IN ANY WAY. WITHDRAW THE MAINS PLUG FROM
THE MAINS OUTLET AND CONSULT QUALIFIED SERVICE PERSONNEL.
6. DO NOT REMOVE ANY FIXED COVERS UNLESS YOU ARE QUALIFIED TO DO SO AND EVEN THEN
WITHDRAW THE MAINS PLUG FROM THE MAINS OUTLET BEFORE YOU START.
7. THIS EQUIPMENT CONTAINS NO USER SERVICEABLE PARTS. REFER ALL SERVICING AND
MAINTENANCE TO QUALIFIED SERVICE PERSONNEL.
8. TO AVOID EXPLOSION, DO NOT OPERATE THIS EQUIPMENT IN AN EXPLOSIVE ATMOSPHERE

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 2
INTRODUCTION
1.1.
General Introduction
HQView-2xx is a very flexible image scaler developed specifically for driving large screen displays from
SD-SDI, HD-SDI and 3G-SDI serial digital source.
HQView-2xx features state of the art digital image processor which provides market leading HD& SD
per-pixel multiple Iow-angle motion-adaptive de-interlacing and automatic film pull-down correction for
3:2 and 2:2, significantly outperforming the capabilities of benchmark competitor products.
HQView-2xx features excellent image processing algorithms for the very best scaling, film and video
noise reduction and MPEG artefact reduction.
HQView-2xx uses a high performance SDI de-serializer with cable equalization.
The output format can be set to I/O Lock mode where it locks the output frame rate to the input frame
rate dynamically without frame rate conversion so as to reduce system latency, or it can be set to a fixed
output frame rate for driving basic screens which are not 50Hz-compatible. Furthermore, the HQView-
100 can be set to have the output resolution match the input resolution to preserve aspect ratio. A Low
latency mode with non-motion adaptive reduced processing is available to further reduce latency.
Outputs are available in DVI digital formats.
HQView-2xx (type V2) supports Pan, Zoom and Tilt to select a part of the input image, fill the screen
and pan within it.
HQView-210 features embedded warp functions to adjust the image in a projection scenario to match a
rotated, tilted or curved screen. For 9:16 portrait mode signage special predefined warp maps are
available to rotate and stretch a video image to fill a +/-90° rotated display panel.
System control is via an OSD controlled by keys on the front panel or through an intuitive ‘Windows’
application connected via a normal RS232 serial port or via TCP/IP (ethernet).
1.2.
Packing List
HQView-2xx is supplied with the following:
1) This manual
2) 3 pin plug IEC mains cable
3) DVI-D output cable
4) CD

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 3
HQVIEW-2XX SYSTEM DESCRIPTION
2.1.
Product Overview
HQView-2xx is designed to accept the input signals:
3GSDI/HDSDI/SDI (Serial Digital Interface) via BNC
2.2.
Product Specification
This section provides technical details of the HQView-100 input and output connections.
2.2.1.
Power Supply Requirement
12V DC table top power supply requiring a 100V-264VAC 50/60Hz mains connection.
2.2.2.
3GSDI Input
Format: SD-SDI
HD-SDI YCbCr 4:2:2 serial digital component video
3G-SDI 4:2:2 serial digital component video
Input impedance: 75 ohms.
SMPTE 292M, SMPTE 259M-C and SMPTE 424M compliant, accepts 484i, 576i, 720, 1080i and 1080p
single link formats at 270Mb, 1.485Gb or 2.97Gb rates.
2.2.3.
Display Output
A DVI-D output connector is provided. The DVI-D connector will support HDMI 1.3 with 36-bit video
when connected to a suitable HDMI 1.3 receiver.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 4
HQVIEW-2XX CONTROL
3.1.
Menu Tree
HQView-200S Menu Tree
1st Level
2nd Level
3rd Level
4th Level

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 5

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 6
HQView-210 has an additional Warp Menu.
1st Level
2nd Level
3rd Level
4th Level

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 7
3.2.
Introduction
The HQView-2xx units have the input connector on one side of the housing and the output connector as
well as the communication ports on the opposite side. The keypad for controlling HQView-2xx is located
on the input connectors side. The active input is indicated by their corresponding triangles lit green.
1 –Keypad with three keys for OSD menu navigation (Menu, Down and Up).
With the Menu key the OSD menu is activated. The up/down keys are used for OSD menu navigation.
To exit the OSD menu or any submenu navigate go to the Exit item and press the menu key. To access
a submenu navigate to it and press the menu key. To apply a change go to the menu item, press the
menu key and make a parameter change with the up/down key. Confirm the change by pressing the
Menu key. This will also bring you back to the submenu.
The active channel is indicated by the associated green lit triangle(s). This is always the 3G-SDI input.
With the following multiple key presses further functions can be applied:
Keypad unlock: Up/Down
Set output and fallback output mode to VGA: Menu/Up
Mode reset: Menu/Down
Factory reset: Menu/Up/Down
A factory reset can also be applied when pressing the factory reset key combination at power up. The
keys have to be kept pressed for about 10 seconds until the 3GSDI input LED stops flashing. If the keys
are released during that 10 seconds period the system will get into Updater mode (see chapter 5) since
the Menu key is part of this key combination.
4
5
6
7
8
1
2

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 8
2 –3G-SDI input 3 –Number intentionally not used
4 –DVI-I output connector (only the digital DVI-D is supported, HDMI 1.3 receivers can be connected
with a DVI/HDMI adapter cable)
5 –TCP/IP port 6 –USB port
7 –RS232 port 8 –Power supply connector
3.3.
Main Menu
The main menu lists 5 sub menus. The 5 sub menus are Output, Colour, Geometry, Enhancement and
System.
On each menu page an Exit menu item is available to leave the menu or submenu. Some adjustments
are not applicable to all signal types or operating modes, in which case those non-applicable functions
will be ghosted and are not accessible via the menus.
All menus have a top status line and a bottom line indicating the firmware revision number. In the status
line the currently selected input channel is indicated and the detected mode is identified. The firmware
revision number displays the revision number of the bootloader behind BL, the revision number of the
firmware behind FW and whether it is a 200S or 210 HQView unit.
To set up your HQView-2xx it is recommended that you follow this procedure:
Choose the correct output mode and parameters to suit your screen or projector.
Set the input levels and features appropriately to optimize the appearance of your image.
Set any other parameters to suit your application.
Note: All Input parameters are specific to your chosen input channel and input signal type, they are not
global to the unit. All Output parameters are global
3.4.
Input
The list of available inputs can be scrolled through using the Up and Down keys. The new input is not
selected until the Menu key is pressed.
The list of inputs are: 3G-SDI and Test Pattern.
Test patterns can be generated by HQView-2xx without needing an input connected. When Test Pattern
is selected as the input, the required test pattern can be chosen with the menu navigation up/down keys
when the OSD menu is off.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 9
3.5. Output
This menu contains adjustments associated with setting up outputs from the unit. Most items are
collected in the Display Type submenu. Use the up and down keys to scroll to the required item and
press the Menu key.
3.5.1. Output Mode
Settings: 640x480, 800x600, 1024x768, 1280x768, 1280x800, 1280x1024, 1360x768, 1366x768,
1400x1050, 1440x900, 1600x1200, 1680x1050, 1920x1200, 720p (1280x720), 1080p (1920x1080),
480p (720x480), 576p (720x576)
Set up the desired output resolution with output mode. The output mode setting should match the native
resolution of the imaging device to avoid double scaling.
3.5.2. Location
Settings: Front Tabletop, Front Ceiling, Rear Tabletop, Rear Ceiling
The image can be flipped to accommodate different projection scenarios as well as screens mounted
upside down.
3.5.3. Optimize for Display
Settings: DVI forced, Optimized, DVI/HDMI
Internally, the display interface processes data at a full ten bits per colour. The colour depth on the DVI-
D output is determined by the supported standard of the attached monitor or device when set to
DVI/HDMI. For DVI 1.0 and HDMI 1.1/1.2 devices it is 24 bit, for HDMI 1.3 compliant devices it is up to
36 bit.
DVI forced will output with 24 bit colour depth irrespective of the supported standard of the attached
monitor.
When the Optimized setting is enabled the output resolution is automatically set to the native screen
resolution of the attached display if the Aspect Ratio menu item was chosen to Scale or when no input is
detected. The colour depth is determined in the same way as when set to DVI/HDMI.
3.5.4. DVI Range
Settings: Default, Limited, Full
When set to Default CEA output modes have limited range, and VESA modes have full range.
Therefore, an incoming limited range mode is either passed through when the output is set to a CEA
output mode or expanded when the output is set to a VESA mode. An incoming full range mode is either
compressed when the output is set to a CEA output mode or passed through when the output is set to a
VESA mode.
If the HDMI/DVI output does not behave as expected, e.g. because the HDMI display is not evaluating
AVInfoFrames properly, the range can be changed manually.
A limited video range is only using the following greyscale for video information - 8 Bit System: 0x10 ..
0xEF, 10 Bit System: 0x040 .. 0x03BF, 12 Bit System: 0x100 .. 0xEFF.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 10
3.5.5. Frame Rate
Settings: 60 Hz, 50 Hz, 48 Hz, 24 Hz, Auto
In auto mode the output frame rate follows the input frame rate as configured in the Frame Rates menu.
Signals with 24Hz, 25H, 48Hz, 50Hz input modes get special treatment, modes with other refresh rates
are displayed at 60Hz.
24Hz input modes will be output at 24Hz if the output resolution is set to either 720p or 1080p and the
Frame Rate setting in the Output Config menu includes 24Hz, otherwise it is displayed at twice the rate
if the Frame Rate setting in the Output Config menu includes 48Hz.
Otherwise a 24Hz input mode is displayed at 60Hz. 48Hz input modes will be output at 48Hz if the
Frame Rate setting in the Output Config menu includes 48Hz.
Otherwise it is displayed at 50Hz.
A 25Hz input mode is output at twice the frame rate 50Hz.
An exception to the 24/25Hz input mode treatment is if the output resolution is set to 480p. 480p is
always run at 60Hz output rate.
50Hz input modes are displayed at 50Hz output rate.
The output frame rate can also manually set to 24Hz, 48Hz, 50Hz or 60Hz if possible, i.e. such output
modes are available.
Only 720p and 1080p output modes are available with 24Hz refresh rate.
The 480p output mode is only available at 60Hz refresh rate.
For all other modes 48Hz, 50Hz and 60Hz refresh rate is available.
3.5.6. (Available) Frame Rates
Settings: 60/50 Hz, 60/50/24 Hz, 60/50/48, 60/50/24/48
Limits the possible output frame rates that can be selected. It is primarily to be able to limit the choices
available for the Auto refresh rate configuration.
3.5.7. I/O Lock
Settings: On, Off
If I/O Lock is switched off the output is run with a fixed refresh rate determined by the frame rate setting,
which deviates from the input refresh rate, even if both are nominally at the same rate. This causes
occasional frame dropping or repeat. If I/O Lock is on the output refresh rate is following the input
refresh rate. This is achieved by modulating the output clock and works if input and output refresh rate
are nominally at the same rate, e.g. when frame rate is set to 60Hz and the video input is also 60Hz. If
e.g. the video input rate is 50 Hz and the Frame rate is set to 60Hz, the output is in free run mode. The
status line of the OSD window under Sync Mode indicates if the output signal is locked to the input
signal (I/O Locked) or in free run mode (Free Run) .
3.5.8. Native Color Temp
Settings: 5500, 6500, 7500, 9300, 10000
Native Color Temp allows the user to select from pre-configured color temperatures to match the
display. If both Native Color Temp set here in the Output menu and Color Temp set in the Color menu
are set to the same value, no conversion is performed.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 11
3.5.9. Output Gamma
Settings: 1.0 to 3.0 in steps of 0.1
Output gamma allows to re-gamma video signals with pre-configured gamma values to match the
display. Input gamma and output gamma both default to 2.2. If they are both set to the same value,
there is no effect on the image.
Note: If e.g. an adjustment to reduce the level of red in the image is required, select a higher number for
the (input) Color Temp in the Color menu, or a lower number for the Native Color Temp in the Output
menu.
3.6. Colour
This menu contains adjustments associated with setting up inputs to the unit. Use the Up and Down
keys to scroll to the required item and press the Menu key.
3.6.1. Black-Level Offset
Settings: 0 IRE, 7.5 IRE
Used to select 7.5 IRE black level set-up adjustment.
3.6.2. Black-Level
Settings: -50 to 50 in steps of 1
Black level controls the offset applied to the video signal.
3.6.3. Contrast
Settings: -50 to 50 in steps of 1
Contrast controls the gain applied to the video signal.
3.6.4. Saturation
Settings: -50 to 50 in steps of 1
Control of video saturation, applies to all video inputs but not computer input signals or formats.
3.6.5. Hue
Settings: -50 to 50 in steps of 1
Control of video hue, applies to all video inputs but not computer input signals or formats.
3.6.6. RGB values
This is a user-defined colour temperature setting whereby individual R,G,B gain and offset (bias) can be
set so as to accurately calibrate a particular input to the display device.
3.6.7. Colour Temp
Settings: 5500, 6500, 7500, 9300
Colour Temp allows the user to select from pre-configured colour temperatures to match the colour
temperature of the incoming signal. If both Colour Temp set here in the Colour menu and Native Colour
Temp set in the Output menu are set to the same value, no conversion is performed.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 12
3.6.8. RGB values
This is a user-defined colour temperature setting whereby individual R,G,B gain and offset (bias) can be
set so as to accurately calibrate a particular input to the display device.
3.6.9. Input Gamma
Settings: Gamma 1.0, Gamma 1.5, Gamma 2.2, Gamma 2.8
Set this value to match the native gamma of the input signal. Input gamma and output gamma both
default to 2.2. If they are both set to the same value, there is no effect on the image.
3.7. Geometry
This menu contains adjustments associated with setting up position, aspect ratio and scale of the input
signal. Scale can be as simple as an overscan up to arbitrarily warping the image.
3.7.1. Horizontal/Vertical Position
Settings: in steps of 1 pixel/line
Change the positional values to match the display boarders.
3.7.2. Aspect Ratio
Settings: Scale, Preserve
The system can be set to scale the input image to a fixed output resolution or, with the setting preserve,
to choose an output resolution matching the input resolution. If no matching output resolution is
available or no input is detected, the pre-defined output resolution is used though.
3.7.3. Warp
Note: Embedded Warp is only available with HQView-210.
Submenu for warping the image. The warp applications are Keystone, 4-Corner and Rotation. Special
portrait warp applications for clockwise (90°) and counter-clockwise (270°) rotation with scaling are
provided as well.
Under the Keystone application the image can be adjusted to match a horizontally and vertically tilted
screen. Also, Pin/Barrel distortion of the lens or screen can be adjusted simultaneously.
Under the 4-Corner application all corners can be moved and the image is calculated to fit into the given
trapezoid.
The Rotation application let you rotate the image from -180 to 180 degree (one full circle). At the same
time Pin/Barrel distortion of the lens or screen can be adjusted again.
Predefined warp maps for portrait mode applications are provided. A 9:16 input image area is rotated
and scaled such that is fills a 16:9 screen.
For convenience all settings can be reset with one button provided in the submenus.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 13
3.7.4. Picture Format
Settings: Standard, Full Screen, Crop, Anamorphic
Picture Format allows a user to select the displayed aspect ratio where the signal input is at variance
with the display panel’s natural aspect ratio. Note that some aspect ratios may not be applicable to all
signal types, in which case selecting a non-applicable aspect ratio conversion will have no effect on the
displayed image. E.g. when a 16:9 image is displayed on a 16:9 panel all settings give an identical full
screen image.
Standard preserves the aspect ratio of the incoming image and scales the image to fit into the size of
the panel. Dependant on the aspect ratio of the panel the image is either bordered by the right/left side
or bottom/top of the panel. Non-used areas of the panel are displayed black (letterboxed). Full Screen
scales the image to the size of the panel without preservation of the aspect ratio. Crop preserves the
aspect ratio and scales the image to fit the screen. Dependant on the aspect ratio of the panel either the
top/bottom or right/left areas of the image are cropped. Anamorphic scales the input image such that it
is displayed with a 16:9 aspect ratio when displayed on the screen. The image is further scaled to fit into
the size of the panel. Dependant on the aspect ratio of the panel the image is then either bordered by
the right/left side or bottom/top of the panel. Non-used areas of the panel are displayed black
(letterboxed).
3.7.5. Overscan
Settings: 0 to 10 in steps of 1
Overscan is used to slightly zoom into the image. Thus, the border area of an image is no longer
displayed on the screen. This cuts off unwanted features at the top or bottom from e.g. video images.
3.7.6. Pan Tilt Zoom
This menu provided settings to zoom and shrink the image, as well as panning within the image.
Pan Tilt Zoom (PTZ) can be switched on or off. When switching on the latency of the system is
increased by one frame. Thus, there is a difference of a PTZ setting off or on with no zoom. PTZ
settings can be saved per mode or globally, i.e. the same PTZ settings are applied when switching input
channels or changing the input mode.
The Zoom slider allows to zoom into the image or shrink it. When Aspect Lock is set to On the separate
slider for zooming vertically is greyed out and the horizontal zoom or shrink factor is used as vertical
factor as well. The aspect ratio is preserved. When Aspect Lock is Off horizontal and vertical scaling
factors can be chosen separately.
With the Pan and Tilt sliders panning within the image in horizontal and vertical direction is possible. Off
raster panning is allowed, i,e, the image can be shifted outside the active area of the display.
For convenience the PTZ settings can be reset with one button.
Note: HQView-2xx V2 excels original HQView-2xx hardware. PTZ is only available on HQView-2xx V2
hardware (check the serial number batch for HQView-2xx or HQView-2xx V2 marking, the product
name as indicated by the top label is HQView-2xx with no further extensions in either case). Firmware
for HQView-2xx V2 also operates on HQView-2xx hardware, only the PTZ menu is greyed out.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 14
3.8. Enhancement
The enhancement menu provide image enhancement functions. Note that the enhancement settings
apply to video input signals only, not computer graphics signals.
3.8.1. Sharpness
Settings: -50 to 50 in steps of 1
Control of the sharpening enhancement filters' levels. These are peaking filters to improve high-
frequency response. Note that setting this control too high on a signal which already has good high
frequency response will cause ringing or ghosting.
3.8.2. Detail
Settings: 0, 1, 2, 3
This filter provides powerful 2D image enhancement which can be used to greatly improve detail
definition and clarity without causing image ringing or ghosting. It improves both horizontal and vertical
detail. Correct setting of the detail enhance filter can make SD signals look virtually indistinguishable
from true HD. At setting 0 the filter is switched off, with setting 3 providing the highest effect.
3.8.3. Video Filters
The video filters menu provides LTI/CTI filters and TRNR/MNR noise reduction filters.
The LTI filter enhances the sharpness of the luminance component. The CTI filter enhances the colour
sharpness of the chrominance signal by increasing the steepness of colour edges.
TRNR (Temporal Recursive Noise Reduction) and MNR (Mosquito Noise Reduction) are available for
SD input signals only. These filters reduce spatial and temporal noise as well as block artifacts.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 15
3.9. System
This selection contains functions which are more applicable to system operation than to picture
adjustment.
3.9.1. User
Settings: USER 1, 2, 3, 4
A predefined setting stored under a user name can be selected. Several settings of the HQView-2xx
can be stored under a user name. Thus, different users can store their preferred HQView-2xx settings
and recall these profiles by picking up their user name from this menu.
Note: Using the Web interface, (any number of) settings can also be stored/restored to/from a PC disc
drive. This feature is only available on V2 hardware
3.9.2. Names/Profiles
The Names/Profiles menu provides input masks to rename the generic input channels and user names.
User names and input channel names can be changed to any word with a maximum of 12 alpha
numeric characters with a value range of 0-9, A-Z and blank.
The Names/Profiles menu allows the user to store profiles under a certain user name. It also allows to
copy user profiles by loading a profile stored under one user name and save it under another user
name. Reset Profile allows to restore default HQView-4xx settings for the currently selected user.
3.9.3. Test Pattern
Settings: Grey V Bars, Grey H Bars, Aspect Test, Multi Test, Warp Adjust, SMPTE, PLUGE
List box to choose a test pattern. When the OSD menu is off the test pattern can be toggled through by
pressing the up and down keys of the keypad.
3.9.4. Display Mode
The “Display Mode” can be set to either Low Latency or Best Picture. In Best Picture optimum image
processing is applied, whereas in Low Latency mode the lowest latency is achieved. The flicker of
interlaced video is not suppressed totally for the latter setting. Thus it has the disadvantage of
conventional CRT TVs, but also their advantage of almost no delay in response, which is important for
applications such as gaming, simulation or imaging in medical treatment.
3.9.5. Switching Transition
When switching input channels (here 3GSDI and Test Pattern only) by default the last frame of the prior
displayed image is frozen and displayed until a stable image of the new input channel can be shown.
The switchover process is supposed to be as seamless as possible. The source and monitor add
switching noise due to unforeseeable activity of the firmware in said devices. By default HQView is in
auto frame rate switching and I/O lock mode. In order to get a best smooth switching result with the
source and monitor I/O lock and auto frame rate switching have to be switched off in the Output/Display
Type menu.

©Calibre UK Limited Issue 2.41 04th November 2013, W: www.calibreuk.com
T:[phone] F: [phone] E: [email protected] 16
3.9.6. Menu Settings
This menu provides items to change the menu position and menu display time, i.e. the time after which
the OSD is switched off again with no user interaction. OSD Messages can be activated and
deactivated.
The menu language can be altered and the keypad can be locked. To unlock the keypad a combination
of keys has to be pressed at the same time. The locking of the keyboard is accompanied by the
message: Keypad is locked. Press Menu/Up/Down to unlock. When successfully unlocking the keypad
the message shows up: Keypad unlocked.
